Engineering the enantioselectivity of yeast old yellow enzyme Oye2Y in asymmetric reduction of (E/Z)-citral to (R)-citronellal

Article abstract of DOI:10.3390/molecules24061057

The members of the Old Yellow Enzyme (OYE) family are capable of catalyzing the asymmetric reduction of (E/Z)-citral to (R)-citronellal—a key intermediate in the synthesis of L-menthol. The applications of OYE-mediated biotransformation are usually hampered by its insufficient enantioselectivity and low activity. Here, the (R)-enantioselectivity of Old Yellow Enzyme from Saccharomyces cerevisiae CICC1060 (OYE2y) was enhanced through protein engineering. The single mutations of OYE2y revealed that the sites R330 and P76 could act as the enantioselectivity switch of OYE2y. Site-saturation mutagenesis was conducted to generate all possible replacements for the sites R330 and P76, yielding 17 and five variants with improved (R)-enantioselectivity in the (E/Z)-citral reduction, respectively. Among them, the variants R330H and P76C partly reversed the neral derived enantioselectivity from 32.66% e.e. (S) to 71.92% e.e. (R) and 37.50% e.e. (R), respectively. The docking analysis of OYE2y and its variants revealed that the substitutions R330H and P76C enabled neral to bind with a flipped orientation in the active site and thus reverse the enantioselectivity. Remarkably, the double substitutions of R330H/P76M, P76G/R330H, or P76S/R330H further improved (R)-enantioselectivity to >99% e.e. in the reduction of (E)-citral or (E/Z)-citral. The results demonstrated that it was feasible to alter the enantioselectivity of OYEs through engineering key residue distant from active sites, e.g., R330 in OYE2y.

Full text of DOI:10.3390/molecules24061057

molecules
Article
Engineering the Enantioselectivity of Yeast Old
Yellow Enzyme OYE2y in Asymmetric Reduction of
(E/Z)-Citral to (R)-Citronellal
1
,
1
1
1
1
1
Xiangxian Ying * , Shihua Yu , Meijuan Huang , Ran Wei , Shumin Meng , Feng Cheng ,
2
3
1
and Zhao Wang 1
Meilan Yu , Meirong Ying , Man Zhao
1
Key Laboratory of Bioorganic Synthesis of Zhejiang Province, College of Biotechnology and Bioengineering,
Zhejiang University of Technology, Hangzhou 310014, China; yushihuafx@163.com (S.Y.);
meyroline.huang@gmail.com (M.H.); weiranzjut@163.com (R.W.); mengshuminzjut@163.com (S.M.);
fengcheng@zjut.edu.cn (F.C.); mzhao@zjut.edu.cn (M.Z.); hzwangzhao@163.com (Z.W.)
College of Life Sciences, Zhejiang Sci-Tech Univeristy, Hangzhou 310018, China; meilanyu@zstu.edu.cn
Grain and Oil Products Quality Inspection Center of Zhejiang Province, Hangzhou 310012, China;
hz85672100@163.com
2
3
*
Correspondence: yingxx@zjut.edu.cn; Tel.: +86-571-88-320-781
ꢀ
ꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Stefano Serra
Received: 3 March 2019; Accepted: 14 March 2019; Published: 18 March 2019
ꢀ
ꢁꢂꢃꢄꢅꢆ
Abstract: The members of the Old Yellow Enzyme (OYE) family are capable of catalyzing the
asymmetric reduction of (E/Z)-citral to (R)-citronellal—a key intermediate in the synthesis of
L-menthol. The applications of OYE-mediated biotransformation are usually hampered by its
insufficient enantioselectivity and low activity. Here, the (R)-enantioselectivity of Old Yellow
Enzyme from Saccharomyces cerevisiae CICC1060 (OYE2y) was enhanced through protein engineering.
The single mutations of OYE2y revealed that the sites R330 and P76 could act as the enantioselectivity
switch of OYE2y. Site-saturation mutagenesis was conducted to generate all possible replacements
for the sites R330 and P76, yielding 17 and five variants with improved (R)-enantioselectivity in the
(
E/Z)-citral reduction, respectively. Among them, the variants R330H and P76C partly reversed
the neral derived enantioselectivity from 32.66% e.e. (S) to 71.92% e.e. (R) and 37.50% e.e. (R),
respectively. The docking analysis of OYE2y and its variants revealed that the substitutions R330H
and P76C enabled neral to bind with a flipped orientation in the active site and thus reverse
the enantioselectivity. Remarkably, the double substitutions of R330H/P76M, P76G/R330H, or
P76S/R330H further improved (R)-enantioselectivity to >99% e.e. in the reduction of (E)-citral or
(
E/Z)-citral. The results demonstrated that it was feasible to alter the enantioselectivity of OYEs
through engineering key residue distant from active sites, e.g., R330 in OYE2y.
Keywords: asymmetric reduction; citral; citronellal; enantioselectivity; Old Yellow Enzyme;
site-saturation mutagenesis; substrate binding mode
1
. Introduction
(
R)-citronellal is a valuable intermediate for the synthesis of L-menthol through an acidic
ene-cyclization and subsequent hydrogenation [ ]. The potential of (R)-citronellal was also
explored for the synthesis of natural vitamin E—a kind of fat-soluble vitamin with relatively
high antioxidant ability [ ]. The commercial Takasago process of (R)-citronellal began with
myrcene to form an allylic amine, which underwent asymmetric isomerization in the presence of a
1–3
4,5
0
0
2
,2 -bis(diphenylphosphino)-1,1 -binaphthyl(BINAP)-Rh complex and subsequent hydrolysis with acid
to give enantiomerically pure (R)-citronellal [ ]. In contrast to the three-step asymmetric synthesis from
myrcene, the one-step enantioselective reduction of natural citral (the crude mixture of 60% geranial
6
Molecules 2019, 24, 1057; doi:10.3390/molecules24061057
www.mdpi.com/journal/molecules

Molecules 2019, 24, 1057
2 of 15
and 40% neral) was a simplified process for the synthesis of (R)-citronellal [
7
]. The enantioselective
hydrogenation of (E/Z)-citral to afford an identical enantiomer remained challenging since the
reduction of the geometric isomers geranial and neral by the same catalyst usually yielded the
enantiocomplementary products. In organocatalysis, the enantioselective hydrogenation of (E/Z)-citral
to yield (R)-citronellal required the use of a dual catalyst system comprising of Pd/BaSO4 and chiral
2
-diarylmethylpyrrolidine [8]. However, the obtained (R)-citronellal with 89% e.e. was insufficient for
broad industrial applications.
To develop a greener and cost-effective alternative to organocatalysis, Old Yellow Enzymes (OYEs;
EC 1.6.99.1) as biocatalysts have been widely investigated, which are capable of catalyzing the C=C
bond reduction of α,β-unsaturated compounds such as (E/Z)-citral [9–13]. Past efforts have been made
on the discovery of new, improved biocatalysts for suitable enantioselectivity and activity. Bacterial
OYEs commonly produced (S)-citronellal from (E/Z)-citral reduction, while the counterparts from
yeasts mainly afforded to (R)-enantiomer [10]. Representative yeast OYEs have been well characterized,
including OYE2.6 from Pichia stipites [
from Saccharomyces cerevisiae [14 15]. So far, the application of OYE-mediated citral reduction still suffers
from insufficient enantioselectivity and activity. Protein engineering has emerged as an attractive and
powerful strategy for improving enzyme activity and selectivity [16 19]. The circular permutation
9], OYE1 from Saccharomyces pastorianus, and OYE2 and OYE3
,
–
of OYE1 from S. pastorianus yielded the variants exhibiting over an order of magnitude improved
catalytic activity [20]. The activity improvement in the protein engineering of yeast OYEs commonly
varied by substrate. The variant P295A of OYE1 from S. pastorianus showed three- and seven-fold
activity for (R)- and (S)-carvone higher than those of wild type enzyme, respectively; however, it had
no significant improvement for geranial and neral [21].
With regard to the alteration of OYE enantioselectivity, one of representative examples was the
variant W116F of OYE1 from S. pastorianus partly reversed the enantioselectivity in the neral reduction
from 19% e.e. (S) to 65% e.e. (R) as compared to the wild type [22]. In contrast to the substrate
binding mode of the wild type enzyme, the W116F mutation enabled the substrate to bind with a
flipped orientation in the active site, and thus reverse the enantioselectivity, while maintaining the
same mechanism of trans-hydrogenation of C=C bond [23,24]. W116 is not the sole determinant of
enantioselectivity in OYEs, and the enantioselectivity switches seemed to vary by enzyme: Y78, I113,
and F247 in OYE2.6 [25]; C26, I69, and H167 in ene reductases YqjM [26]; and W66 and W100 in OYE
from Gluconobacter oxydans (Gox0502) [27]. The study of enantioselectivity alteration in OYEs rarely
use citral as substrate. The latest example was the NADH-dependent cyclohexenone ene reductase
from Zymomonas mobilis (NCR), in which W66 was critical for controlling the orientation of (E/Z)-citral
binding and, thus, the variant W66A/I231A of NCR reversed the geranial derived enantioselectivity
from 99% e.e. (S) to 63% e.e. (R) [28].
The study aims to develop the asymmetric reduction of (E/Z)-citral to (R)-citronellal using
engineered OYE coupled with formate dehydrogenase for NADH regeneration (Scheme 1). The Old
Yellow Enzyme from S. cerevisiae CICC1060 (OYE2y) was cloned, overexpressed, and purified, which
reduced geranial and neral to citronellal with 82.87% e.e. (R) and 32.66% e.e. (S), respectively. OYE2y was
chosen for enantioselectivity alteration since the wild type enzyme showed higher enantioselectivity
than OYE1 from S. pastorianus and OYE2 and OYE3 from S. cerevisiae in the (E/Z)-citral reduction [29].
The key residues for the enantioselectivity of OYE2y were identified through the combination of
sequence alignment and single-point mutations. Relying on subsequent site-saturation mutagenesis,
the OYE2y variants with double substitutions exhibited full (R)-enantioselectivity in the reduction of
(
E)-citral or (E/Z)-citral. In addition, the role of key residues and the substrate binding modes were
examined via homology modeling and molecular docking.

Molecules 2019, 24, 1057
3 of 15
Scheme 1. OYE-mediated asymmetric reduction of (E/Z)-citral to (R)-citronellal coupled with formate
dehydrogenase from Candida boidinii (FDHCB)-catalyzed NADH regeneration. The reactions were
◦
conducted at 37 C and 200 rpm for 11 h.
2
. Results
2
.1. OYE2y-Mediated Reduction of (E/Z)-Citral
The yeast Old Yellow Enzyme OYE2y was heterologously expressed in Echerichia coli BL21(DE3),
and the resulting recombinant OYE2y with N-terminal His tag was purified using affinity
chromatography. The enzyme OYE2y with 400 amino acid residues shared the sequence identities of
91.50%, 98.75%, and 81.25% to OYE1 from S. pastorianus and OYE2 and OYE3 from S. cerevisiae [14],
respectively. To investigate the enantioselectivity of OYE2y in citral reduction, the purified OYE2y
rather than the whole-cell biocatalyst was used to avoid side reactions. OYE2y accepted NADH or
NADPH as coenzyme, and formate/formate dehydrogenase system was used for NADH regeneration
in this study. The composition of (E/Z)-citral was determined to contain 58.45% geranial and 41.55%
neral. During the first 3 h, the concentration of geranial decreased significantly faster than that
of neral. Meanwhile, the concentration of (R)-citronellal increased rapidly, and the e.e. value was
kept at a higher level of >60% (R) (Figure 1A). Then, the conversion rate of neral turned faster
from 3 h to 5 h, resulting in the decreasing of e.e. value from 65.02% (R) to 40.26% (R). After 6 h,
the conversion rate of neral was nearly parallel to that of geranial, meanwhile the e.e. values were kept
almost constant. The 11 h reaction was completed with 89.51% yield, giving (R)-citronellal with an
e.e. value of 38.13% (R). The time course of (E/Z)-citral reduction clearly indicated that the ratio of
geranial and neral significantly affected the e.e. value of (R)-citronellal, which was consistent with
previous observations [
conditions [ 30]. Thus, the use of freshly prepared geranial and neral with high purity was necessary
to study the enantioselectivity of OYEs.
7,14]. In addition, the isomerization of geranial and neral occurred under some
9,
(
A)
Figure 1. Cont.

Molecules 2019, 24, 1057
4 of 15
(
B)
(
C)
Figure 1. Asymmetric reduction of (E/Z)-citral (
A
), (E)-citral (
B
), and (Z)-citral (C) using the purified
OYE2y.
ꢀ
, (R)-citronellal;
#
, (S)-citronellal;
N
, geranial; , neral; ꢁ
H
, the e.e. value of hydrogenated
product. Data present mean values ± SD from three independent experiments.
Considering the high cost of commercial products, geranial and neral with high purity were
prepared according to the previous procedure with improvements [31]. Based on the optimized
conditions, the yields of (E)-citral and (Z)-citral were increased up to 99.39% and 99.35%, respectively.
The obtained (E)-citral sample contained 98.38% geranial and 1.62% neral, and the obtained (Z)-citral
sample contained 96.84% neral and 3.16% geranial. When the enzyme OYE2y was tested with newly
prepared (E)-citral or (Z)-citral for 4 h, the enantioselectivity of OYE2y stayed at a relatively constant
level (Figure 1B,C). The (E)-citral and (Z)-citral-derived e.e. values after 11 h reduction were 82.87% (R)
and 32.66% (S), respectively.
2
.2. Identification of Key Residues for the Enantioselectivity of OYE2y
It was previously reported that the variant W116F of OYE1 from S. pastorianus partly reversed
the enantioselectivity in the neral reduction [22]. However, the same substitution at site W117
corresponding to W116 in OYE1 even lowered the e.e. value from 38.13% (R) to 24.01% (R) when
(E/Z)-citral was tested as substrate, indicating that the enantioselectivity switch for OYE1 and OYE2y
seemed different. Furthermore, the NAD(P)H-dependent enoate reductase (OYE2p) from S. cerevisiae
YJM1341 was newly discovered for asymmetric reduction of (E/Z)-citral to (R)-citronellal with the
e.e. value of 88.8% (R), with four amino acid residues—G13, A59, I289, and H330—in OYE2p different
from S13, S59, V289, and R330 in OYE2y (Figure 2). Considering the difference of enantioselectivity
between OYE2p and OYE2y, it was expected that S13, S59, V289, and/or R330 might be critical for
the enantioselectivity. Then, the single substitutions were conducted to evaluate this expectation.
The catalytic performance of the variants S13G, S59A, and V289I was similar to that of OYE2y (Table 1).

Molecules 2019, 24, 1057
5 of 15
The substitution R330 to H significantly increased the (R)-enantioselectivity from 38.13% to 86.88%
when (E/Z)-citral was used as substrate. Remarkably, the enantioselectivity was reversed from 32.66%
(S) to 71.92% (R) when (Z)-citral was tested. Except for sequence alignment, the identification of key
residues was conducted through the single mutation on the randomly-selected residues. Through
multiple mutation attempts, the variant P76M was discovered to benefit the (R)-enantioselectivity of
OYE2y in the citral reduction (Table 1). The substitution P76 to M increased the (E/Z) citral-derived
e.e. value from 38.13% (R) to 57.60% (R), while the enantioselectivity in the reduction of (Z)-citral
was lowered from 32.66% (S) to 4.76% (S). Thus, both R330 and P76 were chosen as the targets for
subsequent site saturation mutagenesis.
Figure 2. Structure-related sequence alignment between OYE2y and its homologous OYEs. 1OYB: PDB
code of OYE1 from S. pastorianus; OYE2p: NAD(P)H-dependent enoate reductase from S. cerevisiae
YJM1341. The secondary structural elements of 1OYB (
were indicated above the aligned sequences. The numbering shown was from 1OYB. A red background
highlights conserved residues. , the positions where the amino acid residues differed between OYE2y
and OYE2p; F, key residues for catalytic activity. The figure was produced using ESPript 3.0 [32].
α-helices, β-strands, T-turns, and η-helices)
N

Molecules 2019, 24, 1057
6 of 15
Table 1. The catalytic performance of OYE2y and its variants S13G, S59A, P76M, V289I, and R330H a.
(
E)-Citral
(Z)-Citral
e.e. (%)
(E/Z)-Citral
e.e. (%) Yield (%)
Enzyme
e.e. (%)
Yield (%)
Yield (%)
S13G
S59A
V289I
R330H
P76M
OYE2y
a
83.19 ± 1.57 (R)
80.69 ± 2.21 (R)
75.18 ± 1.70 (R)
88.08 ± 1.39 (R)
86.22 ± 0.75 (R)
82.87 ± 0.98 (R)
95.12 ± 2.10
90.32 ± 1.54
94.88 ± 1.81
71.23 ± 0.85
80.39 ± 0.64
92.20 ± 1.07
45.29 ± 1.46 (S)
30.96 ± 1.25 (S)
37.45 ± 1.55 (S)
71.92 ± 1.34 (R)
4.76 ± 1.50 (S)
32.66 ± 1.77 (S)
94.60 ± 1.22
90.88 ± 2.23
91.71 ± 2.10
64.12 ± 1.33
55.19 ± 0.95
88.65 ± 1.49
37.35 ± 1.63 (R)
41.66 ± 1.59 (R)
35.52 ± 2.42 (R)
86.88 ± 1.36 (R)
57.60 ± 0.92 (R)
38.13 ± 1.55 (R)
96.34 ± 1.87
93.48 ± 1.07
90.78 ± 0.93
52.83 ± 0.75
61.53 ± 0.89
89.51 ± 1.68
Data present mean values
.62% neral, (Z)-citral contained 96.84% neral and 3.16% geranial, and (E/Z)-citral contained 58.45% geranial and
1.55% neral.
±
SD from three independent experiments. (E)-citral contained 98.38% geranial and
1
4
2
.3. Site-Saturation Mutagenesis of R330 in OYE2y
All R330X variants of OYE2y (X = one of the other 19 amino acids) were successfully expressed
in E. coli. After the cells were harvested by centrifugation and then disrupted by ultrasonication,
each variant with N-terminal His tag was purified using affinity chromatography. As shown in Figure
S1, all 19 variant proteins remained in the soluble fraction, revealing that these substitutions did not
decrease the solubility. In comparison with the wild type OYE2y, the R330 variants of OYE2y fell into
three categories: R330P without catalytic activity, R330Y with similar (R)-stereoselectivity to OYE2y,
and the other 17 variants with improved (R)-stereoselectivity (Table 2). R330P did not retain the yellow
color, suggesting that its substitution might deactivate the coenzyme binding. When (E/Z)-citral
was tested as substrate, the variants except R330Y and R330P increased the (R)-stereoselectivity but
decreased the product yield to some extent. In contrast to the reduction of (E)-citral, those 17 variants
showed more significant improvement of (R)-enantioselectivity in the reduction of (Z)-citral. Among
them, the variants R330H, R330D, and R330W had superior catalytic performance in terms of activity
and enantioselectivity.
Table 2. The catalytic performance of OYE2y and its R330X variants a.
(
E)-Citral
(Z)-Citral
e.e. (%)
(E/Z)-Citral
Enzyme
e.e. (%)
Yield (%)
Yield (%)
e.e. (%)
Yield (%)
R330H
R330D
R330W
R330I
88.08 ± 1.39 (R)
92.42 ± 2.30 (R)
95.05 ± 1.85 (R)
87.38 ± 1.11 (R)
89.64 ± 0.79 (R)
89.40 ± 1.05 (R)
89.22 ± 0.61 (R)
88.10 ± 1.37 (R)
85.74 ± 2.33 (R)
92.15 ± 2.49 (R)
89.66 ± 1.50 (R)
89.60 ± 1.48 (R)
87.52 ± 1.56 (R)
86.18 ± 0.84 (R)
84.81 ± 1.41 (R)
92.39 ± 1.66 (R)
87.88 ± 1.23 (R)
87.03 ± 1.12 (R)
/
71.23 ± 0.85
63.12 ± 1.93
47.32 ± 1.11
31.45 ± 0.40
75.14 ± 1.25
89.86 ± 1.74
80.92 ± 0.80
83.10 ± 2.11
83.33 ± 2.06
90.55 ± 1.85
91.10 ± 1.01
85.62 ± 1.38
80.50 ± 1.47
84.82 ± 2.19
90.74 ± 2.55
10.96 ± 0.29
92.40 ± 1.77
96.61 ± 2.16
/
71.92 ± 1.34 (R)
73.56 ± 0.51 (R)
72.19 ± 1.09 (R)
20.93 ± 1.21 (R)
45.59 ± 0.75 (R)
57.68 ± 0.86 (R)
47.80 ± 1.14 (R)
51.07 ± 1.23 (R)
27.97 ± 0.48 (R)
41.87 ± 0.73 (R)
24.39 ± 1.55 (R)
33.95 ± 0.67 (R)
33.80 ± 1.41 (R)
5.45 ± 0.59 (R)
10.90 ± 0.84 (R)
5.07 ± 1.22 (R)
0.37 ± 0.65 (R)
40.92 ± 1.53 (S)
/
64.12 ± 1.33
36.41 ± 1.94
53.38 ± 1.12
13.19 ± 0.23
55.72 ± 0.59
78.39 ± 1.34
47.82 ± 1.11
49.12 ± 1.63
43.83 ± 0.87
72.44 ± 1.61
65.15 ± 1.69
69.67 ± 1.92
63.79 ± 1.27
63.69 ± 1.51
76.88 ± 0.66
8.49 ± 0.15
85.18 ± 2.08
88.24 ± 1.89
/
86.88 ± 1.36 (R)
80.30 ± 1.85 (R)
79.71 ± 1.03 (R)
74.52 ± 0.69 (R)
72.58 ± 1.32 (R)
72.50 ± 1.46 (R)
69.42 ± 2.34 (R)
69.42 ± 1.11 (R)
69.12 ± 2.32 (R)
68.19 ± 1.56 (R)
67.68 ± 1.42 (R)
64.39 ± 2.05 (R)
64.35 ± 2.33 (R)
61.53 ± 1.76 (R)
61.17 ± 0.71 (R)
60.97 ± 1.56 (R)
58.40 ± 1.08 (R)
38.65 ± 1.11 (R)
/
52.83 ± 0.75
62.70 ± 0.85
70.98 ± 1.15
28.17 ± 0.68
67.45 ± 1.21
80.49 ± 1.69
72.46 ± 1.02
69.61 ± 0.72
46.61 ± 0.29
78.89 ± 1.98
75.77 ± 1.35
71.80 ± 1.57
70.16 ± 0.86
80.64 ± 0.43
85.23 ± 1.44
14.82 ± 0.33
86.71 ± 1.37
91.56 ± 1.72
/
R330L
R330F
R330E
R330A
R330T
R330N
R330V
R330S
R330C
R330K
R330Q
R330G
R330M
R330Y
R330P b
OYE2y
a
82.87 ± 0.98 (R)
92.20 ± 1.07
32.66 ± 1.77 (S)
88.65 ± 1.49
SD from three independent experiments. (E)-citral
38.13 ± 1.55 (R)
89.51 ± 1.68
X represents any of 20 amino acids. Data present mean values
±
contained 98.38% geranial and 1.62% neral, (Z)-citral contained 96.84% neral and 3.16% geranial, and (E/Z)-citral
contained 58.45% geranial and 41.55% neral. b “/” represents no catalytic activity.

Molecules 2019, 24, 1057
7 of 15
2
.4. Site-Saturation Mutagenesis of P76 in OYE2y
Similar to R330X variants, all P76X variants of OYE2y were successfully expressed in E. coli and
purified (Figure S2). However, the number of the P76 variants in the category without catalytic activity
P76Y, P76Q, P76D, P76E, P76R, P76H, P76F, P76W, and P76K) was obviously greater than that of R330
(
variants, suggesting that P76 could be also critical for the activity. The category with significantly
improved enantioselectivity included P76C, P76S, P76M, P76G, and P76N, whereas the other five
variants (P76A, P76V, P76T, P76L, and P76I) showed similar catalytic performance to that of OYE2y
(
Table 3). Similar to the trend in the R330X variants, higher (R)-stereoselectivity of OYE2y variants was
accompanied by lower product yields. When (E/Z)-citral was used as substrate, the substitution of
P76 to C increased the e.e. value from 44.13% (R) to 69.92% (R), but the yield was lowered from 89.51%
to 49.65%. Particularly, the e.e. value in the reduction of (Z)-citral was partly reversed from 32.66% (S)
to 37.50% (R).
Table 3. The catalytic performance of OYE2y and its P76X variants a.
(
E)-Citral
(Z)-Citral
e.e. (%)
(E/Z)-Citral
Enzyme
e.e. (%)
Yield (%)
Yield (%)
e.e. (%)
Yield (%)
P76C
P76S
85.39 ± 2.70 (R)
65.32 ± 0.76
37.50 ± 1.55 (R)
38.54 ± 1.61
69.92 ± 2.46 (R)
49.65 ± 1.40
81.23 ± 1.79 (R)
81.84 ± 0.62
10.19 ± 0.73 (S)
48.15 ± 0.88
62.80 ± 0.97 (R)
64.48 ± 0.90
P76M
P76G
P76N
P76A
P76V
P76T
P76L
P76I
86.22 ± 0.75 (R)
80.39 ± 0.64
4.76 ± 1.50 (S)
55.19 ± 0.95
57.60 ± 1.92 (R)
61.53 ± 0.89
85.52 ± 2.55 (R)
83.94 ± 0.78
3.63 ± 1.47 (S)
57.54 ± 1.84
53.19 ± 0.81 (R)
78.04 ± 1.52
86.45 ± 1.33 (R)
85.36 ± 0.49
13.05 ± 0.67 (S)
69.39 ± 1.43
49.59 ± 1.55 (R)
72.59 ± 0.77
86.55 ± 0.91 (R)
90.57 ± 1.98
21.21 ± 1.95 (S)
88.96 ± 0.87
41.88 ± 0.95 (R)
90.43 ± 2.22
87.54 ± 1.55 (R)
92.50 ± 2.51
30.15 ± 1.67 (S)
82.30 ± 2.07
40.49 ± 1.01 (R)
87.37 ± 1.28
86.12 ± 1.35 (R)
93.79 ± 2.26
28.10 ± 1.69 (S)
91.24 ± 2.12
37.05 ± 1.13 (R)
91.50 ± 0.94
84.28 ± 1.62 (R)
90.95 ± 1.83
38.01 ± 2.27 (S)
88.36 ± 1.46
35.05 ± 1.64 (R)
88.46 ± 1.32
86.10 ± 1.03 (R)
94.76 ± 1.74
40.23 ± 1.81 (S)
89.95 ± 1.33
34.51 ± 1.17 (R)
91.88 ± 2.45
P76Y b
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
b
P76Q
P76D
P76E
b
b
P76R b
b
P76H
P76F b
b
P76W
P76K b
OYE2y
a
/
/
/
82.87 ± 0.98 (R)
92.20 ± 1.07
32.66 ± 1.77 (S)
88.65 ± 1.49
38.13 ± 1.55 (R)
89.51 ± 1.68
X represents one of the other 19 amino acids. Data present mean values
±
SD from three independent experiments.
(
(
E)-citral contained 98.38% geranial and 1.62% neral, (Z)-citral contained 96.84% neral and 3.16% geranial, and
E/Z)-citral contained 58.45% geranial and 41.55% neral. b “/” represents no catalytic activity.
2
.5. Evaluation of Double Substitution at Sites P76 and R330 of OYE2y
To investigate the effect of the double substitutions on P76 and R330, we firstly conducted
site-directed mutagenesis of P76 to C and R330 to H, D, W, and C, resulting in the four variants
Table 4). The e.e. values and yields of the resulting variants were higher than those of the variant
(
P76C, but similar to those of the corresponding R330H, R330D, R330W, and R330C. On the other hand,
the other set of double substitutions was created by site-directed mutagenesis of R330 to H and P76 to
M, G, and S (Table 4). Among them, the (E)-citral-derived e.e. values were significantly increased up
to >99% (R) with relatively higher yields (64.09%~73.88%). In the (E/Z)-citral reduction, the variants
P76M/R330H, P76M/R330H, and P76M/R330H also exhibited full (R)-enantioselectivity despite lower
product yields (9.12–15.83%).

Molecules 2019, 24, 1057
8 of 15
Table 4. The catalytic performance of double substitution variants of OYE2y at sites P76 and R330 a.
(
E)-Citral
(Z)-Citral
e.e. (%)
(E/Z)-Citral
e.e. (%) Yield (%)
Enzyme
e.e. (%)
85.39 ± 2.70 (R)
P76C/R330H 88.00 ± 2.04 (R)
P76C/R330D
88.77 ± 1.81 (R)
Yield (%)
Yield (%)
P76C
65.32 ± 0.76
78.09 ± 1.16
80.00 ± 1.52
70.30 ± 1.87
90.10 ± 1.96
71.23 ± 0.85
73.88 ± 2.66
64.09 ± 1.32
64.74 ± 1.57
92.20 ± 1.07
37.50 ± 1.55 (R)
76.16 ± 0.88 (R)
76.45 ± 1.03 (R)
70.32 ± 1.16 (R)
49.17 ± 2.44 (R)
71.92 ± 1.34 (R)
75.01 ± 1.59 (R)
77.60 ± 2.06 (R)
74.74 ± 1.84 (R)
32.66 ± 1.77 (S)
38.54 ± 1.61
54.53 ± 0.45
52.23 ± 1.25
56.49 ± 0.68
51.14 ± 0.79
64.12 ± 1.33
13.99 ± 0.23
12.64 ± 0.31
8.90 ± 0.16
88.65 ± 1.49
69.92 ± 2.46 (R)
82.32 ± 1.22 (R)
81.70 ± 2.18 (R)
81.44 ± 1.31 (R)
77.37 ± 1.04 (R)
86.88 ± 1.36 (R)
>99 (R)
49.65 ± 1.40
57.74 ± 0.84
63.28 ± 1.36
65.31 ± 1.72
66.19 ± 1.42
52.83 ± 0.75
15.83 ± 0.45
11.61 ± 0.38
9.12 ± 0.22
89.51 ± 1.68
P76C/R330W 89.53 ± 2.23 (R)
P76C/R330C
R330H
P76M/R330H
P76G/R330H
P76S/R330H
OYE2y
87.43 ± 1.37 (R)
88.08 ± 1.39 (R)
>99 (R)
>99 (R)
>99 (R)
82.87 ± 0.98 (R)
>99 (R)
>99 (R)
38.13 ± 1.55 (R)
a
Data present mean values
.62% neral, (Z)-citral contained 96.84% neral and 3.16% geranial, and (E/Z)-citral contained 58.45% geranial and
1.55% neral.
±
SD from three independent experiments. (E)-citral contained 98.38% geranial and
1
4
3
. Discussion
For the synthesis of (R)-citronellal from OYE-mediated citral reduction, low-cost (E/Z)-citral
is the industrial desire in contrast to geranial and neral [ ]. However, (E/Z)-citral reduction
9
remains challenging due to limited chemoselectivity and enantioselectivity. On the one hand,
the presence of multiple C=C and C=O double bonds of citral makes the whole-cell biocatalyst
impossible to avoid side reactions [33]. Thus, the purified enzyme is commonly required as biocatalyst.
On the other hand, the hydrogenated products from the geometric isomers geranial and neral are
usually enantiocomplementary when the wild type OYE was used as biocatalyst, reducing the
reaction’s enantioselectivity. The features of (E/Z)-citral reduction make it difficult to implement a
high-throughput screening (HTS) method for determining the enantioselectivity of the large variant
libraries [34–36]. Typically, the samples must be examined individually by chiral GC, which requires at
least thirty minutes per sample. To keep the variant library as minimum as possible, the best strategy for
enantioselectivity alteration turns to be site-saturation mutagenesis of individual key residue(s) rather
than the HTS-based directed evolution [18,37,38]. Based on the strategy of site-saturated mutagenesis,
several groups have successfully increased (R)-enantioselectivity in the (E/Z)-citral reduction, and
our study further demonstrated that it was feasible to achieve the full (R)-enantioselectivity in the
OYE-mediated (E/Z)-citral reduction through protein engineering.
The R330X and P76X variant libraries yielded 17 and five variants with improved
(R)-enantioselectivity, respectively, indicating that the subtle change of structure would significantly
affect the enantioselectivity. In the variants R330H and P76C, the amino acid pair R and H possessed
electrically charged side group, while the side groups of the amino acid pair P and C was polar and
uncharged. It was suggested that the substitution could give priority to amino acid residue(s) with
similar side group in terms size, polarity and charge, if no clear structure–function relationship
was available. Furthermore, the (Z)-citral-derived e.e. value of R330H (71.92%, R) was much
higher than that of OYE2p (26.5%, R) [7], suggesting that the role of S13, S59, and V289 could
not be ignored for the (R)-enantioselectivity. For the single substitutions, the (R)-enantioselectivity
improvement in the (E/Z)-citral reduction was mainly attributed to the enantioselectivity inversion in
the (Z)-citral reduction, meanwhile, the same variant reduced (E)-citral to (R)-citronellal with similar
e.e. values. Different from the single substitutions, the double substitutions led to further improved
(R)-stereoselectivity in the (E)-citral reduction rather than (Z)-reduction, which was rarely observed in
the enantioselectivity alternation of OYEs.
To get detailed insights into the molecular mechanism, the models of OYE2y were created from
the OYE1 structure (PDB code: 1OYB) using SWISS-MODEL and molecular docking was conducted
using the program AutoDock Vina. The substrate and FMN were docked in silico into the models
of OYE2y and its variants. In the model of wild type OYE2y, a conserved H192/N195 pair formed

Molecules 2019, 24, 1057
9 of 15
hydrogen bonds with the carbonyl oxygen of
α
,β-unsaturated carbonyl compounds; a hydride was
enantioselectively transferred to the substrate C atom from FMNH ; and the Y197 residue provided
β
2
a proton to the substrate C atom as an electron acceptor [17]. From the model of wild type OYE2y,
α
the distances from C of neral to the side groups of P76 and R330 were calculated to be 14.92 and 20.84
β
Å, respectively (Figure 3). Similarly, the distances from C of geranial to the side groups of P76 and
β
R330 were calculated to be 14.49 and 21.16 Å, respectively. It was assumed that the residues affecting
the enantioselectivity of OYEs might directly interact with the substrate [25]. Our results indicated
that the residue distant from active sites, e.g., R330 in OYE2y, could also be pivotal for determining the
enantioselectivity of OYEs. Furthermore, substrate modeling into the wild type enzyme revealed two
different binding modes for the two isomers geranial and neral, leading to products with different
enantioselectivity. The docking analyses of variants P76C, R330H, and P76M/R330 suggested that the
reversed enantioselectivity in the neral reduction was due to the flipped binding orientation that placed
the opposite face of the alkene above the si face of the FMN cofactor [24]. Meanwhile, the same variant
reduced (E)-citral with preserved (R)-enantioselectivity derived from the same binding orientation
as wild type OYE2y (Figure 4). Although it was acceptable that enantioselectivity was controlled by
tuning the orientation of substrate in the binding sites, how subtle changes control the orientation of
substrate binding remains to be unraveled, and X-ray crystallography of the variants in the future
study would benefit to clarify the subtle structural differences at the substrate-binding site.
(
A)
(B)
Figure 3. The residues targeted for site-saturation mutagenesis in the homology model of OYE2y.
The model structure of OYE2y was constructed with the crystal structure of OYE1 (PDB code: 1OYB) as
template. Distances between the Cβ atom of geranial (A) and neral (B) and side chains of P76 and R330
were determined. Green, carbon atom; blue, nitrogen atom; tangerine, oxygen atom; white, hydrogen
atom; orange, phosphorus atom.

Molecules 2019, 24, 1057
10 of 15
(
A)
(
B)
(
C)
Figure 4. The binding modes of citral isomers in OYE2y and its variants R330H (
and P76M/R330H ( ) leading to either (R)- or (S)-citronellal. The catalytic residues H192, N195, Y197,
A), P76C (B),
C
and the prosthetic group FMN were depicted. Green, carbon atom; blue, nitrogen atom; tangerine,
oxygen atom; white, hydrogen atom; orange, phosphorus atom.
4
. Materials and Methods
4
.1. Organisms and Chemicals
The organism S. cerevisiae CICC1060 was purchased from the China Center of Industrial Culture
Collection (CICC, Beijing, China). S. cerevisiae CICC1060 was cultured with YPD medium (tryptone
◦
2
0 g/L, yeast extract 10 g/L, and glucose 20 g/L) at 30 C for 24 h. The pEASY-E1 expression vector
from TransGen Biotech Co., Ltd (Beijing, China) was used for overexpression of the enzyme OYE2y,
and the E. coli strain BL21(DE3) was used as the host. E. coli cultures were grown routinely in Luria
◦
Bertani (LB) medium at 37 C for 12 h.
The standards (S)-citronellal, (R)-citronellal, and (S/R)-citronellal were obtained from
Sigma-Aldrich (Shanghai) Trading Co., Ltd. (Shanghai, China). Other chemicals of analytical grade

Molecules 2019, 24, 1057
11 of 15
were purchased from Sangon Biotech Co. Ltd (Shanghai, China) or Shanghai Jingchun Reagent Co.,
Ltd (Shanghai, China). The site-directed mutagenesis kit and the restriction enzyme Dpn I were
obtained from Vazyme Biotech Co., Ltd. (Nanjing, China). KOD DNA polymerase was purchased
from TransGen Biotech Co., Ltd (Beijing, China). The Ni-NTA-HP resin column for protein purification
was obtained from GE Healthcare Life Sciences (Shanghai, China).
4
.2. Preparation of (Z)-Citral and (E)-Citral
Z)-citral and (E)-citral were prepared by a modification of the procedure described previously [38].
Activated MnO (1.15 g) was added into a 50-mL three-necked bottom round flask which atmosphere
(
2
was replaced with N . One-hundred milligrams of geraniol or nerol was dissolved in 16 mL dry hexane
2
◦
and was charged in the flask to initiate the alcohol oxidation. The reaction was maintained at 0 C and
4
50 rpm for 6 h. Then, the reaction solution was filtered through a filter paper and hexane in the filtrate
◦
was removed by vacuum evaporation at 45 C. Finally, an aliquot of the collected product (E)-citral or
(Z)-citral was dissolved in ethyl acetate and subjected to the analyses of gas chromatography (GC) and
gas chromatography–mass spectrometry (GC–MS).
4
.3. Cloning, Expression, and Purification of OYE2y
The gene encoding OYE2y was PCR-amplified from the genomic DNA of S. cerevisiae
0
0
CICC1060 using a set of primers: Forward, 5 -ATGCCATTTGTTAAGGACTTTAAGCCAC-3 ; Reverse,
0
0
5
-TTAATTTTTGTCCCAACCGAGTTTTAGAGC-3 . The conditions for PCR amplification of the oye2y
gene were 94 C for 2 min for initial denaturalization, 30 cycles of 94 C for 30 s, 57 C for 30 s, 72 C
for 80 s, and 72 C for 10 min for the final extension.
◦
◦
◦
◦
◦
Following the procedure of expression and purification of ReBDH [39], the PCR products
were purified and then ligated with the expression vector pEASY-E1 through the AT ligation
strategy. The recombinant plasmid harboring the oye2y gene, designated as pEASY-E1-oye2y, was
verified by DNA sequencing (Sangon Biotech, Shanghai, China) and then transformed into E. coli
BL21 (DE3) competent cells, resulting in the recombinant strain E. coli BL21(DE3)/pEASY-E1-oye2y.
The recombinant cells containing pEASY-E1-oye2y were grown in the LB medium with 100
µ
g/mL
◦
ampicillin at 37 C and 200 rpm until the OD600 was 0.6–0.8, and then 0.2 mM isopropyl
◦
β
-D-1-thiogalactopyranoside (IPTG) was supplemented to initiate the induction at 23 C and 160 rpm.
After 12 h of growth, recombinant E. coli cells were harvested by centrifugation and further washed
using 50 mM Tris-HCl buffer (pH 8.0). The cells were disrupted through ultrasonication for 10 min, and
the cell debris and cell lysate were removed by centrifugation to result in a clear cell extract. The crude
cell extracts containing OYE2y was applied to a Ni-NTA chelating affinity column equilibrated with
the binding buffer (5 mM imidazole and 300 mM NaCl dissolved in 50 mM Tris-HCl, pH 8.0). Unbound
proteins were washed off by the application of the binding buffer. The recombinant OYE2y was eluted
with 100 mM imidazole in 50 mM Tris-HCl (pH 8.0), desalted with 50 mM Tris-HCl buffer (pH 8.0) by
◦
ultrafiltration and then stored at −20 C for further study.
4
.4. Construction of OYE2y Variants by Site-Directed Mutagenesis
The variants with single or double substitutions were constructed by site-directed mutagenesis
according to the QuikChange Mutagenesis Kit. PCR amplification to introduce substitution was
performed in 50
µ
L of standard PCR mixture with 50 ng of template plasmid DNA and 15 pmol each
◦
of the appropriate set of primers using the following temperature cycle; 30 s at 95 C, followed by
◦
◦
◦
3
0 cycles of 95 C for 15 s, appropriate annealing temperature (55~61 C) for 15 s, and 72 C for 80 s,
◦
and the final extension of 5 min at 72 C. The plasmid pEASY-E1-oye2y was used as template DNA
in the single substitution, while the creation of double mutants was based on the generated OYE2y
P76C or R330H gene as the template. The primer sets for single or double substitutions were shown
in Tables S1 and S2. The amplified PCR fragments were digested with the restriction enzyme Dpn
◦
I at 37 C for 1 h, and then the digested DNA was directly introduced into E. coli strain BL21(DE3).

Molecules 2019, 24, 1057
12 of 15
Each constructed plasmid was confirmed by sequencing. Expression and purification of the resulting
OYE2y variants were conducted using the same procedure as OYE2y.
4
.5. Homology Modeling and Molecular Docking
Using the crystal structure of OYE1 from S. pastorianus (PDB number: 1OYB) as a template [40], the
structural model of OYE2y was obtained by a homology modeling strategy [41
simulation was performed by AutoDock Vina [43] when the binding package was set at a distance of
5 Å from FMN N atom. (E)-citral or (Z)-citral acted as a ligand to molecular docking with OYE2y,
,42]. Molecular docking
1
5
and the calculation of geometric parameters and ligand structure was performed by ChemBioDraw
2.0 (CambridgeSoft, Cambridge, MA, USA). To make the results more accurate, 100 consecutive runs
1
were performed and the highest ranked score from each run was used to calculate the average score
of each flexible ligand configuration. The optimal configuration and the resulting substrate–enzyme
complexes were further processed using the PYMOL software [44]. The candidate complexes were
acceptable when they met both criteria: (1) the substrate carbonyl oxygen should be capable of forming
hydrogen bonds with the side chains of both H192 and N195 and (2) the distance between the FMN
N atom and the
5
β-unsaturated carbon of the substrate molecule was be in an appropriate range from
3
.5 Å to 4.1 Å [22,45,46].
4
.6. Asymmetric Reduction of Citral Mediated by OYE2y or Its Variants
The reaction mixture (1 mL) contained 50 mM PIPES buffer (pH 7.0), 20 mM substrate, 1 mg
OYE2y or its variant, 0.6 U formate dehydrogease from Candida boidinii (FDHCB), and 100 mM sodium
+
formate, 0.96 mM NAD . The substrate included (Z)-citral, (E)-citral, or (E/Z)-citral, which stock
solution was 200 mM substrate in isopropanol. The overexpression and purification of FDHCB were
◦
conducted according to the procedure described previously [39]. The reaction was conducted at 30 C
and 200 rpm for 11 h, unless otherwise specified. The reaction mixture was centrifuged to remove the
◦
cells, and the resulting supernatant was extracted with equal volume of ethyl acetate at 30 C and
200 rpm for 2 h. Finally, the solvent phase was collected, dried over anhydrous sodium sulfate and
subjected to the analyses of GC and GC–MS.
4
.7. Analyses of GC and GC–MS
Z)-citral, (E)-citral, (S)-citronellal, and (R)-citronellal were determined by GC (Agilent 6890N)
equipped with an FID detector and chiral capillary BGB-174 column (BGB Analytik, Böckten,
(
Switzerland, 30 m
×
250
µ
m
×
0.25
µ
m). The flow rate and split ratio of N as the carrier gas
2
◦
were set as 1.38 mL/min and 1:100, respectively. Both injector and detector were kept at 250 C.
◦
The column temperature program was listed as follows; initial temperature of 90 C for 25 min,
◦
◦
◦
◦
2
0 C/min ramp to 150 C for 3 min, and 30 C/min ramp to 180 C for 3 min. The injection volume
was 1 L. The retention times of (S)-citronellal, (R)-citronellal, (Z)-citral, and (E)-Citral were 22.459 min,
3.067 min, 29.164 min and 30.398 min, respectively (Figure S3).
S)-citronellal, (R)-citronellal, (Z)-citral, and (E)-Citral were validated through GC–MS analysis
µ
2
(
(
Figure S4). The GC–MS analysis (Agilent7890A/5975C, Agilent Technologies Inc., Santa Clara, CA,
◦
USA) comprised the following parameters; auxiliary heating zone temperature, 250 C; MS quadrupole
temperature, 150 C; ion source temperature, 230 C; scan quality range, 30–500 amu; emission current,
◦
◦
2
00 µA; and electron energy, 70 eV.
4
.8. Nucleotide Sequence Accession Number
The gene encoding OYE2y has been deposited in the GenBank database under the accession
numbers of MK372229.

Molecules 2019, 24, 1057
13 of 15
5
. Conclusions
In summary, significant increase of (R)-enantioselectivity in the (E/Z)-citral reduction was
achieved by saturation mutagenesis of P76 and R330 in OYE2y. Remarkably, the variants P76M/R330H,
P76G/R330H, and P76S/R330H exhibited full (R)-enantioselectivity in the reduction of (E)-citral or
(E/Z)-citral. The variants with improved (R)-enantioselectivity usually came along with lower catalytic
activities, indicating that the sites P76 and R330 were important for enantioselectivity as well as
activity. In contrast to P76, R330 was relatively distant from active sites and its substitutions brought
more beneficial impacts on enantioselectivity. Our results proved that it was reasonable to alter the
enantioselectivity of OYE2y by saturation mutagenesis of key residue distant from active sites.
Supplementary Materials: The following are available online at http://www.mdpi.com/1420-3049/24/6/1057/
s1, Table S1: The primer information of site saturation mutation of P76 in OYE2y; Table S2: The primer information
of site saturation mutation of R330 in Oye2y; Figure S1: SDS-PAGE (12%) analysis of the purified OYE2y R330X
variants; Figure S2: SDS-PAGE (12%) analysis of the purified OYE2y P76X variants; Figure S3: Gas chromatography
analysis for standards (S)-citronellal (22.459 min), (R)-citronellal (23.067 min), (Z)-citral (29.164 min), and (E)-citral
(
30.398 min); Figure S4: Gas chromatography–mass spectrometry analysis for (S)-citronellal (A), (R)-citronellal (B),
Z)-citral (C), and (E)-citral (D) in the asymmetric reduction of (E/Z)-citral.
(
Author Contributions: Conceptualization, X.Y.; Data Curation, X.Y., M.Y. (Meilan Yu), and M.Y. (Meirong Ying);
Formal Analysis, X.Y., M.Y. (Meilan Yu), and M.Y. (Meirong Ying); Funding Acquisition, X.Y.; Investigation, S.Y.,
M.H., R.W., S.M., F.C., and M.Z.; Supervision, Z.W.; Writing—Original Draft, X.Y.
Funding: This work was supported by the Natural Science Foundation of Zhejiang Province, China (No.
LY17B020012).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
Itoh, H.; Maeda, H.; Yamada, S.; Hori, Y.; Mino, T.; Sakamoto, M. Kinetic resolution of citronellal by chiral
aluminum catalysts: L-menthol synthesis from citral. Org. Chem. Front. 2014, 1, 1107–1115. [CrossRef]
Lenardão, E.J.; Botteselle, G.V.; de Azambuja, F.; Perin, G.; Jacob, R.G. Citronellal as key compound in organic
synthesis. Tetrahedron 2007, 63, 6671–6712. [CrossRef]
Nie, Y.; Chuah, G.-K.; Jaenicke, S. Domino-cyclisation and hydrogenation of citronellal to menthol over
bifunctional Ni/Zr-Beta and Zr-beta/Ni-MCM-41 catalysts. Chem. Commun. 2006, 790–792. [CrossRef]
[
PubMed]
Coffen, D.L.; Cohen, N.; Pico, A.M.; Schmid, R.; Sebastian, M.J.; Wang, F. A microbial
lipase based stereoselective synthesis of (d)- -tocopherol from (R)-citronellal and
S)-(6-hydroxy-2,5,7,8-tetramethylchroman-2-yl)acetic acid. Heterocycles 1994, 39, 527–552. [CrossRef]
4.
5.
6.
α
(
Eggersdorfer, M.; Laudert, D.; Létinois, U.; McClymont, T.; Medlock, J.; Netscher, T.; Bonrath, W. One
hundred years of vitamins—a success story of the natural sciences. Angew. Chem. Int. Ed. 2012, 51,
1
2960–12990. [CrossRef] [PubMed]
Tani, K.; Yamagata, T.; Akutagawa, S.; Kumobayashi, H.; Taketomi, T.; Takaya, H.; Miyashita, A.; Noyori, R.;
Otsuka, S. Highly enantioselective isomerization of prochiral allylamines catalyzed by chiral diphosphine
Rhodium(I) complexes: Preparation of optically active enamines. J. Am. Chem. Soc. 1984, 106, 5208–5217.
[CrossRef]
7
8
9
1
1
.
.
.
Zheng, L.; Lin, J.; Zhang, B.; Kuang, Y.; Wei, D. Identification of a yeast old yellow enzyme for highly
enantioselective reduction of citral isomers to (R)-citronellal. Bioresour. Bioprocess. 2018, 5, 9. [CrossRef]
Maeda, H.; Yamada, S.; Itoh, H.; Hori, Y. A dual catalyst system provides the shortest pathway for L-menthol
synthesis. Chem. Commun. 2012, 48, 1772–1774. [CrossRef] [PubMed]
Bougioukou, D.J.; Walton, A.Z.; Stewart, J.D. Towards preparative-scale, biocatalytic alkene reductions.
Chem. Comm. 2010, 46, 8558–8560. [CrossRef] [PubMed]
0. Müller, A.; Hauer, B.; Rosche, B. Enzymatic reduction of the α,β-unsaturated carbon bond in citral. J. Mol.
Catal. B Enzym. 2006, 38, 126–130. [CrossRef]
1. Toogood, H.S.; Gardiner, J.M.; Scrutton, N.S. Biocatalytic reductions and chemical versatility of the old
yellow enzyme family of flavoprotein oxidoreductases. ChemCatChem 2010, 2, 892–914. [CrossRef]

Molecules 2019, 24, 1057
14 of 15
1
1
1
1
2. Toogood, H.S.; Scrutton, N.S. New developments in ‘ene’-reductase catalysed biological hydrogenations.
Curr. Opin. Chem. Biol. 2014, 19, 107–115. [CrossRef]
3. Toogood, H.S.; Scrutton, N.S. Discovery, characterization, engineering, and applications of ene-reductases
for industrial biocatalysis. ACS Catal. 2018, 8, 3532–3549. [CrossRef]
4. Müller, A.; Hauer, B.; Rosche, B. Asymmetric alkene reduction by yeast old yellow enzymes and by a novel
Zymomonas mobilis reductase. Biotechnol. Bioeng. 2007, 98, 22–29. [CrossRef]
5. Brenna, E.; Gatti, F.G.; Monti, D.; Parmeggiani, F.; Serra, S. Stereochemical outcome of the biocatalysed
reduction of activated tetrasubstituted olefins by old yellow enzymes 1–3. Adv. Synth. Catal. 2012, 354,
1
05–112. [CrossRef]
1
1
6. Amato, E.D.; Stewart, J.D. Applications of protein engineering to members of the old yellow enzyme family.
Biotechnol. Adv. 2015, 33, 624–631. [CrossRef]
7. Kataoka, M.; Miyakawa, T.; Shimizu, S.; Tanokura, M. Enzymes useful for chiral compound synthesis:
Structural biology, directed evolution, and protein engineering for industrial use. Appl. Microbiol. Biotechnol.
2
016, 100, 5747–5757. [CrossRef]
1
1
2
8. Li, R.; Wijma, H.J.; Song, L.; Cui, Y.; Otzen, M.; Tian, Y.; Du, J.; Li, T.; Niu, D.; Chen, Y.; et al. Computational
redesign of enzymes for regio- and enantioselective hydroamination. Nature Chem. Biol. 2018, 14, 664–670.
[CrossRef]
9. Ying, X.; Zhang, J.; Wang, C.; Huang, M.; Ji, Y.; Cheng, F.; Yu, M.; Wang, Z.; Ying, M. Characterization of a
carbonyl reductase from Rhodococcus erythropolis WZ010 and its variant Y54F for asymmetric synthesis of
(S)-N-Boc-3-hydroxypiperidine. Molecules 2018, 23, 3117. [CrossRef]
0. Daugherty, A.B.; Govindarajan, S.; Lutz, S. Improved biocatalysts from a synthetic circular permutation
library of the flavin-dependent oxidoreductase old yellow enzyme. J. Am. Chem. Soc. 2013, 135, 14425–14432.
[CrossRef]
2
2
1. Quertinmont, L.T.; Lutz, S. Cell-free protein engineering of Old Yellow Enzyme 1 from Saccharomyces
pastorianus. Tetrahedron 2016, 72, 7282–7287. [CrossRef]
2. Padhi, S.K.; Bougioukou, D.J.; Stewart, J.D. Site-saturation mutagenesis of tryptophan 116 of Saccharomyces
pastorianus old yellow enzyme uncovers stereocomplementary variants. J. Am. Chem. Soc. 2009, 131,
3
271–3280. [CrossRef]
3. Brenna, E.; Crotti, M.; Gatti, F.G.; Monti, D.; Parmeggiani, F.; Powell, R.W., III; Santangelo, S.; Stewart, J.D.
Opposite enantioselectivity in the bioreduction of (Z)- -aryl-bcyanoacrylates mediated by the tryptophan
16 mutants of old yellow enzyme 1: Synthetic approach to (R)- and (S)- -aryl-glactams. Adv. Synth. Catal.
015, 357, 1849–1860. [CrossRef]
2
β
1
2
β
2
2
4. Pompeu, Y.A.; Sullivan, B.; Stewart, J.D. X-ray crystallography reveals how subtle changes control the
orientation of substrate binding in an alkene reductase. ACS Catal. 2013, 3, 2376–2390. [CrossRef]
5. Walton, A.Z.; Sullivan, B.; Patterson-Orazem, A.C.; Stewart, J.D. Residues controlling facial selectivity in an
alkene reductase and semirational alterations to create stereocomplementary variants. ACS Catal. 2015, 4,
2
307–2318. [CrossRef]
2
2
6. Rüthlein, E.; Classen, T.; Dobnikar, L.; Schölzel, M.; Pietruszka, J. Finding the selectivity switch—A rational
approach towards stereocomplementary variants of the ene reductase YqjM. Adv. Synth. Catal. 2015, 357,
1
775–1786. [CrossRef]
7. Yin, B.; Deng, J.; Lim, L.; Yuan, Y.A.; Wei, D. Structural insights into stereospecific reduction of
-unsaturated carbonyl substrates by old yellow enzyme from Gluconobacter oxydans. Biosci. Biotechnol.
Biochem. 2015, 79, 410–421. [CrossRef]
α
,
β
2
8. Kress, N.; Rapp, J.; Hauer, B. Enantioselective reduction of citral isomers in NCR ene reductase: Analysis of
an active site mutant library. ChemBioChem 2017, 18, 717–720. [CrossRef]
2
9. Hall, M.; Stueckler, C.; Hauer, B.; Stuermer, R.; Friedrich, T.; Breuer, M.; Kroutil, W.; Faber, K. Asymmetric
bioreduction of activated C=C bonds using Zymomonas mobilis NCR enoate reductase and old yellow
enzymes OYE 1-3 from yeasts. Eur. J. Org. Chem. 2008, 1511–1516. [CrossRef]
3
3
0. Wolken, W.A.M.; ten Have, R.; van der Werf, M.J. Amino acid-catalyzed conversion of citral: Cis-trans
isomerization and its conversion into 6-methyl-5-hepten-2-one and acetaldehyde. J. Agric. Food Chem. 2000
,
4
8, 5401–5405. [CrossRef]
1. Tsuboi, S.; Ishii, N.; Sakai, T.; Tari, I.; Utaka, M. Oxidation of alcohols with electrolytic manganese dioxide.
Its application fro the synthesis of insect pheromones. Bull. Chem. Soc. Jpn. 1990, 63, 1888–1893. [CrossRef]

Molecules 2019, 24, 1057
15 of 15
3
3
2. Robert, X.; Gouet, P. Deciphering key features in protein structures with the new ENDscript server. Nucleic
Acids Res. 2014, 42, W320–W324. [CrossRef]
3. Hall, M.; Hauer, B.; Stuermer, R.; Kroutil, W.; Faber, K. Asymmetric whole-cell bioreduction of an
α,β-unsaturated aldehyde (citral): Competing prim-alcohol dehydrogenase and C-C lyase activities.
Tetrahedron: Asymmetry 2006, 17, 3058–3062. [CrossRef]
3
3
3
4. Cheng, F.; Tang, X.; Kardashliev, T. Transcription factor-based biosensors in high-throughput screening:
Advances and applications. Biotechnol. J. 2018, 13, 1700648. [CrossRef]
5. Cheng, F.; Zhu, L.; Schwaneberg, U. Directed evolution 2.0: Improving and deciphering enzyme properties.
Chem. Commun. 2015, 51, 9760–9772. [CrossRef]
6. Deng, J.; Yao, Z.; Chen, K.; Yuan, Y.A.; Lin, J.; Wei, D. Towards the computational design and engineering of
enzyme enantioselectivity: A case study by a carbonyl reductase from Gluconobacter oxydans. J. Biotechnol.
2
016, 217, 31–40. [CrossRef]
3
3
3
4
4
4
4
4
4
7. Sullivan, B.; Walton, A.Z.; Stewart, J.D. Library construction and evaluation for site saturation mutagenesis.
Enzyme Microb. Technol. 2013, 53, 70–77. [CrossRef]
8. Valetti, F.; Gilardi, G. Improvement of biocatalysts for industrial and environmental purposes by saturation
mutagenesis. Biomolecules 2013, 3, 778–811. [CrossRef]
9. Yu, M.; Huang, M.; Song, Q.; Shao, J.; Ying, X. Characterization of a (2R,3R)-2,3-butanediol dehydrogenase
from Rhodococcus erythropolis WZ010. Molecules 2015, 20, 7156–7173. [CrossRef]
0. Fox, K.M.; Karplus, P.A. Old yellow enzyme at 2 Å resolution: Overall structure, ligand binding, and
comparison with related flavoproteins. Structure 1994, 2, 1089–1105. [CrossRef]
1. Arnold, K.; Bordoli, L.; Kopp, J.; Schwede, T. The SWISS-MODEL workspace: A web-based environment for
protein structure homology modelling. Bioinformatics 2006, 22, 195–201. [CrossRef]
2. Schwede, T.; Kopp, J.; Guex, N.; Peitsch, M.C. SWISS-MODEL: An antomated protein homology-modeling
server. Nucleic Acids Res. 2003, 31, 3381–3385. [CrossRef]
3. Trott, O.; Olson, A.J. AutoDock Vina: Improving the speed and accuracy of docking with a new scoring
function, efficient optimization, and multithreading. J. Comput. Chem. 2010, 31, 455–461. [CrossRef]
4. Seeliger, D.; de Groot, B.L. Ligand docking and binding site analysis with PyMOL and Autodock/Vina.
J. Comput. Aided Mol. Des. 2010, 24, 417–422. [CrossRef]
5. Breithaupt, C.; Strassner, J.; Breitinger, U.; Huber, R.; Macheroux, P.; Schaller, A.; Clausen, T. X-Ray structure
of 12-oxophytodienoate reductase 1 provides structural insight into substrate binding and specificity within
the family of OYE. Structure 2001, 9, 419–429. [CrossRef]
4
6. Fraaije, M.W.; Mattevi, A. Flavoenzymes: Diverse catalysts with recurrent features. Trends Biochem. Sci. 2000
5, 126–132. [CrossRef]
,
2
Sample Availability: Samples of the compounds are not available from the authors
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
CC BY) license (http://creativecommons.org/licenses/by/4.0/).
(
