A colorimetric and fluorescent probe for fluoride ions based on 6-acetyl-2-naphthol

Article abstract of DOI:10.1002/bio.2564

A colorimetric and turn-on fluorescent probe for fluoride ions, tert-butyldimethylsilane 6-acetyl-2-naphtholate, was readily synthesized from 6-acetyl-2-naphthol and tert-butyldimethylchlorosilane (TBSCl). The probe exhibits high sensitivity and good selectivity for fluoride ions in acetonitrile. The inherent mechanism involves the cleavage of the Si-O bond in the probe, which induced yellow color formation and prominent fluorescence enhancement. Copyright

Full text of DOI:10.1002/bio.2564

Research article
Received: 18 March 2013,
Revised: 5 June 2013,
Accepted: 5 June 2013
Published online in Wiley Online Library
(wileyonlinelibrary.com) DOI 10.1002/bio.2564
A colorimetric and fluorescent probe for
fluoride ions based on 6-acetyl-2-naphthol
Peng Hou,a Song Chena and Xiangzhi Songa,b,c
*
ABSTRACT: A colorimetric and turn-on fluorescent probe for fluoride ions, tert-butyldimethylsilane 6-acetyl-2-naphtholate,
was readily synthesized from 6-acetyl-2-naphthol and tert-butyldimethylchlorosilane (TBSCl). The probe exhibits high sensi-
tivity and good selectivity for fluoride ions in acetonitrile. The inherent mechanism involves the cleavage of the Si–O bond in
the probe, which induced yellow color formation and prominent fluorescence enhancement. Copyright © 2013 John Wiley &
Sons, Ltd.
The following supporting information is available online.
Keywords: colorimetric; fluorescent probe; fluoride ion
Introduction
Experimental
Because of the crucial roles of anions in biological systems and
chemical processes, intensive research has been conducted on
the design of signaling probes for anions (1–5). The fluoride
ion has been widely used as an essential element in toothpaste
and pharmaceutical agents to prevent dental caries and ortho-
dontics (6–8). However, fluoride ions are poisonous to biological
systems when levels exceed normal cellular values, and can
cause fluorosis such as metabolic disorders and immunological
damage in humans (9–13). Thus, it is very important to regulate
the uptake of fluoride ions and the detection of fluoride ions has
attracted considerable attention. Owing to its simplicity and ex-
quisite sensitivity, fluorescent probes are highly attractive for the
selective detection of fluoride ions. A number of fluorescent
probes for fluoride ions have been developed in recent years
(14–22). However, many of the reported probes suffer from com-
plicated synthesis procedures, turn-off fluorescence response,
slow response or low sensitivity. Therefore, there is still a high
demand for probes for fluoride ions with good selectivity and
high sensitivity.
It is well known that tert-butyldimethysilane (TBS) ether is
a useful protective group for the hydroxy group and can be
specifically and efficiently cleaved by fluoride ions. Therefore,
TBS ether has been proven to be an attractive component for
the design of fluoride probes (23–32). 6-Acetyl-2-naphthol,
which has a pull–push electron structure, exhibits outstanding
chemical and photophysical properties such as high fluorescent
quantum yield, good photostability and a large Stokes shift in-
duced by an intramolecular charge transfer process (ICT). There-
fore, derivatives of 6-acetyl-2-naphthol have emerged as very
promising fluorescent probes. Here, we report the design and
synthesis of a TBS ether of 6-acetyl-2-naphthol, 1, as a colorimet-
ric and turn-on fluorescent probe for fluoride ions (shown in
Scheme 1). In probe 1, the ICT process was completely inhibited
due to the protection of phenolate by TBS. However, upon the
addition of fluoride ions, probe 1 can be quickly converted into
6-acetyl-2-naphthol, which leads to a marked color change and
significant fluorescence enhancement.
Materials
Acetonitrile was purchased from J&K Scientific Ltd. (Shanghai,
China) Dry methylene chloride was obtained by distillation after
refluxing with CaH2 for 6 h. Unless otherwise stated, all chemicals
were purchased from commercial suppliers and used as received.
The investigated anions were F-, Cl-, Br-, I-, H2PO-4, HSO4- , NO-3, AcO-
and ClO-4, and tetrabutylammonium (TBA+) was the counter cation.
Synthesis of probe 1
The synthetic route for probe 1 is shown in Scheme 1. Following
to the literature, 6-acetyl-2-naphthol was obtained by refluxing
2-acetyl-6-methoxy-naphthalene with concentration hydrochloric
acid for 2 h (33). To a mixture of 6-acetyl-2-naphthol (0.4mmol,
74.5mg), DMAP (0.16 mmol, 20mg) and triethylamine (2mmol,
202 mg) in 50 mL of dry CH2Cl2 was added tert-butyldimethyl-
chlorosilane (2mmol, 301.4mg). After stirring the reaction mixture
at room temperature for 1 h, 50 mL of water was added. The or-
ganic layer was separated and dried over anhydrous Na2SO4. The
drying agent was removed by filtration and the solvent was re-
moved by distillation. The obtained residue was purified by silica
gel column chromatography (10:1 petroleum:ethyl acetate as
* Correspondence to: X. Song, College of Chemistry & Chemical Engineering,
Central South University, 932 Lushan South Road, Changsha, Hunan Province
410083, People's Republic of China. Email: xzsong@csu.edu.cn
a
College of Chemistry & Chemical Engineering, Central South University, 932
Lushan South Road, Changsha, Hunan Province, P. R. China, 410083
b
Key Laboratory of Resource Chemistry of Nonferrous Metals, Ministry of
Education, 932 Lushan South Road, Changsha, Hunan Province, P. R. China,
410083
c
State Key Laboratory for Powder Metallurgy, 932 Lushan South Road,
Changsha, Hunan Province, P. R. China, 410083
Luminescence 2013
Copyright © 2013 John Wiley & Sons, Ltd.

P. Hou et al.
Scheme 1. Synthesis of probe 1.
Figure 2. UV/vis absorption spectra of probe 1 (100 μM) in CH3CN containing dif-
ferent amounts of TBAF (0, 10, 15, 20, 25, 30, 35, 40, 50, 100, 200, 300 μM).
eluent) to yield the product, 1, as a white solid (102mg, 85%)
(Fig. S1,S2). H NMR (400 MHz, CDCl3): δ ppm = 8.40 (s, 1H), 7.97
1
(t, J = 8.8 Hz, 1H), 7.85 (d, J = 9.2Hz, 1H), 7.72 (d, J = 8.8Hz, 1H),
7.21 (d, J = 2.0Hz, 1H), 7.14 (d, J = 8.8 Hz, 1H), 2.70 (s, 3H), 1.03
(s, 9H), 0.27 (s, 6H). GCMS (m/z): 300.1.
Results and discussion
UV/vis absorption studies with fluoride ion
Prior to the reaction with fluoride ions, probe 1 is colorless in
acetonitrile with an absorption maximum at 304 nm, as shown
in Fig. 1. Upon the addition of 3 eq. of fluoride ions, an apparent
102 nm red-shift (from 304 to 406 nm) instantly appeared. With
increasing addition amounts of fluoride ion, the absorption band
at 304 nm progressively decreased and a new band centered at
406 nm gradually formed with a clear isosbestic point at 329 nm
(Fig. 2). To demonstrate the selectivity of probe 1 as a colorimet-
ric probe, titration experiments were carried out on probe 1 with
other typical anions (Cl-, Br-, I-, H2PO4- , HSO-4, NO3- , AcO- and ClO-4)
by observing the absorption spectral change. As shown in Fig. 3,
only fluoride ions could induce the probe to form a yellow color
with 102 nm a red-shift, whereas other typical anions have no in-
fluence on the absorption spectra. The above results proved that
probe 1 could be used as a highly selective colorimetric probe
for fluoride ion.
Figure 3. Absorption spectra of probe 1 (100 μM) in CH3CN upon addition of var-
ious TBA salts (F-, Cl-, Br-, I-, AcO-, HSO4- , H2PO4- , ClO4- and NO-3; 300 μM each). (Inset)
Color changes of the probe 1 (100 μM) in the presence of 3 eq. of TBA salts (F-, Cl-,
Br-, I-, H2PO-4, HSO4- , NO3- , AcO- and ClO4- ) in CH3CN.
Fluorescence studies with fluoride ion
As shown in Fig. 4, probe 1 in acetonitrile is essentially non-
fluorescent in the absence of fluoride ions. By contrast, a dra-
matic fluorescence enhancement (9663-fold) was observed with
a maximum at 488 nm upon treatment with 10 eq. of fluoride
Figure 1. UV/vis absorption spectra of probe 1 (100 μM) in the absence and pres-
ence of TBAF (300 μM) in CH3CN.
Figure 4. Fluorescence spectra of probe 1 (5 μM) recorded before and after reac-
tion with TBAF (50 μM) in CH3CN.
wileyonlinelibrary.com/journal/luminescence
Copyright © 2013 John Wiley & Sons, Ltd.
Luminescence 2013

A colorimetric and fluorescent probe for fluoride ions
Figure 7. Ratio of emission intensity at 488 nm of probe 1 (5 μM) before (I0) and
after (I) the addition of TBAF (10 μM) and other TBA salts (Cl-, Br-, I-, AcO-, HSO4- ,
H2PO-4, S2-, SCN- and NO-3; 50 μM, each).
Figure 5. Fluorescence spectra of probe 1 (5 μM) in CH3CN with different
amounts of TBAF (0, 2, 3, 4, 5, 6, 8, 10, 20, 30, 40, 50 μM). The excitation wavelength
was set at 406 nm.
Figure 8. Time-resolved fluorescence spectra of probe 1 (5 μM) at 488 nm upon
addition of TBAF (50 μM) in CH3CN.
Figure 6. Fluorescence intensity at 488 nm of probe 1 (5 μM) in CH3CN in the
presence of TBAF. (Inset) Linear portion of the curve at low concentrations of TBAF.
ions. There was a good linear correlation between the fluores-
cence intensity and the concentration of fluoride ion in the
range 0–50 μM (Fig. 5). The linear equation was expressed as
y = -734.4 + 379.8x (R = 0.9915, where y denotes the fluorescence
intensity and x denotes the concentration of fluoride ion). The
detection limit was determined to be 40 nM (Fig. 6).
In order to evaluate the selectivity of the probe for fluoride ions,
we investigated the fluorescence behavior of probe 1 with other
typical anions. The results presented in Fig. 7 show that other typ-
ical anions (Cl-, Br-, I-, H2PO4- , HSO4- , NO3- , AcO-, S2-, SCN- and ClO4- )
have no effect on the fluorescence behavior of probe 1, even at
high concentrations (10 eq. of probe 1). Therefore, it can be con-
cluded that the fluorescent probe 1 displayed excellent selectivity
for fluoride ions over other competing anions.
Time-dependent fluorescence studies of probe 1 with fluoride
ions were also conducted. It can be seen in Fig. 8 that the fluo-
rescence intensity was enhanced with increasing reaction time.
Pronounced fluorescence enhancement was observed within
30 s and leveled off to a constant value after 3 min, which indi-
cated that probe 1 showed rapid detection of fluoride ions.
Scheme 2. TBAF-induced cleavage of the Si–O bond in probe 1.
6-acetyl-2-naphtholate in the presence of fluoride ion (Scheme 2).
In comparison with probe 1, the reaction product, 6-acetyl-2-
naphtholate, has a more electron-donating group and possesses
a push–pull electron structure, which can lead to a red-shift in its
absorption spectrum and a strong fluorescence due to the ICT pro-
cess. Absorption and fluorescence studies of probe 1 with fluoride
ions are consistent with this. In order to further confirm the
reaction mechanism, the resulting mixture of probe 1 with fluoride
ion was subjected to ESI mass spectral analysis. The result in Fig. S3
shows a peak at m/z = 185.3, which clearly indicates the formation
of 6-acetyl-2-naphtholate (calcd. 185.2 for C12H9O2). The absorp-
tion, fluorescence (Fig. S4) and ESI spectral studies strongly
support the proposed mechanism in Scheme 2.
Proposed mechanism for the reaction of the probe with
fluoride ion
It is known that fluoride can effectively cleave the Si–O bond.
In our work, we expected that probe 1 was transferred into
Luminescence 2013
Copyright © 2013 John Wiley & Sons, Ltd.
wileyonlinelibrary.com/journal/luminescence

P. Hou et al.
14. Wade CR, Broomsgrove AEJ, Aldridge S, Gabbaï FP. Fluoride ion
complexation and sensing using organoboron compounds. Chem
Rev 2010;110:3958–84.
Conclusions
In summary, on the basis of a specific reaction with fluoride and
exploiting an ICT mechanism, we have developed a colorimetric
and turn-on fluorescent probe based on 6-acety-2-naphthol
moiety. The probe displayed extremely high sensitivity and
good selectivity for the detection of fluoride ion.
15. Cametti M, Rissanen K. Recognition and sensing of fluoride anion.
Chem Commun 2009;20:2809–29.
16. Wang Q, Xie Y, Ding Y, Li X, Zhu W. Colorimetric fluoride sensors based
on deprotonation of pyrrole–hemiquinone compounds. Chem
Commun 2010;46:3669–71.
17. Rochat S, Severin K. A simple fluorescence assay for the detection of
fluoride in water at neutral pH. Chem Commun 2011;47:4391–3.
18. Mashraqui SH, Ghorpade SS, Tripathi S, Britto S. A new indole incorpo-
rated chemosensor exhibiting selective colorimetric and fluorescence
ratiometric signaling of fluoride. Tetrahedron Lett 2012;53:765–8.
19. Sun H, Dong X, Liu S, Zhao Q, Mou X, Yang HY, Huang W. Excellent
Bodipy dye containing dimesitylboryl groups as PET-based fluores-
cent probe for floride. J Phys Chem C 2011;115:19947–54.
20. Jia C, Wu B, Liang J, Huang X, Yang XJ. A colorimetric and ratiometric
fluorescent chemosensor for fluoride based on proton transfer. J
Fluoresc 2010;20:291–7.
SUPPORTING INFORMATION
The following supporting information is available online.
Acknowledgement
This research was supported by NSF of China (No. 21072235)
and NCET(10-0793).
21. Qu Y, Hua J, Tian H. Colorimetric and ratiometric red fluorescent
chemosensor for fluoride ion based on diketopyrrolopyrrole. Org
Lett 2010;12:3320–3.
22. Li S, Zhang C, Huang S, Hu F, Yin J, Liu SH. Highly selective colorimetric
and fluorescent sensors for the fluoide anion based on imidazo[4,5-f]-
1,10-phenanthroline metal-complexes. RSC Adv 2012;2:4215–19.
23. Kim TH, Swager TM. A fluorescent self-amplofying wavelength-
responsive sensory polymer for fluoride ions. Angew Chem Int Ed
2003;42:4803–6.
24. Hu R, Feng J, Hu D, Wang S, Li S, Li Y et al. A rapid aqueous fluoride ion
sensor with dual output modes. Angew Chem Int Ed 2010;49:4915–18.
25. Zhu B, Yuan F, Li R, Li Y, Wei Q, Ma Z et al. A highly selective color-
imetric and ratiometric fluorescent chemodosimeter for imaging
fluoride ions in living cells. Chem Commun 2011;47:7098–100.
26. Bao Y, Liu B, Wang H, Tian J, Bai R. A ‘naked eye’ and ratiometric
fluorscent chemosensor for rapid detection of F- based on combina-
tion of desilylation reaction and excited-state proton transfer. Chem
Commun 2011;47:3957–9.
27. Dong M, Peng Y, Dong YM, Tang N, Wang YW. A selective, colorimet-
ric, and fluorscent chemodosimeter for relay recognition of fluoride
and cyanide anions based on 1,1ʹ-binaphthyl scaffold. Org Lett
2012;14:130–3.
28. Ren J, Wu Z, Zhou Y, Li Y, Xu Z. Colorimetric fluoride sensor based on
1,8-naphthalimide derivatives. Dyes Pigment 2011;91:442–5.
29. Cao X, Lin W, Yu Q, Wang J. Ratiometric sensing of fluoride anions
based on a Bodipy-coumarin platform. Org Lett 2011;13:6098–101.
30. Cao J, Zhao C, Feng P, Zhang Y, Zhu W. Acolorimetric and ratiometric
NIR fluorescent turn-on fluoride chemodosimeter based on Bodipy
derivatives: high selectivity via specific Si–O cleavage. RSC Adv
2012;2:418–20.
31. Cao J, Zhao C, Zhu W. A near-infrared fluorescence chemodosimeter for
fluoride via specific Si–O cleavage. Tetrahedron Lett 2012;53:2107–10.
32. Bozdemir OA, Sozemen F, Buyukcakir O, Guliyev R, Cakmak Y,
Akkaya EU. Reaction-based sensing of fluoride ions using built-in
triggers for intramolecular charge transfer and photoinduced elec-
tron transfer. Org Lett 2010;12:1400–3.
References
1. Duke RM, Veale EB, Pfeffer FM, Kruger PE, Gunnlaugsson T. Colori-
metric and fluorescent anion sensors: an overveiw of rescent devel-
opments in the use of 1,8-naphthalimide-based chemosensors.
Chem Soc Rev 2010;39:3936–53.
2. Xu Z, Kim SK, Yoon J. Revisit to imidazolium receptors for the recog-
nition of anions: highlighted research during 2006–2009. Chem Soc
Rev 2010;39:1457–66.
3. Li AF, Wang JH, Wang F, Jiang YB. Anion complexation and sensing
using modified urea and thiourea-based receptors. Chem Soc Rev
2010;39:3729–45.
4. Amendola V, Fabbrizzi L. Anion receptors that contain metals as
structural units. Chem Commun 2009;5:513–31.
5. Chen S, Hou P, Wang J, Song X. A highly sulfite-selective ratiometric
fluorescent probe based on ESIPT. RSC Adv 2012;2:10869–73.
6. Clarkson JJ, McLoughlin J. Role of fluoride in oral health promotion.
Int Dent J 2000;50:119–28.
7. Horowitz HS. The 2001 CDC recommendation for using fluoride to
prevent and control dental caries in the United States. J Public
Health Dent 2003;63:3–8.
8. Todd MA, Staley RN, Kanellis MJ, Donly KJ, Wefel JS. Effect of a fluo-
ride varnish on demineralization adjacent to orthodontic brackets.
Am J Orthod Dentofac 1999;116:159–67.
9. Singh PP, Barjatiya MK, Dhing S, Bhatnagar R, Kothari S, Dhar V. Evi-
dence suggesting that high intake of fluoride provokes nephrolithiasis
in tribal populations. Urol Res 2001;29:238–44.
10. Matsui H, Morimoto M, Horimoto K, Nishimura Y. Some characteristics
of fluoride-induced cell death in rat thymocytes: cytotoxicity of sodium
fluoride. Toxicol in Vitro 2007;21:1113–20.
11. Barbier O, Arreola-Mendoza L, Del Razo LM. Molecular mechanisms
of fluoride toxicity. Chem Biol Interact 2010;188:319–33.
12. Anuradha CD, Kanno S, Hirano S. Fluoride induces apoptosis by
caspase-3 activation in human leukemia HL-60 cells. Arch Toxicol
2000;74:226–30.
33. Chang KW, Chen CC, Lee SY, Wang HE. Acute toxicity of two
Alzheimer's disease radiopharmaceuticals: FDDNP and IMPY. Drug
Chem Toxicol 2009;32:429–37.
13. Camargo JA, Fluoride toxicity to aquatic organisms: a review.
Chemosphere 2003;50:251–64.
wileyonlinelibrary.com/journal/luminescence
Copyright © 2013 John Wiley & Sons, Ltd.
Luminescence 2013
