molecules
Article
Pd-Catalyzed, Highly Selective C(sp2)-Br Bond
Coupling Reactions of o-(or m-, or p-) Chloromethyl
Bromobenzene with Arylboronic Acids
Ming-ming Pei, Ping Liu *, Yan Liu, Xin-ming Lv, Xiao-wei Ma * and Bin Dai
School of Chemistry and Chemical Engineering/Key Laboratory for Green Processing of Chemical Engineering
of Xinjiang Bingtuan, Shihezi University, Shihezi 832003, China; peimming@163.com (M.-m.P.);
liuyan1979810@aliyun.com (Y.L.); ciqlxm@163.com (X.-m.L.); db_tea@shzu.edu.cn (B.D.)
* Correspondence: liuping1979112@aliyun.com (P.L.); mxw_tea@shzu.edu.cn (X.-w.M.);
Tel.: +86-0993-205-7213 (P.L.)
Received: 25 January 2018; Accepted: 13 February 2018; Published: 15 February 2018
Abstract: Highly selective C(sp2)–C(sp2) cross-coupling of dihalogenated hydrocarbons comprising
C(sp2)–Br and C(sp3)–Cl bonds with arylboronic acids is reported. This highly selective coupling
reaction of the C(sp2)–Br bond is successfully achieved using Pd(OAc)2 and PCy3
HBF4 as the
·
palladium source and ligand, respectively. A series of chloromethyl-1,10-biphenyl compounds are
obtained in moderate-to-excellent yields. Moreover, this protocol can be extended to the one-pot
dual arylation of 1-bromo-4-(chloromethyl)benzene with two arylboronic acids, leading to diverse
unsymmetrical 4-benzyl-1,10-biphenyl derivatives.
Keywords: Pd-catalyzed; selective; dihalogenated hydrocarbon; arylboronic acids; coupling reaction
1. Introduction
Transition-metal-catalyzed cross-coupling reactions between electrophiles and arylboronic acids
are an important method in the C–C bond formation [
benzyl halides have been used as electrophiles for constructing C(sp2)–C(sp2) and C(sp3)–C(sp2)
bonds, respectively [ 10]. To the best of our knowledge, the selective reaction of dihalogenated
hydrocarbons containing the C(sp2)–X and C(sp3)–X bonds with arylboronic acids in the presence
1–3]. Over the past decades, aryl and
4–
of palladium catalyst has been rarely reported [11–16]. Duchêne and Thibonnet reported the
Pd(PPh3)4-catalyzed selective coupling reaction of C(sp3)–Br at the benzylic position of the starting
bromobenzyl bromides with arylboronic acids, affording C(sp3)–C(sp2) as the coupling products
(Scheme 1a) [11,12]. Gueiffier also developed a Pd(PPh3)4-catalyzed one-pot two-step reaction
of bromobenzyl chloride with arylboronic acids by first C(sp3)–C(sp2) coupling and subsequent
C(sp2)–C(sp2) coupling, affording numerous new unsymmetrical methylene-linked biaryl systems
(Scheme 1a)[13]. Çetinkaya et al. achieved the palladium-catalyzed C(sp2)–C(sp2) coupling reactions
with 1-bromo-4-(bromomethyl)benzene and arylboronic acids by using saturated N-heterocarbene
ligands [17]. In 2010, Maseras conducted an experimental and theoretical study on the role of phosphine
ligands in palladium-catalyzed Suzuki cross-coupling of competitive and selective C(sp3)–Br versus
C(sp2)–Br bond activation [18]. Their results indicated that as a less-hindered phosphine, PPh3 is
associated with a bisligated form of the catalyst, which favors the activation of the C(sp3)–Br bond of the
α
-bromosulfoxide side. As the more hindered phosphine, P(1-napthyl)3 is related to the monoligated
form of the catalyst, which promotes the activation of the C(sp2)–Br bond of the bromoaryl moiety.
Molecules 2018, 23, 433; doi:10.3390/molecules23020433
www.mdpi.com/journal/molecules

Molecules 2018, 23, 433
2 of 12
Scheme 1. Selective palladium-catalyzed Suzuki-Miyaura coupling reaction. (a) C(sp3)–C(sp2)
coupling; (b) C(sp2)–C(sp2) coupling.
Inspired by this study and based on our previous studies [19–25], we reported Pd-catalyzed,
highly selective C(sp2)-Br bond coupling reactions of o-(or m-, or p-)chloromethyl bromobenzene
with arylboronic acids in the presence of the ligand PCy3
HBF4, which does not afford C(sp3)–C(sp2)
·
coupling products; instead, the reaction provided highly selective of C(sp2)–C(sp2) coupling products
(Scheme 1b).
2. Results and Discussion
Initially, 1-bromo-4-(chloromethyl)benzene and p-tolylboronic acid were selected as model
substrates to optimize the reaction conditions. Table 1 summarizes the results obtained. The screened
bases were examined by using PCy3
respectively, in toluene/water (1/0.1) at 80 C for 2 h; Cs2CO3 was the most effective base, affording the
·
HBF4 and Pd(OAc)2 as the ligand and palladium source,
◦
desired product in 99% yield (entry 5). On the other hand, other bases such as K2CO3, K3PO4 3H2O,
·
NaOH, and NEt3 afforded the desired products in 16–84% yields (entries 1–4). Remarkably, the ligand
was found to play an important role in this reaction, and PPh3 was not effective for this selective
C(sp2)–C(sp2) coupling reaction (entry 6). Moreover, with the decrease in the reaction temperature to
60 ◦C, the product was obtained in only 74% yield (entry 7). With the decrease in the catalyst amount
from 1 mol % to 0.2 mol %, the desired product was still obtained in a gas chromatography-mass
spectrometer (GC–MS) yield of 99% (entries 8–10). However, with the decrease in the catalyst
loading to 0.1 mol %, the yield was significantly reduced (entry 11). Finally, the combination of
◦
Pd(OAc)2 (0.2 mol %)/PCy3
(1 mL/0.1 mL) was found to constitute the optimum reaction conditions.
·
HBF4 (0.4 mol %) and Cs2CO3 (2 equiv.) at 80 C for 2 h in toluene/water
Table 1. Optimized reaction conditions a.
◦
Yield/% b
Entry
Pd(OAc)2
PCy3·HBF4
4 mol %
4 mol %
4 mol %
4 mol %
4 mol %
PPh3/4 mol %
4 mol %
2 mol %
1 mol %
0.4 mol %
0.2 mol %
Base/Equiv.
T/ C
1
2
3
4
5
6
7
8
9
2 mol %
2 mol %
2 mol %
2 mol %
2 mol %
2 mol %
2 mol %
1 mol %
0.5 mol %
0.2 mol %
0.1 mol %
NEt3
NaOH
80
80
80
80
80
80
60
80
80
80
80
(37) c
(14) c
(69) c
(84) c
99(97) c
0
74
99
99
99
K3PO4·3H2O
K2CO3
Cs2CO3
Cs2CO3
Cs2CO3
Cs2CO3
Cs2CO3
Cs2CO3
Cs2CO3
10
11
23
a
Reaction conditions: 1-bromo-4-(chloromethyl)benzene 0.30 mmol, p-tolylboronic acid 0.33 mmol, base 2 equiv.,
b
1.0 mL toluene and 0.1 mL H2O, 2 h, Ar protection. Gas chromatography-mass spectrometry (GC–MS) yield.
c
Isolated yield.

Molecules 2018, 23, 433
3 of 12
With the optimized reaction conditions in hand, the substrate scope of this selective
Suzuki–Miyaura reaction was examined. First, the coupling reactions of 1-bromo-4-(chloromethyl)benzene
with arylboronic acid were explored under the optimized reaction conditions. 4-Substituted
arylboronic acids bearing electron-donating or electron-withdrawing groups selectively underwent
the coupling reaction, affording corresponding products 3b–3g in 75–93% yields (Table 2).
Furthermore, the selective coupling reaction of 1-bromo-4-(chloromethyl)benzene, with m-tolylboronic
acid, and (3-chlorophenyl)boronic acid afforded the desired products 3h and 3i in 98% and 73% yields,
respectively. Sterically demanding ortho substituents, such as o-tolylboronic acid, did not impair the
coupling reaction, affording the desired product 3j in 90% yield. However, (2,3-difluorophenyl)boronic
acid and (2,6-dimethylphenyl)boronic acid as substrates afforded coupling products 3k and 3l
,
respectively, in low yields. In addition, thiophen-3-ylboronic acid, naphthalen-2-ylboronic acid,
and 4-vinylphenylboronic acid were tolerated, affording desired products 3n–3p in 57–86% yields.
Table 2. Selective coupling reaction of 1-bromo-4-(chloromethyl)benzene with arylboronic acid a.
Cl
C3H7
3b, 79%
3c, 87%
3d, 83%
3g, 75%
3j, 90%
3f, 83%
3i, 73%
3e, 93%
3h, 98%
3k, 47%
3n, 77%
3l, 50%
3o, 86%
3m, 73%
3p, 57%
a
Reaction conditions: 1-bromo-4-(chloromethyl)benzene 0.30 mmol, arylboronic acid 0.33 mmol, 0.2 mol %
Pd(OAc)2, 0.4 mol % PCy3
HBF4, 2 equiv. Cs2CO3, 1.0 mL toluene and 0.1 mL H2O, 80 ◦C, 2 h, Ar protection.
·
The yields of isolated products are given.
Next, the selective coupling reactions of 1-bromo-3-(chloromethyl)benzene with various
arylboronic acids were investigated (Table 3). The results indicated that neither the electronic property
nor the steric hindrance of the substrates clearly affects the coupling reaction: The desired products
4a–4h were obtained in 73–95% yields.

Molecules 2018, 23, 433
4 of 12
Table 3. Selective coupling reaction of arylboronic acid with 1-bromo-3-(chloromethyl)benzene a.
4a, 95%
4e, 92%
4d, 93%
4h, 73%
4b, 90%
4f, 87%
4c, 92%
4g, 95%
a
Reaction conditions: 1-bromo-3-(chloromethyl)benzene 0.30 mmol, arylboronic acid 0.33 mmol, 0.2 mol %
Pd(OAc)2, 0.4 mol % PCy3
HBF4, 2 equiv. Cs2CO3, 1.0 mL toluene and 0.1 mL H2O, 80 ◦C, 2 h, Ar protection.
·
The yields of isolated products are given.
To further ascertain the application scope of the catalytic system, the reaction of
1-bromo-2-(chloromethyl)benzene with arylboronic acids was examined. The present catalytic method
can be applied for the selective coupling of 1-bromo-2-(chloromethyl)benzene with arylboronic acids,
affording the desired products 5a–5h in yields of 80–95% (Table 4).
Table 4. Selective coupling reaction of arylboronic acid with 1-bromo-2-(chloromethyl)benzene a.
5d, 92%
5h, 80%
5a, 97%
5e, 88%
5c, 89%
5g, 95%
5b, 95%
5f, 87%
a
Reaction conditions: 1-bromo-3-(chloromethyl)benzene 0.30 mmol, arylboronic acid 0.33 mmol, 0.2 mol %
Pd(OAc)2, 0.4 mol % PCy3
HBF4, 2 equiv. Cs2CO3, 1.0 mL toluene and 0.1 mL H2O, 80 ◦C, 2 h, Ar protection.
·
The yields of isolated products are given.
A one-pot dual Suzuki coupling reaction for successively substituting 4-bromobenzyl chloride
with distinct aryl groups was contemplated, which could provide a straightforward route for obtaining
diverse 4-benzyl-1,10-biphenyl derivatives (Table 5). First, 4-bromobenzyl chloride was treated with
1.1 equivalent of p-tolylboronic acid in the presence of 2 mol % of Pd(OAc)2, 0.4 mol % of PCy3
·
HBF4,
◦
and 5.0 equiv. of Cs2CO3 in a mixture of toluene and water (10:1). After heating for 2 h at 80 C,
1.0 equivalent of arylboronic acid and 4.0 mol % of PPh3 were added to the reaction system. The reaction
mixture was stirred for 5 h at 80 ◦C, affording the desired products 6a–6d in 57–96% yields.

Molecules 2018, 23, 433
5 of 12
Table 5. One-pot dual arylations of 1-bromo-4-(chloromethyl)benzene a.
6a, 78%
6c, 89%
6b, 96%
6d, 57%
Me
S
a
Reaction conditions: (1) 1-bromo-4-(chloromethyl)benzene 0.30 mmol, arylboronic acid 0.33 mmol, 2 mol %
Pd(OAc)2, 0.4 mol % PCy3
HBF4, 5 equiv. Cs2CO3, 1.0 mL toluene and 0.1 mL H2O, 80 ◦C, 2 h, Ar protection;
·
(2) 4.0 mol % PPh3, arylboronic acid 0.33 mmol, 80 ◦C, 5 h, Ar protection. The yields of isolated products are given.
Next, the coupling reactions of 1-bromo-4-(bromomethyl)benzene (1d) with p-tolylboronic acid
2a) were investigated under the optimized conditions. We found that the selective reaction of
(
C(sp2)–Br bond with arylboronic acids could proceed smoothly to give 42% of the desired product 7a
,
also accompanied by 25% yield of bis-coupling product 7b (Scheme 2). This experimental result shows
that the selectivity of the reaction depends not only on the regulatory effect of the phosphine ligand
but also on the structure of the C(sp3)–X bond.
The selectivity depended exclusively on the palladium ligands.
Scheme 2. Selective coupling reaction of 1-bromo-4-(bromo methyl)benzene with p-tolylboronic acid.
To demonstrate the importance of phosphine ligand for palladium-catalyzed selective coupling
reactions of C(sp2)–Br bond or C(sp3)–Cl bond with arylboronic acid, the external competition
experiment was performed. To this end, we designed an experiment in which mixtures of
bromobenzene and (chloromethyl)benzene were allowed to react with p-tolylboronic acid (Scheme 3).
As expected, the formation of the Csp2–Csp2 cross-coupling product (7c) was achieved in the
competitive experiment when PCy3 HBF4 was used as the phosphine ligand in the palladium catalyst.
·
Scheme 3. Selective coupling reaction of bromobenzene or (chloromethyl)benzene with p-tolylboronic acid.

Molecules 2018, 23, 433
6 of 12
3. Materials and Methods
Chemicals were obtained commercially and used as received. Nuclear magnetic resonance (NMR)
spectra were recorded on a Bruker DPX–400 spectrometer (Bruker Co., Billerica, MA, USA) using
tetramethylsilane (TMS) as the internal standard. Electric impact ionization (EI)–Mass spectrum was
measured on a gas chromatography time of flight high resolution mass spectrometry (GCTOF-HRMS)
(Waters Co, Milford, MA, USA). or GC-MS (Agilent 7890A/5975C, Santa Clara, CA, USA)
instrument. Electrospray ionization (ESI)–Mass spectrum was measured on a matrix-assisted laser
desorption/ionization time of flight mass spectrometry (MALDI-TOF MS) (Bruker Co., Bremen,
Germany). To all copies of 1H NMR, 13C NMR and HRMS spectra, please see Figures S2–S45
in Supplementary Materials. All products were isolated by short chromatography on a silica gel
(200–300 mesh) column using petroleum ether (60–90 ◦C), unless otherwise noted. Arylboronic acids
and o-(or m-, or p-)chloromethyl bromobenzene were of analytical grade quality, purchased from
Adamas-beta Pharmaceuticals, Inc. (Shanghai, China).
3.1. General Procedure for the Selective Coupling Reaction of o-(or m-, or p-)chloromethyl Bromobenzene with
Arylboronic Acid
A Schlenk tube (20 mL) was charged with o-(or m-, or p-)chloromethyl bromobenzene (0.3 mmol),
arylboronic acid (0.33 mmol), Pd(OAc)2 (0.2 mol %), PCy3 HBF4 (0.4 mol %), and Cs2CO3 (2 equiv.).
·
The tube was degassed for 30 s and then was filled with argon. This operation was repeated three times.
After toluene (1.0 mL) and H2O (0.1 mL) were added under argon atmosphere, the resulting reaction
mixture was stirred at 80 ◦C for 2 h under argon. After the completion of the reaction, the reaction
mixture was allowed to cool to room temperature. The solution was quenched with water (10 mL) and
extracted with EtOAc (3
×
10 mL). The combined EtOAc extracts were dried over anhydrous Na2SO4
and filtered, followed by solvent removal under reduced pressure. The residue was purified by flash
column chromatography on silica gel using petroleum ether/EtOAc as the eluent.
3.2. General Procedure for One-Pot Dual Arylations of 1-Bromo-4-(chloromethyl)benzene
A Schlenk tube (20 mL) was charged with 1-bromo-4-(chloromethyl)benzene (0.3 mmol),
arylboronic acid (0.33 mmol), 2 mol % Pd(OAc)2, 0.4 mol % PCy3 HBF4, and 5 equiv. Cs2CO3. The tube
·
was degassed for 30 s and then was filled with argon. This operation was repeated for three times.
After toluene (1.0 mL) an◦d H2O (0.1 mL) were added under argon atmosphere, the resulting reaction
mixture was stirred at 80 C for 2 h under argon. After the completion of the reaction, the solution was
allowed to cool to room temperature. Then, another arylboronic acid (0.33 mmol) and 4 mol % PPh3
were introduced under argon. The reaction mixture was heated at 80 ◦C for 5 h. The solution was
quenched with water (10 mL) and extracted with EtOAc (3
×
10 mL). The combined EtOAc extracts
were dried over anhydrous Na2SO4, filtrated, and then the solvent was removed under reduced
pressure. The residue was purified by flash column chromatography on silica gel with PE/EtOAc as
the eluent.
4-(chloromethyl)-40-methyl-1,10-biphenyl (3a) [26]: Colorless oil (64.3 mg, 99%). 1H-NMR (400 MHz,
CDCl3) δ 7.57 (d, J = 8.4 Hz, 2H), 7.48 (d, J = 8.4 Hz, 2H), 7.44 (d, J = 8.0 Hz, 2H), 7.25 (d, J = 8.0 Hz, 2H),
4.63 (s, 2H), 2.40 (s, 3H). 13C-NMR (100 MHz, CDCl3)
127.43, 127.10, 46.27, 21.27.
δ
141.48, 137.75, 137.53, 136.28, 129.69, 129.18,
1
4-(chloromethyl)-1,10-biphenyl (3b) [27]: Yellow oil (47.9 mg, 79%). H-NMR (400 MHz, CDCl3)
δ
7.58
(d, J = 7.2 Hz, 4H), 7.51–7.40 (m, 4H), 7.39–7.32 (m, 1H), 4.63 (s, 2H). 13C-NMR (100 MHz, CDCl3)
δ
141.53, 140.63, 136.58, 129.19, 128.96, 127.67, 127.63, 127.26, 46.19.
1
4-(chloromethyl)-40-methoxy-1,10-biphenyl (3c) [28]: Colorless oil (60.7 mg, 87%). H-NMR (400 MHz,
CDCl3) δ 7.54 (d, J = 8.8 Hz, 2H), 7.52 (d, J = 8.8 Hz, 2H), 7.44 (d, J = 8.4 Hz, 2H), 6.98 (d, J = 8.8 Hz, 2H),

Molecules 2018, 23, 433
7 of 12
4.63 (s, 2H), 3.85 (s, 3H). 13C-NMR (100 MHz, CDCl3)
127.17, 114.41, 55.51, 46.30.
δ
159.50, 141.16, 135.94, 133.15, 129.19, 128.29,
0
0
1
4-(chloromethyl)-4 -propyl-1,1 -biphenyl (3d): Colorless oil (60.9 mg, 83%). H-NMR (400 MHz, CDCl3)
δ
7.57 (d, J = 8.4 Hz, 2H), 7.50 (d, J = 8.4 Hz, 2H), 7.44 (d, J = 8.4 Hz, 2H), 7.26 (s, 1H), 7.24 (d, J = 2.8 Hz,
1H), 4.63 (s, 2H), 2.65–2.60 (m, 2H), 1.68 (dq, J = 14.8, 7.2 Hz, 2H), 0.97 (t, J = 7.3 Hz, 3H). 13C-NMR
(100 MHz, CDCl3)
δ 142.33, 141.51, 137.97, 136.24, 129.16, 129.09, 127.44, 127.07, 46.27, 37.84, 24.69,
14.03. HRMS (ESI) m/z calcd for C16H17ClNa+ (M + Na)+ 267.09110, found 267.09195.
0
0
1
4-(chloromethyl)-4 -pentyl-1,1 -bipheny (3e) [29]: White solid (75.8 mg, 93%). H-NMR (400 MHz, CDCl3)
7.57 (d, J = 8.4 Hz, 2H), 7.50 (d, J = 8.0 Hz, 2H), 7.44 (d, J = 8.4 Hz, 2H), 7.26 (s, 1H), 7.25 (d, J = 3.2
δ
Hz, 1H), 4.63 (s, 2H), 2.67–2.61 (m, 2H), 1.65 (p, J = 7.4 Hz, 2H), 1.39–1.32 (m, 4H), 0.93–0.88 (m, 3H).
13C-NMR (100 MHz, CDCl3)
31.70, 31.31, 22.71, 14.19.
δ
142.60, 141.51, 137.93, 136.24, 129.16, 129.03, 127.44, 127.09, 46.28, 35.73,
0
0
1
4-(chloromethyl)-4 -fluoro-1,1 -biphenyl (3f) [30]: Colorless oil (54.9 mg, 83%). H-NMR (400 MHz, CDCl3)
δ
7.55 (d, J = 3.2 Hz, 1H), 7.54–7.51 (m, 3H), 7.45 (d, J = 8.0 Hz, 2H), 7.12 (t, J = 8.8 Hz, 2H), 4.63 (s, 2H).
13C-NMR (100 MHz, CDCl3) δ 162.74, 140.53, 136.63, 129.41, 129.25, 128.82, 127.48, 115.85, 46.10.
4-(chloromethyl)-40-(trifluoromethyl)-1,10-biphenyl (3g) [31]: Colorless oil (60.9 mg, 75%). 1H-NMR
(400 MHz, CDCl3)
13C-NMR (100 MHz, CDCl3)
(q, J = 4.0 Hz),123.78 (dd, J =420.0, 271.0 Hz) 45.94.
δ
7.69 (d, J = 1.6 Hz, 4H), 7.59 (d, J = 8.4 Hz, 2H), 7.50 (d, J = 8.0 Hz, 2H), 4.64 (s, 2H).
δ
144.14, 140.03, 137.63, 129.95–129.57 (m), 129.39, 127.79, 127.55, 125.93
1
40-(chloromethyl)-3-methyl-1,10-biphenyl (3h): Colorless oil (63.7 mg, 98%). H-NMR (400 MHz, CDCl3)
7.56 (d, J = 8.4 Hz, 2H), 7.42 (d, J = 8.4 Hz, 2H), 7.37 (d, J = 8.8 Hz, 2H), 7.31 (t, J = 7.6 Hz, 1H),
7.16 (d, J = 7.6 Hz, 1H), 4.61 (s, 2H), 2.40 (s, 3H). 13C-NMR (100 MHz, CDCl3)
141.61, 140.59, 138.52,
δ
δ
136.45, 129.11, 128.85, 128.40, 128.02, 127.59, 124.35, 46.20, 21.66. HRMS (EI): m/z calcd for C14H13Cl
[M]: 216.0723, found [M]: 216.0723.
1
3-chloro-40-(chloromethyl)-1,10-biphenyl (3i): Colorless oil (51.9 mg, 73%). H-NMR (400 MHz, CDCl3)
δ
7.54 (d, J = 8.4 Hz, 3H), 7.47–7.42 (m, 3H), 7.38–7.30 (m, 2H), 4.62 (s, 2H). 13C-NMR (100 MHz, CDCl3)
δ
142.42, 140.02, 137.24, 134.84, 130.18, 129.28, 127.66, 127.56, 127.35, 125.37, 45.99. HRMS (EI): m/z
calcd for C13H10Cl2 [M]: 236.0169, found [M]: 236.0160.
40-(chloromethyl)-2-methyl-1,10-biphenyl (3j) [32]: Colorless oil (58.5 mg, 90%). 1H-NMR (400 MHz,
CDCl3)
δ 7.43 (d, J = 8.0 Hz, 2H), 7.32 (d, J = 8.4 Hz, 2H), 7.28–7.25 (m, 2H), 7.25–7.19 (m, 2H),
4.64 (s, 2H), 2.27 (s, 3H). 13C-NMR (100 MHz, CDCl3)
129.71, 128.49, 127.60, 125.97, 46.28, 20.59.
δ
142.29, 141.35, 136.06, 135.44, 130.52, 129.86,
0
0
1
4 -(chloromethyl)-2,3-difluoro-1,1 -biphenyl (3k): Yellow oil (33.6 mg, 47%). H-NMR (400 MHz, CDCl3)
δ
7.54 (d, J = 6.8 Hz, 2H), 7.48 (d, J = 8.4 Hz, 2H), 7.21–7.08 (m, 3H), 4.63 (s, 2H). 13C-NMR (100 MHz,
CDCl3) 151.25 (dd, J = 247.0, 14.0 Hz), 148.12 (dd, J = 249.0, 14.0 Hz), 137.55, 134.96 (d, J = 4.0 Hz),
δ
130.75 (d, J = 10.0 Hz), 129.45 (d, J = 3.0 Hz), 128.95, 125.46–125.27 (m), 124.29 (dd, J = 7.0, 5.0 Hz),
116.46 (d, J = 20.0 Hz), 45.96. HRMS (EI): m/z calcd for C13H9ClF2 [M]: 238.0369, found [M]: 238.0361.
0
0
1
4 -(chloromethyl)-2,6-dimethyl-1,1 -biphenyl (3l): Colorless oil (34.6 mg, 50%). H-NMR (400 MHz, CDCl3)
7.44 (d, J = 8.0 Hz, 2H), 7.15 (t, J = 2.9 Hz, 2H), 7.13 (s, 1H), 7.10 (d, J = 7.6 Hz, 2H), 4.65 (s, 2H),
2.02 (s, 6H). 13C-NMR (100 MHz, CDCl3)
140.29, 139.54, 137.04, 132.09, 129.33, 128.84, 127.43, 122.00,
46.05, 29.85. HRMS (ESI) m/z calcd for C15H16Cl+ (M + H)+ 231.09350, found 231.09262.
δ
δ
0
0
1
4 -(chloromethyl)-3,4,5-trifluoro-1,1 -biphenyl (3m) [33]: Colorless oil (56.2 mg, 73%). H-NMR (400 MHz,
CDCl3)
7.48 (d, J = 1.6 Hz, 4H), 7.17 (dd, J = 6.4, 6.4 Hz, 2H), 4.62 (s, 2H). 13C-NMR (100 MHz, CDCl3)
151.60 (ddd, J = 248.0, 10.0, 4.0 Hz), 141.05–138.04 (m), 138.43, 137.88, 136.74 (td, J = 7.7, 4.6 Hz),
129.46, 127.3, 111.34–111.04 (m), 45.77.
δ
δ

Molecules 2018, 23, 433
8 of 12
1
3-(4-(chloromethyl)phenyl)thiophene (3n) [34]: Colorless oil (48.2 mg, 77%). H-NMR (400 MHz, CDCl3)
δ
7.58 (d, J = 8.4 Hz, 2H), 7.45 (dd, J = 1.6, 1.6 Hz, 1H), 7.40 (d, J = 8.4 Hz, 2H), 7.38 (d, J = 1.2 Hz, 1H),
7.37 (s, 1H), 4.60 (s, 2H). 13C-NMR (100 MHz, CDCl3)
126.38, 120.84, 46.21.
δ
141.78, 136.3, 136.13, 129.26, 126.88, 126.52,
1
2-(4-(chloromethyl)phenyl)naphthalene (3o) [35]: Colorless oil (65.2 mg, 86%). H-NMR (400 MHz, CDCl3)
δ
8.00 (s, 1H), 7.90–7.82 (m, 3H), 7.71–7.66 (m, 3H), 7.51–7.44 (m, 4H), 4.62 (s, 2H). 13C-NMR (100 MHz,
CDCl3) 141.43, 137.93, 136.68, 133.76, 132.86, 129.30, 128.66, 128.36, 127.89, 127.79, 126.53, 126.24,
126.02, 125.53, 46.21.
δ
1
4-(chloromethyl)-40-vinyl-1,10-biphenyl (3p): Colorless oil (39.1 mg, 57%). H-NMR (400 MHz, CDCl3)
7.59 (d, J = 8.0 Hz, 2H), 7.56 (d, J = 8.0 Hz, 2H), 7.49 (s, 1H), 7.47 (d, J = 2.8 Hz, 2H), 7.45 (s, 1H),
6.76 (dd, J = 10.8, 10.8 Hz, 1H), 5.80 (d, J = 17.6 Hz, 1H), 5.28 (d, J = 10.8 Hz, 1H), 4.64 (s, 2H). 13C-NMR
δ
(100 MHz, CDCl3) δ 140.98, 139.91, 137.00, 136.62, 136.44, 129.21, 127.39, 127.31, 126.83, 114.24, 46.17.
HRMS (ESI) m/z calcd for C15H13ClNa+ (M + Na)+ 251.05980, found 251.06100.
3-(chloromethyl)-1,10-biphenyl (4a) [36]: Yellow solid (57.8 mg, 95%). 1H-NMR (400 MHz, CDCl3)
δ
7.62–7.59 (m, 2H), 7.58 (d, J = 0.8 Hz, 1H), 7.55 (dd, J = 7.6, 1.2 Hz, 1H), 7.47–7.41 (m, 3H), 7.38 (s, 1H),
7.36 (d, J = 1.6 Hz, 1H), 4.65 (s, 2H). 13C-NMR (100 MHz, CDCl3)
δ 141.96, 140.73, 138.10, 129.32, 128.96,
127.69, 127.56, 127.54, 127.36, 127.31, 46.41.
3-(chloromethyl)-40-methyl-1,10-biphenyl (4b) [36]: Colorless oil (58.5 mg, 90%). 1H-NMR (400 MHz,
CDCl3)
δ 7.58 (s, 1H), 7.51 (d, J = 7.6 Hz, 1H), 7.47 (d, J = 8.0 Hz, 2H), 7.40 (t, J = 7.6 Hz, 1H),
7.33 (d, J = 7.6 Hz, 1H), 7.24 (d, J = 7.6 Hz, 2H), 4.62 (s, 2H), 2.38 (s, 3H). 13C-NMR (100 MHz, CDCl3)
δ
141.87, 138.04, 137.83, 137.50, 129.67, 129.27, 127.35, 127.26, 127.16, 127.13, 46.46, 21.25.
3-(chloromethyl)-40-(trifluoromethyl)-1,10-biphenyl (4c) [37]: Colorless oil (74.7 mg, 92%). 1H-NMR
(400 MHz, CDCl3) 7.70–7.64 (m, 4H), 7.59 (s, 1H), 7.52 (dt, J = 7.4, 1.6 Hz, 1H), 7.44 (t, J = 7.6 Hz,
1H), 7.41 (d, J = 7.6 Hz, 1H), 4.63 (s, 2H). 13C-NMR (100 MHz, CDCl3)
144.23, 140.49, 138.44, 129.78
δ
δ
(d, J = 32.0 Hz), 129.57, 128.45, 127.63, 127.60, 127.46, 125.91 (q, J = 4.0 Hz), 124.38 (q, J = 270.0 Hz), 46.15.
1
3-(chloromethyl)-30-methyl-1,10-biphenyl (4d): Colorless oil (60.4 mg, 93%). H-NMR (400 MHz, CDCl3)
δ
7.59 (s, 1H), 7.52 (d, J = 7.6 Hz, 1H), 7.40 (q, J = 7.6 Hz, 3H), 7.33 (dd, J = 13.6, 5.6 Hz, 2H),
7.17 (d, J = 7.2 Hz, 1H), 4.63 (s, 2H), 2.41 (s, 3H). 13C-NMR (100 MHz, CDCl3)
δ
142.06, 140.70, 138.55,
138.02, 129.24, 128.85, 128.42, 128.08, 127.55, 127.44, 127.36, 124.40, 46.43, 1.66. GC-MS (m/z): 217.
1
3-chloro-30-(chloromethyl)-1,10-biphenyl (4e): Colorless oil (65.4 mg, 92%). H-NMR (400 MHz, CDCl3)
δ
7.55 (d, J = 4.0 Hz, 2H), 7.49 (d, J = 7.2 Hz, 1H), 7.44 (d, J = 7.2 Hz, 1H), 7.41 (d, J = 7.6 Hz, 1H), 7.39–7.34
(m, 2H), 7.33–7.31 (m, 1H), 4.62 (s, 2H). 13C-NMR (100 MHz, CDCl3)
δ
142.56, 140.55, 138.32, 134.87,
130.20, 129.48, 128.14, 127.71, 127.50, 127.45, 127.31, 125.47, 46.23. HRMS (EI): m/z calcd for C13H10Cl2
[M]: 236.0172, found [M]: 236.0160.
30-(chloromethyl)-2-methyl-1,10-biphenyl (4f) [32]: Colorless oil (56.6 mg, 87%). 1H-NMR (400 MHz,
CDCl3)
δ 7.36 (dd, J = 12.4, 7.2 Hz, 3H), 7.27 (d, J = 9.6 Hz, 3H), 7.22 (t, J = 5.4 Hz, 2H), 4.61 (s, 2H),
2.26 (s, 3H). 13C-NMR (100 MHz, CDCl3)
128.60, 127.61, 127.07, 125.95, 46.38, 20.56.
δ
142.59, 141.37, 137.43, 135.41, 130.50, 129.84, 129.54, 129.36,
1
3-(3-(chloromethyl)phenyl)thiophene (4g) [32]: Colorless oil (59.5 mg, 95%). H-NMR (400 MHz, CDCl3)
δ
7.61 (s, 1H), 7.55 (dt, J = 7.6, 1.6 Hz, 1H), 7.47 (dd, J = 2.4, 2.0 Hz, 2H), 7.43–7.34 (m, 4H), 7.31 (d, J = 8.0 Hz,
1H), 4.62 (s, 2H). 13C-NMR (100 MHz, CDCl3)
126.52, 126.39, 120.86, 46.35.
δ
141.83, 138.13, 136.52, 129.35, 127.38, 126.79, 126.61,
1
2-(3-(chloromethyl)phenyl)naphthalene (4h): Yellow oil (55.3 mg, 73%). H-NMR (400 MHz, CDCl3)
δ 8.02
(s, 1H), 7.89 (t, J = 7.2 Hz, 2H), 7.85 (d, J = 7.2 Hz, 1H), 7.71 (d, J = 6.4 Hz, 2H), 7.65 (d, J = 7.6 Hz, 1H),
7.52–7.46 (m, 2H), 7.44 (d, J = 7.6 Hz, 1H), 7.38 (d, J = 7.6 Hz, 1H), 4.66 (s, 2H). 13C-NMR (100 MHz,

Molecules 2018, 23, 433
9 of 12
CDCl3)
δ 141.86, 138.22, 138.03, 133.76, 132.86, 129.43, 128.66, 128.35, 127.79, 127.64, 126.53, 126.24,
126.07, 125.58, 46.44. HRMS (EI): m/z calcd for C17H10Cl [M]: 252.0723, found [M]: 252.0706.
0
2-(chloromethyl)-1,1 -biphenyl (5a) [38]: Yellow oil (58.9 mg, 97%). 1H-NMR (400 MHz, CDCl3)
δ 7.55–7.51
(m, 1H), 7.44 (d, J = 8.8 Hz, 1H), 7.42–7.33 (m, 6H), 7.27 (d, J = 9.2 Hz, 1H), 4.52 (s, 2H). 13C-NMR
(100 MHz, CDCl3) δ 142.21, 140.31, 135.05, 130.64, 130.46, 129.28, 128.64, 128.44, 128.07, 127.59, 44.60.
0
0
1
2-(chloromethyl)-4 -methyl-1,1 -biphenyl (5b) [39]: Yellow oil (61.7 mg, 95%). H-NMR (400 MHz, CDCl3)
δ
7.55–7.50 (m, 1H), 7.38–7.33 (m, 2H), 7.31 (d, J = 8.2 Hz, 2H), 7.28–7.22 (m, 3H), 4.53 (s, 2H), 2.41 (s, 3H).
13C-NMR (100 MHz, CDCl3)
δ 142.19, 137.38, 137.29, 135.08, 130.61, 130.50, 129.15, 129.13, 128.61,
127.86, 44.68, 21.33.
2-(chloromethyl)-40-(trifluoromethyl)-1,10-biphenyl (5c) [39]: Colorless oil (72.3 mg, 89%). 1H-NMR
(400 MHz, CDCl3) 7.71 (d, J = 8.4 Hz, 2H), 7.56 (d, J = 7.6 Hz, 3H), 7.46–7.38 (m, 2H), 7.27 (d, J = 10.0 Hz,
1H), 4.48 (s, 2H). 13C-NMR (100 MHz, CDCl3)
143.98, 140.80, 135.04, 130.92, 130.28, 129.89 (dt, J = 95.0,
30 Hz), 129.68, 128.91, 128.79, 125.43 (q, J = 4.0 Hz), 124.34 (q, J = 270.0 Hz), 44.25.
δ
δ
0
0
1
2-(chloromethyl)-3 -methyl-1,1 -biphenyl (5d) [39]: Yellow oil (59.8 mg, 92%). H-NMR (400 MHz, CDCl3)
7.56–7.51 (m, 1H), 7.38–7.34 (m, 2H), 7.31 (d, J = 7.2 Hz, 1H), 7.29–7.25 (m, 1H), 7.21 (d, J = 6.8 Hz, 5H),
δ
4.53 (s, 2H), 2.41 (s, 3H). 13C-NMR (100 MHz, CDCl3)
δ
142.32, 140.25, 138.06, 135.03, 130.58, 130.40,
130.03, 128.56, 128.31, 128.29, 127.95, 126.33, 44.64, 21.62.
1
30-chloro-2-(chloromethyl)-1,10-biphenyl (5e) [39]: Yellow oil (62.3 mg, 88%). H-NMR (400 MHz, CDCl3)
δ
7.53 (dd, J = 7.6, 2.0 Hz, 1H), 7.40 (d, J = 1.2 Hz, 1H), 7.38 (dd, J = 4.8, 1.6 Hz, 1H), 7.37–7.32 (m, 3H),
7.32–7.29 (m, 1H), 7.25–7.22 (m, 1H), 4.49 (s, 2H). 13C-NMR (100 MHz, CDCl3)
δ 142.04, 140.74, 135.02,
134.33, 130.76, 130.29, 129.67, 129.37, 128.78, 128.55, 127.79, 127.49, 44.31.
2-(chloromethyl)-20-methyl-1,10-biphenyl (5f) [40]: Colorless oil (56.5 mg, 87%). 1H-NMR (400 MHz,
CDCl3)
δ 7.55 (d, J = 6.8 Hz, 1H), 7.42–7.30 (m, 3H), 7.30–7.20 (m, 3H), 7.20–7.11 (m, 2H), 4.43–4.26
(m, 2H), 2.07 (s, 3H). 13C-NMR (100 MHz, CDCl3)
128.41, 128.01, 127.92, 125.64, 44.26, 20.30.
δ
141.57, 139.60, 136.16, 135.41, 130.17, 130.09, 129.69,
1
3-(2-(chloromethyl)phenyl)thiophene (5g) [41]: Colorless oil (59.4 mg, 95%). H-NMR (400 MHz, CDCl3)
δ
7.51 (dd, J = 7.2 3.6 Hz, 1H), 7.42 (dd, J = 2.8, 1.2 Hz, 1H), 7.39 (dd, J = 5.2, 3.2 Hz, 1H), 7.35 (d, J = 3.2 Hz,
3H), 7.26–7.22 (m, 1H), 4.58 (s, 2H). 13C-NMR (100 MHz, CDCl3)
128.98, 128.80, 128.08, 125.76, 123.44, 44.95.
δ
140.44, 136.90, 135.18, 130.92, 130.41,
1
2-(2-(chloromethyl)phenyl)naphthalene (5h) [42]: Yellow oil (60.6 mg, 80%). H-NMR (400 MHz, CDCl3)
δ
7.90–7.83 (m, 4H), 7.57–7.51 (m, 2H), 7.51–7.46 (m, 2H), 7.38 (dd, J = 2.8, 2.0 Hz, 1H), 7.37–7.33 (m, 2H),
4.54 (s, 2H). 13C-NMR (100 MHz, CDCl3)
128.16, 128.04, 127.84, 127.49, 126.54
δ 142.13, 137.76, 135.26, 133.28, 130.72, 130.66, 128.68, 128.29,
4-benzyl-40-methyl-1,10-biphenyl (6a) [43]: Yellow oil (60.4 mg, 78%). 1H-NMR (400 MHz, CDCl3)
δ
7.51 (d, J = 2.0 Hz, 1H), 7.48 (dd, J = 3.6, 2.0 Hz, 2H), 7.45 (d, J = 2.0 Hz, 1H), 7.30 (t, J = 6.4 Hz, 2H),
7.26–7.20 (m, 7H), 4.01 (s, 2H), 2.38 (s, 3H). 13C-NMR (100 MHz, CDCl3)
136.96, 129.59, 129.42, 129.11, 128.65, 127.16, 126.98, 126.26, 41.73, 21.24.
δ
141.20, 140.07, 139.11, 138.26,
1
4-(4-methoxybenzyl)-40-methyl-1,10-biphenyl (6b) [44]: Yellow oil (83.1 mg, 96%). H-NMR (400 MHz,
CDCl3)
7.12 (s, 1H), 6.85 (s, 1H), 6.83 (s, 1H), 3.95 (s, 2H), 3.77 (s, 3H), 2.37 (s, 3H). 13C-NMR (100 MHz, CDCl3)
158.14, 140.54, 139.02, 138.29, 136.93, 133.32, 130.03, 129.57, 129.28, 127.13, 126.97, 114.06, 55.41,
δ 7.49 (s, 1H), 7.47 (d, J = 2.0 Hz, 2H), 7.45 (s, 1H), 7.23 (s, 2H), 7.21 (s, 2H), 7.14 (s, 1H),
δ
40.82, 21.23.
4-(4-fluorobenzyl)-40-methyl-1,10-biphenyl (6c): Yellow oil (73.7 mg, 89%).1H-NMR (400 MHz, CDCl3)
δ
7.50 (d, J = 8.0 Hz, 2H), 7.46 (d, J = 8.0 Hz, 2H), 7.24–7.20 (m, 4H), 7.17 (dd, J = 8.8, 5.6 Hz, 2H),
6.98 (t, J = 8.8 Hz, 2H), 3.97 (s, 2H), 2.38 (s, 3H). 13C-NMR (100 MHz, CDCl3)
δ
161.59 (d, J = 243.9 Hz),

Molecules 2018, 23, 433
10 of 12
139.86 (d, J = 1.4 Hz), 139.26, 138.16, 137.04, 136.85 (d, J = 3.3 Hz), 130.45 (d, J = 7.8 Hz), 129.60, 129.31,
127.22, 126.98, 115.40 (d, J = 21.2 Hz), 40.86, 21.24. HRMS (ESI) m/z calcd for C20H19FK+ (M + K)+
315.09459, found 315.09357.
0
0
1
3-((4 -methyl-[1,1 -biphenyl]-4-yl)methyl)thiophene (6d): Colorless oil (45.2 mg, 57%). H-NMR (400 MHz,
CDCl3) 7.50 (d, J = 8.4 Hz, 2H), 7.47 (d, J = 8.0 Hz, 2H), 7.26 (t, J = 2.4 Hz, 2H), 7.23 (d, J = 8.0 Hz, 3H),
6.95 (dd, J = 4.8, 2.8 Hz, 2H), 4.01 (s, 2H), 2.38 (s, 3H). 13C-NMR (100 MHz, CDCl3)
139.53, 139.20,
δ
δ
136.99, 129.59, 129.24, 128.61, 127.17, 126.98, 125.81, 121.44, 36.30, 21.24. HRMS (ESI) m/z calcd for
C18H17S+ (M + H)+ 265.10455, found 265.10495.
4-(bromomethyl)-40-methyl-1,10-biphenyl (7a) [45]: White solid (32.6 mg, 42%). 1H-NMR (400 MHz,
CDCl3)
δ 7.55 (d, J = 8.4 Hz, 2H), 7.48 (d, J = 8.0 Hz, 2H), 7.45 (d, J = 8.4 Hz, 2H), 7.25 (d, J = 6.4Hz, 2H),
4.55 (s, 2H), 2.40 (s, 3H). 13C-NMR (100 MHz, CDCl3)
127.48, 127.08, 33.63, 21.27.
δ 141.48, 137.69,137.56, 137.58, 129.70, 129.61,
0
0
◦
1
4-methyl-4 -(4-methylbenzyl)-1,1 -biphenyl (7b) [46]: White solid, MP: 77–78 C (20.4 mg, 25%). H-NMR
(400 MHz, CDCl3) δ 7.51–7.44 (m, 4H), 7.23 (dd, J = 8.0 3.6 Hz, 4H), 7.11 (s, 4H), 3.97 (s, 2H), 2.38 (s, 3H),
2.32 (s, 3H). 13C-NMR (100 MHz, CDCl3)
128.97, 127.13, 126.98, 41.30, 21.23, 21.17.
δ 140.38, 139.02, 138.31, 138.16, 136.92, 135.74, 129.57, 129.34,
0
4-methyl-1,1 -biphenyl (7c) [25]: White solid (46.8 mg, 92%). 1H-NMR (400 MHz, CDCl3)
δ 7.57 (dd, J = 8.4,
1.6 Hz, 2H), 7.48 (d, J = 8.4 Hz, 2H), 7.41 (t, J = 7.6 Hz, 2H), 7.31 (t, J = 7.6 Hz, 1H), 7.24 (d, J = 8.0 Hz,
3H), 2.38 (s, 3H).
4. Conclusions
In conclusion, an efficient method for the selective Suzuki–Miyaura coupling of o-(or m-,
or p-)chloromethyl bromobenzene with arylboronic acids was described. This Pd-catalyzed highly
selective coupling reaction of the C(sp2)–Br bond was achieved by using PCy3
HBF4 as the ligand
·
and Cs2CO3 as the base in a mixture of toluene/water (10:1). A series of chloromethyl-1,10-biphenyl
compounds were obtained in moderate-to-excellent yields. Importantly, the catalytic system exhibited
a wide substrate scope and good functional group tolerance. Moreover, this protocol was extended to
the one-pot dual arylation of 1-bromo-4-(chloromethyl)benzene, affording numerous unsymmetrical
methylene-linked biaryl derivatives.
Supplementary Materials: Supplementary materials are available online. Figures S2–S46: 1H-, 13C-NMR,
and HRMS of products.
Acknowledgments: We gratefully acknowledge financial support of this work by the National Natural
Science Foundation of China (No. 21563025), the Program for Changjiang Scholars and Innovative Research
Team in University (No. IRT_15R46), and the Yangtze River scholar research project of Shihezi University
(No. CJXZ201601).
Author Contributions: P.L. and X.-w.M. conceived and designed the experiments; M.-m.P. performed the
experiments; B.D. and X.-m.L. contributed reagents/materials/analysis tools; Y.L. wrote the paper.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Miyaura, N.; Suzuki, A. Palladium-Catalyzed Cross-Coupling Reactions of Organoboron Compounds.
Chem. Rev. 1995, 95, 2457–2483. [CrossRef]
2.
Suzuki, A. Recent advances in the cross-coupling reactions of organoboron derivatives with organic
electrophiles, 1995–1998. J. Organomet. Chem. 1999, 576, 147–168. [CrossRef]
3.
4.
5.
Suzuki, A. Cross-coupling reactions via organoboranes. J. Organomet. Chem. 2002, 653, 83–90. [CrossRef]
Diedreich, F.; Stang, P.J. Metal-Catalyzed Cross-Coupling Reactions; Wiley-VCH: New York, NY, USA, 1998.
Chowdhury, S.; Georghiou, P. Palladium catalyzed cross-coupling between phenyl- or naphthylboronic acids
and benzylic bromides. Tetrahedron Lett. 1999, 40, 7599–7603. [CrossRef]

Molecules 2018, 23, 433
11 of 12
6.
7.
8.
9.
Oh, C.H.; Lim, Y.M. Double suzuki reactions of organoboronic acids with 1,n-dibromides. Bull. Korean
Chem. Soc. 2002, 23, 663–664. [CrossRef]
Lu, T.-Y.; Xue, C.; Luo, F.-T. Palladium-Catalyzed Cross-Coupling Reaction of Aryldioxaborolane with
2-Bromo-N,N-dimethylacetamide. Tetrahedron Lett. 2003, 44, 1587–1590. [CrossRef]
Liu, X.; Deng, M. Remarkable Co-Catalysis by Copper(I) Oxide in the Palladium Catalyzed Cross-Coupling
of Arylboronic Acids with Ethyl Bromoacetate. Chem. Commun. 2002, 33, 622–623. [CrossRef]
Gooßen, L. Palladium-Catalyzed Synthesis of Aryl Ketones from Boronic Acids and Carboxylic Acids or
Anhydrides. Chem. Commun. 2001, 669–670. [CrossRef]
10. Netherton, M.R.; Dai, C.; Neuschütz, K.; Fu, G.C. Room-Temperature Alkyl
−
Alkyl Suzuki Cross-Coupling
of Alkyl Bromides that Possess Hydrogens. J. Am. Chem. Soc. 2001, 123, 10099–10100. [CrossRef] [PubMed]
β
11. Langle, S.; Abarbri, M.; Duchêne, A. Selective double Suzuki cross-coupling reactions. Synthesis of
unsymmetrical diaryl (or heteroaryl) methanes. Tetrahedron Lett. 2003, 44, 9255–9258. [CrossRef]
12. Anselmi, E.; Abarbri, M.; Duchêne, A.; Langle-Lamandé, S.; Thibonnet, J. Efficient synthesis of substituted
styrenes and biaryls (or heteroaryls) with regioselective reactions of ortho-, meta-, and para-bromobenzyl
bromide. Synthesis 2012, 44, 2023–2040. [CrossRef]
13. Henry, N.; Enguehard-Gueiffier, C.; Thery, I. One-Pot Dual Substitutions of Bromobenzyl Chloride,
2-Chloromethyl-6-halogenoimidazo[1,2-a]pyridine and -[1,2-b]pyridazine by Suzuki–Miyaura Cross-Coupling
Reactions. Eur. J. Org. Chem. 2008, 2008, 4824–4827. [CrossRef]
14. Mahamo, T.; Mogorosi, M.M.; Moss, J.R.; Mapolie, S.F.; Slootweg, J.C.; Lammertsma, K.; Smith, G.S.
Neutral palladium (II) complexes with P,N Schiff-base ligands: Synthesis, characterization and application
as Suzuki–Miyaura coupling catalysts. J. Organomet. Chem. 2012, 703, 34–42. [CrossRef]
˙
15. Gurbuz, N.; Özdemir, I.; Cetinkaya, B.; Seckin, T. Silica-supported 3-4,5-dihydroimidazol-1-yl-
propyltriethoxysilanedichloropalladium(II) complex: Heck and Suzuki cross-coupling reactions.
Appl. Organomet. Chem. 2003, 17, 776–780. [CrossRef]
16. Heijnen, D.; Tosi, F.; Vila, C.; Stuart, M.C.; Elsinga, P.H.; Szymanski, W.; Feringa, B.L. Oxygen Activated,
Palladium Nanoparticle Catalyzed, Ultrafast Cross-Coupling of Organolithium Reagents. Angew. Chem. Int. Ed.
2017, 129, 3402–3407. [CrossRef]
17. Gürbüz, N.; Özdemir, I.; Demir, S.; Çetinkaya, B. Improved palladium-catalyzed coupling reactions of aryl
halides using saturated N-heterocarbene ligands. J. Mol. Catal. A Chem. 2004, 209, 23–28. [CrossRef]
18. Mollar, C.; Besora, M.; Maseras, F.; Asensio, G.; Medio-Simón, M. Competitive and Selective Csp3-Br versus
Csp2-Br Bond Activation in Palladium-Catalysed Suzuki Cross-Coupling: An Experimental and Theoretical
Study of the Role of Phosphine Ligands. Chem. Eur. J. 2010, 16, 13390–13397. [CrossRef] [PubMed]
19. Liu, Y.; Gu, N.; Liu, P.; Ma, X.; Liu, Y.; Xie, J.; Dai, B. Water-soluble salen–Pd complex as an efficient catalyst
for Suzuki–Miyaura reaction of sterically hindered substrates in pure water. Tetrahedron 2015, 71, 7985–7989.
[CrossRef]
20. Ma, X.; Liu, Y.; Liu, P.; Xie, J.; Dai, B.; Liu, Z. Palladium-catalyzed direct arylation of polyfluoroarene and
facile synthesis of liquid crystal compounds. Appl. Organomet. Chem. 2014, 28, 180–185. [CrossRef]
21. Liu, Y.; Ma, X.; Xie, J.; Liu, P.; Dai, B.; He, R. Metallomicelles of palladium(II) complexes as efficient catalysts
for the Suzuki–Miyaura reaction in neat water. Appl. Organomet. Chem. 2013, 27, 494–498. [CrossRef]
22. Ma, X.; Liu, Y.; Liu, P.; Xie, J.; Dai, B.; Liu, Z. A rapid and efficient catalysis system for the synthesis of
4-vinylbiphenyl derivatives. Appl. Organomet. Chem. 2013, 27, 707–710. [CrossRef]
23. Liu, P.; Yan, M.; He, R. Bis(imino) pyridine palladium(II) complexes as efficient catalysts for the
Suzuki–Miyaura reaction in water. Appl. Organomet. Chem. 2010, 24, 131–134. [CrossRef]
24. Liu, P.; Zhang, W.Z.; He, R. Preparation and catalytic properties of bis(imino) pyridine palladium(II)
complexes as efficient catalysts for Suzuki cross-coupling reaction in water. Appl. Organomet. Chem.
2009, 23, 135–139. [CrossRef]
25. Liu, P.; Zhou, L.; Li, X.G.; He, R. Bis(imino) pyridine palladium(II) complexes: Synthesis, structure and
catalytic activity. J. Organomet. Chem. 2009, 694, 2290–2294. [CrossRef]
26. Barclay, L.R.C.; Sonawane, H.R.; Hudson, J.C. Sterically Hindered Aromatic Compounds. IV. Solvolysis
of t-Butyl-, Phenyl-, and Trialkyl-benzyl Chlorides in Ethanol–Water. Evidence for Steric Acceleration in
2,4,6-Tri-t-butylbenzyl Chloride. Can. J. Chem. 1972, 50, 2318–2325. [CrossRef]
27. Han, L.; Xia, J.B.; You, L.; Chen, C. Ketone-catalyzed photochemical C(sp3)–H chlorination. Tetrahedron
2017, 73, 3696–3701. [CrossRef] [PubMed]

Molecules 2018, 23, 433
12 of 12
28. Burawoy, A.; Spinner, E. Electronic spectra of organic molecules and their interpretation. Part I. Effect
of terminal methyl and substituted methyl groups of conjugated systems on K-bands. J. Chem. Soc.
1955, 2557–2563. [CrossRef]
29. Kauhanka, M.M.; Kauhanka, U.M. Synthesis and properties of some mesogenic benzyl chlorides. Vestsi Nats.
Akad. Navuk Belarusi Ser. Khim. Navuk 2010, 64–67.
30. Filzen, G.F.; Trivedi, B.K.; Geyer, A.G.; Unangst, P.C.; Bratton, L.D. Compounds that Modulate PPAR Activity
and Methods for Their Preparation. WO Patent Application No. 2003084916A2, 24 December 2003.
31. Bartel, S.; Hahn, M.; Moradi, W.A.; Becker, E.; Roelle, T.; Stasch, J.; Schlemmer, K.; Wunder, F.; Knorr, A.
Dicarboxylic Acid Derivatives and Their Use. WO Patent Application No. 2007045433 A1, 26 April 2007.
32. Li, Z.; Liu, C.X.; Xu, X.; Qiu, Q.; Su, X.; Dai, Y.; Yang, J.; Li, H.; Shi, W.; Liao, C.; et al. Discovery of
phenylsulfonyl acetic acid derivatives with improved efficacy and safety as potent free fatty acid receptor
1 agonists for the treatment of type 2 diabetes. Eur. J. Med. Chem. 2017, 138, 458–479. [CrossRef] [PubMed]
33. Kang, H.; Hwang, H.S.; Chin, J. Use of the Fetal Reprogramming of a PPAR
Application No. 2012030165A2, 5 July 2012.
δ Agonistwo. WO Patent
34. Leivers, M.R.; Roberts, C.D.; Liehr, S.J.R.; Chan, S.A.; Rai, R.; Lauchli, R.; Pham, S.M.; Rajwanshi, V.K.;
Ton, T.L. Derivatives of Imidazo [4,5-d] Pyridazine and Their Use as Anti-Viral Compounds. WO Patent
Application No. 2009111501 A1, 9 November 2009.
35. Sabatucci, J.P.; Caufield, C.E.; Greenfield, A.A.; Antane, S. Substituted Naphthylenes for the Treatment of
Non-Insulin Dependent Diabetes Mellitus. U.S. Patent Application No. 20130216442 A1, 11 September 2009.
36. Boettcher, H.; Devant, R.; Greiner, H.; Bartoszyk, G.; Berthelon, J.J.; Noblet, M.; Zeiller, J.J. Preparation of
arylamines as central nervous system agents. EP Patent Application No. 707007 A1, 17 April 1996.
37. Houze, J.; Liu, J.; Ma, Z.H.; Medina, J.C.; Schmitt, M.J.; Sharma, R.; Sun, Y.; Wang, Y.C. Compounds,
Pharmaceutical Compositions and Methods for Their Use in Treating Metabolic Disorders. U.S. Patent
Application No. 7465804 B2, 16 December 2008.
38. Standley, E.A.; Jamison, T.F. Simplifying Nickel(0) Catalysis: An Air-Stable Nickel Precatalyst for the
Internally Selective Benzylation of Terminal Alkenes. J. Am. Chem. Soc. 2013, 135, 1585–1592. [CrossRef]
[PubMed]
39. Hwang, S.J.; Kim, H.J.; Chang, S. Highly Efficient and Versatile Synthesis of Polyarylfluorenes via
Pd-Catalyzed C−H Bond Activation. Org. Lett. 2009, 20, 4588–4591. [CrossRef] [PubMed]
40. Engelhardt, L.M.; Leung, W.P.; Raston, C.L.; Twiss, P.; White, A.H. Axially asymmetric metal alkyls. Part 1.
0
Lithium alkyls of 2,2 -dimethylbiphenyl and its trimethylsilylmethylated compounds: crystal structures of
[{Li(Me2NCH2CH2NMe2)}2{(2-CHRC6H4)2}] for R = H (polymeric) and R = SiMe3(monomeric). J. Chem.
Soc. Dalton Trans. 1984, 321–329.
41. Suga, A.; Kazuta, K.; Morihira, K.; Matsuda, K.; Kakuta, H.; Moritani, H.; Iizumi, Y. Novel Benzylamine
Derivative. WO Patent Application No. 19959518121 A1, 6 July 1995.
42. Biediger, R.J.; Bui, H.; Henry, K.M.; Thrash, T. Modulators of c3a Receptor and Methods of Use Thereof.
WO Patent Application No. 2008079371 A1, 3 July 2008.
43. Tao, J.L.; Wang, Z.X. Pincer-Nickel-Catalyzed Cross-Coupling of Aryl Sulfamates with Arylzinc Chlorides.
Eur. J. Org. Chem. 2015, 29, 6534–6540. [CrossRef]
44. Rao, M.L.N.; Dhanorkar, R.J. Pd-catalyzed chemoselective threefold cross-coupling of triarylbismuths with
benzylic bromides. RSC Adv. 2013, 3, 6794–6798. [CrossRef]
45. Futamura, S.; Zong, Z.M. Photobromination of side-chain methyl groups on arenes with
N-bromosuccinimide–convenient and selective syntheses of bis(bromomethyl)- and (bromomethyl)
methylarenes. Bull. Chem. Soc. Jpn. 1992, 65, 345–348. [CrossRef]
46. Zhang, Y.; Feng, M.T.; Lu, J.M. N-Heterocyclic carbene–palladium(II)–1-methylimidazole complex catalyzed
Suzuki–Miyaura coupling of benzylic chlorides with arylboronic acids or potassium phenyltrifluoroborate
in neat water. Org. Biomol. Chem. 2013, 11, 2266–2272. [CrossRef] [PubMed]
Sample Availability: Samples of the compounds are not available from the authors.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
