Chromaffin Vesicular Monoamine Transporter Inhibitors
J ournal of Medicinal Chemistry, 2003, Vol. 46, No. 13 2603
standard turnover experiments, the granules were resealed
to contain 20 mM ascorbic acid and incubated as above except
that 20 mM ascorbic acid was included in the external
incubation medium.
Syn th esis. All 1H and 13C NMR spectra were recorded with
a Varian Inova 400 MHz spectrometer (Varian), and mass
spectra were obtained from a Finnigan LCQ-Deca ion trap
mass spectrometer (Thermoquest Corporation, San J ose, CA).
All reagents and solvents were obtained from various com-
mercial sources with the highest purity available and used
without further purification. Trimethylsilane (for organic
solvents) or 3-(trimethylsilyl)propionic acid sodium salt (for
D2O) were used as internal standards for NMR.
Com p u ta tion a l Ca lcu la tion s. Ab initio calculations were
carried out using the Gaussian 98-Revision A.9 suite of
programs.31 The rotational barriers were calculated by using
the built-in scan mode. The dihedral angles C7-C3-C2-N1
(see Figure 3A,B) were changed by 5° increments, the geom-
etries were completely optimized, and the energies were
calculated.
3-Am in o-2-(4′-flu or op h en yl)p r op en e‚HCl (6). Mp 168-
169 °C; 1H NMR (D2O) δ 3.97 (s, 2H), 5.32 (s, 1H), 5.52 (s,
1H), 7.07 (t, 2H), 7.40 (d, d, 2H); 13C NMR (D2O) δ 42.9, 115.7,
116.0, 117.5, 128.3, 128.4, 133.4, 139.7, 161.3, 164.5; MS (ESI),
m/z 152.3 (M+). Anal. (C9H11ClFN) C, H, N.
3-Am in o-2-(4′-ch lor op h en yl)p r op en e‚HCl (7). Mp 178-
178 °C; 1H NMR (D2O) δ 3.98 (s, 2H) 5.36 (s, 1H), 5.58 (s, 1H),
7.37 (s, 4H); 13C NMR (D2O) d 45.2, 120.5, 130.4, 131.6, 136.7,
138.30, 142.1; MS (ESI), m/z 168.3 (M+). Anal. (C9H11Cl2N) C,
H, N.
3-Am in o-2-(4′-br om op h en yl)p r op en e‚HCl (8). Mp 183-
185 °C; 1H NMR (D2O) δ3.98 (s, 2H), 5.37 (s, 1H), 5.60 (s, 1H),
7.30 (d, 2H), 7.52 (d, 2H); 13C NMR (D2O) d 45.0, 120.4, 124.7,
130.5, 134.4, 138.7, 142.0; MS (ESI), m/z 214.2 (M+). Anal.
(C9H11BrClN) C, H, N.
3-Am in o-2-(4′-iod op h en yl)p r op en e‚HCl (9). Mp 208-
210 °C; 1H NMR (D2O) δ 4.08 (s, 2H), 5.46 (s, 1H), 5.70 (s,
1H), 7.28 (d, 2H), 7.82 (d, 2H);13C NMR (D2O) d 45.5, 97.2,
121.0, 131.2, 139.8, 141.1, 142.8; MS (ESI), m/z 260.0 (M+).
Anal. (C9H11ClIN) C, H, N.
3-Am in o-2-p h en ylp r op en e‚HCl (1). Mp 178-179 °C (lit.
178-179 °C);26 1H NMR (D2O) δ 7.47-6.95 (m, 5 H), 5.73 (s, 1
H), 5.54 (s, 1 H), 4.13 (s, 2 H); 13C NMR (D2O) δ 44.8, 119.5,
128.4, 131.1, 131.2, 139.2, 142.6; MS (ESI) m/z 134.2 (M+).
3-Am in o-2-(4′-h yd r oxyp h en yl)p r op en e‚HCl (2). This
was synthesized by the method of Padgette et al.26 Yield 17.9%;
mp 173-175 °C (lit. 175 °C);26 1H NMR (D2O) δ 7.3 (d, 2 H),
6.81 (d, 2 H), 5.41 (s, 1 H), 5.18 (s, 1 H), 3.86 (s, 2 H); 13C
NMR (D2O) δ 45.4, 118.3, 118.4, 130.5, 132.0, 142.5, 158.8;
MS (ESI) m/z 149 (M+).
3-Am in o-2-(3′-h yd r oxyp h en yl)p r op en e‚HCl (3). This
was also synthesized by using the same procedure as (2). Yield
31%; mp 144-145 °C (lit. 143-145 °C);26 1H NMR (D2O) δ
6.86-7.61 (m, 4 H), 5.73 (s, 1 H), 5.54 (s, 1 H), 4.13 (s, 2 H);
13C NMR (D2O) δ 45.3, 115.8, 118.5, 120.2, 121.1, 133.1, 141.5,
142.8, 158.6; MS (ESI) m/z 149 (M+).
3-Am in o-2-(4′-m eth oxyp h en yl)p r op en e‚HCl (4). An eth-
anol solution of N-[2-(4′-acetoxyphenyl)-2-propenyl]phthal-
imide was treated with 1 M NaOH until the pH of the solution
was about 10 and stirred for 15 min. The resultant solution
was acidified to pH 8 using concentrated HCl, and ethanol was
removed under reduced pressure. The resultant product was
extracted into CHCl3 and concentrated under reduced pressure
to yield a white solid which was dissolved in DMF and treated
with CH3I in the presence of K2CO3 to give N-[2-(4′-methoxy)-
2-propenyl]phthalimide. This was purified by column chro-
matography using 10% ethyl acetate/hexane, and the phthal-
imide group was removed as described by McDonald et al.24
to yield 3-amino-2-(4′-methoxy)propene. Yield: 18.6%; mp
162-164 °C; 1H NMR (D2O) δ 7.31 (d, 2H), 7.01 (d, 2H), 5.68
(s, 1H), 5.45 (s, 1H), 4.13 (s, 2H), 3.86 (s, 3H); 13C NMR (D2O)
δ 45.3, 58.1, 114.8, 117.4, 131.4, 131.7, 140.0, 162.7; MS (ESI)
m/z 149 (M+). Anal. (C10H14ClNO) C, H, N.
2-(3′-Meth oxyp h en yl)p r op en e. A solution of n-BuLi (18
mL, 0.05 mol in hexane) was added dropwise to a solution of
triphenylphosphonium bromide (14.3 g, 0.04 mol) in 25 mL of
DMSO. The solution was stirred for 1 h at RT, and 3-methoxy-
acetophenone (6 g, 0.04 mol) in 10 mL of DMSO was added
dropwise. The mixture was stirred overnight and quenched
with water, and the product was extracted with hexane. The
concentrated hexane extract was purified by column chroma-
tography using hexane as a solvent. Yield 89%; 1H NMR
(CDCl3) δ 7.60 (m, 2 H), 7.27(d, d 1 H), 6.98 (d, 1 H) 5.35(s, 1
H), 5.09 (s, 1 H), 2.21 (s, 3 H), 2.12 (s, 3 H).
3-Am in o-2-(4′-m eth ylph en yl)pr open e‚HCl (10). Mp 170-
173 °C (lit. 170-173 °C);28 1H NMR (D2O) δ 2.25 (s, 3H) 3.97
(s, 2H), 5.28 (s, 1H), 5.53 (s, 1H), 7.18 (d, 2H), 7.29 (d, 2H);
13C NMR (D2O) d 22.9, 45.3, 119.1, 128.8, 132.3, 136.8, 142.1,
142.9; MS (ESI), m/z 148.1 (M+). Anal. (C10H14NCl) C, H, N.
3-(N -Me t h yla m in e )-2-(4′-h yd r oxyp h e n yl)p r op e n e ‚
HCl (11). A solution of 4′-acetoxy-phenyl R- (bromomethyl)-
styrene (1 g, 3.9 mmol) in THF (10 mL) was added dropwise
to a solution of methylamine (2 M solution, 5 mL, 0.001 mol)
in THF in the presence of NaHCO3 (0.2 g) and stirred for 5 h
under nitrogen. The resulting solution was filtered and
concentrated under reduced pressure. The HCl salt of the
product was recrystalized from ethanol/ether. Yield 35.9%; mp
1
149-150 °C; H NMR (D2O) δ 7.3 (d, 2 H), 6.81 (d, 2 H), 5.41
(s, 1 H), 5.18 (s, 1 H), 3.86 (s, 2 H); 13C NMR (D2O) δ 48.4,
52.1, 116.7, 121.2, 122.4, 130.5, 132.2, 143.1, 158.2; MS (ESI)
m/z 164.4 (M+). Anal. (C10H14ClNO) C, H, N.
3-(N,N-Diet h yla m in o)-2-(4′-h yd r oxyp h en yl)p r op en e‚
HCl (12). This was synthesized by the same procedure
described for 11, except that diethylamine was used in place
of methylamine. Yield 32.4%; mp 182-185 °C; 1H NMR (D2O)
δ 7.41 (d, 2H), 6.95(d, 2H), 5.66 (s, 1H), 5.58 (s, 1H), 4.68 s,
2H), 3.27 (q, 4H), 1.21 (t, 6H); 13C NMR (D2O) δ 15.0, 59.2,
66.9, 119.1, 123.7, 131.6, 133.8, 146.1, 159. 7; MS (ESI) m/z
206.3 (M+). Anal. (C13H20ClNO) C, H, N.
3 -(N ,N ,N -T r i m e t h y l a m i n o )-2 -p h e n y l -p r o p e n e ‚
HBr (13). This was synthesized by the same procedure used
for 11, except that triethylamine was used in place of methyl-
amine. Yield 60%; mp 123-124 °C; 1H NMR (D2O) δ 8.46-
8.48 (m, 2 H), 8.37-8.39 (m, 3 H), 6.85 (s, 1 H), 6.67 (s, 1 H),
5.37 (s, 2 H), 3.90 (s, 9H); 13C NMR (D2O) δ 56.0, 71.42, 129.2,
131.5, 131.9, 139.9, 141.6; MS (ESI) m/z 176.1 (M+). Anal.
(C12H18BrN) C, H, N.
1-(2-P h en yl-2-p r op en yl)p yr id in iu m Br om id e (14). This
was synthesized by the same procedure used for 11, except
that pyridine was used in place of methylamine. Mp 115-116
°C (lit. 115-116);28 1H NMR (D2O) δ 5.68 (s, 1H), 5.81 (s, 2H),
5.86 (s, 1H), 7.42-7.48 (m, 3H), 7.54-7.58 (m, 2H), 8.04 (t,
2H), 8.51 (t, 1H), 8.95 (d, 2H); 13C NMR (D2O) δ 66.1, 123.9,
128.9, 130.7, 131.6, 131.6, 138.3, 143.0, 146.6, 148.9; MS (ESI),
m/z 196.1(M+).
2-Br om o-1-p h en yl-1-p r op a n on e. This was prepared by
the method of King and Ostrum29 in 82% yield. 1H NMR
(CDCl3) δ 1.88 (d, 2H), 5.29 (q, 1H), 7.44 (m, 3H), 8.11 (d, 2H).
The following compounds 5-10 were synthesized from the
corresponding R-methylstyrene derivatives which were ob-
tained by the general Wittig reaction as described for 2-(3′-
methoxyphenyl)propene using the standard procedure.
3-Am in o-2-(3′-m eth oxyph en yl)pr open e‚HCl (5). Mp 158-
160 °C; 1H NMR (D2O) δ 6.86-7.61 (m, 4 H), 5.73 (s, 1 H),
5.54 (s, 1 H), 4.13 (s, 2 H); 13C NMR (D2O) δ 45.3, 58.1, 114.8,
117, 120.6, 121.8, 133.0, 141.5, 142.9, 161.9; MS (ESI) m/z 149
(M+). Anal. (C10H14ClNO) C, H, N.
2-P h th alim ido-1-ph en ylpr opan on e. A solution of 2-bromo-
1-phenyl-1-propanone (3 g, 0.01 mol) in 10 mL of DMF,
potassium phthalimide (1.85 g, 0.01 mol) and K2CO3 (0.3 g)
were mixed and heated to 90 °C under N2 for 1 h and an
additional 1 h at RT and filtered. The filtrate was concentrated
under vacuum. The solid product was recrystalized from
CHCl3/hexane. Yield 56%; 1H NMR (CDCl3) δ 1.74 (d, 3H), 5.62
(q, 1H), 7.41 (m, 3H), 7.71 (dd, 2H), 7.96 (m, 4H).
