1018
J. Fournier Dit Chabert et al. / Tetrahedron Letters 47 (2006) 1015–1018
Fenton, D. E.; McHugh, P. E. Inorg. Chem. Commun.
2004, 7, 147–150.
7-Methoxy-2-(3-methoxy-phenyl)-3-phenyl-quinoline 5b: 3-
Hydroxy-1-methylpiperidine (2 mmol) in 2 mL dried THF
was added dropwise to a suspension of NaH (7 mmol) and
Ni(OAc)2 (1 mmol) in hot THF (6 mL). After 1 h of reflux,
the substrate 4b (74 mg; 0.2 mmol) was added dropwise in
THF (2 mL). After 15 h stirring at 65 °C, the crude
mixture was cooled to 20 °C and ethanol (1 mL) and water
(15 mL) were added. The mixture was extracted three
times with dichloromethane (20 mL), and the combined
organic phases were dried over MgSO4, filtered and
evaporated. The crude products were purified by flash
chromatography (silica, heptane/ethyl acetate 98:2) to
afford compound 5b (35 mg; 52%) as a pale beige solid; mp
113–114 °C. Anal. Found: C 80.51, H 5.66, N 3.89, O 8.95.
Calcd for C23H19NO2: C 80.92, H 5.61, N 4.10, O 9.37; dH
(300 MHz, CDCl3) 3.67 (s, 3H, OCH3), 3.99 (s, 3H,
OCH3), 6.87 (ddd, 1H, J 0.9; 2.6; 8.2 Hz), 7.02 (dd, 1H, J
1.5; 2.6 Hz), 7.06 (ddd, 1H, J 0.9; 1.5; 7.7 Hz), 7.20 (dd,
1H, J 7.7; 8.2 Hz), 7.24 (dd, 1H, J 2.4; 9.0 Hz), 7.25–7.32
(m, 5H), 7.47 (d, 1H, J 2.4 Hz), 7.76 (d, 1H, J 9.0 Hz), 8.11
(s, 1H); dC (75 MHz, CDCl3) 55.2 (CH3), 55.7 (CH3),
107.4 (CH), 114.6 (CH), 115.0 (CH), 120.2 (CH), 122.6
(C), 122.7 (CH), 127.0 (CH), 128.3 (2CH), 128.6 (CH),
129.1 (CH), 129.8 (2CH), 132.5 (C), 137.4 (CH), 140.3 (C),
141.9 (C), 149.0 (C), 158.3 (C), 159.2 (C), 161.0 (C) ppm;
m/z 341 (M+, 40), 340 (100), 325(20), 297 (30), 254 (20);
HRMS CI found: 342.1496, calcd for C23H19NO2H+:
342.1494.
7-Methoxy-2-(4-methoxy-phenyl)-3-phenyl-1,2,3,4-tetra-
hydro-quinoline 6a: Compound 2a (1 mmol) and
NiCl2Æ6H2O (15 mmol) were dissolved in methanol
(35 mL) and THF (15 mL) in an opened flask cooled in
an ice bath. The solution was stirred while NaBH4
(45 mmol) was added in small portions. After stirring
under 30 bar hydrogen pressure at 100 °C for the time
indicated, the crude mixture was filtered over a short pad
of silica. The metallic residue was treated with a 1 M
solution of HCl (50 mL) and extracted with dichloro-
methane (50 mL). The aqueous solution was basified with
a 1 M KOH solution and then extracted with dichloro-
methane (50 mL). The combined organic phases were
dried over MgSO4, filtered and added to the first filtrate
prior to evaporation. The crude product was purified by
flash chromatography (silica, heptane/ethyl acetate
99.5:0.5) to afford compound 6a (193 mg; 56%) as an
amorphous white solid; mp 132–134 °C. Anal. Found: C
79.76, H 6.77, N 3.91, O 9.60. Calcd for C23H23NO2: C
79.97, H 6.71, N 4.05, O 9.26; dH (500 MHz, CDCl3) 3.00
(d, 2H, J 7.5 Hz), 3.49 (dt, 1H, J 4.0; 7.5 Hz), 3.75 (s, 3H,
OCH3), 3.81 (s, 3H, OCH3), 4.32 (br s, 1H, NH), 4.66 (d,
1H, J 4.0 Hz), 6.20 (d, 1H, J 2.5 Hz), 6.33 (dd, 1H, J 2.5;
8.3 Hz), 6.66 (d, 2H, J 8.9 Hz), 6.72 (d, 2H, J 8.9 Hz),
6.84–6.89 (m, 2H), 6.99 (d, 1H, J 8.3 Hz), 7.15–7.20 (m,
3H); dC (75 MHz, CDCl3) 29.2 (CH2), 44.1 (CH), 55.6
(CH3), 55.6 (CH3), 60.1 (CH), 99.3 (CH), 103.5 (CH),
113.3 (2CH), 113.6 (C), 126.8 (CH), 128.2 (2CH), 129.1
(2CH), 129.2 (2CH), 130.5 (CH), 134.2 (C), 141.9 (C),
145.6 (C), 159.0 (C), 159.6 (C) ppm; m/z 345 (M+, 40), 254
(100), 224 (30); HRMS CI found: 346.1805, calcd for
C23H23NO2H+: 346.1807.
15. (a) Schlesinger, H. I.; Brown, H. C.; Finholt, A. E.;
Gilbreath, J. R.; Hoekstra, H. R.; Hyde, E. K. J. Am.
Chem. Soc. 1953, 75, 215–219; (b) Back, T. G.; Yang, K.;
Krouse, H. R. J. Org. Chem. 1992, 57, 1986–1990; (c)
Back, T. G.; Baron, D. L.; Yang, K. J. Org. Chem. 1993,
58, 2407–2413.
16. Reggeli, M.; Hoffman, H.; Ko¨ck, M.; Mierke, D. F. J. Am.
Chem. Soc. 1992, 114, 3272–3277.
17. 3-Methoxy-6-(4-methoxy-phenyl)-11-thia-5-aza-benzo[a]-
fluorene-5-oxide 3a: In a round bottom flask filled with
Raney nickel (15 mmol) in ethanol (5 mL) was added
compound 2a (210 mg; 0.5 mmol) and the mixture was
stirred at room temperature for 2 h. Dichloromethane
(10 mL) was added to dissolve the yellow precipitate and
the mixture was filtered prior to evaporation. The resulting
solid was purified by flash chromatography (silica, cyclo-
hexane/AcOEt 90:10) to afford compound 3a (98 mg;
51%) as a pale yellow powder; mp >270 °C. Anal. Found:
C 71.10, H 4.47, N 3.61, O 12.51. Calcd for C23H17NO3S:
C 71.30, H 4.42, N 3.61, O 12.39; dH (300 MHz, CDCl3)
3.96 (s, 3H, OCH3), 3.99 (s, 3H, OCH3), 6.83 (d, 1H, J
8.3 Hz), 7.15 (ddd, 1H, J 1.1; 7.3; 8.1 Hz), 7.19 (d, 2H, J
8.7 Hz), 7.33 (dd, 1H, J 2.5; 8.9 Hz), 7.36 (ddd, 1H, J 1.1;
7.3; 8.3 Hz), 7.50 (d, 2H, J 8.7 Hz), 7.84 (d, 1H, J 8.1 Hz),
7.96 (d, 1H, J 8.9 Hz), 8.30 (d, 1H, J 2.5 Hz); dC (75 MHz,
CDCl3) 55.5 (CH3), 56.0 (CH3), 100.7 (CH), 115.1 (2CH),
119.0 (C), 121.5 (CH), 122.8 (CH), 124.5 (CH), 125.0 (C),
125.1 (CH), 126.0 (CH), 126.4 (C), 126.7 (CH), 130.7
(2CH), 134.7 (C), 136.1 (C), 138.9 (C), 140.8 (C), 143.7
(C), 160.6 (C), 161.9 (C) ppm; m/z 389 (20), 388 (MH+,
100), 370 (50), 327 (10); HRMS EI found: 387.0924, calcd
for C23H17NO3S+Å: 387.0929.
3-Methoxy-6-(2-methoxy-phenyl)-11-thia-5-aza-benzo[a]-
fluorene 4c: To Raney nickel (0.75 mmol) in ethanol was
added compound 2c (210 mg; 0.5 mmol) and the mixture
was stirred in a hydrogen pressurised (30 atm) reactor at
100 °C for 2 h. Dichloromethane (10 mL) was added to
dissolve the white precipitate and the mixture was filtered
prior to evaporation. The resulting solid was purified by
flash chromatography (silica, cyclohexane/AcOEt 95:5) to
afford compound 4c (145 mg; 78%) as an amorphous
white powder; mp 149–150 °C. Anal. Found: C 74.37, H
4.71, N 3.70, O 8.67. Calcd for C23H17NO2S: C 74.37, H
4.61, N 3.77, O 8.61; dH (300 MHz, CDCl3) 3.63 (s, 3H,
OCH3), 3.98 (s, 3H, OCH3), 7.06 (ddd, 1H, J 0.7; 1.2;
8.1 Hz), 7.11 (d, 1H, J 8.3 Hz), 7.19 (ddd, 1H, J 1.1; 7.2;
8.3 Hz), 7.20 (ddd, 1H, J 1.1; 7.4; 7.5 Hz), 7.30 (dd, 1H,
J2.5; 9.0 Hz), 7.38 (ddd, 1H, J 1.1; 7.2; 8.2 Hz), 7.47 (dd,
1H, J 1.8; 7.5 Hz), 7.56 (ddd, 1H, J 1.8; 7.4; 8.1 Hz), 7.69
(d, 1H, J 2.5 Hz), 7.91 (ddd, 1H, J 0.7; 1.1; 8.1 Hz), 8.04
(d, 1H, J 9.0 Hz); dC (75 MHz, CDCl3) 55.7 (CH3), 55.7
(CH3), 108.9 (CH), 111.3 (CH), 118.4 (C), 119.6 (CH),
121.5 (CH), 122.7 (CH), 123.8 (CH), 125.0 (CH), 125.1
(CH), 126.0 (CH), 126.9 (C), 130.1 (C), 130.1 (CH), 130.5
(CH), 135.8 (C), 138.5 (C), 146.5 (C), 147.1 (C), 154.5 (C),
157.3 (C), 160.8 (C) ppm; m/z 371 (M+, 60), 340 (50), 297
(60), 266 (100), 207 (10); HRMS CI found: 372.1054, calcd
for C23H17NO2SH+: 372.1058.
