Extensive structure modification on luteolin-cinnamic acid conjugates leading to BACE1 inhibitors with optimal pharmacological properties

Article abstract of DOI:10.3390/molecules25010102

BACE1 inhibitory conjugates derived from two natural products, luteolin (1) and p-hydroxy-cinnamic acid (2), were subjected to systematic structure modifications, including various positions in luteolin segment for conjugation, different linkers (length, bond variation), as well as various substitutions in cinnamic acid segment (various substituents on benzene, and replacement of benzene by heteroaromatics and cycloalkane). Optimal conjugates such as 7c and 7k were chosen on the basis of a series of bioassay data for further investigation.

Full text of DOI:10.3390/molecules25010102

molecules
Article
Extensive Structure Modification on
Luteolin-Cinnamic Acid Conjugates Leading to
BACE1 Inhibitors with Optimal
Pharmacological Properties
De-Yang Sun 1, Chen Cheng 2, Katrin Moschke 3,4, Jian Huang 2 and Wei-Shuo Fang 1,
*
1
State Key Laboratory of Bioactive Substances and Functions of Natural Medicines, Institute of Materia
Medica, Chinese Academy of Medical Sciences and Peking Union Medical College, 2A Nan Wei Road,
Beijing 100050, China; sdy887@126.com
College of Life Science, Wuhan University, Wuhan 430072, Hubei, China; cccc@whu.edu.cn (C.C.);
jianhuang@whu.edu.cn (J.H.)
German Center for Neurodegenerative Diseases (DZNE) and Munich Cluster for Systems
Neurology (SyNergy), Technical University of Munich, Feodor-Lynen-Strasse 17, 81377 Munich, Germany;
katrin.moschke@dzne.de
Neuroproteomics, Klinikum rechts der Isar, Technical University of Munich, 81675 Munich, Germany
Correspondence: wfang@imm.ac.cn; Tel.: +86-10-6316-5229
2
3
4
*
Academic Editors: Kamil Kuca, Tanos Celmar Costa Franca and Teodorico C. Ramalho
Received: 21 November 2019; Accepted: 23 December 2019; Published: 26 December 2019
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: BACE1 inhibitory conjugates derived from two natural products, luteolin (1) and
p-hydroxy-cinnamic acid (2), were subjected to systematic structure modifications, including various
positions in luteolin segment for conjugation, different linkers (length, bond variation), as well as
various substitutions in cinnamic acid segment (various substituents on benzene, and replacement of
benzene by heteroaromatics and cycloalkane). Optimal conjugates such as 7c and 7k were chosen on
the basis of a series of bioassay data for further investigation.
Keywords: beta-secretase; BACE1 inhibitor; flavonoid; luteolin; cinnamic acid
1. Introduction
Alzheimer’s disease (AD) is an age-dependent chronic neurodegenerative disease that is
characterized by the presence of extracellular senile plaques and neurofibrillary tangles, as well
as synaptic dysfunction and neuronal cell death. According to the World Health Organization (WHO),
about 35.6 million people were diagnosed with dementia in 2010, and the number is projected to
double every 20 years. The overall cost for dementia worldwide has been estimated at approximately
604 billion U.S. dollars [1].
Although the cause of AD remains in debate, β-amyloid cascade hypothesis (Aβ hypothesis)
or its modified version is the most widely accepted pathological mechanism according to genetic
and pathological evidence among many mechanisms. Aβ, a peptide consisting of 37–43 amino acids,
is proposed as aggregating into soluble oligomers and fibrils, which are toxic to neurons, causing
neuronal death. Another protein, tau, can also be a causative factor independently, presumably acting
downstream of Aβ aggregation [2–4].
A
β
is generated by the sequential endoproteolytic cleavage of amyloid precursor protein (APP),
a transmembrane protein expressed in many tissues and organs, by -secretase (BACE1, also known
as -site amyloid precursor protein cleaving enzyme 1) and -secretases subsequently in the brain [ ].
β
β
γ
5
Molecules 2020, 25, 102; doi:10.3390/molecules25010102
www.mdpi.com/journal/molecules

Molecules 2020, 25, 102
2 of 21
Thus, the key enzyme BACE1 involved in the generation of A
β
has been regarded as an attractive
AD drug target for about two decades. Many different chemotypes of BACE1 inhibitors have been
developed [ ]. Although some BACE1 inhibitors have advanced to clinical research, none of them
6
have finished the phase III clinical trial due to diverse side effects and/or lack of effectiveness [7].
The failure of these clinical trials, including the most recent discontinuation of AstraZeneca/Eli
Lilly’s Lanabecestat in phase III clinical trial, proposed that the early intervention of AD, even without
any symptoms, may be necessary for the success of the BACE1 inhibitors [8,9]. The kickoff of prevention
trial with BACE1 inhibitor CNP250 represents a new trend in BACE1 inhibitor development [10].
The side effects have arisen from, at least for some of the BACE1 inhibitor drug candidates, the
indiscriminately blocking of almost all functions and substrate cleavages related to BACE1 by the
active site inhibitors [11].
Unlike competitive inhibitors targeting enzyme active site, non-competitive inhibitors binding to
allosteric sites may selectively inhibit specific functions of an enzyme, resulting in less side effects [12].
In our previous work [13], luteolin (
simultaneously bind different parts of BACE1 protein by STD-NMR experiment [14]. We designed the
conjugates to link two segments through proper linkage to improve the potency. Conjugate (Figure 1)
was found in our previous work as a potent, cell-permeable, and non-competitive inhibitor. In this
work, an extensive modification of was designed and performed to optimize it so as to find BACE
inhibitors with optimal drug-like properties.
1) and p-hydroxy-cinnamic acid (2) (Figure 1) were found to
3
3
OH
OH
O
HO
O
O
OH
HO
2
OH
1
OH
OH
O
O
O
O
O
HO
OH
3
Figure 1. The structures of source compounds 1, 2, and 3.
In this paper, we first probed the different positions in flavonoid segment for conjugation of
cinnamoyl segment, in order to avoid the possibly imprecise information derived from STD-NMR.
After the C-7 position of flavone segment was confirmed as the optimal position among all conjugates
in Series I, we further designed and prepared Series II and Series III compounds to optimize the
linker and substituents in the cinnamoyl segment of the conjugate (Figure 2).

Molecules 2020, 25, 102
3 of 21
*
*
O
OH
*
O
O
*
*
Series I compounds
OH
OH
OH
O
O
O
O
linker
HO
Series II compounds
OH
OH
R
O
O
O
O
OH
Series III compounds
OH
Figure 2. The structures of Series I, II, III compounds.
2. Results and Discussion
2.1. Design, Synthesis, and Enzyme Inhibitory Activity of Series I Compounds
Although in our previous work [13] a cell permeable BACE1 inhibitor
3
was discovered with the
STD-NMR, we wished in this study to probe various positions in
for direct conjugation of or through ethylene glycol linkers, to avoid the possibly misleading of
imprecise STD-NMR data.
1
(including 30, 40, 3, 6, and 8 positions)
2
In general, our designed conjugates consisted of a flavone segment, a linker, and a cinnamoyl
segment. However, the synthetic routes and the choice of starting material varied to a great extent for
the different conjugates.
Most luteolin analogs with hydroxyl at different positions as the flavone segment for conjugation
are not commercially available, and thus were assembled from the simple starting materials aromatic
aldehyde and aromatic ketone with different substituting groups, through condensation, to form
chalcone structure under basic conditions, cyclized to dihydroflavone under heating conditions, and
then oxidized to flavonoids with I2/pyridine under heating conditions (Scheme 1 and Supplementary
Materials).
OH
OH
a
R'
b
R
R'
R'
R
H
O
O
10
O
11
9
R'
O
O
O
c
R
R
R,R'= Different substituents
O
13
12
Scheme 1. The key synthetic steps of flavonoid structure. Reagents and conditions: (
a
) 20% KOH aq.
ethanol, room temperature, 52–69%; (b) NaOAc, H2O, ethanol, reflux, 26–82%; (c
55–88%.
) I2, pyridine, 100 ◦C,

Molecules 2020, 25, 102
4 of 21
For the synthesis of conjugate 4j, the flavone segment quercertin (3-OH substituted luteolin)
was prepared by de-glycosylation of a natural compound rutin (auercetin-3-rutinoside). At first,
per-benzylated rutin (14) was subjected to acid hydrolysis due to the poor stability of rutin under
acidic condition. Then, ethylene glycol linker was attached to 3-OH to afford 17. The switch of
benzyl-protecting groups in 17 to methoxymethyl group in combination of the removal of temperorary
silyl protection of 3-O-ethylene-ol over two steps furnished 20, which was ready for the 3-O-conjugation
of cinnamoyl side chain. The switch of protecting group was intended to avoid the stringent deprotection
conditions at the final stage of target compound preparation (Scheme 2).
OBn
OBn
OBn
OBn
OH
OH
BnO
O
BnO
O
HO
O
O
b
a
OH
O
O
OH
O
16
OH
O
Rutinoside
OH
Rutinoside
15
14, Rutin
OH
OBn
HO
O
O
OH
BnO
O
O
d
OBn
c
O
OTBS
O
OTBS
OH
OH
18
17
OMOM
OMOM
MOMO
O
O
OMOM
OH
MOMO
O
f
e
OMOM
OTBS
O
O
OH
OH
O
19
20
Scheme 2. The synthetic◦route of target 4j (1). Reagents and conditions: (
◦
(b) HCl, CH3CH2OH, 70 C, 84% (two steps); (c) BrCH2CH2OTBS, K2CO3, 80 C, 53%; (d) Pd/C,
a
) BnBr, DMF, 50 ◦C;
1,4-cyclohexadiene, 80 ◦C, 79%; (e) MOMCl, DIPEA, DCM, −20 ◦C, 57%; (f) CsF, DMF, 50 ◦C, 83%.
The terminal hydroxyl group in 20 was esterified with 4”-acetyl cinnamic acid by activated ester
method, and then the acetyl in 21 was successively removed under alkaline condition and MOM
groups under acidic condition to afford desired conjugates 4j (Scheme 3).
OMOM
OMOM
h
MOMO
O
O
g
MOMO
O
O
OMOM
OMOM
OH
O
O
O
OAc
O
OH
OH
21
20
O
OH
OMOM
HO
O
O
MOMO
i
OH
O
OMOM
O
4j
O
O
O
OH
OH
OH
OH
O
O
22
Scheme 3. The synthetic route of target 4j (2). Reagents and conditions: (g) 4”-acetyl cinnamic acid,
EDCI, DMAP, TEA, THF, r.t. 45%; (
1:15), r.t. 54%.
h) K2CO3 in MeOH/DCM, r.t. 56%; (i) aq. 38% HCl in AcOH (v/v
As seen from Table 1, the BACE1 inhibition of conjugates 4a
–i with p-hydroxy-cinnamic acid
attached to C-30 and -40 of
1, no matter what the linker was, and was weaker than the conjugation to

Molecules 2020, 25, 102
5 of 21
other positions of
1
. Respectively, the inhibitory effect of conjugates 4j
,
4k, and 4l attached to C-3, C-6,
and C-8 were stronger than C-30 and -40 conjugates but weaker than the C-7 conjugate,
3. Conjugate 4k
was weaker than the flavone segment 1 (without conjugation of 2). The above results demonstrated
the C-7 in flavone segment as the optimal conjugation position, consistent with optimization based
on STD-NMR.
In addition, the acetyl group reduced inhibitory activity for all pairs of compounds (4a vs. 4b
, 4c
vs. 4d, 4g vs. 4h), suggesting the terminal phenol group may play a role in the enzyme inhibition.
4'
3'
8
O
O
6
OH
3
Table 1. The enzyme inhibition of Series I compounds.
No.
4a
Structure
Inhibition Rate at 10 µM (%)
IC50 (µM)
23.9 ± 2.95
-
4b
4c
14.8 ± 7.35
31.8 ± 5.25
39.6 ± 12.5
-
-
-
4d
4e
1.9 ± 10.3
-
-
4f
29.4 ± 5.5

Molecules 2020, 25, 102
6 of 21
Table 1. Cont.
No.
Structure
Inhibition Rate at 10 µM (%)
IC50 (µM)
4g
17.1 ± 6.0
-
4h
36.0 ± 4.2
-
4i
37.0 ± 8.6
-
4j
59.2 ± 6.3
60.6 ± 5.3
6.78 ± 0.83
4k
12.86 ± 1.14
OH
O
O
4l
58.4 ± 10.2
2.47 ± 0.17
OH
O
O
O
OH
1
3
-
-
68.6 ± 8.9
64.8 ± 6.0
7.02 ± 0.85
2.19 ± 0.34

Molecules 2020, 25, 102
7 of 21
2.2. Design, Synthesis, and Activity of Series II Compounds
In the previous study [13], conjugates with one to four glycols units as linkers were tested, and
compound with one glycol unit (i.e., in ) was found to be the optimal. Here, we replaced glycol linkers
3
by other polymethylene diols, trying to optimize the length of linker more carefully (Figure 3).
OH
O
O
O
O
OH
O
n=3~6,8,10
5a~5f
linker
HO
n
HO
OH
OH
OH
O
O
O
O
5g
OH
Figure 3. The design of Series II compounds.
For the synthesis of Series II compounds, the di-phenol groups on the C ring of
1
were protected
with diphenylmethylidene to prepare 23. The preparation of different hydroxyalkyl-7-luteolin could
be realized by the treatment of 23 with TBS-O-hydroxyalkyl tosylate- under K2CO3/acetone, except for
butylene diol, in which case the reagent 4-hydroxybutyl 1-tosylate was subjected to intramolecular
reaction to furnish tetrahydrofuran under the basic condition, possibly due to high reactivity of the
OTs group. Thus, 4-TBS-O-butyl bromide was applied to this conjugation and the key intermediate 24
successfully prepared. After the removal of silyl protective group in 24, the terminal hydroxyl group
in 25 was esterified with 4”-acetyl cinnamic acid in the presence of EDCI to furnish 26, which was then
deprotected under acidic conditions to afford desired conjugates 5a–f (Scheme 4).
O
O
Ph
Ph
TBSO
c
O
O
O
4
24
d
OH
O
O
Ph
Ph
OH
OH
O
Ph
Ph
HO
O
O
HO
O
O
HO
HO
O
O
O
b
a
n
n=3,4,5,6,
8,10
23
25a - f
1, letuolin
OH
O
e
OH
OH
OH
OH
AcO
O
O
Ph
Ph
O
O
O
O
f
O
O
O
n
n
O
O
n=3,4,5,6,8,10
26a - f
n=3,4,5,6,8,10
5a - f
OH
OH
O
Scheme 4. The synthetic route of target 5a
diphenyl ether, 165 ◦C, 70%; (
) TsO(CH2)nOH (n = 3, 5, 6, 8, 10), K2CO3, MeCN, reflux, 28–55%; (
Br(CH2)4OTBS, K2CO3, acetone, reflux, 12 h, 53%; ( ) HF, pyridine, MeCN, r.t. overnight, 81%; (
–f. Reagents and conditions: (a) dichlorodiphenylmethane,
b
c)
d
e
)
4”-acetyl cinnamic acid, EDCI, DMAP, TEA, THF, r.t. 24–58%; (
28–50%.
f) aq. 38% HCl in AcOH (v/v 1:15), r.t.

Molecules 2020, 25, 102
8 of 21
To explore the effect of the length of polymethylene diol linker in the conjugates, a series of
conjugates 5a–f with different length of linkers as well as 5g without linker were prepared.
In general, the inhibitory activity of conjugates 5a–f decreased as the length of linker increased
(Table 2). Although conjugate 5a bearing the shortest length of linker in the series was the most active,
its IC50 was still lower than 3 bearing ethylene glycol linker. Thus, we adhered to the ethylene glycol
linker in the next round of optimization.
Table 2. The enzyme inhibition of Series II compounds.
Compound
n
Inhibition Rate at 10 µM (%)
IC50 (µM)
5a
5b
5c
5d
5e
5f
5g
1
3
4
5
6
8
10
-
81.4 ± 3.8
68.1 ± 5.8
62.6 ± 6.4
42.4 ± 3.2
36.1 ± 2.6
58.2 ± 3.3
41.4 ± 4.4
68.6 ± 8.9
64.8 ± 6.0
5.26 ± 0.72
10.36 ± 1.02
20.63 ± 1.44
27.79 ± 1.34
-
2
7.02 ± 0.85
2.19 ± 0.34
3
2.3. Design, Synthesis, and Activity of Series III Compounds
2.3.1. Design, Synthesis, and Enzyme Inhibition Activity of Series III Compounds
Next, we tried to optimize the other segment (i.e., cinnamoyl segment) in the conjugate, through
replacing the p-hydroxy by other substituents on phenyl ring, and the phenyl, by heterocycles and
cyclohexane (Figure 4, Table 3 and Figure 5). In addition, the ester bond between the cinnamoyl
segment and the linker was replaced by amide group to make this possibly labile bond more stable
(Figure 5).
O
O
O
O
O
HO
OH
6
Figure 4. The structure of compound 6.
Table 3. The structure of compounds 7a–7j and 7q.
OH
O
O
O
O
OH
R
OH
O
Compound
R =
Compound
R =
7a
7b
7c
7d
7e
7f
H
2-OH
3-OH
3,4-diOH
4-F
7g
7h
7i
7j
7q
4-NO2
4-NMe2
4-OMe
4-C(CH3)3
4-OAc
4-Cl

Molecules 2020, 25, 102
9 of 21
OH
OH
R
O
O
O
O
OH
O
O
O
O
R=
7l
7m
7k
O
N
O
O
N
N
7n
7o
7p
HO
OH
OH
HO
O
O
O
O
N
H
HO
8
OH
Figure 5. The structure of compound 7k–7p and 8.
The general synthetic routes of Series III compounds were much similar to Series II. It should be
noted that the acyl chloride method was chosen for compound 7b
,
7d, and 7o when the ester bond
compounds were prepared (Scheme 5).
O
O
Ph
Ph
O
O
O
HO
O
O
Ph
O
Ph
O
HO
b or b'
a
27
23
OH
OH
O
OH
O
O
Ph
Ph
O
O
O
O
O
O
c
R
O
OH
R
O
7a - q
28a - q
OH
OH
O
Scheme 5. The general synthetic route of Series III compounds. Reagents and conditions: (
TsOCH2CH2OH, K2CO3, MeCN, reflux, 57%; (
) carboxylic acid, EDCI, DMAP, TEA, THF, 40 ◦C, or
b’) carboxylic acid, SOCl2, DMF, DCE, 80 ◦C, 2 h and Py, DCM, r.t. 4 h 35–82%; (
) aq. 38% HCl in
AcOH (v/v 1:15), r.t. 31–88%.
a).
b
(
c
As shown in Table 4, conjugate 7k with pyridine in placement of phenol exhibited the most potent
inhibitory activity with an IC50 of 0.15 M in the series, with an approximate 10-fold enhancement
compared with the flavone segment or conjugate . It is worth noting that many conjugates exhibited
an inhibition rate of approximately 60% at 10 M, while possessing 50% inhibition even at low
concentration (e.g., 7k 7l with IC50s of 0.1–0.2 M). It was difficult to reach the maximum inhibition
rate of 80–90% even at 20 M or 50 M. An S-curve for IC50 calculation of several compounds is shown
in the Supplementary Materials.
µ
1
3
µ
,
µ
µ
µ

Molecules 2020, 25, 102
10 of 21
Table 4. The enzyme activity of Series III compounds.
Inhibition rate
at 10 µM (%)
Inhibition rate
at 10 µM (%)
Compound
IC50 (µM)
Compound
IC50 (µM)
7a
7b
7c
7d
7e
7f
7g
7h
7i
57.5 ± 7.5
67.7 ± 12.5
66.7 ± 8.3
66.6 ± 7.1
28.5 ± 7.1
21.3 ± 7.1
73.9 ± 7.1
53.8 ± 4.4
28.9 ± 4.4
37.6 ± 4.4
68.6 ± 8.9
2.49 ± 0.32
7q
7k
7l
7m
7n
7o
7p
8
25.7 ± 4.6
54.4 ± 3.5
59.5 ± 7.1
22.2± 7.1
55.2 ± 7.1
51.9 ± 1.9
56.7 ± 4.4
59.5 ± 4.4
20.5 ± 4.4
64.8 ± 6.0
-
2.27 ± 0.42
0.15 ± 1.01
0.37 ± 0.25
-
1.44 ± 0.18
0.23 ± 0.02
-
-
3.05 ± 0.39
-
0.96 ± 1.55
4.39 ± 0.34
4.15 ± 1.97
-
1.09 ± 1.34
6.58 ± 1.16
-
-
6
1
7j
3
1.87 ± 1.91
The structure activity relationship (SAR) for Series III can be summarized as follows: (1) The
hydroxy on ring B of flavone segment was necessary for activity (possibly through hydrogen bonding).
The inhibitory activity of conjugates decreased obviously when the hydroxy was replaced by hydrogen
or other groups (
The inhibitory activity of conjugates decreased when the hydroxy was replaced by other non-polar
substituents, or by methylation or esterification ( 7b 7c 7d vs. 7a 7i 7q). However, the position and
number of hydroxyls did not have a significant impact on the activity (7b 7c vs. ). (3) The derivatives
with aromatic heterocyclic showed favorable activity, especially the compound with pyridine ring.
3 vs. 6). (2) The hydroxy on the benzene ring of cinnamoyl segment was also important.
3,
,
,
,
,
,
3
(4) When the aromatic or heteroaromatic ring (7k–7l, 7n–7p) was replaced by cyclohexyl group (7m),
the activity decreased significantly.
2.3.2. Cytotoxicity of Series III Compounds
It is crucial for the BACE1 inhibitors to exert their activities at sub-toxic concentration, and thus
their cytotoxicity was assessed in HEK293 cells by 3-[4,5-dimethylthiazol-2-yl]-2,5-diphenyl-tetrazolium
bromide (MTT) assays (Table 5). Among the compounds, 7a
(IC50 > 100 M), and 7c and 7p were weak cytotoxic (IC50 = 90
obvious relationship between the structures and their cytotoxicity.
,
7h
,
7q
,
7k, and
8 were the least cytotoxic
µ
µM). Unfortunately, there was no
Table 5. Cytotoxicity study of Series III compounds.
Compound
IC50 (µM)
Compound
IC50 (µM)
7a
7b
7c
7d
7e
7f
7g
7h
7i
>100
15.6
90
7q
7k
7l
7m
7n
7o
7p
5g
6
>100
>100
9.51
14.4
33
10.3
90
4.21
28.3
>100
39.8
16.7
16.8
9.97
21.8
>100
3.94
20.3
62.4
7j
3
8
1
2.3.3. Enzyme Inhibition in Cells
To assess the cellular BACE1 inhibitory activity of the conjugates, 7a
in APP overexpressing HEK293 cells and their inhibition on the three main A
and A -42—the main amyloidogenic peptides produced by BACE1 cleavage of APP peptide—was
measured by an ELISA-like immunoassay method. levels were normalized to the protein
–
d,
7i, and 7k were incubated
β
species A -38, A -40,
β
β
β
A
β

Molecules 2020, 25, 102
11 of 21
concentration in the lysate in order to rule out differences in total cell number per well of the culture
plate. Additionally, the normalized Aβ level was set to 100% for the DMSO-treated control.
The A
Supplementary Materials (A
and dose-dependently reduced A
-42 level at 25 M. However, 7i and 7k did not reduce A
β
levels upon treatment of different compounds are shown in Figure 6 (A
-38 and A -40). At the higher concentrations (10, 25, and 50
levels. It is worth noting that 7c showed an obvious inhibition
β
-42) and the
β
β
µM), 7b
–d
1
β
Aβ
µ
β
levels, and even increased Aβ-42 levels.
Abeta 42-Compound 7i
Abeta 42-Compound 7k
200
150
100
50
250
200
150
100
50
0
0
0.1 µM 1 µM 5 µM 10 µM 25 µM 50 µM
0.1 µM 1 µM 5 µM 10 µM 25 µM 50 µM
Abeta 42- Luteolin（1）
200
150
100
50
0
0.1 µM 1 µM 5 µM 10 µM 25 µM 50 µM
Figure 6. The normalized A
β-42 level in amyloid precursor protein (APP) overexpressing HEK293
cells after the treatment of 7a
–
d,
7i, 7k, and luteolin compared with DMSO (100%), the known inhibitor
C3 [15].
2.3.4. Enzyme Kinetics Experiment and Enzyme Selectivity
We are interested to know if the most active conjugates derived from
1 and 3 will keep or change
their non-competitive mode of inhibition. The Dixon plot was used to determine the kinetics of 4l
,
7c, and 7k inhibiting BACE1. As shown in Figure 7, the three lines that stand for different substrate

Molecules 2020, 25, 102
12 of 21
concentration intersect on the x-axis, demonstrating that 7c was a non-competitive inhibitor with a Ki
value of 1.2 µM, and that 4l and 7k were in mix-competitive mode (Supplementary Materials).
Figure 7. Kinetic analysis of 7c. The inhibitor was tested in the presence of different concentrations of
substrate: 250 nM (N), 500 nM (ꢀ), and 750 nM (ꢀ). BACE1 (β-site amyloid precursor protein cleaving
enzyme 1) inhibition was analyzed in the presence of different concentrations of sample as follows:
0.1 µM, 0.5 µM, 1.0 µM, 5.0 µM.
As BACE1 is a member of aspartyl protease family, its selective inhibition over other closely
related proteases is required to avoid possible severe side effects. We measured the inhibition of 7c
7k, and 8 on BACE-2 and renin, and found 7c and 7k showed very good selectivity (ca. 2–3 orders of
magnitude) on BACE1 over BACE2 and renin (Table 6).
,
Table 6. The enzyme selectivity of compound 7c, 7k, and 8.
Compound
BACE1 IC50 (µM)
BACE2 IC50 (µM)
Renin IC50 (µM)
7c
7k
8
1.44 ± 0.18
0.15 ± 1.01
4.15 ± 1.97
>100
>100
>100
>100
>100
25.42
To assess the potential of these conjugates as CNS drug candidates, the ability to cross the BBB
(blood-brain barrier) is worthy evaluation. Thus, we calculated cLogP and BBB penetration for several
representative conjugates by an open source software [16]. The result (Figure S2) showed that some of
them (e.g., 7k) may have the ability to cross the BBB.
In summary, the extensive optimization of flavone-cinnamic acid conjugates revealed some more
potent BACE1 inhibitors including 7c and 7k. On the basis of the analysis of multiple bioassay data,
7c exhibited improved activity and weaker toxicity in cells, demonstrating an improvement from the
starting point of this work, conjugate 3. Moreover, 7c also showed non-competitive mode of BACE1
inhibition and selectivity over other related enzymes such as BACE2 and renin, suggesting it may retain
the selective inhibition of BACE1 as an allosteric inhibitor to facilitate the reduction of APP processing
and spare other BACE1 functions. Combining the computational result of LogP and BBB-penetrating
ability, it was demonstrated that such a conjugate may be served as a drug candidate for AD therapy,
and in-depth PD (pharmacodynamic) and PK (pharmacokinetic) studies in animals are warranted.
3. Materials and Methods
3.1. Chemical Synthesis
In this part, the preparation for representative conjugates are shown. Other compounds and
also the NMR and mass spectrometry (MS) data for structural characterization for all compounds are
included in the Supplementary Materials.

Molecules 2020, 25, 102
13 of 21
3.1.1. General Methods
All chemicals and reagents were purchased from Beijing Innochem Science and Technology
Co. Ltd. (Beijing, China), Sinopharm Chemical Reagent Co. Ltd. (Beijing, China), and thin-layer
chromatography (TCI). The 200–300 mesh silica gel used for flash column chromatography was
purchased from Rushanshi Shuangbang Xincailiao Co. Ltd. (Rushan, Shandong, China). Visualization
on TLC (analytical thin layer chromatography) was achieved by the use of UV light (254 and
365 nm). All solvents were purified and dried according to the standard procedures. The purification
was performed on flash column chromatography. The high performance liquid chromatography
(HPLC)-electrospray ionization (ESI)-mass spectrometry (MS) analysis was carried out in an Agilent
1260 Infinity HPLC system (Agilent Technologies, Waldbronn, Germany) equipped with a reversed
phase 4.68
×
50 mm (1.8 µm) XDB-C18 Column and consisted of a binary solvent delivery system,
an auto sampler, a column temperature controller, and a UV detector. The mass spectra were acquired by
a 6120 Quadrupole LC-MS mass spectrometer (Agilent Technologies, Waldbronn, Germany) connected
to the HPLC system via an ESI interface. Proton and carbon magnetic resonance spectra (1H-NMR
and 13C-NMR) were recorded on a Bruker BioSpin AG 300 or 400 MHz spectrometer or Varian 400,
1
500, or 600 MHz spectrometer. H-NMR data were reported as follows: chemical shifts, multiplicity
(s = singlet, d = doublet, t = triplet, q = quartet, m = multiplet), coupling constant(s) in Hz, integration.
All tested compounds 4a
–
l
,
5a
–
g
,
6
,
7a
–
q
, and
8
were
≥
95% pure by HPLC (column C18 4.6
×
250
mm 5 m, mobile phase: acetonitrile–water (70:30 or 80:20 or 90:10 in 10 min), flow rate 1.0 mL/min,
µ
detected at 254 nm).
3.1.2. Synthesis of Compound 4j
7-(benzyloxy)-2-(3,4-bis(benzyloxy)phenyl)-3,5-dihydroxy-4H-chromen-4-one (16): To a solution of rutin
(610 mg, 1 mmol) in DMF (30 mL), BnBr (684 mg, 4 mmol) and K2CO3 (552 mg, 4 mmol) were added.
The solution was stirred at 50 ◦C for 3 h. Water (100 mL) was added, and the solution was cooled to
0 ◦C for overnight. The solid 15 was collected by suction filtration and dissolved in 95% alcohol (20
mL), and hydrochloric acid (3 mL) was added. After stirring for 2 h at 70 ◦C, solid was precipitated in
the solution. Then, compound 16 (740 mg, 84%) was collected by suction filtration after the solution
was cooled to r.t.
7-(benzyloxy)-2-(3,4-bis(benzyloxy)phenyl)-3-(2-((tert-butyldimethylsilyl)oxy)ethoxy)-5-hydroxy-4H-chromen-
4-one (17): To a solution of 16 (147 mg, 0.26 mmol) in DMF (5 mL), K2CO3 (54 mg, 0.39 mmol) and
(2-bromoethoxy)(tert-butyl)dimethylsilane (93 mg, 0.39mmol) were added. After stirring at 80 ◦C for
12 h, water (20 mL) was added and extracted with ethyl acetate (25 mL
gathered, dried over Na2SO4, filtered, and concentrated in vacuo. The crude product was purified by
×
2). The organic layer was
column chromatography (PE/acetone = 10:1) to give 17 as yellow solids (101 mg, 52.7%).
3-(2-((tert-butyldimethylsilyl)oxy)ethoxy)-2-(3,4-dihydroxyphenyl)-5,7-dihydroxy-4H-chromen-4-one (18): To
a mixture of 17 (100 mg, 0.14 mmol) and Pd/C (150 mg) in THF (5 mL) and ethanol (5 mL),
◦
1,4-cyclohexadiene (659
µ
L, 7 mmol) was added. After stirring at 80 C for 12 h, the solution
was concentrated in vacuo after suction filtration. The crude product was purified by column
chromatography (PE/acetone/THF = 9:2:1) to give 18 as yellow solids (49 mg, 78.6%).
2-(3,4-bis(methoxymethoxy)phenyl)-3-(2-((tert-butyldimethylsilyl)oxy)ethoxy)-5-hydroxy-7-(methoxymethoxy)-
4H-chromen-4-one (19): The starting material 18 (310 mg, 0.67 mmol) was dissolved in DCM (5 mL), and
MOMCl (0.18 mL, 2.16 mmol) was added at
−
10 ◦C. After 10 mins stirring, DIEA (0.44 mL, 2.16 mmol)
◦
was added slowly and the suspension heated to 0 C. Saturated sodium bicarbonate (10 mL) was
added to quench reaction after 1 h. The dichloromethane layer was separated, then the aqueous phase
was extracted with dichloromethane (10 mL). The organic phase was merged, then washed with
water and brine, dried over Na2SO4, filtered, and concentrated in vacuo. The residue was purified by
column chromatography (petroleum ether/acetone = 10:1) to give 19 as yellow solids (230 mg, 57.4%).

Molecules 2020, 25, 102
14 of 21
2-(3,4-bis(methoxymethoxy)phenyl)-5-hydroxy-3-(2-hydroxyethoxy)-7-(methoxymethoxy)-4H-chromen-4-one
20): A solution of compound 19 (230 mg, 0.39 mmol) and CsF (304 mg, 2 mmol) in dry DMF (2 mL)
was heated to 100 ◦C for 2 h. The resulting mixture was diluted with water (5 mL) and extracted with
ethyl acetate (10 mL 3). The organic layer was dried over Na2SO4, filtered, and concentrated in
(
×
vacuo. The crude product was purified by column chromatography (petroleum ether/acetone = 5:1) to
give 20 as yellow solid (154 mg, 83.0%).
2-((2-(3,4-bis(methoxymethoxy)phenyl)-5-hydroxy-7-(methoxymethoxy)-4-oxo-4H-chromen-3-yl)oxy)ethyl
(E)-3-(4-acetoxyphenyl)acrylate (21): To a solution of 4-acetoxycinnamic acid (41 mg, 0.2 mmol) in THF
(1 mL), EDCI (38 mg, 0.2 mmol), DMAP (6 mg, 0.05 mmol), and Et3N (45 µL, 0.3 mmol) were added.
Then, 16a (27 mg, 0.066 mmol) in THF (1 mL) was added under nitrogen. The solution was stirred
at r.t. for 12 h. The organic layer was concentrated in vacuo. The residue was purified by column
chromatography (petroleum ether/EtOAc = 3:1) to give 21 as white solid (24 mg, 45.0%).
2-((2-(3,4-bis(methoxymethoxy)phenyl)-5-hydroxy-7-(methoxymethoxy)-4-oxo-4H-chromen-3-yl)oxy)ethyl
(E)-3-(4-hydroxyphenyl)acrylate (22): Compound 21 (24 mg, 0.036 mmol) was dissolved in a solution of
CH2Cl2 (1 mL) and a K2CO3 (1.38 mg, 0.01 mmol) MeOH solution (1 mL) was added under argon
at room temperature. After stirring for 12 h, the resulting mixture was concentrated in vacuo and
purified by column chromatography (DCM/acetone = 30:1) to give 22 as yellow solid (12 mg, 56.2%).
2-((2-(3,4-dihydroxyphenyl)-5,7-dihydroxy-4-oxo-4H-chromen-3-yl)oxy)ethyl(E)-3-(4-hydroxyphenyl)acrylate
(4j): To a solution of 22 (12 mg, 0.019 mmol) in 0.2 mL acetone, 38% HCl/AcOH (v/v = 1:15, 1.8 mL)
mixture was added at room temperature. The solution was stirred at room temperature. After 24 h,
yellow solid precipitated and the precipitate was filtered off, washed with water, and dried to give 4j
(5.1 mg, 53.5%) as yellow solid.
3.1.3. Synthesis of Compound 5a–f
Luteolin 3’,4’-O-diphenylmethylidene (23): Dichlorodiphenylmethane (20 µL, 1.1 mmol) was added to a
stirred mixture of luteolin (20 mg, 0.07 mmol) in diphenyl ether (1.4 mL), and the reaction mixture was
heated at 165 ◦C for 2.5 h. After being cooled to room temperature, the reaction solution was poured
into petroleum ether (20 mL), and the precipitation was filtered and washed with petroleum ether.
The filter residue was dissolved into acetone, and the resulting solution was concentrated and purified
by column chromatography (petroleum ether/EtOAc = 4:1) to give 45 as yellow solid (22 mg, 70%).
7-(4-((tert-butyldimethylsilyl)oxy)butoxy)-2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4H-chromen-4-
one (24): TBSCl (452 mg, 3.0 mmol) and imidazole (204 mg, 3.0 mmol) were added to a solution of
4- bromobutanol (300 mg, 2.0 mmol) in DMF (3 mL) at room temperature. After stirring overnight,
the resulting mixture was poured into ice-water, and extracted with EtOAc. The organic layer was
washed with saturated aqueous NaHCO3 and NaCl successively, dried over Na2SO4, filtered, and
concentrated in vacuo to give Br(CH2)4OTBS crude. The crude was dissolved in acetone (3 mL), then
23 (225 mg, 0.5 mmol) and K2CO3 (276 mg, 2 mmol) were added. The reaction mixture was then
refluxed overnight and concentrated in vacuo. The residue was purified by column chromatography
(petroleum ether/acetone = 7:1) to give 24 as yellow solid (136 mg, 42.8%).
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-(3-hydroxypropoxy)-4H-chromen-4-one (25a): Potassium
carbonate (143 mg, 1.0 mmol) was added to a solution of 23 (315 mg, 0.7 mmol) and TsO(CH2)3OH
(230 mg, 1.0 mmol) in CH3CN (4 mL) at room temperature. The reaction mixture was then refluxed
overnight. The resulting mixture was poured into ice-water, adjusted to neutral pH with aqueous
HCl (5%), and extracted with EtOAc. The organic layer was washed with brine, dried over Na2SO4,
filtered, and concentrated in vacuo. The residue was purified by column chromatography (petroleum
ether/acetone = 5:1) to give 25a as yellow solid (218 mg, 34.2%).

Molecules 2020, 25, 102
15 of 21
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-((5-hydroxypentyl)oxy)-4H-chromen-4-one
(25c):
Compound 25c (60 mg, 27.8%) was synthesized from TsO(CH2)5OH (104 mg, 0.4 mmol), according to
the procedure used to prepare 25a, obtained as yellow solid.
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-((6-hydroxyhexyl)oxy)-4H-chromen-4-one
(25d):
Compound 25d (132 mg, 47.5%) was synthesized from TsO(CH2)6OH (133 mg, 0.49 mmol), according
to the procedure used to prepare 25a, obtained as yellow solid.
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-((8-hydroxyoctyl)oxy)-4H-chromen-4-one
(25e):
Compound 25e (237 mg, 55.3 %) was synthesized from TsO(CH2)8OH (288 mg, 0.96 mmol), according
to the procedure used to prepare 25a, obtained as yellow solid.
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-((10-hydroxydecyl)oxy)-4H-chromen-4-one
(25f):
Compound 25f (212 mg, 49.9%) was synthesized from TsO(CH2)10OH (340 mg, 1.04 mmol), according
to the procedure used to prepare 25a, obtained as yellow solid.
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-(4-hydroxybutoxy)-4H-chromen-4-one (25b): HF
(743
µL, 17.1 mmol) and pyridine (1.4 mL, 17.1 mmol) were added to a solution of 24 (36 mg,
0.057 mmol) in MeCN (1 mL) at room temperature. After stirring overnight, the reaction was quenched
by 1N hydrochloric acid, and extracted with EtOAc. The organic layer was washed with saturated
aqueous NaHCO3 and NaCl successively, dried over Na2SO4, filtered, and concentrated in vacuo to
give 25b (24 mg, 80.7%) as yellow solid.
(E)-3-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)propyl
3-(4-acetoxyphenyl)acrylate (26a): Compound 26a (34 mg, 24.4%) was synthesized from 25a
(101 mg, 0.2 mmol) according to the procedure used to prepare 17. The crude product was purified by
column chromatography (PE/acetone = 5:1) to give 26a as yellow solids.
(E)-4-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)butyl
3-(4-acetoxyphenyl)acrylate (26b): Compound 26b (19 mg, 58.1%) was synthesized from 25b
(24 mg, 0.046 mmol) according to the procedure used to prepare 17. The crude product was purified by
column chromatography (PE/DCM/acetone = 10:10:1) to give 25b as yellow solids.
(E)-5-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)pentyl
3-(4-acetoxyphenyl)acrylate (26c): Compound 26c (17 mg, 36.1%) was synthesized from 25c
(35 mg, 0.065 mmol) according to the procedure used to prepare 17. The crude product was purified by
column chromatography (PE/DCM/acetone = 10:10:1) to give 26c as yellow solids.
(E)-6-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)hexyl
3-(4-acetoxyphenyl)acrylate (26d): Compound 26d (35 mg, 33.8%) was synthesized from 25d
(75 mg, 0.14 mmol) according to the procedure used to prepare 17. The crude product was purified by
column chromatography (PE/DCM/acetone = 10:10:1) to give 26d as yellow solids.
(E)-8-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)octyl
3-(4-acetoxyphenyl)acrylate (26e): Compound 26e (52 mg, 40.1%) was synthesized from 25e
(100 mg, 0.17 mmol) according to the procedure used to prepare 17. The crude product was purified by
column chromatography (PE/DCM/THF = 20:20:3) to give 26e as yellow solids.
(E)-10-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)decyl
3-(4-acetoxyphenyl)acrylate (26f): Compound 26f (44 mg, 30.7%) was synthesized from 25f
(110 mg, 0.18 mmol) according to the procedure used to prepare 17. The crude product was purified by
column chromatography (PE/DCM/THF = 20:20:3) to give 26f as yellow solids.
(E)-3-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)propyl 3-(4-hydroxyphenyl)acrylate
(5a): Compound 5a (12 mg, 48.9%) was synthesized from 26a (34 mg, 0.05 mmol) according to

Molecules 2020, 25, 102
16 of 21
the procedure used to prepare 4j. The crude product was purified by column chromatography
(chloroform/methanol = 35:1) to give 5a as yellow solids.
(E)-4-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)butyl 3-(4-hydroxyphenyl)acrylate
(5b): Compound 5b (5.2 mg, 36.8%) was synthesized from 26b (19 mg, 0.028 mmol), according to the
procedure used to prepare 5a, to give 5b as yellow solids.
(E)-5-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)pentyl 3-(4-hydroxyphenyl)acrylate
,
(5c): Compound 5c (5.1 mg, 42.8%) was synthesized from 26c (17 mg, 0.023 mmol), according to the
procedure used to prepare 5a, to give 5c as yellow solids.
(E)-6-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)hexyl 3-(4-hydroxyphenyl)acrylate
5d): Compound 5d (6.9 mg, 27.6%) was synthesized from 26d (35 mg, 0.047 mmol), according to the
(
procedure used to prepare 5a, to give 5d as yellow solids.
(E)-8-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)octyl 3-(4-hydroxyphenyl)acrylate (5e):
Compound 5e (8.2 mg, 29.3%) was synthesized from 26e (38 mg, 0.05 mmol), according to the procedure
used to prepare 5a, to give 5e as yellow solids.
(E)-10-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)decyl 3-(4-hydroxyphenyl)acrylate
(5f): Compound 5f (7.3 mg, 27.6%) was synthesized from 26f (36 mg, 0.045 mmol), according to the
procedure used to prepare 5a, to give 5f as yellow solids.
3.1.4. Synthesis of Compound 7a–q
2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-7-(2-hydroxyethoxy)-4H-chromen-4-one (27): Compound
27 (195 mg, 57%) was synthesized from 23 according to the procedure used to prepare 25a. The crude
product was purified by column chromatography (CH2Cl2/acetone = 10:1) to give 27 as yellow solids.
2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl cinnamate (28a):
Compound 28a (28 mg, 57.6%) was synthesized from 27 (40 mg, 0.08 mmol) and cinnamic acid (35 mg,
0.24 mmol) according to the procedure used to prepare 21. The crude product was purified by column
chromatography (PE/acetone = 5:1) to give 28a as yellow solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(2-acetoxyphenyl)acrylate (28b): To a solution of 2-acetoxycinnamic acid (54 mg, 0.26 mmol)
in dichloroethane (5 mL), SOCl2 (100
stirred at 80 ◦C for 1 h, the organic solvent was removed under vacuum, and the residue dissolved in
dry CH2Cl2 (4 mL). Pyridine (31
L, 0.38 mmol) was added at 0 ◦C, then 27 (64 mg, 0.13 mmol) was
µL, 2.6 mmol) and DMF (1d) were added. The solution was
µ
added dropwise. The resulting mixture was transferred to r.t. and stirred for 4 h. The organic solvent
was washed with 1M hydrochloric acid and brine, dried over Na2SO4, filtered, and concentrated in
vacuo. The crude product was purified by column chromatography (PE/acetone = 5:1) to give 28b as
yellow solid (58 mg, 50.3%).
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(3-acetoxyphenyl)acrylate (28c): Compound 28c (48 mg, 35.2%) was synthesized from 27 (100
mg, 0.2 mmol) and 3-acetoxycinnamic acid (124 mg, 0.6 mmol), according to the procedure used to
prepare 21. The crude product was purified by column chromatography (PE/acetone = 5:1) to give 28c
as yellow solids.
(E)-4-(3-(2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethoxy)-3-oxoprop
-1-en-1-yl)-1,2-phenylene diacetate (28d): Compound 28d (24 mg, 46.3%) was synthesized from 27 (35 mg,
0.07 mmol) and 3,4-diacetoxycinnamic acid (28 mg, 0.11 mmol), according to the procedure used to
prepare 28b. The crude product was purified by column chromatography (PE/acetone = 4:1) to give
28d as yellow solids.

Molecules 2020, 25, 102
17 of 21
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(4-fluorophenyl)acrylate (28e): Compound 28e (37 mg, 44.3%) was synthesized from 27 (64 mg,
0.13 mmol) and 4-fluorocinnamic acid (65 mg, 0.39 mmol), according to the procedure used to prepare
21. The crude product was purified by column chromatography (PE/acetone = 5:1) to give 28e as
white solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(4-chlorophenyl)acrylate (28f): Compound 28f (44 mg, 55.6%) was synthesized from 27 (60 mg,
0.12 mmol) and 4-chlorocinnamic acid (66 mg, 0.36 mmol), according to the procedure used to prepare
21. The crude product was purified by column chromatography (PE/acetone = 5:1) to give 28f as
yellow solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(4-nitrophenyl)acrylate (28g): Compound 28g (34 mg, 55.8%) was synthesized from 27 (45 mg,
0.09mmol) and 4-nitrocinnamic acid (52 mg, 0.27 mmol), according to the procedure used to prepare
21. The crude product was purified by column chromatography (PE/acetone = 5:1) to give 28g as
white solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(4-(dimethylamino)phenyl)acrylate (28h): Compound 28h (24 mg, 45.1%) was synthesized
from 27 (40 mg, 0.08 mmol) and 4-dimethylaminocinnamic acid (46 mg, 0.24 mmol), according to the
procedure used to prepare 21. The crude product was purified by column chromatography (PE/acetone
= 5:1) to give 28h as white solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-(4-methoxyphenyl)acrylate (28i): Compound 28i (44 mg, 42.1%) was synthesized from 27
(80 mg, 0.16 mmol) and 4-methoxycinnamic acid (86 mg, 0.48 mmol), according to the procedure used
to prepare 21. The crude product was purified by column chromatography (PE/acetone = 5:1) to give
28i as yellow solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-(tert-butyl)
phenyl)acrylate (28j): Compound 28j (31 mg, 48.4%) was synthesized from 27 (51 mg, 0.1 mmol) and
4-tert-butylcinnamic acid (61 mg, 0.3 mmol), according to the procedure used to prepare 21. The crude
product was purified by column chromatography (PE/acetone = 5:1) to give 28j as white solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(pyridin-3-yl)
acrylate (28k): Compound 28k (63 mg, 63.0%) was synthesized from 27 (80 mg, 0.16 mmol) and
(E)-3-(pyridin-3-yl)acrylic acid (46 mg, 0.48mmol), according to the procedure used to prepare 21. The
crude product was purified by column chromatography (PE/acetone = 3:1) to give 28k as yellow solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(furan-3-yl)
acrylate (28l): Compound 28l (36 mg, 36.6%) was synthesized from 27 (80 mg, 0.16 mmol) and
(E)-3-(furan-3-yl)acrylic acid (66 mg, 0.48 mmol), according to the procedure used to prepare 21. The
crude product was purified by column chromatography (PE/acetone = 5:1) to give 28l as white solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl
3-cyclohexylacrylate (28m): Compound 28m (43 mg, 42.7%) was synthesized from 27 (80 mg,
0.16 mmol) and (E)-3-cyclohexylacrylic acid (74 mg, 0.48 mmol), according to the procedure used to
prepare 21. The crude product was purified by column chromatography (PE/DCM/acetone = 20:20:1)
to give 28m as yellow solids.
(E)-2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(3,5-dimethyl
-1H-pyrazol-1-yl)acrylate (28n): Compound 28n (42 mg, 81.6%) was synthesized from 27 (41 mg, 0.08
mmol) and 3-(3,5-dimethyl-1H-pyrazol-1-yl)propanoic acid (41 mg, 0.24 mmol), according to the

Molecules 2020, 25, 102
18 of 21
procedure used to prepare 21. The crude product was purified by column chromatography (PE/acetone
= 4:1) to give 28m as yellow solids.
2-((2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 4-acetoxybenzoate
(28o): Compound 28o (24 mg, 53.7%) was synthesized from 27 (31 mg, 0.07 mmol) and 4-hydroxybenzoic
acid (29 mg, 0.21 mmol), according to the procedure used to prepare 28b. The crude product was
purified by column chromatography (PE/acetone = 5:1) to give 28o as yellow solids.
(E)-2-(2-(2,2-diphenylbenzo[d][1,3]dioxol-5-yl)-5-hydroxy-4-oxo-4H-chromen-7-yloxy)ethyl
3-(4-acetoxyphenyl)acrylate (28q): Compound 28q (76 mg, 55.7%) was synthesized from 27
(100 mg, 0.2 mmol) and 4-acetoxycinnamic acid (124 mg, 0.6 mmol), according to the procedure used
to prepare 21. The crude product was purified by column chromatography (PE/acetone = 5:1) to give
28q as yellow solids.
2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl cinnamate (7a): 28a (9 mg,
0.015 mmol) was dissolved in a solution of acetone (0.1 mL) and 38% HCl/AcOH (v/v = 1:15, 0.5 mL).
The mixture was stirred at room temperature for 20 h. Th resulting mixture was poured into ice-water
and extracted with EtOAc. The organic layer was washed with brine, dried over anhydrous Na2SO4,
and concentrated in vacuo. The residue was purified by column chromatography (DCM/MeOH = 50:1)
to give 7a as yellow solid (2.4 mg, 32.6%).
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(2-acetoxyphenyl)acrylate (7b):
Compound 7b (26.7 mg, 75.8%) was synthesized from 28b (49 mg, 0.072 mmol) according to the
procedure used to prepare 7a, obtained as brown solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(3-acetoxyphenyl)acrylate (7c):
Compound 7c (12.8 mg, 45.6%) was synthesized from 28c (40 mg, 0.059 mmol) according to the
procedure used to prepare 7a, obtained as yellow solids.
(E)-4-(3-(2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethoxy)-3-oxoprop-1-en-1-yl)-1,2
-phenylene diacetate (7d): Compound 7d (2.2 mg, 37.3%) was synthesized from 28d (6 mg, 0.012
mmol), according to the procedure used to prepare 7a. The crude product was purified by column
chromatography (DCM/MeOH = 20:1) to give 7d as white solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-fluorophenyl)acrylate (7e):
Compound 7e (9.3 mg, 62.7%) was synthesized from 28e (23 mg, 0.031 mmol) according to the procedure
used to prepare 7a, obtained as light-yellow solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-chlorophenyl)acrylate (7f):
Compound 7f (26 mg, 87.7%) was synthesized from 28f (40 mg, 0.06 mmol) according to the procedure
used to prepare 7a without post process, obtained as white solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-nitrophenyl)acrylate (7g):
Compound 7g (4.1 mg, 63.5%) was synthesized from 28g (9 mg, 0.013 mmol) according to the procedure
used to prepare 7a, obtained as white solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-(dimethylamino)phenyl)
acrylate (7h): Compound 7h (5.1 mg, 49.7%) was synthesized from 28h (15 mg, 0.02 mmol) according to
the procedure used to prepare 7a, obtained as yellow solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-methoxyphenyl)acrylate (7i):
Compound 7i (18.8 mg, 57.3%) was synthesized from 28i (44 mg, 0.067 mmol) according to the
procedure used to prepare 7a, obtained as white solids
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-(tert-butyl)phenyl)acrylate
(7j): Compound 7j (8.8 mg, 46.3%) was synthesized from 28j (25 mg, 0.037 mmol) according to the
procedure used to prepare 7a, obtained as white solids.

Molecules 2020, 25, 102
19 of 21
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(pyridin-3-yl)acrylate (7k):
Compound 7k (12 mg, 57.3%) was synthesized from 28k (20 mg, 0.067 mmol) according to the procedure
used to prepare 7a, obtained as yellow solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(furan-3-yl)acrylate (7l):
Compound 7l (4.4 mg, 42.5%) was synthesized from 28l (14 mg, 0.023 mmol) according to the
procedure used to prepare 7a, obtained as light-yellow solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-cyclohexylacrylate (7m):
Compound 7m (19.2 mg, 60.6%) was synthesized from 28m (43 mg, 0.068 mmol) according to
the procedure used to prepare 7a, obtained as white solids.
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(3,5-dimethyl-1H-pyrazol-1-
yl)acrylate (7n): Compound 7n (14.2 mg, 59.2%) was synthesized from 28n (32 mg, 0.05 mmol) according
to the procedure used to prepare 7a, obtained as yellow solids.
2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 4-hydroxybenzoate (7o): Compound
7o (5.2 mg, 57.8%) was synthesized from 28o (12 mg, 0.02 mmol) according to the procedure used to
prepare 7a, obtained as yellow solids.
2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-hydroxyphenyl)propanoate (7p):
To a solution of compound 28p (24 mg, 0.038 mmol) in THF (1 mL) and EtOH (1 mL), 10% Pb/C (16 mg,
0.015 mmol) and 1,4-cyclohexadiene (141 µL, 1.5 mmol) were added. The solution was stirred reflux for
5 h. The resulting solution was concentrated after filtrating and purified by column chromatography
(DCM/MeOH = 40:1) to give 7p as yellow solid (11 mg, 61.4%).
(E)-2-((2-(3,4-dihydroxyphenyl)-5-hydroxy-4-oxo-4H-chromen-7-yl)oxy)ethyl 3-(4-acetoxyphenyl)acrylate (7q):
To a solution of compound 28q (100 mg, 0.15 mmol) in DCM (5 mL), CF3COOH (0.55 mL, 7.5 mmol) was
added. The solution was stirred at room temperature for 12 h. The resulting solution was concentrated
and purified by column chromatography (DCM/MeOH = 30:1) to give 7q as yellow solid (16.7 mg,
31.4%).
3.2. In Vitro BACE1 Enzyme Assay
The BACE1 FRET assay kit was purchased from the PanVera Co. (Invitrogen, USA). The assay
was carried out according to the supplied manual with modifications. Briefly, assays were performed
in triplicate in 384-well black plates with a mixture of 5
µL of BACE1 (1.0 U/mL), 5
µL of the substrate
(750 nM, Rh-EVNLDAEFK-Quencherin 50 mM, ammonium bicarbonate), and 5
µL of compound
dissolved in 10% DMSO. The fluorescence intensity was measured with a TECAN infinite 200 microplate
reader for 60 min at 25 ◦C in the dark. The mixture was irradiated at 544 nm and the emission intensity
recorded at 590 nm. The percent inhibition (%) was obtained by the following equation: Inhibition % =
(1
−
SS/SC)
×
100%, where SC is the slope of fluorescence change of the control (enzyme, buffer, and
substrate) during 60 min, and SS is the slope of fluorescence change of the tested samples (enzyme,
sample solution, and substrate) during 60 min of measurement. IC50 values were calculated from
the nonlinear curve fitting of percentage inhibition against inhibitor concentration using Prism 3.0
software (GraphPad Software, San Diego, CA, USA).
3.3. Inhibition of Aβ Production in APP Overexpressed Cells
HEK293 cells stably overexpressing human APP695 were plated in a poly-d-lysine-coated 96-well
plates and grown to a density of 80–90%. Compounds were dissolved in DMSO to make a 10 mM stock
solution and diluted in DMEM complete medium to the final concentrations: 0.1, 1.0, 5.0, 10.0, 25.0,
and 50.0
BACE1 inhibitor (C3, also known as BACE inhibitor IV) as a positive control. After 23 h of incubation,
the cell supernatants were directly used for measurement in the V-Plex A Peptide Panel 1 (6E10) Kit
µM. DMSO was used at a 1:200 dilution as a negative control and a commercially available
β

Molecules 2020, 25, 102
20 of 21
from Meso Scale Diagnostics (Rockville, MD, USA) for measuring A
Cells were washed with PBS and lysed in Triton X100 lysis buffer for subsequent protein concentration
β
38,
−
40, and
−
42 simultaneously.
(BCA) measurement.
3.4. Kinetic Analysis
The Dixon plot is a graphical method (plot of 1/enzyme velocity (1/V) against inhibitor concentration
(I)) for determination of the type of enzyme inhibition, which was used to determine the dissociation or
inhibition constant (Ki) for the enzyme inhibitor complex [17]. The Dixon plots for BACE1 inhibition
were obtained in the presence of various concentrations of BACE1 substrate (250, 500, 750 nM) and the
concentrations of 4l, 7c, and 7k as follows: 0.1 µM, 0.5 µM, 1.0 µM. In this way, the inhibition constants
(Ki) of 4e were determined by interpretation of Dixon plots, where the value of the x-axis represents
−Ki when 1/V = 0.
3.5. MTT Assays
The cytotoxicity was examined by using 3-[4,5-dimethylthiazol-2-yl]-2,5-diphenyl-tetrazolium
bromide (MTT) assay. HEK293T cells were seeded with complete DMEM into 96-well plates (104/well,
100 L/well), incubated at 37 ◦C in a humidified atmosphere with 5% CO2 for 24 h. All the compounds
were diluted with the phenol red-free DMEM at a specific concentration. After 24 h of exposure to
different concentrations of compound, the supernatant was removed and then 20% (v/v) MTT (5 mg/mL)
diluted with fresh culture medium was added into each well and incubated for 4 h. Cells were lysed
with 100 µL dimethyl sulfoxide (DMSO) and shaken for 10 min at room temperature. The absorbance
in each well was detected at a wavelength of 490 nm using a Universal Microplate Reader (ELX 800 lv,
BIO-TEK Instruments, Inc., Winooski, VT, USA).
Supplementary Materials: The following are available online at http://www.mdpi.com/1420-3049/25/1/102/s1:
Scheme S1. Synthesis of compound 4a–4h; Scheme S2. Synthesis of compound 4i; Scheme S3. Synthesis of
compound 4k; Scheme S4. Synthesis of compound 4l; Scheme S5. Synthesis of compound 5g; Scheme S6.
Synthesis of compound ; Scheme S7. Synthesis of compound ; Figure S1. The normalized A 38 level in APP
overexpressing HEK293 cells after the treatment of 7a 7d 7i 7k, and luteolin compared with DMSO (100%) the
known inhibitor C3; Figure S2 The normalized A 38 level in APP overexpressing HEK293 cells after the treatment
of 7a 7d 7i 7k, and luteolin compared with DMSO (100%) and the known inhibitor C3; Figure S3 Kinetic analysis
of 4l; Figure S4 Kinetic analysis of 7k; Figure S5. S-curve for IC50 calculation of compounds 7a 7d 7p 7h 7g 7k,
and ; Table S1. The NMR data and MS data of compounds shown in the text; Table S2. ClogP and BBB level
calculation by http://admet.scbdd.com/
6
8
β
–
,
,
β
–
,
,
,
,
,
,
,
8
Author Contributions: D.-Y.S. performed chemical synthesis and some enzyme experiments; C.C. carried out
the cytotoxicity test and enzyme selectivity test; K.M. carried out the study of enzyme inhibition activity in
cells; writing—original draft preparation, D.-Y.S. and C.C.; writing—review and editing, W.-S.F. and J.H.; W.-S.F.
planned, designed, and organized the whole research of this study. All authors have read and agreed to the
published version of the manuscript.
Funding: This research was funded by NSFC, grant nos. 81273406 (W.-S.F.) and 31371331 (J.H.), and by the Drug
Innovation Major Project Grant, grant nos. 2018ZX09711001-001-001 and 2018ZX09711001-001-003.
Acknowledgments: The authors cordially thank Stefan Lichtenthaler, Technical University of Munich for his
generous support to this work.
Conflicts of Interest: The authors declare no conflict of interest regarding the publication of this paper.
References
1.
Silva, T.; Reis, J.; Teixeira, J.C.S.; Borges, F. Alzheimer’s disease, enzyme targets and drug discovery struggles:
From natural products to drug prototypes. Ageing. Res. Rev 2014, 15, 116–145. [CrossRef] [PubMed]
Dourlen, P.; Kilinc, D.; Malmanche, N.; Chapuis, J.; Lambert, J.C. The new genetic landscape of Alzheimer’s
2.
disease: From amyloid cascade to genetically driven synaptic failure hypothesis? Acta Neuropathol. 2019
138, 221–236. [CrossRef] [PubMed]
,
3.
Karran, E.; Mercken, M.; De, S.B. The amyloid cascade hypothesis for Alzheimer’s disease: An appraisal for
the development of therapeutics. Nat. Rev. Drug. Disc. 2011, 10, 698–712. [CrossRef] [PubMed]

Molecules 2020, 25, 102
21 of 21
4.
5.
Cline, E.; Bicca, M.A.; Viola, K.L.; Klein, W.L. The amyloid-
decade. J. Alzheimers. Dis. 2018, 64, S567–S610. [CrossRef] [PubMed]
Vassar, R.; Kuhn, P.-H.; Haass, C.; Kennedy, M.E.; Rajendran, L.; Wong, P.C.; Lichtenthaler, S. Function,
therapeutic potential and cell biology of BACE proteases: Current status and future prospects. J. Neurochem.
2014, 130, 4–28. [CrossRef] [PubMed]
β
oligomer hypothesis: Beginning of the third
6.
Coimbra, J.R.M.; Marques, D.F.F.; Baptista, S.J.; Pereira, C.M.F.; Moreira, P.I.; Dinis, T.C.P.; Santos, A.E.;
Salvador, J.A.R. Highlights in BACE1 inhibitors for Alzheimer’s disease treatment. Front. Chem. 2018, 6,
178–188. [CrossRef] [PubMed]
7.
8.
9.
Weller, J.; Budson, A. Current understanding of Alzheimer’s disease diagnosis and treatment. F1000Research
2018, 7, 1161–1170. [CrossRef] [PubMed]
Hu, X.; Das, B.; Hou, H.; He, W.; Yan, R. BACE1 deletion in the adult mouse reverses preformed amyloid
deposition and improves cognitive functions. J. Exp. Med. 2018, 3, 927–940. [CrossRef] [PubMed]
Keskin, A.D.; Kekuš, M.; Adelsberger, H.; Neumann, U.; Shimshek, D.R.; Song, B.; Zott, B.; Peng, T.; Förstl, H.;
Staufenbiel, M.; et al. BACE inhibition-dependent repair of Alzheimer’s pathophysiology. Proc. Natl. Acad.
Sci. USA 2017, 114, 8631–8636. [CrossRef] [PubMed]
10. Justyna, A.; Zakaria, J.A.D.; Vassar, R.J. A promising, novel, and unique BACE1 inhibitor emerges in the
quest to prevent Alzheimer’s disease. EMBO Mol. Med. 2018, 10, 1–3.
11. Morris, G.P.; Clark, I.A.; Vissel, B. Questions concerning the role of amyloid-β in the definition, aetiology
and diagnosis of Alzheimer’s disease. Acta. Neuropathol. 2018, 136, 663–689. [CrossRef] [PubMed]
12. Williams, P.; Sorribas, A.; Howes, M.J. Natural products as a source of Alzheimer’s drug leads. Nat. Prod. Rep.
2010, 28, 48–77. [CrossRef] [PubMed]
13. Fang, W.-S.; Sun, D.-Y.; Yang, S.; Cheng, C.; Moschke, K.; Li, T.Q.; Sun, S.S.; Stefan, L.; Huang, J.; Wang, Y.H.
Discovery of a series of selective and cell permeable beta-secretase (BACE1) inhibitors by fragment linking
with the assistance of STD-NMR. Bioorg. Chem. 2019, 92, 1–7. [CrossRef] [PubMed]
14. Krishna, N.R.; Jayalakshmi, V. Quantitative analysis of STD-NMR spectra of reversibly forming
ligand-receptor complexes. Top. Curr. Chem. 2008, 273, 15–54. [PubMed]
15. Stachel, S.J.; Coburn, C.A.; Steele, T.G.; Jones, K.G.; Loutzenhiser, E.F.; Gregro, A.R. Structure-based design of
potent and selective cell-permeable inhibitors of human beta-secretase (BACE-1). J. Med. Chem. 2004, 47,
6447–6450. [CrossRef] [PubMed]
16. Dong, J.; Wang, N.-N.; Yao, Z.-J.; Zhang, L.; Cheng, Y.; Ouyang, D.F.; Lu, A.-P.; Cao, D.-S. ADMETlab:
A platform for systematic ADMET evaluation based on a comprehensively collected ADMET database.
J. Cheminform. 2018, 10, 29–40. [CrossRef] [PubMed]
17. Cornish-Bowden, A.; Eisenthal, R. Statistical considerations in the estimation of enzyme kinetic parameters
by the Direct Linear Plot and other methods. Biochem. J. 1974, 139, 721–730. [CrossRef] [PubMed]
Sample Availability: Not available.
©
