Triacylglycerol Analogues
1133 1140
analysis calcd (%) for C11H22O2 (186.3): C 70.92, H 11.90; found: C 71.03,
H 11.69.
analysis calcd (%) for C61H112O6 (941.5): C 77.81, H 11.99; found: C
77.89, H 11.93.
(Z)-2-Methyl-9-octadecenoic acid: Yellow oil. Yield 3.40 g (82%); 1H
NMR: d=11.50 (b, 1H; COOH), 5.33 (m, 2H; CH=), 2.30 2.50 (m, 1H;
CH), 1.95 2.15 (m, 4H; CH2CH=), 1.58 1.80 (m, 2H; CH2CH), 1.25 1.55
(m, 20H; 10îCH2), 1.15 1.20 (m, 3H; CHCH3), 0.88 1.00 ppm (m,
3CH; CH2CH3); 13C NMR: d=183.6 (COOH), 130.0 (CH=), 129.7 (CH=),
39.4 (CH), 34.1 (CH2), 33.5 (CH2), 31.9 (CH2), 29.8 (CH2), 29.6 (CH2),
29.5 (CH2), 29.4 (CH2), 29.3 (CH2), 29.1 (CH2), 27.2 (CH2), 27.1 (CH2),
22.7 (CH2), 16.8 (CHCH3), 14.1 ppm (CH2CH3); elemental analysis calcd
(%) for C19H39O2 (296.5): C 76.97, H 12.24; found: C 76.83, H 12.32.
1,1-Bis{[(1-oxodecyl)oxy]methyl}pentyl ester of decanoic acid, (9b): Yel-
lowish oil. Yield 4.22 g (69%); 1H NMR: d=4.37 (dd, 1J=11.8 Hz, 2J=
31.2 Hz, 4H; 2îCH2O), 2.22 2.45 (m, 6H; 3îCH2CO), 1.85 2.10 (m,
2H; CCH2), 1.50 1.70 (m, 6H; 3îCH2), 1.15 1.45 (m, 40H; 20îCH2),
0.88 ppm (m, 12H; 4îCH3); 13C NMR: d=180.0 (CO), 173.8 (CH), 81.6
(C), 66.5 (CH2O), 34.5 (CH2), 34.2 (CH2), 31.8 (CH2), 29.4 (CH2), 29.2
(CH2), 29.1 (CH2), 29.0 (CH2), 24.9 (CH2), 24.6 (CH2), 23.1 (CH2), 22.6
(CH2), 14.1 ppm (CH3); elemental analysis calcd (%) for C37H70O6
(610.9): C 72.74, H 11.55; found: C 72.89, H 11.43.
General procedure for the synthesis of triacylglycerol analogues 3a e,
9a b, and 10a b: The appropriate acid (50 mmol) was added in a solu-
tion of the appropriate alcohol (10 mmol) in dichloromethane (65 mL),
and the solution was cooled to 08C. Then, a catalytic amount of DMAP
was added (122 mg, 1.0 mmol), followed by the addition of a solution of
DCC (10.3 g, 50 mmol) in dichloromethane (60 mL). The solution was
stirred for 30 min at 08C for several nights at room temperature. The re-
action mixture was filtered through a small pad of celite, and the solvent
was evaporated under reduced pressure. The residue was purified by
flash column chromatography by using petroleum ether/Et2O 95:5, and
9:1 as an eluent.
2-Methyl-2,3-bis{[(Z)-2-methyl-1-oxo-8-heptadecenyl]oxy}propyl ester of
9-octadecenoic acid, (Z)-(10a): Yellowish oil. Yield 6.68 g (72%); 1H
NMR: d=5.25 5.45 (m, 7H; 3îCH=, CHO), 4.35 (m, 4H; 2îCH2O),
2.30 2.55 (m, 3H; 3îCH), 1.90 2.10 (s, 12H; 6îCH2CH=), 1.58 1.75
(m, 6H; 3îCH2CH), 1.25 1.55 (m, 60H; 30îCH2), 1.15 1.20 (m, 9H;
3îCHCH3), 0.88 1.00 ppm (m, 9H; 3îCH2CH3); 13C NMR: d=176.0
(CO), 130.0 (CH=), 129.7 (CH=), 68.9 (CHO), 62.0 (CH2O), 39.5 (CH),
39.4 (CH), 33.6 (CH2), 31.9 (CH2), 29.7 (CH2), 29.5 (CH2), 29.4 (CH2),
29.3 (CH2), 29.1 (CH2), 27.2 (CH2), 27.1 (CH2), 22.7 (CH2), 16.9 (CH3),
14.1 ppm (CH3); elemental analysis calcd (%) for C60H110O6 (927.5): C
77.70, H 11.95; found: C 77.59, H 12.03.
2-Methyl-2,3-bis{[(Z)-1-oxo-8-heptadecenyl]oxy}propyl ester of 9-octade-
cenoic acid, (Z)-(3a): Yellowish oil. Yield 7.01 g (78%); 1H NMR: d=
2-Methyl-2,3-bis[(1-oxodecyl)oxy]propyl ester of decanoic acid, (10b):
Yellowish oil. Yield 4.78 g (80%); 1H NMR: d=5.38 (m, 1H; CHO),
4.35 (m, 4H; 2îCH2O), 2.35 2.55 (m, 3H; 3îCH), 1.55 1.75 (m, 6H;
3îCH2CH), 1.20 1.50 (m, 36H; 18îCH2), 1.10 1.20 (m, 9H; 3î
CHCH3), 0.88 1.00 ppm (m, 9H; 3îCH2CH3); 13C NMR: d=176.2
(CO), 68.8 (CHO), 62.1 (CH2), 39.5 (CH), 39.4 (CH), 33.6 (CH2), 31.8
(CH2), 29.5 (CH2), 29.4 (CH2), 29.2 (CH2), 27.2 (CH2), 22.6 (CH2), 16.9
(CH3), 14.1 ppm (CH3); elemental analysis calcd (%) for C36H68O6
(596.9): C 72.44, H 11.48; found: C 72.59, H 11.35.
1
2
5.33 (6H, m, 3îCH2), 4.31 (dd, J=11.4 Hz, J=25.4 Hz, 4H; 2îCH2O),
2.30 (m, 6H; 3îCH2), 1.99 (m, 12H; 6îCH2), 1.62 (m, 6H; 3îCH2),
1.49 (s, 3H; CH3), 1.27 (s, 72H; 36îCH2), 0.87 ppm (t, J=6.2 Hz, 9H;
3îCH3); 13C NMR: d=173.0 (CH), 172.7 (CO), 130.1 (CH), 130.0 (CH),
129.8 (CH), 79.6 (C), 64.7 (CH2), 35.1 (CH2), 34.1 (CH2), 31.9 (CH2), 29.7
(CH2), 29.5 (CH2), 29.3 (CH2), 29.1 (CH2), 27.1 (CH2), 24.9 (CH2), 22.6
(CH2), 18.9 (CH3), 14.1 ppm (CH3); elemental analysis calcd (%) for
C58H106O6 (899.5): C 77.45, H 11.88; found: C 77.38, H 12.05.
Monomolecular film experiments–Force/area curves: Surface pressure-
area curves were measured in the rectangular reservoir compartment of
the ™zero-order∫ trough (14.8 cm wide and 24.9 cm long). Before each ex-
periment the trough was at first washed with tap water, then gently
brushed in the presence of distilled ethanol, washed again with plenty of
tap water, and finally rinsed with twice-distilled water. The lipidic film as
a solution in CHCl3 (approximately 1 mgmLÀ1) was spread with a Hamil-
ton syringe over an aqueous subphase of Tris/HCl (10mm, pH 8.0), NaCl
(100mm), CaCl2 (21mm), and EDTA (1mm). The above-mentioned
buffer solution was prepared with twice-distilled water, and filtered
through a 0.22 mm millipore membrane. Before each utilization, residual
surface-active impurities were removed by sweeping and suction of the
surface. The force/area curves were automatically recorded upon a con-
2-Methyl-2,3-bis{[(Z)-2-methyl-1-oxo-8-heptadecenyl]oxy}propyl ester of
9-octadecenoic acid, (Z)-(3b): Yellowish oil. Yield 4.52 g (48%); 1H
NMR: d=5.33 (m, 6H; 3îCH=), 4.33 (m, 4H; 2îCH2O), 2.30 2.50 (m,
3H; 3îCH), 1.90 2.10 (s, 12H; 6îCH2CH=), 1.58 1.80 (m, 6H; 3î
CH2CH), 1.25 1.55 (m, 60H; 30îCH2), 1.15 1.20 (m, 9H; 3îCHCH3),
0.88 1.00 ppm (m, 9H; 3îCH2CH3); 13C NMR: d=176.0 (CO), 175.6
(CO), 130.0 (CH=), 129.6 (CH=), 79.6 (C), 64.6 (CH2O), 40.3 (CH), 39.5
(CH), 33.6 (CH2), 31.9 (CH2), 29.7 (CH2), 29.4 (CH2), 29.3 (CH2), 29.1
(CH2), 27.2 (CH2), 27.1 (CH2), 24.9 (CH2), 22.7 (CH2), 18.9 (CH3), 17.0
(CH3), 14.1 ppm (CH3); elemental analysis calcd (%) for C61H112O6
(941.5): C 77.81, H 11.99; found: C 77.69, H 12.07.
2-Methyl-2,3-bis[(1-oxodecyl)oxy]propyl ester of decanoic acid, (3c): Yel-
lowish oil. Yield 4.15 g (73%); 1H NMR: d=4.33 (dd, 1J=11.6 Hz, 2J=
25.2 Hz, 4H; 2îCH2O), 2.32 (m, 6H; 3îCH2), 1.61 (m, 6H; 3îCH2),
1.51 (s, 3H; CH3), 1.27 (b, 42H; 21îCH2), 0.88 ppm (t, 9H J=6.4 Hz;
3îCH3); 13C NMR: d=173.1 (CO), 79.6 (C), 64.9 (CH2), 64.7 (CH2),
35.1 (CH2), 34.1 (CH2), 31.8 (CH2), 29.4 (CH2), 29.5 (CH2), 29.1 (CH2),
24.1 (CH2), 22.6 (CH2), 18.9 (CH3), 14.1 ppm (CH3); elemental analysis
calcd (%) for C34H64O6 (568.9): C 71.79, H 11.34; found: C 71.63, H
11.38.
tinuous compression rate at 0.5 cmminÀ1
.
Enzyme kinetic experiments: The inhibition experiments were performed
by using the monolayer technique. The surface pressure of the lipid film
was measured by means of the platinum Wilhelmy plate technique cou-
pled with an electromicrobalance. The principle of this method has been
described previously by Verger et al.[13]
For the inhibition studies the method of ™mixed monomolecular films∫
was used. This method involved the use of a ™zero-order∫ trough, which
consisted of two compartments: a reaction compartment, in which mixed
films of substrate and inhibitor are spread, and a reservoir compartment,
in which only pure films of substrate are spread. The two compartments
are connected to each other by narrow surface channels. HPL (final con-
centration 8.3 and 4.8 ngmLÀ1 for 14 and 17 mNmÀ1, respectively), and
HGL (final concentration 113 and 56 ngmLÀ1 for 17 and 20 mNmÀ1, re-
spectively) were injected into the subphase of the reaction compartment,
in which efficient stirring was applied. In the case of HPL, the aqueous
subphase was composed of Tris/HCl (10mm, pH8.0) NaCl (100mm),
CaCl2 (21mm), and EDTA (1mm). In the case of HGL the aqueous sub-
phase was composed of CH3COONa/HCl (10mm, pH5.0), NaCl
(100mm), CaCl2 (21mm), and EDTA (1mm). Due to the lipolytic action
of the enzyme, the surface pressure decreased, and a mobile barrier
moved over the reservoir compartment to compress the film, and thus
kept the surface pressure constant. The surface pressure was measured
on the reservoir compartment. The surface and volume of the reaction
compartment was 100 cm2 and 120 mL, repsectively. The reservoir com-
partment was 14.8 cm wide and 24.9 cm long. The lipidic films were
2-Methyl-2,3-bis[(2-methyl-1-oxodecyl)oxy]propyl ester of decanoic acid,
(3d): Yellowish oil. Yield 3.48 g (57%); 1H NMR: d=4.35 (m, 4H; 2î
CH2O), 2.35 2.55 (m, 3H; 3îCH), 1.58 1.75 (m, 6H; 3îCH2CH), 1.51
(s, 3H; CH3), 1.20 1.48 (m, 36H; 18îCH2), 1.05 1.20 (m, 9H; 3î
CHCH3), 0.88 1.00 ppm (m, 9H; 3îCH2CH3); 13C NMR: d=176.0
(CO), 79.6 (C), 64.6 (CH2O), 40.3 (CH), 39.5 (CH), 33.7 (CH2), 31.8
(CH2), 29.5 (CH2), 29.4 (CH2), 29.2 (CH2), 27.2 (CH2), 22.6 (CH2), 18.9
(CH3), 17.0 (CH3), 14.1 ppm (CH3); elemental analysis calcd (%) for
C37H70O6 (610.9): C 72.74, H 11.55; found: C 72.59, H 11.63.
2-{[(Z)-1-oxo-8-heptadecenyl]oxy}-2-{{[(Z)-1-oxo-8-heptadecenyl]oxy}-
methyl}hexyl ester of 9-octadecenoic acid, (Z)-(9a): Yellowish oil. Yield
4.22 g (69%); 1H NMR: d=5.33 (m, 6H; 3îCH=), 4.35 (dd, 1J=
11.8 Hz, 2J=31.2 Hz, 4H; 2îCH2O), 2.22 2.50 (m, 6H; 3îCH2CO),
1.85 2.10 (m, 14H; 6îCH2CH=, CCH2), 1.55 1.70 (m, 6H; 3îCH2),
1.15 1.45 (m, 74H; 37îCH2), 0.88 ppm (m, 12H; 4îCH3); 13C NMR:
d=173.0 (CH), 172.5 (CO), 130.0 (CH), 81.8 (C), 63.0 (CH2O), 34.2
(CH2), 31.9 (CH2), 29.7 (CH2), 29.5 (CH2), 29.3 (CH2), 29.1 (CH2), 27.2
(CH2), 24.9 (CH2), 24.7 (CH2), 22.7 (CH2), 14.1 ppm (CH3); elemental
1139
Chem. Eur. J. 2004, 10, 1133 1140
¹ 2004 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
