Microwave-assisted solid-phase synthesis of antisense acpP peptide nucleic acid-peptide conjugates active against colistin- and tigecycline-resistant E. coli and K. pneumoniae

Article abstract of DOI:10.1016/j.ejmech.2019.02.024

Recent discovery of potent antibacterial antisense PNA-peptide conjugates encouraged development of a fast and efficient synthesis protocol that facilitates structure-activity studies. The use of an Fmoc/Boc protection scheme for both PNA monomers and amino acid building blocks in combination with microwave-assisted solid-phase synthesis proved to be a convenient procedure for continuous assembly of antisense PNA-peptide conjugates. A validated antisense PNA oligomer (CTCATACTCT; targeting mRNA of the acpP gene) was linked to N-terminally modified drosocin (i.e., RXR-PRPYSPRPTSHPRPIRV; X = aminohexanoic acid) or to a truncated Pip1 peptide (i.e., RXRRXR-IKILFQNRRMKWKK; X = aminohexanoic acid), and determination of the antibacterial effects of the resulting conjugates allowed assessment of the influence of different linkers as well as differences between the L- and D-forms of the peptides. The drosocin-derived compound without a linker moiety exhibited highest antibacterial activity against both wild-type Escherichia coli and Klebsiella pneumoniae (MICs in the range 2–4 μg/mL ～ 0.3–0.7 μM), while analogues displaying an ethylene glycol (eg1) moiety or a polar maleimide linker also possessed activity toward wild-type K. pneumoniae (MICs of 4–8 μg/mL ～ 0.6–1.3 μM). Against two colistin-resistant E. coli strains the linker-deficient compound proved most potent (with MICs in the range 2–4 μg/mL ～ 0.3–0.7 μM). The truncated all-L Pip1 peptide had moderate inherent activity against E. coli, and this was unaltered or reduced upon conjugation to the antisense PNA oligomer. By contrast, this peptide was 8-fold less potent against K. pneumoniae, but in this case some PNA-peptide conjugates exhibited potent antisense activity (MICs of 2–8 μg/mL ～ 0.3–1.2 μM). Most interestingly, the antibacterial activity of the D-form peptide itself was 2- to 16-fold higher than that of the L-form, even for the colistin- and tigecycline-resistant E. coli strains (MIC of 1–2 μg/mL ～ 0.25–0.5 μM). Low activity was found for conjugates with a two-mismatch PNA sequence corroborating an antisense mode of action. Conjugates containing a D-form peptide were also significantly less active. In conclusion, we have designed and synthesized antisense PNA-drosocin conjugates with potent antibacterial activity against colistin- and tigecycline-resistant E. coli and K. pneumonia without concomitant hemolytic properties. In addition, a truncated D-form of Pip1 was identified as a peptide exhibiting potent activity against both wild-type and multidrug-resistant E. coli, P. aeruginosa, and A. baumannii (MICs within the range 1–4 μg/mL ～ 0.25–1 μM) as well as toward wild-type Staphylococcus aureus (MIC of 2–4 μg/mL ～ 0.5–1.0 μM).

Full text of DOI:10.1016/j.ejmech.2019.02.024

Accepted Manuscript
Microwave-assisted solid-phase synthesis of antisense acpP peptide nucleic acid-
peptide conjugates active against colistin- and tigecycline-resistant E. coli and K.
pneumoniae
Anna Mette Hansen, Gitte Bonke, Wouter Frederik Johan Hogendorf, Fredrik
Björkling, John Nielsen, Kenneth T. Kongstad, Dorota Zabicka, Magdalena Tomczak,
Malgorzata Urbas, Peter E. Nielsen, Henrik Franzyk
PII:
S0223-5234(19)30138-2
DOI:
https://doi.org/10.1016/j.ejmech.2019.02.024
EJMECH 11116
Reference:
To appear in: European Journal of Medicinal Chemistry
Received Date: 23 March 2018
Revised Date: 5 February 2019
Accepted Date: 7 February 2019
Please cite this article as: A.M. Hansen, G. Bonke, W.F.J. Hogendorf, F. Björkling, J. Nielsen, K.T.
Kongstad, D. Zabicka, M. Tomczak, M. Urbas, P.E. Nielsen, H. Franzyk, Microwave-assisted solid-
phase synthesis of antisense acpP peptide nucleic acid-peptide conjugates active against colistin- and
tigecycline-resistant E. coli and K. pneumoniae, European Journal of Medicinal Chemistry (2019), doi:
https://doi.org/10.1016/j.ejmech.2019.02.024.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Microwave-assisted solid-phase synthesis of antisense acpP peptide nucleic acid-peptide
conjugates active against colistin- and tigecycline-resistant E. coli and K. pneumoniae
Anna Mette Hansen,[a] Gitte Bonke,[a] Wouter Frederik Johan Hogendorf,[a] Fredrik Björkling,[a]
John Nielsen,[a] Kenneth T. Kongstad,[a] Dorota Zabicka,[b] Magdalena Tomczak[b], Malgorzata
Urbas,[b] Peter E. Nielsen,[c] and Henrik Franzyk*[a]
[a] Department of Drug Design and Pharmacology, Faculty of Health and Medical Sciences, University of
Copenhagen, Jagtvej 162, DK-2100, Denmark
[b] Department of Epidemiology and Clinical Microbiology, National Medicines Institute, ul. Chełmska 30/34,
00-725 Warsaw, Poland
[c] Department of Cellular and Molecular Medicine, Faculty of Health and Medical Sciences, University of
Copenhagen, Blegdamsvej 3, DK-2100, Denmark
*E-mail: henrik.franzyk@sund.ku.dk
Abstract
Recent discovery of potent antibacterial antisense PNA-peptide conjugates encouraged
development of a fast and efficient synthesis protocol that facilitates structure-activity studies.
The use of an Fmoc/Boc protection scheme for both PNA monomers and amino acid building
blocks in combination with microwave-assisted solid-phase synthesis proved to be a convenient
procedure for continuous assembly of antisense PNA-peptide conjugates.
A validated antisense PNA oligomer (CTC-ATA-CTC-T; targeting mRNA of the acpP gene) was linked
to N-terminally modified drosocin (i.e., RXR-PRPYSPRPTSHPRPIRV; X = aminohexanoic acid) or to a
truncated Pip1 peptide (i.e., RXRRXR-IKILFQNRRMKWKK; X = aminohexanoic acid), and
determination of the antibacterial effects of the resulting conjugates allowed assessment of the
influence of different linkers as well as differences between the L- and D-forms of the peptides.
The drosocin-derived compound without a linker moiety exhibited highest antibacterial activity
against both wild-type Escherichia coli and Klebsiella pneumoniae (MICs in the range 2-4 µg/mL
0.3-0.7 µM), while analogues displaying an ethylene glycol (eg1) moiety or a polar maleimide
linker also possessed activity toward wild-type K. pneumoniae (MICs of 4-8 µg/mL 0.6-1.3 µM).
1

ACCEPTED MANUSCRIPT
Against two colistin-resistant E. coli strains the linker-deficient compound proved most potent
(with MICs in the range 2-4 µg/mL 0.3-0.7 µM).
The truncated all-L Pip1 peptide had moderate inherent activity against E. coli, and this was
unaltered or reduced upon conjugation to the antisense PNA oligomer. By contrast, this peptide
was 8-fold less potent against K. pneumoniae, but in this case some PNA-peptide conjugates
exhibited potent antisense activity (MICs of 2-8 µg/mL 0.3-1.2 µM). Most interestingly, the
antibacterial activity of the D-form peptide itself was 2- to 16-fold higher than that of the L-form,
even for the colistin- and tigecycline-resistant E. coli strains (MIC of 1-2 µg/mL 0.25-0.5 µM). Low
activity was found for conjugates with a two-mismatch PNA sequence corroborating an antisense
mode of action. Conjugates containing a D-form peptide were also significantly less active. In
conclusion, we have designed and synthesized antisense PNA-drosocin conjugates with potent
antibacterial activity against colistin- and tigecycline-resistant E. coli and K. pneumonia without
concomitant hemolytic properties. In addition, a truncated D-form of Pip1 was identified as a
peptide exhibiting potent activity against both wild- type and multidrug-resistant E. coli, P.
aeruginosa, and A. baumannii (MICs within the range 1-4 µg/mL 0.25-1 µM) as well as toward
wild-type Staphylococcus aureus (MIC of 2-4 µg/mL 0.5-1.0 µM).
Keywords: antisense PNA; delivery peptide; conjugates; antibacterial; Escherichia coli; Klebsiella
pneumoniae.
Abbreviations:
A: adenine; Alloc: allyloxycarbonyl; AMP: antimicrobial peptide; AMR: antimicrobial resistance; B:
β-alanine; Bhoc: benzhydryloxycarbonyl; Boc: tert-butyloxycarbonyl; BSA: bovine serum albumin;
Bts: 1,3-benzothiazol-2-yl; Cl-Bhoc: chloro-benzhydryloxycarbonyl; C: cytosine; CFU: colony-
forming unit; CST: colistin; CST-R: colistin-resistant; CST-S: colistin-susceptible; DIPEA: N,N-
Diisopropylethylamine; DMT: 4,4'-dimethoxytrityl; Dde: 1-(4,4-dimethyl-2,6-dioxocyclohex-1-
ylidene)ethyl; Dts: dithiasuccinoyl; ESBL: extended-spectrum β-lactamase; eg1: O-linker = AEEA
linker = [2-(2-aminoethoxy)ethoxy]acetic acid; Fmoc: fluoren-9-ylmethoxycarbonyl; G: guanine; I:
intermediate; KPC: Klebsiella pneumoniae carbapenemase; MCR: mobile colistin resistance; MDR:
multidrug-resistant; MIC: minimal inhibitory concentration; Mmt: monomethoxytrityl; Mtt:
monomethyltrityl; MW: microwave; NDM: New Delhi metallo-β-lactamase; NHS: N-
hydroxysuccinimidyl; NMI: National Medicine Institute, Warzaw, Poland; NVOC:
nitroveratryloxycarbonyl; 4-OMe-Z: p-methoxybenzyloxycarbonyl; PMB: p-methoxybenzyl; PNA:
2

ACCEPTED MANUSCRIPT
peptide nucleic acid; pNZ: p-nitrobenzyloxycarbonyl; R: resistant; S: susceptible; SMCC:
succinimidyl 4-(N-maleimidomethyl)cyclohexane-1-carboxylate; SPPS: solid-phase peptide
synthesis; SPS: solid-phase synthesis; Teoc: 2-(trimethylsilyl)ethyloxycarbonyl; T: thymine; TGC:
tigecycline; TGC-I: tigecycline-intermediate; TGC-R: tigecycline-resistant; TGC-S: tigecycline-
susceptible; X: 6-aminohexanoic acid; Z: benzyloxycarbonyl; TSTU: O-(N-succinimidyl)-1,1,3,3-
tetramethyluronium tetrafluoroborate.
1. Introduction
Antimicrobial resistance (AMR) is a continually growing global threat to human
health, and already in 2011 more than 2 million infections caused approx. 23.000 deaths in the US
[1,2]. In particular, AMR in the Gram-negative bacteria Escherichia coli and Klebsiella pneumoniae
constitutes a challenge due to high prevalence of multidrug-resistant (MDR) clinical isolates [3].
The situation is further aggravated by the fact even though 30 antibiotics have been launched
since 2000, only five represent novel classes of antibiotics, and these are all limited to targeting
Gram-positive bacteria. This emphasizes the importance of identifying new classes of antibiotics
with efficacy against Gram-negative pathogens [4]. As of 2015 the pipeline of compounds in
clinical development for treatment of Gram-negative infections comprised 24 potential antibiotics.
However, these comprise primarily improved analogues belonging to the classes of β-lactams
(including combinations with β-lactamase inhibitors), tetracyclines, aminoglycosides and
topoisomerase inhibitors that all interact with targets well-known for their propensity to undergo
rapid mutation with ensuing short expected clinical lifetime of the antibiotics [5]. Consequently,
novel antibacterial agents with alternative targets and/or novel mode of action as compared to
current antibiotics are needed.
An antisense approach relying on peptide nucleic acid (PNA) oligomers for silencing
of essential bacterial gene expression was introduced two decades ago [6-9]. In particular, the
acpP gene, essential for fatty acid biosynthesis, has been validated as a sensitive target for
antisense PNA-peptide conjugates [6,7,10]. Originally, conjugation to the peptide (KFF)3K, and
subsequently to arginine-rich peptides [7-13], was employed as a means for enhancing delivery of
antisense PNA oligomers that inherently display poor bacterial uptake. Moreover, site-specific
activity of the anti-acpP PNA sequence was confirmed by the real-time quantitative PCR [14].
Recently, antimicrobial peptides (AMPs) with an intracellular target were shown to constitute
alternative carriers enabling efficient bacterial delivery of PNA oligomers [13].
3

ACCEPTED MANUSCRIPT
Bacterial resistance to certain PNA-peptide conjugates has been correlated to the
presence of a functional sbmA gene encoding an ABC transporter involved in translocation of Pro-
rich AMPs, PNA oligomers, and PNA-peptide conjugates across the inner membrane of Gram-
negative bacteria [10,13,15-18]. However, delivery moieties (e.g., repetitive arginine/6-
aminohexanoic acid motifs as well as the AMPs Pep-1-K, KLW-9,13-a, and the C-terminally
modified drosocin-RXR with X = 6-aminohexanoic acid) that confer PNA antisense activity in a
∆sbmA E. coli strain have recently been identified [10,13]. In the present work, we investigated the
synthesis and antibacterial activity of a 10-mer PNA oligomer conjugated to N-terminally RXR-
modified drosocin or a shortened version of PNA-internalizing peptide 1 (Pip1) [19], the latter
being a hybrid between the cell-penetrating RXR repeats and R6-penetratin [19,20].
Originally, PNA oligomers were obtained via assembly of Boc/Z-protected monomers
[21-24], and subsequently by a number of synthetic protocols involving Fmoc-protected building
blocks displaying a variety of nucleobase protecting groups: Z [25], Bhoc (commercially available)
[26,27], Cl-Bhoc [27], F-Bhoc [27], 4-OMe-Z [27], Teoc [27], Boc [27,28], and bis(Boc) [29-31]. In
addition, alternatives to Fmoc protection as temporary backbone amine protecting group have
been proposed (with the nucleobase protecting groups stated in the brackets): Mmt (anisoyl/4-
tBu-benzoyl/isobutanoyl) [32], Dts (Z) [33], DMT (PMB) [34], azido (Bhoc) [35], Alloc (Bhoc) [36],
NVOC (anisoyl/isobutyryl) [37], Dde (Mmt) [38], Bts (Boc) [39], Mtt (Boc) [40], and pNZ (bis-Boc)
[41].
Methodologies for obtaining PNA-peptide conjugates involve either continuous Boc-,
Fmoc- or combined Boc(PNA)/Fmoc(peptide)-based solid-phase synthesis (SPS), or alternatively a
two-step assembly of purified PNA oligomer and peptide by using a bisfunctional linker [20,42].
However, the latter approach is time-consuming as it involves three separate syntheses each
requiring purification by HPLC. In previous protocols for manual PNA synthesis [43] and continuous
automated synthesis of PNA-peptide conjugates the commercially available Fmoc/Bhoc monomers
have been applied since this enables a convenient simultaneous removal of all protecting groups
and cleavage from resin under acidic conditions [44-46]. To our knowledge only building blocks
displaying a traditional Bhoc protection of the nucleobases in combination with a temporary Fmoc
protection are commercially available. Nevertheless, these Bhoc-protected monomers are both
expensive and possess reduced solubility in the solvents usually employed for SPS (i.e., DMF, NMP
or CH2Cl2). Addition of DMSO may promote dissolution, but then different coupling conditions
with other MW settings may need to be used for the C monomer due to the large difference in the
degree of MW energy absorption between DMF/NMP and DMSO, thus complicating the
4

ACCEPTED MANUSCRIPT
methodology. Another advantage of applying this protection scheme for the nucleobases is that
Boc constitutes a “traceless protecting group” when employed in combination with a TFA-H2O-TIS
cleavage mixture (in many cases TIS may be omitted). Thus, when using Boc protection of the
nucleobases it is possible to avoid any sample clean-up prior to purification by HPLC. Hence,
alternative strategy using Fmoc/Boc monomers [27] was chosen for exploration of a novel
protocol for automated microwave (MW)-assisted continuous synthesis of PNA-peptide
conjugates.
Existing protocols for synthesis of PNA-peptide conjugates by MW-assisted SPS
comprise: (i) separate peptide synthesis and PNA oligomer synthesis by using Fmoc/Bhoc-
protected PNA monomers [19] followed by conjugation, or (ii) continuous synthesis of the entire
PNA-peptide conjugate [47]; an alternative method for the latter involves an Fmoc/Dde protection
scheme [48]. By contrast, there appears to be no reports on the use of Fmoc/Boc PNA monomers
[27] for MW-assisted assembly of PNA alone or in combination with Fmoc-protected amino acids
with acid-labile side-chain protecting groups. Nevertheless, since Fmoc-based solid-phase peptide
synthesis (SPPS) is the most commonly used methodology in automated assembly of peptides, we
have investigated the use of such PNA monomers in a versatile strategy for automated continuous
synthesis of PNA-peptide constructs.
2. Results and Discussion
2.1. Chemistry
2.1.1. Monomer synthesis
Fmoc/Bhoc-protected PNA monomers as well as Fmoc-protected thymine monomer
were obtained from a commercial supplier, while Fmoc/Boc-protected cytosine, adenine and
guanine monomers were prepared via modifications of conversions reported in earlier synthesis
studies [27], combined with alternative starting materials and strategies, thereby enabling overall
shorter synthetic sequences (Fig. 1).
The starting Fmoc-protected aminoethylglycine PNA backbone (1) was prepared in
large scale according to previously reported procedures [46,49]. Next, the Fmoc/Boc-protected
cytosine PNA monomer (3) was obtained from acylation of 1 with the intermediate acetic acid 2 in
high yield (93% cf. 72% in [27]) by using TSTU as the coupling reagent, albeit extended activation
and prolonged reaction times were needed. Synthesis of the Fmoc/Boc-protected adenine PNA
monomer (7) was achieved in three steps starting from the commercially available ethyl ester 4.
Initial Boc protection of the aminopurine moiety followed by saponification of the ethyl ester 5
5

ACCEPTED MANUSCRIPT
afforded Boc-protected acetic acid 6 in 40% overall yield, which was comparable to the original
more time-consuming sequence starting from adenine with conversion into the benzyl ester
corresponding to 4. Finally, coupling of 6 to the PNA backbone 1 resulted in an acceptable yield
(66% cf. 64% in [26]) of the Fmoc/Boc-protected adenine PNA monomer (7). Importantly, this
modified shorter sequence constitutes a cheap, fast and readily scalable protocol.
Figure 1. Reaction scheme for synthesis of Fmoc/Boc-protected PNA monomers. (a) TSTU and
DIPEA, rt, 2 h; then 1 and DIPEA, 3 h, rt (3: 93%; 7: 66%; 11: 82%); (b) carbonyldiimidazole (CDI),
105 °C, 1 h; tert-butanol, 95°C → rt, overnight (45%); (c) LiOH, 48 h, rt (89%); (d) K2CO3, ethyl 2-
bromoacetate (dropwise during 30 min), rt, overnight (87%); (e) NaH and 2-cyanoethanol, THF, -78
°C → 0 °C; then 9, 0 °C → rt, 48 h, followed by H2O, 0 °C, pH 2-3 (67%).
6

ACCEPTED MANUSCRIPT
The Fmoc/Boc-protected guanine PNA monomer (11) was obtained in four steps
starting from 8 [50]. First, alkylation of 2-amino-6-chloropurine building block 8 with ethyl
bromoacetate afforded 9 in good yield (87%), while subsequent one-pot saponification and
transformation into guanine resulted in Boc-guanine acetic acid 10 in a moderate yield (67%).
Similarly, the Fmoc/Boc-protected guanine PNA monomer (11) was assembled in good yield (82%)
by TSTU coupling of Boc-guanine acetic acid 10 with backbone 1, which gave an 48% overall yield
of guanine PNA building block 11, while a 36% overall yield was obtained in four steps starting
from 6-chloro-2-aminopurine via the corresponding benzyl acetic ester [27]. Despite the present
improvements, purification of the desired protected monomers remained a challenge due to low
solubility in solvent mixtures suitable for extraction and/or column chromatography, however, by
combining previous and modified methods gram-scale syntheses of all three monomers were
accomplished with purities appropriate for use in SPS.
2.1.2. Microwave-assisted solid-phase synthesis
Initially, the efficiency of Fmoc/Boc-protected PNA monomers in assembly of PNA
oligomers was assessed by performing SPS of a PNA pentamer, containing all four nucleobases
(i.e., Fmoc-Gly-TGCAT-NH2 retaining the Fmoc at the N-terminus to confer sufficient retention on
HPLC), on an Fmoc-Rink amide polystyrene resin as well as on an H-Rink amide ChemMatrix® resin.
Comparison of the HPLC chromatograms of the crude products (see Fig. S1 in Supplementary
Material) indicated that the ChemMatrix® resin was superior in terms of purity of the crude
product as reported earlier for similarly complex compounds [51].
Standard MW-assisted SPPS is conducted at 75 °C for most couplings (when using a
CEM Liberty synthesizer [52,53]). However, the potential thermolability of Boc protecting groups
[54,55] present on the nucleobases constitutes a risk for spontaneous Boc deprotection during the
repeated cycles of MW heating, potentially leading to branched byproducts. To investigate at
which temperature the Boc group might undergo spontaneous degradation Fmoc-Gly-TGCAT-NH2
was synthesized manually (with conventional heating), while Fmoc-Gly-GCAT-NH2 was prepared by
automated synthesis (with MW heating) at 45 °C, 55 °C, 65 °C and 75 °C. HPLC chromatograms of
the crude oligomers (see Fig. S2 in Supplementary Material) showed that high-purity crude
products was formed at 45 °C, while several byproducts were produced at temperatures above 45
°C. Additional experiments, in which each Fmoc/Boc-protected PNA monomer was heated to 45
°C, 55 °C, 65 °C and 75 °C, confirmed that Boc groups on nucleobases indeed are labile at
temperatures higher than 45 °C as judged by analytical HPLC and MALDI-TOF analysis. Thus,
7

ACCEPTED MANUSCRIPT
assembly of both PNA oligomer and peptide should proceed cleanly when performed at 45 °C,
thereby enabling continuous synthesis of the entire PNA-peptide conjugate. When a (reversed)
peptide-PNA conjugate is desired the peptide may be synthesized at a higher coupling
temperature followed by PNA assembly at a lower temperature.
The excess of PNA monomer required to achieve a satisfactory purity of the resulting
oligomer and ultimately of the conjugate is another variable. For MW-assisted SPPS, the
recommended default excess of amino acid building block is 5 equivalents. However, due to the
considerably higher cost of PNA monomers it was attractive to investigate whether use of a lower
excess might be feasible. Experiments using 2, 3, or 4 equivalents of each PNA monomer for
preparation of Fmoc-Gly-GCAT-NH2 showed that purity did not improve significantly beyond the
use of 3 equivalents. Finally, in order to achieve a fast and efficient methodology, the coupling
time was likewise varied (5, 10 and 15 min), and similar purity was obtained with both the
standard period of 10 min and with a prolonged coupling of 15 min, while a coupling time of 5 min
proved less efficient.
These optimized conditions were employed for the continuous synthesis of PNA-
peptide compounds lacking a linker or having an eg1 moiety as spacer, as the latter previously has
been incorporated in conjugates obtained by manual continuous Boc-based synthesis.
2.1.3. Approaches for obtaining PNA-peptide conjugates
Encouraged by our recent finding that SbmA-independent antibacterial conjugates
could be obtained by combining a validated 10-mer acpP antisense PNA oligomer (CTC-ATA-CTC-T)
with AMPs possessing a propensity for bacterial internalization [13], we investigated similar
conjugates based on an RXR-modified drosocin (i.e., RXR-PRPYSPRPTSHPRPIRV-NH2; L-12) and a
truncated analogue of Pip1 ([RXR]3IKILFQNRRMKWKKM) with only two RXR repeats. Conjugates
having different linkers between the two parts as well as the conjugate devoid of a linker were
synthesized, since previous studies had inferred that this structural feature might influence the
antibacterial activity [7] and/or delivery to human cells [20,56,57].
Previously, several linker moieties were utilized for connecting antisense PNA
oligomers with suitable delivery peptides [20], e.g., one or more repeats of the ethylene glycol
linker (eg1; also denoted as the O-linker) or the succinimidyl 4-(N-maleimidomethyl)cyclohexane-
1-carboxylate (SMCC). These as well as a more hydrophilic maleimide ethylene glycol linker (i.e.,
Mal-eg1; not previously explored for this purpose) were studied in the present work (Fig. 2A). The
initial step involved formation of an amide linkage between the N-terminus of the PNA oligomer
8

ACCEPTED MANUSCRIPT
and the appropriate bisfunctional reagent containing an N-hydroxysuccimide (NHS) ester moiety
as well as a maleimide group (i.e., SMCC NHS ester [7,58] or Mal-eg1 NHS ester [59,60]; Fig. 2B).
After full conversion into an intermediate modified PNA the final conjugate was obtained upon
addition of a Cys-containing delivery peptide to the maleimide moiety (a one-pot protocol may be
utilized for Mal-eg1 while a precipitation step is included for SMCC).
Figure 2. Synthesis of conjugates via bisfunctional linkers. (A) Different linkers used in the present
work; (B) Two-step one-pot assembly protocol (see Experimental Section for details).
2.1.3. Peptides and PNA-peptide conjugates
For all-L RXR-drosocin (L-12) either the hydrophobic SMCC linker or the more
hydrophilic Mal-eg1 linker was inserted between the anti-acpP PNA oligomer (targeting acpP
9

ACCEPTED MANUSCRIPT
expression) and the delivery peptide to give conjugates L-13 and L-14, respectively (see Table 1).
Also, the corresponding all- peptide (i.e., D-12) and the corresponding antisense PNA conjugate
D
(i.e., D-14) were included for comparison. In addition, PNA-peptide conjugate L-15 (having a single
eg1 residue as linker) and L-16 (lacking a linker between the PNA and peptide moieties) as well as
its mismatch control L-16m (displaying a PNA oligomer with a shuffled base sequence) and the
conjugate containing the all-D peptide (i.e., D-16) were synthesized.
Likewise, the truncated Pip1-derivative (i.e., [RXR]2IKILFQNRRMKWKK-NH2; L-17) was
conjugated to anti-acpP PNA via the SMCC, Mal-eg1 or eg1 moieties to give L-18, L-19, and L-20,
respectively. Also, the all-D peptide D-17 was conjugated to anti-acpP PNA to give conjugate D-19.
A compound without a linker moiety (i.e., L-21), as well as mismatch controls (L-19m and L-21m)
were included in this series of compounds.
2.2. Microbiological evaluation
2.2.1. Panel of bacteria and activity trends
Minimal inhibitory concentrations (MICs) for the peptides and PNA-peptide
conjugates were determined against a panel of pathogenic bacteria (capable of causing human
diseases) comprising wild-type (WT) ATCC strains of E. coli, K. pneumoniae, Pseudomonas
aeruginosa, Acinetobacter baumannii, Staphylococcus aureus as well as an E. coli ∆sbmA strain
lacking a functional SbmA inner-membrane peptide transporter (Table 1). In addition, the
conjugates were tested against four selected MDR Enterobacteriaceae strains comprising K.
pneumoniae NMI 2697/14 and NMI 3081/09, and E. coli NMI3898/15 and NMI 3548/14, all being
clinical isolates obtained from Polish hospitals during the period of 2009-2015. These MDR strains
represent various resistance patterns, levels and mechanisms (see Table 2, and Table S2 in
Supplementary Material), including plasmidic (mcr-1) and chromosomally encoded resistance to
colistin, tigecycline, and/or β-lactams (associated with expression of various β-lactamases e.g.,
CTX-M-like ESBLs, carbapenemase KPC, or CMY-2 cephalosporinase).
10

ACCEPTED MANUSCRIPT
Table 1. MIC values (in µg/mL) against the screening panel of bacteria.
E. coli
E. coli
K. pneumoniae
P. aeruginosa
P. aeruginosa
A. baumannii
S. aureus
ATCC 25922
ATCC 13883
ATCC 27853
PAO1
ATCC 19606
ATCC 29213
∆sbmA
L-12
D-12
L-13
L-14
D-14
L-15
L-16
(RXR)PRPYSPRPTSHPRPIRV-NH2
(rXr)prpysprptshprpirv-NH2
>64
>64
16
>64
>64
>64
>64
64
>64
>64
8
-
>64
>64
>64
>64
>64
>64
>64
>64
>64
64
>64
>64
>64
>64
>64
>64
>64
>64
>64
-
>64
>64
>64
64
(RXR)PRPYSPRPTSHPRPIRVC-SMCC-(PNA2301)
(RXR)PRPYSPRPTSHPRPIRVC-(Mal-eg1)-(PNA2301)
(rXr)prpysprptshprpirvc-(Mal-eg1)-(PNA2301)
(RXR)PRPYSPRPTSHPRPIRV-eg1-(PNA2301)
(RXR)PRPYSPRPTSHPRPIRV-(PNA2301)
-
16
32
4-8
8-16
4-8
2-4
64
-
-
32
4
>64
>64
>64
>64
-
>64
>64
64
L-16m (RXR)PRPYSPRPTSHPRPIRV-(PNA3961)
>64
>64
-
-
>64
>64
D-16
(rXr)prpysprptshprpirv-(PNA2301)
8-16
L-17
D-17
L-18
L-19
(RXR)2IKILFQNRRMKWKK-NH2
(rXr)2ikilfqnrrmkwkk-NH2
8
2-4
16
8
8
2
64
4
-
2
-
8
1
8
2
32-64
2-4
64
(RXR)2IKILFQNRRMKWKKC-SMCC-(PNA2301)
(RXR)2IKILFQNRRMKWKKC-(Mal-eg1)-(PNA2301)
16
8-16
32
8
4-8
2-4
64
16
8
32
32-64
32
16
16
-
>64
>64
32
L-19m (RXR)2IKILFQNRRMKWKKC-(Mal-eg1)-(PNA3961)
32
8
-
16
D-19
L-20
L-21
(rXr)2ikilfqnrrmkwkkc-(Mal-eg1)-(PNA2301)
(RXR)2IKILFQNRRMKWKK-eg1-(PNA2301)
(RXR)2IKILFQNRRMKWKK-(PNA2301)
-
8
32
4
32
16
16
64
16
16
64
-
>64
>64
>64
8
>64
-
32
32
16
16-32
L-21m (RXR)2IKILFQNRRMKWKK-(PNA3961)
-
CST
0.125-0.5
0.5
2-4
0.25
0.5
0.25
>16
Compounds with prefices L and D indicates that peptide is the all-L and all-D form, respectively, while suffix m indicates that the conjugate contains a control PNA with two
mismatched (interchanged) nucleobases. X = 6-aminohexanoic acid = H2N-(CH2)5COOH residue. Anti-acpP: PNA2301 = H-CTCATACTCT-NH2; Mismatch: PNA3961 = H-CTCTTACACT-
NH2. CST = colistin.
11

ACCEPTED MANUSCRIPT
The minimal inhibitory concentrations (MICs) revealed that only PNA-peptide L-16
exhibited efficient antisense activity in E. coli ATCC 25922 (MIC = 4 µg/mL 0.7 µM), while the
activity of conjugates L-19 and D-19 appears to arise mainly from the delivery peptide (i.e., L-17).
Moreover, in E. coli antibacterial activity was abolished in the mutant lacking the SbmA peptide
transporter, which recently was reported to be the case for several similar PNA-AMP conjugates
[13]. The peptide D-17 was significantly more potent (MIC values of 1-4 µg/mL 0.25-1 µM) than
L-17 (MICs in the range 8-64 µg/mL). K. pneumoniae, displaying an identical acpP antisense target
sequence, proved to be susceptible to several PNA-peptide conjugates (MICs in the range 2-8
µg/mL 0.3-1.3 µM). By contrast, in P. aeruginosa, A. baumannii, and S. aureus, having a different
acpP target sequence, the antibacterial effect of the conjugates containing the modified pip1
appears to arise from the peptide. Noticeably, peptide D-17 exhibited broad-spectrum activity
(with MICs in the range 1-4 µg/mL 0.25-1 µM) against all Gram-negative pathogens included in
the panel as well as toward the Gram-positive S. aureus.
The two most potent compounds L-16 and D-17 were also tested against additional
strains, including wild-type P. aeruginosa ATCC 27853, two colistin-resistant P. aeruginosa and A.
baumannii strains (CST-R; MIC >16 µg/mL), and three E. coli clinical isolates obtained from Polish
hospitals during the period of 2011-1016: susceptible to colistin but resistant to carbapenems due
to expression of NDM-1 or NDM-5 carbapenemases (Table 3). Both compounds L-16 and D-17
exhibited potent activity against all NDM producers (MIC range 0.5-2 µg/mL 0.1-0.5 µM), but
only D-17 was efficient against colistin-resistant P. aeruginosa and A. baumannii strains (MIC 2-4
µg/mL 0.5-1 µM).
2.2.2. PNA-drosocin series
Compound L-16, lacking a linker, exhibited potent activity against WT E. coli (MIC of 4
µg/mL 0.7 µM) that may be ascribed to an SbmA-dependent antisense mechanism, based on the
finding of an at least 16-fold lower activity of the delivery peptide (i.e., L-12 ) and of the
mismatched PNA conjugate L-16m in combination with a similarly low activity of L-16 against the
E. coli ∆sbmA strain.
Noticeably, the linker-containing antisense conjugates had only moderate activity
against WT E. coli (i.e., L-13, L-14 and L-15 had MIC values in the range 16-32 µg/mL). This
observation infers that the presence of a linker moiety may indeed influence the bacterial delivery.
That linkers appear to influence PNA uptake by cells was earlier found also by Hatamoto et al. [61],
12

ACCEPTED MANUSCRIPT
and in more recent work with a vitamin B12-mediated transport of PNA to E. coli cells [62,63].
Similarly, differences between linker types were observed in an earlier study where a PNA-peptide
conjugate with an SMCC linker gave rise to a lower antibacterial activity in E. coli than the
corresponding conjugate with an eg1 spacer [7]. Moreover, the potency of L-16 is comparable to
that of the analogue with the RXR motif inserted at the C-terminus of drosocin (i.e.,
GKPRPYSPRPTSHPRPI-RXR-NH2) [13]. Interestingly, for the latter conjugate activity was retained
when tested against an E. coli ∆sbmA strain [13]. In addition D-16, exhibited a more than 16-fold
lower activity in WT E. coli. Surprisingly, the tigecyline- and colistin-resistant E. coli isolate
NMI3898/15 was more susceptible than the WT strain to conjugates based on drosocin (Table 2).
Thus, compounds L-13, L-14 and L-16 had 2- to 8-fold lower MIC values (as compared to those
against the WT strain), again with L-16 being the most potent (MIC of 1-2 µg/mL 0.15-0.3 µM)
and retaining high activity against E. coli mcr-1 (NMI 3898/15; MIC of 4 µg/mL 0.6 µM ).
Table 2. MIC values (in µg/mL) against drug-resistant strains.
E. coli
E. coli
NMI 3898/15
K. pneumoniae
NMI 2697/14
K. pneumoniae
NMI 3081/09
Hemolysis (%)
at 100 µM
NMI3548/14
L-12
D-12
L-13
32->64
32- >64
>64
>64
>64
32
<1%
<1%
<1%
<1%
<1%
<1%
<1%
<1%
<1%
>64
4-8
>64
16-64
8-32
>64
32 - >64
32 - >64
>64/64
>64
L-14
2-8
64
D-14
L-15
32
64/32
32- >64
4
64
16-32
1-2
32-64
8
L-16
32
L-16m
D-16
>64
64
>64
>64
8-16
>64
>64
>64
L-17
D-17
L-18
L-19
L-19
D-19
L-20
L-21
L-21
4-8
1
16
2
>64
16
>64
16
<1%
<1%
<1%
<1%
<1%
1.6%
<1%
<1%
<1%
8-16
4-8
16-32
8
16
32
16
16
16-32
>64
8-16
>64
16
32-64
8
64
8
32
>64
16
8-16
32
32
64 - >64
>64
16
64- >64
>64
CST
-
2-4
-
-
-
MDR Enterobacteriaceae strains used for the evaluation: E. coli NMI3548/14: tigecycline-resistant (TGC-R with MIC =
16) and colistin (CST-R with MIC = 4; mcr-negative), ESBL (CTX-M-positive); E. coli NMI 3898/15: tigecycline-susceptible
(TGC-S, MIC = 0.5), colistin-resistant (CST-R, MIC =4; mcr1-positive), CMY-2-positive [64]; K. pneumoniae NMI 2697/14:
tigecycline-susceptible (TGC-S, MIC = 0.5), colistin-resistant (CST-R, MIC >16; mcr-negative), ESBL (CTX-M)-positive; K.
pneumoniae NMI 3081/09: tigecycline-intermediate (TGC-I, MIC =2), colistin-susceptible (CST-S, MIC = 1), KPC-positive.
13

ACCEPTED MANUSCRIPT
See also Table S2 in Supplementary Material for further details on resistance patterns. CST = colistin. NMI = National
Medicine Institute, Warzaw, Poland.
Likewise, conjugate L-16 was the most active (MIC of 2-4 µg/mL 0.3-0.7 µM)
against WT K. pneumoniae, albeit also conjugates L-13, L-14, and L-15 displayed 2- to 4-fold lower
MIC values (4-8 µg/mL 0.6-1.2 µM) as compared to those found against E. coli. Notably, the
compound based on the all-D peptide (i.e., D-16 lacking a spacer/linker) was 2- to 8-fold less active
than the L-16. With respect to the resistant K. pneumoniae isolates, only L-16 retained activity
against the MDR (but colistin-susceptible) strain NMI 3081/09 with a MIC value of 8 µg/mL,
whereas all analogues lacked activity in the highly colistin-resistant K. pneumoniae NMI 2697/14
isolate. Finally, none of the conjugates showed significant activity against P. aeruginosa, A.
baumannii, or S. aureus (Table 1).
Table 3. MIC values (in µg/mL) of compounds L-16 and D-17 against MDR clinical.
E. coli
E. coli
E. coli
P. aeruginosa
P. aeruginosa
A. baumannii
NMI 3371/16
ST101 NDM-1
NMI 636/15
ST405 NDM-5
NMI 5428/11
ST410 NDM-1
ATCC 27853
NMI 506/17
NMI 3658/17
L-16
0.5
1
2
1
>64
2
>64
4
32
D-17
2
1-2
2
MDR Enterobacteriaceae strains: E. coli NMI 3371/16: carbapenem-resistant, colistin-susceptible (CST-S), and NDM-1-
positive; E. coli NMI 636/15: carbapenem-resistant, colistin-susceptible (CST-S), and NDM-5-positive; E. coli NMI
5428/11: carbapenem-resistant, colistin-susceptible (CST-S), and NDM-1-positive [65]; P. aeruginosa NMI 506/17:
colistin-resistant (CST-R, MIC >16; mcr-negative); A. baumannii NMI 3658/17: colistin-resistant (CST-R, MIC >16; mcr-
negative).
The corresponding (KFF)3K-eg1-PNA2301 was previously found to exhibit low
micromolar potency against the E. coli strains K12 [7] and DH10B [9], while another (KFF)3K-based
conjugate with a 12-mer PNA (targeting rpoD gene expression) was somewhat less active toward
E. coli MG1655 and an ESBL-producing strain (ATCC 35218) [66]. Also, the anti-acpP PNA with a C-
terminally added lysine, i.e., (KFF)3K-eg1-PNA2301-K (MIC of 16 µg/mL) was also found to be active
against the pathogenic E. coli O157:H7 ST2-8624 strain [67].
Importantly, all peptides and conjugates in this series were found to be essentially
non-hemolytic, as less than 1% hemolysis typically was observed at 100 µM, which corresponds to
a cell selectivity (based on the concentration giving 10% hemolysis relative to the MIC) well above
100 for the most potent compounds.
14

ACCEPTED MANUSCRIPT
2.2.3. PNA-Pip1 series
Inspired by previous reports on targeting gene expression in the Gram-positive
Streptomyces pyogenes [68] and S. aureus [69] by using a common eukaryotic CPP, such as Tat
(GRKKKRRQRRRYK), for bacterial delivery, it was explored whether a shortened analogue of one of
the so far most efficient CPPs for delivery of PNA to human cells, namely the Pip1 peptide [19],
likewise might facilitate efficient uptake in bacteria. Since modification of AMPs with a single
repeat of the RXR motif may be sufficient to confer SbmA-independent enhanced uptake in E. coli
[13], an analogue of Pip1 ([RXR]2IKILFQNRRMKWKK-NH2; L-17), having only two instead of three
RXR repeats at the N-terminus, was examined as delivery peptide in anti-acpP PNA-peptide
conjugates. In this case the peptide itself (L-17) exhibited activity in the Gram-negative species
(albeit weakly in K. pneumoniae). Interestingly, all antisense-based conjugates (L-18, L-19, L-20,
and L-21) were in general equipotent or less active than peptide L-17 itself against all bacteria,
except in the case of K. pneumoniae where all conjugates containing the anti-acpP PNA showed
higher activity than that of peptide L-17 and PNA mismatch control conjugates (L-19m and L-21m),
thereby inferring an antisense mode of action. Finally, L-19 retained significant activity (MIC of 8-
16 µg/mL) against the KPC-producing, colistin-susceptible K. pneumoniae strain NMI 3081/09
(Table 2). In this series, in which the activity is due to the CPP, rather than to a PNA antisense
mechanism, the conjugate lacking a linker or with a short eg1 moiety inserted (i.e., L-21 and L-20,
respectively) were slightly less potent against WT K. pneumoniae than the conjugates containing
either an SMCC or a Mal-eg1 linker (i.e., L-18 or L-19, respectively) with the latter conjugate being
most potent (MIC of 2-4 µg/mL 0.3-0.6 µM).
The antibacterial activity of anti-acpP PNA conjugated to peptide L-17 may relate to
its resemblance to (RXR)4-XB (B = β-alanine) used as an efficient vehicle for delivery of antisense
PMOs and PNAs in E. coli [70,10], K. pneumoniae [66] and P. aeruginosa [12,71]. However,
previous findings suggest that the antibacterial activity of such conjugates may to some extent be
exerted by the (RXR)4-XB peptide moiety [12]. This also seems to be the case for conjugates based
on L-17, albeit less pronounced for K. pneumoniae.
Quite surprisingly, D-17 was significantly more potent (MICs in the range 1-4 µg/mL)
than L-17 (MICs of 8 µg/mL) against all WT strains (Table 1), while D-17 retained activity against
the two colistin-resistant E. coli strains NMI 3548/14 and NMI 3898/15 (MICs of 1 and 2 µg/mL,
respectively, corresponding to 0.25 and 0.5 µM). This could simply be a result of the increased
stability to enzymatic degradation conferred by the all-D stereochemistry or alternatively be due
to another mechanism of action for the -form.
D
15

ACCEPTED MANUSCRIPT
Most analogues in this series, including the all-D peptide D-17, were found to be
essentially non-hemolytic, as less than 1% hemolysis typically was observed at 100 µM, which
further infers that both peptide D-17 and conjugate L-19 constitute promising hit compounds.
2.3. Conclusion
The present work shows that assembly of PNA-peptide conjugates may be performed
conveniently by an Fmoc/Boc-based continuous MW-assisted SPS strategy. This methodology has
the advantage of utilizing monomer building blocks with suitable solubility properties as well as a
decreased workload in synthesis (avoiding a solution-phase conjugation) and purification.
How introduction of a linker between the antisense PNA and the delivery peptide
affects activity remains to be elucidated in detail as it appears to depend on both the delivery
peptide and the targeted bacteria. However, it was demonstrated that absence or proper
selection of a linker or spacer moiety indeed constitutes an optimization feature for PNA-peptide
conjugates. This is exemplified by the finding that the most active conjugate against E. coli (i.e., L-
16) was devoid of a linker residue while for K. pneumoniae also the conjugate containing the Mal-
eg1 linker (i.e., L-14) was almost equipotent, while the SMCC linker was slightly less favorable.
Interestingly, the drosocin-based conjugate D-16 having an all-
D peptide moiety was
inactive in E. coli (while D-14 also containing an all- peptide displayed weak activity), indicating
D
that either translocation across the outer membrane is compromised or the SbmA transporter
discriminates between enantiomers or is preferentially transporting shorter (proteolytically
degraded) fragments of the all-
L drosocin conjugates. For the corresponding pip1-derived
compounds any such effects were totally dominated by the inherent potent antibacterial activity
of the all-
D
pip1 peptide D-17.
Together with earlier findings on the effect of introducing RXR motifs at the termini
of delivery peptides [13], it appears that this approach is not a general solution to circumvent
SbmA-dependent uptake that constitutes a potential Achilles´ heel with respect to resistance
development. However, further optimization concerning size and sequence of RXR-based motifs
may address this. Provided that SbmA-dependent uptake can be abolished, the present bacterial
delivery approach may be useful for exploring other antisense-based therapies targeting bacterial
ribosomes via domain II of 23S rRNA [72] or 16S rRNA [73], or as a means of overcoming resistance
to β-lactam antibiotics as recently explored in E. coli [74]. In relation to K. pneumoniae, earlier
work on antisense-mediated growth inhibition comprise: (i) KFF)3K conjugated to 16-mer anti-gyrA
or anti-ompA PNA oligomers [74], (ii) KFF)3K- and (RXR)4XB-conjugated 10-mer PNAs targeting
16

ACCEPTED MANUSCRIPT
rpoD expression [66], and (iii) KFF)3K-conjugated anti-acpP and anti-murA 10-mer PNAs [9]. It is
noteworthy that out of these conjugates, only the latter displayed low micromolar activity.
Therefore, several of the novel compounds described here constitute interesting starting points
for further optimization of PNA delivery in K. pneumoniae. In conclusion, the most potent
conjugates exhibit promising potency even in certain MDR clinical isolates of E. coli and K.
pneumoniae, which warrant further optimization studies of these.
3. Experimental section
3.1. General procedures
Starting materials and solvents were purchased from commercial suppliers (ABCR GmbH, Alfa
Aesar, AppliChem, CHEMsolute, Fluka, Iris Biotech, LabScan, Merck, Sigma Aldrich and VWR and
used without further purification. Deionized water was filtered (0.22 µm) in-house by use of a
Milli-Q plus system (Millipore, Billerica, MA). Column chromatography was performed on
Screening Devices silica gel 60 (0.040-0.063 mm). TLC analysis was conducted on HPTLC aluminium
sheets (Merck, silica gel 60, F245). Compounds were visualized by UV absorption (245 nm), by
spraying with 20% H2SO4 in ethanol or with a solution of (NH4)6Mo7O24·4 H2O 25 g/L and
1
13
(NH4)4Ce(SO4)4·2 H2O 10 g/L, in 10% aqueous H2SO4 followed by heating. H, and C NMR spectra
were recorded on a Bruker Avance III HD equipped with a cryogenically cooled 5 mm dual probe
1
optimized for H and 13C (600 MHz and 150 MHz respectively). NMR spectra were recorded in
CDCl3 or DMSO-d6 with chemical shift (δ) relative to tetramethylsilane. All intermediates were
more than 95% pure as determined by HPLC, and identity established by MALDI-TOF (on a Bruker
SolariX XR in MALDI mode or on a Bruker MicroTOF-Q II equipped with an electrospray ionization
interface operated in positive ionization mode. For peptides preparative reversed-phase high
pressure liquid chromatography (RP-HPLC) was performed by using a Phenomenex Luna C18(2)
column (250 × 21.2 mm, particle size: 5 µm) on a Shimadzu system consisting of a CBM-20A
Prominence communication bus module, two LC-20AP Prominence pumps, an SPD-M20A
Prominence diode array detector, and an SIL-20A HT Prominence autosampler. Elution was
performed by using an aqueous MeCN gradient with 0.1% TFA (eluent A: 5:95 MeCN–H2O + 0.1%
TFA, eluent B: 95:5 MeCN–H2O + 0.1% TFA). Analytical UHPLC was performed on a Shimadzu
Prominence UHPLC system using a Phenomenex Luna C18(2) HTS column (100 × 3.0 mm; particle
size: 2.5 μm) eluted at a rate of 0.5 mL/min (using either 0 → 40B% or 0 → 60B% gradient) by
using same eluents as for preparative RP-HPLC. High-resolution mass spectra were obtained on an
17

ACCEPTED MANUSCRIPT
Agilent (Santa Clara, CA, USA) 1260 series chromatographic HPLC system consisting of a G1311B
quaternary pump with built-in degasser, a G1316A thermostated column compartment, a G1315D
photodiode-array detector and a G1329B autosampler. Chromatographic separation of was
performed on a Phenomenex Luna C18(2) column (150 mm × 4.6 mm; particle size: 3 µm, pore
size: 100 Å) at 40 °C using an elution system consisting of H2O–MeCN (95:5) (eluent A) and MeCN–
H2O (95:5) (eluent B), both acidified with formic acid 0.1%, in a flow rate of 0.8 mL/min with linear
gradient from 0% → 100% B over 15 min. HRMS spectra were acquired using a Bruker micrOTOF-Q
II mass spectrometer equipped with an electrospray ionization (ESI) interface (Bruker Daltonik,
Bremen, Germany). Mass spectra were acquired in positive ionization mode, at 200 °C drying
temperature, capillary voltage of 4100 V, nebulizer pressure of 2.0 bar, and drying gas flow of 7
L/min. A solution of sodium formate clusters was automatically injected at the beginning of each
run to enable internal mass calibration. By means of a syringe pump (KD Scientific), selected
peptides were continually infused into the mass spectrometer at 3 µL/min with the settings
described above. Prior to the analyses, the spectrometer was calibrated using a solution of sodium
formate clusters.
3.2. Cytosine PNA monomer (3)
To a solution of Boc-protected cytosine acetic acid 2 (8.08 g, 30.0 mmol) in DMF (100 mL) were
added TSTU (9.48 g, 31.5 mmol) and DIPEA (6.80 mL, 5.04 g, 39.0 mmol). The resulting mixture
was stirred for 2 h, and then finely ground PNA backbone 1 (11.24 g, 33.0 mmol) was added in
o
portions. Alternately, the suspension was stirred, heated to 45 C, and sonicated until a clear
solution was obtained. Additional DIPEA (6.80 mL, 5.04 g, 39.0 mmol) was added, and then the
mixture was stirred for 3 h, after which it was cooled to 0 oC. Then 1M KHSO4 (100 mL) was slowly
added, followed by more water to a total volume of 500 ml, at which point the product
precipitated. The resulting suspension was filtered, and the solid washed with water (50 mL). The
dried crude product was purified by flash column chromatography (MeOH:acetone:CHCl3, 0:1:1 →
0:1:0 → 1:1:0) to afford a slightly yellow solid, which was further purified by dissolution in
chloroform ( 100 mL) followed by precipitation upon addition of petrol ether ( 500 mL) and
o
o
cooling to 0 C. Monomer 3 (16.5 g, 93%) was obtained as an off-white solid. M.p. >165 C
1
(decomposition). H NMR (600 MHz, DMSO-d6): δ ppm 1.45 (s, 9H, 3 × CH3 in Boc), 3.10–3.45 (m,
4H, 2 × CH2, appears under H2O peak, signals assigned by COSY), 3.93–4.05 (m, 2H, CH2), 4.18–4.35
(m, 3H, CHCH2 in Fmoc), 4.60 (s, 1H, CHH), 4.79 (s, 1H, CHH), 6.90–7.00 (m, 1H, H-5), 7.26–7.92 (m,
10H, H-6, NH Fmoc, 8 × Ar-H), 10.22–10.32 (m, 1H, NH Boc); 13C NMR (150 MHz, DMSO-d6,): δ ppm
18

ACCEPTED MANUSCRIPT
27.8, 38.0, 38.7, 46.7, 47.0, 47.3, 49.4, 49.5, 65.5*, 80.9*, 93.9, 120.1*, 120.1*, 125.1, 125.2,
127.1*, 127.6*, 140.7*, 143.9*, 150.5, 152.1, 155.1, 156.1, 156.3, 163.3, 167.0, 167.6; * two close
peaks; several rotamers were present. HRMS: calcd for [M+H]+ 592.2407, found 592.2401; ΔM =
1.0 ppm.
3.3. Boc-protected adenine acetic acid ethyl ester (5)
To a suspension of adenine-AcOEt (4; 50.0 g, 226 mmol, co-evaporated with 2 × 100 mL of dry
DMF) in DMF (450 mL, dried over 3Å MS) was added 1,1'-carbonyldiimidazole (CDI, 73.3 g, 452
o
mmol). The mixture was heated to 105 C and stirred for 1 h, and then additional CDI (27.5 g, 170
mmol) was added. After 1 h, the mixture was cooled to 90 oC and tert-BuOH (64.8 mL, 50.3 g, 678
mmol) was added, after which the mixture was stirred at rt overnight. Most of the solvent was
removed in vacuo leaving a residue ( 300 g) to which EtOAc (500 mL) was added. The resulting
organic solution was washed with water (500 mL). The aqueous layer was extracted back with
EtOAc (2 × 500 mL), and the combined organic layers were washed with brine (500 mL). The brine
layer was extracted back with EtOAc (250 mL). All EtOAc phases were combined and dried
(Na2SO4) and concentrated in vacuo. The residue ( 300 g) was diluted with petrol ether (500 mL),
and then the mixture was cooled to 0 oC and stirred for 1 h during which a precipitate formed. The
white solid was filtered and washed further with petrol ether. The mother liquor was evaporated
and treated similarly with EtOAc and petrol ether to yield a second crop of solid. Drying overnight
under vacuum of the combined portions afforded 5 (33.0 g, 103 mmol, 45%) as an amorphous
white solid. 1H NMR (600 MHz, CDCl3): δ ppm 1.21 (t, 3H, J = 7.1 Hz, CH2CH3), 1.48 (s, 9H, 3 × CH3 in
Boc), 4.18 (q, 2H, J = 7.1 Hz, CH2CH3), 5.18 (s, 2H, CH2), 8.40, 8.58 (each s, 1H, H-2/H-8), 10.09 (s,
1H, NHBoc); 13C NMR (150 MHz, CDCl3): δ ppm 14.0, 27.8, 44.2, 61.5, 80.1, 123.0, 144.4, 149.9,
151.1, 151.6, 152.0, 167.7; HRMS: calcd for [M+H]+ 322.15153, found 322.15221; ΔM = 2.1 ppm.
3.4. Boc-protected adenine acetic acid (6)
To ethyl ester 5 (30.85 g, 96.0 mmol) in a mixture of 1,4-dioxane (432 mL) and water (48 mL) was
added LiOH (4.60 g, 192 mmol). After stirring for 48 h, the mixture was diluted with CH2Cl2 (1200
mL) and freshly solvent-rinsed Dowex H+ was added until pH 5-6. Then Na2SO4 was added, and the
mixture filtered on a glassfilter with a bed ( 5 cm) of Na2SO4. The filtrate was evaporated to give 6
1
(25.1 g, 85.6 mmol, 89%) as an amorphous white solid. H NMR (600 MHz, CDCl3): δ ppm 1.48 (s,
9H, 3 × CH3 in Boc), 5.07 (s, 2H, CH2), 8.40, 8.57 (each s, 1H, H-2/H-8), 10.09 (s, 1H, NHBoc); 13C
19

ACCEPTED MANUSCRIPT
NMR (150 MHz, CDCl3): δ ppm 27.9, 44.2, 80.1, 123.0, 144.5, 149.8, 151.2, 151.5, 152.1, 169.1;
HRMS: calcd for [M+H]+ 294.12023, found 294.12060; ΔM = 1.2 ppm.
3.5. Adenine PNA monomer (7)
To a solution of Boc-Adenine-AcOH 6 (9.27 g, 31.6 mmol) in DMF (105 ml) were added TSTU (9.99
g, 33.2 mmol) and DIPEA (7.16 mL, 5.31 g, 41.1 mmol). The resulting mixture was stirred for 2 h,
and then finely ground PNA backbone 1 (11.84 g, 34.8 mmol) was added in portions. Alternately,
the mixture was stirred, heated to 45 oC, and sonicated until it a clear solution was obtained. More
DIPEA (7.16 mL, 5.31 g, 41.1 mmol) was added, and the mixture stirred for 2 h. The resulting
reaction mixture was cooled to 0 oC, 1M KHSO4 (105 mL) was slowly added, after which water was
added (to give a total volume of 500 mL) to precipitate the product. The solid was filtered and
washed with water (50 mL). After drying, the crude product was purified by flash column
chromatography (MeOH:acetone:CHCl3, 0:1:1 → 0:1:0 → 1:1:0), giving a slightly yellow solid which
was purified further by dissolution in chloroform ( 100 mL) followed by precipitation upon
o
addition of petrol ether ( 500 mL) and cooling to 0 C. The monomer 7 (12.8 g, 20.8 mmol, 66%)
was obtained as an off-white solid. M.p. >153 oC (decomposition). 1H NMR (600 MHz, DMSO-d6): δ
ppm 1.48 (s, 9H, 3 × CH3 in Boc), 3.11–3.17 (m, 1H, CHH), 3.30–3.39 (m, 2H, 2 × CHH), 3.52–3.57
(m, 1H, CHH), 3.95–4.11 (m, 2H, CH2), 4.17–4.37 (m, 3H, CHCH2 in Fmoc), 5.13–5.31 (m, 2H, CH2),
7.28–7.33 (m, 2H, Ar-H), 7.37–7.42 (m, 2H, Ar-H), 7.48–7.56 (m, 1H, NHFmoc), 7.64–7.69 (m, 2H,
Ar-H), 7.85–7.89 (m, 2H, Ar-H), 8.24–8.52 (m, 2H, H-2, H-8), 10.02–10.04 (m, 1H, NHBoc); 13C NMR
(150 MHz, DMSO-d6): δ ppm 27.9, 37.9, 38.7, 43.8, 44.0, 46.7*, 46.9, 47.4, 48.1, 51.0, 65.5*, 79.2,
79.9, 80.0*, 120.1*, 122.9*, 125.1, 125.2, 127.0, 127.1, 127.6*, 140.7*, 143.8, 143.9, 144.9, 145.0,
149.6, 149.7, 151.1, 151.3, 151.4, 152.2, 152.3, 156.1, 156.4, 166.4, 167.1, 170.6, 171.1; * two
close peaks; several rotamers were present. HRMS: calcd for [M+H]+ 616.2419, found 616.2514;
ΔM = 0.8 ppm.
3.6. 2-N-Boc-6-Cl-purine acetic acid ethyl ester (9)
Ethyl bromoacetate (3.88 mL, 5.85 g, 35.0 mmol) was added dropwise (over 30 min) to a mixture
of 2-N-Boc-6-Cl-purine 8 (9.45 g, 35.0 mmol) and K2CO3 (9.69 g, 70.1 mmol) in dry DMF (470 mL).
After stirring for 16 h, the mixture was filtered over celite and the filtrate concentrated in vacuo.
The residue was dissolved in EtOAc (100 mL) and washed with a 1:1-mixture of water and brine
(100 mL) and then with brine (100 mL). The combined aqeous layers were extracted with EtOAc
(50 mL), and the resulting organic layer was washed with brine (50 mL). The combined organic
20

ACCEPTED MANUSCRIPT
layers were dried (Na2SO4), filtered and concentrated in vacuo. The residue was purified by flash
column chromatography (petrol ether–EtOAc, 1:1 → 1:2) to give 9 (10.9 g, 30.6 mmol, 87%) as an
off-white amorphous solid. 1H NMR (600 MHz, CDCl3): δ ppm 1.22 (t, 3H, J = 7.1 Hz, CH2CH3), 1.46
(s, 9H, 3 × CH3 in Boc), 4.19 (q, 2H, J = 7.1 Hz, CH2CH3), 5.11 (s, 2H, CH2), 8.45 (s, 1H, H-8), 10.30 (s,
1H, NHBoc); 13C NMR (150 MHz): δ ppm 14.0, 27.9, 44.4, 61.7, 79.8, 126.4, 146.5, 149.1, 150.9,
152.7, 153.1, 167.4; HRMS: calcd for [M+H]+ 356.11256, found 356.11356; ΔM = 2.8 ppm.
3.7. Boc-protected guanine acetic acid (10)
o
To a cooled (–78 C) suspension of sodium hydride (7.69 g, 192 mmol, 60% dispersion in mineral
oil) in THF (225 mL) was added 2-cyanoethanol (13.1 g, 13.7 g, 192 mmol). The mixture was
o
allowed to warm to 0 C, after which a solution of 9 (11.4 g, 32.0 mmol) in THF (100 mL) was
added dropwise during 5 min. Then the mixture was allowed to warm up to rt, and then stirring
was continued for 48 h. The solvent was removed under reduced pressure after which water (130
mL) was added, and then the mixture was extracted with hexane (150 mL) and EtOAc (150 mL).
o
Next, the aqeous layer was cooled to 0 C and carefully acidified to pH 2-3 with hydrochloric acid
(37% aq.) Then EtOAc (120 mL) was added, and the mixture was stirred vigorously until the
product precipitated. The crude product was filtered and washed on the filter with water, EtOAc
and petrol ether. The solid was recrystallized from EtOAc–petrol ether (1:1, 200 mL), giving 10
1
(6.65 g, 21.5 mmol, 67%) as a pale amber solid. H NMR (600 MHz; CDCl3): δ ppm 1.48 (s, 9H, 3 ×
CH3 in Boc), 4.85 (s, 2H, CH2), 7.91 (s, 1H, H-8), 11.11, 11.39 (each s, 1H, NH guanine/NHBoc),
13.20– 3.42 (s, 1H, COOH); 13C NMR (150 MHz, CDCl3): δ ppm 27.8, 44.2, 82.5, 119.1, 147.7, 149.4,
153.8, 155.1, 169.0; HRMS: calcd for [M+H]+ 310.11514, found 310.11557; ΔM = 1.3 ppm.
3.8. Guanine PNA monomer (11)
To a solution of Boc-Guanine-AcOH (10; 1.86 g, 6.00 mmol) in DMF (20 mL), TSTU (1.99 g, 6.60
mmol) and DIPEA (1.36 mL, 1.01 g, 7.80 mmol) were added. The resulting mixture was stirred for
1.5 h, and then finely ground PNA backbone 1 (2.25 g, 6.60 mmol) was added in portions.
o
Alternately, the mixture was stirred, heated to 45 C, and sonicated until a clear solution was
obtained. More DIPEA (1.36 ml, 1.01 g, 7.80 mmol) was added, and then the mixture was stirred
o
for 2 h. Then the mixture was cooled to 0 C, 1M KHSO4 (20 mL) was slowly added, after which
additional water was added (to a total volume of 100 mL), at which point the product
precipitated. The solid was filtered and washed with water (50 mL). After drying, the crude
product was purified by flash column chromatography (MeOH:acetone:CHCl3, 0:1:1 → 0:1:0 →
21

ACCEPTED MANUSCRIPT
1:1:0), giving a pale amber solid, which was further purified by dissolution in chloroform ( 20 mL)
o
followed by precipitation upon addition of petrol ether ( 80 mL) and cooling to 0 C. The G PNA
o
monomer 11 (3.10 g, 4.91 mmol, 82%) was obtained as an off-white solid. M.p. >175 C
1
(decomposition). H NMR (600 MHz, DMSO-d6): δ ppm 1.44–1.46 (m, 9H, 3 × CH3 in Boc), 3.13–
3.49 (m, 4H, 2 × CH2, appears under H2O peak, signals assigned by 2D NMR), 3.87–3.91 (m, 2H,
CH2), 4.19–4.35 (m, 3H, CHCH2 in Fmoc), 4.89, 5.04 (each s, 1H, CH2), 7.27–7.31 (m, 2H, 2 × Ar-H),
7.37–7.41 (m, 2H, 2 × Ar-H), 7.57–7.88 (m, 6H, H-8, NHFmoc, 4 × Ar-H), 10.98–11.42 (m, 2H, NH
guanine, NHBoc); 13C NMR (150 MHz, DMSO-d6): δ ppm 27.7, 38.0, 38.9, 43.9, 46.6, 46.7, 47.8,
52.4, 65.5, 82.3, 82.4, 118.8, 120.0, 120.1, 125.0, 125.3, 127.0, 127.1, 127.5, 127.6, 140.4, 140.6,
140.7, 143.8, 143.9, 147.5, 149.5, 149.7, 153.7, 153.9, 155.1, 156.0, 156.3, 166.1, 167.1, 170.6;
several rotamers were present. HRMS: calcd for [M+H]+ 632.2469, found 632.2468; ΔM = 0.1 ppm.
3.9. Peptide synthesis.
All peptides listed in Table 1 (characterization data are listed in Table S1) were synthesized on a
CEM LibertyTM MW peptide synthesizer by using MW-assisted Fmoc-based SPPS on an H-Rink-
Amide ChemMatrix® resin (loading 0.52 mmol/g, 0.1 mmol; 100-200 mesh) or on an Fmoc-Rink-
Amide AM resin (loading 0.7 mmol/g, 0.1 mmol; 100-200 mesh). Chain elongation was performed
by using 0.2 M Nα-Fmoc-protected amino acid building blocks (5 equiv; with acid-labile
tBu/Trt/Boc/Pbf as side chain protecting groups) in DMF in combination with 0.5 M HBTU (5.0
equiv) as coupling reagent and 2 M DIPEA in NMP as activator base. Fmoc deprotection was
performed with 20% piperidine in DMF at 75 °C (37 W for 30 sec followed by 40 W for 180 sec),
while amino acid couplings were conducted at 75 °C (25 W for 300 sec). Couplings involving Arg or
hindered amino acid building blocks (Val, Pro, Ile, Thr) as well as the subsequent elongations were
performed as double couplings (each perfomed as above). After assembly of the delivery peptide
sequence, the final tagging with a cysteine residue was carried out by manual coupling (for 2 h) of
Boc-Cys(Trt)-OH (5 equiv) to the deprotected N-terminus in the presence of HBTU (5 equiv), 1-
hydroxybenzotriazole (HOBt) (5 equiv) and DIPEA (10 equiv). All peptides were cleaved by using
TFA–TIS–H2O (95:2.5:2.5; 4 mL) for 2 × 1 h, eluting the resin with additional CH2Cl2. The combined
eluates were kept at room temp for at least 8 h, and then co-evaporated with toluene under
vacuum. The residue was then triturated twice with Et2O giving crude peptides with C-terminal
amides. Peptides were purified by preparative RP-HPLC, and purity (>95%; typically with 2-3%
dimer present in Cys-containing peptides) was confirmed by analytical RP-HPLC (see Table S1 in
supporting information), while the molecular masses of the peptides were confirmed by HRMS.
22

ACCEPTED MANUSCRIPT
3.10. PNA synthesis and solution-phase conjugation of PNA and peptides.
The PNAs for solution-phase conjugation were synthesized on a CEM LibertyTM MW peptide
synthesizer by using MW-assisted Fmoc/Boc-based SPS (0.1 mmol scale) on an H-Rink-Amide
ChemMatrix® resin (loading 0.52 mmol/g). Chain elongation was performed by using 0.2 M Fmoc-
protected monomer building blocks (with Boc-protected nucleobases; 5 equiv) in DMF in
combination with 0.5 M HBTU (5 equiv) as coupling reagent and 2 M DIPEA in NMP as activator
base. Fmoc deprotection was performed with 20% piperidine in DMF at 45 °C (15 W for 60 sec
followed by 15 W for 300 sec), while monomer building block couplings were conducted at 45 °C
(15 W for 600 sec).
PNA-peptide conjugates via an SMCC NHS ester were obtained as previously described [7,57].
Conjugates with the polar Mal-eg1 linker were obtained as follows (adapted method from
[58,59]): PNA oligomer (1.0 equiv) and the Mal-eg1 NHS ester (0.95 eq) were dissolved in 1.5 mL
phosphate buffer (pH 7.4) and left stirring for two hours. The reaction mixture was checked by
UHPLC to confirm conversion of the starting PNA into the adduct. The linker-modified PNA was
transferred to a vial containing the Cys-modified peptide, and then the mixture was stirred for 16
h. The resulting conjugate was purified by preparative HPLC, and identity was verified by MALDI-
TOF and HRMS.
3.11. Continuous synthesis.
The PNA-peptides without a linker or with an eg1 spacer were synthesized on a CEM LibertyTM
MW peptide synthesizer by using MW-assisted Fmoc-based SPPS on an H-Rink-Amide
ChemMatrix® resin (loading 0.52 mmol/g, 0.1 mmol). Assembly of the PNA part was performed as
described in section 3.10, followed by chain elongation with 0.2 M Nα-Fmoc-protected amino acid
building blocks (with acid-labile tBu/Trt/Boc/Pbf as side-chain protecting groups; 5 equiv) in DMF
in combination with 0.5 M HBTU (5 equiv) as coupling reagent and 2 M DIPEA in NMP as activator
base. Fmoc deprotection was performed with 20% piperidine in DMF at 45°C (15 W for 60 sec
followed by 15 W for 300 sec), while amino acid couplings were conducted at 45 °C (25 W for 600
sec). Couplings involving Arg or hindered amino acid building blocks (Val, Pro, Ile, Thr) as well as
the subsequent elongations were performed as double couplings.
3.12. MIC determinations
23

ACCEPTED MANUSCRIPT
MICs were evaluated by the modified Hancock lab protocol [76] in non-binding polystyrene
microtitre plates, using bacterial suspensions of 2 × 105 CFU/mL in Mueller-Hinton broth (Difco,
Sparks MD, USA), with Mg2+ and Ca2+ concentrations of 4 mg/L each. The compounds were
dissolved in H2O and diluted in 0.01% acetic acid, 0.2% BSA (final concentration), and aliquots of
11 μL of 10× test compounds were transferred to the appropriate wells with bacterial suspensions.
To prepare the compounds, low-binding sterile tubes and tips (Axygen, Union City CA, USA) were
used. The MICs were read after 20 h incubation of covered plates at 35 °C (± 2 °C) with circular
shaking 220 rpm. MDR strains and clinical isolates used in the MIC assays were obtained from the
National Medicine Institute (NMI), Warzaw, Poland.
4. Acknowledgements
The authors thank technicians Birgitte Simonsen and Jolanta Ludvigsen are acknowledged for
assistance in HPLC and synthesis/purification of the PNA, respectively. Marek Gniadkowski is
acknowledged for bacteria strains selection and characterization. The research was supported by
IMI ENABLE, grant agreement no 115583 (AMH, WJFH, DZ, MT, MU, FB ), Department of Drug
Design and Pharmacology (HF, FB, JN, KTK, GB), Department of Cellular and Molecular Medicine
(PE) and Center for Peptide-Base Antibiotics (PE, HF, FB), Faculty of Health and Medical Sciences,
University of Copenhagen (G.B.). NMR equipment used in this work was purchased via grant #10-
085264 from The Danish Research Council for Independent Research | Nature and Universe.
Appendix A. Supplementary Material.
Supplementary data related to this article can be found at…
References
[1] Centers for Disease Control and Prevention (CDC). Antibiotic resistance threats in the United States,
2013. U. S. Department of Health and Human Services, Atlanta, Georgia, 2013.
[2] World Health Organization (WHO). Antimicrobial Resistance, Global report on surveillance, 2014. WHO,
Geneva, Switzerland, 2014.
[3] Center for Disease Dynamics, Economic & Policy. State of the Worlds Antibiotics, 2015. CDDEP,
Washington D. C., USA, 2015.
[4] K. Bush. Investigational agents for the treatment of Gram-negative bacterial infections: A reality check.
ACS Infect. Dis. 1 (2015) 509-511.
[5] M.S. Butler, M.A.T. Blaskovich, M.A. Cooper. Antibiotics in the clinical pipeline at the end of 2015. J.
Antibiotics 70 (2017) 3-24.
24

ACCEPTED MANUSCRIPT
[6] L. Good, P.E. Nielsen. Antisense inhibition of gene expression in bacteria by PNA targeted to mRNA. Nat.
Biotechnol. 16 (1998) 355-358.
[7] L. Good, S.K. Awasthi, R. Dryselius, O. Larsson, P.E. Nielsen. Bactericidal antisense effects of peptide-PNA
conjugates. Nat. Biotechnol. 19 (2001) 360-364.
[8] N. Nekhotiaeva, A. Elmquist, G.K. Rajarao, M. Hällbrink, Ü.Langel, L. Good. Cell entry and antimicrobial
properties of eukaryotic cell-penetrating peptides. FASEB J. 18 (2004) 394-396.
[9] M. Mondhe, A. Chessher, S. Goh, L. Good, J.E.M Stach. Species-Selective Killing of Bacteria by
Antimicrobial Peptide-PNAs. PLoS One 9 (2014) e89082.
[10] A. Ghosal, A. Vitali, J.E.M. Stach, P.E. Nielsen. Role of SbmA in the Uptake of Peptide Nucleic Acid
(PNA)-Peptide Conjugates in E. coli. ACS Chem. Biol. 8 (2013) 360-367.
[11] A. Nikravesh, R. Dryselius, O. R. Faridani, S. Goh, M. Sadeghizadeh, M. Behmanesh, A. Ganyu, E. J. Klok,
R. Zain, L. Good. Antisense PNA Accumulates in Escherichia coli and Mediates a Long Post-antibiotic Effect.
Molecular Therapy (2007) 1537–1542.
[12] N. Nekhotiaeva, S.K. Awasthi, P.E. Nielsen, L. Good. Inhibition of Staphylococcus aureus Gene
Expression and Growth Using Antisense Peptide Nucleic Acids. Mol. Ther. 10 (2004) 652-659.
[13] A. Ghosal, P.E. Nielsen. Potent antibacterial antisense peptide-peptide nucleic and conjugate against
Pseudomonas aeruginosa. Nucl. Acids Ther. 22 (2012) 323-333.
[14] A. M. Hansen, G.B. Seigan, C.J. Larsen, N. Yavari, P.E. Nielsen, H. Franzyk. Antibacterial peptide nucleic
acid − antimicrobial peptide (PNA-AMP) conjugates: Antisense targeting of fatty acid biosynthesis Antisense
targeting of fatty acid biosynthesis. Bioconjugate Chem. 27 (2016) 863-867.
[15] M. Pränting, A. Negrea, M. Rhen, D.I. Andersson. Mechanism and Fitness Costs of PR-39 Resistance in
Salmonella enterica Serovar Typhimurium LT2. Antimicrob. Agents Chemother. 52 (2008) 2734-2741.
[16] M. Mattiuzzo, A. Bandiera, R. Gennaro, M. Benincasa, S. Pacor, N. Antcheva, M. Scocchi. Role of the
Escherichia coli SbmA in the antimicrobial activity of proline-rich peptides. Mol. Microbiol. 66 (2007)
151−163.
[17] S. Narayanan, J. K. Modak, C.S. Ryan, J. Garcia-Bustos, J.K. Davies, A. Roujeinikova. Mechanism of
Escherichia coli resistance to pyrrhocoricin. Antimicrob. Agents Chemother. 58 (2014) 2754−2762.
[18] F. Guida, M. Benincasa, S. Zahariev, M. Scocchi, F. Berti, R. Gennaro, A. Tossi. Effect of size and N-
terminal residue characteristics on bacterial cell penetration and antibacterial activity of the proline-rich
peptide Bac7. J. Med. Chem. 58 (2015) 1195−1204.
[19] G.D. Ivanova, A. Arzumanov, R. Abes, H. Yin, M.J.A. Wood, B. Lebleu, M.J. Gait. Improved cell-
penetrating peptide–PNA conjugates for splicing redirection in HeLa cells and exon skipping in mdx mouse
muscle. Nucleic Acids Res. 36 (2008) 6418-6428.
[20] B. Lebleu, H.M. Moulton, R. Abes, G.D. Ivanova, S. Abes, D.A. Stein, P.L Iversen, A.A. Arzumanov, M.J.
Gait. Cell penetrating peptide conjugates of steric block oligonucleotides. Adv. Drug. Del. Rev. 60 (2008)
517-529.
25

ACCEPTED MANUSCRIPT
[21] P.E. Nielsen, M. Egholm, R.H. Berg, O. Buchardt. Sequence-selective recognition of DNA by strand
displacement with a thymine-substituted polyamide. Science 254 (1991) 1497-1500.
[22] K.L. Dueholm, M. Egholm, C. Behrens, L. Christensen, H.F. Hansen, T. Vulpius, K.H. Petersen, R.H. Berg,
P.E. Nielsen, O. Buchardt. Synthesis of peptide nucleic acid monomers containing the four natural
nucleobases: thymine, cytosine, adenine, and guanine and their oligomerization. J. Org. Chem. 59 (1994)
5767-5773.
[23] L. Christensen, R. Fitzpatrick, B. Gildea, K.H. Petersen, H.F. Hansen, T. Koch, M. Egholm, O. Buchardt,
P.E. Nielsen, J. Coull, R.H. Berg. Solid-phase synthesis of peptide nucleic acids. J. Pept. Sci. 3 (1995) 175-183.
[24] T. Koch, H.F. Hansen, P. Andersen, T. Larsen, H.G. Batz, K Otteson, H. Ørum. Improvements in
automated PNA synthesis using Boc/Z monomers. J. Pept. Res. 49 (1997) 80-88.
[25] S.A. Thomson, J.A. Josey, R. Cadilla, M.D. Gaul, C.F. Hassman, M.J. Luzzio, A.J. Pipe, K.L. Reed, D.J. Ricca,
R.W. Wiethe, S.A. Noble. Fmoc-mediated synthesis of peptide nucleic acids. Tetrahedron 51 (1995) 6179-
6194.
[26] R. Casale, I.S. Jensen, M. Egholm, Synthesis of PNA oligomers by Fmoc chemistry. In P.E. Nielsen (Ed.)
Peptide Nucleic acids, Protocols and applications, Horizon Scientific Press, Norfolk, UK, 1999, pp 39-50.
[27] S. Pothukanuri, Z. Pianowski, N. Winssinger. Expanding the Scope and Orthogonality of PNA Synthesis,
Eur. J. Org. Chem. (2008) 3141-3148.
[28] T. Sugiyama, A. Kittaka, Y. Takemoto, H. Takayama, R. Kuroda. Synthesis of PNA using a Fmoc/Boc
protecting group strategy. Nucl. Acids Res. Suppl. 2 (2002) 145-146.
[29] F. Wojciechowski, R.H.E. Hudson. A convenient route to N-[2-(Fmoc)aminoethyl]glycine esters and PNA
oligomerization using a Bis-N-Boc nucleobase protecting group strategy. J. Org. Chem. 73 (2008) 3807-3816.
[30] A. Porcheddu, G. Giacomelli, I. Piredda, M. Carta, G. Nieddu. A practical and efficient approach to PNA
monomers compatible with Fmoc-mediated solid-phase synthesis protocols. Eur. J. Org. Chem. (2008)
5786-5797.
[31] E.C. Browne, S.J. Langford, B.M. Abbott. Peptide nucleic acid monomers: A convenient and efficient
synthetic approach to Fmoc/Boc monomers. Aust. J. Chem. 65 (2012) 539-544.
[32] D.W. Will, G. Breipohl, D. Langner, J. Knolle, E. Uhlmann. The Synthesis of Polyamide Nucleic Acids
using a Novel Monomethoxytrityl Protecting-Group Strategy. Tetrahedron 51 (1995) 12069-12082.
[33] M. Planas, E. Bardají, K.J. Jensen, G. Barany. Use of the Dithiasuccinoyl (Dts) Amino Protecting Group
for Solid-Phase Synthesis of Protected Peptide Nucleic Acid (PNA) Oligomers. J. Org. Chem. 64 (1999) 7281-
7289.
[34] R.D. Viirre, R.H.E. Hudson. Optimization of a Solid-Phase Synthesis of a PNA Monomer. Org. Lett. 3
(2001) 3931-3934.
[35] F. Debaene, N. Winssinger. Azidopeptide Nucleic Acid. An Alternative Strategy for Solid-Phase Peptide
Nucleic Acid (PNA) Synthesis. Org. Lett. 5 (2003) 4445-4447.
[36] F. Debaene, L. Mejias, J.L. Harris, N. Winssinger. Synthesis of a PNA-encoded cysteine protease
inhibitor library. Tetrahedron 60 (2004) 8677-8690.
26

ACCEPTED MANUSCRIPT
[37] Z.C Liu, D.-S. Shin, K.-T. Lee, B.-H. Jun, Y.-K. Kim, Y.-S. Lee. Synthesis of photolabile o-
nitroveratryloxycarbonyl (NVOC) protected peptide nucleic acid monomers. Tetrahedron 61 (2005) 7967-
7973.
[38] L. Bialy, J.J. Diaz-Mochon, E. Specker, L. Keinicke, M. Bradley. Dde-protected PNA monomers,
orthogonal to Fmoc, for the synthesis of PNA-peptide conjugates. Tetrahedron 61 (2005) 8295-8305.
[39] H. Lee, J.H. Jeon, J.C. Lim, H. Choi, Y. Yoon, S.K. Kim. Peptide nucleic acid synthesis by novel amide
formation. Org. Lett. 9 (2007) 3291-3293.
[40] D. Chouikhi, M. Ciobanu, C. Zambaldo, V. Duplan, S. Barluenga, N. Winssinger. Expanding the scope of
PNA-encoded synthesis (PES): Mtt-protected PNA fully orthogonal to Fmoc chemistry and a broad array of
robust diversity-generating reactions. Chem. Eur. J. 18 (2012) 12698-12704.
[41] Y.-C. Huang, C. Cao, X.-L.Tan, X. Li, L. Liu. Facile solid-phase synthesis of PNA–peptide conjugates using
pNZ-protected PNA monomers. Org. Chem. Front. 1 (2014) 1050-1054.
[42] J.J. Turner, D. Williams, D. Owen, M.J. Gait. Disulfide conjugation of peptides to oligonucleotides and
their analogs. Curr. Protoc. Nucleic Acid Chem. 2006, Chapter 4, Unit 4.28.1-4.28.21.
[43] C. Avitabile, L. Moggio, L.D. d’Andrea, C. Pedone, A. Romanelli. Development of an efficient and low-
cost protocol for the manual PNA synthesis by Fmoc chemistry. Tetrahedron Lett. 51 (2010) 3716-3718.
[44] C.A. Chantell, G. Fuentes, H. Patel, M. Menakuru. Low-cost, automated synthesis of a PNA-peptide
conjugate on a peptide synthesizer. Am. Biotechnol. Lab. 27 (2009) 8-10.
[45] R. Joshi, D. Jha, W. Su, J. Engelmann. Facile synthesis of peptide nucleic acids and peptide nucleic acid-
peptide conjugates on an automated peptide synthesizer. J. Pept. Sci. 17 (2011) 8-13.
[46] F. Debaene, J.A. Da Silva, Z. Pianowski, F.J. Duran, N. Winssinger. Expanding the scope of PNA-encoded
libraries: divergent synthesis of libraries targeting cysteine, serine and metallo-proteases as well as tyrosine
phosphatases, Tetrahedron 63 (2007) 6577–6586.
[47] M.M. Fabani, C. Abreu-Goodger, D. Williams, P.A. Lyons, A.G. Torres, K.G. Smith, A.J. Enright, M.J. Gait,
E. Vigorito. Efficient inhibition of miR-155 function in vivo by peptide nucleic acids. Nucl. Acids Res. 38
(2010) 4466-4475.
[48] N. Svensen, J.J. Díaz-Mochón, M. Bradley. Microwave-assisted orthogonal synthesis of PNA–peptide
conjugates, Tetrahedron Lett. 49 (2008) 6498-6500.
[49] B.M. Patureau, R.H.E. Hudson, M.J. Damha. Induction of RNAse H activity by arabinose-peptide nucleic
acid chimeras. Bioconjugate Chem. 18 (2007) 421-430.
[50] S. Fletcher, V.M. Shahani, P.T. Gunning. Facile and efficient access to 2,6,9-tri-substituted purines
through sequential N9, N2 Mitsunobu reactions. Tetrahedron Lett. 50 (2009) 4258-4261.
[51] F. García-Martín, M. Quintanar-Audelo,Y. García-Ramos, L.J. Cruz, C. Gravel, R. Furic, S. Côté, J. Tulla-
Puche, F. Albericio. ChemMatrix, a poly(ethylene glycol)-based support for the solid-phase synthesis of
complex peptides. J. Comb. Chem. 8 (2006) 213-220.
[52] F. Rizzolo, G. Sabatino, M. Chelli, P. Rovero, A.M. Papini. A convenient microwave-enhanced solid-
phase synthesis of difficult peptide sequences: case study of Gramicidin A and CSF114(Glc). Int. J. Pept. Res.
Ther. 13 (2007) 203-206.
27

ACCEPTED MANUSCRIPT
[53] L. Malik, A.P. Tofteng, S.L. Pedersen, K.K. Sørensen, K.J. Jensen. Automated 'X-Y' robot for peptide
synthesis with microwave heating: application to difficult peptide sequences and protein domains. J. Pept.
Sci. 16 (2010) 506-512.
[54] A. Thaqi, A. McCluskey, J.L. Scott. A mild Boc deprotection and the importance of a free carboxylate.
Tetrahedron Lett. 49 (2008) 6962-6964.
[55] S.R. Dandepally, A.L. Williams. Microwave-assisted N-Boc deprotection under mild basic conditions
using K3PO4 H2O in MeOH. Tetrahedron Lett. 50 (2009) 1071-1074.
[56] N. Bendifallah, F.W. Rasmussen, V. Zachar, P. Ebbesen, P.E. Nielsen, U. Koppelhus. Evaluation of cell-
penetrating peptides (CPPs) as vehicles for intracellular delivery of antisense peptide nucleic acid (PNA).
Bioconjugate Chem. 17 (2006) 750-758.
[57] S. Abes, J. J. Turner, G. D. Ivanova, D. Owen, D. Williams, A. Arzumanov, P. Clair, M.J. Gait, B. Lebleau.
Efficient splicing correction by PNA conjugation to an R6-penetratin delivery peptide. Nucl. Acids Res. 35
(2007) 4495-4502.
[58] J. G Harrison, C. Frier, R. Laurant, R. Dennis, K. D. Raney, S. Balasubramanian. Inhibition of the human
telomerase by PNA-cationic peptide conjugates. Bioorg. Med. Chem. Lett. 9 (1999) 1273-1278.
[59] N. Nanaware-Kharade, G.A. Gonzalez III, J. O. Lay Jr., H.P. Hendrickson, E.C. Peterson. Therapeutic Anti-
Methamphetamine Antibody Fragment-Nanoparticle Conjugates: Synthesis and in Vitro Characterization.
Bioconjugate Chem. 23 (2012) 1864-1872.
[60] S.K. Taylor, R. Pei, B.C. Moon, S. Damera, A. Shen, M.N. Stojanovic. Triggered Release of an Active
Peptide Conjugate from a DNA Device by an Orally Administrable Small Molecule. Angew. Chem. Int. Ed. 48
(2009) 4394-4397.
[61] M. Hatamoto, K. Nakai, A. Ohashi, H. Imachi. Sequence-specific bacterial growth inhibition by peptide
nucleic acid targeted to the mRNA binding site of 16S rRNA. Appl Microbiol Biotechnol. 84 (2009) 1161-
1168.
[62] M. Równicki, M. Wojciechowska, A. J. Wierzba, J. Czarnecki, D. Bartosik, D. Gryko, J. Trylska. Vitamin
B12 as a carrier of peptide nucleic acid (PNA) into bacterial cells. Sci Rep. 7 (2017) 7644 .
[63] A. J. Wierzba, K. Maximova, A. Wincenciuk, M. Rjwnicki, M. Wojciechowska, E. Nexø, J. Trylska, D.
Gryko. Does a Conjugation Site Affect Transport of Vitamin B12–Peptide Nucleic Acid Conjugates into
Bacterial Cells? Chem. Eur. J. 24 (2018) 18772-18778.
[64] R. Izdebski, A. Baraniak, K. Bojarska, P. Urbanowicz, J. Fiett, M. Pomorska-Wesołowska, W. Hryniewicz,
M. Gniadkowski, D. Żabicka. Mobile MCR-1-associated resistance to colistin in Poland J Antimicrob
Chemother. 8 (2016) 2331-2333.
[65] J. Fiett, A. Baraniak, R. Izdebski, I. Sitkiewicz, D. Żabicka, A. Meler, K. Filczak, W. Hryniewicz, M.
Gniadkowski. The first NDM metallo-β-lactamase-producing Enterobacteriaceae isolate in Poland: evolution
of IncFII-type plasmids carrying the bla(NDM-1) gene. Antimicrob Agents Chemother. 2014;58(2):1203-7.
[66] H. Bai, Y. You, H. Yan, J. Meng, X. Xue, Z. Hou, Y. Zhou, X. Ma, G. Sang, X. Luo. Antisense inhibition of
gene expression and growth in gram-negative bacteria by cell-penetrating peptide conjugates of peptide
nucleic acids targeted to rpoD gene. Biomaterials 33 (2012) 659-667.
28
