Phenyltriazolinones as potent factor Xa inhibitors
*
Mimi L. Quan , Donald J. P. Pinto, Karen A. Rossi, Steven Sheriff, Richard S. Alexander, Eugene Amparo,
Kevin Kish, Robert M. Knabb, Joseph M. Luettgen, Paul Morin, Angela Smallwood, Francis J. Woerner,
Ruth R. Wexler
Research and Development, Bristol-Myers Squibb, PO Box 5400, Princeton, NJ 08543-5400, United States
a r t i c l e i n f o
a b s t r a c t
Article history:
We have discovered that phenyltriazolinone is a novel and potent P1 moiety for coagulation factor Xa. X-
ray structures of the inhibitors with a phenyltriazolinone in the P1 position revealed that the side chain of
Asp189 has reoriented resulting in a novel S1 binding pocket which is larger in size to accommodate the
phenyltriazolinone P1 substrate.
Received 17 November 2009
Revised 27 December 2009
Accepted 4 January 2010
Available online 11 January 2010
Ó 2010 Elsevier Ltd. All rights reserved.
Keywords:
Factor Xa inhibitors
Coagulation
Cardiovascular diseases are the leading cause of death in devel-
oped countries, and most cardiovascular events are primarily due
to thrombosis.1 Despite the extensive efforts to discover and devel-
op new antithrombotic agents,2 warfarin remains the only
approved oral anticoagulant in the United States.3 Other agents
such as heparin and fondaparinux are available only by parenteral
administration. Limitations of these agents have prompted exten-
sive research for novel anticoagulants.3 Factor Xa (fXa) has been
a major focus of pharmaceutical intervention in the past decade
because of its central and unique position in the coagulation
cascade.4 Significant progress has been made in the discovery
and development of fXa inhibitors as anticoagulants. Several small
molecule fXa inhibitors have been in phase III clinical trials. Among
them the first oral fXa inhibitor, rivaroxaban, has recently been
approved in both Europe and Canada for the prophylaxis of venous
thromboembolism.5
Our efforts to discover and develop orally active inhibitors of
fXa led to clinical candidates DPC423 (1),6 razaxaban (2),7 and
apixaban (3)8 (Fig. 1). Razaxaban and apixaban were studied in
phase II clinical trials and shown to be efficacious in the treatment
of deep vein thrombosis.9 Apixaban, which has an overall better
pharmacokinetic profile, is currently in phase III clinical trials for
both venous and arterial indications.9b The discovery effort which
ultimately led to apixaban significantly advanced our understand-
ing of moieties that were sufficiently tolerated on the P1 phenyl
group.10,11 As part of our efforts to further diversify the P1 portfolio,
we discovered a novel phenyltriazolinone P1 moiety as shown in
structures 4b and 5. Herein we describe the synthesis and X-ray
crystal structures of these potent and selective fXa inhibitors
containing a phenyltriazolinone in the P1 position.
F
F3C
F
F3C
N
N
SO2Me
H
N
H
N
N
N
N
N
N
O
O
2, Razaxaban
1, DPC423
Xa Ki = 0.19 nM
Xa Ki = 0.15 nM
NH2
NH2
O
N
F3C
F
H2NOC
H
N
SO2Me
O
N
N
N
N
N
N
O
O
H
N
3, Apixaban
4b
Xa Ki = 0.08 nM
O
N
OMe
HN
R1
N
R2
N
N
O
H
N
5
O
N
HN
