Formation of thiolene versus dithiolene species from TTBEO.
Crystal structures of [Au(ddtCO2Et)(PPh3)] and [Sn(ddtCO2Et)2-
Me2] {TTBEO ؍ 2,5,7,9-tetrathiabicyclo[4.3.0]non-1(6)-en-8-one;
ddtCO2Et ؍ 3-(ethoxycarbonylsulfanyl)-5,6-dihydro-1,4-dithiine-2-
thiolate}
Elena Cerrada,a J. Felipe García,a Mariano Laguna,*a Raquel Terrobab and
M. Dolores Villacampaa
a Departamento de Química Inorgánica, Instituto de Ciencia de Materiales de Aragón,
Universidad de Zaragoza-CSIC, 50009 Zaragoza, Spain
b Departamento de Química, Universidad de la Rioja, Obispo Bustamante 3, 26001 Logroño,
Spain
Received 1st July 1998, Accepted 25th August 1998
Thiolene gold() and tin() complexes such as [Au(ddtCO2R)L] [L = PPh3, PPh2Me or AsPh3; R = Et or Me;
ddtCO2R = 3-(alkoxycarbonylsulfanyl)-5,6-dihydro-1,4-dithiine-2-thiolate] and [Sn(ddtCO2R)2Me2] have been
obtained from solutions of TTBEO {2,5,7,9-tetrathiabicyclo[4.3.0]non-1(6)-en-8-one} with sodium ethoxide or
methoxide and the corresponding halogeno-complexes [AuCl(L)] and SnMe2Cl2. Reaction of the same solutions
with [N(PPh3)2]2[ZnCl4] and [ZnCl2(N–N)] [N–N = 1,10=phenanthroline (phen) or 2,2Ј-bipyridine (bipy)] afforded
the dithiolene complexes [N(PPh3)2]2[Zn(dddt)2], [Zn(dddt)(phen)] and [Zn(dddt)(bipy)] which are the trans-
metallating starting materials for the synthesis of dithiolene gold() and tin() complexes [{Au2(dddt)(AsPh3)}n],
[Au2(dddt)(PPh3)2], [Au2(dddt)(PPh2Me)2] and [Sn(dddt)Me2]. The results point to the existence of both thiolene
ddtCO2RϪ and dithiolene dddt2Ϫ species in TTBEO solutions with sodium alkoxide. The crystal structures of
[Au(ddtCO2Et)(PPh3)] and [Sn(ddtCO2Et)2Me2] confirm the presence of the ethoxycarbonylsulfanyl ligand.
S
S
Se
Se
Se
Se
S
Se
S
S
S
Se
Se
Introduction
S
S
S
Se
S
Se
Se
Metal bis(1,2-dithiolene) complexes have been widely studied
over the past two decades1,2 as precursors for molecular metals
and superconductors. Owing to their nearly planar structures
they show large third order optical non-linearities,3,4 have good
properties for optical data storage,5,6 as well as unusual mag-
netic behaviour.7,8 The most studied complexes are those con-
taining the ligand 4,5-disulfanyl-1,3-dithiole-2-thiolate (C3S5,
dmit), which gives some examples of superconductors even
at ambient pressure as α-[EDT-TTF][Ni(C3S5)2].9 Conduct-
ing salts of dithiolene metal complexes tend to show one-
dimensional structures and most of them become insulating at
low temperatures. Ligands with one to five selenium atoms
instead of sulfur in dmit derivatives, or ligands with a more
extended sulfur framework, are the two strategies to prevent
Peierls’ transition to insulators by building up two- or three-
dimensional structures. The former gives rise to a number of
new ligands such as dmise (C3S4Se), dsit (C3S3Se2), dsise
(C3S2Se3) and dsis (C3Se5)10–13 and the latter to new ligands as
dddt, 5,6-dihydro-1,4-dithiin-2,3-dithiolate, the [M(dddt)2]nϪ
complexes of which show a related structure to bis(ethylene-
dithio)tetrathiafulvalene (BEDT-TTF). The latter is a donor
organic molecule which forms superconductor salts14,15 and
some of the charge transfer salts with [M(dddt)2] have been
reported to present metallic behaviour at low temperatures.16–28
Continuing with our latest research in dithiolene gold chem-
istry and the role of dithiolene tin() and zinc() complexes as
transmetallating reagents,29–31 in this work we select TTBEO
{2,5,7,9-tetrathiabicyclo[4.3.0]non-1(6)-en-8-one} as starting
material for the synthesis of dddt complexes of gold(), zinc()
and tin(). Formation of monothiolene ddtCO2R, 3-(alkoxy-
carbonylsulfanyl)-5,6-dihydro-1,4-dithiine-2-thiolate (R = Me
S
Se
S
S
S
dsit
dsise
dsis
dmit
dmise
n-
S
S
S
S
S
S
S
S
S
S
S
S
S
M
S
S
S
[M(dddt)2]n-
BEDT-TTF
S–
SCO2R
S
S
S
S–
S–
S
S
O
S
S
S
dddt
ddtCO2R
TTBEO
or Et), derivatives occurs in competition with the more frequent
dithiolene formation as evidenced by the crystal structures of
[Au(ddtCO2Et)(PPh3)] and [Sn(ddtCO2Et)2Me2]. Preparation
of dddt2Ϫ derivatives with the same metallic centres gold()
and tin() is achieved by other preparative procedures involv-
ing transmetallation reactions through the zinc complex
[N(PPh3)2]2[Zn(dddt)2] or [Zn(dddt)(N–N)] [N–N = 1,10-phen-
anthroline (phen) or 2,2Ј-bipyridine (bipy)].
Results and discussion
The synthesis of dddt complexes by reaction of the suitable
halogenometal complexes with dddt2Ϫ solutions prepared in situ
from TTBEO and sodium ethoxide or methoxide (Scheme 1)
J. Chem. Soc., Dalton Trans., 1998, 3511–3516
3511

View Article Online
n–
S
S
S
S
S
S
S-
S-
S
S
S
S
S
S
S
S
(i)
(ii)
M
O
Scheme 1 (i) NaOR (2 equivalents) or Na in ROH (R = Me or Et);
(ii) [MCl4]nϪ
.
OR
O
S
S
S
S
Me
Sn Me
S
S
S
O
S
RO
Fig. 1 Molecule of complex 1 in the crystal with the atom numbering
