A facile synthesis of 4-Ar-2-bromopyridine and its 2,2′-bipyridine derivatives

Article abstract of DOI:10.1081/SCC-200028631

By means of selective cross-coupling of ArMgBr with 2-bromo-4-iodopyridine in the presence of a catalytic amount of Pd(PPh₃)₄, 4-Ar-2-bromopyridines were facilely one-step synthesized. These pyridine compounds were smoothly transform

Full text of DOI:10.1081/SCC-200028631

This article was downloaded by: [West Virginia University]
On: 16 April 2015, At: 01:22
Publisher: Taylor & Francis
Informa Ltd Registered in England and Wales Registered Number: 1072954
Registered office: Mortimer House, 37-41 Mortimer Street, London W1T
3JH, UK
Synthetic Communications:
An International Journal
for Rapid Communication of
Synthetic Organic Chemistry
Publication details, including instructions for
authors and subscription information:
http://www.tandfonline.com/loi/lsyc20
A Facile Synthesis of
4‐Ar‐2‐bromopyridine and Its
2,2′‐Bipyridine Derivatives
Xin‐Fang Duan a , Xiang‐Hong Li a , Fu‐You Li b &
Chun‐Hui Huang b
a Department of Chemistry , Beijing Normal
University , Beijing, 100875, China
b Institute of Advanced Materials , Fudan
University , Shanghai, China
Published online: 10 Jan 2011.
To cite this article: Xin‐Fang Duan , Xiang‐Hong Li , Fu‐You Li & Chun‐Hui
Huang (2004) A Facile Synthesis of 4‐Ar‐2‐bromopyridine and Its 2,2′‐Bipyridine
Derivatives, Synthetic Communications: An International Journal for Rapid
Communication of Synthetic Organic Chemistry, 34:17, 3227-3233, DOI: 10.1081/
SCC-200028631
To link to this article: http://dx.doi.org/10.1081/SCC-200028631
PLEASE SCROLL DOWN FOR ARTICLE
Taylor & Francis makes every effort to ensure the accuracy of all
the information (the “Content”) contained in the publications on our
platform. However, Taylor & Francis, our agents, and our licensors
make no representations or warranties whatsoever as to the accuracy,
completeness, or suitability for any purpose of the Content. Any opinions
and views expressed in this publication are the opinions and views of

the authors, and are not the views of or endorsed by Taylor & Francis.
The accuracy of the Content should not be relied upon and should be
independently verified with primary sources of information. Taylor and
Francis shall not be liable for any losses, actions, claims, proceedings,
demands, costs, expenses, damages, and other liabilities whatsoever
or howsoever caused arising directly or indirectly in connection with, in
relation to or arising out of the use of the Content.
This article may be used for research, teaching, and private study
purposes. Any substantial or systematic reproduction, redistribution,
reselling, loan, sub-licensing, systematic supply, or distribution in any form
to anyone is expressly forbidden. Terms & Conditions of access and use
can be found at http://www.tandfonline.com/page/terms-and-conditions

SYNTHETIC COMMUNICATIONSw
Vol. 34, No. 17, pp. 3227–3233, 2004
A Facile Synthesis of 4-Ar-2-bromopyridine
and Its 2,20-Bipyridine Derivatives
1
2
Xin-Fang Duan,1, Xiang-Hong Li, Fu-You Li, and
*
Chun-Hui Huang2
1Department of Chemistry, Beijing Normal University,
Beijing, China
2Institute of Advanced Materials, Fudan University,
Shanghai, China
ABSTRACT
By means of selective cross-coupling of ArMgBr with 2-bromo-4-iodo-
pyridine in the presence of a catalytic amount of Pd(PPh3)4, 4-Ar-2-bro-
mopyridines were facilely one-step synthesized. These pyridine
compounds were smoothly transformed into their 2,20-bipyridine deriva-
tives via Stille-type cross-couplings.
Key Words: 4-Ar-2-bromopyridine; 2,2-Bipyridine; 2-Bromo-4-iodo-
pyridine; Stille-coupling.
2,20-Bipyridines have been extensively used in supermolecular chemistry,
molecular biology, and photochemistry.[1,2] As a result, the efficient syntheses
*
Correspondence: Xin-Fang Duan, Department of Chemistry, Beijing Normal Univer-
sity, Beijing, 100875, China; E-mail: xinfangduan@vip.163.com.
3227
DOI: 10.1081/SCC-200028631
0039-7911 (Print); 1532-2432 (Online)
www.dekker.com
Copyright # 2004 by Marcel Dekker, Inc.

3228
Duan et al.
of these compounds have always attracted the attention of researchers. Among
various synthetic approaches to these compounds,[3,4] modern palladium(0)-
catalyzed Suzuki,[5] Negishi,[6], and Stille[7]-type cross-couplings provide
the most effective methods.
As part of our investigations, we wished to prepare a series of 4-Ar-2,20-
bipyridines or 4-Ar-40-Ar0-2,20-bipyridines. Obviously 4-Ar-2-bromopyridines
are the key building blocks for these bipyridine compounds because they can be
conveniently and flexibly built up into the required bipyridines via the above-
mentioned cross-couplings. For instance, transformations of 4-Ar-2-bromo-
pyridines into symmetrical bipyridines can be easily achieved by homo-coup-
lings,[8] while unsymmetrical bipyridines can be achieved in the following two
ways: (1) directly coupled with 2-pyridyl organometallics; (2) transformed into
the corresponding organometallics, then coupled with 2-pyridyl halides.
4-Ar-2-bromopyridines can be synthesized by reported procedures[9]
involving: (a) preparation of 4-Ar-pyridines;[8] (b) 2-amination via the Chichi-
babin reaction; (c) Sandermeyer substitution of bromide. As a linear route
with three steps, this synthetic strategy seems unattractive and inconvenient
for a variety of 4-Ar-2-bromopyridines. Very recently Bouillon[10] reported
a general synthetic approach to 4-Ar-2-bromopyridines based on the Suzuki
couplings of 2-halopyridin-4-yl-boronic acids with aryl halides. Obviously
these syntheses suffer from inconvenience of preparing boronic acids.
Recently we developed an efficient and convenient synthesis of 2-bromo-4-
iodopyridine via halogen-dance from 2-bromopyridine.[11] Therefore, we con-
sidered that a variety of 4-Ar-2-bromo-pyridines can be facilely one-step pre-
pared by selective substitutions of 2-bromo-4-iodopyridine (at 4-position)
through cross-couplings of ArMgX and 2-bromo-4-iodopyridine.
Cross-couplings of ArMgx to halopyridines performed under the catalysis
of Ni(PPh3)2Cl2 and PdCl2(dppb)2 have been reported.[9,12] During the selec-
tive cross-couplings of ArMgX to 2-bromo-4-iodopyridine (at 4-position) we
selected three readily available catalysts to promote the couplings: (a) CuI; (b)
Ni(PPh3)2Cl2; (c) Pd(PPh3)4. Experiment results revealed that the best catalyst
was Pd(PPh3)4 and the optimal temperature was 2408C. When Ni(PPh3)2Cl2
was used, the reaction consumed 2-bromo-4-iodopyridine almost completely
at 2408C in tetrahydrofuran (THF); however, the substitutions of bromine (by
ArMgX or homo-coupling) also occurred. On the other hand, in the presence
of CuI, the coupling was sluggish and incomplete with excess ArMgX at
2108C, and its optimized yield was only approximately 40%. We their pre-
pared a series of 4-Ar-2-bromopyridines in 54%–70% using Pd(PPh3)4, as
summarized in Table 1.
Having efficiently prepared 4-Ar-2-bromopyridines, we next synthesized
2,20-bipyridines through homo-couplings and the Stille-type couplings,
respectively. According to reported procedures[8] we found that the yields

Facile Synthesis of 4-Ar-2-bromopyridine
3229
of homo-couplings of 2a did not exceed 30%.[11] We found debromination
occurred seriously during the couplings. The preparations via the Stille coup-
lings were accomplished in two ways, as illustrated in Sch. 1: (1) 2a cross-
coupled with 4-RC5H3N-2-SnBu3; (2) the tributylstannyl derivative of 2a
cross-coupled with 2-Br-4-R-pyridine. These couplings were carried out accor-
ding standard procedures,[7] and the yields were moderate (as summarized in
Table 1).
In summary, by virtue of the selective cross-couplings of ArMgBr with
2-bromo-4-iodopyridine, this synthetic strategy furnishes us with an efficient
preparation of 2,2-bipyridine derivatives with only two or three steps.
EXPERIMENTAL
Melting points were measured using a RY-1 capillary melting point appar-
atus and uncorrected (China). 1H and 13CNMR spectra were recorded in CDCl3
on a 500 MHz Brucker instrument (Germany) using tetramethylsilane (TMS)
as the internal standard. Infrared (IR) spectra were recorded on a 60 FT-IR
Vaatar3 spectrometer (Italy).
General Procedure for the Syntheses of
2-Bromo-4-Ar-pyridines
A solution of 2-bromo-4-iodopyridine (2.0 g, 7 mmol), Pd(PPh3)4
(400 mg, 0.35 mmol) in 50 mL THF was cooled to 2408C. A solution of
Scheme 1.

3230
Duan et al.
d
d

Facile Synthesis of 4-Ar-2-bromopyridine
3231

3232
Duan et al.
ArMgBr (0.74 mmol) in THF was added and kept at that temperature. After
completion of the coupling [monitored by thin layer chromatography
(TLC)], the reaction was quenched by a saturated NH4Cl aqueous solution
and extracted with CH2Cl2. After dried over anhyd K2CO3, CH2Cl2 was evap-
orated and the resulting crude product was purified by flash chromatography
(petroleum-ethyl acetate-triethylamine; 180 : 10 : 1).
General Procedure for the Syntheses of 4-Ar-40-R-2,20-
pyridines via Stille-Coupling
To a solution of 2-tributylstannyl-4-R-pyridine[7] [or 4-(4-MeC6H4)-2-
tributylstannyl-pyridine] (12 mmol), Pd(PPh3)4 (500 mg, 0.44 mmol) in
50 mL xylene was added 2-bromo-4-(4-MeC6H4)pyridine (or 4-R-pyridine)
(10 mmol). The reaction mixture was stirred at 1208C–1308C under an Ar
atmosphere. After completion of the coupling (monitored by TLC), the reac-
tion was quenched by a saturated NH4Cl aqueous solution and extracted with
CH2Cl2. After being dried over anhyd K2CO3, CH2Cl2 was evaporated and the
resulting crude product was purified by flash chromatography (petroleum-
ethyl acetate-triethylamine; 180 : 10 : 1).
ACKNOWLEDGMENTS
The authors thank NHTRDP (863 Program No. 2002AA322403),
National Science Foundation of China (20221101), Shanghai Sci. Tech.
Comm. (03QB14006), and Shanghai Nanotech Promotion (0216nm040) for
financial support.
REFERENCES
1. Trawick, B.N.; Daniher, A.T.; Bashkin, J.K. Inorganic mimics of ribo-
nuclease and ribozymes: from random cleavage to sequence-specific
chemistry to catalytic antisense drugs. Chem. Rev. 1998, 98, 939.
2. Harriman, A.; Ziessel, R. Building photoactive molecular-scale wires.
Coord. Chem. Rev. 1998, 171, 331.
3. Fallaphour, R.A. An efficient and easy route to trimethyl derivatives of
2,20 : 60,200-terpyridine. Synthesis 2000, 1138.

Facile Synthesis of 4-Ar-2-bromopyridine
3233
4. Cargill Thompson, A.M.W. The synthesis of 2,20 : 60,200-terpyridine
ligands – versatile building blocks for supramolecular chemsitry.
Coord. Chem. Rev. 1997, 160, 1.
5. Miyaura, N.; Suzuki, A. Palladium-catalyzed cross-coupling reactions of
organoboron compounds. Chem. Rev. 1995, 95, 2457.
6. Amat, A.; Hadida, S.; Bosch, J. Palladium-catalyzed heteroarylation
of 1-(tert-butyl-dimethylsilyl)-3-indolylzinc chloride. Efficient synthesis
of 3-(2-pyridyl)indoles. Tetrahedron Lett. 1994, 35, 793.
7. Heller, M.; Schubert, U.S. Multi-functionalized 2,20 : 60,200-terpyridines.
Synlett 2002, 751.
` ´
8. Chambron, J.C.; Sauvage, J.P. Synthese de composes macrocyliques
´ ´
comportant deux fragment coordinants separres et differents, de type
0
´ ´
bipyridyl-2,2 et diphenyl-2,9 phenanthroline-1,10. Tetrahedron 1987,
43, 895.
9. Kelly, C.J.; Ansu, K.; Budisusetyo, W.; Ghiorghis, A.; Qin, Y.-X.;
Kauffman, M. Syntheses and philosophical properties of some
4-arypyridum salts. J. Heterocycl. Chem. 2001, 38, 11.
10. Bouillon, A.; Lancelot, J.-C.; Collot, V.; Bovy, P.R.; Rault, S. Synthesis
of novel halopyridinyl boronic acids and esters. Part 3: 2, or 3-halopyri-
din-4-yl-boronic acids and esters. Tetrahedron 2002, 58, 4369.
11. Li, X.-H. Dissertation; Beijing Normal University: China, 2003.
12. Pridgen, L.N. Dichlorobis(triphenyphosphine)nickel(Ii) catalysis of cross
coupling of Grinard reagents to halopyridines. J. Heterocycl. Chem. 1975,
12, 443.
Received in Japan January 19, 2004.
