WANG ET AL.
5 of 6
and added to the reaction mixture. The resulting brown
solution was stirred for 48 hours at 120 °C. The solution
was then cooled to room temperature and filtered through
Celite. Removal of the solvent yielded a purple liquid
which was then taken up in 3 ml dichloromethane and
was purified through a silica chromatography, dried under
vacuum to give 3 (1.03 g, 68% yield) as a brown oil. 1H NMR
(300 MHz, CDCl3, 298 K/ppm) δ 7.66 (s, 1H, NCHN), 7.33–
7.26 (m, 2H, Harom), 7.26–7.19 (m, 3H, Harom), 7.13 (s, 1H,
Harom), 7.02–6.95 (m, 2H, Harom), 6.93–6.87 (m, 2H, Harom),
5.87 (s, 1H, NH), 3.01–2.93 (m, 4H, NCH2CH2CH2CH2N),
1.85–1.76 (m, 4H, NCH2CH2CH2CH2N). 13C NMR
(75 MHz, CDCl3, 298 K/ppm): δ 142.4, 140.1, 137.8, 133.3,
130.1, 129.8, 127.4, 123.2, 121.9, 120.3, 120.2, 119.2, 118.3,
115.5, 50.6, 24.3.
133.1, 131.5, 127.0, 124.2, 123.7, 122.9, 122.8, 122.7,
121.5, 120.2, 117.9, 50.2, 31.9, 24.5, 19.3, 13.5.
4.5 | Synthesis of 5a
A 100 ml reaction vessel was charged with 4a (1.28 g,
3.0 mmol) and THF (30 ml) under a N2 atmosphere. Et3N
(0.27 g, 6.6 mmol) was slowly added to the reaction and
until the suspension turned to brown solution, Ni (DME)
Cl2 (0.92 g, 3.0 mmol, DME = dimethoxyethane)
suspended in THF (10 ml) was added to the solution
slowly. The reaction mixture was stirred over night at room
temperature. After remove of the solvent under vacuum,
the green residue was washed with n‐pentane (30 ml), then
taken up with Et2O (3 × 20 ml) and filtered through Celite.
Evaporation of the solvent yielded a green solid and dried
under vacuum. Yield: (1.14 g, 85% based on 4a). IR (Nujol,
cm−1): 1582 ν(C=C). 1H NMR (300 MHz, CDCl3,
298 K/ppm): δ 7.53 (d, J = 8.1 Hz, 1H, Harom), 7.37 (d,
J = 1.6 Hz, 1H, Harom), 7.29 (s, 1H, Harom), 7.06 (s, 1H,
Harom), 7.05 (d, J = 1.8 Hz, 1H, Harom), 6.98 (t, J = 7.3 Hz,
1H, Harom), 6.89 (dd, J = 15.4, 7.8 Hz, 2H, Harom), 6.73 (t,
J = 7.4 Hz, 1H, Harom), 6.55 (t, J = 7.2 Hz, 1H, Harom),
5.76–5.67 (m, 1H, CH (CH3)2), 4.17–4.01 (m, 1H,
NCH2CH2CH2CH2N), 3.94–3.85 (m, 1H, NCH2CH2
CH2CH2N), 3.45–3.32 (m, 1H, NCH2CH2CH2CH2N),
3.06–3.00 (m, 3 Hz, 1H, NCH2CH2CH2CH2N), 2.14–2.03
(m, 1H, NCH2CH2CH2CH2N), 1.97–1.85 (m, 1H,
NCH2CH2CH2CH2N), 1.84–1.73 (m, 2H, NCH2CH2
CH2CH2N), 1.69 (d, J = 6.8 Hz, 3H, C (CH3)2), 1.42 (d,
J = 6.6 Hz, 3H, C (CH3)2). 13C NMR (75 MHz, CDCl3,
298 K/ppm): δ 150.3 (Ccarbene), 149.9, 145.8, 142.5, 130.6,
126.5, 126.2, 121.5, 120.4, 119.7, 119.5, 118.0, 117.4, 117.1,
115.8, 60.4, 54.5, 51.2, 25.3, 24.5, 23.3, 22.4. Anal. Calcd
for C22H25BrN4Ni (%): C, 54.59; H, 5.21; N, 11.57. Found
(%): C, 54.01; H, 5.50; N, 11.30.
4.3 | Synthesis of 4a
To a solution of 3 (3.04 g, 10 mmol) in acetonitrile (30 ml)
i
was added PrBr (2.46 g, 20 mmol). The reaction mixture
was refluxed for 70 hr. The solution was then cooled to
room temperature. After removal of the solvent under
vacuum, recrystallization from CH3OH/Et2O gave 4a
(3.64 g, 88% yield based on 3) as a gray powder. 1H
NMR (300 MHz, CDCl3, 298 K/ppm) δ: 9.97 (s, 1H,
Harom), 7.49 (s, 1H, Harom), 7.37 (d, J = 7.9 Hz, 1H, Harom),
7.30–7.17 (m, 3H, Harom), 6.83–6.97 (m, 5H, Harom), 6.77
(s, 1H, NH), 5.08–4.95 (m, 1H, CH (CH3)2), 3.04 (m, 4H,
NCH2CH2CH2CH2N), 1.78 (m, 4H, NCH2CH2CH2CH2N),
1.50 (d, J = 6.7 Hz, 6H, CH (CH3)2).13CNMR (75 MHz,
CDCl3, 298 K/ppm): δ 139.2, 136.7, 133.6, 131.5, 127.1,
124.5, 124.4, 123.8, 123.2, 121.7, 121.6, 120.4, 120.1,
118.1, 60.4, 53.8, 24.7, 22.5.
4.4 | Synthesis of 4b
4.6 | Synthesis of 5b
To a solution of 3 (3.04 g, 10 mmol) in acetonitrile (30 ml)
was added nBuBr (2.75 g, 20 mmol). The reaction mixture
was refluxed for 48 hr. The solution was then cooled to
room temperature. After removal of the solvent under
vacuum, recrystallization from CH3OH/Et2O gave 4b
(3.98 g, 95% yield based on 3) as a gray powder. 1H
NMR (300 MHz, CDCl3, 298 K/ppm): δ 7.67 (s, 1H,
Harom), 7.28 (s, 1H, Harom), 7.22 (t, J = 5.0 Hz, 2H, Harom),
7.15–7.05 (m, 3H, Harom), 7.00–6.96 (m, 2H, Harom), 6.95–
6.87 (m, 2H, Harom), 6.72–6.45 (m, 2H, CH2CH2CH2), 5.91
A 100 ml reaction vessel was charged with 4b (1.32 g,
3.0 mmol) and THF (30 ml) under a N2 atmosphere.
Et3N (0.27 g, 6.6 mmol) was slowly added to the reaction
and until the suspension turned to brown solution, Ni
(DME)Cl2 (0.92 g, 3.0 mmol) suspended in THF
(10 ml) was added to the solution slowly. The reaction
mixture was stirred over night at room temperature.
After remove of the solvent under vacuum, the green
residue was washed with n‐pentane (30 ml), then taken
up with Et2O (3 × 20 ml) and filtered through Celite.
Evaporation of the solvent yielded a green solid and
dried under vacuum. Yield: (1.22 g, 90% based on 4b).
IR (Nujol, cm−1): 1582 ν(C=C). 1H NMR (300 MHz,
CDCl3, 298 K/ppm): δ 7.48 (dd, J = 8.4, 1.0 Hz, 1H,
(d,
J
=
20.5 Hz, 1H, NH), 2.99 (m, 4H,
NCH2CH2CH2CH2N), 2.79–2.72 (m, 2H, CH2CH2CH2),
2.69–2.62 (m, 2H, CH2CH2CH2), 1.85–1.80 (m, 4H,
NCH2CH2CH2CH2N), 1.76 (t, J = 12 Hz, 3H, CH3). 13C
NMR (75 MHz, CDCl3, 298 K/ppm) δ 139.2, 137.4,
