Selective C-C Bond Formation on the First
Ketene-Alkyne Complexes
H. C. Lo and Douglas B. Grotjahn*
Warming of either diphenylketene complex 18 (Scheme 1)
with alkyne 2 or of diphenylketene 4 with alkyne complex 59
led to a mixture containing free P(i-Pr)3 and the monophosphine
complex 3 in a molar ratio of 1:1.10 A series of NMR
experiments implicate the formulation shown for 3.11 For
example, by using 2D NMR, resonances for all 10 aryl protons
of 3a could be found between 6.98 and 8.25 ppm, showing that
C-H activation (Vide infra) had not yet occurred. Inequivalent
alkyne CH3 groups were revealed by sharp three-proton singlets
at δ 1.95 and 2.33 ppm. HMBC (1H, 13C) showed that the
acetylenic carbons resonated at 164.79 (d, J ) 9.1 Hz) and
144.07 (s) ppm.12 These data and a second narrow 13C{1H}
doublet at 118.74 (d, J ) 4.9 Hz) due to a ketene carbon verify
the presence of one phosphine, cis to both ketene and alkyne.12
The acetylenic carbons in 3a appear far downfield from those
in 5a (δ 56.83), consistent with replacement of trans-Cl in 5a
with the π-acid ketene. Binding of the ketene to Ir in 3a is
implicated by a significant cross peak in the HMBC spectrum
between the C)C)O carbon at 204.87 ppm and the alkyne
protons at 1.95 ppm, and the chemical shifts of the CdCdO
carbons are more consistent with coordination to the CdC
bond.13 Finally, and most significantly, η2-binding of the metal
to the ipso and ortho carbons of one ketene C6H5 substituent is
indicated by two sets of data: (1) the upfield shifts of the ortho
proton resonances [δ 6.98 Vs 8.25 ppm for those on the
uncoordinated ring]; (2) the upfield shifts and splitting of the
ipso and ortho carbon resonances [coordinated ring, ipso δ
118.42-118.60 (narrow unresolved m), ortho 118.74 (d, J )
4.9 Hz); uncoordinated ring, ipso 142.82 (s) and ortho 130.99
(s)]. The equivalence of the ortho and meta protons and carbons
on the coordinated C6H5 ring implies a rapid rotation of the
ring, as documented in some other η2-arene complexes.14
Similar spectroscopic properties were seen for other ketene-
alkyne complexes 3. As alkyne displaces P(i-Pr)3 from 1 to
give 3, the profound change in ketene binding, particularly η2-
arene coordination, presages regiospecific C-H bond activa-
tion15 of the ketene at an ortho position.
Department of Chemistry and Biochemistry
Arizona State UniVersity
Box 871604, Tempe, Arizona 85287-1604
ReceiVed October 28, 1996
Metal π-complexes of alkynes1 and of ketenes2 are key
intermediates in reactions capable of constructing synthetically
challenging organic molecules.3,4 Metal-mediated redox ho-
mocoupling of alkynes (to give metallacyclopentadienes A) is
a reaction of wide scope at the heart of syntheses of dienes,
arenes, heterocycles, and other organic products.3a,b Only two
isolated reports of ketene homocoupling exist [B, M ) Ti or
Ni, R1-R4 ) Ph].5 Even rarer is ketene-alkyne heterocou-
pling: the clearest example is limited to the parent compounds,
giving C (M ) Ti, R1-R4 ) H),6 but organic products were
not liberated from metallacycle C. Certain organic products
from reactions of chromium carbene complexes and alkynes
could be explained by invoking ketene-alkyne coupling as in
C7a or as in D,7b although these metallacycles were not observed.
Here we report the chemo-, regio-, and stereoselective coupling
of diphenylketene with internal alkynes on Ir(I) to give irida-
benzopyrans 8 rather than C or D. In these reactions, the first
ketene-alkyne complexes 3 are formed chemoselectively.
Spectral features of 3 point to η2-arene coordination, explaining
