Elongation of the π-system of phthalocyanines by introduction of thienyl substituents at the peripheral β positions. Synthesis and characterization

Article abstract of DOI:10.1021/jo010384r

1,4,8,11,15,18,22,25-Octabutoxyphthalocyanines ((OBu)₈Pcs) having eight 2-thienyl (1) and [2,2′-bithiophene]-5-yl (2) groups at β positions and their zinc(II) and cobalt(II) derivatives were prepared from 2-thienyl- (3) or [2,2′-bithiophene]-5-yl (4)-substituted phthalonitriles in moderate to good yields. The electronic absorption spectra of the Pcs showed red-shifted Q-bands relative to β-unsubstituted (OBu)₈Pcs. The longer substituent, the [2,2′-bithiophene]-5-yl group, is more effective than the 2-thienyl group in enlarging the π-conjugated system of the Pcs. The ring oxidation potential obtained by cyclic voltammetry shifted cathodically with increasing chain length, indicating destabilization of the HOMOs. Due to the shift of the Q-band, 2-thienyl- and [2,2′-bithiophene]-5-yl-substituted Pcs exhibit a remarkable color change from the original green color.

Full text of DOI:10.1021/jo010384r

J . Org. Chem. 2001, 66, 6109-6115
6109
Elon ga tion of th e π-System of P h th a locya n in es by In tr od u ction of
Th ien yl Su bstitu en ts a t th e P er ip h er a l â P osition s. Syn th esis a n d
Ch a r a cter iza tion
Tsuyoshi Muto, Tetsuji Temma, Mutsumi Kimura, Kenji Hanabusa, and Hirofusa Shirai*
Department of Functional Polymer Science, Faculty of Textile Science and Technology,
Shinshu University, Tokida 3-15-1, Ueda 385-8567, J apan
hshirai@giptc.shinshu-u.ac.jp
Received April 16, 2001
1,4,8,11,15,18,22,25-Octabutoxyphthalocyanines ((OBu)8Pcs) having eight 2-thienyl (1) and [2,2′-
bithiophene]-5-yl (2) groups at â positions and their zinc(II) and cobalt(II) derivatives were prepared
from 2-thienyl- (3) or [2,2′-bithiophene]-5-yl (4)-substituted phthalonitriles in moderate to good
yields. The electronic absorption spectra of the Pcs showed red-shifted Q-bands relative to
â-unsubstituted (OBu)8Pcs. The longer substituent, the [2,2′-bithiophene]-5-yl group, is more
effective than the 2-thienyl group in enlarging the π-conjugated system of the Pcs. The ring oxidation
potential obtained by cyclic voltammetry shifted cathodically with increasing chain length, indicating
destabilization of the HOMOs. Due to the shift of the Q-band, 2-thienyl- and [2,2′-bithiophene]-5-
yl-substituted Pcs exhibit a remarkable color change from the original green color.
In tr od u ction
and another is to substitute the rings with electron
donors, thereby shifting the Q- and B-bands.16,17 Fur-
thermore, direct attachment of the Pc ring systems with
other chromophores through π-conjugated bridges tends
to alter the electronic structures.18-21 In such cases, the
Q-band of the Pcs undergoes a shift toward the near-
infrared (NIR) direction, which has been attributed to
the extension of the π-conjugation system, with concomi-
tant splitting or broadening of the Q-band.
Phthalocyanines (Pcs) are macrocyclic molecules whose
π-electron system provides their unique photophysical,
electronic, and electrical conducting properties.1,2 Re-
cently, the compounds have gained importance in opto-
electronic industry, as exemplified by their potential use
in electrophotography3,4 and optical data storage materi-
als.5,6 In addition, their properties have been considered
to have potential applications to photovoltaic cells,7,8 gas-
sensing materials,9,10 and the photodynamic therapy
(PDT) of cancer.11,12 Undoubtedly, these properties are
derived from the stability and delocalized electronic
nature of the Pc ring systems. Most of the modern uses
of Pcs are focused on the electronic properties of the
π-electron system of the macrocycles. The diversity of the
properties of Pcs has led us to develop extended Pc
derivatives. One approach to extension of the π-system
of the Pc ring is to benzoannulate the Pc molecules13-15
Much less effort has been focused on the preparation
of the Pc systems having π-conjugated groups at â
positions, such as with aromatic groups22-25 or nonaro-
matic groups.26,27 In preliminary studies by us,28 the
Q-band of a â-heteroaromatic-substituted Pc, 2,3,9,10,-
16,17,23,24-octa(2-thienyl)phthalocyanine, underwent a
red shift of about 20 nm relative to those of tetra-tert-
butylphthalocyanine. This phenomenon is considered to
be a result of a strong interaction between the π-electrons
(15) Aoudia, M.; Cheng, G.; Kennedy, V. O.; Kenny, M. E.; Rodgers,
M. A. J . J . Am. Chem. Soc. 1997, 119, 6029-6039.
(16) Kobayashi, N.; Sasaki, N.; Higashi, Y.; Osa, T. Inorg. Chem.
1995, 34, 1636-1637.
(1) Leznoff, C. C.; Lever, A. B. P. Phthalocyanines-Properties and
Applications; VCH Publishers (LSK) Ltd.: Cambridge, 1989, 1993,
1996; Vols. 1-4.
(2) Mckeown, N. B. Phthalocyanine Materials-Synthesis, Structure
and Function; Cambridge University Press: Cambridge, 1998.
(3) Law, K.-Y. Chem. Rev. 1993, 93, 449-486.
(17) Cook, M. J .; Dunn, A. J .; Howe, S. D.; Thomson, A. J . J . Chem.
Soc., Perkin Trans. 1 1988, 2453-2458.
(18) Kobayashi, N.; Higashi, Y.; Osa, T. Chem. Lett. 1994, 1813-
1816.
(4) Gregory, P. High-Technology Applications of Organic Colorants,
Plenum: New York, 1991.
(5) Emmerius, M.; Pawlowski, G.; Vollmann, H. W. Angew. Chem.,
Int. Ed. Engl. 1989, 28, 1445-1470.
(6) Ao, R.; Ku¨lmmerl, L.; Haarer, D. Adv. Mater. 1995, 7, 495-499.
(7) Whitelock, J . B.; Panayotatos, P.; Sharma, G. D.; Cox, M. D.;
Sauers, R. R.; Bird, G. R. Opt. Eng. 1993, 32, 1921-1934.
(8) Eichhorn, H. J . Porphyrins Phthalocyanines 2000, 4, 88-102.
(9) Snow, A. W.; Barger, W. R. Phthalocyanines-Properties Applica-
tions; Lever, A. B. P.; Leznoff, C. C., Eds.; VCH: New York, 1989; Vol.
1,
(19) Garc´ıa-Frutos, E. M.; Ferna´ndi-La´zaro, F.; Maya, E. M.;
Va´zquez, P.; Torres, T. J . Org. Chem. 2000, 65, 6841-6846.
(20) Maya, E. M.; Va´zquez, P.; Torres, T.; Gobbi, L.; Diederich, F.;
Pyo, S.; Echegoyen, L. J . Org. Chem. 2000, 65, 823-830.
(21) Li, J .; Lindsey, J . S. J . Org. Chem. 1999, 64, 9101-9108.
(22) Trominko, G. M.; Berezin, B. D. Zh. Neorg. Khim. 1993, 38,
1048-1052.
(23) J ian, Y.; van de Mark, M. J . Heterocycl. Chem. 1995, 32, 1521-
1524.
(24) Humberstone, P.; Clarkson, G. J .; Mckeown, N. B.; Treacher,
K. E. J . Mater. Chem. 1996, 6, 315-322.
(25) Tian, M.; Wada, T.; Kimura-Suda, H.; Sasabe, H. J . Mater.
Chem. 1997, 7, 861-863.
(10) Dogo, S.; Germain, J . P.; Maleysson, C.; Pauly, A. Thin Solid
Films 1992, 219, 244-250.
(11) Rosenthal, I. Photochem. Photobiol. 1991, 53, 859-870.
(12) Ali, H.; van Lier, J . Chem. Rev. 1999, 99, 2379-2450.
(13) Kobayashi, N.; Nakajima, S.; Osa, T. Inorg. Chim. Acta 1993,
210, 131-133.
(26) Leznoff, C. C.; Li, Z.; Isago, H.; D’ascanio, A. M.; Terekhov, D.
S. J . Porphyrins Phthalocyanines 1999, 3, 406-416.
(27) Beck, A.; Hanack, M. Chem. Ber. 1993, 126, 1493-1494.
(28) Muto, T.; Temma, T.; Kimura, M.; Hanabusa, K.; Shirai, H.
Chem. Commun. 2000, 1649-1650.
(14) Bedworth, P. V.; Perry, J . W.; Marder, S. R. Chem. Commun.
1997, 1353-1354.
10.1021/jo010384r CCC: $20.00 © 2001 American Chemical Society
Published on Web 08/08/2001

6110 J . Org. Chem., Vol. 66, No. 18, 2001
Muto et al.
solution of tetra-n-butylammonium hexafluorophosphate (Bu4-
NPF6, Aldrich) in CH2Cl2 or a 0.3 M tetra-n-butylammonium
perchlorate (Bu4NClO4, Nakalai Tesque) in o-dichlorobenzene
containing 1.0 mM of sample was purged with nitrogen for 20
min; then the voltammograms were recorded at ambient
temperature under dark. Potential was referenced to Ag/Ag+
in MeCN.
4,5-Dibromo3,6-dibutoxyphthalonitrile,31 2-(tri-n-buthyl)-
stannylthiophene,33 2-(tri-n-butyl)stannyl-5,2′-bithiophene,34
(OBu)8ZnPc,17 and (OBu)8CoPc35 were prepared according to
the literature methods or their slight modification. We syn-
thesized six types of new Pcs (1, 2, 1-Zn , 1-Co, 2-Zn , and 2-Co)
in this work (Scheme 1). All the synthesis of the Pcs was
started from 4,5-dibromo-3,6-dibutoxyphthalonitrile.31 The
transformation of this compound into thiophene-substituted
phthalonitriles involves palladium-catalyzed cross-coupling29,34
between the starting material and the appropriate tri-n-
butylstannane of the thiophene. The Pcs obtained in our study
have high solubility (>10-3 M) in common organic solvents
such as CH2Cl2, THF, or toluene, but not in acetonitrile. The
thiophene-substituted (OBu)8Pcs, particularly the free-bases
and zinc derivatives, are acid sensitive. It is advantageous to
base-wash the glassware and the quartz cell prior to use for
the Pcs.
of the Pc ring and the thiophene moieties. From these
results, we noticed the reformation of the π-system of Pc
by â-thienyl substitution which has the potential for
synthetic flexibility compared to other methodologies.
Oligothiophenes are a frequently investigated class of
π-conjugated moieties due to their stability and the fact
that their synthetic chemistry has been well-defined.29
In addition, their structural planarity permits strong
electronic conjugation within the structure. For these
reasons, substitution of thienyl and bithienyl groups at
the â positions of the Pc ring could result in the extension
and refinement of the π-systems.
In this paper, we describe the preparation and elec-
tronic condition of â-octa(2-thienyl)- and ([2,2′-bithiophene]-
5-yl)-1,4,8,11,15,18,22,25-octabutoxyphthalocyanines ((O-
Bu)8MPc, M ) H2, Zn, and Co). The electronic states of
the Pcs are discussed by means of photophysical studies
as well as by electrochemical studies. The (OR)8Pcs
generally are stable compounds that have an intense
Q-band in the red to deep-red region.17,30 This implies
that they have potential to exhibit intense Q-absorption
in the NIR region by the introduction of π-conjugated
moieties to the Pc ring through a σ-bond and are useful
in modern applications as a new class of Pcs.
3,6-Dibu toxy-4,5-d i(2-th ien yl)p h th a lon itr ile (3). 4,5-
