Journal of Thermal Analysis and Calorimetry, Vol. 96 (2009) 1, 195–201
THERMAL BEHAVIOR OF COPPER(II) 4-NITROIMIDAZOLATE
L. Ji-zhen*, F. Xue-zhong, H. Rong-zu, Z. Xiao-dong, Z. Feng-qi and G. Hong-Xu
Xi’an Modern Chemistry Research Institute, Xi’an, Shaanxi 710065, China
The thermal behavior of copper(II) 4-nitroimidazolate (CuNI) under static and dynamic states are studied by means of high-pressure
DSC (PDSC) and TG with the different heating rates and the combination technique of in situ thermolysis cell with rapid-scan Fou-
rier transform infrared spectroscopy (thermolysis/RSFTIR).
The results show that the apparent activation energy and pre-exponential factor of the major exothermic decomposition reac-
tion of CuNI obtained by Kissinger’s method are 233.2 kJ mol–1 and 1017.95 s–1, respectively. The critical temperature of the thermal
explosion and the adiabatic time-to-explosion of CuNI are 601.97 K and 4.4~4.6 s, respectively. The decomposition of CuNI begins
with the split of the C–NO2 and C–H bonds, and the decomposition process of CuNI under dynamic states occurs less readily than
those under static states because the dynamic nitrogen removes the strong oxidative decomposition product (NO2). The above-men-
tioned information on thermal behavior is quite useful for analyzing and evaluating the stability and thermal charge rule of CuNI.
Keywords: copper(II) 4-nitroimidazolate, DSC, IR, kinetics, TG, thermolysis
Introduction
4-Nitroimidazole, an energetic material, which was
studied as the intermediate of medicines [1–3], is
Scheme 1 Structure of CuNI
found to be used as a main intermediate of dinitro-
imidazoles, trinitroimidazoles and metal 4-nitroimid-
azolates which can be used to improve the character-
Experimental instruments and conditions
istics of cast explosives and solid propellants [4–8].
Copper(II) 4-nitroimidazolate (CuNI), a kind of new
PDSC measurements were carried out on
a
metal 4-nitroimidazolate, can be used as a main com-
ponent, combustion catalyzer, of solid propellants.
The study of thermal behavior is a very important
starting point for the selection and exploitation of
CuNI in applications, but there is no report on it until
today.
Model DSC204 Netzsch instruments. The operation
conditions were as follows: heating rates, 5, 10, 15, 20
and 40°C min–1; sample mass, 0.5 to 1.0 mg; aluminium
sample cell; atmosphere, static nitrogen with 1.0 MPa.
TG/DTG measurements were performed on a
Model TA2950 TGA instruments. The conditions of
TG/DTG were as follows: sample mass, 1.0 to
2.0 mg; heating rates, 5, 10, 15 and 20°C min–1; atmo-
sphere, flowing rate of N2 gas, 60 mL min–1.
The aim of this work is to study the thermolysis
kinetics of CuNI under static and dynamic state and
the real-time thermal decomposition [9] of CuNI by
means of PDSC, TG [10–12] and the combination
technique of in situ thermolysis cell with rapid-scan
Fourier transform infrared spectroscopy (thermolysis/
RSFTIR).
Thermolysis/RSFTIR measurements were con-
ducted using a Nicolet Model NEXUS 870 FT-IR In-
strument and in situ thermolysis cell (Xiamen Univer-
sity, China) in the temperature range of 20~455°C and
heating rate of 10°C min–1. KBr pellet samples, well
mixed by about 0.7 mg CuNI and 150 mg KBr, were
used. Infrared spectra in the range of 4000~400 cm–1
were obtained by a model DTGS detector at a rate of
11 files min–1 and 8 scans file–1 with 4 cm–1 resolution.
The specific heat capacity (Cp, J mol–1 K–1) of
CuNI was determined with continuous Cp mode on a
Micro-DSC III mircocalorimeter (Setaram Co., France).
Experimental
Material
CuNI used in this work was prepared by Xi’an Mod-
ern Chemistry Research Institute, whose purity was
more than 99.0%. Its structure is shown in Scheme 1.
*
Author for correspondence: jizhenli@126.com
1388–6150/$20.00
Akadémiai Kiadó, Budapest, Hungary
Springer, Dordrecht, The Netherlands
© 2009 Akadémiai Kiadó, Budapest

JI-ZHEN et al.
Results and discussion
From the original data in Tables 2 and 3, the value
of Ea corresponding to the values of a for the thermal
decomposition reaction under static and flowing N2 gas
conditions obtained by integral isoconversional non-lin-
ear (NL-INT) equation (3) [17]
The thermal decomposition behavior of CuNI under
static N2 gas conditions and flowing N2 gas
The PDSC and TG curves for CuNI at different heat-
ing rates are shown in Figs 1 and 2. PDSC curves
show that there are two exothermic peaks before
430°C. A major exothermic peak before 360°C is
caused by the decomposition of CuNI. An exothermic
process at the temperature of higher than 370°C is due
to further decomposition of the decomposition prod-
ucts in coacervate phase. The TG curves also show
two-stage mass loss processes.
n
n
b I (Ea ,Ta,i )
j
min =
-n(n-1)
(3)
åå
j¹i b I (Ea ,Ta,j )
i
i
are shown in Figs 3–4 and Tables 2–3. It is clear that
the values of Ea do not seem to remain constant in the
Analysis of kinetic data
In order to obtain the kinetic parameters (the apparent
activation energy Ea and pre-exponential constant A) of
the major exothermic decomposition reaction of CuNI, a
multiple heating method [13] (Kissinger’s method) is
employed. From the original data in Table 1, Ea is deter-
mined to be 233.21 kJ mol–1 and A as 1017.95 s–1. The lin-
ear correlation coefficient (rk) is 0.9868. The values of
Ea and r0 obtained by Ozawa’s method [14] are
231.52 kJ mol–1 and 0.9879, respectively.
Under the condition of static N2 gas, the value
(Te0) of the onset temperature (Te) corresponding to
b®0 by Eq. (1) taken from [15] using the data of Te
and b in Table 1 are 589.85 K,
Fig. 1 PDSC curves of CuNI at different heating rates
Tei =Te0 +bb +cb2 +db3, i=1, 2, …, 5
(1)
i
i
i
where, b, c and d are the coefficients.
The value of the critical temperature of thermal
decomposition (Tb) obtained from Eq. (2) taken from
[16] using the value of Te0 and Eo in Table 1 is
601.97 K,
Eo - Eo2 -4EoRTe0
Tb =
(2)
2R
where R is the gas constant (8.314 J mol–1 K–1) and Eo
the value of E obtained by Ozawa’s method
(231.5 kJ mol–1).
Fig. 2 TG curves of CuNI at different heating rates
Table 1 Kinetic parameters of thermal decomposition of CuNI under static atmosphere calculated by Kissinger’s method and
Ozawa’s method*
b/K min–1
a
Ek /
kJ mol–1
a
Ak /
s–1
b
E0 /
kJ mol–1
c
Tb /K
rk
r0
Te0/K
5
10
15
20
40
Te/K 603.16 610.13 619.29 620.22 629.03
Tp/K 604.54 612.75 621.56 622.33 630.56
230.60
231.52
0.9891 589.85 601.97
0.9879
233.21
1017.95 0.9868
*Te – onset temperature in the DSC curve; Tp – maximum peak temperature; b – heating rate; Teo – the value (Teo) of the onset
temperature (Te) corresponding to b®0 by Eq. (1); Tb – critical temperature of thermal explosion; Ea – apparent activation energy;
A – pre-exponential constant; r – linear correlation coefficient; subscript k – data obtained by Kissinger’s method; subscript
o – data obtained by Ozawa’s method. aValues of Ek and Ak calculated from the relationship of ln(bi/Tp2i ) vs. 1/Tpi; bValues of Eo
calculated from the relationship of lgbi vs. 1/Tei or Tpi; cThe value of Tb obtained from Eq. (2) using the data of Eo and Te0.
