Inorg. Chem. 2002, 41, 6703−6710
Synthesis, Crystal Structures, and Redox Potentials of
2,3,12,13-Tetrasubstituted 5,10,15,20-Tetraphenylporphyrin Zinc(II)
Complexes
Yuichi Terazono, Brian O. Patrick, and David H. Dolphin*
Department of Chemistry, UniVersity of British Columbia, 2036 Main Mall,
VancouVer, BC, Canada
Received May 13, 2002
Zinc(II) complexes of antipodal â-tetrasubstituted meso-tetraphenylporphyrin with trifluoromethyl (Zn(TPP(CF ) )
3 4
(1a)), bromine (Zn(TPPBr4) (2a)), and methyl groups (Zn(TPP(CH ) ) (3a)) were synthesized in order to examine
3 4
the steric and the electronic effects of trifluoromethyl groups on the macrocycle. The analysis of X-ray crystal
structures of the five-coordinate complexes Zn(TPP(CF ) )(EtOH)3 (1b), Zn(TPPBr4)(MeOH)(DMF) (2b), and Zn(TPP-
3 4
(CH ) )(THF)1.6(CHCl3)0.4 (3b) revealed distorted macrocyclic cores where significant differences in the Zn−N distance
3 4
between the â-substituted and the non-â-substituted side were observed. The difference was significant in 1b due
to the strong steric interactions among the peripheral substituents and the electronic effects of trifluoromethyl
groups. The macrocycles of 1b−3b are saddle-distorted and slightly ruffled due to the five-coordination of zinc(II)
and the peripheral substitution. Distortion of the macrocycles of 2b and 3b were modest. On the other hand,
distortion in 1b was severe due to the peripheral strain. Cyclic voltammetric measurements of the four-coordinate
complexes Zn(TPP) and 1a−3a were performed and their redox potentials were analyzed together with previously
reported potentials of Zn(TPP(CN)4). The oxidation potential of 1a did not gain as much as expected from the
electron-withdrawing effect of the four trifluoromethyl groups. The HOMO−LUMO gap of 1a was very small (1.5 V)
and cannot just be explained by macrocyclic distortion. The magnitude of this gap is very similar to that of Zn-
(TPP(CN)4). Compound 2a also exhibited a modest gap contraction. Compound 3a was easier to oxidize and
harder to reduce than Zn(TPP), even though the HOMO−LUMO gap of 3a was similar to that of Zn(TPP).
Introduction
withdrawing substituents, have focused on catalytic oxida-
tions in order to mimic and improve their cytochrome P-450-
like activity.8-10 So far various porphyrins bearing electron-
withdrawing substituents such as pentachlorophenyl, penta-
fluorophenyl, perfluoroalkylphenyl, fluoro, chloro, bromo,
cyano, nitro, or perfluoroalkyl groups on meso and/or pyrrolic
â-positions of the porphyrin macrocycle have been syn-
Synthetic porphyrins used in model studies of hemopro-
teins have been prepared using design strategies involving
both structural and electronic modifications. For example,
model studies of hemoglobins and myoglobins were driven
by sterically hindered synthetic porphyrins into a successful
globin-like control of axial ligand coordination.1-3 Recent
examples of structurally modified porphyrins have been
involved in studies concerning nonplanarity of the porphyrin
macrocycle whose link to the functions of hemoproteins has
been suggested.4-7 Meanwhile, electronically and sterically
modified porphyrins, especially incorporating strongly electron-
(4) Barkigia, K. M.; Chantranupong, L.; Smith, K. M.; Fajer, J. J. Am.
Chem. Soc. 1988, 110, 7566.
(5) Nurco, D. J.; Medforth, C. J.; Forsyth, T. P.; Olmstead, M. M.; Smith,
K. M. J. Am. Chem. Soc. 1996, 118, 10918.
(6) Senge, M. O. In The Porphyrin Handbook; Kadish, K. M., Smith, K.
M., Guilard, R., Eds.; Academic Press: San Diego, 2000; Vol. 1, 239.
(7) Shelnutt, J. A.; Song, X.-Z.; Ma, J.-G.; Jia, S.-L.; Jentzen, W.;
Medforth, C. J. Chem. Soc. ReV. 1998, 27, 31.
(8) Sheldon, R. A. Metalloporphyrins in Catalytic Oxidations; Marcel
Dekker Inc.: New York, 1994.
(9) Montanari, F.; Casella, L. Metalloporphyrin Catalyzed Oxidations;
Kluwer Academic Publishers: Dordrecht, 1994.
(10) Dolphin, D.; Traylor, T. G.; Xie, L. Y. Acc. Chem. Res. 1997, 30,
251 and references therein.
* Author to whom correspondence should be addressed. Tel: (604) 822-
4571. Fax: (604) 822-9678. E-mail: ddolphin@qltinc.com.
(1) Collman, J. P.; Gagne, R. R.; Halbert, T. R.; Marchon, J. C.; Reed,
C. A. J. Am. Chem. Soc. 1973, 95, 7868.
(2) Almog, J.; Baldwin, J. E.; Huff, J. J. Am. Chem. Soc. 1975, 97, 227.
(3) Momenteau, M.; Loock, B.; Mispelter, J.; Bisagni, E. NouV. J. Chim.
1979, 3, 77.
10.1021/ic020339h CCC: $22.00 © 2002 American Chemical Society
Published on Web 11/12/2002
Inorganic Chemistry, Vol. 41, No. 25, 2002 6703

Terazono et al.
thesized.11-29 Of the numerous electron-withdrawing groups,
perfluoroalkyl groups are unique from a few viewpoints.
Perfluoroalkyl groups are inert and strongly σ-electron-
withdrawing, but they do not function as π-electron donors.
Accordingly, perfluoroalkyl groups effectively stabilize the
HOMO of the porphyrin macrocycle30 and provide stable
porphyrin ligands. In addition, perfluoroalkyl porphyrins are
soluble in a wide range of solvents27,28 and may be useful as
catalysts in special media.29,31
Electron-withdrawing and bulky trifluoromethyl groups in
â-trifluoromethyl-meso-tetraphenylporphyrins dramatically
alter the properties of the macrocycle, compared with those
of meso-tetraphenylporphyrin.32 Here, we describe the mo-
lecular and electronic properties of the zinc(II) complex of
â-tetrakis(trifluoromethyl)-meso-tetraphenylporphyrin exam-
ined by X-ray crystal structural analysis and cyclic voltam-
metric studies. â-Tetrabromo and â-tetramethyl derivatives
were also synthesized for comparison.
measurements were performed with a single-compartment electro-
chemical cell, a Pine Instrument Co. bipotentiostat model AFCBP1,
and Pine Chem sweep voltammetry software for Windows ver. 2.00.
5,10,15,20-Tetraphenylporphyrinatozinc(II) (Zn(TPP)). Zn-
(II) was inserted into H2TPP by a standard procedure.33 UV-vis
(CH2Cl2): λmax (nm) 419, 548, 582. 1H NMR (CDCl3): δ 7.73 (m,
12H, phenyl-p- and -m-H), 8.08 (m, 8H, phenyl-o-H), 8.90 (s, 8H,
pyrr-â-H).
[2,3,12,13-Tetrakis(trifluoromethyl)-5,10,15,20-tetraphenylpor-
phyrinato]zinc(II) (Zn(TPP(CF3)4)) (1a). Zn(OAc)2‚2H2O (37 mg,
0.17 mmol) in methanol (10 mL) was added to a brown suspension
of 7,8,17,18-tetrakis(trifluoromethyl)-5,10,15,20-tetraphenylporphy-
rin (50 mg, 0.056 mmol) in chloroform (10 mL) at room
temperature. The color instantly changed to a bright green, and the
solution became homogeneous. The mixture was then stirred for
30 min at room temperature, chloroform (100 mL) was added, and
the mixture was washed with water (2 × 100 mL). The volume of
the green solution was reduced in vacuo, and the solution was dried
over anhydrous sodium sulfate. Filtration and removal of the solvent
gave a green powder of the product. The yield was 52 mg (98%).
1
UV-vis (CH2Cl2): λmax (nm) (log ꢀ) 442 (5.37), 662 (4.31). H
Experimental Section
NMR (CDCl3): δ 7.70 (m, 12H, phenyl-m- and -p-H), 8.07 (m,
8H, phenyl-o-H), 8.43 (s, 4H, pyrr-â-H). 19F NMR (CDCl3): δ
(vs CFCl3) -48.3. CHN anal. (%), calcd for C48H24F12N4Zn: C,
60.68; H, 2.55; N, 5.90. Found: C, 60.60; H, 2.56; N, 5.75.
Materials. All chemicals were purchased from Sigma-Aldrich
fine chemicals, Across Chemicals, or Fisher Scientific. Deuterated
solvents for NMR measurements were purchased from Cambridge
Isotope Laboratories. Chlorinated solvents were filtered using
neutral alumina (Fisher, activity I) to remove trace acid. Methylene
chloride for cyclic voltammetric measurements was distilled from
CaH2, degassed by three cycles of the freeze-thaw pumping, and
stored over activated molecular sieves (4 Å). Free-base porphyrins
were synthesized as described previously.32
Instrumentation. UV-visible spectra were recorded on a Varian
Cary 50 scan UV-visible spectrophotometer. NMR spectra were
recorded on Bruker AC-200 or Avance 300. Cyclic voltammetric
(11) Wijesekera, T.; Matsumoto, A.; Dolphin, D.; Lexa, D. Angew. Chem.,
Int. Ed. Engl. 1990, 29, 1028.
(12) Longo, F. R.; Finarelli, M. G.; Kim, J. B. J. Heterocycl. Chem. 1969,
6, 927.
(13) Woller, E. K.; DiMagno, S. G. J. Org. Chem. 1997, 62, 1588.
(14) Leroy, J.; Bondon, A.; Toupet, L.; Rolando, C. Chem. Eur. J. 1997,
3, 1890.
(15) Lyons, J. E.; Ellis, P. E. Catal. Lett. 1991, 8, 45.
(16) Traylor, T. G.; Tsuchiya, S. Inorg. Chem. 1987, 26, 1338.
(17) Callot, H. J. Tetrahedron Lett. 1973, 4987.
(18) Callot, H. J. Bull. Soc. Chim. Fr. 1974, 1492.
(19) Duval, H.; Bulach, V.; Fischer, J.; Weiss, R. Inorg. Chem. 1999, 38,
5495.
(20) Ozette, K.; Leduc, P.; Palacio, M.; Bartoli, J.-F.; Barkigia, K. M.;
Fajar, J.; Battioni, P.; Mansuy, D. J. Am. Chem. Soc. 1997, 119, 6442.
(21) Palacio, M.; Mansuy-Mouries, V.; Loire, G.; Le Barch-Ozette, K.;
Ledue, P.; Barkigia, K. M.; Fajar, J.; Battioni, P.; Mansuy, D. Chem.
Commun. 2000, 1907.
(22) Ono, N.; Muratani, E.; Fumoto, Y.; Ogawa, T.; Tajima, K. J. Chem.
Soc., Perkin Trans. 1 1998, 3819.
(23) Ono, N.; Kawamura, H.; Maruyama, K. Bull. Chem. Soc. Jpn. 1989,
62, 3386.
(24) Aoyagi, K.; Haga, T.; Toi, H.; Aoyama, Y.; Mizutani, T.; Ogoshi, H.
Bull. Chem. Soc. Jpn. 1997, 70, 937.
(25) Tamiaki, H.; Nagata, Y.; Tsudzuki, S. Eur. J. Org. Chem. 1999, 2471.
(26) Nelson, N. Y.; Medforth, C. J.; Nurco, D. J.; Jia, S.-L.; Shelnutt, J.
A.; Smith, K. M. Chem. Commun. 1999, 2071.
(27) Goll, J. G.; Moore, K. T.; Ghosh, A.; Therien, M. J. J. Am. Chem.
Soc. 1996, 118, 8344.
(28) DiMagno, S. G.; Williams, R. A.; Therien, M. J. J. Org. Chem. 1994,
59, 6943.
(2,3,12,13-Tetrabromo-5,10,15,20-tetraphenylporphyrinato)-
zinc(II) (Zn(TPPBr4)) (2a). Zn(II) was inserted into 7,8,17,18-
tetrabromo-5,10,15,20-tetraphenylporphyrin by a standard procedure
for the synthesis of metalloporphyrins.33 LR-MS (EI, 300 °C): M+
(m/z) ) 993; calcd for C44H24Br4N464Zn, 993.7. UV-vis (CH2-
1
Cl2): λmax (nm) 430, 560, 598. H NMR (DMSO-d6): δ 8.61 (s,
4H, pyrr-â-H), 8.02 (m, 8H, phenyl-o-H), 7.80 (m, 12H, phenyl-p-
and -m-H). CHN anal. (%), calcd for C44H24Br4N4Zn: C, 53.18;
H, 2.43; N, 5.64. Found: C, 53.25; H, 2.54; N, 5.42.
(2,3,12,13-Tetramethyl-5,10,15,20-tetraphenylporphyrinato)-
zinc(II) (Zn(TPP(CH3)4) (3a). The free-base porphyrin (20 mg,
0.030 mmol) was dissolved in chloroform (20 mL). Zn(OAc)2‚2H2O
(20 mg, 0.091 mmol) was dissolved in methanol (10 mL) and added
to the chloroform solution of the porphyrin. The mixture was
refluxed for 1 h. The color of the solution changed from purple to
red. After the solvents were removed by rotary evaporation, the
product was dissolved in chloroform (60 mL) and washed with
water (3 × 60 mL). The solution was dried using anhydrous sodium
sulfate. Filtration and evaporation of the solvent yielded a red
powder (18 mg, 80%). LR-MS (EI): M+ (m/z) ) 732; calcd for
C48H36N464Zn, 732.8. UV-vis (CH2Cl2): λmax (nm) 420, 534sh,
(29) Pozzi, G.; Montanari, F.; Quici, S. Chem. Commun. 1997, 69.
(30) Gassman, P. G.; Ghosh, A.; Almlo¨f, J. J. Am. Chem. Soc. 1992, 114,
9990.
(31) Horva´th, I. T.; Ra´bai, J. Science 1994, 266, 72.
(32) Terazono, Y.; Dolphin, D. J. Org. Chem., submitted.
(33) Adler, A. D.; Longo, F. R.; Kampas, F.; Kim, J. J. Inorg. Nucl. Chem.
1970, 32, 2443.
6704 Inorganic Chemistry, Vol. 41, No. 25, 2002

5,10,15,20-Tetraphenylporphyrin Zinc(II) Complexes
Table 1. Crystallographic Data for 1b-3b
data was performed using φ oscillations from 0.0° to 190.0° at ø
) -90°, -90°, and 0°, and a second sweep was performed using
ω oscillations between -23.0° and 18.0°, -19.0° and 23.0°, and
-19.0° and 23° at ø ) -90° for 1b-3b, respectively. The structures
were solved by heavy-atom Patterson methods34 for 1b and by direct
methods35 for 2b and 3b and expanded using Fourier techniques.36
The non-hydrogen atoms were refined anisotropically. The OH
hydrogen atom of the coordinated ethanol was refined isotropically.
In 3b, one disordered molecule of THF coordinated to Zn(II); in
addition, two different solvents, THF and CHCl3, partially occupy
the same volume in the asymmetric unit. In 3b, all the disordered
solvent molecules were refined isotropically, while all other atoms
were refined anisotropically. All calculations were performed using
the teXsan crystallographic software package.37
1b
2b
3b
empirical formula
C54H42F12N4-
O3Zn
C48H35Br4N5-
O2Zn
C54.80H49.20N4-
ZnO1.60Cl1.20
897.34
P21/n (No. 14)
13.585(1)
fw
1088.31
P1h (No. 2)
12.0428(11)
13.275(2)
16.909(2)
96.951(5)
108.124(2)
107.354(2)
2383.2(5)
2
1098.83
P1h (No. 2)
12.257(2)
13.4377(8)
14.387(1)
83.819(2)
71.227(2)
73.575(3)
2151.7(3)
2
space group
a (Å)
b (Å)
18.182(1)
18.065(2)
c (Å)
R (deg)
â (deg)
γ (deg)
V (Å3)
Z
93.274(3)
4454.9(6)
4
D
calc (g/cm3)
1.52
6.13
-93 ( 1
10728
1.70
43.42
-100 ( 1
8177
1.34
6.70
µ(Mo KR) (cm-1
T (°C)
)
-100 ( 1
no. of indep reflns
(I > 0.00σ(I))
no. of obsd reflns
(I > 3σ(I))
7452
Results and Discussion
5823
6086
2621
X-ray Crystal Structures. ORTEP views of the crystal
structures for Zn(TPP(CF3)4)(EtOH)3 (1b), Zn(TPPBr4)-
(MeOH)(DMF) (2b), and Zn(TPP(CH3)4)(CHCl3)0.4(THF)1.6
(3b) are shown in Figure 1. Selected bond lengths and bond
angles for the three molecules together with previously
reported data for pentacoordinated Zn(TPP)(H2O)38 are
summarized in Table 2.
Coordination around Zn(II) in 1b-3b is pentacoordinate
square pyramidal, a common geometry for Zn(II) porphy-
rins.39 However, these exhibit the unique core structures
commonly observed for antipodal â-substituted meso-tetra-
phenylporphyrinato metal complexes such as Ni(TPP(CN)4)-
(L)2 (L ) pyr or 1-meim),40 (Fe(TPPBr4))2O,41 Fe(TPPBr4)-
Cl,42 or Zn(tTETPP)(pyr);43 M-N distances are nonequivalent
in different N-N vectors (i.e., N1-N3 and N2-N4). The
average Zn-N distances for 1b-3b along the N1-N3 vector
(i.e., Zn-N in Table 2) are longer than those along the N2-
N4 vector (i.e., Zn-N′ in Table 2). The nonequivalence of
the M-N distances is caused by in-plane elongation of the
porphyrin core due to the steric strain enforced by the
Ra
Rw
0.053
0.091
0.033
0.089
0.051
0.155
b
2
2
a R1 ) ∑||Fo| - |Fc||/∑|Fo|, I > 3σ(I). b wR2 ) [∑(Fo - Fc )2)/
2
∑w(Fo )2]1/2
.
1
551, 587sh. H NMR (CDCl3): δ 2.34 (s, 12H, -CH3), 7.75 (m,
12H, phenyl-m- and -p-H), 8.06 (m, 8H, phenyl-o-H), 8.65 (s, 4H,
pyrr-â-H).
Zn(TPP(CF3)4)‚(EtOH)3 (1b). Zn(TPP(CF3)4 (1a) was dissolved
in a 50:50 chloroform:ethanol solution, and crystallization of 1b
was induced by slow evaporation at room temperature. After a
period of 2 weeks, purple prisms were obtained. 1H NMR
(CDCl3): δ 0.34 (t, 3H, EtOH (-OH)), 0.73 (t, 9H, EtOH (-CH3)),
2.94 (m, 6H, EtOH (-CH2-)), 7.70 (m, 12H, phenyl-m- and -p-
H), 8.08 (m, 8H, phenyl-o-H), 8.37 (s, 4H, pyrr-â-H). 19F NMR
(CDCl3): δ (vs CFCl3) -48.36. UV-vis (CH2Cl2) λmax (nm) (log
ꢀ): 444 (5.42), 598sh (3.82), 664 (4.34). CHN anal. (%), calcd for
C54H42F12N4ZnO3: C, 59.60; H, 3.89; N, 5.15. Found: C, 60.00;
H, 3.64; N, 5.02.
Zn(TPPBr4)‚(MeOH)‚(DMF) (2b). Crystallization was induced
by slow diffusion of methanol into a solution of Zn(TPPBr4) (2a)
in DMF. After a period of 1-2 days shiny purple chips were
(34) Beurskens, P. T.; Admiraal, G.; Beurskens, G.; Bosman, W. P.; Garcia-
Granda, S.; Gould, R. O.; Smits, J. M. M.; Smykalla, C. PATTY. In
The DIRDIF program system; Technical Report; Crystallography
Laboratory, University of Nijmegen: Nijmegen, The Netherlands,
1992.
(35) Altomare, A.; Burla, M. C.; Cammalli, G.; Cascarano, M.; Giacovazzo,
C.; Guagliardi, A.; Moliterni, A. G. G.; Polidori, G.; Spagna, A. J.
Appl. Crystallogr. 1999, 32, 115.
(36) Beurskens, P. T.; Admiraal, G.; Beurskens, G.; Bosman, W. P.; de
Gelder, R.; Israel, R.; Smits, J. M. M. The DIRDIF-94 program
system; Technical Report; Crystallography Laboratory, University of
Nijmegen: Nijmegen, The Netherlands, 1994.
(37) teXsan: Crystal Structure Analysis Package; Molecular Structure
Corp.: The Woodlands, TX, 1985 and 1992.
(38) Golder, A. J.; Povey, D. C. Acta Crystallogr. 1990, C46, 1210.
(39) Scheidt, W. R. In The Porphyrin Handbook; Kadish, K. M., Smith,
K. M., Guilard, R., Eds.; Academic Press: New York, 2000; Vol. 3,
49.
(40) Ni(TPP(CN)4)(L)2: Hexacoordinate (2,3,12,13-tetracyano-5,10,15,20-
tetraphenylporphyrinato)nickel(II). L ) axial ligand. (a) Reference 19.
(b) Duval, H.; Bulach, V.; Fischer, J.; Weiss, R. Acta Crystallogr.
1997, C53, 1027.
1
obtained. H NMR could not be measured in CDCl3 because of
low solubility. 1H NMR (DMSO-d6): δ 2.75 (s, 3H, DMF (-CH3)),
2.89 (s, 3H, DMF (-CH3)), 3.22 (d, 3H, MeOH (-CH3)), 4.08 (q,
1H, MeOH (-OH)), 7.78 (m, 12H, phenyl-m- and -p-H), 7.99 (s,
1H, DMF (-CHO)), 8.02 (m, 8H, phenyl-o-H), 8.60 (s, 4H, pyrr-
â-H). CHN anal. (%), calcd for C48H35Br4N5O2Zn (2): C, 52.47;
H, 3.21; N, 6.37. Found: 52.32; H, 3.17; N, 6.02.
Zn(TPP(CH3)4)‚(THF)1.6‚(CHCl3)0.4 (3b). Zn(TPP(CH3)4) (3a)
was dissolved in 50:50 chloroform:tetrahydrofuran, and crystal-
lization was induced by slow evaporation at room temperature. After
1
a period of 1 week, red needle crystals were obtained. H NMR
(CD2Cl2): δ 1.76 (m, THF), 2,37 (s, H2O), 3.56 (m, THF), 7.25
(s, CHCl3), 7.75 (m, 12H, phenyl-m- and -p-H), 8.06 (m, 8H,
phenyl-o-H), 8.65 (s, 4H, pyrr-â-H). CHN anal. (%), calcd for
C
54.8H49.2Cl1.2N4O1.6Zn (3): C, 73.35; H, 5.53; N, 6.24. Found: C,
73.15; H, 5.60; N, 6.06.
(41) (Fe(TPPBr4))2O: (µ-Oxo)bis(2,3,12,13-tetrabromo-5,10,15,20-tetraphe-
nylporphyrinato)iron(III). Kadish, K. M.; Autret, M.; Ou, Z.; Tagli-
atesta, P.; Boschi, T.; Fares, V. Inorg. Chem. 1997, 36, 204.
(42) Fe(TPPBr4)Cl: Chloro(2,3,12,13-tetrabromo-5,10,15,20-tetraphe-
nylporphyrinato)iron(III). Duval, H.; Bulach, V.; Fischer, J.; Renner,
M. W.; Fajer, J.; Weiss, R. J. Biol. Inorg. Chem. 1997, 2, 662.
(43) Zn(tTETPP)(pyr): Pyridine(2,3,12,13-tetraethyl-5,10,15,20-tetraphe-
nylporphyrinato)zinc(II). Senge, M. O.; Kalisch, W. W. Inorg. Chem.
1997, 36, 6103.
X-ray Crystallography. All measurements were made on a
Rigaku/ADSC CCD area detector with graphite-monochrometed
Mo KR radiation (λ ) 0.71069 Å). Crystal data and details of the
diffraction data collections are given in Table 1. The data were
collected at -93 ( 1, -100 ( 1, and -100 ( 1°C to a maximum
2θ value of 60.2°, 55.7°, and 50.1° at 0.50° oscillations with 80.0,
12.0, and 58.0 s exposures for 1b-3b, respectively. A sweep of
Inorganic Chemistry, Vol. 41, No. 25, 2002 6705

Terazono et al.
Figure 1. X-ray crystal structures of (a) Zn(TPP(CF3)4)(EtOH)3 (1b), (b) Zn(TPPBr4)(MeOH)(DMF) (2b), and (c) Zn(TPP(CH3)4)(THF)1.6(CHCl3)0.4 (3b).
The axial ligand and the solvated molecules for the top views (left column) and the meso-phenyl groups and some solvated molecules for the side views
(right column) were omitted for clarity. Ellipsoids are drawn at 30% probability.
peripheral substituents.39 The mechanism of elongation of
the porphyrin core is explained by repulsion of pyrrolic â-â
substituents that push the meso-phenyl groups toward the
unsubstituted pyrroles. Relief of the peripheral steric strain
than that of the methyl (2.0 Å) and the bromine groups (1.95
Å).46 Thus, of the three Zn(II) porphyrins, the strongest steric
interaction among the peripheral substituents is expected in
1b. As suggested in previous reports,40,42 the electronic effect
of â-substituents may also contribute to different M-N
distances in both vectors; strongly electron-withdrawing
substituents on the pyrrolic â-positions will decrease the
electron density on N1 and N3, and the weakened M-N1
and M-N3 bonds will be longer than the other M-N pair.
Of the three structures, the difference in the Zn-N distances
is largest (∆Zn-N ) 0.117 Å) in 1b and relatively small
(∆Zn-N ) 0.070 Å) in 3b. While all of the above factors
results in, for example, Câ-Câ > Câ′-Câ′ and Câ-Cmeso
-
Cph > CR′-Cmeso-Cph, as shown in Table 2. This phenom-
enon is observed for 1b-3b, with 1b showing the largest
elongation. The van der Waals radius of the trifluoromethyl
group is estimated to be 2.2 Å44 (or more),45 which is larger
(44) Smart, B. E. In Chemistry of Organic Fluorine Compounds II. A
Critical ReView; Hudlicky´, M., Pavlath, A. E., Eds.; American
Chemical Society: Washington, DC, 1995.
(45) Kitazume, T.; Yamazaki, T. Experimental Methods in Organic Fluorine
Chemistry; Kodansha, Gordon and Breach Science Publishers: Tokyo,
1998.
(46) Cotton, F. A.; Wilkinson, G. AdVanced Inorganic Chemistry, 3rd ed.;
Interscience Publishers: New York, 1972.
6706 Inorganic Chemistry, Vol. 41, No. 25, 2002

5,10,15,20-Tetraphenylporphyrin Zinc(II) Complexes
Table 2. Core Size, Selected Bond Lengths (Å), Distances (Å), and
Bond Angles (°)
much smaller than that of typical porphyrin ligands like TPP;
the largest displacement of the Zn(II) atom in 1b corresponds
to the smallest core size. The Zn-O distances in 1b and 2b
are about 0.12 Å shorter than the 2.228 Å in Zn(TPP)(H2O)38
or 2.226 Å in Zn(OETPP)(MeOH)49 but close to that (2.092
Å) in Zn(TPPF8)(H2O).14 Presumably, in electron-deficient
porphyrins the Zn(II) atoms are pulled out of the porphyrin
core by the axial ligand. Thus, the largest Zn(II) atom
displacement in 1b is due to the combination of steric and
electronic effects.
Figure 2 shows the magnitude of distortion in the mac-
rocycles of 1b-3b. For all three, pyrrole rings are alternately
up and down relative to the N4 mean plane. As shown in
the displacements of the pyrrolic R-, â-, and meso-carbons,
the pyrrole rings are slightly twisted along the M-N axes.
Thus the macrocycles are mainly saddle-distorted and gently
ruffled. The average displacements for the pyrrolic â-carbons
from the N4 mean plane for 1b-3b are 0.79, 0.40, and 0.46
Å, respectively. Distortion of the macrocycles of 2b and 3b
is similar to that in Zn(TPPF8)(H2O), which is saddle-
distorted and has a displacement of 0.49 Å for the pyrrolic
â-carbons.50 In fact, a potentially planar porphyrin can be
distorted by the mode of coordination. For example, crystal
structures of a four-coordinate Zn(TPPBr4)51 and a free base
of a â-octafluoro-TPP analogue, H2TPPF28,52 showed planar
porphyrin macrocycles. Thus, the distortion in 2b and Zn-
(TPPF8)(H2O) seems due to the axial ligand coordination to
the Zn(II) atoms. The average displacement of 0.46 Å for
pyrrolic â-carbons from the N4 mean plane in 3b is more or
less the same as that in 2b and Zn(TPPF8)(H2O), suggesting
that the distortion in 3b could also be due to the coordination
pattern of the Zn(II) atom and that the peripheral steric strain
might not be sufficiently large to cause severe macrocyclic
distortion. The obviously large average value of 0.79 Å for
1 indicates that factors other than the mode of coordination
may be involved in the severe distortion of the macrocycle.
Comparison of the root-mean-square values (Figure 2), which
are the average deviations of the 24 core atoms from their
least-squares plane, also shows the considerable distortion
in 1b. The van der Waals radius of fluorine is close to that
of hydrogen.46 However, the longer C-F bond length (1.3-
1.4 Å) compared to the C-H bond length (1.1 Å)53 makes
the CF3 group bulkier than the CH3 group. Thus, steric
interactions among the peripheral substituents in 1b will be
larger than those in 3b. As shown in the top view of 1b
(Figure 1), two meso-phenyl groups are extremely twisted
due to the steric interaction with trifluoromethyl groups. The
average torsion angle made by Cortho(C26 or C30)-C25-
1b
2b
3b
Zn(TPP)a
2.043
N‚‚‚Ctb
2.106
1.962
2.094
2.009
2.076
2.012
N′‚‚‚Ct
Zn-O
2.110(3)
2.119(2)
2.002(2)
1.374(3)
1.381(4)
1.451(4)
1.450(4)
1.368(4)
1.336(4)
1.422(4)
1.396(4)
108.2(2)
106.6(2)
118.6(3)
116.0(3)
129.0(3)
125.0(3)
2.108(3)
2.115(3)
2.026(3)
1.375(4)
1.370(4)
1.448(5)
1.446(4)
1.350(5)
1.344(5)
1.409(4)
1.401(5)
108.2(3)
106.8(3)
119.7(3)
115.8(3)
129.6(3)
129.2(2)
2.182(4)
2.092(5)
2.022(5)
1.375(7)
1.377(7)
1.456(9)
1.454(9)
1.376(9)
1.348(8)
1.419(8)
1.388(8)
105.9(5)
107.4(5)
118.2(6)
116.0(5)
129.0(6)
128.6(6)
2.228
2.050
1.372
Zn-N
Zn-N′
N-CR
N′-CR′
CR-Câ
1.442
CR′-Câ′
Câ-Câ
1.341
1.405
106.8
117.2
Câ′-Câ′
CR-Cmeso
CR′-Cmeso
CR-N-CR
CR′-N-CR′
CR-Cmeso-Cph
CR′-Cmeso-Cph
CR-Câ-X1(X4)c
CR-Câ-X2(X3)c
a Reference 38. b Ct is the centroid of the four nitrogen atoms. c X1 )
C21 or Br1, X2 ) C22 or Br2, X3 ) C23 or Br3, and X4 ) C24 or Br4.
contribute to the conformation of 1a, the major influence
on the M-N distances results from the unique 18π-electron
pathway. The free-base â-tetrakis(trifluoromethyl)-meso-
tetraphenylporphyrin has a bacteriochlorin-like chromophore
where the aromatic system avoids the CF3-substituted carbon
atoms.32 The crystal structure of (2,3,12,13-tetrahydro-5,-
10,15,20-tetraphenylporphinato)(pyridine)-zinc(II)47 shows a
similar core distortion with M-N bond lengths of 2.04 and
2.21 Å.
In complexes 1b-3b, the Zn(II) atoms are displaced by
0.325, 0.277, and 0.234 Å from the least-squares plane
through the four porphyrin nitrogen atoms (the N4 mean
plane). These values are larger than the 0.173 Å for Zn-
(TPP)(H2O).38 The value of 0.325 Å for 1b is especially large
compared to those in typical five-coordinate Zn(II) porphy-
rins with apical Zn-O coordination.48 Here again two factors,
steric and electronic, seem to be affecting the position of
the Zn(II) atoms. Displacement of the Zn(II) atoms from the
N4 plane occurs due to the larger size of the Zn(II) atom
relative to the core sizes of the macrocycles.39 The core sizes
(N‚‚‚Ct in Table 2) along the N2-N4 vector in 1b-3b are
(49) Zn(OETPP)(MeOH): Methanol(2,3,7,8,12,13,17,18-octaethyl-5,10,-
15,20-tetraphenylporphyrinato)zinc(II). Barkigia, K. M.; Berber, M.
D.; Fajar, J.; Medforth, C. J.; Renner, M. W.; Smith, K. M. J. Am.
Chem. Soc. 1990, 112, 8851.
(50) Zn(TPPF8)(H2O): Aqua(2,3,7,8,12,13,17,18-octafluoro-5,10,15,20-
tetraphenylporphyrinato)zinc(II). The value is the displacement from
the porphyrin least-squares plane. Reference 14.
(51) Zou, J.-Z.; Li, M.; Xu, Z.; You, X.-Z. Jiegou Huaxue 1997, 16, 29.
(52) H2TPPF28: 2,3,7,8,12,13,17,18-Octafluoro-5,10,15,20-tetrakis(pen-
tafluorophenyl)porphyrin. Leroy, J.; Bondon, A.; Toupet, L. Acta
Crystallogr. 1999, C55, 464.
(53) Handbook of Chemistry & Physics, 81st ed.; CRC Press: Boca Raton,
FL, 2000-2001; p 9-5.
(47) Barkigia, K. M.; Miura, M.; Thompson, M. A.; Fajer, J. Inorg. Chem.
1991, 30, 2233.
(48) Cheng, B.; Scheidt, W. R. Inorg. Chim. Acta 1995, 237, 5.
Inorganic Chemistry, Vol. 41, No. 25, 2002 6707

Terazono et al.
Figure 2. Displacements (in 0.01 Å units) of the porphyrin core, pyrrolic â-substituents, and Zn(II) atom relative to the N4 mean plane (left column) and
linear display (in Å units) of the skeletal deviations from the N4 mean plane (right column) of (a) Zn(TPP(CF3)4)(EtOH)3 (1b), (b) Zn(TPPBr4)(MeOH)-
(DMF) (2b), and (c) Zn(TPP(CH3)4(THF)1.6)(CHCl3)0.4 (3b). 9 indicates the pyrrolic carbons bearing substituents. The rms values show the average deviation
of the 24 core atoms from their least-squares plane.
C5-CR(C4 or C6) is 54.4°, and similarly 52.1° for the other
phenyl ring (C31-36). Interestingly, two other phenyl rings
(C37-42 and C43-48) are almost orthogonal to the best
plane of the porphyrin macrocycle (the corresponding torsion
angles are 85.2° and 80.2°, respectively). The crystal structure
of 1b viewed from a different angle (Figure 3) shows that
the twisting angles of phenyl rings C25-30 and C31-36
affect those of phenyl rings C37-42 and C43-48. The steric
interaction between phenyl ring C43-48 and trifluoromethyl
group CF1-3 determines the orientation of the trifluorom-
ethyl group so that no fluorine of F1-3 is pointing at the
face of the phenyl ring. This orientation forces F3 to point
at the adjacent CF4-6, which orients so that F3 points
between F4 and F5. The orientation of CF4-6 is such that
the phenyl ring C25-30 cannot lie orthogonal to the
porphyrinato core due to the penetration of F6 into the
π-cloud of ring C25-30. In order to avoid this situation,
the phenyl ring rotates to reduce the contact with CF4-6.
The relatively small CR-Câ-X2 angle for 1b (Table 2)
indicates that phenyl ring C25-30 is pushed away by CF4-
6. Thus, an electrostatic repulsion between the π-cloud of
the phenyl rings and the trifluoromethyl groups appears to
be the major driving force for the macrocyclic distortion.
Such interactions between fluorine atoms and the π-electrons
of phenyl rings have been reported.54 It should be noted that
the 282 MHz 19F NMR spectrum of 1b in CDCl3 at room
temperature displayed a sharp singlet at -48.4 ppm (vs
CFCl3), and this equivalency of the trifluoromethyl fluorines
indicates rotation of the groups in solution.
The average torsion angles made by the Cortho-CPh-
(54) Hayashi, N.; Mori, T.; Matsumoto, K. Chem. Commun. 1998, 1905.
6708 Inorganic Chemistry, Vol. 41, No. 25, 2002

5,10,15,20-Tetraphenylporphyrin Zinc(II) Complexes
Figure 4. Optical spectra of (a) 1a, (b) 2a, and (c) 3a in CH2Cl2. Q-bands
are magnified by five times.
trifluoromethyl groups where they are shielded by the ring
current of the macrocycle. It is not possible that the
intramolecular hydrogen bonding in 1b, shown in Figure 1,
is the rationale for the mode of buckling, since we also
observed similar coordination and distortion patterns for a
crystal structure of CoII(TPP(CF3)4)(pyr),56 which has no such
bonding.
Optical Spectra. Figure 4 shows the optical spectra of
1a-3a. 3a shows a spectrum similar to that of Zn(TPP) (419,
548, and 582 nm), while 2a shows a small red shift.
Compound 1a, on the other hand, exhibits a unique optical
spectrum. The extremely red-shifted Q-band is indicative of
a narrower HOMO-LUMO, see below, which is caused by
both the macrocyclic distortion4 and the bacteriochlorin-like
electronic structure.32 It is interesting to note that [meso-
tetrakis(trifluoromethyl)porphyrinato]zinc(II) (λmax, nm (log
ꢀ) 409 (5.27), 554 (3.99), 593 (4.29)),27 where the four CF3
groups are bonded to the meso positions, exhibits an optical
spectrum27 similar to that of Zn(TPP).
Redox Potentials of Zn(II) Porphyrins. In the previous
section, the relationship between the optical properties and
structures was described briefly. In addition, we have also
attempted to analyze the electronic structures of the Zn(II)
porphyrins using cyclic voltammetry. Cyclic voltammetric
measurements were performed using the four-coordinate
complexes Zn(TPP(CF3)4) (1a), Zn(TPPBr4) (2a), and Zn-
(TPP(CH3)4) (3a). As presented in Figure 5a, two reversible
one-electron waves were observed for 1a. The first oxidation
and reduction potentials of 1a (â-CF3), 2a (â-Br), 3a (â-
CH3), Zn(TPP) (â-H), and Zn(TPP(CN)4)57 (â-CN) are
plotted against the 4σp value (Figure 5b).58 As the 4σp value
increases, both the oxidation (removal of an electron from
the HOMO) and reduction (filling of an electron into the
LUMO) potentials increase. The first oxidation potentials
change almost linearly. A slight deviation of the first
Figure 3. Orientations of meso-phenyl and â-trifluoromethyl groups in
Zn(TPP(CF3)4)(EtOH)3 (1b).
Cmeso-CR are 68.4°, 78.2°, 76.8°, and 72.9° in 2b and 75.9°,
67.6°, 71.5°, and 71.3° in 3b, such that no severe interaction
of the phenyl and pyrrolic â-substituents was observed.
Another interesting feature of the crystal structure of 1b
is coordination of the axial ligand and the macrocycle
distortion. Buckling of the macrocycles along the N1-N3
vector (i.e., â-substituted direction) for 1b is different from
that for 2b and 3b. In square-pyramidal coordination of five-
coordinate metalloporphyrins, the metal atom is displaced
from the N4 mean plane toward the axial ligand and this
displacement is accompanied by doming of the porphyrinate
core.55 In the case of 1b, doming of the porphyrinate core
seems to be hampered by the severe steric interaction among
the peripheral substituents.
As shown in Figure 1, the axial ethanol is hydrogen
bonded to the second ethanol (O2‚‚‚H1 (1.90 Å)), whose
methylene hydrogen (H32) has a nonbonding contact with
F9 (F9‚‚‚H32 (2.71 Å)). The third ethanol is also hydrogen-
bonded to the second ethanol (O3‚‚‚H31 (2.03 Å), where
O3 is the oxygen atom in the third ethanol and H31 is the
hydroxyl hydrogen of the second ethanol). This network of
hydrogen bonding is no doubt enhanced by the extreme
electron deficiency of the zinc indued by the peripheral
trifluoromethyl groups. There were also some other F‚‚‚H
nonbonding contacts within 3 Å between solvent ethanols,
â-pyrrolic hydrogen, or phenyl ring hydrogen and trifluo-
romethyl moieties across the different porphyrin units.
Intermolecular δ+C-Fδ- and δ-C-Hδ+ bond dipole interac-
tions or C-H‚‚‚F-C hydrogen bonding is well-known.44
Nonbonding contacts between ethanol molecules and trif-
luoromethyl groups in solution are also suggested by the
high-field shifts of the ethanol peaks (δ 0.34 (t, -OH); 0.73
1
(t, -CH3); 2.94 (m, -CH2-)) in the H NMR spectrum of
(56) Co(TPP(CF3)4)(py): Pyridine[2,3,12,13-tetrakis(trifluoromethyl)-5,-
10,15,20-tetraphenylporphyrinato]cobalt(II). Manuscript in preparation.
(57) Zn(TPP(CN)4): (2,3,12,13-Tetracyano-5,10,15,20-tetraphenylporphy-
rinato)zinc(II). Source for the redox potentials of Zn(TPP(CN)4):
Giraudeau, A.; Callot, H. J.; Gross, M. Inorg. Chem. 1979, 18, 201.
(58) σp values for the substituents were obtained from ref 58a. See ref 58b
for the redox potentials vs σ values. (a) Hansch, C.; Leo, A.; Taft, R.
W. Chem. ReV. 1991, 91, 165. (b) Kadish, K. M.; Morrison, M. M. J.
Am. Chem. Soc. 1976, 98, 3326.
1b in CDCl3. The large high-field shifts of the ethanol signals
of 1b, compared to free ethanol in CDCl3 (δ 1.18 (t, -CH3);
2.05 (bs, -OH); 3.65 (q, -CH2-)), indicates that the ethanol
molecules in 1b exist in the pocket created by the four
(55) Scheidt, W. R. In The Porphyrins; Dolphin, D., Ed.; Academic Press:
New York, 1978; p 463.
Inorganic Chemistry, Vol. 41, No. 25, 2002 6709

Terazono et al.
coplanarity of the porphyrinato ligand. This implies that
macrocyclic distortion is also unlikely in the four-coordinate
Zn(TPP(CN)4). Thus, the HOMO-LUMO gap contraction
should be mainly related to the electronic effect of the
â-substituents. In a recent report, we demonstrated that a
dramatic HOMO-LUMO gap contraction is observed for
the free bases of â-trifluoromethyl-meso-tetraphenylpor-
phyrins with a fixed 18π-electron pathway.32 Thus, the large
HOMO-LUMO gap contraction in 1a presumably originates
from its unique electronic structure. In â-octasubstituted
porphyrins the electronic effect of peripheral substituents
does not normally affect the HOMO-LUMO gap whereas
macrocyclic distortion does.59 It should be noted that the gap
contraction observed for the antipodally â-substituted electron-
deficient porphyrins such as 1a or Zn(TPP(CN)4) is signifi-
cantly larger (>600 mV) when compared to an offset by
severe macrocyclic distortion (<500 mV for Zn(II) com-
plexes of â-octabromoporphyrins61,62). It also should be noted
that the HOMO-LUMO gap of [meso-tetrakis(trifluorom-
ethyl)porphyrinato]zinc(II) (Zn(P(CF3)4))27 has been reported
as 2.15 V (in benzonitrile), which is similar to that of Zn-
(TPP). The large difference between 1a and Zn(P(CF3)4)
indicates that the position of the groups affects the HOMO-
LUMO gap greatly. The electronic effect of the groups in
3a is not significant.
Figure 5. Cyclic voltammetric analysis of the four-coordinate antipodal
â-tetrasubstituted meso-tetraphenylporphyrin Zn(II) complexes: (a) cyclic
voltammogram of 1a in CH2Cl2 at [1a] ) 0.001 M, [TBAPF6] ) 0.1 M,
and a scan rate of 50 mV/s, and (b) 4σp vs the first oxidation (b) and the
first reduction (O) potentials. The white arrow in part a of the figure indicates
the internal reference; ferrocene/ferrocenium coupling.
Conclusion
A comparative analysis of the structures of three 2,3,12,-
13-tetrasubstituted porphyrins determined by X-ray crystal-
lography revealed that the electronic and steric effects of
pyrrolic â-trifluoromethyl groups on the macrocycle are
dramatic. Steric interactions between the trifluoromethyl and
phenyl groups and the strong electron-withdrawing effect of
the trifluoromethyl groups are the driving force for the severe
macrocycle in-plane and out-of-plane distortions. The elec-
tronic structure, specifically of 1a, also reveals the dramatic
effects of the â-trifluoromethyl substitution where, as with
the free base,32 the 18π-aromatic system is locked and avoids
the atoms bearing these groups.
oxidation potential for 1a (â-CF3) from this curve is about
0.2 V, which is probably off set by the porphyrin macrocycle
distortion. Previous studies have shown that oxidation of the
macrocycle is sensitive to structural changes of the porphyrin
and the reduction is not; nonplanarity of the macrocycle
contributes to lowering the energy level of the HOMO, and
that of the LUMO changes linearly with the electron-
withdrawing effect of the substituents regardless of the
structural changes of the macrocycle.59-61 The plots of the
reduction potentials in Figure 5b show an interesting result,
in which the reduction potential is not proportional to the
sum of the σp value, and the plots show a gentle sigmoid
curve. The number of available data is limited, but the
plots show that both oxidation and reduction potentials
seem to be leveling off at higher 4σp values leading to a
narrow HOMO-LUMO gap. It is unlikely that the four-
coordinate Zn(II) complexes except for 1a have very
distorted macrocycles, and crystal structure analysis for
hexacoordinate Ni(II) complexes of â-tetracyano-TPP showed
Acknowledgment. We thank Prof. Brian James and his
group in the Department of Chemistry at the University of
British Columbia for their generous support of the cyclic
voltammetric measurements. This work was supported by
the Natural Science and Engineering Research Council of
Canada.
Supporting Information Available: Table of redox potentials
of 1a-3a. X-ray crystallographic files in CIF format. This material
is available free of charge via the Internet at http://pubs.acs.org.
(59) Takeuchi, T.; Gray, H. B.; Goddard, W. A., III. J. Am. Chem. Soc.
1994, 116, 9730.
(60) Ochsenbein, P.; Ayougou, K.; Mandon, D.; Fischer, J.; Weiss, R.;
Austin, R. N.; Jayaraj, K.; Gold, A.; Terner, J.; Fajar, J. Angew. Chem.,
Int. Ed. Engl. 1994, 33, 348.
IC020339H
(61) D’Souza, F.; Zandler, M. E.; Tagliatesta, P.; Ou, Z.; Shao, J.; Van
Caemelbecke, E.; Kadish, K. M. Inorg. Chem. 1998, 37, 4567.
(62) Hodge, J. A.; Hill, M. G.; Gray, H. B. Inorg. Chem. 1995, 34, 809.
6710 Inorganic Chemistry, Vol. 41, No. 25, 2002
