P.J.Belshaw et al.
FULL PAPER
and EMD Biosciences (San Diego, CA).Diisopropyldichlorosilane was
obtained from Fluka (Milwaukee, WI).The benzylamine salt of ( 2S,4S)-
N-Boc-4-hydroxypiperidine-2-carboxylic acid was obtained from Chiro-
tech Technology Ltd (Cambridge, UK).Hydroxymethyl polystyrene res-
in SS, 100 200 mesh, 1% DVB, 1.0 mmolgꢀ1 was obtained from Ad-
vanced ChemTech (Louisville, KY).All other reagents were obtained
from Aldrich Chemical (Milwaukee, WI) and used without further purifi-
cation.Solid-phase reactions were conducted inside 50 mL round-bot-
tomed flasks or 10 mL polypropylene poly-prep chromatography columns
obtained from Bio-Rad Laboratories (Hercules, CA) and agitated on a
Labquake shaker.Tetrahydrofuran (THF) and toluene were distilled
from sodium benzophenone ketyl; dichloromethane (CH2Cl2) was distil-
led from phosphorous pentoxide.Analytical thin-layer chromatography
(TLC) was carried out on EM Science TLC plates precoated with silica
gel 60 F254 (250 mm layer thickness).TLC visualization was accomplished
by using a UV lamp and/or charring solutions of either ninhydrin or
phosphomolybdic acid (PMA).Flash column chromatography (FCC) was
performed on Silicycle silica gel 60 (230 400 mesh). 1H NMR spectra
were recorded in deuterated solvents on a Bruker AC-250 (250 MHz),
Bruker AC-300 (300 MHz) or a Varian UNITY-500 (500 Mhz) spectrom-
eter.Chemical shifts are reported in parts per million (ppm, d) relative
to tetramethylsilane (TMS, d 0.00) or relative to residual solvent signals
(CDCl3 7.27 (1) or CD3CN 1.94 (5)). Coupling constants (J values) are
given in Hz, and peak multiplicities are denoted by s (singlet), d (dou-
blet), dd (doublet of doublets), ddd (doublet of doublet of doublets), dq
(doublet of quartets), dt (doublet of triplets), m (multiplet), q (quartet),
and t (triplet). 13C NMR spectra were recorded in deuterated solvents on
a Bruker AC-250 (62.5 MHz), Bruker AC-300 (75 MHz) or a Varian
UNITY-500 (125 MHz) spectrometer.Chemical shifts are reported in
parts per million (ppm, d) relative to residual solvent signals (CDCl3
77.23 (3) or CD3CN 1.39 (7)). For compounds with multiple rotamers all
observed signals are reported.Optical rotations were obtained on a
Perkin Elmer 241 digital polarimeter at room temperature with an Na
lamp.Concentrations ( c) are reported in g per 100 mL.Fourier transform
infrared (FT-IR) spectra were obtained on a Mattson Polaris instrument.
High-resolution electrospray ionization mass spectra (HRESI-MS) were
obtained on a Micromass LCT.
mogeneous by TLC analysis. Rf =0.66 (hexanes/Et2O 7:3); [a]=ꢀ17.2
1
(c=0.087 in CHCl3); H NMR (300 MHz, CDCl3, 258C): d=0.065 (d, J=
0.7 Hz, 6H), 0.88 (s, 9H), 1.44 (s, 9H), 1.47 (s, 10H), 1.60 (m, 1H), 1.79
(m, 1H), 2.30 (m, 1H), 2.99 (m, 1H), 3.58 (m, 1H), 3.99 (m, 1H),
4.74 ppm (m, 1H); 13C NMR (75 MHz, CDCl3, 258C): d=ꢀ4.6, 18.2,
25.9, 28.1, 28.4, 34.5, 34.8, 36.1, 40.2, 40.7, 54.5, 55.6, 67.0, 79.9, 81.4,
155.5, 155.6, 170.6, 170.8 ppm; FT-IR (thin film): n˜ =2976, 2930, 2857,
1739, 1704, 1473 cmꢀ1; MS (HRESI-MS) calcd for [C21H41NO5Si+Na]+:
438.2652; found: 438.2656.
Fmoc-(2S,4S)-hyPip(OTBS)-OtBu 2: Boc-(2S,4S)-hyPip(OTBS)-OtBu 1
(30 mg, 0.072 mmol) was dissolved in CH2Cl2 (0.7 mL) and treated with a
solution of TMS-OTf in toluene (0.292m, 0.25 mL, 0.073 mmol) at room
temperature.The reaction mixture was stirred at room temperature
under an atmosphere of N2 for 4 h and was quenched with MeOH
(1 mL), concentrated and purified by chromatography on silica gel (50:1
Et2O/MeOH) to give the a-amino ester as a liquid that was homogene-
ous by TLC analysis.The product was dissolved in CH 2Cl2 (2 mL), pyri-
dine (50 mL, 0.62 mmol) was added, and the system was cooled to 08C.
Fmoc-Cl (26 mg, 0.1 mmol) was added and the reaction mixture was stir-
red at room temperature under an atmosphere of N2 for 15 h.The mix-
ture was concentrated and purified by chromatography on silica gel (9:1
hexanes/Et2O) to give 2 as a solid (30 mg, 77%) that was homogeneous
by TLC analysis. Rf =0.40 (hexanes/Et2O 7:3); [a]=ꢀ11.4 (c=0.70 in
CHCl3); 1H NMR (300 MHz, CDCl3, 258C): d=0.12 (s, 6H), 0.93 (s,
9H), 1.46 (m, 1H), 1.50 (s, 9H), 1.66 (m, 1H), 1.87 (m, 1H), 2.40 (m,
1H), 3.17 (m, 1H), 3.67 (m, 1H), 4.14 (m, 1H), 4.35 (m, 3H), 4.89 (m,
1H), 7.36 (m, 4H), 7.60 (m, 2H), 7.78 ppm (d, J=7.5 Hz, 2H); 13C NMR
(75 MHz, CDCl3, 258C): d=ꢀ4.5, 18.3, 26.0, 28.2, 34.7, 34.8, 36.3, 40.6,
40.7, 47.4, 47.5, 55.2, 55.3, 66.9, 68.0, 82.0, 82.2, 120.1, 125.3, 127.3, 127.8,
141.5, 144.1, 144.3, 155.9, 156.3, 170.4 ppm; FT-IR (thin film): n˜ =3067,
2953, 2929, 1736, 1708, 1451 cmꢀ1
; MS (HRESI-MS) calcd for
[C31H43NO5Si+Na]+: 560.2808; found: 560.2815.
Fmoc-(2S,4S)-hyPip-OtBu 3: Fmoc-(2S,4S)-hyPip(OTBS)-OtBu
2
(90 mg, 0.167 mL) was dissolved in THF (5 mL) and HF/pyridine
(3.0 mL) was injected at 08C.The reaction mixture was stirred at room
temperature for 2 h and diluted with Et2O.The mixture was extracted
with saturated aq NaHCO3 (î1), aq HCl (0.1m, î2), and H2O (î1).
The organic layer was collected, concentrated, and purified by chroma-
tography on silica gel (1:4 hexanes/Et2O) to give 3 as a solid (68 mg,
96%) that was homogeneous by TLC analysis. Rf =0.45 (Et2O); [a]=
ꢀ23.2 (c=1.10 in CHCl3); 1H NMR (300 MHz, CDCl3, 258C): d=1.26
(m, 1H), 1.47 (s, 9H), 1.60 (m, 1H), 1.97 (m, 1H), 2.08 (s, 1H), 2.50 (m,
1H), 3.14 (m, 1H), 3.70 (m, 1H), 4.12 (m, 1H), 4.36 (m, 3H), 4.90 (m,
1H), 7.35 (m, 4H), 7.58 (m, 2H), 7.78 ppm (d, J=7.6 Hz, 2H) ; 13C NMR
(75 MHz, CDCl3, 258C): d=28.2, 34.2, 35.7, 40.4, 40.6, 47.4, 47.5, 55.0,
55.1, 66.0, 66.1, 68.0, 82.2, 82.4, 120.2, 125.2, 127.2, 127.9, 141.4, 144.0,
144.2, 155.9, 156.3, 170.2 ppm; FT-IR (thin film): n˜ =3435, 3066, 2975,
Boc-(2S,4S)-hyPip(OTBS)-OH: Aqueous HCl (0.5m) saturated with
sodium chloride (10 mL) was slowly added to the suspension of the ben-
zylamine salt of (2S,4S)-N-Boc-4-hydroxypiperidine-2-carboxylic acid
(1.0 g, 2.84 mmol) in EtOAc (10 mL) at 08C.The mixture was stirred at
08C for 20 min, diluted with EtOAc, and extracted with saturated aq
NaCl.The organic layer was collected, dried (Na SO4), and concentrated,
2
affording acid as a solid.The obtained acid was dissolved in THF
(30 mL) and imidazole (1.2 g, 17.04 mmol), 2,6-lutidine (1.3 mL,
11.36 mmol), and TBS-Cl (1.3 g, 8.52 mmol) were added at 08C.The re-
action mixture was stirred at room temperature under an atmosphere of
N2 for 48 h.The mixture was diluted with EtOAc and extracted with aq
HCl (0.1m, î2).The organic layer was collected and concentrated.The
resultant residue was suspended in MeOH (20 mL), stirred for 5 h, after
which the mixture was concentrated and purified by chromatography on
silica gel (50:50:1 hexanes/Et2O/AcOH) to give the side-chain TBS-pro-
tected acid as a solid (1.0 g, 98%) that was homogeneous by TLC analy-
sis. Rf =0.32 (hexanes/Et2O/HOAc 25:25:1); [a]=ꢀ23.3 (c=0.18 in
2931, 1733, 1704, 1451 cmꢀ1
[C25H29NO5+Na]+: 446.1943; found: 446.1921.
Alloc-l-MePhe-OH: solution of allyl chloroformate (1.5 mL,
;
MS (HRESI-MS) calcd for
A
13.9 mmol) in dioxane (20 mL) and aq NaOH (1m, 20 mL) were simulta-
neously added dropwise at 08C to a solution of H-l-MePhe-OH¥HCl
(2.0 g, 9.27 mmol), H2O (30 mL), aq NaOH (1m, 20 mL), and Et2O
(20 mL).The ice-bath was removed, and the reaction mixture was stirred
for 12 h at room temperature.The mixture was diluted with EtOAc and
extracted with saturated aq NaHCO3.The aqueous layer was collected,
acidified with concentrated HCl, and extracted with EtOAc.The organic
layer was collected, dried (Na2SO4), and concentrated affording a solid
(1.95 g, 80%) that was homogeneous by TLC analysis. Rf =0.35 (hex-
anes/Et2O/HOAc 30:20:1); [a]=ꢀ65.4 (c=2.09 in MeOH); 1H NMR
(250 MHz, CD3CN, 678C): d=2.81 (s, 3H), 3.10 (dd, J=10.7, 14.5 Hz,
1H), 3.33 (dd, J=5.2, 14.4 Hz, 1H), 4.51 (d, J=5.2 Hz, 2H), 4.88 (dd, J=
5.2, 10.5 Hz, 1H), 5.20 (m, 2H), 5.89 (m, 1H), 7.28 (m, 5H), 8.24 ppm (s,
1H); 13C NMR (62.5 MHz, CD3CN, 678C): d=33.0, 36.1, 61.9, 67.2,
117.8, 127.9, 129.8, 130.3, 134.7, 139.3, 157.5, 172.8 ppm; FT-IR (thin
film): n˜ =3078, 3029 2938, 1743, 1700, 1653, 1401 cmꢀ1; MS (HRESI-MS)
calcd for [C14H16NO4]ꢀ: 262.1079; found: 262.1069.
1
CHCl3); H NMR (300 MHz, CDCl3, 258C): d=0.060 (d, J=1.3 Hz, 6H),
0.87 (s, 9H), 1.45 (s, 9H), 1.72 (m, 3H), 2.36 (m, 1H), 2.98 (m, 1H), 3.65
(m, 1H), 4.01 (m, 1H), 4.92 (m, 1H), 11.35 ppm (s, 1H); 13C NMR
(75 MHz, CDCl3, 258C): d=ꢀ4.8, 17.9, 25.7, 28.2, 34.3, 35.4, 39.8, 40.5,
53.6, 54.5, 66.7, 80.6, 155.2, 155.7, 176.4, 176.6 ppm; FT-IR (KBr pellet):
n˜ =2954, 2856, 1750, 1630, 1439 cmꢀ1
[C17H32NO5Si]ꢀ: 358.2050; found: 358.2045.
Boc-(2S,4S)-hyPip(OTBS)-OtBu 1:
;
MS (HRESI-MS) calcd for
Boc-(2S,4S)-hyPip(OTBS)-OH
(0.92 g, 2.56 mmol) was dissolved in CH2Cl2 (5 mL) and anhydrous 2-
methyl-2-propanol (0.72 mL, 7.68 mmol) was added, followed by DMAP
(94 mg, 0.77 mmol). The solution was cooled to 08C, and DIC (0.80 mL,
5.12 mmol) in CH2Cl2 (5 mL) was injected dropwise over 15 min.The re-
action mixture was stirred at 08C under an atmosphere of N2 for 15 min
and then at room temperature for 5 h.The mixture was diluted with
Et2O and extracted with aq HCl (0.1m, î2) and H2O (î1).The organic
layer was collected, concentrated, and purified by chromatography on
silica gel (9:1 hexanes/Et2O) to give 1 as a solid (1.0 g, 94%) that was ho-
Alloc-d-Abu-OH: (d)-Aminobutyric acid (1.0 g, 9.7 mmol) was dissolved
in a mixture of H2O (15 mL), aq NaOH (1m, 10 mL), and Et2O (10 mL)
and the system cooled to 08C.A solution of allyl chloroformate (14. mL,
12.9 mmol) in dioxane (13 mL) was added slowly and simultaneously
4338
