Evaluation of a monolith-supported Pt/Al2O3 catalyst for wet oxidation of carbohydrate-containing waste streams

Article abstract of DOI:10.1021/es000887z

Catalytic oxidation of glucose and cellulose has been demonstrated in a monolith reactor, a novel contacting device for the oxidation of carbohydrate feedstocks that allows the processing of nonsoluble components without reactor plugging. Catalytic enhancement is observed for glucose oxidation, and the catalyst promotes selectivity to two-carbon carboxylic acids. It is proposed that catalytic oxidation of glucose occurs through parallel pathways: thermal oxidation to a wide range of organic acids and selective catalytic oxidation to low molecular weight acids. On the other hand, cellulose oxidation was not always enhanced by the presence of the catalyst. Here, the effect of the catalyst was to enhance the conversion of the organic acids produced during thermal oxidation. However, these organic acids also catalyzed the primary conversion of cellulose, thus the conversion of cellulose decreased as the reaction temperature was increased. A kinetic model is provided that is consistent with the inverse temperature effect observed for the cellulose oxidation experiments. Catalytic oxidation of glucose and cellulose has been demonstrated in a monolith reactor, a novel contacting device for the oxidation of carbohydrate feedstocks that allows the processing of nonsoluble components without reactor plugging. Catalytic enhancement is observed for glucose oxidation, and the catalyst promotes selectivity to two-carbon carboxylic acids. It is proposed that catalytic oxidation of glucose occurs through parallel pathways: thermal oxidation to a wide range of organic acids and selective catalytic oxidation to low molecular weight acids. On the other hand, cellulose oxidation was not always enhanced by the presence of the catalyst. Here, the effect of the catalyst was to enhance the conversion of the organic acids produced during thermal oxidation. However, these organic acids also catalyzed the primary conversion of cellulose, thus the conversion of cellulose decreased as the reaction temperature was increased. A kinetic model is provided that is consistent with the inverse temperature effect observed for the cellulose oxidation experiments.

Full text of DOI:10.1021/es000887z

Environ. Sci. Technol. 2000, 34, 3480-3488
Wet oxidation is defined as an aqueous-phase oxidation
Evaluation of a Monolith-Supported
Pt/Al2O3 Catalyst for Wet Oxidation
of Carbohydrate-Containing Waste
Streams
process brought about when an organic and/ or oxidizable
inorganic-containing liquid is mixed thoroughly with a
gaseous source of oxygen (usually air) at temperatures of
150-325 °C. Gauge pressures of 2000-20 000 kPa are
maintained to promote reaction and control evaporation
(3). Elevated temperatures and pressures enhance the
solubility of oxygen and provide a strong driving force for
oxidation.
T R E N T A . P A T R I C K A N D
M A R T I N A . A B R A H A M *
Recent reviews of wet air oxidation describe the chemistry
(4, 5), process technologies (6), and reactor design issues (7)
surrounding this waste treatment process. The liquid effluent
of a wet oxidation process is generally composed of low
molecular weight compounds consisting primarily of car-
boxylic acids and other carbonyl group compounds; CO2
and water are produced as the ultimate end products if the
reaction conditions are severe enough. Both homogeneous
catalysts (particularly soluble copper complexes) and het-
erogeneous catalysts (including copper supported on base
metal oxides) have been used to increase the rate of oxidation
(5). A recent study showed that the catalytic wet oxidation
of acetic acid could be achieved using a Pt/ Al2O3 catalyst
supported on a monolith (2). Two-phase flow within the
channels of the monolith provided a high rate of mass transfer
for oxygen through the liquid phase and to the surface of the
catalyst, thereby enhancing the conversion of the reactant
(8).
Department of Chemical and Environmental Engineering,
The University of Toledo, Toledo, Ohio 43606
Catalytic oxidation of glucose and cellulose has been
demonstrated in a monolith reactor, a novel contacting
device for the oxidation of carbohydrate feedstocks that
allows the processing of nonsoluble components without
reactor plugging. Catalytic enhancement is observed
for glucose oxidation, and the catalyst promotes selectivity
to two-carbon carboxylic acids. It is proposed that
catalytic oxidation of glucose occurs through parallel
pathways: thermal oxidation to a wide range of organic
acids and selective catalytic oxidation to low molecular weight
acids. On the other hand, cellulose oxidation was not
always enhanced by the presence of the catalyst. Here,
the effect of the catalyst was to enhance the conversion of
the organic acids produced during thermal oxidation.
However, these organic acids also catalyzed the primary
conversion of cellulose, thus the conversion of cellulose
decreased as the reaction temperature was increased. A
kinetic model is provided that is consistent with the
inverse temperature effect observed for the cellulose
oxidation experiments.
Selective oxidation (for example, the conversion of glucose
to gluconic acid) can be achieved through the use of
supported noble metal catalysts (9) and mild reaction
temperatures. Wet oxidation of glucose at 110-140 °C in a
neutral solution obtained conversions up to 40% and yielded
a diverse set of reaction products including gluconic acid,
glucaric acid, glucosone, 5-ketogluconic acid, arabonic acid,
and various products with 4 or less carbon atoms (10). In one
case (11), the conversion and the rate of catalyst deactivation
were shown to be dependent upon the pH of the solution,
but the selectivity to gluconic acid was relatively independent
of pH. Palladium supported on alumina was more active
than palladium on activated carbon for the conversion of
glucose to gluconic acid at 55 °C and yielded complete
conversion in only 2 h (12).
Introduction
As the duration of human occupied space missions becomes
longer, the current method of taking the essential elements
needed to sustain life becomes increasingly less feasible. As
a result, processes for the regeneration of air, water and food
need to be designed using a combination of physicochemical
and biological technologies. Such a system, known as a
controlled ecological life support system (CELSS), is closed
to mass transfer with its surroundings (1).
A CELSS is defined as a life support system that relies
heavily on biological subsystems for recycling (2). In a CELSS,
a system must be developed that combines the photosyn-
thetic activity of plants with physicochemical processes to
regenerate waste material into food and oxygen for a crew
(1). One such process under investigation to regenerate waste
material is catalytic wet oxidation. The main advantages of
wet air oxidation in a CELSS environment are the recovery
of useful water and the reduction of solid wastes to a very
small volume and weight of sterile, nondegradable ash. In
addition to that, other advantages include the production of
carbon dioxide and residual aqueous inorganic matter that
can be used as plant nutrients and the comparatively low
energy requirements, since water does not have to be
evaporated (2).
Although much experimental work has been correlated
using pseudo-first-order kinetics, a more detailed reaction
sequence (13) has emerged that successfully captures the
complex nature of the reaction process. The feedstock is first
converted to organic intermediates, acetic acid, or CO2
through parallel reaction pathways. The organic intermedi-
ates are unstable and are rapidly converted to acetic acid or
CO2. The acetic acid is relatively stable and is only converted
to CO2 if the reaction conditions are sufficiently severe. A
kinetic model based on these reaction pathways has now
been developed (14), and the model has also been extended
for use with heterogeneously catalyzed systems (15).
Solid waste in a CELSS includes human fecal waste,
packaging waste from food products, inedible plant biomass,
food system wastes, and other subsystems waste products,
such as salts, filters, and media. One common feature of all
the solid waste in a CELSS is the high fiber content, most of
which is cellulose. The current research effort focused on
the catalytic wet oxidation of glucose and cellulose using the
monolith catalyst previously shown to be effective. These
two model chemicals were chosen because they are common
products of the biomass conversion pretreatment step, acid
hydrolysis.
* Corresponding author tel: (419)530-8092; fax: (419)530-8086;
e-mail: mabraham@eng.utoledo.edu.
9
3 4 8 0 ENVIRONMENTAL SCIENCE & TECHNOLOGY / VOL. 34, NO. 16, 2000
10.1021/es000887z CCC: $19.00
2000 Am erican Chem ical Society
Published on Web 07/14/2000

FIGURE 1. Schematic diagram of experimental system.
