time for 30 min heating. Mass production at 15–20 mmol is
also verified for model compounds with satisfied yield of 64–
70%. The good tolerance of functional groups ensures myriad
possibilities in extending the structure of SpAs. More
important, SpAs with multiple amines or ketones also succeed
which could greatly extent their variety. To estimate their
applications in OLEDs, 10-(4-(tert-butyl)phenyl)-10’’-(4-(4,6-
diphenyl-1,3,5-triazin-2-yl)-phenyl)-10H,10’’H-dispiro [acri-
dine-9,10’-indeno[2,1-b]fluorene-12’,9’’-acridine] (D2T-TR)
was synthesized and evaluated as an example. EQE as high
as 27.1% have been achieved in multi-layered devices
illustrating the excellence of D2T-TR as a TADF emitter.
This procedure opens a practical perspective for assembling
SpAs for organic optoelectronic materials.
The general procedure contains two steps: pre-heating of
diarylamines with acid at 1408C under inner atmosphere for
about 15 min, then adding ketones and increasing the
temperature for 30 min reaction. Further prolonging the
reaction time contributes less to yield but more to the
byproducts. One-pot heating of all the agents would also give
the demanding compounds but with lower yields. p-Toluene-
sulfonic acid (TsOH) was used owing to its strong acidity and
low oxidability. The reaction is first investigated by screening
a series of reacting temperatures. No obvious products obtain
when the temperature is below 1608C. Meanwhile, a sharp
increase of unidentifiable byproducts and severe carboniza-
tion occurs when the reaction heated higher than 2208C. The
optimized temperature is set at 2008C.
With the optimized condition, the substrate scope with
regards to diarylamines was examined (Supporting Informa-
tion, Figure S1). As shown in Scheme 2, a series of diaryl-
amines successfully underwent the cyclization with fluore-
none (2a, Supporting Information, Figure S2) to afford SpAs
in good yields (4a–4g). This protocol shows a tolerance of
functional group including symmetrical/unsymmetrical
methyl, phenyl, t-butyl and active fluoro/chloro groups
which is important for further extension of these molecules.
Bromo substituted diarylamine (bis(4-bromophenyl)amine
(1j, Supporting Information, Figure S1)) fails the reaction
may due to high reactivity of bromo or the active N-para
position. This failure also inspires us to lock the para position
of diarylamines to avoid unfavorable reactions. Product 4d
and 4g were obtained with low yield, which may attribute to
the steric hinderance of the bulky t-butyl and m-methyl
groups on the substrates. Moreover, model compound 10H-
spiro[acridine-9,9’-fluorene] (4a) is performed under scale of
15 mmol with a satisfied yield of 64% which demonstrates the
capability of this procedure in commercial application. As
shown in the Supporting Information, Figure S3, compared
with 4a, 4b possess a little red-shifted absorption which could
ascribe to the electron-donating properties of methyl. Both
donors show identical phosphorescence, indicating their same
triplet energy level. Such properties suggest 4b could be
a useful candidate for TADF emitters.
Scheme 2. Scope of substrates with isolated yields, *: yield of mass
production (4a at 15 mmol, see supporting information, section of
synthesis and characterization), **: total yield of the inseparable
isomers.
in 2,7- and 3,6-position enabling a huge potential in post-
functionalization. Benzophenone (2j, Supporting Informa-
tion, Figure S2) with free rotating phenyl also succeeds,
indicating the possibility of assembling more flexible ketone
agents. Furthermore, anthraquinones (3a–d, Supporting
Information, Figure S4) were tested to generalize the variety
of ketones. Even better, excellent yield of 80% was reached
by 2,7-dimethyl-10H,10’H-spiro[acridine-9,9’-anthracen]-10’-
one (5a). While, bromo decorated anthraquinones could
generate SpAs with moderate yield of 44–48%. Reaction
between 1b and 2-bromo-6-phenylanthracene-9,10-dione
(3d, Supporting Information, Figure S4) generates insepara-
ble isomers 5d and 5e with a molar ratio of 0.85:1 which can
1
be identified in their H NMR spectrum (Supporting Infor-
mation). Furthermore, the combination of unsymmetrical
arylamines and ketones could afford chiral SpAs which can be
applied in developing chiral emitters.
The successful assembly of simple SpAs enlightens us to
develop more complicated structures. Multi amines N1, N3-
diphenylbenzene-1,3-diamine (1h), N1, N3-di-p-tolylbenzene-
1,3-diamine (1i, Supporting Information, Figure S1) and
ketones indeno[2,1-b]fluorene-10,12-dione (2k), indeno[1,2-
b]fluorene-6,12-dione (2l, Supporting Information, Fig-
ure S2) are examined as example. Multi-amines react well
with fluorene with good yields. More importantly, the reaction
of 1h and fluorenone could provide (Scheme 3) N-phenyl-
10H-spiro[acridine-9,9’-fluoren]-3-amine (4q) or 5’,7’-dihy-
Next, the scope of fluorenone was explored using di-p-
tolylamine (1b, Supporting Information, Figure S1) with
methyl to eliminate the extra active para position of aryl-
amines as inspired. Surprisingly, this reaction shows good
tolerance with single or double bromo units on fluorenes both
2
