A New Tool in Peptide Engineering: A Photoswitchable Stilbene-type
b-Hairpin Mimetic
MµtØ ErdØlyi,[a, b] Anders KarlØn,[b] and Adolf Gogoll*[a]
Abstract: Peptide secondary structure
mimetics are important tools in medici-
nal chemistry, as they provide ana-
logues of endogenous peptides with
new physicochemical and pharmaco-
logical properties. The development,
synthesis, photochemical investigation,
and conformational analysis of a stil-
bene-type b-hairpin mimetic capable of
light-triggered conformational changes
have been achieved. In addition to
standard spectroscopic techniques (nu-
clear Overhauser effects, amide tem-
perature coefficients, circular dichroism
spectroscopy), the applicability of self-
diffusion measurements (longitudinal
eddy current delay pulsed-field gradi-
ent spin echo (LED-PGSE) NMR
technique) in conformational studies of
oligopeptides is demonstrated. The title
compound shows photoisomerization
of the stilbene chromophore, resulting
in a change in solution conformation
between an unfolded structure and a
folded b-hairpin.
Keywords: beta-hairpin · peptido-
mimetics · photochemistry · self-
diffusion · stilbene
Introduction
we present here a photoswitchable, stilbene-based peptido-
mimetic and its conformational analysis.
Molecular switches are compounds capable of existing in
two or more interconvertible conformational states.[1] Exter-
nal switching between these isomers may be driven by pH
change, chemical reactions, complexation, electron transfer,
heat, or magnetic or electric fields, or it may be triggered by
irradiation at a selected wavelength.[2] The development of
such photoresponsive systems is of outstanding interest be-
cause they have considerable potential for application as
new tools in biomedical engineering.[3] Incorporation of a
molecular switch into bioactive compounds may allow exter-
nal modulation of their biological effect: it may, for exam-
ple, enable photoactivation of a prodrug, in a manner re-
sembling the bioactivation of vitamin D,[4] photoactivation
of a drug in a specific area in the human body, or light-trig-
gered association/dissociation of a ligand–receptor complex.
As a key step towards the development of such compounds,
The b-hairpin motif is involved in numerous vital physio-
logical processes and pathological disorders. Because the
biological activities of some b-hairpins[5] have been shown to
be correlated with the thermodynamic stabilities of their
folded conformations,[6] a b-hairpin mimetic incorporating a
stilbene moiety should be an attractive candidate for a pho-
toswitchable peptidomimetic. Such a mimetic should allow
externally triggered interconversion between a bioactive b-
hairpin and a bioinactive nonhairpin conformation. The in-
corporation of
a diazobenzene dipeptide mimic into
cyclic[3,7] and acyclic[8] peptides was recently reported, but
the hairpin-inducing ability of this turn mimic appeared to
be limited.[7b] In addition, diazobenzenes are in many ways
inferior to stilbene derivatives in that they undergo thermal
cis–trans isomerization and are sensitive to reducing agents,
whilst the separation of their isomers is also often compli-
cated, if not impossible.[7b,8] At present, no attempts at incor-
poration of stilbene derivatives into peptides have been re-
ported. Because of their greater chemical stability, however,
they would be attractive alternatives to azobenzenes.
[a] Dr. M. ErdØlyi, Prof. Dr. A. Gogoll
Department of Chemistry, Organic Chemistry
Uppsala University, Box 599, 751 24 Uppsala (Sweden)
Fax : (+46)18-471-3818
E-mail: adolf.gogoll@kemi.uu.se
Results and Discussion
[b] Dr. M. ErdØlyi, Dr. A. KarlØn
Department of Medicinal Chemistry, Uppsala University
Box 574, 751 23 Uppsala (Sweden)
Here we present the development of a stilbene-type pepti-
domimetic capable of light-triggered conformational
changes between an unfolded structure and a folded b-hair-
Supporting information for this article is available on the WWW
under http://www.chemeurj.org/ or from the author.
Chem. Eur. J. 2006, 12, 40030–64W12iꢀley2-VCH Verlag GmbH & Co. KGaA, Weinheim
403

pin form. In this model study, the trans isomers of a cyclic
and an acyclic peptidomimetic—cyclo(Leu-Leu-Val-Ile-stil-
bene-Thr-Thr-Ala-Leu-Gly-DPro) and Leu-Leu-Val-Ile-stil-
bene-Thr-Thr-Ala-Leu-X—were prepared by combination of
solution-phase and solid-phase methodologies (X=diethyl-
aminoacetyl; Scheme 1) and their cis isomers were obtained
by subsequent photoisomerization. The amino acid strands
of the investigated compounds were extracted from the S4
region of the TATA-box binding protein, and are known to
fold into b-sheets in their native environments.[9] Surprising-
ly, no attempts at application of these amino acid strands in
model hairpin studies have yet been reported, although
their sequences are very likely to provide stable b-hairpin
conformations, as aliphatic b-branched amino acids are
known to promote the formation of hydrophobic clusters,[10]
and so are frequent constituents of the strand segments of
native b-hairpins.[11] For comparison, the nonswitchable ana-
logue Leu-Leu-Val-Ile-Gly-DPro-Thr-Thr-Ala-Leu-X was
also prepared by standard solid-phase peptide synthesis
(SPPS). A DPro-Gly dipeptide incorporated into 1 is a well-
known b-turn inducer,[12] so this peptide was designed to
fold into a b-hairpin. The acyclic (2 and 3) and cyclic (4 and
5) peptidomimetics incorporating a photoswitchable stilbene
unit were expected to allow externally triggered folding and
unfolding through irradiation at selected wavelength(s). In
addition, diethylaminoacetyl tails were also attached to the
N termini of all but the cyclic peptides 4 and 5 to increase
their solubility in polar solvents.[13]
Photochemistry: Isomerizations of 2–5 were carried out in
dimethyl sulfoxide by selective use of irradiation at the ab-
sorption maxima (lmax =300 or 280 nm)[14] of the trans- or
cis-stilbene double bonds. In the case of 2, the maximum
percentage of cis isomer 3 at the photostationary state was
reached after 3 h of irradiation (l=300 nm) and was 63%,
1
as determined by H NMR spectroscopy. For 4, the photo-
Scheme 1. The structures of b-hairpin mimetic 1, together with its open-chain (2, 3) and cyclic (4, 5) photoswitchable analogues. Amino acid building
blocks and photochemical transitions are indicated.
404
www.chemeurj.org
ꢀ 2006 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Chem. Eur. J. 2006, 12, 403 – 412

Stilbene-type b-Hairpin Mimetic
FULL PAPER
stationary state (80% cis isomer 5) was reached after 90 min
of irradiation at l=300 nm. Isomerization of the cis isomer
5 at l=280 nm resulted in 16% of the trans compound 4.
Attempts to separate the cis and trans isomers by prepara-
tive reversed-phase HPLC were successful in the case of
compounds 4 and 5, so—in contrast with similar studies on
azobenzene derivatives[15]—the cis peptidomimetic 5 was an-
alyzed separately from its trans isomer, subsequent to their
separation. Because of the lack of separation of the acyclic
compounds, the conformation of 3 was successfully investi-
gated in the cis–trans mixture obtained after isomerization
of 2.
Conformational analysis by NMR spectroscopy: The most
reliable and extensively employed tool used today for explo-
ration of peptide solution conformations is without doubt
the detection of nuclear Overhauser effects (NOEs).[16] The
observation of nonsequential NOEs hence provides the
strongest evidence for the three-dimensional solution struc-
ture of a compound, and so conformational analysis was
first performed with standard NMR techniques in water,
methanol, and dimethyl sulfoxide.[13] As expected, inter-
strand NOEs observed in the solutions of compound 1 in
methanol and dimethyl sulfoxide were characteristic of a b-
hairpin (Scheme 2). However, the absence of such NOEs in
aqueous solution suggests that folded conformations ob-
served in methanol and dimethyl sulfoxide have low thermo-
dynamic stability. No NOEs between nonadjacent residues
were observed in the cases of compounds 2, 3, and 4, thus
clearly indicating unfolded solution structures. It should be
mentioned, though, that the NOESY spectra obtained for 4
showed a few indications of the formation of a DPro-Gly b-
turn. In contrast with its open-chain analogue 3, interstrand
NOEs observed in the case of the cyclic peptidomimetic 5
provided strong evidence of its folding into a b-hairpin con-
formation (Scheme 2).
Scheme 2. NMR evidence for folded b-hairpin conformations in com-
pounds 1 and 5. The building blocks, the observed amide temperature co-
efficients (bold), and interstrand NOEs (arrows) of 1 and 5 in methanol
are indicated.
tion of compound 1 in dimethyl sulfoxide (Table 1) were
consistent with a folded b-hairpin structure in which the
amide protons of Leu-9 and Ile-7 are intramolecularly hy-
drogen bonded and Thr-4 is in equilibrium between hydro-
gen-bonded and nonbonded states.[17] The Dd/DT values ob-
tained for 1 in methanol imply that the folded conformation
has low thermodynamic stability and exists in exchange with
unfolded structures in competitive solvents, an observation
in good agreement with the NOE studies performed with
water solutions (Scheme 2). Moreover, the alternating
amide temperature coefficients of the cis isomer of the
cyclic peptidomimetic 5 are typical of a folded b-hairpin
structure in which the amide protons of Leu-1, Thr-3, Stil-
