Highly Fluorescent Ditopic Ligand Based on 1,6-Bis(ethynyl)pyrene
FULL PAPER
mode-locked cw-pumped Nd:YAG laser (Coherent “Antares 76-
S”), a dye amplifier and a Nd:YAG regenerative amplifier. Pulses
of 1 ps (1 mJ, 10 Hz repetition rate) tuned to 600 nm were gener-
ated. The samples were excited with 1 ps pulses at 300 nm gener-
ated by frequency doubling of the fundamental 600 nm laser pulse
in a KDP crystal. Fluorescence was collected by use of achromatic
lenses and detected through a polarizer set at magic angle (54.7°)
with a Hamamatsu C5680 streak camera and a Chromex 250IS
spectrograph.
from hot toluene to afford 5A as brown needles (200 mg, 58%
yield). 1H NMR (250 MHz, CDCl3): δ = 3.64 (s, 2 H, CϵC–H),
8.13–8.22 (m, 6 H, Hpyr), 8.62 (d, 2 H, J = 9.1 Hz, H2 and H7) ppm.
13C NMR (50.3 MHz, CDCl3): δ = 83.0 (CϵC), 125.1, 126.3, 128.3,
130.6 ppm. MS (EI), m/z: 250 [M]+.
Diethynyl Compound (7): A solution of 5A (0.401 g, 1.6 mmol), 6
(1.701 g, 3.13 mmol), and freshly distilled diethylamine (50 mL)
was freeze–pump–thaw-degassed and transferred to a mixture of
Pd[PPh3]2Cl2 (115.5 mg, 0.16 mmol) and CuI (30.8 mg, 0.16 mmol)
under argon atmosphere. The reaction mixture was heated at 50 °C
for 20 h under inert atmosphere. After the mixture had cooled
down to room temperature, the solvent was removed under vac-
uum. The crude product obtained was dissolved in dichlorometh-
ane and filtered. The filtrate was concentrated and purified by
chromatography on a silica gel column, with elution with dichloro-
methane, to yield the coupling product as an orange solid (1.03 g,
All chemicals were purchased from Aldrich Chemical Co. and were
used as received. Solvents were distilled prior to use. 1H and 13C
NMR spectra were recorded with a Bruker AC 200 or a Bruker
AC 250 spectrometer. Mass spectra were obtained with a VG Au-
tospec-Q Micromass spectrometer either in the EI or the LSIM+
(NBA matrix) mode.
Diiodopyrene (3A, 3B): Pyrene (12 g, 59.3 mmol) was dissolved in
acetic acid (400 mL) at 90 °C. The reaction mixture was cooled
to 40 °C, and then water (40 mL), iodine (15.07 g, 59.36 mmol),
potassium iodate (5.14 g, 24 mmol), and concentrated H2SO4
(4 mL) were added. The mixture was stirred at 40 °C for 4 h. The
brown solid was filtered, washed with dichloromethane and water,
and dried under vacuum to afford 3A and 3B as a mixture after
recrystallization from hot toluene (8.8 g, 32% yield). M.p. 120–
140 °C. 1H NMR (200 MHz, CDCl3): δ = 7.92 (d, J = 8.1 Hz, 2
H, H3 and H8), 8.1 (d, J = 9.1 Hz, 2 H, H4 and H9), 8.34 (d, J =
9.1 Hz, 2 H, H5 and H10), 8.54 (d, J = 8.1 Hz, 2 H, H2 and H7) ppm
for 3A. 1H NMR (200 MHz, CDCl3): δ = 7.91 (d, J = 8.1 Hz, 2
H, H3 and H6), 8.07 (s, 2 H, H4 and H5), 8.39 (s, 2 H, H9 and H10),
8,54 (d, J = 8.2 Hz, 2 H, H2 and H7) ppm for 3B.
1
61% yield). M.p. 150 °C. H NMR (200 MHz, CDCl3): δ = 0.85–
1.03 (m, 24 H, CH3), 1.2–1.85 (m, 44 H, –CH2–), 1.66 [s, 12 H,
C(CH3)2], 3.93–4.0 (m, 8 H, –O–CH2), 7.0 (s, 2 H, Hphen), 7.14 (s,
2 H, Hphen), 8.10–8.21 (m, 6 H, Hpyr), 8.80 (d, J = 9 Hz, 1 Hz, 2
H, H2 and H7) ppm. MS (LSIMS+), m/z: 1079 [M]+. Analysis:
calcd. (found) for C74H94O6 (1078): C 82.33 (82.65), H 8.78
(8.72)%.
A mixture of this protected compound (380 mg, 0.35 mmol) and
KOH (260 mg, 4.63 mmol) in toluene (20 mL) was heated at reflux
for 1 h and was then filtered. The filtrate was washed with water
until pH 7. The organic layer was dried over Na2SO4. After re-
moval of the solvent, the crude product was purified by column
chromatography (silica gel), with elution with petroleum ether/
dichloromethane (1 to 25%) to yield 7 as a yellow oil (0.180 g, 53%
yield). 1H NMR (250 MHz, CDCl3): δ = 0.80–1.05 (m, 24 H, CH3),
1.2–2.0 (m, 44 H, CH2), 3.37 (s, 2 H, CϵCH), 3.95–4.05 (m, 8 H,
OCH2), 7.06 (s, 2 H, Hphen), 7.17 (s, 2 H, Hphen), 8.12–8.21 (m, 6
H, Hpyr), 8.81 (d, J = 9.1 Hz, 2 H, H2 and H7) ppm. MS (LSIMS+),
m/z: 963 [M + 1]+.
Disubstituted Pyrene (4A, 4B): A Schlenk flask was charged with
a solution of 2-methyl-but-3-yn-2-ol (1 mL, 10.3 mmol) in freshly
distilled diethylamine (60 mL). The solution was freeze–pump–
thaw degassed and transferred to a mixture of 3A and 3B (2 g,
4.4 mmol), Pd[PPh3]2Cl2 (68 mg), and CuI (0.12 mmol) under ar-
gon atmosphere. The reaction mixture was heated at 50 °C under
argon atmosphere for 20 h. The solvent was removed under vac-
uum and the insoluble product was filtered, washed with dichloro-
methane, and dried. Compound 4A was obtained as a brownish
solid (1.07 g, 66%). The filtrate was evaporated and the crude pro-
duct was then subjected to column chromatography (silica gel) with
elution with dichloromethane/methanol (0 to 1%). Compound 4B
was obtained as a yellow solid (538 mg, 33% yield).
Bis-bipyridine Pyrene Ligand (2):
A solution of 7 (150 mg,
0.15 mmol) and 4-bromo-2,2Ј-bipyridine (78 mg, 0.33 mmol) in
freshly distilled toluene (10 mL) and diisopropylamine (4 mL) was
freeze–pump–thaw degassed and transferred by cannula to the cat-
alyst Pd[PPh3]4 (23 mg, 0.02 mmol) under argon. The reaction mix-
ture was heated at 80 °C under inert atmosphere for 24 h. After the
mixture had cooled to room temperature, the solvent was removed
under vacuum. The crude product was purified by column
chromatography (silica gel) with petroleum ether/dichloromethane
(50 to 100%) and then dichloromethane/methanol (0 to 2%) as
eluent. Compound 2 was obtained as an orange solid (120 mg, 61%
yield). 1H NMR (250 MHz, CDCl3): δ = 0.79–2.04 (m, 60 H, alkyl
chains), 4.02–4.09 (8 H, OCH2), 7.14 (s, 2 H, Hphen), 7.22 (s, 2 H,
Hphen), 7.33–7.46 (m, 4 H, Hbpy), 7.84–7.91 (m, 2 H, Hbpy), 8.14–
8.27 (m, 6 H, Hpyr), 8.38–8.43 (m, 2 H, Hbpy), 8.57 (s, 3 H, Hbpy),
8.66–8.78 (m, 4 H, Hbpy), 8.84 (d, J = 9.1 Hz, 2 H, H2 and
H7) ppm. MS (LSIMS+), m/z: 1271 [M + 1]+. Analysis calcd.
(found) for C88H94N4O4 (1270): C 83.11 (82.01); H 7.45 (7.77); N
4.41 (3.56).
1
Compound 4A: M.p. 237–238 °C. H NMR (200 MHz, CDCl3): δ
= 1.81 (s, 12 H, CH3), 8.09–8.13 (m, 6 H, Hpyr), 8.52 (d, J = 9.1 Hz,
2 H, H2 and H7) ppm. 13C NMR (50.3 MHz, CDCl3): δ = 32.1
(CH3), 82.4 (CϵC), 82.9 (CϵC), 117.2, 125.0, 126.2, 128.2, 130.4,
131.3, 132.4, 132.7 ppm. MS (EI): m/z: 366 [M]+. Analysis: calcd.
(found) for C26H22O2 (198): C 85.24 (83.91), H, 6.01 (6.06).
1
Compound 4B: M.p. 95–100 °C. H NMR (250 MHz, CDCl3): δ =
1.80 (s, 12 H, CH3), 8.04 (s, 2 H, H3 and H6), 8.11 (s, 4 H, H4, H5,
H9 and H10), 8.60 (s, 2 H, H2 and H7) ppm. 13C NMR (50.3 MHz,
CDCl3): δ = 31.8 (CH3), 66.1 (–C–CϵC), 81.1 (CϵC), 100 (CϵC),
117.9, 125.0, 126.2, 127.9, 131.3, 132.8 ppm. MS (EI), m/z: 366
[M]+; Analysis: calcd. (found) for C26H22O2 (198): C 85.24 (84.10),
H 6.01 (6.02)%.
1,6-Diethynyl-pyrene (5A): A solution of 4A (500 mg, 1.34 mmol)
and NaOH (480 mg, 12 mmol) in freshly distilled toluene (20 mL)
was heated at reflux for 3 h. This solution was filtered while hot.
After cooling down to room temperature, the organic layer was
washed with water until pH = 7 and dried over sodium sulfate, and
the solvents were evaporated. The crude product was recrystallized
Acknowledgments
We are grateful to Dr. Jean Oberlé (Université Bordeaux 1, Talence,
France) for his kind assistance in time-resolved fluorescence spec-
troscopy measurements.
