Instantaneous Low Temperature Gelation by a
Multicomponent Organogelator Liquid System Based on
Ammonium Salts
Daniel Garc´ıa Vela´zquez, David D´ıaz D´ıaz,*,† Angel Gutie´rrez Ravelo, and
´
Jose´ Juan Marrero Tellado*
Instituto UniVersitario de Bio-Orga´nica “Antonio Gonza´lez”, UniVersity of La Laguna,
Astrof´ısico Francisco Sa´nchez 2, 38206 La Laguna, Tenerife, Spain
Received January 16, 2008; Revised Manuscript Received April 15, 2008; E-mail: DDiaz-Diaz@dow.com; jtellado@ull.es
Abstract: A new synergistic multicomponent organogelator liquid system (MOGLS) was discovered during
the standard protocol of tartaric acid-mediated racemic resolution of (()-trans-1,2-diaminocyclohexane.
The MOGLS is formed by a 0.126 M methanolic solution of (1R,2R)-(+)-1,2-diaminocyclohexane L-tartrate
and 1 equiv of concentrated hydrochloric acid. Nonreversible gelation of oxygenated and nitrogenated
solvents occurs efficiently at low temperature. Several features make this system unique: (1) it is a
multicomponent solution where each of the five components is required for the organogelation property;
(2) the multicomponent organogelator liquid system (MOGLS) is formed by simple, small, and commercially
available chiral building blocks dissolved in a well-defined solvent system (MeOH/HCl/H2O); (3) the chiral
building blocks are easily amenable for further modifications in structure-property relationship studies; (4)
the gelation phenomenon takes place efficiently at low temperature upon warming up the isotropic solution,
conversely to the typical gel preparation protocol (gel formation upon cooling down the isotropic solution);
(5) the formed organic gels are not thermoreversible in spite of the noncovalent interactions that hold the
3D-fibrillar network together.
Introduction
nogels, are thermoreversible, viscoelastic materials consisting
of an organic liquid and a low molecular-mass compound
(usually <5 wt%) self-assembled into gel fibers, often of
micrometer scale lengths and nanometer scale diameters.7a Thus,
the gel architecture strongly reflects the molecular shape of unit
components. The aggregation of such low molecular-mass
organic gelators (LMOGs) typically occurs spontaneously upon
cooling down their isotropic solutions, being driven by multiple,
weak interactions such as dipole-dipole, van der Walls (long
alkyl, aromatic groups, etc.), and hydrogen-bonding interactions
(amide, urea, hydroxyl, etc.).1 It is widely accepted that the
entanglement of such microheterogeneous fibrillar phases gives
complex nanoscale three-dimensional (3D) networks through
new “junction zones”, which immobilizes a large volume of
organic liquid into the network compartments primarily by
surface tension and capillary forces.8 Despite the extensive and
remarkable achievements of supramolecular chemistry in many
In a fascinating journey from serendipity to rational design,
materials made by means of gelation of organic solvents have
received increasing attention over the last 10-15 years,1 because
of their unique supramolecular architectures and potential
applications2 as functional soft materials in the fabrication of
sensors,3 liquid crystallines,4 electrophoretic and electrically
conductive matrices,5 templates for cell growth or the growth
of sol-gel structures,6 and in many other industrial fields such
as cosmetics, oils, and foods.1 These systems, so-called orga-
† Current address: The Dow Chemical Company, Dow Europe GmbH,
Bachtobelstrasse, 3, CH 8810 Horgen, Switzerland.
(1) (a) Abdallah, D. J.; Weiss, R. G. AdV. Mater. 2000, 12, 1237–1247.
(b) Terech, P.; Weiss, R. G. Chem. ReV. 1997, 97, 3133–3159. (c)
van Esch, J. H.; Feringa, B. L. Angew. Chem., Int. Ed. 2000, 39, 2263–
2266. (d) Gronwald, O.; Shinkai, S. Chem. Eur. J. 2001, 7, 4328–
4334. (e) Hanabusa, K. Springer Ser. Mater. Sci. 2004, 78, 118–137.
(f) Weiss, R. G. Terech, P. Molecular Gels: Materials with Self-
Assembled Fibrillar Networks; Springer: New York, 2006. (g) George,
M.; Weiss, R. G. Acc. Chem. Res. 2006, 39, 489–497, and references
therein.
(2) (a) Vintiloui, A.; Leroux, J.-C. J. Controlled Rel. 2008, 125, 179–
192. (b) Jung, J. H.; Shinkai, S. Top. Curr. Chem. 2004, 248, 223–
260. (c) Sangeetha, N. M.; Maitra, U. Chem. Soc. ReV. 2005, 34, 821–
836.
(6) (a) Sanchez, C.; Llusar, M. Chem. Mater. 2008, 20, 782–820. (b) van
Bommel, K. J. C.; Friggeri, A.; Shinkai, S. Angew. Chem., Int. Ed.
2003, 42, 980–999, and references therein. (c) Friggeri, A.; van
Bommel, K. J. C.; Shinkai, S. In Molecular Gels: Materials with Self-
Assembled Fibrillar Networks; Springer: New York 2006; pp 857-
893.
(3) Li, S.; John, V. T.; Irvin, G. C.; Bachakonda, S. H.; McPherson, G. L.;
O’Connor, C. J. J. Appl. Phys. 1999, 85, 5965–5972.
(4) Kato, T. Science 2002, 295, 2414–2418, and references therein.
(5) (a) Puigmarti-Luis, J.; Laukhin, V.; del Pino, A. P.; Vidal-Gancedo,
J.; Rovira, C.; Laukhina, E.; Amabilino, D. B. Angew. Chem., Int.
Ed. 2007, 46, 238–241. (b) Kubo, W.; Kambe, S.; Nakade, S.;
Kitamura, T.; Hanabusa, K.; Wada, Y.; Yanagida, S. J. Phys. Chem.
B 2003, 107, 4374–4381.
(7) (a) Ihara, H.; Takafuji, M.; Sakurai, T. Encyclopedia of Nanoscience
and Nanotechnology 2004, 9, 473. (b) Low Molecular Mass Gelators
ed. Fages, F. in Topics in Current Chemistry, vol. 256, Springer-Verlag,
Berlin, Heidelberg, 2005.
(8) Huang, X.; Terech, P.; Raghavan, S. R.; Weiss, R. G. J. Am. Chem.
Soc. 2005, 127, 4336–4344.
9
10.1021/ja8002777 CCC: $40.75
2008 American Chemical Society
J. AM. CHEM. SOC. 2008, 130, 7967–7973 7967

A R T I C L E S
Vela´zquez et al.
solution, conversely to the typical gel preparation protocol (gel
formation upon cooling down the isotropic solution); (5) the
formed organic gels are not thermoreversible in spite of the
noncovalent interactions that hold the 3D-fibrillar network
together.
Results and Discussion
Discovery of the Multicomponent Organogelator Liquid
System (MOGLS). The serendipitous discovery of this MOGLS
took place when we were using the standard protocol of tartaric
acid-mediated racemic resolution of (()-trans-1,2-diaminocy-
clohexane14 for other purposes. During the cleaning of the
glassware used during the experimental work, we were fasci-
nated to observe the instantaneous formation of a transparent
jellylike material upon addition of acetone to wash out any
remained substance. The unexpected phenomenon took place,
based on the experimental protocol, only in the beaker contain-
ing (1R,2R)-(+)-1,2-diaminocyclohexane L-tartrate, MeOH, and
aqueous HCl.
The stunning discovery was followed by a rational design of
experiments in order to disclose the nature of the jellylike
material and the required components for its formation, as well
as their possible synergistic effect. Such comprehensive study
(see below) led to a 0.126 M methanolic solution of (1R,2R)-
(+)-1,2-diaminocyclohexane L-tartrate and 1 equiv of concen-
trated hydrochloric acid (37% HCl) as the optimum multicom-
ponent organogelator solution, which corresponds to a molar
ratio of diaminocyclohexane:tartaric acid:MeOH:HCl:H2O )
1:1:195:1:3.25. As it will be discused later, the presence of each
component, including the water,15 was found to be crucial for
the gelation event.
We were delighted to observe that the addition of tiny
amounts of this solution to a variety of organic solvents
instantaneously induced their gelation at room temperature.
Nevertheless, a closer inspection of the formed jellylike materi-
als revealed a nonhomogeneous gel phase, which often leaked
a small amount of solvent after turning the test tube upside-
down. In order to prepare clear homogeneous and stable gels,
we found that the organic solvents must be cooled down close
to their freezing point prior to addition of an appropriate volume
of the MOGLS. Then, the homogeneous mixture was allowed
to warm up to promote formation of the gels. Interestingly, both
the solvent-MOGLS mixture and the MOGLS solution remain
as clear solutions at temperatures as low as -100 °C for any
period of time. As far as we are aware, this is the first example
where the gelation phenomenon efficiently takes places upon
warming up instead of cooling down the isotropic solution of
the gelator.16 The only example that might be considered rather
similar is the uncommon gelation of organic fluids at room
temperature without the heating/cooling cycle.11b It is worth
noting that the formation of higher aggregates upon raising the
temperature is also observed in nature. Living organisms have
developed an impressive molecular machinery to achieve motion
and other biological functions by free energy transductions of
any chemical event (protein folding/unfolding or self-assembling
Figure 1. New multicomponent organogelator liquid system (MOGLS),
in which the presence and stoichiometry of each component is critical for
the gelation of organic fluids. Molar ratio of diaminocyclohexane:tartaric
acid:MeOH:HCl:H2O ) 1:1:195:1:3.25.
