An integrated platform for automatic design and screening
of virtual mutants based on 3D-QSAR analysis
Valerio Ferrarioa, Cynthia Eberta, Allan Svendsenb,
Werner Besenmatterb, Lucia Gardossia,∗
a Dipartimento di Scienze Chimiche e Farmaceutiche, Università degli Studi di Trieste, Piazzale Europa 1, 34127 Trieste, Italy
b Novozymes A/S, Krogshoejvej 36, DK-2880 Bagsvaerd, Denmark
a r t i c l e i n f o
a b s t r a c t
Article history:
An innovative application of 3D-QSAR methodology to the rational design of enzymes is here reported.
The introduction of amidase activity inside the scaffold of lipase B from Candida antarctica (CaLB) was
studied and 3D-QSAR models were constructed to correlate the structures of a set of CaLB mutants with
their experimentally measured activities. Properties, like hydrophilicity, hydrophobicity and hydrogen
bonding capability of the enzyme active site were computed by means of the GRID method and the
output was used as molecular descriptors. Correlations with experimental behavior of the catalysts were
calculated by means of partial least square regression (PLS). The analysis of the QSAR model fully exploits
fundamental knowledge while avoiding conceptual biases. Rationales for driving enzyme engineering
are disclosed and a priori evaluation of new virtual candidate mutants becomes feasible. On that respect,
the whole procedure for production of virtual mutants and scoring of their activity was automated within
a workflow constructed by means of the modeFRONTIER package. The method allows for the automated
construction and scoring of each mutant in 2 h on a normal workstation.
Received 8 October 2013
Received in revised form
19 November 2013
Accepted 9 December 2013
Available online 18 December 2013
Keywords:
Rational enzyme engineering
3D-QSAR
In silico automatic screening
Multivariate, Statistical analysis
© 2013 Elsevier B.V. All rights reserved.
1. Introduction
high [4–6] or moderately high [7–9] level of theory. However,
the computational demand of these methods makes it difficult to
Natural biocatalysts are often not optimally suited for industrial
applications. The development of efficient strategies for improving
enzyme properties and expanding the range of reactions catalyzed
by enzymes is of crucial importance for boosting the use of biocat-
alysts at industrial level.
Over the past twenty years, enzyme properties have been tail-
ored through in vitro directed evolution of enzymatic proteins
using random genetic mutation and recombination, followed by
screening for a desired enzymatic activity. This technique does
not rely on a priori knowledge of the relationship between protein
structure and function [1].
As an alternative approach, enzyme properties have been opti-
mized by means of rational design, usually assisted by molecular
modeling and bioinformatic analysis [2,3]. Ideally, rational design
of enzyme mutants should be driven by fundamental knowledge
of the whole array of structural, electronic and functional factors
that affect enzyme properties. Current computational studies of
enzyme activity as measured by the activation free energy generally
restrict their focus to the wild type enzyme and a limited num-
ber of mutants, which have been described with a comparatively
apply them to the actual design of new enzymatic catalysts where
the activity of hundreds of mutants has to be evaluated. Hediger
et al. have recently published a computational method for high-
throughput computational screening of mutant activity [10] and
the method was benchmarked against experimentally measured
amidase activity for mutants of Candida antarctica lipase B (CaLB)
with the aim of identifying promising mutants.
Here we report on an alternative computational strategy for
approaching the same engineering problem. Molecular model-
ing, experimental studies and multivariate statistical analysis are
merged to develop low computational demanding models for in
silico screening and analysis of mutants.
The main concept at the basis of this hybrid strategy is that cat-
alytic efficiency of enzymes depends on multiple contributions of
factors that are not independent but rather interact among them,
thus resulting in a complex behavior. Consequently, it is manda-
tory to follow a strategy that allows identifying and analyzing not
only the effect of each single variable but also their interactions.
Multivariate statistical analysis is the tool able to account for vari-
able interactions and to extract the relevant information contained
in huge matrixes of data [11]. Principal Component Analysis (PCA)
and Partial Least Square analysis (PLS) are suitable for the interpre-
tation and modeling of complex systems described by exceeding
number of variables. Variables that are correlated with one another
∗
Corresponding author.
E-mail address: gardossi@units.it (L. Gardossi).
1381-1177/$ – see front matter © 2013 Elsevier B.V. All rights reserved.
http://dx.doi.org/10.1016/j.molcatb.2013.12.004

8
V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
are combined into a ‘principal component’ (or latent variable) so
that objects are projected on a space of reduced dimensionality (i.e.
a reduced number of independent variables corresponding to the
new components) [12]. In particular, when a certain response (Y
variable) of the system must be modeled and optimized, the new
variables or components are extracted to give the best fit of both
Y and X variable matrices. This is accomplished by applying the
PLS analysis, where the Y latent variables are correlated to X latent
variables [13].
fermented as submerged culture in shake flasks and the lipase
variants secreted into the fermentation medium. After the fermen-
tation, the lipase variants were purified from the sterile filtered
fermentation medium in a three-step procedure with (i) hydropho-
bic interaction chromatography on decylamine-agarose, (ii) buffer
exchange by gel filtration, and (iii) ion exchange chromatography
with cation exchange on SP-sepharose at pH 4.5. The lipase variant
solutions were stored frozen.
In principle, data calculated using molecular simulation meth-
ods could be analyzed by PLS to reveal the inherent structure of the
data and to find three-dimensional quantitative structure–activity
relationships (3D-QSAR). Suitable molecular descriptors are nec-
essary for extracting relevant structural information from target
molecules and correlate them with chemical or physical properties
[14]. Although QSAR methods are well established in drug design
strategies [15], they have been applied to biocatalysis only recently
for the study of enzyme thermostability [16], enzyme specificity
[17,18] and enantioselectivity [19].
2.2. Experimental screening of mutants
The amidase activity was determined with a fluorimetric assay
similar to the one described previously [21].
The aqueous reaction mixture contained 0.03 mg/ml CaLB vari-
ant, 5 mM substrate (benzyl chloroacetamide), 25 mM phosphate
(potassium salt) pH 7.0, 10% (w/v) tetrahydrofuran and was set
up in 96-well microtiter plates. The concentration of the enzyme
stock solution was determined by measuring the absorbance at
280 nm and calculated based on the extinction coefficient of 1.21
for CaLB. The microtiter plate was covered with parafilm and incu-
bated for 18 h at 37 ◦C and 300 rpm in the MTP Thermomixer
Comfort (form Eppendorf AG). Afterwards 50 ml of 20 mM 4-
chloro-7-nitrobenzofurazan (NBDCl) in 1-hexanol was pipetted to
200 ml reaction mixture and incubated for 1 h at 37 ◦C and 500 rpm.
Afterwards the fluorescence intensity was measured with the fluo-
rimeter Fluostar Optima (from BMG Labtech GmbH) with excitation
filter at 485 nm and emission filter at 540 nm. The specific activity of
CaLB wild type is 1.27 0.16 × 10−2 ␮mol/mg/h. The activity value
for each enzyme variant is the average of three replications, in three
wells. In parallel, each enzyme variant was also set up in three dif-
ferent wells without substrate, to measure the small background
fluorescents from each variant. Further three wells were set up
without substrate and without enzyme, thus only aqueous medium
with buffer and solvent, to measure the small background fluores-
cents from the medium. The average value from the measurements
with enzyme and with substrate is named ‘es’; the value with
enzyme and without substrate is ‘e’; the value without enzyme and
with substrate is ‘s’; the value without enzyme and without sub-
strate is ‘o’. To correct for fluorescents from enzyme, medium and
autohydrolysis the following subtractions were calculated: (es-e)-
(s-o) = (es-s)-(e-o) = es-e-s + o = corrected enzyme variant activity
value. S-o = autohydrolysis of substrate. Because these measure-
ments are in arbitrary fluorescents units, these values were
normalized to percentage of substrate that reacted. Zero percent
means no reaction of substrate, 100% means complete reaction of
substrate to products. For this normalization two wells for each
enzyme variant were set up in parallel. These wells contained the
same composition as the other wells, except that they contained
instead of substrate the products at a concentration that corre-
sponds to 10% reaction. Thus, the concentrations in these two wells
were 0.03 mg/ml enzyme, 0.5 mM hydrolysis products (i.e. 0.5 mM
benzylamine and 0.5 mM chloroacetic acid), 25 mM phosphate pH
7.0, 10% (w/v) tetrahydrofuran. The average value from the mea-
surements with enzyme and with product is named ‘ep’. To correct
for background fluorescents from the enzyme variants, the average
value from the measurements with enzyme and without product
(and without substrate), which was named ‘e’, was subtracted. In
short, the normalized and corrected enzyme variant activity was
calculated as 10((es-e)-(s-o))/(ep-e).
The present study represents, to the best of our knowledge, the
first attempt to apply 3D-QSAR analysis for correlating structures of
mutants and their activity within an enzyme engineering strategy.
In order to fully exploit fundamental knowledge while avoiding
conceptual biases, computational and statistical techniques were
evaluated in the context of enhancing amidase activity in Candida
antarctica lipase B (CaLB). As is widely known, most proteases, ami-
dases and lipases contain the same type of catalytic machinery as
serine hydrolases. Nonetheless, esterases/lipases have very low or
undetectable amidase activity and this fact has been extensively
discussed [20]. The QSAR study here reported allowed obtaining
quantitative information on variables affecting amidase activity
and their interactions, thus providing guidelines for mutagene-
sis strategies. Overall, by “learning” from a model that correlates
structural information with kinetic data, the methodology allows to
extract objectively information that actually affects the activation
energy of the reaction of interest. Of course, QSAR predictive mod-
els are reliant on the data on which they are based and on the overall
quality of the information, including the item to be modeled. There-
fore, the validity and extendibility of the method strongly depends
on the data set used for training the model. The 3D-QSAR math-
ematical analysis here reported provides a semi-quantitative tool
for in silico screening of virtual mutants and the perspectives for the
exploitation of these computational approaches to rational enzyme
engineering are also discussed herein.
2. Experimental
2.1. Production of CaLB mutants
The experimental CaLB variants were produced according the
procedure previously reported by Suplatov et al. [21].
Variants of CaLB were generated by polymerase chain reaction-
based (PCR) site-directed mutagenesis. The PCR was set up with
the proof-reading KOD DNA polymerase (from Novagen, Toyobo)
and a 7467 basepair Escherichia coli–Aspergillus plasmid that was
previously methylated with CpG methyltransferase (from NEB).
The PCR products were used to transform competent E. coli DH5a
cells (from TaKaRa). Plasmid DNA was recovered and sequenced
to verify the presence of the desired substitution. Confirmed plas-
mid variants were used to transform an Aspergillus oryzae strain
that is negative in pyrG (orotidine-5-O-phosphate decarboxylase)
and that is also negative in the proteases pepC (a serine protease
homologous to yscB), alp (an alkaline protease) NpI (a neutral
metalloprotease I) to avoid degradation of the lipase variants during
and after fermentation. The transformed Aspergillus strains were
2.3. Modeling CaLB WT and mutants
All the calculations were performed using GROMACS software
[22] version 4 compiled on a virtual ROKCS linux cluster with 4
nodes.

V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
9
2.4. Pre-equilibration of CaLB
2.8. Construction of the automatic workflow for virtual screening
with ModeFRONTIER
The structure 1TCA [23] (Protein Data Bank, PDB) [24] of CaLB
was used. The structure was pre-processed by deleting the crys-
tal water molecules, ions and sugar moieties in correspondence
of glycosylation sites. The force-field employed was GROMOS-96
modeFRONTIER version 4 was used [29]; a number of differ-
ent software were integrated into the modeFRONTIER workflow
(PyMOL, GRID, GROMACS and the QSAR equation). The first gen-
eration of mutants was randomly produced and the next mutant
generations were created using NGSA II genetic algorithm. The
improvement of the mutant activity, as defined by the QSAR score,
was set as the optimization objective.
53a6 [25]; the enzyme was put in the center of a cubic space of
3
˚
343 A and solvated with explicit water at experimental density.
The charges were counter-balanced using Na+ or Cl− ions. The sys-
tem was minimised (10.000 steps of steepest descendent gradient)
and dynamised for 6 ns at 300 K with the software GROMACS [22]
version 4.
3. Results and discussion
Enzyme catalysis is a matter of different and complex factors
such as, for instance, enthalpic contribution, entropic factors and
dynamic behavior. The present did not aim at computing each
contribution but rather at finding an empiric equation suitable to
correlate enzyme structure with its ability to catalyze the hydrol-
ysis of a model amide (N-Benzyl-2-chloroacetamide). Therefore,
GRID mapping of the active site and multivariate statistical analy-
sis were used to record variables describing the active site, both in
terms of electrostatic and geometrical features. Through the selec-
tion of these variables, aminoacids were identified relevant for
the catalytic activity of the considered substrate. The correlation
between the selected variables and the activity of the mutants was
described through the construction of a Three-Dimensional Quan-
titative Structure Activity Relationship (3D-QSAR) mathematical
model.
2.5. Computation of the mutants structures
Mutations were performed starting from the pre-equilibrated
CaLB structure and using the mutagenesis tool of the software
PyMOL [26]. Each of the 30 generated mutants along with the wild
type structure were defined in the GROMOS-96 53a6 force-field
[25] and then embedded in a cubic space of 343 A . Each system
was solvated with explicit water and charges were neutralized with
Na+ or Cl− ions. Each structure was minimised (10,000 steps of
steepest descendent gradient) and subjected to a 500 ps molecular
dynamic (MD) simulation performed with the software GROMACS
[22] version 4. The outcome of each MD simulation (mutant struc-
ture) was superposed to the WT CaLB and used for the calculation
of the descriptors.
3
˚
Three-Dimensional Quantitative Structure Activity Relation-
ships (3D-QSAR) were established for a set of mutants (training
set) by means of PLS analysis that extracts the latent X (structural
properties) and Y variables (amidase activity). The new variables
or components are extracted to give the best fit of both Y and X
variable matrices.
The PLS method has been conceived to allow the use of a num-
ber of independent variables extremely high in relation to the
number of objects. Using the principal components, only the vari-
ables directly correlated to the dependent variable contribute to
the model. It is also possible to quantify the extent of this contri-
bution, thus identifying the variables of interest in the description
of the biological activity [12].
2.6. Computation of molecular descriptors
The molecular descriptors (differential Molecular Interaction
Fields, dMIFs) were calculated on the outcome of the MD sim-
ulations for the 30 mutants and the wild type CaLB, The MIF
descriptors were calculated on each protein structure by the GRID
program [27] on a three dimensional grid with a resolution of 2
planes per Å, extended over a volume of 100 nm3 that comprises
the opening of the active site and its floor. Four different probes
were used for the calculation: WATER probe, which describes and
quantifies the dipolar interactions and the hydrogen bond forma-
tion; DRY probe, which describes hydrophobic interactions; O::
probe, which represents a H-bond acceptor carbonylic oxygen and
therefore accounts for interactions with H-bond donors; N1 probe,
which represents a H-bond donor group and describes interac-
tions with H-bond acceptors. The final dMIFs descriptors were
obtained by subtracting the corresponding MIF computed for the
wild type CaLB from the MIF of each mutant. This procedure led
to the calculation of 479,700 variables for each object (mutant).
The variables were divided into four different blocks, belonging to
the original probes (WATER, DRY, O:: and N1) used for the MIF
calculation.
The strategy for the construction of the 3D-QSAR model can be
schematized in the following 4 main steps:
1. Generation and selection of mutants constituting the “training
set”.
2. Modeling the mutants.
3. GRID analysis of each mutant and extraction of molecular
descriptors.
4. Statistical analysis.
Finally, the overall procedure for the generation of mutant mod-
els was automated within a workflow where all software and
computational procedurer are integrated. The validated 3D-QSAR
model was then integrated as well inside the work-flow, as scoring
function for the screening of new generations of virtual mutants.
2.7. 3D-QSAR model
The variables of the dMIFs descriptors were used in order to
generate a QSAR model using the software GOLPE version 4.5
[28] a different weight factor was assigned to each block of vari-
ables, therefore, the initial 479,700 variables were selected by
using D-Optimal preselection and FFD variable selection algo-
rithm, finally 1650 variables were selected for the statistical
model.
3.1. Generation and selection of mutants that form the “training
set”
In the present work the objective of the engineering strategy
was to introduce amidase activity inside the scaffold of lipase B
from Candida antarctica (CaLB) and a training set of 30 CaLB mutants
was used for constructing the mathematical model (Table 1). As a
general rule, the training set should include mutants that present
The predictivity q2 of the model was calculated by using both
the leave-one-out (LOO) and the leave-group-out (LGO) methods.
The latter was applied by using five different groups with random
object selection.

10
V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
Table 1
equilibrated structure, mutations were introduced and the result-
ing protein was minimised as well as dynamised for 500 ps.
The dynamised mutant structures were superposed using the
backbone of the wild type CaLB as reference, thus obtaining an
Training set used for the construction of the 3D-QSAR model. Experimental activity
of mutants is expressed as improvement factor as compared to the wild type CaLB
(wild type = 1).
Mutant
Mutation
Activity
(improvement factor)
˚
average RMSD of 1.206 A (Figure S1 in Supplementary material).
D01
D02
D03
D04
D05
D06
D07
D08
D09
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
D21
D22
D23
D24
D25
D26
D27
D28
D29
D30
A225V
D145S
D265P
G39A
I189H
I189Q
L140E
L278A
Q191R
R249Q
T103G
T256K
T40A
T40S
W104F
A225I
1.22
0.69
0.57
2.76
1.11
0.41
0.55
2.50
1.28
0.74
1.10
0.75
0.12
0.50
2.00
1.55
1.26
0.86
1.67
1.49
4.15
1.87
0.10
0.80
3.20
2.90
5.75
10.60
1.90
0.80
3.3. GRID analysis of CaLB and mutants: computation of
molecular descriptors
A molecular descriptor is the final result of a logic and
mathematical procedure which transforms chemical information
encoded within a symbolic representation of a molecule into use-
ful numbers [32]. Any characteristic of a given molecule can be
translated into numbers that constitute the molecular descriptors.
Accordingly, the information contained in the descriptor influences
the quality of the QSAR model, its ability to describe the data
set quantitatively and to correlate molecular properties with the
dependent variable of interest (Y variable).
Taking this into account, the analysis of the structure of CaLB and
its mutants was performed by means of molecular descriptors gen-
erated by the GRID program [27], a computational procedure that
calculates the interaction energies between any target molecule (in
the present case represented by the active site enzyme) and a small
chemical probe (i.e. a chemical functional group). Energies are cal-
culated in all the nodes of a three-dimensional grid that spans the
structure of interest, namely the enzyme active site. The computa-
tional output is called Molecular Interaction Field (MIF), which can
be visualized as an isopotential surface. The calculated MIFs were
used as input for the multivariate analysis to generate QSAR models
[33].
MIFs descriptors [19] were computed using four different
probes: WATER probe, which describes and quantifies the dipolar
interactions and the hydrogen bond formation; DRY probe which
describes hydrophobic interactions; O:: probe, which represents
a H-bond acceptor carbonylic oxygen and therefore accounts for
interactions with H-bond donors; N1 probe, which represents
a H-bond donor group and describes interactions with H-bond
acceptors. The selection of these four probes was motivated by
the consideration that the ability of a certain enzyme to catalyze
the hydrolysis of the amide bond in N-Benzyl-2-chloroacetamide
(Fig. 1) is not only the result of the geometric and electronic fea-
tures of the residues located in the close proximity of the catalytic
triad and the oxyanion hole. Indeed, this “catalytic machinery”
is embedded in an active site that acts as a micro-environment
where the reaction takes place. In any chemical reaction, the
medium can contribute to the stabilization/destabilization of the
transition state. In analogy, the active site of an enzyme is “pre-
organized” also for stabilizing the transition state through the
establishment of a favourable micro-environment, for instance by
enabling H-bonds or hydrophobic interactions. Therefore, the aim
of the present computational method is to identify the array of
physical–chemical factors that contribute to stabilize the transi-
tion state of the hydrolytic reaction of an amide inside the active
sites of different CaLB mutants.
D223G
D223K
39A278A281G
39A191R
39A104F
T42G
40G278G104F225M157V189A134A
39A103G
39A278A
39A103G278A
39A104F278A
39A103G104F278A
39A103G104Q278A
39A104F225K278A
sufficient variability in terms of enzymatic activity and structural
properties. Models trained on structurally homogeneous objects
are expected to have an excellent predictivity but only within a
restricted range of structural properties because regression models
are able to predict the effect of a variable X (i.e. a specific structural
feature of an enzyme/mutant) on amidase activity (Y variable) as
long as such a variable is somehow represented in the training set.
The activity of mutants was evaluated in terms of hydrolytic
activity towards N-Benzyl-2-chloroacetamide (Fig. 1) that was cho-
sen as reference substrate for the amidase activity (see materials
and methods). The measured activity was expressed as improve-
ment factor as compared to the wild type CaLB (wild type amidases
activity = 1).
The 30 variants were selected because of their heterogeneous
distribution of activity values within a wider data base contain-
ing CaLB mutants presenting mutations focused in different active
site regions. Globally the mutations involve 17 residues, determin-
ing 19 monovariants and 11 multivariants, which result from their
combinations.
3.2. Modeling the mutants
GRID descriptors were calculated for each mutant by computing
MIFs with a resolution of 2 planes per Å, extended over a vol-
ume of 100 nm3, which comprises the opening of the active site
and its floor. The conformations of the mutants superposed to the
WT enzyme are reported in Figure S1 of Supplementary materi-
als. In order to focus the attention on the differences between the
wild type CaLB and the mutants, differential MIFs were calculated
(dMIFs) [19] before computing the 3D-QSAR model. dMIFs were
obtained by subtracting the corresponding MIF computed for the
wild type CaLB from the MIF of each mutant. This procedure led to
the calculation of 479,700 variables for each object (mutant). The
variables were divided into four different blocks, each belonging to
The wild type (WT) CaLB was modeled starting from the struc-
ture available on the Protein Data Bank (PDB) [24] with the code
1TCA [23], which was also used as template for modeling the
mutants. The wild type CaLB was previously subjected to 6 ns of
molecular dynamic simulation in explicit water with the aim to sta-
bilize the flexible lid domain [30,31] (see Experimental for details)
because such flexibility might interfere in the computation of struc-
tural differences coming from mutations.
The dynamised WT CaLB structure was used as template for
the generation of mutants structures. Therefore, starting from that

V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
11
Fig. 1. Scheme of the hydrolysis of N-Benzyl-2-chloroacetamide catalyzed by CaLB and used for the screening of mutants.
Table 2
the different probes used for the MIF calculation (WATER, DRY, O::
and N1).
External validation of the QSAR model reported in Fig. 2 by using mutants external
to the training set.
Mutation
Predicted activity
Experimental activity
3.4. PLS analysis and construction of the QSAR model
I189N
D223N
T42S
0.82
2.08
1.47
0.71
0.95
0.99
1.13
0.95
1.30
1.21
0.55
1.19
0.75
1.26
A different weight factor was assigned to each block of vari-
ables to confer them the same initial importance in the model,
thus overcoming the differences in absolute value of hydrophobic
and polar interactions. Variables were selected by using D-Optimal
pre-selection and FFD variable selection algorithm, which allowed
retaining only 1650 variables [15].
G39S
A225L
A225F
A225G
A PLS model was built up by correlating the dMIFs descriptors
with the experimental activity values of the training set. The math-
ematical model, on the second Principal Component (PC), explains
38% of the whole variance (r2 = 0.98). The predictivity coefficient
was calculated on the second principal component by means of
the leave-one-out cross-validation (LOO) and by using the “leave-
group-out” (LGO) procedure, obtaining q2 values of 0.79 and 0.74
respectively.
3.5. Statistical analysis of the effect of the variables
The PLS analysis selected the variables that correlate with the
amidase activity, which were ultimately projected on the three-
dimensional structure of CaLB to visualize promising hot spots.
Fig. 3 illustrates the spatial location of all selected variables for all
probes used in the GRID analysis (water, H-bond donor, H-bond
acceptor, hydrophobic interactions). By positioning a certain vari-
able on the 3D model it is possible to identify aminoacids, within a
For the first PC a q2 of 0.43 was obtained using both methods
(Fig. 2).
˚
radius of 1.5 A, which contribute at a different extent to the effect
The graphical representation of the model points out how the
PLS analysis was performed using a limited number of highly active
mutants, whereas most of the CaLB variants had activity in the
range of 0.5 and 2.0. Therefore, the model is expected to describe
and predict more accurately new virtual mutants within that range
of relative activity (between 0.5 and 2.0) and this explains why the
activity of the best mutant (D28) is underestimated.
of the selected variable.
It must be underlined that the amidase activity depends not only
on the effect of the single variables but also it is the complex result
of the interaction between them. This is mathematically accounted
by the 3D-QSAR model. Accordingly, any interpretation of the effect
of the selected variables cannot rely on a simple visual inspection of
The predictivity of the model was validated by computing the
descriptors for 7 mutants external to the training set and by
comparing the experimentally determined value with the activ-
ity predicted by the 3D-QSAR model (Table 2). Results confirm that
the model is able to discriminate between poor and good mutants,
thus allowing a pre-selection in silico.
Fig. 3. Selected variables represented as dots. Colours are indicative of the value of
variable loadings: green = negative; from yellow to red = increasingly positive. (For
interpretation of the references to color in figure legend, the reader is referred to
the web version of the article.)
Fig. 2. QSAR model: predicted vs experimental graph. Two principal components
were considered in the PLS analysis.

12
V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
Table 3
List of the aminoacids that contribute to determine the effect of the selected vari-
ables of the QSAR model. Residues not included in the list of mutations (see Table 1)
are highlighted in bold.
Probe
Water
Aminoacids
Gly39, Thr42, Trp104, Leu109, Asp134, Leu140, Ala141,
Gln157, Ile189, Leu228, Ile285
O::
N1
Thr42, Leu109, Ala141
Thr42, Leu109, Asp134, Leu140, Val190, Ile285, Lys290
the enzyme structure but, rather, must be based on a rigorous sta-
tistical analysis of the data. Conversely, the analysis of the loadings
of the selected variables provides quantitative information on the
contribution of each variable to the second principal component of
the 3D-QSAR model.
It is important to underline that each variable comes from the
differential MIF obtained by subtracting each MIF calculated for the
wild type CaLB from the corresponding MIF of the mutant.
Once identified a “hot spot” residues, the mutagenesis strategy
must go in the direction suggested by the loading values; hot-
spot residues related to highly positive or highly negative loadings
will have the highest impact on the mutant activity. For instance,
a highly positive loading suggests a direct correlation with the
mutant activity, therefore the difference between the values cal-
culated for the mutant and the wild type must be positive in order
to have a positive effect on the mutant activity.
All the selected variables were sorted out and represented visu-
ally on the basis of the probe used for their computation, so that
each variable block was analyzed separately. Table 3 reports a
schematic overview of the residues identified as relevant by the
statistical analysis and representing promising hot spots for muta-
genesis (Fig. 4).
It must be underlined that out of the 17 residues addressed by
the mutations of the training set (Table 1), 7 were recognized as
correlated to the observed variations in the amidase activity. On
the other hand, 6 new residues were pointed out despite the fact
they were not mutated within the training set.
From the results reported in Table 3 water interactions or
“hydratability” of the active site emerge as the key factors for the
conversion of the CaLB scaffold into an amidase enzyme. Notably,
the model does not select any variable coming from interactions
with the DRY probe. In order to verify the criteria used for the selec-
tion of the variable a model was constructed using only the DRY
variables and its mathematical output confirms that DRY variables
do not correlate with the activity. Nevertheless, this result might
have two explanations: either the training set contains mutants
displaying negligible differences in terms of hydrophobicity or such
differences are not correlated with the amidase activity.
Notably, the statistical analysis identified five new hydrophobic
residues as hot spots located in the core of the protein and only
one polar residue (Lys 290) located on an external flexible domain
(Fig. 4B). Globally the results suggest that an engineering strat-
egy aiming at introducing amidase activity in CaLB scaffold should
address those residues that affect the ability of the active site to be
hydrated. It must be underlined that this concept is consistent with
the ability of amidases to accept polar substrates able to establish
H-bonds and to drag water inside the active site. Moreover, it is
widely known that lipases are active in non-aqueous media even
at very low water activity values, whereas amidases need to be
hydrated in order to maintain their activity in organic media and
this observation suggests a specific role of water in amidase activity
of hydrolases [34].
Fig. 4. Structure of CaLB (wild type). (A) Highlights (violet) the 17 residues object of
mutations (see Table 1) whereas (B) shows the hot spots identified through the sta-
tistical analysis of significant variables (Fig. 3). (For interpretation of the references
to color in figure legend, the reader is referred to the web version of the article.)
for proton transfer between the catalytic base (the Histidine N␧
atom for serine proteases) and the scissile nitrogen atom (the P1ꢀ
nitrogen). This is because after the attack of the catalytic Ser O␥ on
the carbonyl carbon of the amide bond, the scissile nitrogen lone
pair will be situated antiperiplanar to the formed Ser O␥-C bond
in the tetrahedral intermediate and will point away from the His-
tidine in accordance with Deslongchamps’ stereoelectronic theory.
Results reported by the group of Hult were based on the study of
the hydrolysis of p-nitroanilide: data supported the hypothesis that
enzymatic catalysis occurs when the transition state is stabilized
thanks to a hydrogen bond donated by the scissile amide bond and
The role of H-bonds in amidase mechanism was also discussed
recently by Hult and co-workers [35]. Their study pointed out
how, in the mechanism of enzymatic hydrolysis of amides, nitro-
gen inversion or rotation needs to take place in order to prepare

V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
13
Fig. 6. Detail of the wild type CaLB (red) superposed to mutant D04 (G39A) in cyan.
G39 is in orange, A39 is in green. Residues forming the catalytic triad and the oxyan-
ion hole are in yellow. (For interpretation of the references to color in figure legend,
the reader is referred to the web version of the article.)
not only a variation of the electrostatic factors in the surrounding
region but also it produces steric effects due to its bulkiness.
In the case of the single mutation of Gly39 into Ala there is appar-
ently a simpler interpretation of the increase of amidase activity:
Fig. 6 shows how the bulkier Ala reduces the space available to the
substrate.
As a consequence, the G39A mutation forces the substrate to
assume a productive conformation, stabilized by a H-bond formed
with Gln106 (Fig. 7), which favours the nucleophilic attack of Ser
105 to the acyl carbon. The distance between the nucleophilic oxy-
˚
˚
gen of Ser105 and the amidic nitrogen is reduced from 3.1 A to 2.9 A.
Moreover, the oxyanion stabilization is increased by the reduced
distance between the H-bond donors and the substrate oxygen
Fig. 5. A comparison of variants at residue 189. Ile189 (wild type) in green, His189
(D05) in orange, Gln189 (D06) in cyan. Residues forming the catalytic triad (Ser
105, His 224, Asp 187) and the oxyanion hole (Gln 106, Thr 40) are in yellow. (For
interpretation of the references to color in figure legend, the reader is referred to
the web version of the article.)
˚
˚
(from 3.4 and 1.9 A to 2.1 and 1.6 A; Fig. 7). However, it would be
difficult to predict and explain why the combination of this muta-
tion with others (for example D24, D30) produces a negative result
as emerged from Table 1.
accepted by the enzyme. The same study identified Ile 189 as a hot
spot for mutagenesis that should go in the direction of introducing
a residue able to establish an extra H-bond necessary for the stabi-
lization of the transition state of the reaction. Data obtained in our
study shows that mutant I189Q (D06) displays a reduced amidase
activity, while the mutation I189H (D05) (Fig. 5) has a negligible
influence (Table 1). However, in the present study the screening for
amidase activity was based on the hydrolysis of an amide and not
an anilide, so that structural and electronic differences of the two
substrates must be taken into account and no direct comparison
with the results of the previous study can be done.
In conclusion, from the statistical analysis (Table 3) it appears
that the structural differences that correlate most with the
observed variations in amidase activity depend on the ability of the
active site to bind water. Of course, WATER probe provides informa-
tion that includes also the general ability of the target to establish
H bonds but this property is not related to one single residue of
the active site but it is rather the complex combination of contrib-
utions coming from different aminoacids that cannot be analyzed
separately.
3.6. Automatic procedure for in-silico virtual screening
The credibility of any in silico engineering strategy at indus-
trial scale depends strongly on the time scale of its application.
Ideally, in silico design and screening should be feasible by using
a moderate computational power and within a highthroughput
frame. On that respect, the automatic generation of virtual mutants
requires effective integration of all necessary software into a coher-
ent work-flow and efficient in silico screening depends on reliable
scoring functions. In order to explore the possibility of developing
a comprehensive computational tool for automatic in silico design
and screening of mutants, the modeFRONTIER software [29] was
used. It provides an environment for automation of different pro-
cedures or software. In the present case modeFRONTIER integrates
in a single workflow the following programs: PyMOL [26] (gen-
eration of 3D-structure of mutants), GROMACS [22] (molecular
dynamics, structure minimisation and equilibration) and GRID [27]
(calculation of molecular descriptors); finally, also the mathemat-
ical equation of the 3D-QSAR model was integrated. A scheme of
the workflow used for the process automation in modeFRONTIER
is showed in Fig. 8.
The possibility of revealing the structural and electronic features
responsible for a change of activity from a simple visual inspection
results prohibitive even for single point mutants. As an example,
Fig. 5 focuses the attention on position 189 and presents a com-
parison between Ile (CaLB wild type), His (mutant D05) and Gln
(mutant D06). A simple visual inspection would not be sufficient for
predicting the negative effect of mutation I189Q, since Gln causes
The workflow used as an input a number of hot spots residues
identified by the previous QSAR analysis and the corresponding vir-
tual mutants were firstly generated and then automatically scored
by means of the 3D-QSAR model.

14
V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
Fig. 7. Docking of N-Benzyl-2-chloroacetamide in wild type CaLB (left) and in D04 (right).
Fig. 8. Workflow used for the automatic in-silico generation and screening of mutants. From left to right: selection of mutations and mutant generation, mutant minimisation
and mutant scoring.
The workflow can be subdivided into the following steps (Fig. 8):
Therefore, although preliminary, these results support the pos-
sibility to develop computational tools able to rationally design,
generate and screen virtual mutants within a hightroughput
scheme.
A. Selection of mutations and generation of the virtual mutants
using the PyMOL software and CaLB structure as a template (see
Experimental).
B. Equilibration of each mutant by a minimisation and MD simula-
tion procedure performed with GROMACS.
4. Conclusions
C. Superimposition of each mutant to the WT CaLB structure
(PyMOL).
D. Automatic calculation of the molecular descriptors (dMIFs) using
the software GRID.
E. Scoring of each virtually generated mutant by applying the math-
ematical 3D-QSAR model to the matrix of the descriptors.
This study represents, at the best of our knowledge, the first
example of 3D-QSAR strategy applied to enzyme rational engi-
neering. The 3D-QSAR analysis provides a tool for approaching
protein engineering through the comparisons of three-dimensional
structures rather than sequences. The problem of engineering ami-
dase activity inside a lipase (CaLB) scaffold was faced by taking
into account that each mutation affects the properties of a mutant
at multiple levels, leading to a complex, not linear, combination
of factors. Consequently, simple visual inspection was considered
inadequate for identifying structural motifs responsible for a cer-
tain property. Instead, multivariate statistical analysis (PLS) was
applied because it has no conceptual bias in the interpretation of
data and it simplifies the representation of results. Remarkably, the
model takes into account also the interactions between variables,
which are of major importance in such complex systems.
The modeFRONTIER software computes randomly a first gener-
ation of 20 mutants (the number of mutants for each generation
can be modified by the user), which were scored. The scoring
results of the first generation were then exploited for the calcu-
lation of the next 20 mutants using a genetic algorithm that is
already integrated into the modeFRONTIER software (NSGA II). The
use of the genetic algorithm makes modeFRONTIER able to learn
generation after generation which are the empiric rules necessary
to increase the amidases activity of CaLB (hydrolysis of N-Benzyl-
2-chloroacetamide).
The methodology identified variables affecting the ami-
dase activity of a set of CaLB mutants towards N-Benzyl-2-
chloroacetamide and in particular the major role of hydratability
of the active site. Specific hot spots were pointed out and they
should be addressed for further improvement of mutants in terms
of amidase activity.
The automatic workflow generates and scores each virtual
mutant in 2 h on a normal workstation and, in principle, the mode-
FRONTIER software can compute generations of mutants until the
established convergence criteria are achieved.

V. Ferrario et al. / Journal of Molecular Catalysis B: Enzymatic 101 (2014) 7–15
15
Regarding the applicability of the 3D-QSAR approach to in silico
screening of mutants the model here reported is able to dis-
criminate between poor and good mutants. More importantly, by
integrating all computational and statistical procedures inside a
modeFRONTIER workflow it was demonstrated that it is possible
to automate the whole methodology. This is of major importance
in the perspective of a realistic application of the virtual screening
process at industrial scale.
[7] L. Noodleman, T. Lovell, W. Han, J. Li, F. Himo, Chemical Reviews 104 (2004)
459–508.
[8] P. Sirén, K. Hult, ChemCatChem 3 (2011) 853–860.
[9] L. Tian, R. Friesner, Journal of Chemical Theory and Computation 5 (2009)
1421–1431.
[10] M.R. Hediger, L. De Vico, A. Svendsen, W. Besenmatter, J.H. Jensen, PLoS ONE 7
(2012) e49849, http://dx.doi.org/10.1371/journal.pone.0049849.
[11] P. Braiuca, C. Ebert, A. Basso, P. Linda, L. Gardossi, Trends in Biotechnology 24
(2009) 419–425.
[12] S. Wold, K. Esbensen, P. Geladi, Chemometrics and Intelligent Laboratory Sys-
tems 2 (1987) 37–52.
Overall, the present study underlines also some of the con-
straints of the regression approach: the model can predict a
property as long as it has been trained with the information relevant
for describing such property. Accordingly, highly active mutants
can be predicted and selected only by starting from a training set
of mutants with a broad range of activity values. Therefore, the
methodology appears particularly suited for optimizing and tuning
engineering strategies once an appropriate library of mutants is
made available.
[13] S. Wold, PLS for linear modelling, in: D. van de Waterbeem (Ed.), Chemometric
Methods in Molecular Design, vol. 2, VCH Verlagsgesellschaft, Weinheim, 1995,
pp. 195–218.
[14] S. Wold, Chemometrics and Intelligent Laboratory Systems 58 (2001)
109–130.
[15] G. Cruciani, S. Clementi, M. Baroni, 3D QSAR in Drug Design: Theory, Methods
and Applications, ESCOM, Leiden, 1993, pp. 567–582.
[16] P. Braiuca, A. Buthe, C. Ebert, P. Linda, L. Gardossi, Biotechnology Journal 2
(2007) 214–220.
[17] V. Ferrario, P. Braiuca, P. Tessaro, L. Knapic, C. Gruber, J. Pleiss, C. Ebert, E. Eich-
horn, L. Gardossi, Journal of Biomolecular Structure and Dynamics 30 (2012)
74–88.
[18] P. Braiuca, L. Boscarol, C. Ebert, P. Linda, L. Gardossi, Advanced Synthesis and
Catalysis 348 (2006) 773–780.
Acknowledgments
[19] P. Braiuca, L. Knapic, V. Ferrario, C. Ebert, L. Gardossi, Advanced Synthesis and
Catalysis 351 (2009) 1293–1302.
[20] Y. Nakagawa, A. Hasegawa, J. Hiratake, K. Sakata, Protein Engineering Design &
Selection 20 (2007) 339–346.
[21] D.A. Suplatov, W. Besenmatter, V.K. Svedas, A. Svendsen, Protein Engineering,
Design & Selection 25 (2012) 689–697.
[22] H.J.C. Berendsen, D. van der Spoel, R. van Drunen, Computer Physics Commu-
nications 91 (1995) 43–56.
This work has received funding from the European Community’s
Seventh Framework Programme under the FP7-KBBE-2008-2B
grant agreement no. 227279.
We are grateful to Dr. Danilo Di Stefano and Dr. Lorena Knapic
for useful discussions.
[23] J. Uppenberg, M.T. Hansen, S. Patkar, T.A. Jones, Structure 2 (1994) 293–308.
[24] H.M. Berman, J. Westbrook, Z. Feng, G. Gilliland, T.N. Bhat, H. Weis-
sig, I.N. Shindyalov, P.E. Bourne, Nucleic Acids Research 28 (2000)
235–242.
[25] C. Oostenbrink, A. Villa, A.E. Mark, W.F. van Gunsteren, Journal of Computa-
tional Chemistry 25 (2004) 1656–1676.
[26] The PyMOL Molecular Graphics System, Version 1.5.0.3 Schrödinger, LLC.
[27] P.J. Goodford, Journal of Medicinal Chemistry 28 (1985) 849–857.
[28] Golpe, MIA s.r.l. (www.miasrl.com).
Appendix A. Supplementary data
Supplementary data associated with this article can be found,
in the online version, at http://dx.doi.org/10.1016/j.molcatb.
2013.12.004.
[29] modeFRONTIER, ESTECO s.p.a. (www.esteco.com).
[30] M. Skjot, L. De Maria, R. Chatterjee, A. Svendsen, S.A. Patkar, P.R. Ostergaard, J.
Brask, ChemBioChem 10 (2009) 520–527.
[31] V. Ferrario, C. Ebert, L. Knapic, D. Fattor, A. Basso, P. Spizzo, L. Gardossi, Advanced
Synthesis and Catalysis 253 (2011) 2466–2480.
[32] R. Todeschini, V. Consonni, Handbook of Molecular Descriptors, Wiley-VCH,
Weinheim, 2000.
[33] M. Pastor, G. Cruciani, I. McLay, S. Pikett, S. Clementi, Journal of Medicinal
Chemistry 43 (2000) 3233–3243.
[34] A. Basso, L. De Martin, C. Ebert, L. Gardossi, P. Linda, V. Zlatev, Journal of Molec-
ular Catalysis B: Enzymatic 11 (2001) 851–855.
[35] P. Syrén, P. Hendil-Forssell, L. Aumailley, W. Besenmatter, F. Gounine, A. Svend-
sen, M. Martinelle, K. Hult, ChemBioChem 13 (2012) 645–648.
References
[1] M.T. Reetz, J.D. Carballeira, Nature Protocols 2 (2007) 891–903.
[2] T. Nagai, A. Sawano, E.S. Park, A. Miyawaki, Proceedings of the Natural Academy
of Sciences of the United States of America 98 (2001) 3197–3202.
[3] C.A. Ouzounis, A. Valencia, Bioinformatics 19 (2002) 2176–2190.
[4] F. Claeyssens, J. Harvey, F. Manby, R. Mata, A. Mulholland, K.E. Ranaghan, M.
Schutz, S. Thiel, W. Thiel, H.J. Werner, Angewandte Chemie International Edi-
tion 118 (2006) 7010–7013.
[5] J. Parks, H. Hu, J. Rudolph, W. Yang, The Journal of Physical Chemistry B 113
(2009) 5217–5224.
[6] J. Hermann, J. Pradon, J. Harvey, A. Mulholland, The Journal of Physical Chem-
istry A 113 (2009) 11984–11994.
