1272
D. N. Nguyen et al. / Bioorg. Med. Chem. Lett. 12 (2002) 1269–1273
versus GGPTase-I (IC50=16 nM) compared to analo-
gous 16-membered ring-contracted macrocycles.19 To
further increase GGPTase-I activity, modifications to
20a were investigated. As in the linear series, various
groups were introduced to replace the p-cyano group.
The synthetic route to obtain 20a–b and 21a–e is
described in Scheme 4. The trityl histamine 15 was
available from histamine by a protection–alkylation–
deprotection sequence. 15 was alkylated with 1619 to
provide 17. Reductive alkylation with glycol aldehyde
dimer, followed by Mitsunobu-type ring closure of
the piperazinone12 yielded 18. Alkylation of 18 with
4-bromo-3-fluorobenzyl alcohol followed by deprotec-
tion of the imidazole gave 19. SNAr macrocyclization of
19 proceeded to provide 20, even with the marginally
activated 3-fluoro-4-bromobenzyl group.20 The 4-bro-
mophenyl macrocycle 20b underwent either Suzuki
coupling with p-trifluoromethylphenyl boronic acid
(21a) or Stille coupling with tetra-n-butyl tin (21c) or
tributylalkynyl tin (21d). During purification of 21c, a
small amount of reduced by-product 21b was isolated.
Alkyl-substituted 21e was obtained from palladium
catalyzed hydrogenation of 21d.
identified 4-trifluoromethylphenyl (5h, 13a, and 13b) as
a good p-cyano replacement. In the constrained macro-
cylic analogues of 20a, excellent inhibitory activities
against both FPTase and GGPTase-I were obtained
with 4-trifluoromethylphenyl, trifluoropentynyl and tri-
fluoropentyl substituents. Both series showed effective
functional inhibition of FPTase and GGPTase-I activity
in cell culture.
Acknowledgements
The authors wish to thank K. D. Anderson, A. B.
Coddington, G. M. Smith, H. G. Ramjit, C. W. Ross
III, B.-L. Wan, and M. M. Zrada for analytical support,
and C. J. Dinsmore and S. L. Graham for critical reading
of the manuscript.
References and Notes
1. Rodenhuis, S. Semin. Cancer Biol. 1992, 3, 241.
2. (a) Barbacid, M. Annu. Rev. Biochem. 1987, 56, 779.
(b) Kato, K.; Cox, A. D.; Hisaka, M. M.; Graham, S. M.;
Buss, J. E.; Der, C. J. Proc. Natl. Acad. Sci. U.S.A. 1992, 89,
6403.
3. (a) Casey, P. J.; Solski, P. J.; Der, C. J.; Buss, J. E. Proc.
Natl. Acad. Sci. U.S.A. 1989, 86, 8323. (b) Gibbs, J. B. Cell
1991, 65, 1. (c) Gibbs, J. B.; Oliff, A. I.; Kohl, N. E. Cell 1994,
77, 175.
4. (a) Bos, J. L. Cancer Res. 1989, 49, 4682. (b) Clark, G. J.;
Der, C. J. Cell. Cancer Markers 1995, 17.
5. Moomaw, J. F.; Casey, P. J. J. Biol. Chem. 1992, 267,
17438.
Interestingly, synthetic intermediate 20b still maintained
good potency in the FPTase (IC50=1.2 nM) and
CRAFTI (IC50=2.0 nM) assays, though it was 10-fold
less active versus GGPTase-I compared to the p-cyano
analogue 20a (Table 2). As anticipated, 21a, which
contained the p-trifluoromethylphenyl substituent, was
a potent inhibitor. Compared to 20a, 21a was approxi-
mately 10-fold less active versus FPTase (IC50=2.1 nM)
and CRAFTI (IC50=1.1 nM), although its activity ver-
sus GGPTase-I (IC50=15.6 nM) was undiminished.
Molecular modeling of the p-cyanophenyl group of 20a
into the FPTase active site indicated that the lipophilic
binding pocket might be long enough to accommodate a
longer substituent.15 To test this hypothesis, 4-n-butyl
analogue 21c was synthesized. Unfortunately, 21c was
not as active as 20a with respect to FPTase or
GGPTase-I inhibition. The reduced activity of 21c
could have been due to several factors: the carbon chain
might not be long enough or too flexible, resulting in
weaker affinity to the enzymes. To further explore the
modeling prediction, 21d and 21e were made. Although
both 21d and 21e were moderately active versus FPTase
with IC50=6.1 nMand IC 50=3.1 nM, respectively, they
were almost 10-fold more potent in cell culture. Because
the CRAFTI assay incubates inhibitors with the enzyme
for a longer time than in the FPTase assay, the differ-
ence in the CRAFTI/FPTase ratio of 21d and 21e may
be the result of slow-binding, although this hypothesis
was not directly tested.21 HDJ2 and Rap1a processing
in PSN-1 cells was inhibited by 21e with EC50=6.9 nM
and EC50=800 nM, respectively. The best GGPTase-I
inhibitor in this series was 21d, which was also the most
balanced FTI/GGPTI. Overall, these substituted-phenyl
macrocycles had good potency with respect to FPTase,
GGPTase-I and especially CRAFTI.
6. (a) CaaX; ‘C’=cysteine, ‘a’=any aliphatic amino acid,
‘X’=a prenylation specificity residue. (b) Reiss, Y.; Goldstein,
J. L.; Seabra, M. C.; Casey, P. J.; Brown, M. S. Cell 1990, 62,
81.
7. Bell, I. M. Exp. Opin. Ther. Pat. 2000, 10, 1813.
8. (a) Ciccarone, T. M.; MacTough, S. C.; Williams, T. M.;
Dinsmore, C. J.; O’Neill, T. J.; Shah, D.; Culberson, J. C.;
Koblan, K. S.; Kohl, N. E.; Gibbs, J. B.; Oliff, A. I.; Graham,
S. L.; Hartman, G. D. Bioorg. Med. Chem. Lett. 1999, 9, 1991.
(b) Anthony, N. J.; Gomez, R. P.; Schaber, M. D.; Mosser,
S. D.; Hamilton, K. A.; O’Neil, T. J.; Koblan, K. S.; Graham,
S. L.; Hartman, G. D.; Shah, D.; Rands, E.; Kohl, N. E.;
Gibbs, J. B.; Oliff, A. I. J. Med. Chem. 1999, 42, 3356.
9. Williams, T. M.; Bergman, J. M.; Brashear, K.; Breslin,
M. J.; Dinsmore, C. J.; Hutchinson, J. H.; MacTough, S. C.;
Stump, C. A.; Wei, D. D.; Zartman, C. B.; Bogusky, M. J.;
Culberson, J. C.; Buser-Doepner, C.; Davide, J.; Greenberg,
I. B.; Hamilton, K. A.; Koblan, K. S.; Kohl, N. E.; Motzel,
S. L.; Gibbs, J. B.; Graham, S. L.; Heimbrook, D. C.; Hart-
man, G. D.; Oliff, A. I.; Huff, J. R. J. Med. Chem. 1999, 42,
3779.
10. Williams, T. M.; Dinsmore, C. J.; Bogusky, M. J.; Cul-
berson, J. C.; Bergman, J. M.; Nguyen, D. N.; Stump, C. A.;
Zartman, C. B.; Buser, C. A.; Huber, H. E.; Koblan, K. S.;
Kohl, N. E.; Lobell, R. B.; Kassahun, K.; Rodrigues, D. D.;
Gibbs, J. B.; Heimbrook, D. C.; Hartman, G. D.; Huff, J. R.;
Graham, S. L. 222nd National Meeting of the American
Chemical Society, Chicago, IL, Aug 26–30, 2001; MEDI-2.
11. Askin, D.; Cowen, J. A.; Maligres, P. E.; Mcwilliams, C.
J.; Waters, M. S. U.S. Patent 6,239,280, 2001; Chem. Abstr.
2001, 134, 366876.
Exploring biaryl replacements for the p-cyanophenyl
group has led to the discovery of highly potent dual
FTI/GGTI analogues of 1. In the linear series, we
