Optical resolution of C₂-symmetric racemic 1,4-diols, 1,2-bis(1-hydroxyalkyl)benzene, was examined using (S)-5-allyl-2-oxabicyclo[3.3.0]octene ((S)-ALBO-V) as chiral resolving agent. Diastereomeric acetals obtained from the 1,4-diols with (S)-A

Full text of DOI:10.1246/bcsj.20150066

Short Articles
On the other hand, optical resolution is another method to
obtain optically active compounds. As for the optical resolution
of chiral secondary alcohols, (S)-5-allyl-2-oxabicyclo[3.3.0]-
octene ((S)-ALBO-V) was reported as a useful chiral resolving
agent.9 Various diastereomeric acetals prepared from racemic
secondary alcohols with (S)-ALBO-V were easily separated by
silica-gel column chromatography, and both enantiomers of the
alcohols with high enantiomeric excesses were easily obtained
after removal of (S)-ALBO-V by deacetalization. Herein, we
established a facile procedure for the preparation of both enan-
tiomers of chiral 1,4-diols 1 bearing various alkyl groups by
optical resolution using (S)-ALBO-V.
Optical Resolution of C2-Symmetric
Racemic 1,4-Diols with o-Xylylene
Structure by Chiral Resolving
Agent (S)-ALBO-V
Masatoshi Asami,* Lvling Zhong, Naoki Sekiguchi,
Kumiko Yamada, Yuya Hiwatashi,
Toshiro Taniguchi, Naoya Hosoda, and Suguru Ito
In the first place, various racemic 1,4-diols 1a-1g were syn-
thesized from o-phthalaldehyde (2) and the corresponding
Grignard reagents according to a known procedure with slight
modification (Table 1).10 Namely, to dialdehyde 2 in cyclo-
pentyl methyl ether (CPME) was added an ethereal solution of
ethylmagnesium bromide, prepared from 2.5 molar amounts of
bromoethane, at 0 °C and the reaction mixture was refluxed
for 3 h. After acidic work-up, a mixture of desired 1,4-diol
rac-1a, its diastereomer meso-3a, and reduced product 4a,
which resulted from a single nucleophilic addition followed
by a reduction by β-hydrogen of the Grignard reagent, were
obtained in 55%, 13%, and 16% yields, respectively (Entry 1).
Similarly, the reaction with methylmagnesium iodide gave
rac-1b and meso-3b in 46% and 47% yields, respectively
(Entry 2). As for the synthesis of rac-1c, the amount of
isopropylmagnesium bromide was increased to that prepared
from 5.0 molar amounts of 2-bromopropane until 2 was not
detected by TLC, and rac-1c was obtained in 29% yield along
with meso-3c and 4c with 6% and 31% yields, respectively
(Entry 3). 1,4-Diols 1d-1f were also obtained in 37-57%
yields by the reaction of 2 with Grignard reagents prepared
from 4-5 molar amounts of the corresponding alkyl halides
(Entries 4-6).
Department of Advanced Materials Chemistry, Graduate
School of Engineering, Yokohama National University, 79-5
Tokiwadai, Hodogaya-ku, Yokohama, Kanagawa 240-8501
E-mail: m-asami@ynu.ac.jp
Received: February 28, 2015; Accepted: March 26, 2015;
Web Released: April 3, 2015
Optical resolution of C2-symmetric racemic 1,4-diols,
1,2-bis(1-hydroxyalkyl)benzene, was examined using (S)-
5-allyl-2-oxabicyclo[3.3.0]octene ((S)-ALBO-V) as chiral
resolving agent. Diastereomeric acetals obtained from the
1,4-diols with (S)-ALBO-V were easily separated by silica-
gel column chromatography. After removal of the resolving
agent, both enantiomers of the 1,4-diols were obtained with
high enantiomeric excesses.
C2-Symmetric 1,2-, 1,3-, and 1,4-diols have been recognized
as useful chiral scaffolds in various asymmetric transformations
as chiral ligands and chiral auxiliaries,1-5 since the existence of
a C2-symmetric element is often important in asymmetric syn-
thesis to induce high levels of stereoselectivity.6 Among them,
the structural variety of chiral C2-symmetric 1,4-diols is rather
limited, and the precise control of the stereochemical outcome
of asymmetric reactions is generally difficult due to their
structural flexibility except for 1,1¤-bi-2-naphthol (BINOL)
derivatives3 and α,α,α¤,α¤-tetraaryl-1,3-dioxolane-4,5-dimetha-
nol (TADDOL) derivatives4 with relatively rigid structures.
We have reported the asymmetric synthesis of chiral C2-
symmetric 1,4-diols with o-xylylene structure, (S,S)-1,2-bis-
(1-hydroxyalkyl)benzene (1), and the use of (S,S)-1,2-bis-
(1-hydroxypropyl)benzene (1a) (R = Et) as chiral auxiliary
or starting material of chiral ligands.7 The superiority of chiral
1,4-diol 1a as chiral auxiliary was shown in the 1,4-addition
of phenyllithium to a β-nitrostyrene derivative by comparing
the results using other C2-symmetric chiral 1,2-, 1,3-, and 1,4-
diols.7c In the previous report,7a however, the stepwise enan-
tioselective addition of dialkylzinc reagent to aromatic aldehyde
was utilized for the construction of two benzylic stereogenic
centers of 1,4-diol 1. Therefore, the examples of chiral 1,4-diols
1 with high enantiomeric excesses have been limited to 1a
and 1b (R = Me). Although van Koten et al. also reported the
enantioselective synthesis of several examples of 1,4-diol 1, the
enantioselectivities of the reactions were less than 90%.8
Table 1. Synthesis of Racemic 1,4-Diols 1a-1f
rac-1
/%b)
meso-3
/%b)
4
/%b)
Entry
RMgXa)
1
2
3
4c)
5
EtMgBr (2.5)
MeMgI (2.5)
i-PrMgBr (5.0)
i-BuMgBr (4.0)
n-C5H11MgBr (5.0)
c-C6H11MgCl (5.0)
55
46
29
37
41
57
13
47
6
15
23
14
16
0
31
39
34
14
6
a) Molar amounts of the corresponding alkyl halides used were
in parentheses. b) Isolated yield. c) The reaction was carried
out at room temperature.
966 | Bull. Chem. Soc. Jpn. 2015, 88, 966–968 | doi:10.1246/bcsj.20150066
© 2015 The Chemical Society of Japan

Table 3. Acetalization of Various 1,4-Diols with (S)-
ALBO-V
7/%a)
8/%a)
Entry
1
R
(R)
(S)
(R)
(S)
1
2
3
1b
1c
1d
1e
1f
Me
i-Pr
i-Bu
n-C5H11
c-C6H11
(C2H5)2CH
Trace
15
5
7
14
14
Trace
5
Trace
Trace
5
40
28
45
37
30
28
43
42
46
42
37
39
Scheme 1. Synthesis of 1,2-bis(2-ethyl-1-hydroxybutyl)-
benzene (1g).
4b)
5
Table 2. Acetalization of rac-1a with (S)-ALBO-V
6c)
1g
6
a) Isolated yield. b) Reaction time was 3 h. c) Reaction was
carried out using 20 mol % of p-TsOH.
and (R)-8a and (S)-8a were obtained in high isolated yields
(Entry 3). The amount of (S)-ALBO-V was reduced to 2.2
molar amounts to give (R)-8a and (S)-8a in 40% and 45%
yields, respectively (Entry 4).
As a good result was obtained for rac-1a, the optical resolu-
tion of various 1,4-diols 1b-1g was then examined (Table 3).
When 1b (R = Me), 1d (R = i-Bu), and 1e (R = n-C5H11) were
reacted with (S)-ALBO-V, diacetals 8b, 8d, and 8e were
obtained in high isolated yields (Entries 1, 3, and 4). In the
cases of 1c (R = i-Pr) and 1f (R = c-C6H11), diacetals (S)-8c
and (S)-8f were obtained in high yields although ca. 15% of
monoacetals (R)-7c and (R)-7f were isolated and the yields of
(R)-8c and (R)-8f were moderate probably due to the steric
hindrance of the substituents (Entries 2 and 5). The yields of
(R)-8c and (R)-8f were not improved by elongation of the reac-
tion time or increasing the amount of p-toluenesulfonic acid.
As for 1,4-diol 1g (R = (C2H5)2CH), a higher catalyst loading
(20 mol %) was required for the formation of diacetals (R)-8g
and (S)-8g (28% and 39% yields, Entry 6). All diastereomeric
diacetals (R)-8b-8g and (S)-8b-8g were also separated by
silica-gel column chromatography.
As both enantiomers of various 1,4-diols 1a-1g were ob-
tained in diacetal form with (S)-ALBO-V, deacetalization of
diacetals 8a-8g was carried out to obtain (R)-1a-1g and (S)-
1a-1g (Table 4). In the presence of 1 mol % of p-toluene-
sulfonic acid, a methanol solution of diacetal (R)-8a was heated
under reflux for 1 h to give (R)-1a in 98% yield with 98% ee
(Entry 1). The chiral resolving agent was recovered as meth-
anol adduct, which is the precursor of (S)-ALBO-V and there-
fore reusable.9 Similarly, deacetalization of (S)-8a afforded (S)-
1a in 96% yield with 97% ee (Entry 2). Deacetalization of
other diacetals, (R)-8b-8g and (S)-8a-8g, also proceeded to
give the corresponding 1,4-diols (R)-1b-1g and (S)-1a-1g in
high yields and enantiomeric excesses (Entries 3-14). Although
the ee values of 1,4-diols 1a-1g should be >99% in principle
since enantiomerically pure (S)-ALBO-V was used as chiral
resolving agent, the ee values were 92-98% in some cases. This
is probably due to the technical problem in the separation of
diastereomeric diacetals (R)-8 and (S)-8 by silica-gel column
7a/%a)
8a/%a)
(S)-ALBO-V Time
Entry
/mol. amt.
/h
(R)
(S)
(R) (S)
1b)
2
3
1.0
2.0
3.0
2.2
3
10
7
22
15
26
8
6
29
42
40
9
41
45
45
Trace Trace
9
4
17
4
a) Isolated yield. b) Recovery of rac-1a was 13%.
1,2-Bis(2-ethyl-1-hydroxybutyl)benzene 1g was prepared
from 1,2-dibromobenzene (5), since the reaction of 1-ethyl-
propylmagnesium halide with 2 afforded rac-1h in ca. 10%
yield due to the predominant formation of 4g and 1,2-bis-
(hydroxymethyl)benzene. Dibromide 5 was mono-lithiated by
butyllithium in Et2O/THF at between ¹115 and ¹110 °C, and
the resulting aryl lithium was reacted with 2-ethylbutanal to
give bromoalcohol 6 in 81% yield. Treatment of 6 with butyl-
lithium in Et2O at room temperature, and the subsequent reac-
tion with 2-ethylbutanal afforded rac-1g and meso-3g in 32%
and 36% yields, respectively (Scheme 1).
Next, the optical resolution of rac-1a was examined using
(S)-ALBO-V (Table 2). When rac-1a was mixed with 1.0
molar amount of (S)-ALBO-V in the presence of a catalytic
amount (1 mol %) of p-toluenesulfonic acid in toluene at room
temperature for 3 h, diastereomers of monoacetals (R)-7a and
(S)-7a were obtained in moderate yields along with diastereo-
meric diacetals (R)-8a and (S)-8a. The resulting four products
((R)-7a, (S)-7a, (R)-8a, and (S)-8a) were separated by a single
silica-gel column chromatography (Entry 1). The reaction was
then examined using 2.0 molar amounts of (S)-ALBO-V, and
diacetals (R)-8a and (S)-8a were obtained in 29% and 41%
yields, respectively (Entry 2). Monoacetals were fully con-
verted to diacetals by using 3.0 molar amounts of (S)-ALBO-V,
Bull. Chem. Soc. Jpn. 2015, 88, 966–968 | doi:10.1246/bcsj.20150066
© 2015 The Chemical Society of Japan | 967

Table 4. Deacetalization of Various Acetals 8
mental Analysis Center, Yokohama National University) for
their technical assistance in the elemental analyses and the
high-resolution mass spectrometric analyses.
Supporting Information
Details of experimental procedures and characterization data
of synthesized compounds. This material is available electroni-
cally on J-STAGE.
Entry
R
Acetal
Yield/%a)
ee/%b)
98
97
98
98
97
99
92 (>99)c)
98 (>99)c)
96
>99
>99
98
97
96
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Et
(R)-8a
(S)-8a
(R)-8b
(S)-8b
(R)-8c
(S)-8c
(R)-8d
(S)-8d
(R)-8e
(S)-8e
(R)-8f
(S)-8f
(R)-8g
(S)-8g
98
96
95
96
86
87
72
79
85
88
92
81
84
85
References
Me
1
K. C. Bhowmick, N. N. Joshi, Tetrahedron: Asymmetry
2006, 17, 1901.
i-Pr
2
3
4
5
K. Okano, Tetrahedron 2011, 67, 2483.
J. M. Brunel, Chem. Rev. 2007, 107, PR1.
H. Pellissier, Tetrahedron 2008, 64, 10279.
For some recent examples of asymmetric reactions using
i-Bu
n-C5H11
c-C6H11
(C2H5)2CH
C2-symmetric chiral diols, see: a) M. G. Baker-Salisbury, B. S.
Starkman, G. M. Frisenda, L. A. Roteta, J. M. Tanski, Inorg. Chim.
Acta 2014, 409, 394. b) Y. Gök, L. Kekeç, Tetrahedron Lett. 2014,
55, 2727. c) U. Bhakta, E. Sullivan, D. G. Hall, Tetrahedron 2014,
70, 678. d) D. X. Hu, G. M. Shibuya, N. Z. Burns, J. Am. Chem.
Soc. 2013, 135, 12960. e) Y. A. Konik, D. G. Kananovich, O. G.
Kulinkovich, Tetrahedron 2013, 69, 6673. f) A. Bertogg, L.
Hintermann, D. P. Huber, M. Perseghini, M. Sanna, A. Togni,
Helv. Chim. Acta 2012, 95, 353. g) P. W. N. M. van Leeuwen, D.
Rivillo, M. Raynal, Z. Freixa, J. Am. Chem. Soc. 2011, 133, 18562.
h) J. Matsuo, Y. Hattori, H. Ishibashi, Org. Lett. 2010, 12, 2294.
a) Isolated yield. b) Determined by HPLC analysis. c) After
single recrystallization.
chromatography. In the case of 1d, enantiomerically pure sam-
ples (>99% ee) were obtained for both enantiomers after single
recrystallization from Et2O/hexane.
6
7
J. K. Whitesell, Chem. Rev. 1989, 89, 1581.
a) M. Asami, M. Wada, S. Furuya, Chem. Lett. 2001, 1110.
In conclusion, various C2-symmetric rac-1,4-diols with o-
xylylene structure were synthesized from the easily available
starting materials in one or two steps with good yields. Acetal-
type chiral resolving agent (S)-ALBO-V was found to be useful
for the optical resolution of 1,4-diols 1, and both enantiomers
of 1 were obtained with high enantiomeric excesses. The chiral
1,4-diols obtained in this study would find applications in
various kinds of asymmetric transformations as chiral ligands
or chiral auxiliaries.
b) Y. Yokoyama, T. Okuyama, Y. Yokoyama, M. Asami, Chem.
Lett. 2001, 1112. c) M. Asami, A. Taketoshi, K. Miyoshi, H.
Hoshino, K. Sakakibara, Chem. Lett. 2007, 36, 64. d) S. Anezaki,
Y. Yamaguchi, M. Asami, Chem. Lett. 2010, 39, 398. e) S.
Anezaki, Y. Yamaguchi, M. Asami, J. Organomet. Chem. 2011,
696, 2399.
8
H. Kleijn, J. T. B. H. Jastrzebski, J. Boersma, G. van Koten,
Tetrahedron Lett. 2001, 42, 3933.
a) H. Nemoto, W. Zhong, T. Kawamura, M. Kamiya, Y.
9
Nakano, K. Sakamoto, Synlett 2007, 2343. b) K. Sakamoto, H.
Nemoto, J. Synth. Org. Chem., Jpn. 2007, 65, 626. c) H. Nemoto,
Tetrahedron Lett. 1994, 35, 7785.
10 L. Lemiègre, F. Lesetre, J.-C. Combret, J. Maddaluno,
Tetrahedron 2004, 60, 415.
This work was supported by JSPS KAKENHI Grant Number
24550113. The authors are grateful to ZEON CORPORATION
for providing (S)-ALBO-V and CPME. The authors also wish
to thank Mr. Shinji Ishihara and Dr. Hironari Kurihara (Instru-
968 | Bull. Chem. Soc. Jpn. 2015, 88, 966–968 | doi:10.1246/bcsj.20150066
© 2015 The Chemical Society of Japan
