One-pot synthesis of Au@SiO2 catalysts: A click chemistry approach

Article abstract of DOI:10.1021/co5000932

Using the copper-catalyzed azide-alkyne cycloaddition "click" reaction, a library of triazole amphiphiles with a variety of functional polar "heads" and hydrophobic or superhydrophobic "tails" was synthesized. The amphiphiles were evaluated for their abil

Full text of DOI:10.1021/co5000932

Letter
pubs.acs.org/acscombsci
One-Pot Synthesis of Au@SiO2 Catalysts: A Click Chemistry Approach
Vera A. Solovyeva,† Khanh B. Vu,† Zulkifli Merican,† Rachid Sougrat,‡ and Valentin O. Rodionov*,†
‡
†Division of Physical Sciences and Engineering and KAUST Catalysis Center and KAUST Advanced Nanofabrication Imaging and
Characterization Core Laboratory, King Abdullah University of Science and Technology (KAUST), Thuwal, 23955-6900, Kingdom
of Saudi Arabia
S
* Supporting Information
ABSTRACT: Using the copper-catalyzed azide−alkyne cycloaddition “click”
reaction, a library of triazole amphiphiles with a variety of functional polar “heads”
and hydrophobic or superhydrophobic “tails” was synthesized. The amphiphiles were
evaluated for their ability to stabilize small Au nanoparticles, and, at the same time,
serve as templates for nanocasting porous SiO2. One of the Au@SiO2 materials thus
prepared was found to be a highly active catalyst for the Au nanoparticle-catalyzed
regioselective hydroamination of alkynes.
KEYWORDS: gold nanoparticles, click chemistry, fluorous surfactant, hydroamination
phile templates. Using the copper-catalyzed azide−alkyne
atalysis with gold nanoparticles (AuNPs) is a topic of
Cconsiderable current interest. That particles be small is a cycloaddition (CuAAC) “click” reaction,18 we synthesized a
1
library of triazole amphiphiles with a variety of functional polar
“heads” and hydrophobic or superhydrophobic “tails”. The
amphiphiles were evaluated for their ability to stabilize small
AuNPs,19 and, at the same time, to serve as templates for
nanocasting porous SiO2.20 One of the Au@SiO2 materials thus
prepared was found to be highly active catalyst for the AuNP-
catalyzed regioselective hydroamination of alkynes.6,21
We synthesized alkyne-bearing, polar surfactant “heads”
starting from cinchonidine (compounds 1a−b) and cinchonine
(compounds 2a−3b), two readily available alkaloids. These
alkaloids were chosen because we hypothesized that their
quinoline and tertiary amine moieties could catalyze the
hydrolysis of SiO2 precursors and/or bind to AuNP surfaces.
Two simpler alkyne “heads” were synthesized based on
oligo(ethylene glycol) (compound 4)22 and trimethylammo-
nium (compound 5). Two types of hydrophobic azide “tails”
were used, C10H21N3 linear hydrocarbon and perfluorinated
C8F17CH2CH2N3. The resulting library is presented in Chart 1.
The amphiphiles thus prepared were evaluated for their ability
to stabilize AuNPs, and, following that, used for one-pot
emulsion syntheses of Au@SiO2 materials. We found that the
morphologies of the AuNPs and the SiO2 support were
strongly influenced by the structure of the amphiphiles.
prerequisite for high catalytic activity in many of the gold-
catalyzed chemistries.2 Small AuNPs have been stabilized using
a variety of surface ligands,3,4 macromolecules,5−7 and solid
supports,8,9 such as SiO2, Al2O3, and mesoporous carbon. The
nature of the stabilizing ligands and supports can dramatically
influence both the stability and the catalytic competency of
AuNPs. Fine control over the structures of both the support
and the nanoparticles is highly desirable for the development of
practical catalysts.
Postsynthesis incorporation methods, such as wet impreg-
nation/calcining,10 immobilization of premade nanoparticles,11
and chemical vapor deposition12 allow full control over the
structure of solid support. However, the chosen support
necessarily determines the size of the nanoparticles, their spatial
distribution, and surface properties. Furthermore, nanoparticles
often localize close to the surface of the support, and may block
the channels/pores, limiting the catalyst’s accessibility.13
In situ incorporation methods, in which the solid support is
synthesized in the presence of premade nanoparticles or the
metal salt precursor, are experimentally simple and can yield
materials with a uniform distribution of confined nanoparticles.
This one-pot approach has been used to prepare SiO2-
supported Pd, Pt and Au nanoparticle catalysts, using
polymers,14 such as Pluronics F1279 and P123,15,16 chitosan,15
or cross-linked polystyrene-co-polystyrenesulfonate,17 as both
nanoparticle stabilizing agents and structure-directing agents for
the SiO2 solid support. Here, we present a combinatorial
approach that provides easy access to a range of SiO2-confined
AuNP materials (Au@SiO2) based on small-molecule amphi-
Neither of the hydrocarbon-tail cinchona surfactants 1b or
2b were effective stabilizers for gold nanoparticles, as extensive
Received: June 18, 2014
Revised: September 8, 2014
© XXXX American Chemical Society
A
dx.doi.org/10.1021/co5000932 | ACS Comb. Sci. XXXX, XXX, XXX−XXX

ACS Combinatorial Science
Letter
synthesis of SiO2, markedly different morphologies of silica
resulted (Figure S15, SI). Amphiphile 1a templated highly
porous, spherical, uniformly sized SiO2 nanoparticles, with a
tendency to form hollow shell structures.23 Rod-shaped SiO2
particles templated by 2a were significantly smaller and more
disordered. Using mixtures of 1a and 2a provided access to a
range of spherical to rod-shaped SiO2 morphologies. We
attribute these changes in morphology to differences in the
long-range order that exists in micellar assemblies of 1a, 2a, and
their mixtures. We chose to use amphiphile 1a for the
remainder of the study due to the high porosity (Figure S7 and
Table S1, SI) and regular structure of SiO2 templated by it.
The UV−vis spectra of the 1a-stabilized AuNPs and of the
corresponding Au@SiO2 material prepared in situ were found
to be very similar to each other (Figure S2, SI), and did not
show a prominent plasmonic peak. This indicates that the
AuNPs growth was not significant in the presence of SiO2 or
Si(OEt)4 precursor, and is supported by the size distributions of
the 1a-stabilized AuNP (Figure S3, SI) and the as-made Au@
SiO2 (Figure S4, SI). The zeta potential of the 1a-stabilized
AuNPs (Figure S6, SI) was +33.9 ( 0.5) mV at pH 9.3,
suggesting that the interaction between amphiphile-embedded
AuNPs and SiO2 and its precursor (negative zeta potential at
high pH) came from the direct co-condensation of anionic
inorganic species with the cationic surfactant.24 After the
reaction, the zeta potential of the Au@SiO2 material was −19.6
( 1.0) mV at pH 8.7, indicating that the surfactant-stabilized
AuNPs were covered by silica.
Chart 1. Library of fluorous 1,2,3-triazole surfactants
This Au@SiO2 material retained a significant amount of
amphiphile 1a (Figure S8, SI). The as-made material is easily
dispersible in perfluorodecalin and other fluorous solvents. In
biphasic fluorous-hydrocarbon mixtures, the 1a-Au@SiO2
material partitions into the fluorous phase (Figure S16, SI).
The removal of encapsulated surfactant by calcining the sample
in static air at 500 °C for 4 h resulted in AuNPs with a bimodal
particle size distribution (Figure 1 F and Figure S14, SI). This
suggests that the remnant 1a plays a role in the stabilization of
AuNPs in the SiO2 matrix. The calcined Au@SiO2 completely
lost its dispersibility in fluorous solvents.
Additional insight into the aggregation behavior of AuNPs
and growth of SiO2 in the presence of amphiphile 1a was
gained from cryo-transmission electron microscopy (cryo-
TEM) images of the 1a-stabilized AuNPs and corresponding
Au@SiO2 materials.
Images of AuNPs@1a with different electron doses are
shown in Figure 1A and B. With an electron dose of 100 e−/Å2
(Figure 1A), we observed raspberry-like assemblies of low- and
high-density objects, corresponding to aggregates of 1a and
AuNPs, respectively. It can be seen that 1a forms stable and
well-defined aggregates in water. The assemblies are ∼20 nm in
diameter, and have a positive zeta potential (Figure S6, SI).
These assemblies are remarkable in their ability to stop Ostwald
ripening of small AuNPs (Figure S3, SI). To verify that the low-
density objects are indeed amphiphile aggregates, we increased
the electron dose from 100 to 400 e−/Å2. The low-density
objects were damaged by the electron beam, as can be seen in
Figure 1 B, while the high-density objects remained stable.
Cryo-TEM images of the corresponding Au@SiO2 material
with low and high electron doses are shown in Figure 1C and
D. The images suggest that SiO2 shells are growing around the
AuNP@1a aggregates. This interaction between the SiO2 shells
and 1a-stabilized AuNPs was confirmed by increasing the
electron dose from 100 to 400 e−/Å2. The soft/organic parts of
aggregation and precipitation was observed (Figure S1 D-E,
Supporting Information (SI)). The neutral oligo(ethylene
glycol)-based surfactant 4 was neither able to stabilize the
gold nanoparticles, nor to serve as a structure-directing agent
for SiO2. The average diameter of the gold nanoparticles
obtained in the presence of 4 was 12.3 nm, and there was no
obvious interaction between the gold and silica (Figure S10,
SI). We found that amphiphile 5 could serve as a template for
structured SiO2, although the diameters of the gold nano-
particles were far from uniform and hopelessly too big for any
catalytic application (11.2 nm, Figure S11, SI).
The surfactant 3a bearing two fluorous “tails” was capable of
stabilizing somewhat smaller AuNPs, with an average diameter
of 4.5 nm (Figure S9, SI). However, the structure of SiO2
directed by 3a was highly irregular, and low solubility of this
amphiphile precluded its use in larger scale syntheses of Au@
SiO2. Likewise, the hybrid fluorous-hydrocarbon amphiphile 3b
stabilized relatively large AuNPs, as indicated by the obvious
plasmonic band at ∼500 nm in the UV−vis spectrum (Figure
S13, SI).
To our delight, the single-tail fluorous amphiphile 1a and its
pseudoenantiomer 2a could stabilize small, sub-2 nm AuNPs, as
indicated by the color of the colloidal solutions and the absence
of plasmonic bands in the range of 500−550 nm in their UV−
vis spectra7 (Figure S1, S2 and S12, SI). The AuNP solutions
stabilized by 1a and 2a were found to be stable for at least 10
months (Figure S3, SI).
The stereochemistry of the surfactant “head” in 1a and 2a
did not significantly affect the ability of the amphiphiles to
stabilize AuNPs. However, when the pseudoenantiomeric
amphiphiles were used as structure-directing agents for the
B
dx.doi.org/10.1021/co5000932 | ACS Comb. Sci. XXXX, XXX, XXX−XXX

ACS Combinatorial Science
Letter
mined by XPS and ICP-OES was 1.1 and 1.6 wt %, respectively.
These results confirm that the material is indeed AuNPs
encapsulated in SiO2, since the apparent gold content from the
surface analysis (XPS) is lower than that from the bulk analysis
(ICP-OES).25 Since Au 4f7/2 and 4f5/2 of the Au 4f spectrum of
Au@SiO2 were not well separated and broad compared with
those of the Au 4f spectrum of the Au0 film, more than one
valence state of Au should be expected. We attributed the Au
4f7/2 at 83.87 eV and that at 84.60 eV to Au0 and Auδ+,
respectively.26 The assignment of the partially charged Auδ+
(∼40% of total Au present) in this case was neither Au+ (85.6
eV) nor Au3+ (87.5 eV), for which the binding energies are well
established.27 A possible explanation for this observation is that
the low and high binding energy represents the bulk (core) and
surface (the shell interacting with the fluorinated surfactant) of
the AuNPs, respectively. The same observation was made for
thiolate-protected AuNPs.4,28
The Au@SiO2 material, prepared in the presence of 1a,
exhibited excellent activity and 100% selectivity for the imine
products when used in hydroamination of alkynes with anilines
(Table 1). It is important to note that for each of the reactions
a
Table 1. Hydroamination of Alkynes with Anilines
time
(h)
alkyne conv.
b
entry
R1
R2
(%)
TON
1
2
3
4
5
H
H
H
H
H
H
16
16
16
16
16
97
100
93
1605
1640
1361
1640
1605
p-Et
Figure 1. Cryo-TEM and TEM images of 1a-stabilized AuNPs and
Au@SiO2 materials. (A and B) Cryo-TEM images of 1a-stabilized
AuNPs, total doses of 100 and 400 e−/Å2; (C and D) Cryo-TEM
images of Au@SiO2, total doses of 100 and 400 e−/Å2; (E and F):
High resolution TEM images of as-made Au@SiO2 and calcined Au@
SiO2.
p-PhO
p-C5H11
100
98
1-ethynyl-
naphthalene
6
H
p-MeO
p-MeO
p-MeO
p-MeO
p-MeO
16
16
16
16
16
100
100
100
95
1640
1640
1640
1560
1619
7
p-Et
8
p-PhO
p-C5H11
the material (aggregates of 1a) were damaged, while the SiO2
shells remained intact.
We further characterized the Au@SiO2 material prepared in
the presence of 1a using X-ray photoelectron spectroscopy
(XPS) (Figure 2) and inductively coupled plasma optical
emission spectroscopy (ICP-OES). The gold content deter-
9
10
1-ethynyl-
naphthalene
99
11
12
13
14
H
p-Me
p-Me
p-Me
p-Me
16
16
16
16
88
92
94
99
1441
1514
1534
1626
p-Et
p-C5H11
1-ethynyl-
naphthalene
15
16
2,4-di(CF3)
H
H
36
36
60
77
984
2,4-
di(CF3)
1263
c
c
17
18
19
H
H
H
H
16
16
16
97
1605
c
c
p-Et
p-PhO
83
1361
c
c
77
1256
a
Reaction conditions: 1 mmol of acetylene, 1.5 mmol of aniline, 7.5
mg of as-made catalyst (0.61 mmol, 0.61 × 10−3 eq Au), under Ar, 135
b
°C. Determined by GC/MS with chlorobenzene as internal standard;
c
With calcined catalyst (3.2 mg, 0.61 mmol, 0.61 × 10−3 equiv of Au).
in the Table, the corresponding blank reactions did not lead to
the formation of any imine product. The optimal reaction
conditions were achieved by using a neat mixture of 1 equiv of
alkyne and 1.5 equiv of aniline under Ar atmosphere at 135 °C
for 16 h. These conditions led to an almost quantitative
conversion of the alkyne to an imine for most of the substrates,
Figure 2. XPS spectra of the Au 4f level.
C
dx.doi.org/10.1021/co5000932 | ACS Comb. Sci. XXXX, XXX, XXX−XXX

ACS Combinatorial Science
Letter
with only a trace amount of a hydrolysis byproduct
(corresponding acetophenone). The presence of electron-
donating substituents in both the alkyne and aniline substrates
activated them for hydroamination (Table 1, entries 2−14).
The reactions were markedly slowed by electron-withdrawing
substituents (Table 1, entries 15−16).
REFERENCES
■
(1) (a) Haruta, M. When Gold is Not Noble: Catalysis By
Nanoparticles. Chem. Rec. 2003, 3, 75−87. (b) Mikami, Y.;
Dhakshinamoorthy, A.; Alvaro, M.; Garcia, H. Catalytic Activity of
Unsupported Gold Nanoparticles. Catal. Sci. Technol. 2013, 3, 58−69.
(c) Corma, A.; Leyva-Perez, A.; Sabater, M. J. Gold-Catalyzed Carbon-
́
Heteroatom Bond-Forming Reactions. Chem. Rev. 2011, 111, 1657−
1712.
(2) (a) Turner, M.; Golovko, V. B.; Vaughan, O. P. H.; Abdulkin, P.;
Berenguer-Murcia, A.; Tikhov, M. S.; Johnson, B. F. G.; Lambert, R.
M. Selective Oxidation With Dioxygen By Gold Nanoparticle Catalysts
Derived From 55-Atom Clusters. Nature 2008, 454, 981−983.
(b) Corma, A.; Garcia, H. Supported Gold Nanoparticles as Catalysts
for Organic Reactions. Chem. Soc. Rev. 2008, 37, 2096−2126.
(3) (a) Brust, M.; Walker, M.; Bethell, D.; Schiffrin, D. J.; Whyman,
R. Synthesis of Thiol-Derivatised Gold Nanoparticles in a Two-Phase
Liquid-Liquid System. J. Chem. Soc., Chem. Commun. 1994, 801−802.
(b) Zhang, L.; Sun, X.; Song, Y.; Jiang, X.; Dong, S.; Wang, E.
Didodecyldimethylammonium Bromide Lipid Bilayer-Protected Gold
Nanoparticles: Synthesis, Characterization, and Self-Assembly. Lang-
muir 2006, 22, 2838−2843.
We compared the catalytic efficiency of the as-made and
calcined Au@SiO2 materials (same Au loading as determined
by ICP-OES). The as-made Au@SiO2 catalyst containing
amphiphile 1a was found to be catalytically more effective for
hydroamination of alkynes. The activity of the calcined catalyst
was similar to the as-made material for the reaction of
phenylacetylene with aniline (Table 1, entries 1 and 17).
However, the calcined material exhibited markedly lower
activity for substituted phenylacetylenes and anilines (Table
1, entries 2, 3, 18, and 19). As determined by nitrogen sorption
(Figure S7 and Table S1, SI) the Au surface of the calcined
Au@SiO2 should be more accessible than that of the as-made
Au@SiO2, since the surfactant in the as-made material could
slow the diffusion of the substrates and products. Thus, the
difference in activity between the two samples is due to the
difference in AuNP size. The smaller particles in the as-made
catalyst are stabilized by the remnant 1a. Since SiO2 has a
strongly negative ζ-potential, 1a-stabilized AuNPs tend to
remain inside the SiO2 matrix. Leaching of Au into the reaction
medium was explored by ICP-OES, after incubating the catalyst
under typical reaction conditions at 130 °C for 16 h. No
significant leaching has been observed (see SI).
In conclusion, we screened a library of triazole-based
surfactants for their ability to stabilize Au nanoparticles in
aqueous solution. We determined that at least one perfluori-
nated hydrophobic “tail” combined with a large cationic “head”
in the surfactant molecule is necessary to stabilize small,
catalytically competent AuNPs. Au@SiO2 materials prepared in
the presence of amphiphile 1a exhibited high turnover numbers
and selectivity in hydroamination of alkynes with anilines. Our
combinatorial approach to the surfactant-templated nano-
particle@SiO2 materials is general; we are now applying it in
our laboratories to the synthesis of other catalysts and porous
oxide supports.
(4) Negishi, Y.; Nobusada, K.; Tsukuda, T. Glutathione-Protected
Gold Clusters Revisited: Bridging the Gap Between Gold(I)−Thiolate
Complexes and Thiolate-Protected Gold Nanocrystals. J. Am. Chem.
Soc. 2005, 127, 5261−5270.
(5) (a) Daiel, M.-C.; Astruc, D. Gold Nanoparticles: Assembly,
Supramolecular Chemistry, Quantum-Size-Related Properties, and
Applications Toward Biology, Catalysis, and Nanotechnology. Chem.
Rev. 2003, 104, 293−346. (b) Dioos, B. M. L.; Vankelecom, I. F. J.;
Jacobs, P. A. Aspects of Immobilisation of Catalysts on Polymeric
Supports. Adv. Synth. Catal. 2006, 348, 1413−1446.
́ ́
(6) Corma, A.; Concepcion, P.; Domínguez, I.; Forne, V.; Sabater, M.
J. Gold Supported on a Biopolymer (Chitosan) Catalyzes the
Regioselective Hydroamination of Alkynes. J. Catal. 2007, 251, 39−47.
(7) Kim, Y.-G.; Oh, S.-K.; Crooks, R. M. Preparation and
Characterization of 1−2 nm Dendrimer-Encapsulated Gold Nano-
particles Having Very Narrow Size Distributions. Chem. Mater. 2003,
16, 167−172.
(8) (a) Chen, J.; Zhang, R.; Han, L.; Tu, B.; Zhao, D. One-Pot
Synthesis of Thermally Stable Gold@Mesoporous Silica Core-Shell
Nanospheres With Catalytic Activity. Nano Res. 2013, 6, 871−879.
(b) Chen, L.; Hu, J.; Richards, R. Intercalation of Aggregation-Free
and Well-Dispersed Gold Nanoparticles Into the Walls of Mesoporous
Silica as a Robust “Green” Catalyst for N-Alkane Oxidation. J. Am.
̀
Chem. Soc. 2008, 131, 914−915. (c) Gajan, D.; Guillois, K.; Delichere,
ASSOCIATED CONTENT
■
P.; Basset, J.-M.; Candy, J.-P.; Caps, V.; Coperet, C.; Lesage, A.;
Emsley, L. Gold Nanoparticles Supported on Passivated Silica: Access
to an Efficient Aerobic Epoxidation Catalyst and the Intrinsic
Oxidation Activity of Gold. J. Am. Chem. Soc. 2009, 131, 14667−
14669. (d) Liu, Y.; Tsunoyama, H.; Akita, T.; Tsukuda, T. Preparation
of ∼1 nm Gold Clusters Confined Within Mesoporous Silica and
Microwave-Assisted Catalytic Application for Alcohol Oxidation. J.
Phys. Chem. C 2009, 113, 13457−13461. (e) Zhu, F.-X.; Wang, W.; Li,
H.-X. Water-Medium and Solvent-Free Organic Reactions Over a
Bifunctional Catalyst With Au Nanoparticles Covalently Bonded to
HS/SO3H Functionalized Periodic Mesoporous Organosilica. J. Am.
Chem. Soc. 2011, 133, 11632−11640.
S
* Supporting Information
Complete experimental details, characterization (1D and 2D
1H, 13C, and 19F NMR and FTIR spectra), and additional TEM
images. This material is available free of charge via the Internet
at http://pubs.acs.org/.
AUTHOR INFORMATION
■
Corresponding Author
*E-mail: valentin.rodionov@kaust.edu.sa. Tel: +966-12-
8084592.
(9) Wang, S.; Zhao, Q.; Wei, H.; Wang, J.-Q.; Cho, M.; Cho, H. S.;
Terasaki, O.; Wan, Y. Aggregation-Free Gold Nanoparticles in
Ordered Mesoporous Carbons: Toward Highly Active and Stable
Heterogeneous Catalysts. J. Am. Chem. Soc. 2013, 135, 11849−11860.
Author Contributions
V.A.S. and K.B.V. contributed equally.
Notes
(10) (a) Kohn, R.; Froba, M. Nanoparticles of 3d Transition Metal
̈
̈
The authors declare no competing financial interest.
Oxides in Mesoporous MCM-48 Silica Host Structures: Synthesis and
Characterization. Catal. Today 2001, 68, 227−236. (b) Wang, Z.; Xie,
Y.; Liu, C.-J. Synthesis and Characterization of Noble Metal (Pd, Pt,
Au, Ag) Nanostructured Materials Confined in the Channels of
Mesoporous SBA-15. J. Phys. Chem. C 2008, 112, 19818−19824.
(c) Scott, R. W. J.; Wilson, O. M.; Crooks, R. M. Titania-Supported
ACKNOWLEDGMENTS
■
Support from KAUST baseline funding program is acknowl-
edged with thanks.
D
dx.doi.org/10.1021/co5000932 | ACS Comb. Sci. XXXX, XXX, XXX−XXX

ACS Combinatorial Science
Letter
Au and Pd Composites Synthesized From Dendrimer-Encapsulated
́
Lazaro, M. J.; de la Fuente, G. F.; Laguna, M.; Munoz, E. Synthesis and
̃
Metal Nanoparticle Precursors. Chem. Mater. 2004, 16, 5682−5688.
Application of Gold−Carbon Hybrids as Catalysts for the Hydro-
amination of Alkynes. Appl. Catal., A 2013, 456, 88−95.
(22) Francis, D. V.; Miles, D. H.; Mohammed, A. I.; Read, R. W.;
Wang, X. Towards Functional Fluorous Surfactants. Synthesis of
Hydrophilic Fluorous 1,2,3-Triazolylmethyl Ethers and Di(1,2,3-
Triazolylmethyl) Ethers. J. Fluorine Chem. 2011, 132, 898−906.
(23) Tan, B.; Lehmler, H. J.; Vyas, S. M.; Knutson, B. L.; Rankin, S.
E. Fluorinated-Surfactant-templated Synthesis of Hollow Silica
Particles With a Single Layer of Mesopores in Their Shells. Adv.
Mater. 2005, 17, 2368−2371.
(11) (a) Wittmann, S.; Schatz, A.; Grass, R. N.; Stark, W.; Reiser, O.
̈
A Recyclable Nanoparticle-Supported Palladium Catalyst for the
Hydroxycarbonylation of Aryl Halides in Water. Angew. Chem., Int. Ed.
2010, 49, 1867−1870. (b) Malynych, S.; Luzinov, I.; Chumanov, G.
Poly(Vinyl Pyridine) as a Universal Surface Modifier for Immobiliza-
tion of Nanoparticles. J. Phys. Chem. B 2002, 106, 1280−1285.
(12) (a) Dossi, C.; Psaro, R.; Bartsch, A.; Fusi, A.; Sordelli, L.; Ugo,
R.; Bellatreccia, M.; Zanoni, R.; Vlaic, G. Chemical Vapor Deposition
of Platinum Hexafluoroacetylacetonate Inside KL Zeolite: A New
Route to Nonacidic Platinum-in-Zeolite Catalysts. J. Catal. 1994, 145,
377−383. (b) Gary, J.; Sandrine, R.; Patricia, M. P.; Uschi, M. G.;
Alan, D.; Syed, K.; Elin, R.; Burtron, H. D. Low Temperature Water-
Gas Shift: Examining the Efficiency of Au as a Promoter for Ceria-
Based Catalysts Prepared By CVD of an Au Precursor. Appl. Catal., A
2005, 292, 229−243.
(24) Huo, Q.; Margolese, D. I.; Ciesla, U.; Feng, P.; Gier, T. E.;
Sieger, P.; Leon, R.; Petroff, P. M.; Schuth, F.; Stucky, G. D.
Generalized Synthesis of Periodic Surfactant/Inorganic Composite
Materials. Nature 1994, 368, 317−321.
(25) (a) Serpell, C. J.; Cookson, J.; Ozkaya, D.; Beer, P. D. Core@
Shell Bimetallic Nanoparticle Synthesis Via Anion Coordination. Nat.
Chem. 2011, 3, 478−483. (b) Zesheng, L.; Chunyong, H.; Mei, C.;
Shuai, K.; Pei, K. S. A Strategy for Easy Synthesis of Carbon Supported
Co@Pt Core−Shell Configuration as Highly Active Catalyst for
Oxygen Reduction Reaction. Int. J. Hydrogen Energy 2012, 37, 14152−
14160.
(26) Moulder, J. F.; Stickle, W. F.; Sobol, P. E.; Bomben, K. D.
Handbook of X-Ray Photoelectron Spectroscopy: A Reference Book of
Standard Spectra for Identification and Interpretation of XPS Data;
Perkin-Elmer Corporation: Eden Prairie, MN, 1992; p 261.
(27) Salama, T. M.; Shido, T.; Minagawa, H.; Ichikawa, M.
Characterization of Gold(I) in NaY Zeolite and Acidity Generation.
J. Catal. 1995, 152, 322−330.
(28) (a) Ohta, T.; Shibuta, M.; Tsunoyama, H.; Negishi, Y.; Eguchi,
T.; Nakajima, A. Size and Structure Dependence of Electronic States in
Thiolate-Protected Gold Nanoclusters of Au25(SR)18, Au38(SR)24, and
Au144(SR)60. J. Phys. Chem. C 2013, 117, 3674−3679. (b) Tanaka, A.;
Takeda, Y.; Imamura, M.; Sato, S. Dynamic Final-State Effect on the
Au 4f Core-Level Photoemission of Dodecanethiolate-Passivated Au
Nanoparticles on Graphite Substrates. Phys. Rev. B 2003, 68,
No. 195415.
(13) (a) Cai-Hua, T.; Ai-Qin, W.; Ming-Yuan, Z.; Xiao-Dong, W.;
Tao, Z. Factors Influencing the Catalytic Activity of SBA-15-Supported
Copper Nanoparticles in Co Oxidation. Appl. Catal., A 2006, 297, 40−
47. (b) Bronstein, L. M.; Chernyshov, D. M.; Karlinsey, R.; Zwanziger,
J. W.; Matveeva, V. G.; Sulman, E. M.; Demidenko, G. N.; Hentze, H.-
P.; Antonietti, M. Mesoporous Alumina and Aluminosilica With Pd
and Pt Nanoparticles: Structure and Catalytic Properties. Chem. Mater.
2003, 15, 2623−2631.
(14) Bronstein, L.; Kramer, E.; Berton, B.; Burger, C.; Forster, S.;
̈
̈
Antonietti, M. Successive Use of Amphiphilic Block Copolymers as
Nanoreactors and Templates: Preparation of Porous Silica With Metal
Nanoparticles. Chem. Mater. 1999, 11, 1402−1405.
(15) Gaweł, B.; Lambrechts, K.; Gaweł, K.; Øye, G. One-Pot
Synthesis of Gold Nanoparticle Functionalised Mesoporous Silica
The Double Role of a Tri-Block Copolymer and Chitosan. Micropor.
Mesopor. Mater. 2012, 164, 32−37.
(16) Li, L.; Jin, C.; Wang, X.; Ji, W.; Pan, Y.; van der Knaap, T.; van
der Stoel, R.; Au, C. T. Cyclohexane Oxidation Over Size-Uniform Au
Nanoparticles (SBA-15 Hosted) in a Continuously Stirred Tank
Reactor Under Mild Conditions. Catal. Lett. 2009, 129, 303−311.
(17) Whilton, N. T.; Berton, B.; Bronstein, L.; Hentze, H.-P.;
Antonietti, M. Organized Functionalization of Mesoporous Silica
Supports Using Prefabricated Metal-Polymer Modules. Adv. Mater.
1999, 11, 1014−1018.
(18) (a) Tornøe, C. W.; Christensen, C.; Meldal, M. Peptidotriazoles
on Solid Phase: [1,2,3]-Triazoles By Regiospecific Copper(I)-
Catalyzed 1,3-Dipolar Cycloadditions of Terminal Alkynes to Azides.
J. Org. Chem. 2002, 67, 3057−3062. (b) Rostovtsev, V. V.; Green, L.
G.; Fokin, V. V.; Sharpless, K. B. A Stepwise Huisgen Cycloaddition
Process: Copper(I)-Catalyzed Regioselective Ligation of Azides and
Terminal Alkynes. Angew. Chem., Int. Ed. 2002, 41, 2596−2599.
(19) (a) Aprile, C.; Abad, A.; Garcia, H.; Corma, A. Synthesis and
Catalytic Activity of Periodic Mesoporous Materials Incorporating
Gold Nanoparticles. J. Mater. Chem. 2005, 15, 4408−4413.
(b) Premkumar, T.; Kim, D.; Lee, K.; Geckeler, K. E. A Facile and
Efficient “One-Step” Synthesis of Auo With Tunable Size. Gold Bull.
2007, 40, 321−327. (c) Gao, J.; Bender, C. M.; Murphy, C. J.
Dependence of the Gold Nanorod Aspect Ratio on the Nature of the
Directing Surfactant in Aqueous Solution. Langmuir 2003, 19, 9065−
9070.
(20) Polarz, S.; Antonietti, M. Porous Materials Via Nanocasting
Procedures: Innovative Materials and Learning About Soft-Matter
Organization. Chem. Commun. 2002, 2593−2604.
(21) (a) Widenhoefer, R. A.; Han, X. Gold-Catalyzed Hydro-
amination of C−C Multiple Bonds. Eur. J. Org. Chem. 2006, 2006,
4555−4563. (b) Alonso, F.; Beletskaya, I. P.; Yus, M. Transition-
Metal-Catalyzed Addition of Heteroatom−Hydrogen Bonds to
Alkynes. Chem. Rev. 2004, 104, 3079−3160. (c) Zhao, J.; Zheng, Z.;
Bottle, S.; Chou, A.; Sarina, S.; Zhu, H. Highly Efficient and Selective
Photocatalytic Hydroamination of Alkynes By Supported Gold
Nanoparticles Using Visible Light At Ambient Temperature. Chem.
Commun. 2013, 49, 2676−2678. (d) Seral-Ascaso, A.; Luquin, A.;
E
dx.doi.org/10.1021/co5000932 | ACS Comb. Sci. XXXX, XXX, XXX−XXX
