Aggregation-free Gold Nanoparticles in Ordered Mesoporous Carbons:
Towards Highly Active and Stable Heterogeneous Catalysts
†
†
†
‡
§
§
Shuai Wang , Qingfei Zhao , Huimin Wei , Jianqiang Wang , Minhyung Cho , Haesung Cho ,
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
§
,†
Osamu Terasaki , Ying Wan*
†
The Education Ministry Key Lab of Resource Chemistry, Shanghai Key Laboratory of Rare Earth
Functional Materials, and Department of Chemistry, Shanghai Normal University, Shanghai 200234,
‡
P. R. China; Shanghai Synchrotron Radiation Facility (SSRF), Shanghai Institute of Applied
§
Physics, Chinese Academy of Sciences, Shanghai, 201204, P. R. China; Center for Functional
Nanomaterials, Department of Chemistry, Korea Advanced Institute of Science and Technology,
Daejeon 305ꢀ701, Korea
RECEIVED DATE (to be automatically inserted after your manuscript is accepted if required
according to the journal that you are submitting your paper to)
*
To whom correspondence should be addressed. Tel: 86ꢀ21ꢀ6432ꢀ2516; Fax: 86ꢀ21ꢀ6432ꢀ2511;
Eꢀmail: ywan@shnu.edu.cn
1
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 2 of 42
1
2
3
4
5
6
7
8
9
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
6
Abstract
A coordination assisted route is firstly reported here for the synthesis of highly active and stable
gold nanoparticles in ordered mesoporous carbon catalysts using triblock copolymer F127 as a
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
4
structureꢀdirecting agent, thiolꢀcontaining silane as a coordination agent, HAuCl as a gold source
and phenolic resin as a carbon source. Upon carbonization, monoꢀdispersed gold nanoparticles with
a size of ~ 9.0 nm are reduced and simultaneously confined by the “rigid” mesoporous carbonaceous
framework. Nanoparticle aggregation is inhibited even at a high temperature of 600 °C. After
removal of the silica component, the carbonꢀbased catalysts possess the ordered mesostructure, high
2
3
surface area (~1800 m /g), large pore volume (~1.19 cm /g) and uniform bimodal mesopore size (<
2
.0 and 4.0 nm). The monoꢀdispersed gold nanoparticles are highly exposed because of the
interpenetrated bimodal pores in the carbon framework, which exhibit excellent catalytic
performance. A complete conversion of benzyl alcohol in water to benzoic acid can be achieved at
9
0 °C and 1 Mpa. Benzyl alcohol can also completely convert to benzoic acid at 60 °C even under
an atmospheric pressure, showing great advantages in green chemistry. The catalysts are stable,
poison resistance and can be reused with negligible activity loss and metal leaching. The silane
coupling agent shows multifunctions: (1) coordination with gold species by thiol group to obtain
monoꢀdispersed gold species; (2) reaction with phenolic resins by silanol groups to form relatively
“
rigid” composite framework; (3) poreꢀforming agent to generate secondary pores inside carbon pore
walls that provides high surface areas, large pore volumes and accessibility to gold nanoparticles;
and (4) complete elimination that shows negligible effect on catalytic performance for Auꢀcontaining
mesoporous carbon catalysts.
2
