Aniline is an important compound and a key skeletal
component in various drugs and natural products.[20] Among
could lead to a considerable improvement in yield and
selectivity (80%, para/ortho > 20/1). The other oxidants such
as (NH4)2S2O8, TBHP, and Na2S2O8 were further tested;
however, none can give better yields than that of K2S2O8 (see
the Supporting Information). Control experiments showed
that potassium persulfate and photoredox catalysts were both
indispensable for this transformation.
À
the reported direct C H trifluoromethylation reactions,
À
ortho-selective C H trifluoromethylation of anilides has
been well developed.[21] However, direct para-selective C H
trifluoromethylation has always posed
À
a
challenge.[22]
Recently, the site-selective introduction of a CF3 group onto
arenes was accomplished via the radical route reported by
Ritter et al.[23] However, only one example of a trifluoroace-
tyl-protected aniline was used as the substrate; the two-step
procedure and complex reaction conditions slightly limited
reaction feasibility. Recently, our group discovered the steric
hindrance of a ligand significantly affected site-selectivity
when the free radical reacted with aromatic rings;[24] there-
fore, a matched catalyst would coordinate with the protected
aniline, change the spatial environments of the ortho and meta
positions, and might lead to a para-selective trifluoromethy-
lation.
With the optimized reaction protocol, we next screened
protecting groups for photoredox catalyst-enabled light-
À
induced
para-selective
C H
trifluoromethylation
(Scheme 1). We found ethyl-, n-butyl-, and i-butyl-N-phenyl-
With these conditions in mind, Langlois reagent
(CF3SO2Na) was selected as the source of CF3 radicals
owing to its low toxicity and cost, and the commonly used tert-
butoxycarbonyl- protected aniline was shortlisted as the
standard substrate. First, tert-butyl carbanilate (1a) was
directly treated with CF3SO2Na (2) and potassium persulfate
(3 equiv) in the presence of the photoredox catalyst (2 mol%)
in acetonitrile at room temperature for 11 h (Table 1). The
photoredox catalysts fac-Ir(ppy)3 and Ru(Phen)3Cl2 provided
the trifluoromethylated product in low yields; meanwhile, the
ortho and para selectivity was rather poor. Several organic
photoredox catalysts, such as Eosin B, TPT (2,4,6-triphenyl-
pyrylium tetrafluoroborate), and Fluorescein were further
investigated. Interestingly, better selectivity and yield was
obtained when fluorescein was used as the catalyst. Several
fluorescein derivatives were further screened and we found
that 4,5-dichlorofluorescein (DCFS) could be used to gen-
erate the para-trifluoromethylated product 3a in 57% yield
with high site-selectivity. Next, we screened solvents including
DMSO, acetone, DCM, and DMF, and found that DMSO
Scheme 1. Comparison of different protecting groups.[a] [a] Reaction
conditions: 1 (0.2 mmol), 2 (2 equiv), DCFS (2 mol%), K2S2O8
(3 equiv), DMSO (2 mL) at room temperature (23–258C) using
irradiation with 40 W blue LEDs for 11 h, isolated yield.
carbamates to be good substrates, which led to the corre-
sponding product in good yields (3b–3e). The use of Cbz-
protected aniline resulted in a single para-trifluoromethylated
product 3e in 66% yield. Unfortunately, N-phenylbenzamide
and trifluoro-N-phenylmethanesulfonamide were completely
unreactive, along with starting material recovery. The sub-
strate 1 f, which is a key precursor of teriflunomide, could be
transformed into product 3 f with an acceptable yield. Further
study revealed that 2-benzoxazolinone was also an effective
substrate, affording a highly para-selective trifluoromethy-
lated product 3g in 57% yield.
Encouraged by these promising results, we next examined
if Boc-protected aniline derivatives could be tolerated in the
para-selective trifluoromethylation. Gratifyingly, both ortho
and meta-substituted aniline derivatives were well tolerated
and afforded the corresponding products in moderate to good
yields (Scheme 2). The functional groups, including OMe,
OEt, OBn, Me, Et, Ac, Cl, Br, and OCF3, were well tolerated
and led to the corresponding products in moderate to good
yields (5a–5k, 5m). It is noteworthy that the sensitive iodo
group on the meta-position was also a good substrate, which
led to the trifluoromethylated product 5l in 67% yields.
Unfortunately, the use of N-Boc-3-(trifluoromethyl)aniline
only afforded the trifluoromethylated product in 39% yield
(5p), along with recovery of the starting material. This is
likely due to the strong electron-withdrawing effect of the
trifluoromethyl group, which affected the reactivity of the
aromatic ring. Interestingly, when tert-butoxyacyl-protected
m-phenylenediamine 1n was used, a mixture of mono and di-
trifluoromethylated products were obtained in a total yield of
91% (m/d = 1.45). When the quantity of CF3SO2Na was
Table 1: Optimization of reaction conditions.[a]
(3a+3a’)
Yield [%]
3a/3a’
(p/o)
Entry
Photocatalyst
Oxidant
Solvent
1
2
3
4
5
6
7
8
9
fac-Ir(ppy)3
Ru(Phen)3Cl2
Eosin B
TPT
Fluorescein
DCFS
DCFS
DCFS
–
K2S2O8
K2S2O8
K2S2O8
K2S2O8
K2S2O8
K2S2O8
K2S2O8
–
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
DMSO
DMSO
DMSO
21
11
21
35
37
57
80
trace
trace
2:1
3:2
5:1
6:1
9:1
13:1
>20:1
K2S2O8
[a] Reaction conditions: 1a (0.2 mmol), 2 (2 equiv), DCFS (2 mol%),
K2S2O8 (3 equiv), DMSO (2 mL) at room temperature (23–258C) using
irradiation with 40 W blue LEDs for 11 h. Yields were based on GC with
tridecane as the internal standard.
