Enantioselective synthesis of "quaternary" 1,4-benzodiazepin-2-one scaffolds via memory of chirality

Article abstract of DOI:10.1021/ja0365781

Glycine-derived 1,4-benzodiazepine-2-ones such as diazepam are chiral by virtue of the boat-shaped conformation of the diazepine ring and exist as a racemic mixture of conformational enantiomers. However, the presence of a chiral center at C-3 of the benz

Full text of DOI:10.1021/ja0365781

Published on Web 08/28/2003
Enantioselective Synthesis of “Quaternary” 1,4-Benzodiazepin-2-one
Scaffolds via Memory of Chirality
Paul R. Carlier,* Hongwu Zhao, Joe DeGuzman, and Polo C.-H. Lam
Department of Chemistry, Virginia Tech, Blacksburg, Virginia 24061
Received June 9, 2003; E-mail: pcarlier@vt.edu
Scheme 1. Dynamic Chirality of 1a-c and Stereochemical
Cooperativity in 2b (∆Gq Values Were Determined by 1H NMR
Spectroscopy (Coalescense))
1,4-Benzodiazepines are among the most important scaffolds in
medicinal chemistry, representing the prototypical “privileged
structure”.1 Tens of thousands of these compounds have been
prepared on solid phase and in solution, and the development of
new 1,4-benzodiazepine drug candidates shows no sign of abating.2
Yet amidst this impressive diversity, the reliance of most of these
syntheses upon proteinogenic amino acid starting materials has
systematically excluded one class of targets: enantiopure benzo-
diazepines possessing a quaternary stereogenic center.3 In this
Communication, we report an enantioselective R-alkylation route
to “quaternary” 1,4-benzodiazepin-2-ones that relies upon the
intrinsic chirality of the benzodiazepine ring.
Despite the absence of a stereogenic center, glycine-derived 1,4-
benzodiazepin-2-ones 1 such as diazepam (1b) are chiral,4,5 existing
as (M)- and (P)-conformational enantiomers6 (Scheme 1). When
the N1 substituent is relatively small (H, Me, i-Pr, i.e., 1a-c),
racemization is facile at room temperature, preventing resolution
of these compounds.4,7 Only when the N1 substituent is very large
(e.g., 1d, R1 ) t-Bu) is the racemization barrier high enough to
allow preparative resolution of the (M)- and (P)-enantiomers.4,8
It is well known5,8-10 that placement of a single substituent at
C3 perturbs the conformational equilibrium of N-Me 1,4-benzodi-
azepin-2-ones (e.g., 2b), stabilizing the pseudoequatorial conformer;
thus, (3S)-stereochemistry will induce the diazepine ring to adopt
the (M)-conformation (Scheme 1). We envisioned that the effective
stereochemical cooperativity demonstrated by 3-alkyl-1,4-benzo-
diazepin-2-ones such as 2b might allow the development of an
enantioselective R-alkylation protocol. Although deprotonation of
(3S)-2b would destroy the stereogenic center at C3, the resulting
enolate would remain chiral by virtue of the nonplanar diazepine
ring. Deprotonation/alkylation sequences of glycine-derived 1,4-
benzodiazepin-2-ones have been previously reported11 as a means
to prepare novel benzodiazepines and the corresponding amino
acids, including an auxiliary-based asymmetric method.11b However,
the only reported R-alkyation route to 3,3-dialkyl-1,4-benzodiaz-
epin-2-ones affords low (0-20%) yields.11a
Enantiomerically pure 1,4-benzodiazepin-2-ones (3S)-2a and
(3S)-3a (R1 ) H) were prepared in 91% and 67% yield from (S)-
Boc-Ala and (S)-Boc-Phe, using a modification of Shea’s protocol.12
Conversion to the N-Me (2b 94%) and the N-i-Pr derivatives (2c
82%; 3c, 58%) in 100% ee was achieved upon treatment of the
sodium salts with the corresponding alkyl triflates.13 After consider-
able optimization, we determined that acceptable yields of desired
R-alkylation products could be attained by deprotonating 2b-c and
3c with LDA in the presence of HMPA, and treatment with n-BuLi
before addition of the electrophile (Table 1).14 However, application
of this protocol to the enolate of N-Me benzodiazepine (3S)-2b
and BnBr gave 4 in a disappointing 0% ee. Fortunately, identical
treatment of the N-i-Pr analogue (3S)-2c gave the desired product
5 in 97% ee (Table 1, cf. entries 1, 2). Knowing that the inversion
barrier of benzodiazepines is a function of the size of the N1
Table 1. Racemizing (2b) and Enantioselective (2c, 3c)
Deprotonation/Trapping Reactions of 1,4-Benzodiazepin-2-ones
a
entry
R
1
R
2
E
product
% yield
% eeb
1
2
3
4
5
6
7
8
Me
Me
Me
Me
Me
Me
Me
Bn
Bn
Bn
(()-4
(+)-5
(+)-6
(+)-7
(+)-8
(+)-9
(-)-5
(+)-10
72
74
68
70
76
85d
64
57
0c
97 (3R)
95 (3R)
99
i-Pr
i-Pr
i-Pr
i-Pr
i-Pr
i-Pr
i-Pr
4-MeC6H4CH2
2-PhC6H4CH2
allyl
D
Me
allyl
94
99 (3S)
95 (3S)
86
Bn
a Electrophiles used: BnBr, 4-MeC6H4CH2Br, 2-PhC6H4CH2Br, allyl
bromide, D-OTFA, MeI. b % ee measured by chiral stationary phase HPLC
(Chiralcel OD, AD). c Racemic 4 is also obtained if BnBr is added only 10
s after deprotonation by LDA. d The extent of deuteration is 96%.
substituent (Scheme 1), we reason that an N-Me group is not large
enough to impart sufficient conformational stability to the enolate
ring at -78 °C on the deprotonation/alkylation time scale. Even
with short deprotonation times (LDA only, 10 s), N-Me benzodi-
azepine (3S)-2b produces racemic 4. In contrast, deprotonation/
trapping reactions of the N-i-Pr analogues examined thus far are
highly enantioselective. In addition to benzylation, reaction of the
enolate derived from (3S)-2c with other active electrophiles proceeds
9
11482
J. AM. CHEM. SOC. 2003, 125, 11482-11483
10.1021/ja0365781 CCC: $25.00 © 2003 American Chemical Society

C O M M U N I C A T I O N S
(Table 1, entries 1, 2) may be rationalized. Finally, consistent with
this high racemization t1/2 estimate for 13c, we find that, after a
deprotonation time of 8 h at -78 °C, benzylation of the enolate of
(3S)-2c occurs in 92% ee (cf. Table 1, entry 2).
Acknowledgment. We thank the National Science Foundation
(CHE-0213525), the Jeffress Memorial Trust, and the Virginia Tech
Department of Chemistry for financial support.
Supporting Information Available: Experimental procedures,
spectroscopic data and HPLC chromatograms, and computational details
(PDF). This material is available free of charge via the Internet at http://
pubs.acs.org.
Figure 1. B3LYP/6-31G* equilibrium geometry and ring inversion
transition structure of N-i-Pr enolate anion 13c (relative free energies at
B3LYP/6-31+G*//B3LYP/6-31G*).
Scheme 2. Correlation of Benzodiazepines 5 and 6 by
Conversion to the Corresponding Quaternary Amino Acids 11 and
References
(1) Evans, B. E.; Rittle, K. E.; Bock, M. G.; DiPardo, R. M.; Freidinger, R.
M.; Whitter, W. L.; Lundell, G. F.; Veber, D. F.; Anderson, P. S.; Chang,
R. S. L.; Lotti, V. J.; Cerino, D. J.; Chen, T. B.; Kling, P. J.; Kunkel, K.
A.; Springer, J. P.; Hirschfield, J. J. Med. Chem. 1988, 31, 2235-2246.
(2) (a) Ellman, J. A. Acc. Chem. Res. 1996, 29, 132-143. (b) Wu, Z.; Ercole,
F.; FitzGerald, M.; Perera, S.; Riley, P.; Campbell, R.; Pham, Y.; Rea,
P.; Sandanayake, S.; Mathieu, M. N.; Bray, A. M.; Ede, N. J. J. Comb.
Chem. 2003, 5, 166-171.
12
(3) The only published route to such compounds involves lipase-catalyzed
acylation of prochiral 3,3-bis(hydroxymethyl)-1,4-benzodiazepin-2-
ones: Avdagic, A.; Lesac, A.; Majer, Z.; Hollosi, M.; Sunjic, V. HelV.
Chim. Acta 1998, 81, 1567-1582.
(4) Linscheid, P.; Lehn, J.-M. Bull. Chim. Soc. Fr. 1967, 992-997.
(5) Konowal, A.; Snatzke, G.; Alebic-Kolbah, T.; Kajfez, F.; Rendic, S.;
Sunjic, V. Biochem. Pharm. 1979, 28, 3109-3113.
(6) The sense of chirality of the ring has traditionally been described using
the helical descriptors (M)- and (P)-, based on the sign of the τ2345 torsional
angle. The same sense of chirality is noted using the more easily perceived
τ(R1)178 or τ2176 torsional angles.
in 94-99% ee (Table 1, entries 3-6). High enantioselectivities are
also observed in methylation and allylation of the enolate of Phe-
derived (3S)-3c (Table 1, entries 7, 8). Interestingly, H and 13C
1
(7) Application of the Eyring equation allows the racemization t1/2 values
(298 K) of 1a-c to be estimated as 60 µs, 0.9 s, and 2.8 min.
(8) Gilman, N. W.; Rosen, P.; Earley, J. V.; Cook, C.; Todaro, L. J. J. Am.
Chem. Soc. 1990, 112, 3969-3978.
NMR spectroscopy demonstrate that, unlike 2c and 3c, 3,3-
disubstituted benzodiazepines 4-8, 10 exist as ∼1:1 mixtures of
(M)- and (P)-conformers, consistent with the similar local steric
demands of the C3 substituents.15
The stereochemical course of these reactions appears to be
uniformly retentive. Retentive deuteration of the enolate of (3S)-
(+)-2c was established by comparison of (+)-9 with the starting
material. Retentive alkylation of the enolate of (3S)-2c was
established by hydrolysis of (+)-5 and (+)-6 to the corresponding
quaternary amino acids 11 and 12 (Scheme 2).
(9) Sunjic, V.; Lisini, A.; Sega, A.; Kovac, T.; Kajfez, F.; Ruscic, B. J.
Heterocycl. Chem. 1979, 16, 757-761.
(10) Paizs, B.; Simonyi, M. Chirality 1999, 11, 651-658.
(11) (a) Reitter, B. E.; Sachdeva, Y. P.; Wolfe, J. F. J. Org. Chem. 1981, 46,
3945-3949. (b) Decorte, E.; Toso, R.; Sega, A.; Sunjic, V.; Ruzic-Toros,
Z.; Kojic-Prodic, B.; Bresciani-Pahor, N.; Nardin, G.; Randaccio, L. HelV.
Chim. Acta 1981, 64, 1145-1149. (c) Kim, K.; Volkman, S. K.; Ellman,
J. A. J. Braz. Chem. Soc. 1998, 9, 375-379. (d) Goumri-Magnet, S.;
Guerret, O.; Gornitzka, H.; Cazaux, J. B.; Bigg, D.; Palacios, F.; Bertrand,
G. J. Org. Chem. 1999, 64, 3741-3744.
(12) Hart, B. R.; Rush, D. J.; Shea, K. J. J. Am. Chem. Soc. 2000, 122, 460-
465.
Retentive conversion of Phe-derived (3S)-3c to (3S)-(-)-5 was
confirmed by HPLC and optical rotation (Table 1, entries 2, 7).
The transformations of 2c and 3c described above can be viewed
as examples of Seebach’s “self-regeneration of stereocenters (SRS)”
principle.16 The novel feature here is the use of dynamic, confor-
mational chirality (rather than static, central chirality) to control
alkylation stereochemistry of the enolates; from this perspective,
these transformations also rely upon “memory of chirality”.17
Dynamic chirality of the enolates is suggested by the sensitivity
of the R-alkylation % ee to the size of the N1 substituent, and by
the calculated (B3LYP/6-31G*) equilibrium geometries and ring
inversion transition structures of the (des-chloro) enolate anions
13b,c (derived from 2b,c; 13c depicted in Figure 1).18 The
equilibrium geometries of enolates 13b,c are chiral and feature
essentially flat C3 carbons (sum of angles 358.5°, 359.0°). The ring
inversion transition structures of 13b,c indicate near eclipsing of
the N1 substituent (R1) and C8 (dihedral angles 13.4°, 12.8°).
B3LYP/6-31+G*//B3LYP/6-31G* activation free energies for ring
inversion at 195 K of 13b (N-Me) and 13c (N-i-Pr) are 12.4 and
17.5 kcal/mol, which correspond to racemization t1/2 (195 K) values
of 0.11 min and 970 h, respectively. Thus, the divergent stereo-
chemical outcomes for deprotonation/benzylation of 2b and 2c
(13) Less reactive alkylating agents (MeI, i-PrOTs) give partial racemization.
(14) No alkylation products are obtained in the absence of HMPA. If treatment
of the enolate with n-BuLi is not carried out before trapping, alkylation
and deuteration yields decrease, and significant amounts of starting material
are recovered. We suspect that enolate‚diisopropylamine complexes
produce starting material via an internal return mechanism, see: Seebach,
D. Angew. Chem., Int. Ed. Engl. 1988, 27, 1624-1654.
(15) 1H-1H EXSY NMR spectroscopy (297 K, CDCl3) of 5 indicates that the
conformers exchange at a rate of 0.2 s-1 (∆Gq ) 18.5 kcal/mol).
(16) Seebach, D.; Sting, A. R.; Hoffman, M. Angew. Chem., Int. Ed. Engl.
1996, 35, 2708-2748.
(17) (a) Kawabata, T.; Yahiro, K.; Fuji, K. J. Am. Chem. Soc. 1991, 113, 9694-
9696. (b) Fuji, K.; Kawabata, T. Chem.-Eur. J. 1998, 4, 373-376. (c)
Wanyoike, G. N.; Onomura, O.; Maki, T.; Matsumura, Y. Org. Lett. 2002,
4, 1875-1877. (d) Brewster, A. G.; Jayatissa, J.; Mitchell, M. B.;
Schofield, A.; Stoodley, R. J. Tetrahedron Lett. 2002, 43, 3919-3922.
(18) Frisch, M. J.; Trucks, G. W.; Schlegel, H. B.; Scuseria, G. E.; Robb, M.
A.; Cheeseman, J. R.; Zakrzewski, V. G.; Montgomery, J. A., Jr.;
Stratmann, R. E.; Burant, J. C.; Dapprich, S.; Millam, J. M.; Daniels, A.
D.; Kudin, K. N.; Strain, M. C.; Farkas, O.; Tomasi, J.; Barone, V.; Cossi,
M.; Cammi, R.; Mennucci, B.; Pomelli, C.; Adamo, C.; Clifford, S.;
Ochterski, J.; Petersson, G. A.; Ayala, P. Y.; Cui, Q.; Morokuma, K.;
Malick, D. K.; Rabuck, A. D.; Raghavachari, K.; Foresman, J. B.;
Cioslowski, J.; Ortiz, J. V.; Stefanov, B. B.; Liu, G.; Liashenko, A.;
Piskorz, P.; Komaromi, I.; Gomperts, R.; Martin, R. L.; Fox, D. J.; Keith,
T.; Al-Laham, M. A.; Peng, C. Y.; Nanayakkara, A.; Gonzalez, C.;
Challacombe, M.; Gill, P. M. W.; Johnson, B. G.; Chen, W.; Wong, M.
W.; Andres, J. L.; Head-Gordon, M.; Replogle, E. S.; Pople, J. A. Gaussian
98, revision A.11.1; Gaussian, Inc.: Pittsburgh, PA, 2001.
JA0365781
9
J. AM. CHEM. SOC. VOL. 125, NO. 38, 2003 11483
