Full Paper
but had no effect, when it was attached to the 8-position
(entry 10).
An electron-withdrawing group such as a chloride in posi-
tion 6 decreases the catalytical activity of the quinoline ligand
(Table 1, entry 11). Interestingly, 6-bromoquinoline undergoes
a Br/Mg-exchange reaction with PhMgCl (2a), providing the
debrominated quinoline, which gave similar results to quino-
line (compare entries 3 and 12). Based on this small snapshot
of all tested ligands, the following trend could be found. Elec-
tron-donating substituents give better results than electron-
withdrawing ones. The 2-position of quinoline should not be
substituted. Electron-donating groups placed in position 6 of
quinoline are beneficial. Finally, chelating ligands such as bis-
pyridine deactivate the iron catalyst, probably due to chela-
tion. We have found that 10 mol% was the optimum amount
of isoquinoline and that most reactions were complete within
15 min at 258C. Screening of various metal salts showed that
isoquinoline was also a good ligand for Co-catalyzed cross-cou-
pling reactions.
Scheme 1. Iron-catalyzed cross-couplings of 1-chloroisoquinoline (1a) or 2-
chloropyridine (1b) with PhMgCl (2a).
have found that the arylated pyridine 3b was obtained at
a much faster rate (within 15 min) and with an increased isolat-
ed yield of 89% under these new reaction conditions
(Scheme 1). Herein, we report our full investigations on the
iron- and cobalt-catalyzed cross-coupling reactions promoted
by N-heterocyclic ligands. We describe the reaction scope as
well as some extensions allowing a direct aryl–aryl cross-cou-
pling with some special substrates.
Both FeBr3 and CoCl2 had similar activity in combination
with isoquinoline and both metal salts catalyze under these
conditions the cross-couplings between N-heterocyclic halides
and aryl- or heteroaryl-magnesium reagents.[21] Thus, 2-bromo-
pyridine (4a) reacted with the heterocyclic Grignard reagent
(2b), providing the desired pyridine (5a) in 61% isolated yield
(Table 2, entry 1). TMS-substituted 2-bromopyridine (4b) under-
goes Fe- and Co-catalyzed coupling reactions with various
electron-rich (2c) and sulfur-containing Grignard reagents (2d–
f) to furnish the respective 2,3-disubstituted bis(hetero)aromat-
ics (5b–e) in 49–91% yields (entries 2–5). Also, 2-halogenated
6-methoxypyridines (4c–d) couple well with 4-fluorophenyl-
magnesium bromide (2g) as well as the indolylmagnesium re-
agent (2b) to furnish the coupling products (5 f–g) in 65–75%
yields (entries 6–7). Bis-halogenated pyridine (4e) undergoes
cross-coupling reactions with the ester substituted phenylmag-
nesium bromide (2h) and the electron-rich nucleophile (2i) ex-
clusively at position 2 (entries 8–9). We subsequently screened
various substituted 3-arylated 2-halogenated pyridines (4 f–g)
in Fe- and Co-catalyzed Csp2–Csp2 cross-coupling reactions.
The bromopyridines (4 f–g) undergo high-yielding coupling re-
actions with Grignard reagents 2c, 2g, and 2i that result in
the 2,3-bisarylated pyridines (5j–l) in 68–82% yields (en-
tries 10–12). 4-Thienyl-2-bromopyridine (4h) is well tolerated in
these coupling reactions, resulting in various 2,4-bisarylated
pyridines (5m–o) in 65–79% yields (entries 13–15). Polyhalo-
genated 4-arylated pyridines (4i–k) undergo Fe- and Co-cata-
lyzed coupling reactions exclusively in position 2, using steri-
cally demanding aromatic Grignard reagents like mesitylmag-
nesium bromide (2m) or the Grignard reagent 2h leading to
the products (5p–r) in 65–82% yields (entries 16–18). Sensitive
functional groups, such as an alkyne, which may undergo car-
bometallation with Fe catalysis,[22] gave poor yields of cross-
coupling products. However, it was found that the use of 3%
CoCl2 and 10% isoquinoline improved this yield and allowed
the isolation of pyridine 5s in 62% yield (entry 19). Oligomeri-
sation reactions of the pyridyl halides may explain the low
yields.
The accelerating effect of isoquinoline for performing cross-
coupling reactions (see Scheme 1) led us to screen other li-
gands. We systematically examined various substituted quino-
lines and isoquinolines (Table 1). 1-Methylisoquinoline had
Table 1. Screening of various additives for the Fe-catalyzed cross-cou-
pling reaction of 2-chloropyridine (1b) with PhMgCl (2a).
Entry]
Additive
Yield of 3b [%][a]
1
2
3
without additive
isoquinoline
quinoline
40
92 (89)[b]
75
4
5
6
7
8
9
10
11
12
1-methylisoquinoline
2-methylquinoline
8-methylquinoline
6-methylquinoline
4-methoxyquinoline
6-methoxyquinoline
8-methoxyquinoline
6-chloroquinoline
6-bromoquinoline
91
67
48
82
73
82
40
58
73
[a] Yield determined after 15 min by integration of a GC chromatogram
and comparison against undecane as a calibrated internal standard.
[b] Isolated yield after purification by flash column chromatograpy.
a similar catalytic activity as isoquinoline (Table 1, entry 4). An
erosion of the rate enhancement occurs when a methyl group
is attached either to the 2- or 8-position (entries 5 and 6), and
only a slight improvement was observed when the methyl
group is attached to position 6 of the quinoline ring (entry 7).
An electron-donating methoxy group had a positive effect,
when it was placed at the 4- or 6-positions (entries 8 and 9)
&
&
Chem. Eur. J. 2015, 21, 1 – 9
