Acrylates via Metathesis of Crotonates
Dirk Schweitzer, and Kristi Snell
Org. Process Res. Dev., Just Accepted Manuscript • DOI: 10.1021/op5003006 • Publication Date (Web): 05 Nov 2014
Downloaded from http://pubs.acs.org on November 6, 2014
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
Organic Process Research & Development is published by the American Chemical
Society. 1155 Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
Acrylates via Metathesis of Crotonates
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Dirk Schweitzer* and Kristi D. Snell
Metabolix, 21 Erie St., Cambridge, MA 02139, USA. E-mail: dschweitzer@metabolix.com
KEYWORDS: Acrylate, bio-based, crotonate, metathesis, poly-3-hydroxybutyrate (P3HB).
ABSTRACT
Crotonic acid has the potential to be produced from renewable resources at low cost, but has
currently a limited market. We are investigating catalytic routes to exploit the functionalities of
crotonic acid to produce a range of established industrial chemicals. Here we report our work on
converting crotonates to acrylates, where a cost-competitive bio-based alternative can provide a
market advantage. Our optimized cross-metathesis reaction conditions between crotonates and
ethylene resulted in an increase of catalyst turn-over numbers by two orders of magnitude as
compared to literature values. Control experiments showed the cross-metathesis with ethylene to
be an equilibrium reaction. The turn-over number limiting factor was found to be the stability of
the metathesis catalyst.
ACS Paragon Plus Environment
1

Organic Process Research & Development
Page 2 of 20
1
2
3
4
Introduction
5
6
7
8
9
Acrylic acid and acrylates are important industrial chemicals from which many products
are manufactured.1 Current industrial processes synthesize these molecules from fossil resources
(oil, coal, natural gas),1 which are not renewable within a human time scale.2 Thus, pathways to
provide “bio-based” acrylates starting from biological materials are being developed.3-10 In order
to access bio-based acrylates, we are pursuing two pathways. One involves the production of
poly-3-hydroxypropionate (P3HP), a member of the polyhydroxyalkanoate family of bio-
polymers, in a microbial organism, followed by its thermolysis/pyrolysis to provide acrylic
acid8,9 or alcoholysis to provide acrylates.9 A related approach is the direct fermentative
production of 3-hydroxypropionic acid followed by its dehydration.5-7 Since the production of a
bio-based chemical directly from plant biomass has the potential to be cost advantaged, we are
investigating a second pathway. We have carried out extensive work to produce poly-3-
hydroxybutyrate (P3HB) in the biomass of genetically engineered plants.11-15 The
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
thermolysis/pyrolysis of P3HB to provide crotonic acid is a well-known process,16,17 which can
be performed directly on P3HB-containing plant biomass.8,18,19 Crotonic acid has the potential to
be a valuable platform chemical, if it can be produced at a low cost, providing access to a range
of industrial and fine chemicals such as n-butanol,20 fumaric acid, maleic anhydride, propylene,
and acrylic acid/acrylates.11 As part of our efforts to develop crotonic acid as a bio-based
platform chemical derived from P3HB-producing plants,11,19,20 we investigated the production of
acrylates via the olefin metathesis of crotonates. Acrylic acid/acrylates have been previously
synthesized via the ethenolysis of crotonic acid, cinnamic acid, or cinnamates,21,22 diethyl
fumarate,23 and bio-based di-n-butyl muconate.24,25 However, in all of these reactions, only
modest turn-over numbers (TONs) (0 to 25) were achieved, thus requiring high catalyst loadings
ACS Paragon Plus Environment
2

Page 3 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
(2 to 12.5 mol %) to reach high yields. Herein, we report the results of our studies aimed at
maximizing the TONs of metathesis catalysts and understanding the parameters influencing the
cross-metathesis between ethylene/propylene and crotonates.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1.
Catalysts evaluated in this study.
Experimental
All utilized chemicals were purchased from commercial suppliers and used as received.
Specifically, the metathesis catalysts (Figure 1) were purchased from Aldrich (Grubbs I, CAS
number: 172222-30-9; Grubbs II, 246047-72-3; Hoveyda-Blechert,26 301224-40-8; 2-Pr-Py,
802912-44-3) and Strem Chemicals (Re2O7, 1314-68-7; di-RuOD, 34801-97-3; catMETium
RF3, 1190427-50-9; Zhan 1B, 918870-76-5; immobilized Zhan 1B; iBu-C8, 894423-99-5; SB-
ACS Paragon Plus Environment
3

Organic Process Research & Development
Page 4 of 20
1
2
3
4
5
6
H, 934538-12-2; SB-NO2, 934538-04-2). Ethylene (Chemical Pure grade, pmax ~ 255 psi) and
propylene (polymer-grade, pmax ~ 115 psi) were purchased from Airgas.
7
8
9
The self-metathesis experiments were performed in sealed tubes: the neat substrate (2 g,
ethyl crotonate or ethyl acrylate) or a solution of the substrate in dioxane (2 g in 6 g dioxane,
crotonic acid or acrylic acid) and the catalyst (~ 20 mg) were held under stirring at room
temperature overnight. The reaction mixtures were analyzed using HPLC. All metathesis
reactions using a gas as one of the reactants were conducted in a 5522-series Parr reactor. To the
Parr reactor internal glass vessel were added the substrate (0.35 mol, ethyl crotonate, n-butyl
crotonate, or ethyl cinnamate) followed by a weighted amount of catalyst. After assembly of the
Parr reactor, under stirring, its contents were degassed 3 times with N2 (80 to 10 psi). The
internal pressure was now allowed to lower to 0 psi, at which point the metathesis partner gas
(ethylene or propylene) was introduced up to the desired pressure. Following the disconnection
of the gas cylinder, the contents of the Parr reactor were heated to the desired temperature for the
desired amount of time. After cooling to room temperature, the Parr reactor was opened, and a
sample of the reaction solution was analyzed by HPLC. Detailed HPLC methods, all numerical
results, and selected chromatograms are provided in the supporting information.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Results and Discussion
Ethylene-free Reaction
Ruthenium olefin metathesis catalysts are known to be unstable in the presence of
ethylene.27-31 If, however, steps are undertaken to remove ethylene from the reaction mixture
ACS Paragon Plus Environment
4

Page 5 of 20
Organic Process Research & Development
1
2
long catalyst life times can be realized.32 We thus decided to investigate the cross-metathesis
between alkyl crotonate and propylene (Scheme 1) using the Hoveyda-Blechert catalyst (Figure
1),33,34 which proved to be one of the more active catalysts examined herein, vide infra. Such a
process provides the advantage that the initial metathesis products are alkyl acrylate and 2-
butene, meaning that “the metathesis catalyst is never exposed to ethylene and is therefore”
expected “to maintain the high reaction rates and high yields needed for industrial biochemical
processes”.8
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 1.
Cross-metathesis between alkyl crotonate and propylene
Surprisingly, only a relatively small amount of alkyl acrylate was formed in each case (R
= Et: 1.6 % yield, TON = 32; R = n-Bu: 4.8 % yield, TON = 96). It is thus of interest to
understand the parameters influencing the cross-metathesis between alkyl crotonate and
ethylene/propylene.
ACS Paragon Plus Environment
5

Organic Process Research & Development
Page 6 of 20
1
2
3
4
Catalyst Screen of Self-Metathesis Reactions
5
6
7
8
9
In order to determine the relative catalytic ability of various metathesis catalysts (Figure
1) the self-metathesis reactions of ethyl crotonate (EtCr), ethyl acrylate (EtAc), crotonic acid
(CA), and acrylic acid (AA) were chosen as test reactions (Scheme 2).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 2.
Self-metathesis catalyst and substrate screening experiments
O
2
OR
R = Et or H
ethyl crotonate or crotonic acid
2-butene
O
self-metathesis
RO
+
or
or
OR
R = Et or H
diethyl fumarate
or fumaric acid
O
O
~ 0.12 mol % catalyst each
neat or in dioxane (R = H)
in sealed tube, 25 oC, 21 h
2
OR
R = Et or H
ethyl acrylate or acrylic acid
ethylene
Table 1.
Selected results of the self-metathesis screening experimentsa
Amount of Diethyl Fumarate / Fumaric Acid Self-Metathesis Product
[Area %]
Substrate
Catalyst
catMETium RF3
Grubbs II
Hoveyda-Blechert
Zhan 1B
EtCr
NR
0.2
NR
0.1
EtAc
4.4
13.5
22.9
24.7
7.0
CA
NR
0.1
NR
0.1
NR
AA
0.1
1.3
7.7
4.7
1.0
2-Pr-Py
NR
aReaction conditions as denoted in Scheme 2. NR = < 0.1 area % of product present.
ACS Paragon Plus Environment
6

Page 7 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
The reaction mixtures were analyzed by HPLC and the catalytic ability of each catalyst
was judged by the observed peak area of the diethyl fumarate or fumaric acid product. Only
catalysts catMETium RF3, Grubbs II, Hoveyda-Blechert, Zhan 1B, and 2-Pr-Py provided a
significant amount of product (Tables 1 and S-5). Using ethyl acrylate as the starting material
provided an order of magnitude larger amount of self-metathesis product than did acrylic acid,
whereas ethyl crotonate provided a two orders of magnitude smaller amount of product as
compared to ethyl acrylate. These results may reflect differences in the equilibrium
compositions35 resulting from these substrates and the reduced stability of metathesis catalysts in
a protic environment.21,22
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Solvent Screen of the Cross-Metathesis
Since the Hoveyda-Blechert catalyst is one of the most active catalysts of our study
(Tables 1 and S-5), it was used in the investigation of the solvent dependence of the cross-
metathesis between ethyl crotonate and ethylene or propylene (Scheme 3).
Scheme 3.
Solvent screen of the cross-metathesis between ethyl crotonate and ethylene
or propylene
ACS Paragon Plus Environment
7

Organic Process Research & Development
Page 8 of 20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 2.
Results of the solvent screen of the cross-metathesis between ethyl crotonate and
ethylene or propylene using the Hoveyda-Blechert catalyst (reaction conditions as denoted in
Scheme 3).
Importantly, the highest TON was observed when ethyl crotonate was used without any
additional solvent (Figure 2). The relative TONs observed in the four screened metathesis
solvents are: neat ethyl crotonate substrate >> CH2Cl2 > propylene carbonate > dioxane. Notably,
in all screened solvents the cross-metathesis using ethylene achieved about a 4-fold larger
number of turnovers than the cross-metathesis using propylene. Potential reasons for these
different observed TONs are not known, but may include (a) a difference of the ethylene versus
propylene reaction rate constant, corresponding to a different amount of reaction that can occur
prior to catalyst decomposition, vide infra, (b) a difference in the ethylene versus propylene
reaction equilibrium composition, and (c) competing “non-productive” metathesis in the
ACS Paragon Plus Environment
8

Page 9 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
propylene reaction. Experiments to correctly identify these reason(s) are beyond the scope of our
study. The results for the solvent dependence of the corresponding cross-metatheses catalyzed by
SB-H and SB-NO2 (Figure 1) are included in the SI (Table S-8). These two metathesis catalysts
contain an alkoxide-Schiff-base bidentate ligand. They achieved double digit TONs at 60 °C in
neat substrate as the reaction medium, but only single digit TONs at 40 °C, indicative of their
higher reactivity at higher temperatures.36,37
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Temperature and Pressure Screen of the Ethylene Cross-Metathesis
Since ethylene is a better metathesis partner than propylene (Figure 2) and the Hoveyda-
Blechert catalyst is one of the most active catalysts of our study (Tables 1 and S-5), the effects of
temperature and pressure on the cross-metathesis between ethyl crotonate and ethylene catalyzed
by it were investigated (Scheme 4).
Scheme 4.
Temperature and pressure screen of the cross-metathesis between ethyl
crotonate and ethylene
ACS Paragon Plus Environment
9

Organic Process Research & Development
Page 10 of 20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 3.
Contour map of the experimental results of the temperature- and pressure-
dependent cross-metathesis between ethyl crotonate and ethylene using the Hoveyda-Blechert
catalyst (reaction conditions as denoted in Scheme 4).
Two main conclusions can be derived from the results of these experiments (Figure 3).
Firstly, significant catalyst decomposition must be occurring within the first 2 h of the metathesis
reaction, since the observed TON of the room temperature reaction after 2 h is not much lower
than the TON of the room temperature reaction after 21 h. Secondly, the ethylene pressure
utilized determines the amount of conversion of starting material occurring, as quantified by the
TON achieved.38 Our finding of a steady increase of the observed TON as a function of the
ethylene pressure contradicts previously published work, wherein a maximum TON of 5.8 was
observed for the cross-metathesis of cinnamic acid with ethylene at just 7.3 psi of ethylene
ACS Paragon Plus Environment
10

Page 11 of 20
Organic Process Research & Development
1
2
pressure.21,22 In comparison to the effect of ethylene pressure on the result of this metathesis
reaction, temperature does not have any apparent effect. These results show that in the case of
the Hoveyda-Blechert catalyst, the cross-metathesis of ethyl crotonate with ethylene proceeds
best when conducted at room temperature using the maximum possible ethylene pressure (255
psi) which could be applied using the equipment available for our study. The numerical TONs
for all experiments of Figure 3 are included in the SI (Table S-9).
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Cross-Metathesis Equilibrium Determination
Metathesis reactions are in general equilibrium reactions.35 Although catalyst
decomposition occurs under our reaction conditions, knowledge of the equilibrium state is
necessary for the design of a commercially relevant process. A commercial alkyl crotonate to
alkyl acrylate process would consist of two unit operations: a cross-metathesis of the alkyl
crotonate with either ethylene or propylene over an immobilized catalyst followed by a
distillative separation step to isolate the desired alkyl acrylate product from the equilibrium
amount of alkyl crotonate starting material.39 In this scenario, the metathesis catalyst is not
exposed to the elevated temperatures necessary for the distillation. Unreacted alkyl crotonate
starting material, combined with fresh starting material, can be subjected to another round of
cross-metathesis.
ACS Paragon Plus Environment
11

Organic Process Research & Development
Page 12 of 20
1
2
3
4
Scheme 5.
Equilibrium determination of the cross-metathesis between ethyl or n-butyl
5
6
crotonate and ethylene
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
By approaching the metathesis equilibrium from both the forward and reverse direction
using increasing catalyst loadings (Scheme 5), linear relationships between the amounts of both
the starting material and product as a function of the catalyst loading were obtained (Tables S-
10), allowing calculation of the approximate equilibrium compositions (Table 2).
In both the ethyl and n-butyl system, the metathesis equilibrium state is characterized by
a near 3/2 alkyl crotonate to alkyl acrylate ratio, representing the maximum achievable amount
of alkyl acrylate via the reaction of alkyl crotonate with ethylene, if no product is continuously
removed from the reaction mixture. Separation of the alkyl acrylate product from the reaction
mixture containing an excess of alkyl crotonate is necessary as a consequence of the equilibrium
state of this metathesis reaction.
Interestingly, in comparison to the equilibrium state of the ethyl ester metathesis reaction
(35.8 mol % of ethyl acrylate) the equilibrium state of the n-butyl ester metathesis reaction (39.6
mol % of n-butyl acrylate) is shifted by a small amount, 3.8 mol %, towards the product side,
indicative of a more hydrophobic environment in the n-butyl ester system. As an extension of
this observation, it is expected that using an even longer alkyl crotonate ester will result in an
even larger amount of alkyl acrylate ester present at equilibrium. Comparing (Table 2) the alkyl
ACS Paragon Plus Environment
12

Page 13 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
crotonate + ethylene = alkyl acrylate + propylene equilibria (Equation 1) with the methyl oleate
ethenolysis equilibrium, methyl oleate + ethylene = 1-decene + methyl 9-decenoate (Equation
2),40 whose equilibrium constant has been determined,35,41,42 confirms this prediction in that the
more hydrophobic environment of methyl oleate results in the shift of its ethenolysis equilibrium
to the right side (94.6 mol % each of 1-decene and methyl 9-decenoate).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Keq = ([alkyl acrylate][propylene])/[alkyl crotonate]
Keq = ([1-decene][methyl 9-decenoate])/[methyl oleate]
[Equation 1]
[Equation 2]
Table 2.
Equilibrium compositions of ethenolysis reactions
at Equilibrium
Ethenolysis Substrate
Ethyl Crotonate
mol % Substrate
mol % Product
Equilibrium Constant
64.2
60.4
5.36
35.8
39.6
94.64
0.20
0.26
16.7
n-Butyl Crotonate
Methyl Oleate35,41,42
The limited catalyst stability became evident in these two equilibrium determination
experiments. Although in both systems a near identical equilibrium state is approached, in the n-
butyl ester system more conversion occurred prior to the catalyst loosing activity, i.e., the
equilibrium was reached at an apparent catalyst loading of 0.34 mol % (Figure S-10-n-Bu),
whereas in the ethyl ester system the equilibrium was reached at an apparent catalyst loading of
ACS Paragon Plus Environment
13

Organic Process Research & Development
Page 14 of 20
1
2
3
4
5
6
7
8
9
0.53 mol % (Figure S-10-Et). It is thus of interest to determine the time course of the ethylene
metathesis, i.e., for how long conversion to product occurs before the catalyst loses activity
(decomposes).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Time-Course of the Cross-Metathesis with Ethylene
To determine the stability of the Hoveyda-Blechert metathesis catalyst under the reaction
conditions, the time course of the cross-metathesis of ethylene with ethyl crotonate and n-butyl
crotonate was investigated using a series of independent experiments (Scheme 6).
Scheme 6.
ethylene
Time-dependent cross-metathesis between ethyl or n-butyl crotonate and
ACS Paragon Plus Environment
14

Page 15 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 4.
Results of the time-dependent cross-metathesis between ethyl or n-butyl crotonate
and ethylene catalyzed by the Hoveyda-Blechert catalyst (reaction conditions as denoted in
Scheme 6). Each data point is the end point of an experiment which was stopped at the indicated
time.
It was found that the ethylene metathesis with ethyl crotonate reached maximum yield
within 1.3 h, whereas the corresponding reaction with n-butyl crotonate occurred for up to 3 h
(Figure 4). Ceasing of product formation, while the equilibrium has not yet been reached, is
indicative of the catalyst having undergone decomposition. These results show that the Hoveyda-
Blechert catalyst is more stable in n-butyl crotonate than in ethyl crotonate. It can catalyze more
reaction cycles in n-butyl crotonate, TON = 444 under our reaction conditions (t = 2.67 h
experiment), than in ethyl crotonate, TON = 280 (t = 1.33 h experiment), before it decomposes.
The higher catalyst stability in n-butyl crotonate as the solvent, as compared to ethyl crotonate, is
also evident in the equilibrium determination experiments previously discussed. In comparison,
since methyl oleate is more hydrophobic than n-butyl crotonate, even longer catalyst life times
are realized in it, allowing the achievement of one order of magnitude higher ethylene metathesis
ACS Paragon Plus Environment
15

Organic Process Research & Development
Page 16 of 20
1
2
TONs.41,43-45 The numerical TONs for all time-dependent cross-metathesis experiments are
included in the SI (Table S-11).
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Reaction Pathway Control Experiments
An alternative mechanistic pathway for the formation of alkyl acrylate from alkyl
crotonate could occur via dialkyl fumarate as an intermediate: a self-metathesis of alkyl
crotonate to form butylene and dialkyl fumarate followed by its cross-metathesis/cleavage with
ethylene to provide two equivalents of alkyl acrylate (Scheme S-12). To test this hypothesis, neat
ethyl crotonate was exposed to metathesis catalyst without any metathesis partner gas being
present (0.1 % yield, TON 1) and neat diethyl fumarate was exposed to the maximum possible
pressure of ethylene (255 psi), which was available for our study, in the presence of metathesis
catalyst (1.0 % yield, TON 20).23 The results of these two control experiments demonstrate that,
while some reaction products were detected, the pathway via dialkyl fumarate as an intermediate
does not significantly contribute to the formation of alkyl acrylate from alkyl crotonate in the
presence of ethylene.
Optimal Reaction Temperature of Metathesis Catalysts
The temperature- and pressure-dependent experiments presented above for the Hoveyda-
Blechert catalyst show that it catalyzes the cross-metathesis of ethyl crotonate with ethylene best
when the reaction is conducted at room temperature under the maximum possible ethylene
pressure (255 psi) available for our study. Using the ethenolysis of n-butyl crotonate under 255
ACS Paragon Plus Environment
16

Page 17 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
psi ethylene pressure as the test reaction, the optimal reaction temperature of selected other
metathesis catalysts was determined. For comparison, the ethenolyses of ethyl crotonate and
ethyl cinnamate21,22 were then performed at these optimized temperatures. Maximum TONs in
the 500s were observed for the ethenolysis of n-butyl crotonate (HB and Z1B at 25 °C, 2-Pr-Py
at 60 °C), in the 300s for ethyl crotonate (HB and Z1B at 25 °C, SB-H at 120 °C), and in the
100s for ethyl cinnamate (HB and Z1B at 25 °C) (Tables 3 and S-13).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Table 3.
Selected results showing the optimal reaction temperature of various ethenolysesa
TON
Substrate
Catalyst
Hoveyda-Blechert
Zhan 1B
T [°C]
25
25
60
120
n-Butyl Crotonate Ethyl Crotonate Ethyl Cinnamate
492
537
537
356
332
350
210
340
125
125
73
2-Pr-Py
SB-H
48
a0.05 mol % catalyst, 255 psi ethylene, 21 h.
Conclusions
Our optimized cross-metathesis reaction conditions (neat crotonate substrate, 25 °C, 255
psi ethylene, Hoveyda-Blechert or Zhan 1B catalyst) resulted in an increase of the observed
TONs by two orders of magnitude as compared to previously reported values.21-23,25 Maximum
TONs in the 500s were achieved for the ethenolysis of n-butyl crotonate, in the 300s for ethyl
crotonate, and in the 100s for ethyl cinnamate. Control experiments showed the cross-metathesis
with ethylene to be an equilibrium reaction. Thus, a commercially relevant process must include
ACS Paragon Plus Environment
17

Organic Process Research & Development
Page 18 of 20
1
2
3
4
5
6
a separation step of the formed product from the equilibrium reaction mixture. The TON limiting
factor was found to be the stability of the metathesis catalyst.
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Acknowledgements
The authors thank Mr. David Lanteigne for developing the HPLC methods to analyze the
carboxylic acids and ethyl esters. This research was supported by a grant from the US
Department of Energy’s (DOE) Office of Energy Efficiency and Renewable Energy (EERE) to
Metabolix (grant DE-EE0004943).
Supporting Information. Detailed experimental methods, all numerical results, and selected
chromatograms. This material is available free of charge via the Internet at http://pubs.acs.org.
References
(1) Arpe, H.-J. Industrial Organic Chemistry; Wiley-VCH: Weinheim, Germany, 2010.
(2) Murray, J.; King, D. Nature 2012, 481, 433.
(3) Devaux, J.-F.; Fauconet, M.; Tlili, N. WO Patent 156,706 (CAN159:610545), 2013.
(4) Ozmeral, C.; Glas, J. P.; Dasari, R.; Tanielyan, S.; Bhagat, R. D.; Kasireddy, M. R. WO
Patent 033,845 (CAN156:419366), 2012.
(5) Tengler, R.; DeCoster, D.; Hoyt, S.; Roach, S. WO Patent 192,453 (CAN160:118080), 2013.
(6) Jessen, H. J.; Liao, H. H.; Gort, S. J.; Selifonova, O. V. WO Patent 027,742
(CAN148:324131), 2008.
(7) Bindel, M. WO Patent 085,330 (CAN161:54282), 2014.
(8) van Walsem, J.; Anderson, E.; Licata, J.; Sparks, K. A.; Mirley, C.; Sivasubramanian, M. S.
WO Patent 100,608 (CAN155:301407), 2011.
(9) Harris, S.; Sparks, K. A.; Peoples, O. P.; Shabtai, Y.; McChalicher, C. W. J.; van Walsem, J.;
Mirley, C.; Schweitzer, D. WO Patent 185,009 (CAN160:34188), 2013.
(10) Tullo, A. H. Chemical & Engineering News 2013, 91, 18.
ACS Paragon Plus Environment
18

Page 19 of 20
Organic Process Research & Development
1
2
3
4
5
6
7
8
9
(11) Somleva, M. N.; Peoples, O. P.; Snell, K. D. Plant Biotechnology Journal 2013, 11, 233.
(12) McQualter, R. B.; Petrasovits, L. A.; Gebbie, L. K.; Schweitzer, D.; Blackman, D. M.;
Hodson, M. P.; Plan, M. R.; Riches, J. D.; Snell, K. D.; Brumbley, S. M.; Nielsen, L. K. Plant
Biotechnology Journal, In Press.
(13) Somleva, M. N.; Snell, K. D.; Beaulieu, J. J.; Peoples, O. P.; Garrison, B. R.; Patterson, N.
A. Plant Biotechnology Journal 2008, 6, 663.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
(14) Bohmert-Tatarev, K.; McAvoy, S.; Daughtry, S.; Peoples, O. P.; Snell, K. D. Plant
Physiology 2011, 155, 1690.
(15) McQualter, R. B.; Somleva, M. N.; Gebbie, L. K.; Li, X.; Petrasovits, L. A.; Snell, K. D.;
Nielsen, L. K.; Brumbley, S. M. BMC Biotechnology 2014, 14, 83.
(16) Ariffin, H.; Nishida, H.; Shirai, Y.; Hassan, M. A. Polymer Degradation and Stability 2008,
93, 1433.
(17) Billingham, N. C.; Henman, T. J.; Holmes, P. A. In Developments in Polymer Degradation;
Elsevier Applied Science Publishers: London, 1987; Vol. 7, Chapter 3, p 81.
(18) Talbot, D. MIT Technology Review 2013, 116, 84.
(19) Mullen, C. A.; Boateng, A. A.; Schweitzer, D.; Sparks, K.; Snell, K. Journal of Analytical
and Applied Pyrolysis 2014, 107, 40.
(20) Schweitzer, D.; Mullen, C. A.; Boateng, A. A.; Snell, K. D. Organic Process Research &
Development, in Press (DOI: 10.1021/op500156b).
(21) Sanders, J. P. M.; van Haveren, J.; Scott, E. L.; van Es, D. S.; Le Nôtre, J.; Spekreijse, J.
WO Patent 002,284 (CAN154:88689), 2011.
(22) Spekreijse, J.; Le Nôtre, J.; van Haveren, J.; Scott, E. L.; Sanders, J. P. M. Green Chemistry
2012, 2747.
(23) Burk, M. J.; Pharkya, P.; van Dien, S. J.; Burgard, A. P.; Schilling, C. H. WO Patent
045,637 (CAN150:423701), 2009.
(24) Bui, V.; Lau, M. K.; MacRae, D.; Schweitzer, D. WO Patent 085,311 (CAN155:180076),
2011.
(25) Schofer, S.; Safir, A.; Vazquez, R. WO Patent 082,264 (CAN159:75685), 2013.
(26) It is also known as the “2nd generation Hoveyda-Grubbs catalyst.”
(27) Schwab, P.; Grubbs, R. H.; Ziller, J. W. Journal of the American Chemical Society 1996,
118, 100.
(28) Sanford, M. S.; Love, J. A.; Grubbs, R. H. Journal of the American Chemical Society 2001,
123, 6543.
(29) Hong, S. H.; Day, M. W.; Grubbs, R. H. Journal of the American Chemical Society 2004,
126, 7414.
(30) Hong, S. H.; Wenzel, A. G.; Salguero, T. T.; Day, M. W.; Grubbs, R. H. Journal of the
American Chemical Society 2007, 129, 7961.
(31) Sauvage, X.; Zaragoza, G.; Demonceau, A.; Delaude, L. Advanced Synthesis & Catalysis
2010, 352, 1934.
(32) Scholz, J.; Loekman, S.; Szesni, N.; Hieringer, W.; Görling, A.; Haumann, M.;
Wasserscheid, P. Advanced Synthesis & Catalysis 2011, 353, 2701.
(33) Garber, S. B.; Kingsbury, J. S.; Gray, B. L.; Hoveyda, A. H. Journal of the American
Chemical Society 2000, 122, 8168.
(34) Gessler, S.; Randl, S.; Blechert, S. Tetrahedron Letters 2000, 41, 9973.
(35) Grubbs, R. H.; Nguyen, S. T.; Johnson, L. K.; Hillmyer, M. A.; Fu, G. C. WO Patent 04,289
(CAN125:58749), 1996.
ACS Paragon Plus Environment
19

Organic Process Research & Development
Page 20 of 20
1
2
3
4
5
6
7
8
9
(36) Chang, S.; LeRoy, J. I.; Wang, C.; Henling, L. M.; Grubbs, R. H. Organometallics 1998, 17,
3460.
(37) Drozdzak, R.; Allaert, B.; Ledoux, N.; Dragutan, I.; Dragutan, V.; Verpoort, F. Advanced
Synthesis & Catalysis 2005, 347, 1721.
(38) Under our reaction conditions, crotonate reacted to form only acrylate, and no further
reaction of acrylate was observed.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
(39) The boiling points at atmospheric pressure of the starting material and more volatile product
of this reaction are sufficiently different (> 30 K) allowing for an efficient distillative separation:
ethyl crotonate (142 oC), ethyl acrylate (100 oC), n-butyl crotonate (180 oC), and n-butyl acrylate
(145 oC).
(40) Since ethylene was present in an excess in these reactions, its "effective concentration"
(fugacity) did not change.
(41) Burdett, K. A.; Harris, L. D.; Margl, P.; Maughon, B. R.; Mokhtar-Zadeh, T.; Saucier, P. C.;
Wasserman, E. P. Organometallics 2004, 23, 2027.
(42) Kabro, A.; Roisnel, T.; Fischmeister, C.; Bruneau, C. Chemistry - A European Journal
2010, 16, 12255.
(43) Forman, G. S.; McConnell, A. E.; Hanton, M. J.; Slawin, A. M. Z.; Tooze, R. P.; van
Rensburg, W. J.; Meyer, W. H.; Dwyer, C.; Kirk, M. M.; Serfontein, D. W. Organometallics
2004, 23, 4824.
(44) Holtcamp, M. W.; Faler, C. A.; Huff, C. P.; Bedoya, M. S.; Hagadorn, J. R. WO Patent
100,022 (CAN155:328408), 2011.
(45) Schrodi, Y.; Pederson, R. L.; Kaido, H.; Tupy, M. J. WO Patent 046,106
(CAN148:474047), 2008.
Graphic for the Journal’s Table of Contents
this study
+ ethylene
O
O
O
O
+ n-BuOH
H
O
thermolysis
OH
O-n-Bu
n-butyl crotonate
O-n-Bu
n-butyl acrylate
esterification
+ propylene
OH
n
crotonic acid
metathesis
P3HB/biomass
ACS Paragon Plus Environment
20
