A Fluorescence Turn-on Detection of
Cyanide in Aqueous Solution Based on
the Aggregation-Induced Emission
Lihua Peng, Ming Wang, Guanxin Zhang, Deqing Zhang,* and Daoben Zhu
Beijing National Laboratory for Molecular Sciences, Organic Solids Laboratory,
Institute of Chemistry, Chinese Academy of Sciences, Beijing 100190, China
dqzhang@iccas.ac.cn
Received February 22, 2009
ABSTRACT
The nucleophilic addition of cyanide to the trifluoroacetylamino group in 2 yields an amphiphilic species which would induce the aggregation
of silole 1, and as a result, the fluorescence of the ensemble increases largely. Accordingly, a fluorescence turn-on detection of cyanide in
aqueous solution can be established with the ensemble of silole 1 and compound 2. Also, this ensemble displays good selectivity toward
cyanide over other common inorganic anions.
Cyanide binds to the ferric form of cytochrome-c and inhibits
the mitochondrial electron-transport chain.1 For this reason,
cyanide is one of the most toxic anions and harmful to human
health and the environment. A large proportion of fatalities
among fire victims is due to cyanide poisoning, as blood
cyanide concentrations reach a level of 23-26 µM.2 Fur-
thermore, cyanide concentrations in drinking water have been
required to be lower than 1.9 µM.3 However, the use of
cyanide salts remains widespread, particularly in gold mining,
electroplating, and metallurgy.4 Also, cyanide salts have been
widely applied in the production of organic chemicals and
polymers including nitriles, nylon, and acrylic plastics.5
Despite the increasing level of monitoring and strict control,
accidental releases of cyanide into the environment do occur.
Therefore, it is highly desirable to develop sensitive and
selective chemical sensors for cyanide. By making use of
the coordination ability and nucleophilic reactivity of cyanide,
a number of chemical sensors for cyanide were developed.6
For instance, Sessler et al. have recently described a selective
cyanide indicator based on the benzyl cyanide reaction.7
However, drawbacks exist for these cyanide sensors. These
(5) Ullmann’s Encyclopedia of Industrial Chemistry, 6th ed.; Wiley-
VCH: New York, 1999.
(6) (a) Ros-Lis, J. V.; Martínez-Ma´n˜ez, R.; Soto, J. Chem. Commun.
2002, 2248–2249. (b) Badugu, R; Lakowicz, J. R.; Geddes, C. D. Anal.
Biochem. 2004, 327, 82–90. (c) Tomasulo, M.; Raymo, F. M. Org. Lett.
2005, 7, 4633–4636. (d) Ros-Lis, J. V.; Martínez-Ma´n˜ez, R.; Sato, J. Chem.
Commun. 2005, 5260–5262. (e) Tomasulo, M.; Sortino, S.; White, A. J. P.;
Raymo, F. M. J. Org. Chem. 2006, 71, 744–753. (f) Todd, W.; Gabba,
F. P. J. Am. Chem. Soc. 2007, 129, 11978–11986. (g) Sessler, J. L.; Barkey,
N. M.; Dan Pantos, G.; Lynch, V. M. New J. Chem. 2007, 31, 646–654.
(h) Ren, J. Q.; Zhu, W. H.; Tian, H. Talanta 2008, 75, 760–764. (i) Lou,
X. D.; Zhang, L. Y.; Qin, J. G.; Li, Z. Chem. Commun. 2008, 5848–5850.
(j) Zelder, F. H. Inorg. Chem. 2008, 47, 1264–1266.
(1) Vennesland, B.; Comm, E. E.; Knownles, C. J.; Westly, J.; Wissing,
F. Cyanide in Biology; Academic Press: London, 1981.
(2) (a) Ishii, A.; Seno, H.; Watanabe-Suzuki, K.; Suzuki, O.; Kumazawa,
T. Anal. Chem. 1998, 70, 4873–4876. (b) Moriya, F.; Hashimoto, Y. J.
Forensic Sci. 2001, 46, 1421–1425.
(3) Guidelines for Drinking-Water Quality; World Health Organization:
Geneva, 1996.
(4) Young, C.; Tidwell, L.; Anderson, C. Cyanide: Social, Industrial,
and Economic Aspects; Minerals, Metals, and Materials Society: Warrendale,
2001.
(7) (a) Cho, D. G.; Kim, H.-J.; Sessler, J. L. J. Am. Chem. Soc. 2008,
130, 12163–12167. (b) Sessler, J. L.; Cho, D.-G. Org. Lett. 2008, 10, 73–
75.
10.1021/ol900376r CCC: $40.75
Published on Web 04/03/2009
 2009 American Chemical Society

include poor selectivity,8 particularly in the presence of
fluoride or acetate, and the fact that the detection of cyanide
cannot be performed in aqueous solution in some cases.
Fluorescent probes for cyanide were reported,9 but fluores-
cence turn-on detection still remains rare. Thus, there remains
a need for improved sensing ensembles for cyanide. In this
paper, we will report a fluorescence turn-on sensing ensemble
for cyanide in aqueous solution by making use of the
aggregation-induced-emission (AIE) feature of silole (sila-
cyclopentadiene) compounds.
Scheme 1. (A) Chemical Structure of Silole 1 with an
