Paquette and Lo
H), 5.66 (d, J ) 6.7 Hz, 1 H), 4.74 (d, J ) 12.1 Hz, 1 H), 4.69-
4.65 (m, 2 H), 4.59 (d, J ) 4.2 Hz, 1 H), 4.20 (s, 1 H), 4.11 (s,
1 H), 4.07 (dd, J ) 5.4, 10.0 Hz, 1 H), 4.01 (d, J ) 10.3 Hz, 1
H), 3.28 (s, 3 H), 3.27 (m, 1 H), 2.62 (dd, J ) 6.6, 18.6 Hz, 1 H)
2.39 (s, 3 H), 2.26-2.25 (m, 1 H), 2.07-1.91 (m, 3 H), 1.80-
1.79 (m, 1 H), 1.66 (s, 3 H), 1.30 (s, 3 H), 0.93 (s, 9 H), 0.75 (s,
3 H), 0.07 (s, 3 H), -1.84 (s, 3 H); 13C NMR (75 MHz, CDCl3)
δ 213.8, 210.2, 164.6, 159.4, 133.5, 131.5, 130.6, 129.8, 129.6,
129.3, 128.8, 113.9, 83.4, 83.2, 73.4, 73.1, 71.7, 71.2, 57.4, 55.2,
51.8, 42.7, 40.4, 38.2, 37.9, 31.4, 30.9, 27.4, 25.8, 22.7, 18.3,
11.8, -1.9, -4.0; ES HRMS m/z (M + Na)+ calcd 807.3210,
3.27 (m, 1 H), 2.44-2.40 (m, 2 H), 2.38-2.29 (m, 2 H), 2.21-
2.05 (m, 1 H), 1.94-1.89 (m, 1 H), 1.81-1.79 (m, 1 H), 1.58 (s,
3 H), 1.51 (s, 3 H), 0.97 (s, 3 H), 0.83 (s, 9 H), -0.04 (s, 3 H),
-0.18 (s, 3 H); ES HRMS m/z (M + Na)+ calcd 761.3333, obsd
761.3340; [R]20 -53 (c 0.16, CHCl3).
D
Rin g Clea va ge of 16 w ith Osm iu m Tetr a oxid e. To a
solution of 16 (2 mg, 2.8 µmol) in acetone (1 mL) and H2O (0.2
mL) was added neat OsO4 (0.8 mg, 3.1 µmol). The solution was
stirred at rt for 5 h, sodium dithionite solution (5 mL) was
introduced, and after 3 h the resulting mixture was extracted
with EtOAc (2 × 10 mL). The combined organic extracts were
dried, filtered, and concentrated. The residue was subjected
to flash chromatography on silica gel (elution with 1:1 hexane/
EtOAc) to furnish 21 (1.5 mg, 71%) as a colorless oil identical
to the material isolated above.
obsd 807.3198; [R]20 +7.3 (c 0.66, CHCl3).
D
Osm a te Ester 19. To a solution of 16 (8.3 mg, 0.012 mmol)
in THF (2 mL) and pyridine (1 mL) was added neat OsO4 (3.3
mg, 0.013 mmol) at 0 °C. The reaction mixture was stirred for
20 min, treated with saturated sodium hydrosulfite solution
(5 mL), and stirred for 3 h. Following extraction with EtOAc
(2 × 10 mL), the combined organic phases were dried, filtered,
and concentrated. Flash chromatography of the residue on
silica gel (elution with EtOAc) afforded 19 (4.7 mg, 83% at
65% conversion) as a pale brown oil along with 2.9 mg (35%)
of recovered 16.
Mon osilyla tion of 20. To a solution of 20 (2.0 mg, 2.7 µmol)
in CH2Cl2 (2 mL) were added 2,6-lutidine (9.4 µL, 0.081 mmol)
and TMSCl (3.4 µL, 0.027 mmol) sequentially at -78 °C under
N2. The reaction mixture was stirred at this temperature for
20 min, saturated NaHCO3 solution (5 mL) was introduced,
and stirring was maintained for 10 min prior to extraction with
EtOAc (2 × 10 mL). The combined organic extracts were dried,
filtered, and concentrated. Flash chromatography of the
residue on silica gel (elution with 10:1 hexane/EtOAc) afforded
22 (2.2 mg, 100%) as a colorless oil: IR (neat, cm-1) 3452, 1723,
1252; 1H NMR (400 MHz, C6D6) δ 8.39-8.19 (m, 2 H), 7.45 (d,
J ) 8.6 Hz, 2 H), 6.99-6.96 (m, 3 H), 6.79 (d, J ) 13.7 Hz, 2
H), 6.15-6.13 (m, 1 H), 5.05 (d, J ) 3.9 Hz, 1 H), 4.85 (dd, J
) 5.0, 11.6 Hz, 1 H), 4.70 (d, J ) 10.1 Hz, 1 H), 4.32 (s, 1 H),
4.24 (d, J ) 10.1 Hz, 1 H), 4.11 (d, J ) 5.2 Hz, 1 H), 3.88 (d,
J ) 10.2 Hz, 1 H), 3.72 (s, 1 H), 3.69 (s, 1 H), 3.37 (d, J ) 10.3
Hz, 1 H), 3.26 (s, 3 H), 2.84 (br s, 1 H), 2.56 (dd, J ) 6.8, 19
Hz, 1 H), 2.31 (br s, 1 H), 2.28-2.25 (m, 1 H), 2.16-2.03 (m,
2 H), 1.84-1.78 (m, 2 H), 1.67 (s, 3 H), 1.31 (s, 3 H), 0.92 (s, 9
For 19: IR (neat, cm-1) 3451, 1718, 1512; 1H NMR (400
MHz, CDCl3) δ 8.42-8.40 (m, 2 H), 7.36-7.29 (m, 5 H) 6.86-
6.84 (m, 2 H), 5.73 (d, J ) 2.7 Hz, 1 H), 4.95-4.92 (m, 1 H),
4.92 (s, 1 H), 4.78 (dd, J ) 4.8, 11.8 Hz, 1 H), 4.57 (br s, 1 H),
4.50 (d, J ) 10.7 Hz, 1 H), 4.19 (d, J ) 2.7 Hz, 1 H), 4.10 (d,
J ) 8.4 Hz, 1 H), 4.02 (s, 1 H), 3.98 (d, J ) 7.4 Hz, 1 H), 3.78
(s, 3 H), 3.53-3.48 (m, 1 H), 2.52 (s, 1 H), 2.37-2.30 (m, 5 H),
2.03-1.91 (m, 2 H), 1.34 (s, 3 H), 1.10 (s, 3 H), 0.85 (s, 3 H),
0.82 (s, 9 H), 0.07 (s, 3 H), 0.00 (s, 3 H); [R]20 -89 (c 0.24,
D
CHCl3).
Osm iu m Tetr a oxid e Oxid a tion of 16. To a solution of
16 (2 mg, 2.8 µmol) in THF (2 mL) and DABCO (0.6 mg, 5.6
µmol) was added neat OsO4 (0.7 mg, 2.8 µmol) at rt. As the
reaction mixture turned to bright red, it was stirred for 24 h,
treated with sodium dithionite (4.9 mg, 0.028 mmol) in water
(2 mL), stirred 3 h longer, and extracted with EtOAc (2 × 10
mL). The combined organic extracts were dried, filtered, and
concentrated. The residue was purified by flash chromatog-
raphy on silica gel (elution with 1:1 hexane/EtOAc) to give 20
(1.8 mg, 75%) as a colorless oil: IR (neat, cm-1) 3470, 1719,
1706, 1514; 1H NMR (400 MHz, CDCl3) δ 7.94 (d, J ) 7.2 Hz,
2 H), 7.54-7.52 (m, 1 H), 7.44-7.40 (m, 2 H), 7.26 (d, J ) 8.5
Hz, 2 H), 6.81 (d, J ) 8.5 Hz, 2 H), 5.71 (d, J ) 5.8 Hz, 1 H),
4.79 (d, J ) 4.0 Hz, 1 H), 4.55 (dd, J ) 4.3, 11.6 Hz, 1 H), 4.43
(d, J ) 10.5 Hz, 1 H), 4.06 (d, J ) 10.6 Hz, 1 H), 3.99 (s, 1 H),
3.87 (br s, 1 H), 3.82 (d, J ) 5.8 Hz, 1 H), 3.74 (s, 3 H), 3.56 (d,
J ) 10.2 Hz, 1 H), 3.43-3.41 (m, 1 H), 3.36 (s, 1 H), 3.16-
3.06 (m, 1 H), 2.77 (s, 1 H), 2.77-2.72 (m, 1 H), 2.36-2.26 (m,
2 H), 2.18-2.16 (m, 1 H), 1.94-1.93 (m, 1 H), 1.88-1.80 (m, 1
H), 1.80-1.70 (m, 1 H), 1.30 (s, 3 H), 1.03 (s, 3 H), 0.87 (s, 3
H), 0.78 (s, 9 H), 0.01 (s, 3 H), -0.06 (s, 3 H); 13C NMR (75
MHz, CDCl3) δ 212.3, 208.9, 165.2, 159.4, 152.8, 133.8, 129.8,
129.5, 128.98, 128.9, 113.8, 84.2, 81.6, 75.2, 74.0, 73.5, 71.5,
67.2, 62.9, 58.7, 55.2, 51.3, 42.1, 38.9, 38.0, 32.9, 31.0, 29.6,
25.7, 22.7, 18.2, 10.0, -2.1, -4.2; ES HRMS m/z (M + Na)+
H), 0.76 (s, 3 H), 0.01 (s, 3 H), 0.00 (s, 3 H), -0.34 (s, 9 H); 13
C
NMR (75 MHz, C6D6) δ 210.8, 208.3, 177.6, 165.5, 159.6, 132.8,
130.2, 130.1, 129.8, 128.4, 113.7, 84.2, 82.9, 74.2, 73.9, 71.1,
67.6, 62.9, 59.0, 54.4, 51.4, 42.3, 38.9, 37.7, 33.2, 30.8, 28.2,
25.7, 22.6, 18.2, 10.1, -1.7, -2.3, -4.6; ES HRMS m/z (M +
Na)+ calcd 835.3885, obsd 835.3837; [R]20D +3.1 (c 0.37, CHCl3).
Desilyla tive Mesyla tion of 22. To a solution of 22 (2 mg,
2.0 µmol) in pyridine (2 mL) was added MsCl (2 µL, 0.02 mmol)
at 0 °C. The solution was warmed to rt, stirred for 24 h, and
quenched with NaHCO3 solution (5 mL). The resulting mixture
was extracted with EtOAc (2 × 10 mL), and the combined
organic extracts were dried, filtered, and concentrated. Flash
chromatography of the residue on silica gel (elution with 1:1
hexane/EtOAc) afforded 23 (2 mg, 100%) as a colorless oil: 1H
NMR (500 MHz, C6D6) δ 8.18 (d, J ) 7.2 Hz, 2 H), 7.42 (d, J
) 8.6 Hz, 2 H), 7.04-6.96 (m, 3 H), 6.82 (d, J ) 8.6 Hz, 2 H),
6.10 (d, J ) 5 Hz, 1 H), 4.64 (d, J ) 10 Hz, 1 H), 4.73 (dd, J )
5.1, 11.5 Hz, 1 H), 4.64 (d, J ) 10 Hz, 1 H), 4.53 (d, J ) 12 Hz,
1 H), 4.29 (d, J ) 12 Hz, 1 H), 4.25 (s, 1 H), 4.18 (d, J ) 10 Hz,
1 H), 4.12 (d, J ) 4.8 Hz, 1 H), 4.09 (br s, 1 H), 3.30 (s, 1 H),
3.26 (s, 3 H), 3.26-3.25 (m, 1 H), 2.55 (dd, J ) 7.1, 18 Hz, 1
H), 2.41 (br s, 2 H), 2.27-2.13 (m, 2 H), 2.12-2.08 (m, 2 H),
1.75 (s, 3 H), 1.74-1.73 (m, 1 H), 1.58 (s, 3 H), 1.27 (s, 3 H),
0.91 (s, 9 H), 0.72 (s, 3 H), -0.037 (s, 3 H), -0.039 (s, 3 H); ES
HRMS m/z (M + Na)+ calcd 841.3265, obsd 841.3295.
Silyl-P r otected Mesyla te 24. To a solution of 22 (2 mg,
0.002 mmol) in CH2Cl2 (20 mL) were added DMAP (48 mg,
0.4 mmol) and methanesulfonyl chloride (2 µL, 0.02 mmol)
sequentially at 0 °C. The reaction mixture was warmed to rt,
stirred for 24 h, and quenched with saturated NaHCO3
solution (5 mL). The product was extracted into EtOAc (2 ×
10 mL), the combined organic extracts were dried, filtered, and
concentrated, and the residue was flash chromatographed
(elution with 5:1 hexane/EtOAc) to afford 24 (1.9 mg, 90%) as
a colorless oil: IR (neat, cm-1) 3461, 1724, 1513; 1H NMR (500
MHz, C6D6) δ 8.11 (d, J ) 7.2 Hz, 2 H), 7.50 (d, J ) 8.6 Hz, 2
H), 7.05-7.02 (m, 1 H), 6.98-6.95 (m, 2 H), 6.90 (d, J ) 8.6
Hz, 2 H), 6.15-6.13 (m, 1 H), 5.11 (d, J ) 3.6 Hz, 1 H), 5.06
calcd 763.3490, obsd 763.3432; [R]20 +5.2 (c 0.56, CHCl3).
D
Ru th en iu m Tetr a oxid e-P r om oted Oxid a tion of 16. A
solution of 16 (5 mg, 7.0 µmol) in 1:1 acetonitrile/EtOAc (2 mL)
cooled to 0 °C was treated via cannula with a solution of
ruthenium trichloride (0.1 m, 0.49 µmol) and sodium periodate
(1.5 mg, 7.0 µmol) in water (0.5 mL). The reaction mixture
was stirred at 0 °C for 2 min, treated with a saturated solution
of sodium dithionite (5 mL), and extracted with EtOAc (2 × 5
mL). The combined organic phases were processed as described
above to give 2.5 mg (40%) of 20 and 2.7 mg (47%) of 21.
1
For 21: colorless oil; IR (neat, cm-1) 3446, 1717, 1515; H
NMR (500 MHz, CDCl3) δ 9.61 (s, 1 H), 8.06-8.04 (m, 2 H),
7.63-7.60 (m, 1 H), 7.52-7.49 (m, 2 H), 7.294-7.290 (m, 2
H), 6.95-6.93 (m, 2 H), 4.82 (d, J ) 10.6 Hz, 1 H), 4.19 (d, J
) 2.5 Hz, 1 H), 4.07 (s, 1 H), 3.86 (s, 3 H), 3.43 (s, 1 H), 3.34-
2288 J . Org. Chem., Vol. 68, No. 6, 2003
