Pharmaceutical composition of valsartan: β-Cyclodextrin: Physico-chemical characterization and anti-hypertensive evaluation

Article abstract of DOI:10.3390/molecules15064067

Valsartan, a water-insoluble drug, is mainly used in the treatment of hypertension albeit with reduced oral bioavailability. The aim of work was to develop a valsartan:β-cyclodextrin (VAL:β-CD) pharmaceutical composition in order to improve its water solubility and bioavailability. The VAL:β-CD complexes were prepared by the kneading, solid dispersion and freeze-drying methods, of which the freeze-drying method (FDY) was found to be the best to prepare an inclusion complex. A physical mixtyure PM was also prepared. Complexes were characterized by thermal analysis, Fourier transformed-infrared (FTIR) spectroscopy, Powder X-ray diffractometry, intrinsic dissolution and NMR (2D-ROESY). Phase-solubility analysis showed AL-type diagrams with β-cyclodextrin (β-CD). Microcalorimetric titrations suggested the formation of 1:1 inclusion complex between VAL and β-CD. The apparent stability constants K1:1 calculated from phase-solubility plots were 165.4 M^-1 (298 K), 145.0 M^-1 (303 K) and 111.3 M ^-1 (310 K). In vivo experiments in rats showed that reduction in arterial pressure for the FDY complex is better than with valsartan used alone. The better activity of FDY can be attributed to the higher solubility of valsartan after inclusion in the cyclodextrin cavity, as suggest by the intrinsic dissolution studies.

Full text of DOI:10.3390/molecules15064067

Molecules 2010, 15, 4067-4084; doi:10.3390/molecules15064067
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Pharmaceutical Composition of Valsartan: β-Cyclodextrin:
Physico–Chemical Characterization and Anti-Hypertensive
Evaluation
Carlos Eduardo de Matos Jensen 1,3, Robson Augusto Souza dos Santos 2, Angelo Márcio Leite
Denadai 1, Cynthia Fernandes Ferreira Santos 2, Aline Nardoni Gonçalves Braga 2 and Rubén
Dario Sinisterra 1,*
1
Departamento de Química, ICEx, Universidade Federal de Minas Gerais, Avenida Pres. Antônio
Carlos 6627, 31270-901, Belo Horizonte, Brazil; E-Mail: cej.jensen@gmail.com (C.E.M.J.)
2
Departamento de Fisiologia e Biofísica, ICB, Universidade Federal de Minas Gerais, 31270-901
Belo Horizonte, Brazil; E-Mails: robsonsant@gmail.com (R.A.S.);
cynthiaff.santos@gmail.com.br (C.F.F.S.); losartan04@yahoo.com.br (A.N.G.B)
3
Campus Centro Oeste Dona Lindu, Universidade Federal de São João del Rei, R. Sebastião
Gonçalves Coelho, 400, 35501-296, Divinópolis, Brazil
* Author to whom correspondence should be addressed; E-Mail: sinisterra@ufmg.br;
Tel.: +55 31 3409 5778; Fax: +55 31 3409 5700.
Received: 17 May 2010 / Accepted: 27 May 2010 / Published: 4 June 2010
Abstract: Valsartan, a water-insoluble drug, is mainly used in the treatment of
hypertension albeit with reduced oral bioavailability. The aim of work was to develop a
valsartan:β-cyclodextrin (VAL:β-CD) pharmaceutical composition in order to improve its
water solubility and bioavailability. The VAL:β-CD complexes were prepared by the
kneading, solid dispersion and freeze-drying methods, of which the freeze-drying method
(FDY) was found to be the best to prepare an inclusion complex. A physical mixtyure PM
was also prepared. Complexes were characterized by thermal analysis, Fourier
transformed- infrared (FTIR) spectroscopy, Powder X-ray diffractometry, intrinsic
dissolution and NMR (2D-ROESY). Phase-solubility analysis showed AL-type diagrams
with β-cyclodextrin (β-CD). Microcalorimetric titrations suggested the formation of 1:1
inclusion complex between VAL and β-CD. The apparent stability constants K1:1
calculated from phase-solubility plots were 165.4 M-1 (298 K), 145.0 M-1 (303 K) and
111.3 M-1 (310 K). In vivo experiments in rats showed that reduction in arterial pressure for

Molecules 2010, 15
the FDY complex is better than with valsartan used alone. The better activity of FDY can
4068
be attributed to the higher solubility of valsartan after inclusion in the cyclodextrin cavity,
as suggest by the intrinsic dissolution studies.
Keywords: valsartan; β-cyclodextrin; intrinsic dissolution; ROESY; anti-hypertensive evaluation
1. Introduction
Hypertension is one of the most prevalent chronic adult illnesses today and cannot be cured, but it
can be controlled. The pharmacological treatment for control of hypertension utilizes various drug
therapies, single doses or associations of diuretics, beta-blockers, calcium channel blockers,
angiotensin converting enzyme (ACE) inhibitors and angiotensin II receptor (AT1) antagonist (ARA)
[1,2]. Valsartan (VAL, Figure 1) is one of the angiotensin II receptor (AT1) antagonists recommended
for treatment of hypertension, post-myocardial infarction or congestive heart failure. VAL is
administered at a dose of 80 mg or 160 mg per day. Other drugs in the same group include losartan,
irbesartan, olmesartan and candesartan [3,4].
ARAs have different chemical structures derived from imidazole-5-acetic acid with a common
tetrazole-biphenyl structure. The differences between ARAs are related to structural features that lead
to changes of their acid dissociation constants (pKa), partition coefficients (LogP), as well as
absorption and bioavailability. After oral administration, only 25% of VAL (Figure 1) is absorbed,
food intake being one of the possible causes for the low bioavailability [5]. Other drugs from the ARA
group have bioavailabilities ranging between 33% (losartan) and 60–80% (irbesartan) [6,7]. The low
bioavailability of VAL is associated with its poor water solubility. Despite the reduced water solubility
VAL is freely soluble in alkaline solution as the corresponding salt.
According to the Biopharmaceutics Classification System (BCS) aqueous solubility and
permeability are the most important variables affecting drug bioavailability. VAL, along with
telmisartan, irbesartan and candesartan, is classified as Class II, that is drugs that have low solubility
and high permeability characteristics after oral administration. Losartan is included in Class III, where
the drugs have high solubility and low permeability [8]. The use of cyclodextrins is one of the
pharmaceutical strategies available to circumvent these drawbacks, as they can be used as complexing
agents to increase the aqueous solubility of hydrophobic drugs and to increase their bioavailability and
stability [9–12].
Figure 1. VAL or 3-methyl-2-[pentanoyl-[[4-[2-(2H-tetrazol-5-yl)phenyl]phenyl]methyl]-
amino] -butanoic acid [CAS number: 137862-53-4].

Molecules 2010, 15
4069
Cyclodextrins (CDs) are cyclic oligosaccharides consisting of (α-1,4)-linked α-D-glucopyranose
units that contain a lipophilic internal cavity and a hydrophilic outer surface resembling the shape of a
truncated cone. The hydroxyl functions of the glucose are orientated to the exterior of the cone, where
primary hydroxyl groups are in the narrow edge of the cone and the secondary hydroxyl groups at the
wider edge. The inner cavity is lined by skeletal carbons and ethereal oxygens of the sugar residues,
which gives it a lipophilic character. These characteristics allow CDs to form inclusion complexes with
a variety of host-guest molecules of suitable polarity and size. Their use has been extensively exploited
to improve the pharmaceutical properties of numerous drugs such as water solubility, stability,
physicochemical incompatibilities, oral absorption and controlled release in order to modulate
biological activity [9,11,13–15].
The main objective of the present work was to use the host:guest strategy to obtain a more efficient
VAL pharmaceutical employing cyclodextrins. The interaction between the VAL:β-CD binary systems
was studied in solution using the phase solubility method. VAL:β-CD solid systems in equimolar ratio
were prepared through physical mixing, and the solid dispersion, kneading and freeze-drying methods.
All the adducts were characterized by Thermal Analysis (TG/DTG and DSC), Fourier Transform
Infrared Analysis (FTIR), ROESY-NMR spectroscopy and intrinsic dissolution experiments. In vivo
experiments in rats were performed to evaluate the anti-hypertensive properties of the resulting
VAL:β-CD complexes.
2. Results and Discussion
The phase solubility diagrams obtained in the study with β-CD and VAL are depicted in Figure 2.
Analyzing the phase solubility profiles it is possible to observe the increase of VAL solubility in the
system due to molecular interaction with β-CD. VAL formed soluble complexes with β-CD in water
showing a typical AL-type solubility diagrams [16] where the inclusion stability constant (Kc),
calculated according to Equation (1) and summarized in Table 1, indicate a decrease of Kc when the
temperature increase, as expected for an exothermic process.
Figure 2. Phase solubility diagram of VAL:β-CD inclusion complex at 298, 303 and 310 K.

Molecules 2010, 15
4070
Similar temperature effects on the stability constants were found by Brunella, et al. and Karathanos
et al. [9,12,17,18]. The Kc values indicate a moderate host:guest affinity by VAL due to the hight
molecular weight and lower water solubility, which hindered the insertion of molecule inside the β-CD
cavity [9,19]. The integrated form of the van’t Hoff equation (1) permits calculation of entropy and
enthalpy changes, from variations of the Kc in different temperatures:
ΔH 0 ΔS0
ln Kc = −
+
(1)
RT
R
The van’t Hoff plot for the VAL:β-CD complex is a linear function between Kc and the inverse of
absolute temperature (1/T), as shown in Figure 3. The thermodynamic parameters ΔH, ΔS and ΔG for
the host:guest compound were calculated and are shown in Table 2. The enthalpy change (∆H) is
-24.90 kJ·mol-1, which is relatively small, indicating that the VAL:β-CD interaction is an exothermic
process and typical of low energy interactions, such as hydrophobic van der Waals interaction due to
the displacement of water molecules from the cavity of the βCD. The change of entropy (ΔS) is
-0.041 J·mol-1·K-1 and can be explained considering that complexation process causes a decrease in
translational and rotational degrees of freedom of the VAL included as compared with the free ones.
The standard Gibbs energy change (∆G) is -12.45 kJ·mol-1, calculated through enthalpy and entropy
changes, shows the spontaneous formation of VAL:β-CD inclusion complex in aqueous solution
[9,12,15,18,20].
Figure 3. van’t Hoff plots (ln K versus 1/T) for VAL:β-CD complexation, determined by
solubility diagram experiments.
Evidence of interactions between VAL and β-CD in the solid state can be obtained using thermal
analysis. When guest molecules are included in CD cavities, their melting, boiling, glass transition and
sublimation points shift to different temperatures or disappear [21].

Molecules 2010, 15
4071
Table 1. Linear regression and Stability constant (Kc) calculated from the system VAL:β-
CD at absolute temperature of 298 K, 303 K and 310 K.
Temperature
298 K
Linear equation
Linearity (R)
0.9960
Stability constant (Kc) ± SD
165.4 M-1 ± 0.16
145.0 M-1 ± 0.08
y = 0.0685x + 0.0004
y = 0.0646x + 0.0005
y = 0.0636x + 0.0006
303 K
0.9947
310 K
0.9960
111.3 M-1 ± 0.02
Table 2. Thermodynamic parameters for complexation of VAL:β-CD.
∆H (kJ·mol-1)
∆S (J·mol-1·K-1)
∆G (kJ·mol-1)
-24.90
-0.041
-12.45
In order to confirm the average stoichiometry of complex in solution, isothermal calorimetric
titrations – ITC – were performed. Microcalorimetric titration allows simultaneous determination of
the enthalpy, equilibrium constant and stoichiometry from a single titration curve, through a least
square non-linear adjusted line derived from the Wiseman isotherm [22], according to the equation (2):
⎡
⎢
⎤
⎥
⎛
⎜
⎝
⎞
⎟
⎠
dQ
1
2
1− XR − r
2 (1+ XR − r)2 − 4XR
o
(2)
= ΔH Vo
+
d[Val]tot
⎢
⎣
⎥
⎦
P
This above equation relates to the stepwise change in heat of the system normalized with respect to
moles of valsartan added per injection (dQ/d[Val]t)P at constant pressure, to the absolute ratio of
ligand to receptor concentration (XR = [Val]t/[β-CD]t) at any point during the course of the titration.
The parameter ΔH is the molar enthalpy of binding, Vo is the initial volume of the β-CD solution
(1.5 mL) in the titration cell and r is composition variable 1/[ β-CD]t.Kc.
Figure 4. Isothermal titration microcalorimetry of VAL - βCD interactions.

Molecules 2010, 15
4072
The experimental data for the titration of valsartan 30 mM in buffer (blank experiment) and
valsartan 30 mM in βCD 1 mM solution, at temperature of 298 K, is shown in Figure 4. The
thermodynamic properties were calculated after subtraction of the blank curve as shown in the figure,
using the “one binding site” model. The non-linear regression showed an equivalence point at a molar
ratio of approximately 1.0. These data and the relative size of the molecules suggest strongly a 1:1
stoichiometry. It was observed that interaction between valsartan and β-CD is principally exothermic.
The enthalpy changes could be attributed to binding of enthalpy-rich water molecules released from
the cyclodextrin cavity with bulk water molecules, in agreement with the literature [23], and/or the
formation of cooperative van der Waals interactions between guest and the cyclodextrin cavity through
the hydrophobic valsartan moiety.
X-ray powder diffraction patterns of VAL, β-CD and the corresponding complexes of VAL with β-
CD are shown in Figure 5. In the X-ray diffractogram of VAL its possible to characterize the powder
as a semi-crystalline product. No diffraction peaks relevant to VAL were detectable in all the systems
with β-CD. Complete drug amorphization was instead observed in SDP and FDY. For KND the
presence of free crystalline β-CD was revealed by peaks at 12.4º and 19.0º 2θ. The diffractogram of the
KND differs much from that of SDP and FDY as well as VAL and β-CD, indicating no complex
formation. In the literature there is described a complex formed by VAL and β-CD as a crystalline
material, with peaks in 12.7, 10.8 and 19.8 2θ [24].
Figure 5. XRD diffractogram of VAL, β-CD and the complexes prepared by the solid
dispersion (SDP), freeze-drying (FDY) and kneading (KND) methods.
The TG/DTG curve results for VAL and β-CD are not shown. Analyzing the TG curve for β-CD,
we can observe a weight loss in the range of 30 ºC to 95 ºC, which corresponds to the loss of eight

Molecules 2010, 15
4073
water molecules present in the β-CD internal cavity. Next, there is a thermal stability period up to
approximately 350 ºC, followed by total mass loss at 700 ºC, indicating complete decomposition of the
β-CD in accordance with the literature [21,24,25]. In regards to the studies of complexes between β-
CD and VAL prepared using the kneading method, solid dispersion, as well as physical mixture, there
was no solid residue generation at the end of analyses. This indicates complete decomposition of the
substances. During the freeze-drying method, there was a solid residue generation corresponding to
7.84% (± 0.093) of the whole sample. This residue is possibly related to potassium oxide as result from
potassium hydroxide use for pH adjustment of the freeze-drying solution.
DSC was another technique employed for the characterization of the complexes. The DSC thermal
profiles for the samples are represented in Figure 6. DSC curve for VAL shows an endothermic peak at
100.5 ºC related to drug melting point. A weak association is show only for physical mixture (PM),
where the melting peak is observed at 100.5 ºC in contrast with the observations for the SDP, FDY and
KND compounds [26]. The absence of a melting peak of VAL in the solid was taken as an indication
that the drug is included in β-CD cavity, leading to a reduction in the overall crystallinity of the system.
Figure 6. DSC curves for β-CD, VAL, the complexes prepared by the solid dispersion
(SDP), freeze-drying (FDY), kneading (KND) methods and the physical mixture (PM).
The IR spectra, shown in Figure 7, could reveal important changes in some vibrational modes as a
consequence of the host:guest interactions. The VAL proportion was the same in all complexes – 24.8%
w/w (± 2.57). The spectra of the inclusion complex FDY, KND, SDP and the PM were dominated by
the vibrational bands of the cyclodextrin molecule since there are seven repeating glucose units in the
β-CD molecule. In the inclusion compounds, when the molecule is included into the hydrophobic β-
CD cavity no significant displacement of signals in the FTIR spectra is Expected. The host:guest
interaction is mediated by weak forces between molecules, such as hydrogen bonding, hydrophobic
interactions as van der Waals forces, etc.
VAL has shown the presence of two strong stretching absorption bands around 1,731 cm-1 and
1,600 cm-1, corresponding to the carbonyl group (amide and carboxylic acid) contributions. Analyzing
the SDP, FDY and KND FTIR spectra we can observe low intensity of these stretching ν(C=O) upon

Molecules 2010, 15
4074
host:guest interaction in contrast with the PM FTIR spectra where no perceptible changes were noted.
Moreover, the ν(C=C) aromatic ring deformation at 1,455 cm-1 of VAL also diminished in intensity after
the association with β-CD but was explicit in the PM. Based on the above results it is reasonable to
suggest that there is a formation of new supramolecular compound after association of VAL with
β-CD [17,27].
Figure 7. FTIR spectra for β-CD, VAL, the VAL and β-CD complexes prepared by solid
dispersion (SDP), freeze-drying (FDY), kneading (KND) methods and the physical mixture (PM).
The inclusion complex of VAL with β-CD has been described in the literature [28]. The IR spectra
of this complex, prepared in the 1:1 molar ratio, showed a band shift for the carboxyl carbonyl group
of valsartan, which in the physical mixture appears at 1,732 cm-1 and in the complex at 1,734 cm-1.
Moreover, the authors explain that the band shift characteristic for the amide carbonyl group in the
physical mixture appears at 1,646 cm-1, while in the complex it appears at 1,642 cm-1. Others signals
also change and the authors concluded that these alterations confirm that an inclusion complex was
formed. Our work is in accordance with these results.
Intrinsic dissolution is a pharmaceutical method which utilizes a compressed disc of known area
(with a constant surface) eliminating surface area and surface electrical charges as dissolution variables.
The dissolution rate observed is specific for each solid product in a given solvent under the determined
experimental variables. The result is generally expressed as mg dissolved per minute per centimeter
squared [29]. Based on these results, it is possible to predict problems due to dissolution rate of the
drug [30]. Intrinsic dissolution studies were performed in order to study the effect of inclusion process
on the dissolution of VAL. Figure 8 show the plot of VAL and the SDP and FDY VAL:β-CD

Molecules 2010, 15
4075
complexes dissolved versus time at pH 6.8. The data were normalized to percentage of VAL released
versus time. The linearity was higher than 0.99 (Table 3) and the calculated intrinsic dissolution shows
a small Relative Standard Deviation (RSD), indicating good reproducibility. It is interesting to note a
higher dissolution rate of at least 16 times and 2.4 times for the FDY and SDP complexes, respectively,
when compared to the free VAL dissolution rate. These results are very relevant as the increased VAL
dissolution rate could increase its bioavailability [8].
Figure 8. Intrinsic dissolution profiles for VAL and complexes prepared by the solid
dispersion (SDP) and freeze-drying (FDY) methods.
Table 3. Linear regression, linearity and intrinsic dissolution for VAL and complexes
prepared by solid dispersion (SDP) and freeze-drying (FDY).
Intrinsic dissolution
Linear equation
Linearity
(mg/min/cm2) (± RSD)
1.0 (± 1.2%)
2.4 (± 2.4%)
VAL
SDP
FDY
0.9996
0.9985
0.9962
y = 0.2481x + 0.1183
y = 0.5940x - 1.1834
y = 4.1940x + 0.2000
16.8 (± 3.1%)
RSD: Relative Standard Deviation.
1H-NMR spectroscopy in solution is on the most effective methods for studying cyclodextrin
inclusion complexes [31–37]. Two dimensional (2D) NMR is known to allow the observation of inter-
and intra-molecular interactions [38]. The presence of NOE cross-peaks between protons from the
host:guest species indicates spatial contacts of less than 5 Å. In order to get more information, we used
2D ROESY to study the host guest compounds, analyzing cross-peaks involving the protons (H3 and
H5) inside the β-CD cavity.
Figure 9 shows the 1H-NMR spectrum of valsartan in DMSO-d6 and the Figure 10 shows the partial
contour map of 2D-ROESY experiments in DMSO-d6 for inclusion complexes prepared by the FDY

Molecules 2010, 15
4076
method. The results (data not shown) demonstrate that there are no cross-peaks between VAL and
β-CD in the complex resulting from KND and SDP. Such an interaction can only be observed in the
complex prepared by the FDY method (Figure 10). The correlation occurs between the hydrogens (H3
and H5) located inside the β-CD cavity with the aromatic hydrogens of the “b” (δ 7,544–7,669 ppm)
and “c” VAL rings (δ 6,462–7,235 ppm). Another correlation can be observed between the aromatic “b”
and “c” rings of VAL and H6 of β-CD, confirming the formation of the inclusion complex. These
results could suggest the presence of two valsartan conformers at room temperature.
Figure 9. 1H-NMR spectrum of valsartan in DMSO-d6 at 400 MHz at 27 ºC.
Figure 10. Partial contour map of the 2D-ROESY in DMSO-d6 at 400 MHz for the
VAL:βCD complex prepared by freeze-drying (FDY) method.
Figure 11 shows the variation of arterial pressure in Wistar rats after oral administration of VAL or
FDY complex. As shown, the single oral administration of 1.14 mg.kg-1 of VAL in hypertensive rats
produced a hypotensive effect. VAL alone significantly reduced blood pressure for about two days.

Molecules 2010, 15
4077
The most significant reduction in arterial pressure occurred in the first day and was -4.65 ± 0.67 mmHg
compared with the control period (p < 0.05) and the mean reduction in arterial pressure in these two
days was -4.00 ± 0.36 mmHg. On the third day the values of reduction in arterial pressure were not
significantly different from those observed in the control period (p > 0.05). On the other hand, the
FDY produced a significant reduction in arterial pressure after forty minutes and in the first day this
reduction was -11.16 ± 0.92 mmHg compared with control period (p < 0.05). The hypotensive effect of
FDY was significant for four days compared with control period (p > 0.05) and the mean reduction in
arterial pressure in these four days was -5.17 mmHg ± 0.38 mmHg. The heart frequency was measured
(data not shown) and did not change significantly during the experiment. These results could be due to
the higher solubility of the FDY complex that causes a faster and prolonged action of VAL.
Figure 11. Arterial pressure variation of Wistar rats after one oral dose of VAL (white bars)
or FDY (black bars). * no significant difference between VAL and FDY, ** p > 0.05 in
comparison to control period, *** p < 0.0001 comparing VAL and FDY in the same day.
3. Experimental Section
3.1. General
VAL (Mw = 435.53) was purchased from Hetero Labs Limited (Hyderabad, India) and β-CD
(Mw = ~1135.01) was purchased from Sigma-Aldrich (Milwaukee, WI, USA) and used as received.
All other chemicals and solvents were of pharmaceutical or analytical reagent grade. The water used in
the experiments was ultrafiltered with Milli Q plus equipment from Millipore® (Billerica, MA, USA).
3.2. Phase solubility studies
The VAL phase solubility studies were carried out according to the method previously reported by
Higuchi and Connors [16]. Briefly, excess amounts of VAL (15 mg) were added to water (2 mL)
containing various concentrations of β-CD (0 to 0.01215 mol·L-1). The suspensions were shaken at 298,
303 and 310 K for three days. After reaching equilibrium, the samples were filtered through a 0.45 μm

Molecules 2010, 15
4078
membrane filter (Millipore®) and suitably diluted in 0.01 mol·L-1 NaOH. VAL concentration was
determined spectrophotometrically (HP UV/Vis spectrophotometer, model 8453, Hewlett Packard,
Palo Alto, CA, USA) at 225 nm. The stability constants, Kc, were calculated from the phase solubility
diagrams assuming the 1:1 stoichiometry, according to the equation:
slope
K1:1 =
(3)
So (1− slope)
where S0 is VAL solubility in the absence of β-CD.
3.3. Microcalorimetric measurements
Calorimetric titrations were carried out in duplicate with a VP-ITC Microcalorimeter from Microcal
at 298.15 K. The ITC instrument was previously calibrated electrically and chemically. Each titration
experiment consisted of 41 successive injections of valsartan (30 mM) dissolved in phosphate buffer
solution into the reaction cell charged with of β-CD (1.5 mL, 1 mM) in phosphate buffer solution, with
time intervals of 540 s. The first injection of 1 μL was discarded to eliminate diffusion effects of
material from syringe to cell calorimetric. The subsequent were injected at constant volume of 5 μL of
valsartan. The time of injection was 2 s. The β-CD concentration in the calorimeter cell varied from 1
to 0.86 mM and the concentration of the valsartan from 0.0 to 4.3 mM. The raw data were analyzed by
the software supplied with the calorimeter (Microcal Origin 5.0 for ITC), next the subtraction of blank
experiment (dilution of valsartan in phosphate buffer solution).
3.4. Preparation of inclusion complexes
The VAL:β-CD inclusion complex was prepared using three different methodologies, namely
kneading (KND), solid dispersion (SDP), freeze-drying (FDY), which are described below. The 1:1
molar ratio was considered based on previous solubility studies. A physical mixture (PM) was also
used. The powder obtained was stored at 4ºC until physicochemical characterization.
3.4.1. Kneading method
In order to prepare the complex using the kneading method, the β-CD and VAL were transferred to
a glass mortar, mixed and homogenized with water in the proportion of 1:4 (solid-water) to produce the
slurry, which was kneaded for 45 min. Following this period, the material was dried at 40 ºC for 24 h.
3.4.2. Solid dispersion
Complexes were also prepared by the solid dispersion method. Initially β-CD (200 mg) was
dissolved in water at concentration of 1.67 w/v%. VAL (77 mg) was dissolved in ethyl alcohol (1 mL)
and added to the β-CD solution in order to allow complexation. This suspension obtained was kept in
an ultrasonic bath for 10 min, frozen using liquid nitrogen and freeze-dried for 24 h.

Molecules 2010, 15
4079
3.4.3. Freeze-drying
VAL (77 mg) was dispersed in water and the pH was adjusted to 6.0 with 0.1 mol·L-1potassium
hydroxide. The drug was soluble under these conditions because it is a weak acid, its pKa being 4.73.
The solution containing VAL was mixed with a solution containing β-CD (200 mg) and stirred at room
temperature for 24 h. Then, the solution was freeze-dried and the powder obtained was stored at 4 ºC.
The freeze-dryer used was a Thermo Savant Modulyo D Freeze Dryer-115 instrument (Ramsey, MN, USA).
3.4.4. Physical mixture
For comparison reasons, 1:1 physical mixtures were prepared Briefly, β-CD (200 mg) was
transferred to a glass mortar together with VAL (77 mg) and mixed for 5 min.
3.5. Powder X-ray diffractometry
X-Ray powder diffraction patterns were recorded at room temperature using a Rigaku Geigerflex
2037 from Rigaku Corp. (Tokyo, Japan). The measurement conditions were as follows: Co-filtered, Cu
Kα radiation, scanning speed of 4θ per min over a 2θ range of 4º to 60º.
3.6. Thermal analyses
Differential Scanning Calorimetry (DSC) curves were produced in triplicate in a DSC-50
instrument (Shimadzu Co., Kyoto, Japan) using the following conditions: dynamic nitrogen
atmosphere (50 mL·min-1), heating rate of 10 ºC·min-1. Samples were weighted out accurately and
submitted to further heat scanning from 25 ºC to 500 ºC in a sealed aluminum pan with a capacity of
40 μL. An empty sealed aluminum pan was used as reference. The equipment was periodically
calibrated with indium (99.98%, m.p. 156.65 ºC, Sigma-Aldrich, Milwaukee, WI, USA). Data analysis
was carried out using TA Analysis Software.
3.7. Fourier transformed-infrared (FTIR) spectroscopy
Infrared spectra covering the range of 4,000–400 cm-1 were obtained with a FTIR spectrometer
(Spectrum one, Perkin Elmer, Waltham, MA, USA). The spectra were an average of 32 scans at a
resolution of 4 cm-1.
3.8. Nuclear Magnetic Resonance (NMR) experiments
NMR spectra were recorded on a DRX-400 Avance 400 MHz spectrometer (Bruker-Biospin,
Rheinstetten, Germany) at 300 K. DMSO-d6 (isotopic purity at least 99.5%) was purchased from
Aldrich and used as solvent, and tetramethylsilane (TMS) as internal standard (δ 0.0). The solutions
were transferred to NMR tubes with 8 inches in length and 5 mm in external diameter. One-
dimensional NMR experiments (1H and 13C) were performed with a 5 mm dual probe (1H/13C) using

Molecules 2010, 15
inverse detection with z-gradient coil. The intermolecular interaction between β-CD and VAL was
4080
1
1
monitored by H-NMR and H-1H rotating-frame nuclear overhauser spectroscopy, 2D-ROESY
(500 ms spin lock). The water suppression was performed using the WATERGATE technique [38–40].
Data were processed using the software XWIN NMR, 3.1 (Bruker-Biospin, Rheinstetten, Germany)
and its edited with Mestre C®, version 4.9.9.6.
3.9. Intrinsic dissolution
The dissolution test was conducted under sink conditions in phosphate buffer
(900 mL, 0.05 mol·L-1, pH 6.8) at 37 ± 0.5 ºC and rotational speeds of 100 rpm. Each dissolution test
was performed at least in triplicate [29]. The dissolution system was fitted with ERWEKA DT800
(Distek Inc., NJ, USA) and a HP 89092A 7-channel peristaltic pump (Agilent Technologies Italia Spa.,
Roma, Italy). The aliquots collected containing VAL were filtered using a 0.45 μm filter (Millipore®),
mixed with 0.01 mol·L-1 NaOH and analyzed in a spectrophotometer at 225 nm. FDY, SDP complexes
and VAL discs were prepared compressing powder (200.0 mg) in a Perkin Elmer hydraulic press
(Waltham, Massachusetts, USA) for 1 min under 3 t compression force, using a 8 mm punch. The
surface area exposed was 0.5 cm2 and the disk distance from vessel bottom was 2.54 cm. Aliquots of
VAL from the mixture prepared by the freeze-drying (FDY) method were automatically collected
every 5 min until 20 min. For SDP and VAL the aliquots were collected every 15 min until 60 min.
The results were normalized to the percentage of VAL released, a linear regression of VAL released
versus time was plotted and the intrinsic dissolution rate of the drug was determined in mg per minute
per cm2 from the slope of the regression line calculated. Only the linear portion of each dissolution
profile was considered for the intrinsic dissolution rate determination. The slope and the other
statistical parameters of the curves were calculated by linear regression analysis.
3.10. Ultraviolet spectroscopy (UV-Vis)
UV-Vis spectra of VAL were registered on a HP UV/Vis, model 8453spectrophotometer (Hewlett
Packard, Palo Alto, CA, USA), using 0.01 mol·L-1 NaOH as the solvent at a chosen wavelength of
225 nm. Quartz cuvettes with path length 1 cm were also used. The slope and the other statistical
parameters of the calibration curves were calculated by linear regression analysis.
3.11. Anti-hypertensive evaluation
After evidence of VAL:β-CD inclusion formation, the antihypertensive efficacy in vivo was tested
on VAL, VAL:β-CD complex prepared by the freeze-drying (FDY) and vehicle as control. The
method used was telemetry, where male Wistar rats (14–16 weeks old) weighing 250–300 g were used.
All rats were obtained from CEBIO (Centro de Bioterismo do Instituto de Ciências Biológicas,
Universidade Federal de Minas Gerais). All rats in the study received subcutaneous infusion of
angiotensin II (5 μg·h-1) throughout the experiment to induce hypertension. The rats were housed in
separated cages, under controlled temperature conditions (25 ºC) and 12/12 h light/dark cycle (light:
6:00 AM–6:00 PM), free access was allowed to standard diet (Nuvilav CR1 - Nuvital Nutrientes) and

Molecules 2010, 15
4081
tap water was supplied ad libitum. Before the experiments, the animals underwent acclimatization for
7 days in an isolated telemetry room. The studies were performed in accordance with the guidelines for
the human use of laboratory animals of our institution and approved by local authorities. A telemetry
system (Data Sciences International, MN) was used for measuring mean arterial pressure (MAP). This
monitoring system consists of a radio frequency transducer model TA11-PA C40, a receiver, a matrix,
and an IBM-compatible personal computer with accompanying software (Dataquest A.R.T. Gold 2.0)
to store and analyze the data. After insertion of an infusion pump containing the angiotensin II, the rats
were housed in individual cages for three days until the telemetry tracing had indicated re-
establishment of 24 h oscillations of blood pressure and heart rate. Data were sampled every 10 min
for 72 h. After recovery, the rats were randomized in three experimental groups: vehicle (n = 4), FDY
(n = 4) and VAL (n = 4). In order to characterize the cardiovascular effects of the inclusion compound
in Wistar rats, we evaluated the variation in blood pressure after oral administration by gavage of the
VAL (1.14 mg·kg-1 body weight) and the FDY inclusion complex in a dose of 4.22 mg·kg-1 body
weight, equivalent at 1.14 mg of VAL. The period of observation was seven days after oral
administration of control, VAL or FDY. Data were collected every 10 min during the entire
experimental period. Time course: the variation in MAP was calculated each 10 min by the difference
of the MAP value and an average of MAP values collected for 72 h before administration of the
compounds. Data were analyzed by unpaired t test. All statistical analysis differences were considered
significant at p < 0.05.
4. Conclusions
In our work different processes, namely FDY, KND and SDP, have been applied to prepare
inclusion complex of VAL and β-CD. The phase solubility diagram was classified as AL-type
indicating the formation of a 1:1 VAL:β-CD inclusion complex. The lower values of the stability
constants (Kc) suggest that the VAL:β-CD interaction is weak and also that the inclusion process is
exothermic, defined as enthalpically driven and spontaneous.
The host:guest interaction was better characterized by the dipolar correlation in the 2D-ROESY
contour map, where protons from the aromatic region of the drug present correlations with protons
inside the β-CD cavity. Another advantage is the use of only water for the FDY preparation, allowing
clean production of inclusion compounds between VAL and β-CD with elimination of organic solvents
involved in the processes described in the literature.
The solubility characterization by intrinsic dissolution shows that the complexes studied have better
rate solubility than free VAL, at least 16 times more for FDY and 2.4 times more for SDP. This
solubility gain can improve the oral bioavailability of VAL. In studies with Wistar rats VAL
administered alone shown significant reduction in arterial pressure for two days after oral
administration. On the other hand, FDY produced a significant reduction in arterial pressure after forty
minutes and was able to reduce arterial pressure for four days exceeding VAL.
Acknowledgments
The authors are very grateful to the Brazilian research supporting agencies CNPq (Conselho
Nacional de Pesquisa), FAPEMIG (Fundação de Amparo à Pesquisa de Minas Gerais), INCT

Molecules 2010, 15
4082
(Nacional Institute of Science and Technology) and the NANO-BIOFAR (CNPq/INCT/FAPEMIG) for
their financial support for this work.
References and Notes
1. Ladak, N.; Thompson, J. Drugs acting on the heart: antihypertensive drugs. Anaesth. Intensive
Care Med. 2009, 10, 392–395.
2. Mahmud, A.; Feely, J. Low-dose quadruple antihypertensive combination more efficacious than
individual agents–a preliminary report. Hypertension 2007, 49, 272–275.
3. Ibrahim, M.M. RAS inhibition in hypertension. J. Human Hypert. 2006, 20, 101–108.
4. Tamargo, J.; Caballero, R.; Gómez, R.; Núñez, L.; Vaquero, M.; Delpón, E. Características
farmacológicas de los ARA-II. ¿Son todos iguales? Rev. Esp. Cardiol. Supl. 2006, 6, 10C–24C.
5. Li, H.; Wang, Y.; Jiang, Y.; Tang, Y.; Wang, J.; Zhaob, L., Gua, J. A liquid
chromatography/tandem mass spectrometry method for the simultaneous quantification of
valsartan and hydrochlorothiazide in human plasma. J. Chromatogr. B 2007, 852, 436–442.
6. Brunner, H.R. The new angiotensin II receptor antagonist, irbesartan. Am. J. Hypertens. 1997, 10,
331S–317S.
7. Zusman, R.M. Are there differences among angiotensin receptor blockers? Am. J. Hyperten. 1999
12, 231S–235S.
8. Therapeutic sytems reseearch laboratories, biopharmaceutics classification system.
http://www.tsrlinc.com/services/bcs/results.cfm (2010) (accessed 6 March 2010).
9. Uekama, K; Hirayama, F.; Irie, T. Cyclodextrin Drug Carrier Systems. Chem. Rev. 1998, 98,
2045–2076.
10. Loftsson, T. Cyclodextrins and the Biopharmaceutics Classification System of Drugs. J. Incl.
Phenom. Macro. Chem. 2002, 44, 63–67.
11. Loftsson, T.; Duchêne, D. Cyclodextrins and their pharmaceutical applications. Int. J. Pharm.
2007, 329, 1–11.
12. Brewster, M.E.; Loftsson, T. Cyclodextrins as pharmaceutical solubilizers. Adv. Drug Deliver.
Rev. 2007, 59, 645–666.
13. Szejtli, J. Introduction and General Overview of Cyclodextrin Chemistry. Chem. Rev. 1998, 98,
1743–1753.
14. Challa, R.; Ahuja, A.; Ali, J.; Khar, R.K. Cyclodextrins in Drug Delivery: An Updated Review.
AAPS Pharm. Sci. Tech. 2005, 6, E329–E357.
15. Martin Del Valle, E.M. Cyclodextrins and their uses: a review. Process Biochem. 2004, 39,
1033–1046.
16. Higuchi, T.; Connors, K.A. Phase solubility techniques. Adv. Anal. Chem. Instrum. 1965, 4,
117–212.
17. Cappello, B.; Di Maio, C.; Lervolino, M.; Miro, A. Improvement of Solubility and Stability of
Valsartan by Hydroxypropyl-β-Cyclodextrin. J. Incl. Phenom. Macrocycl. Chem. 2006, 54,
289–294.

Molecules 2010, 15
4083
18. Karathanos, V.T.; Mourtzinos, I.; Yannakopoulou, K.; Andrikopoulos, N.K. Study of the
solubility, antioxidant activity and structure inclusion complex of vanillin with β-cyclodextrin.
Food Chem. 2007, 101, 652–658.
19. Loftsson, T.; Hreinsdoóttir, D.; Másson, M. The complexation efficiency. J. Incl. Phenom.
Macrocycl. Chem. 2007, 57, 545–552.
20. Jullian, C.; Orosteguis, T.; Pérez-Cruz, F.; Sánchez, P.; Mendizabal, F.; Olea-Azar. C.
Complexation of morin with three kinds of cyclodextrin: A thermodynamic and reactivity study.
Spectrochim. Acta Part A 2008, 71, 269–275.
21. Giordano, F.; Novak, C.; Moyano, J.R. Thermal analysis of cyclodextrins and their inclusion
compounds. Thermochim. Acta 2001, 380, 123–151.
22. Turnbull, W.B.; Daranas, A.H. On the value of c: can low affinity systems be studied by
isothermal titration calorimetry? J. Am. Chem. Soc. 2003, 125, 14859–14866.
23. Loftsson, T.; Hreinsdoóttir, D.; Másson, M. The complexation efficiency. J. Incl. Phenom.
Macrocycl. Chem. 2007, 57, 545–552.
24. Cepanec, I.; Litvic, M.; Bartolincic, A.; Sporec, A.; Druskovic, V. Process for production of
inclusion complexes of valsartan with β-cyclodextrin. WO/2005/056607. 23.06.2005
25. Bettinetti, G.; Novák, C.; Sorrenti, M. Thermal and structural characterization of commercial α-,
β-, and δ-cyclodextrins. J. Therm. Anal. Calorim. 2002, 68, 517–529.
26. Orgoványi, J.; Pöppl, L.; -Otta, K.H.; Lovas, G.A. Thermoanalytical method for studying the
guest content in cyclodextrin inclusion complexes. J. Therm. Anal. Calorim. 2005, 81, 261–266.
27. Winters, C.S.; York, P.; Timmins, P. Solid state examination of a gliclazide:beta-cyclodextrin
complex. Eur. J. Pharm. Sci. 1997, 5, 209–214.
28. Pravin, N.; Babasaheb, A.; Neha, D.; Vilasrao, K.; Rajashree, H. Solid state characterization of
the inclusion complex of valsartan with methyl β-cyclodextrin. J. Incl. Phenom. Macrocycl. Chem.
2009, 65, 377–383.
29. The United States pharmacopeia, 31st ed.; The United States Pharmacopeial Convention:
Rockville, Maryland, MD, USA, 2007; General Chapter Number ‹1087›.
30. Blagden, N.; De Matas, M.; Gavan, P.T.; York, P. Crystal engineering of active pharmaceutical
ingredients to improve solubility and dissolution rates. Adv. Drug Delivery Rev. 2007, 59,
617–630.
31. Al Omari, M.M.; Zughul, M.B.; Davies, J.E.D.; Badwan, A.A. Sildenafil / cyclodextrin
1
complexation: Stability constants, thermodynamics, and guest–host interactions probed by H
NMR and molecular modeling studies. J. Pharm. Biomed. Anal. 2006, 41, 857–865.
32. Ficarra, R.; Tommasini, S.; Raneri, D.; Calabrò, M.L.; Di Bella, M.R.; Rustichelli, C.; Gamberini,
M.C.; Ficarra, P. Study of flavonoids/β-cyclodextrins inclusion complexes by NMR, FT-IR, DSC,
X-ray investigation. J. Pharm. Biomed. Anal. 2002, 29, 1005–1014.
1
33. Sun, D.Z.; Li, L.; Qiu, X.M.; Liu, F.; Yin, B.I. Isothermal titration calorimetry and H NMR
studies on host–guest interaction of paeonol and two of its isomers with β-cyclodextrin. Int. J.
Pharm. 2006, 316, 7–13.
1
34. Fronza, G.; Mele, A.; Redenti, E.; Ventura, P. H NMR and molecular modeling study on the
inclusion complex β-cyclodextrin-indomethacin. J. Org. Chem. 1996, 61, 909–914.

Molecules 2010, 15
4084
35. Bernini, A.; Spiga, O.; Ciutti, A.; Scarselli, M.; Bottoni, G.; Mascagni, P.; Niccolai, N. NMR
studies of the inclusion complex between β-cyclodextrin and paroxetine. Eur. J. Pharm. Sci. 2004,
22, 445–450.
36. Lula, I.; Gomes, M.F.; Veloso, D.P.; Noronha, A.L.O.; Duarte, H.A.; Santos, R.S.; Sinisterra, R.D.
Spironolactone and its complexes with b-cyclodextrin: modern NMR characterization and
structural DFTB-SCC Calculations. J. Incl. Phenom. Macrocycl. Chem. 2006, 56, 293–302.
37. Denadai, A.M.L.; Ianzer, D. Alcântara, A.F.C.; Santoro, M.M.; Santos, C.F.F.; Lula, I.S.;
Camargo, A.C.M.; Faljoni-Alario, A.; Santos, R.A.S.; Sinisterra, R.D. Novel pharmaceutical
composition of bradykinin potentiating penta peptide with β-cyclodextrin: Physical–chemical
characterization and anti-hypertensive evaluation. Int. J. Pharm. 2007, 336, 90–98.
38. Schneider, H.J.; Hacket, F.; Rüdiger, V.; Ikeda, H. NMR studies of cyclodextrins and cyclodextrin
complexes. Chem. Rev. 1998, 98, 1755–1785.
39. Werner, M.H. Advanced User’s Guide, Brucker. <940712>; Spectrospin A.G.: Fallanden,
Switzerland, 1994.
40. Rahman, A. One and Two Dimensional NMR Spectroscopy, 1st ed.; Elsevier: New York, NY,
USA, 1989.
Sample Availability: Samples are not available.
© 2010 by the authors; licensee MDPI, Basel, Switzerland. This article is an Open Access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
