A. Fürstner and J. W. J. Kennedy
ture for 18 h. For work up, the mixture was diluted with water (75 mL)
and extracted with tert-butyl methyl ether (520 mL). The combined or-
ganic layers were washed with brine (25 mL), dried (Na2SO4), and evapo-
rated and the residue was purified by flash chromatography (Combiflash
Companion, 0!50% tert-butyl methyl ether in hexanes) to give product
31 as a colorless oil (868 mg, 88%).[40]1 H NMR (400 MHz, CDCl3, ro-
tamers): d=4.13 (m, 1H), 3.59 (m, 2H), 3.33 (m, 2H), 2.93 (brs, 1H),
1.97 (m, 1H), 1.88 (m, 2H), 1.65 (m, 2H), 1.50–1.31 (m, 1H), 1.47 (s,
9H); 13C NMR (100 MHz, CDCl3): d=79.9, 59.3, 53.6, 46.4, 38.4, 31.2,
28.5, 23.5; MS (EI): m/z (%): 215 (4) [M +], 170 (14), 142 (11), 114 (86),
70 (100), 57 (100), 41 (29), 29 (17); HRMS: m/z: calcd for C11H21NO3 +
Na: 238.141361; found: 238.141392.
158.8, 154.0, 148.1, 147.9, 144.6, 134.2, 133.2, 121.1, 114.5, 114.2, 113.9,
112.4, 112.1, 110.4, 88.3, 87.9, 81.1, 80.8, 79.0, 78.7, 55.9, 55.6, 55.0, 46.6,
46.3, 30.2, 29.4, 28.2, 24.7, 24.0, 23.2, 22.4; IR (film): n˜ =2969, 1690, 1603,
1393, 1365, 1254, 1167, 1029 cmꢀ1; MS (EI): m/z (%): 451 (23) [M +], 378
(8), 282 (16), 281 (12), 170 (30), 114 (100), 70 (74), 57 (35), 41 (5);
HRMS: m/z: calcd for C27H33NO5 +Na: 474.225096; found: 474.225134;
elemental analysis calcd (%) for C27H33NO5: C 71.82, H 7.37, N 3.10;
found: C 71.88, H 7.43, N 2.96.
(R)-N-(tert-Butoxycarbonyl)-2-[(2,3,6-trimethoxyphenanthren-10-yl)-
methyl]-pyrrolidine (34): Prepared according to the representative proce-
dure for the cycloisomerization described above, upon treatment of a sol-
ution of substrate 33 (194 mg, 0.430 mmol) with PtCl2 (30 mg, 0.11 mmol)
in toluene (43 mL) at 608C for 1 h and then at 808C for 3 h. Flash chro-
matography (Combiflash Companion, 0!30% tert-butyl methyl ether in
hexanes) of the crude product gave phenanthrene 34 as an oil which
slowly solidified upon standing (141 mg, 72%). Chiral HPLC analysis
(Chiralcel OD-H (250 mm4.6 mm), n-heptane/isopropanol 98:2,
0.5 mLminꢀ1, 28.07 min (R isomer), 33.85 min (S isomer)) showed that
(R)-N-(tert-Butoxycarbonyl)-2-propargylpyrrolidine (32): A mixture of
homoprolinol 31 (2.62 g, 12.2 mmol), NMO (2.16 g, 18.5 mmol), and pow-
dered molecular sieves (3 , 7.61 g) in CH2Cl2 (25 mL) was treated at
08C with TPAP (227 mg, 0.646 mmol).[33] The resulting dark mixture was
stirred at this temperature for 30 min and then at ambient temperature
for 2 h. The mixture was filtered through a short silica gel column with
tert-butyl methyl ether. The filtrates were evaporated to give crude (R)-
N-(tert-butoxycarbonyl)-2-(2-oxoethyl)-pyrrolidine as an oil (1.91 g,
73%)[41] which was used in the next step without further purification.
Characteristic data: 1H NMR (400 MHz, CDCl3, rotamers): d=9.77 (t,
J=2.0 Hz, 1H), 4.25 (m, 1H), 3.36 (m, 2H), 2.86 (m, 1H), 2.47 (ddd, J=
16.2, 7.5, 1.7 Hz, 1H), 2.11 (m, 1H), 1.85 (m, 2H), 1.66 (m, 1H), 1.44 (s,
9H); 13C NMR (100 MHz, CDCl3): d=201.0, 154.4, 79.8, 52.4, 49.2, 46.4,
31.7, 28.5, 23.4; IR (film): n˜ =2973, 1690, 1393, 1169 cmꢀ1; MS (EI): m/z
(%): 213 (0.5) [M +], 212 (0.5), 185 (10), 114 (34), 70 (56), 57 (100), 41
(34), 29 (10); HRMS: m/z: calcd for C11H19NO3 +Na: 236.125712; found:
236.125605.
the product had an enantiomeric excess of
> 98%. M.p. 99–1018C;
1
[a]2D0 =ꢀ72.1 (c 1.07, CH2Cl2); H NMR (400 MHz, CDCl3, rotamers): d=
8.32 (brs, 1H), 7.91 (s, 1H), 7.84 (d, J=2.3 Hz, 1H), 7.72 (d, J=8.7 Hz,
1H), 7.38 (s, 1H), 7.16 (dd, J=8.7, 2.3 Hz, 1H), 4.26 (m, 1H), 4.20 (brs,
3H), 4.11 (s, 3H), 4.01 (s, 3H), 3.90 (m, 1H), 3.48 (m, 1H), 3.35 (m, 1H),
2.62 (m, 1H), 2.00 (m, 1H), 1.82 (m, 2H), 1.66 (m, 1H), 1.49 (s, 9H);
13C NMR (100 MHz, CDCl3): d=157.8, 154.7, 149.8, 148.8, 131.0, 130.6,
129.6, 127.3, 126.0, 125.8, 124.6, 115.3, 106.8, 103.9, 103.5, 79.0, 57.3, 56.7,
56.0, 55.6, 46.8, 38.5, 29.1, 28.6, 23.4; IR (film): n˜ =2927, 1684, 1609, 1394,
1260, 1160, 1029, 799 cmꢀ1; MS (EI): m/z (%): 451 (37) [M +], 378 (7),
282 (33), 281 (77), 170 (18), 114 (100), 70 (72), 57 (52), 41(14); HRMS:
m/z: calcd for C27H33NO5 +Na: 474.225093; found: 474.224895; elemental
analysis calcd (%) for C27H33NO5: C 71.82, H 7.37, N 3.10; found: C
71.68, H 7.32, N 3.15.
A
solution of the crude homoprolinal described above (588 mg,
2.76 mmol) and the Bestmann–Ohira reagent 24 (551 mg, 2.86 mmol)[25]
in MeOH (15 mL) at 08C was treated with K2CO3 (895 mg, 6.48 mmol)
and the resulting mixture was allowed to slowly reach ambient tempera-
ture. After stirring for 20 h, the reaction was quenched with aq. NH4Cl
(75 mL) and water (10 mL) and extracted with tert-butyl methyl ether
(515 mL). The combined extracts were washed with brine (25 mL),
dried (Na2SO4), and evaporated. Flash chromatography of the residue
(10% tert-butyl methyl ether in hexanes) gave alkyne 32 as a colorless oil
which slowly solidified upon standing (317 mg, 55%). Chiral GC analysis
(BGB-176SE/SE-52 column (30 m0.25 mm, 0.25 mm stationary phase
thickness), injection at 2208C, 1408C isothermal, FID detection at 3208C,
0.7 bar H2, tR =33.1 min (R), tR =34.4 min (S)) showed that the product
had an enantiomeric excess of > 99.5%. M.p. 52–548C; [a]2D0 =+73.5 (c
1.03, CH2Cl2); 1H NMR (400 MHz, CDCl3, rotamers): d=3.89 (m, 1H),
3.37 (m, 2H), 2.59 (m, 1H), 2.38 (m, 1H), 2.10–1.92 (m, 4H), 1.90–1.70
(m, 1H), 1.47 (s, 9H); 13C NMR (100 MHz, CDCl3): d=154.4, 81.7, 79.4,
69.6, 56.1, 46.9, 30.7, 29.8, 28.6, 23.2; IR (film): n˜ =3243, 2969, 1678, 1396.
1171 cmꢀ1; MS (EI): m/z (%): 209 (0.4) [M +], 170 (19), 114 (67), 70
(100), 57 (88), 41 (23), 29 (11); HRMS: m/z: calcd for C12H19NO2 +Na:
232.130794; found: 232.130771; elemental analysis calcd (%) for
C12H19NO2: C 68.87, H 9.15, N 6.69; found: C 68.81, H 9.22, N 6.58.
(ꢀ)-Antofine (2): A solution of phenanthrene 34 (122 mg, 0.271 mmol) in
EtOH (12 mL) was treated with aqueous HCHO (37% w/w, 2.2 mL,
27 mmol) and HCl (12m, 0.4 mL, 5 mmol) and the resulting mixture was
stirred at 808C in the dark for 43 h. The solvents were evaporated and
the residue was taken up in NaOH (6m, 5 mL) and extracted with
CH2Cl2 (45 mL). The combined extracts were washed with water (4
5 mL) and brine (10 mL), dried (Na2SO4), and concentrated to give the
title compound as a powder (90 mg, 0.25 mmol, 91%). Chiral HPLC
analysis (Chiralpak AD-H (250 mm4.6 mm), n-heptane/isopropanol
4:1, 0.5 mLminꢀ1, 33.39 min (S isomer), 49.72 min (R isomer)) showed
that the product had an enantiomeric excess of > 98%. [a]2D0 =ꢀ113.4 (c
1.23, CHCl3); 1H NMR (400 MHz, CDCl3): d=7.93 (s, 1H), 7.92 (d, J=
2.6 Hz, 1H), 7.83 (d, J=9.0 Hz, 1H), 7.32 (s, 1H), 7.22 (dd, J=9.0,
2.6 Hz, 1H), 4.71 (d, J=14.8 Hz, 1H), 4.12 (s, 3H), 4.08 (s, 3H), 4.03 (s,
3H), 3.72 (d, J=15.0 Hz, 1H), 3.47 (m, 1H), 3.37 (dd, J=15.8, 2.4 Hz,
1H), 2.92 (m, 1H), 2.47 (m, 2H), 2.26 (m, 1H), 2.05 (m, 1H), 1.92 (m,
1H), 1.78 (m, 1H); 13C NMR (100 MHz, CDCl3): d=157.6, 149.5, 148.5,
130.3, 127.0, 126.3, 125.5, 124.3, 124.1, 123.6, 115.0, 104.7, 104.0, 103.9,
60.3, 56.1, 55.9, 55.6, 55.1, 53.7, 33.5, 31.3, 21.6; IR (film): n˜ =2913, 1614,
1510, 1205, 1032, 840, 830, 808, 780 cmꢀ1; MS (EI): m/z (%): 363 (28)
[M +], 294 (100), 279 (7), 251 (5); HRMS: m/z: calcd for C23H26NO3:
364.190721; found: 364.190408.
(R)-N-(tert-Butoxycarbonyl)-2-[3-(3’,4’,5-trimethoxybiphenyl-2-yl)-prop-
2-ynyl]-pyrrolidine (33): Prepared according to the representative proce-
dure for the 9-MeO-9-BBN mediated coupling process described above,
using alkyne (R)-32 (279 mg, 1.33 mmol) in THF (3 mL), n-BuLi (1.45m
in hexanes, 0.92 mL, 1.33 mmol), 9-MeO-9-BBN (220 mg, 1.45 mmol),
iodide 20 (400 mg, 1.08 mmol), and [(dppf)PdCl2](47 mg, 0.058 mmol).
Flash chromatography of the crude product (Combiflash Companion,
0!25% tert-butyl methyl ether in hexanes) afforded product 33 as a col-
orless syrup (284 mg, 0.629 mmol, 58%). Chiral HPLC analysis (Chiralcel
Tylophorine series
1,2-Dimethoxy-4-iodobenzene (36):[36] A purple solution of veratrole 35
(2.10 g, 15.23 mmol) and iodine (4.23 g, 16.7 mmol) in CH2Cl2 (60 mL)
was treated with red HgO (3.58 g, 16.5 mmol). After stirring for 5 h, the
mixture was filtered through Celite and the filtrate was washed with aq.
Na2S2O3 (5% w/w, 415 mL) and brine (50 mL) before being dried
(Na2SO4) and concentrated to a reddish oil which could be used without
further purification (3.90 g, 97%). 1H NMR (400 MHz, CDCl3): d=7.22
(dd, J=8.5, 2.1 Hz, 1H), 7.12 (d, J=2.1 Hz, 1H), 6.62 (d, J=8.4 Hz, 1H),
3.86 (s, 3H), 3.85 (s, 3H); 13C NMR (100 MHz, CDCl3): d=149.8, 149.2,
129.8, 120.4, 113.2, 82.3, 56.1, 55.9; IR (film): n˜ =3076, 2999, 1583, 1501,
1250, 839, 798, 762 cmꢀ1; MS (EI): m/z (%): 264 (100) [M +], 249 (28),
221 (8), 94 (26); HRMS (EI): m/z: calcd for C8H9IO2: 263.964730; found:
263.964440.
OJ (250 mm4.6 mm), n-heptane/isopropanol 9:1, 0.5 mLminꢀ1
,
18.38 min (R isomer), 48.27 min (S isomer)) showed that the product had
1
an enantiomeric excess of > 98%. [a]2D0 +45.6 (c 1.19, CH2Cl2); H NMR
(400 MHz, CDCl3, rotamers): d=7.42 (d, J=8.5 Hz, 1H), 7.14 (m, 1H),
7.11 (dd, J=8.2, 1.7 Hz, 1H), 6.92 (d, J=8.2 Hz, 1H), 6.88 (d, J=2.6 Hz,
1H), 6.70 (dd, J=8.5, 2.5 Hz, 1H), 3.92 (s, 3H), 3.91 (s, 3H), 3.82 (s,
3H), 3.78 (m, 1H), 3.4–3.3 (m, 2H), 2.8–2.6 (m, 1H), 2.44 (m, 1H), 1.9–
1.6 (m, 4H), 1.45 (s, 9H); 13C NMR (100 MHz, CDCl3, rotamers): d=
7406
