Tailoring the structure and acid site accessibility of mordenite zeolite for hydroisomerisation of n-hexane

Article abstract of DOI:10.1016/j.apcata.2018.05.035

Mordenite zeolites with diffusion-restricted access to the acid sites located in mono-dimensional 12-ring channels and 8-ring side pockets have found broad applications as catalysts for hydroisomerisation of linear C₅ and C₆ alkanes and other highly relevant acid-catalysed processes. The accessibility of the porous structure of mordenite (MOR) zeolite is traditionally enhanced by dealumination, but this is invariably connected with a dramatic reduction in the aluminium content and corresponding concentration of the acid sites in the zeolites. Here we describe the preparation of MOR zeolite with high micropore volume, three-dimensional supermicropores (d ～ 7.5 ?) and good acid site accessibility by concurrent extraction of Si and Al using postsynthesis fluorination-alkaline-acid treatment. The concurrent extraction of Si and Al enables formation of more developed supermicroporous structure and preservation of the molecular Si/Al. The procedure yields MOR with a crystalline structure in which the Si/Al ratio and the micropore volume can be tailored (Si/Al from ～ 6, V_MI up to 0.25 cm³.g^?1) by the chemical conditions of the treatment. The Al-rich 3D supermicroporous structure with accessible Br?nsted and Lewis active sites provides strongly enhanced activity, selectivity and long-term catalytic stability in the transformation of n-hexane into the corresponding branched isomers.

Full text of DOI:10.1016/j.apcata.2018.05.035

Accepted Manuscript
Title: Tailoring the structure and acid site accessibility of
mordenite zeolite for hydroisomerisation of n-hexane
Authors: Jana Pastvova, Radim Pilar, Jaroslava Moravkova,
Dalibor Kaucky, Jiri Rathousky, Stepan Sklenak, Petr Sazama
PII:
S0926-860X(18)30265-5
DOI:
Reference:
https://doi.org/10.1016/j.apcata.2018.05.035
APCATA 16684
To appear in:
Applied Catalysis A: General
Received date:
Revised date:
Accepted date:
31-1-2018
14-5-2018
28-5-2018
Please cite this article as: Pastvova J, Pilar R, Moravkova J, Kaucky D, Rathousky J,
Sklenak S, Sazama P, Tailoring the structure and acid site accessibility of mordenite
zeolite for hydroisomerisation of n-hexane, Applied Catalysis A, General (2018),
https://doi.org/10.1016/j.apcata.2018.05.035
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Tailoring the structure and acid site accessibility of mordenite zeolite for
hydroisomerisation of n-hexane
Jana Pastvova1, 2, Radim Pilar1, Jaroslava Moravkova1, Dalibor Kaucky1, Jiri Rathousky1,
Stepan Sklenak1, Petr Sazama*1
1J. Heyrovsky Institute of Physical Chemistry, Academy of Sciences of the Czech Republic,
Dolejskova 3, 182 23 Prague, Czech Republic, *E-mail: petr.sazama@jh-inst.cas.cz
2University of Pardubice, Studentska 95, Pardubice, 532 10, Czech Republic
Graphical abstract
Highlights

The acid sites located in mono-dimensional 12-ring channels and 8-ring side pockets of
mordenite zeolites are diffusion-restricted.

Concurrent extraction of Si and Al by postsynthesis treatment of Al-rich mordenite provides
three-dimensional supermicroporous (d ~ 7.5 Å) channel structure with high accessibility of
the acid sites.


The Al-rich supermicroporous mordenites with accessible active sites provide strongly
enhanced activity, selectivity and long term catalytic stability in the hydroisomerization of n-
hexane.
The concept of the concurrent extraction of Si and Al provides opportunities for the creation
of accessible acid sites in Al-rich zeolites for variety of diffusion-restricted reactions.
1

Abstract:
Mordenite zeolites with diffusion-restricted access to the acid sites located in mono-
dimensional 12-ring channels and 8-ring side pockets have found broad applications as
catalysts for hydroisomerisation of linear C5 and C6 alkanes and other highly relevant acid-
catalysed processes. The accessibility of the porous structure of mordenite (MOR) zeolite is
traditionally enhanced by dealumination, but this is invariably connected with a dramatic
reduction in the aluminium content and corresponding concentration of the acid sites in the
zeolites. Here we describe the preparation of MOR zeolite with high micropore volume, three-
dimensional supermicropores (d ~ 7.5 Å) and good acid site accessibility by concurrent
extraction of Si and Al using postsynthesis fluorination-alkaline-acid treatment. The
concurrent extraction of Si and Al enables formation of more developed supermicroporous
structure and preservation of the molecular Si/Al. The procedure yields MOR with a
crystalline structure in which the Si/Al ratio and the micropore volume can be tailored (Si/Al
from ~ 6, VMI up to 0.25 cm3.g-1) by the chemical conditions of the treatment. The Al-rich 3D
supermicroporous structure with accessible Brønsted and Lewis active sites provides strongly
enhanced activity, selectivity and long-term catalytic stability in the transformation of n-
hexane into the corresponding branched isomers.
Keywords: Isomerisation; n-hexane; mordenite (MOR) zeolites; supermicroporosity;
micromesoporous structure
2

1. INTRODUCTION
The catalytic hydroisomerisation of linear C5 and C6 alkanes as an integral part of the
production of automotive gasoline has become a process performed on an impressively large
scale. While the chlorinated catalysts in the other large-scale catalytic acid-catalysed
processes have been displaced by catalysts based mainly on zeolites, environmentally
problematic chlorinated catalysts are still predominantly used in the hydroisomerisation
process for their superior activity exceeding that of zeolite catalysts [1, 2]. The high activity
of chlorinated catalysts allows performance of the hydroisomerisation process at low
temperatures (about 150 °C), where the thermodynamic equilibrium is inclined towards the
desired multi-branched isomers with high octane number [2]. In contrast, the relatively low
zeolite activity means that the reaction must be performed at much higher temperatures (250-
300 °C) where, for thermodynamic reasons, the proportion of the two-branched and mono-
branched isomers is insufficiently low for modern high-octane automotive fuels [2]. Although
besides problematic chlorinated alumina based catalysts, some perspective alternatives were
in parallel developed, these still suffer considerable disadvantages. Tungstated zirconia could
show
enhanced
low-temperature-activity
but
still
suffer
from
unsolved
deactivation/regeneration, which hinder their large-scale application [3]. Strongly acidic
sulphated zirconia provides a lower reaction rate compared to chlorinated alumina [4, 5].
Previous studies have shown that the activity of zeolites in n-hexane hydroisomerisation is
controlled by interplay of the concentration of the acidic centres and accessibility of the acid
sites for the n-hexane molecule in the micropore reaction space, allowing effective formation
of the transition state [6-8]. The high concentration and proximity of Brønsted sites facilitate
synergistic effects that substantially shift the conversion to the lower temperature range
important for the formation of di-branched isomers with a high octane number [9].
Zeolites with mordenite structure are among the most active and selective zeolite
catalysts reported in the literature and are used in industrial catalytic processes [6, 10-14]. A
high concentration of acidic centres in a zeolite with mordenite structure is readily available
due to the synthesis of mordenite zeolites with high Al content in the structural framework
(Si/Al ~5) [15]. However, the accessibility of the acid sites in the channel system of the
mordenite zeolite comprising monodimensional straight channels with twelve-membered ring
(12-ring) openings and side pockets with 8-ring openings is diffusion-restricted [7, 9-11, 14].
The small size of the opening of the side pockets (2.6 Å × 5.7 Å) and the kinetic diameters of
linear (4.3 Å), mono-branched (5.0 Å - 5.6 Å) and di-branched (5.8 Å – 6.2 Å) hexane
3

isomers limit the accessibility of the acidic centres in the side pocket [9, 11, 15-17]. The
openings of the main channel (6.5 Å × 7.0 Å) allow for easy interaction of all the hexane
isomers with acid sites located in the main channel; however, the monodimensional channel
limits molecular transport and the long residence time reduces the selectivity of the reaction
due to side cracking reactions that lead to the formation of undesired C1-C4 molecules [9]. An
increase in the accessibility of acidic centres in MOR catalysts can be easily achieved by
partial dealumination. The hydrolysis of the Al-O-Si bond and the extraction of the Al atom
from the framework during dealumination yield large deformed elongated rings or merging of
the two 8-rings, providing a large void space depending on the T site of the extracted atom
[9]. The formation of these secondary micropores enables the diffusion of large molecules to
the active sites [18]. However, the decrease in the concentration of aluminium in the
framework is associated with a significant decrease in the concentration of acidic Brønsted
sites limiting the activity of the resulting catalyst.
In the present study, we attempted to create mordenite zeolites with enhanced activity
for hydroisomerisation of n-hexane that contain a high concentration of aluminium and
corresponding concentration of acid sites readily accessible for the hexane molecules. For this
purpose, we modified the structure of mordenite zeolite with a high content of lattice
aluminium (Si/Al 5.8) by postsynthesis concurrent extraction of Si and Al atoms from the
framework using fluorination-alkaline-acid treatments. This modification provides an increase
in the dimensions of the channel openings, enlargement of the micropores, 3D interconnection
of the micropores as well as the formation of acidic sites with enhanced activity. The
combination of the super-mesoporosity and the occurrence of highly active acidic sites
dramatically increase the activity of mordenite zeolites in the hydroisomerisation of n-hexane
to its branched isomers. The high activity shifts the window of operating temperatures to the
thermodynamically more suitable area for the formation of di-branched isomers.
2. EXPERIMENTAL
2.1.Preparation of MOR zeolites
Mordenite zeolite (Zeolyst Int., CBV 10A molar Si/Al 5.8), denoted as MOR/5.8, was used
for preparation of mordenites with enhanced accessibility of micropores using postsynthesis
fluorination-alkaline-acid leaching procedures (Figure 1). MOR/5.8 was treated by
fluorination-alkaline leaching with various concentrations of NH4F and NaOH and
subsequently by mild dealumination. Typically, 5 g of MOR zeolite was impregnated with 15
4

ml aqueous solutions of NH4F at room temperature, kept at RT for 8 h and was then dried at
120 °C for 12 h and calcined at 550 °C for 3 h. The alkaline treatments were applied to the
fluorinated zeolites (1 g of fluorinated MOR per 30 ml NaOH solution stirred in a beaker at a
temperature of 85 °C for 30 min). Prepared catalysts are denoted as MOR-XF/Y, where X is
the concentration of NH4F and Y is the molar ratio of Si/Al. In the 1st series, concentrations of
0.36 M NH4F and 0.2 M NaOH solutions were used and the sample was denoted as MOR-
0.36F/5.7. The 2nd series was prepared using 0.5 M NH4F and 0.4 M NaOH solutions and the
sample denoted as MOR-0.5F/5.6. 1 M NH4F and 0.4 M NaOH solutions were used for
preparation of the 3rd series and the sample was denoted as MOR-F/5.4. The 4th series was
prepared using 4 M NH4F and 0.4 M NaOH solutions and the sample was designated as
MOR-4F/6.2. Finally, after fluorination and alkaline treatment, the samples were mildly
dealuminated by adding 30 ml of 0.1 M HNO3 per 1 g prepared MOR at 50 °C for 15 min and
were designated as deAl-MOR-0.36F/7.0, deAl-MOR-0.5F/6.5, deAl-MOR-1F/6.8 and deAl-
MOR-4F/6.9, respectively. For the 5th series, the parent MOR zeolite was treated only by
dealumination with HNO3 (1 g parent MOR zeolite was added to 30 ml 0.1 M HNO3 at 50 °C
for 15 min) and the sample was denoted as deAl-MOR/6.6. 100 ml 0.5 M NH4NO3 was
employed per 1 g zeolite at RT (three times over 12 h) to obtain the ammonium form of the
zeolites. To obtain the hydroisomerisation catalysts, Pt was introduced into the NH4-form of
the MOR zeolites. Pre-dried (at 105 °C for 2 h) powder samples were impregnated with an
H2PtCl6 solution to yield 1.5 wt. % of Pt. The amount of distilled water used for preparation
of the impregnation solutions corresponded to the porous volume of each zeolite and was
typically in the range 0.5 - 1.0 cm3.g-1.
2.2.Structural and textural analysis
The diffraction patterns of the zeolites were collected on the Bruker AXSD8 Advance
diffractometer (Bruker, U.S.A.) with Cu Kα radiation with a graphite monochromator and a
position sensitive detector (Våntec-1) in Bragg–Brentano geometry. The chemical
compositions of the parent and prepared Pt-zeolites were determined by X-ray fluorescence
spectroscopy using a Performix XRF-spectrometer (Thermo ARL, Switzerland). The samples
were measured and evaluated using UNIQUANT5 software. The texture parameters of
modified zeolitic materials were determined from the analysis of the N2 adsorption isotherms
at the boiling point of liquid nitrogen (77 K) using the Micromeritics ASAP 2010 apparatus
and of the Ar adsorption isotherms at the boiling point of liquid nitrogen (77 K) using the
5

Micromeritics 3Flex system. Prior to the adsorption measurements, the samples were
outgassed at 240 °C for 24 hours. The micropore volume was determined by the Broekhoff-de
Boer t-plot method. In this method, the isotherm of nitrogen at 77 K for the studied sample is
compared with a suitable standard isotherm, which is explicitly expressed by a thickness
equation as representative of layer thicknesses on comparable type of material. In the
derivation of the thickness equation, Broekhoff and de Boer related the thickness of the
adsorbed film to the total chemical potential of the adsorbed layer rather than assuming
thickness to be solely dependent on relative pressure [19]. The total pore volume (Vtot) was
obtained from the adsorption at a relative pressure of 0.8 converted to the corresponding
volume of liquid nitrogen. A relative pressure of 0.8 should ensure the complete filling of the
pores by N2 and, at the same time, this pressure is low enough to avoid substantial
condensation of nitrogen in the interstitial space between zeolite particles. The mesopore size
distribution was calculated using DFT method based on a model for the adsorption of nitrogen
on oxidic surfaces. The Ar adsorption isotherms at the boiling point of liquid nitrogen were
employed for the analysis of the micropore size distribution, as the spherical molecule of Ar is
more suitable for analysis of sub-nanometer microporous texture than diatomic molecules of
nitrogen with a quadrupole moment. Micropore size distribution was calculated by the
Horwath-Kawazoe method used in the Saito-Foley extension to cylindrical pores applicable to
zeolite studies. The Cheng-Yang correction for the non-ideality of the two-dimensional
behaviour of the adsorbed gas was taken into account. In the Horwath-Kawazoe expansion of
the model of Everett and Powl describing the potential energy of a single adsorbate molecule
confined in a pore, the space in the pore is assumed to be filled with adsorbate molecules [19].
In the case of a filled pore adsorbate-adsorbate-adsorbent interaction contributes a potential in
addition to the adsorbate-adsorbent interaction. By averaging the potential over the space
within the pore an expression for average interaction energy is obtained, which provides the
relationship between the relative equilibrium pressure of the adsorbate and the pore width.
Later on, Saito and Foley extended the Horwath-Kawazoe approach by using a cylindrical
potential to obtain a method better applicable to studies of zeolites. Finally Cheng and Yang
corrected the non-linearity of the adsorbed gas which was not included in the original
Horwath-Kawazoe equation [19]. All the methods used were performed using Micromeritics
software. As the adsorption experiment using argon were carried out at a temperature of the
boiling point of liquid nitrogen, about 10 K below the boiling point of liquid argon, the total
pore volume determined from the argon isotherms was corrected. According to the Gurvitsch
rule, the volume of liquid condensed in the pores of a porous solid from a condensable gas
6

near its saturation vapour pressure is equivalent to the volume of the pores and should be
practically the same for different adsorptives [19]. Therefore, the adsorption isotherms of
argon were normalised by multiplying the Ar adsorption by the ratio of total pore volumes
Vtot N2/Vtot Ar. The mesoporous volume VME and surface area were also calculated from the Ar
adsorption isotherms. A Hitachi S-4800 scanning electron microscope (Hitachi, Japan) was
used to obtain the SEM images. The HR-TEM micrographs were obtained on a JEM 3010
microscope (JEOL, Japan) equipped with a LaB6 cathode, operated at 300 kV. Before
analysis, MOR zeolite samples were calcined at 500 °C in the air and subsequently reduced in
a stream of H2 at 250 °C. The FTIR spectra of the H-forms of the zeolites were measured on a
Nicolet nexus 670 FTIR (Thermo Nicolet Co., U.S.A.). Self-supporting wafers were made
from the MOR zeolite samples and inserted into the metal holder in the IR cell. The wafers of
zeolite samples were evacuated at 450 °C maintained for 3 h and then recorded at RT by
collecting 256 scans at 2 cm−1 resolution for each spectrum. CD3CN was used as a molecular
probe for analysis of the concentration of Brønsted and Lewis acid sites. CD3CN was
adsorbed at a partial pressure of 10 Torr for 20 min at RT and subsequently desorbed for 15
min at RT. The resulting IR spectra of the stretching C≡N vibrations and the extinction
coefficients 휀B = 2.05 cm.μmol-1 and 휀L = 3.60 cm.μmol-1 were used for calculations of the
acidic Brønsted and Lewis site concentrations [16]. The accessibility of the OH groups for n-
hexane in the MOR zeolites was measured using the adsorption of n-hexane. The n-hexane
was adsorbed on the dehydrated samples at a vapour pressure of 1.4 Torr for 20 min at RT
with gradual desorption to 0.005 Torr at RT. The accessibility of the OH groups in the MOR
zeolite samples was determined by subtracting the intensity of the absorption bands of the
stretching vibration mode of the OH in the spectra of dehydrated MOR before and after
adsorption of n-hexane. Details of the method are described elsewhere [8]. Information on the
oxidation and coordination states of Pt particles in the zeolite was obtained using the method
of CO adsorption as a molecular probe in FTIR spectroscopy. Before adsorption of CO, the
zeolite samples were heated at 450 °C for 1 h and then activated by reduction in H2.
Hydrogenation of the zeolite samples was performed by gradually heating the sample from
RT to 250 °C, which was maintained for 1 h. Subsequently, the samples of Pt/H-MOR zeolite
were evacuated and CO was introduced for 30 min. Finally, the IR cell with the samples was
27
degassed and the spectra were recorded at RT. The solid state Al MAS NMR method was
used for characterisation of the Al species with different coordination in the zeolite. The
experiments were performed on a Bruker Avance 500 MHz Wide-Bore spectrometer (Bruker,
27
U.S.A.) equipped with a 4 mm double-resonance MAS NMR probe head. The Al MAS
7

NMR spectra of the fully hydrated samples were measured with a high-power decoupling
pulse sequence with a p/12 (0.7 µs) excitation pulse, 1 s relaxation delay and rotation speed of
12 kHz. The chemical shifts were referred to an aqueous solution of Al(NO3)3.
2.3.Hydroisomerisation of n-hexane
The catalytic activity in hydroisomerisation of n-hexane to the corresponding iso-C6 isomers
was measured in a U-shaped glass through-flow reactor with catalyst loading of 0.5 g on a
porous glass septum. The reactants were preheated in spiral tubing in the inlet part of the
reactor. Before each catalytic experiment, activation of the Pt/MOR-zeolite was carried out in
an oxygen stream at 450 °C for 3 h and then the zeolite was cleaned with pure nitrogen for 15
min. After calcination, the temperature was lowered to 250 °C and the catalyst was reduced in
a mixture of 80 mol % H2 + 20 mol % N2 at 250 °C for 1 h. Then 1 mol % of n-hexane was
fed into this mixture using a glass saturator kept at the selected temperature. The total gas
flow was set at 66 cm3.min-1, corresponding to GHSV 5 000 and WSHV 0.25 h-1. The reactor
temperature was kept in the desired range of 125 – 325 °C, controlled by an inserted K-
thermocouple. The reaction products containing n-C6, iso-C6 and low molecular products (i.e.:
C1, C2, C3, C4 and iso-C4, C5 and iso-C5) were analysed by an on-line connected GC (Finnigan
9001), equipped with a capillary column (type: Al2O3/KCl, dimensions: length×inner
diameter×inner layer: 50m×0.32mm×5m) and conventional FID detector. He 5.0 purity as
carrier gas for the column (with input pressure 4.2 atm and flow rate 1.2 cm3.min-1 STP) was
used. The following temperature program was used: Temperature range 40 - 100°C with the
heating rate 2.5°C.min-1, then 100 - 180°C with rate 5 °C.min-1, and 180 – 200 °C with rate
7.5 °C.min-1. A steady-state regime was typically attained during approx. 0.5 - 1 h of time-on-
stream.
3. RESULTS AND DISCUSSION
3.1.Structural Analysis
3.1.1. Formation of supermicroporous structure in mordenite zeolites
The well-developed crystalline structure of parent MOR/5.8 is manifested by smooth lattice
fringes in a representative HR-TEM image (Figure 2A), high intensities of the characteristic
lines in the X-ray diffractogram without impurity phases (Figure 3), a micropore volume of
0.16 cm3.g-1 (Table 1) and size distribution of the micropores corresponding to the mordenite
8

structure (Figure 4). Fluorination-alkaline treatment (Figure 5) resulted in a slight decrease in
the intensity of the diffraction lines associated with reducing the density of the structural
framework and slight roughness of the lattice fringes of the crystalline structure in the HR-
TEM images. Use of fluorination-alkaline treatment with concentrations of 0.36 M NH4F in
the 1st and 0.5 M NH4F in the 2nd series resulted in an increase in the micropore volume to
about 0.2 cm3/g, with a further increase after mild dealumination to 0.23 and 0.24 cm3/g,
respectively, with only minor creation of mesopores with a volume of 0.05 and 0.06 cm3/g,
respectively, also visible at the HR-TEM images. In the first series, the micropore volume is
increased mainly by an increase in the number of micropores with dimensions of about 0.7
nm. This enhancement could be ascribed to enlargement of the narrow openings of the 8-ring
channels. It is also reflected in an increase in the accessibility of the OH groups in the 8-ring
channels for the n-hexane molecule in the originally inaccessible pores (see the FTIR analysis
par. 3.1.2). In the 2nd series, the mean pore diameter of the micropores is also increased. A
procedure using the fluorination-alkaline treatment was developed by Yu et al. [20] to form a
micro-mesoporous structure in the ZSM-5 zeolite with relatively high content of Al in the
framework Si/Al ~ 15. The introduction of NH4F into microporous ZSM-5 zeolite leads to the
formation of F-bearing tetrahedral Al species which are readily dislodged in the subsequent
alkaline treatment [20], leading to concurrent extraction of Al and Si. In our previous study
[9], we demonstrated the development of secondary mesoporosity and preservation of
microporosity via concurrent extraction of SiO2 and a smaller amount of Al using the
fluorination-alkaline treatment of MOR zeolite Si/Al ~ 12. The significant increase in the
micropore volume, the increase in the size of some micropores and only minor formation of
mesopores observed for the samples in series 1 and 2 prepared from Al-rich MOR (Si/Al ~
5.8) show that a high concentration of Si-O-Al in the framework increases the resistance to
alkaline treatment, as also reported for ZSM-5 [21]. The degree of susceptibility of the parent
MOR/5.8 zeolite towards alkaline leaching after fluorination results in controlled concurrent
extraction of both Al and Si atoms, indicated by comparable Si/Al compositions before and
after leaching (Table1), leading to desirable development of the microporosity without
excessive formation of mesopores. The effect of the extraction of two neighbouring Al and Si
atoms from the walls of the zeolite channels of MOR zeolite on the micropore structure is
illustrated in Figure 6A (for analysis of the local changes in the structure, see par. 3.1.2). It is
obvious that the simultaneous extraction of Al and Si pairs from the MOR framework leads to
enlargement and interconnection of the micropores (Fig. 1 and 2).
9

The fluorination-alkaline treatment with a concentration of 1M NH4F resulted in a
decrease in the micropore volume compared to the parent zeolite, but the subsequent mild
acid leaching increased the micropore volume to 0.24 cm3.g-1. The preserved lattice fringes in
the HR-TEM images and the intensity of the X-ray diffraction pattern of the zeolite after the
fluorination-alkaline treatment are indicative of the preservation of the crystalline structure.
Previous studies showed that hydrolysis of framework Al under harsh conditions of
desilication leads to the formation of extraframework Al species which can easily block the
openings in the pseudo-monodimensional channel structure of MOR [9, 22]. A slight increase
in the molar Si/Al ratio (Table 1) and the significant increase in the micropore volume after
mild acid leaching indicate that the extraframework Al blocking part of the micropores was
removed. The size distribution of the micropores indicates a further increase in their
dimensions associated with supermicroporosity and 3D interconnection of the
monodimensional mordenite channels [8, 10, 11, 14, 23].
The harshest fluorination treatment by 4 M NH4F in the 4th series led to partial
destruction of the crystalline structure, manifested in a significant decrease in the XRD
intensity, negligibly low adsorption of N2 in fluorination-alkaline treated sample MOR-4F/6.2
and only partial restoration of the micropore volume of deAl-MOR-4F/6.9 after mild acid
treatment (Table 1). The 5th series was prepared by acid treatment of MOR/5.8 providing
mildly dealuminated deAl-MOR/6.6. The size distribution of the micropores determined by
Ar adsorption clearly show their enlargement compared to MOR/5.8 The increase in the sizes
and improvement of the connectivity of the micropore channels resulting from the extraction
of Al from the framework have been described in the literature [23-25]. An addition to these
desirable structural changes, a small decrease in the micropore volume could indicate the
partial blockage of some micropores.
The adsorption measurements supplemented by the HR-TEM images and the X-ray
diffractograms show the concurrent extraction of Al and Si by fluorination-alkaline-acid
treatment of Al-rich MOR essentially alters the monodimensional structure with poorly
accessible side pockets into a supermicropore channel structure characterised by high
micropore volume (up to 0.25 ml.g-1) formed by accessible internal voids with mean diameter
of about 7.5 Å.
3.1.2. Concentration, nature and accessibility of acid sites in supremicroporous
mordenites
27Al MAS NMR analysis
10

Figure 7 compares the 27Al MAS NMR spectra of MOR zeolites before and after fluorination-
alkaline-acid (Series 1 - 3) and acid (Series 5) treatments. A symmetric signal at 56 ppm
associated with tetrahedrally coordinated aluminium (AlTd) in the zeolite framework is
27
observed in the Al MAS NMR spectrum of the parent MOR/6 sample. The high symmetry
of the signal is a result of the symmetrical local environment of the tetrahedral framework Al
sites in the hydrated zeolite mitigating the quadrupolar couplings. The postsynthesis
fluorination-alkaline and acid leaching lead to a broadening and shift in the maxima of the
main signal to approx. 54 ppm, the formation of an asymmetric signal of high intensity at
about 40 ppm, a barely visible signal of weak intensity at 30 ppm, and the appearance of a
signal at 0 ppm. The shift in the maximum of the signal of the Td coordinated Al is an
indication of the preferable extraction of Al atoms located in specific T sites. This
interpretation is consistent with previous studies of the acid leaching of MOR zeolites, which
exhibited preferential dealumination of the T4 site [18, 26, 27]. In the literature [7, 9, 28-34],
the signal at about 40 ppm is ascribed to perturbed Al in the framework in a less ordered
27
environment and/or Al species partly removed from the framework. The combination of Al
(1H) REDOR (3Q) MAS NMR and 27Al (1H) CP (3Q) MAS NMR experiments and
DFT/Molecular computations in our previous study [30] showed that the shoulder at 40 ppm
is associated with a perturbed framework Al in the (SiO)3AlOH groups (δi = 59 – 62 ppm, CQ
= 5 MHz, and η = 0.3 – 0.4). The low local symmetry of the group results in the appearance
of a highly asymmetric signal visible as a shoulder on the main signal. The weak signal
observed around 30 ppm was assigned to traces of penta-coordinated extra-framework Al
species [17]. The signal at 0 ppm is associated with octahedrally coordinated extra-framework
Al. The perturbed framework tetrahedrally coordinated Al, the penta-coordinated and
tetrahedral extra-framework Al manifested in the shoulder at 40 ppm and the signals at 30 and
0 ppm, respectively, were often observed in faujasite or high-silica zeolites after steaming
[32-37]. The penta-coordinated and octahedral extra-framework Al could be present in the
form of positively charged oxo/hydroxo moieties (AlO+·nH2O, AlOH2+·nH2O) compensating
the negative charge of the MOR framework or neutral Al(OH)3·nH2O, Al2O3·nH2O or
AlOOH·nH2O species (Figure 1) [38]. The changes observed in the spectra after the
fluorination-alkaline treatment are thus associated with partial extraction of Al preferentially
from the T4 sites in the framework, the formation of a significant proportion of perturbed
framework Al in the (SiO)3AlOH groups and the formation of a limited amount of extra-
framework Al species of various structures. Comparison of the 27Al MAS NMR spectra of the
samples from series 1 to series 3, prepared with increasing concentrations of the agents used
11

for fluorination-alkaline treatments (Figure 7), reveals a considerable increase in the intensity
of the shoulder at about 40 ppm and broadening of the signal at 0 ppm with increasing
harshness of the treatment, indicative of an increase in the proportion of the perturbed
framework Al in the (SiO)3AlOH groups and greater distortion of the local environment of the
extra-framework Al species, respectively.
Similar changes in the 27Al MAS NMR spectra of MOR/5.8 after acid leaching (deAl-
MOR/6.6, Series 5.) and observed after fluorination-alkaline treatments (Series 1 - 3) indicate
the formation of similar Al species after both the fluorination-alkaline treatment and the acid
treatments. The decrease in the Al concentration (Table 1) and decrease in the intensity of the
bands of the perturbed and extra-framework Al in the spectra of the acid-treated deAl-MOR-
0.36F/7.0 sample compared to MOR-0.36F/5.7 (series 1) clearly show that the acid leaching
results in concurrent dislocation of the framework Al and extraction of all the defective forms
of the Al species from the zeolite. The gradual dislocation and extraction of Al from the
zeolite framework and related structural changes in the MOR zeolites following acid
treatment have been described in detail in the scientific literature [23-25].
FTIR analysis
Figure 8 depicts the FTIR spectra of MOR zeolites before and after fluorination-alkaline-acid
treatment (Series 1 – 3), and also simple acid (Series 5) treatments, as manifested before and
after d3-acetonitrile adsorption experiments. The spectra of the samples of all the series
display a typical asymmetrical shape of the band in the OH region with a dominant band at
3610 cm-1 and a clearly defined sideband at lower wavenumbers. This shape of the spectra,
characteristic for MOR, was already explained by Wakabayashi et al. [39] and Zholobenko et
al. [40] and assigned to an OH bond located in the main 12-ring channels, and the low-
frequency component near 3590 cm-1 was attributed to OH in the smaller side pockets with an
8-ring, and connected with the T3 site [39]. Further analysis substantiated this interpretation
and some effort was devoted to use this analysis for semi-quantitative evaluation of both
structures. Despite some controversies in this respect, we used the recommendation of
Makarova [40] for the semi-quantitative evaluation, yielding a ratio of extinction coefficients
of the 12 OH / 8 OH bands of about 1.5. Semi-quantitative analysis of the acidity of the
analyzed samples was based on the results of the d3-acetonitrile adsorption experiments, using
the extinction coefficient for d3-acetonitrile interacting with the Lewis acid sites as 휀L = 3.60
cm.μmol-1, and 휀B = 2.05 cm.μmol-1 for d3-acetonitrile interacting with the OH [16].
12

The FTIR spectra of the parent MOR/5.8 sample represent typical spectra of well-
developed MOR zeolites with relatively high-intensity bands in the region of the Brønsted
OH, with a dominant band at 3610 cm-1, i.e. at the position of OH located in the 12-ring, and
the relatively less intense side band at 3590 cm-1 of the OH in the 8-ring. Based on the
quantitative analysis, the relative contents of the two 12 OH / 8 OH structures in the parent
zeolite equaled about 2. The small intensity of the band of the terminal OH (a band at about
3745 cm-1) and negligible structure indicated at the position typical of AlOH with the band at
3660 cm-1 further demonstrated the regularity of the parent MOR. The results of the
adsorption of d3-acetonitrile provided data for semi-quantitative evaluation of the Brønsted (a
band at 2286 cm-1) and two distinguished Al-related Lewis acid sites (with bands at 2313 and
2323 cm-1). Analysis of the spectra in the OH region demonstrated that, after the d3-
acetonitrile adsorption/partial desorption procedure, most of the terminal SiOH were free of
the d3-acetonitrile while, at the same time, full interaction with both the OH groups located in
the 12-ring and 8-ring was achieved. Accordingly, the d3-acetonitrile spectra could have been
used for the semi-quantitative analysis of the concentration of both OH and the Lewis sites.
The relatively intense additional band at 2280 cm-1 with a shoulder at about 2277 cm-1 was
assigned to the d3-acetonitrile molecule interacting with structurally undefined defects in the
MOR structure and a small part of the terminal SiOH, which was not fully reconstructed
during the mild desorption of the d3-acetonitrile. It should be noticed that the band at 2280
cm-1 was much less intense in the previous experiments over MOR (Si/Al ~ 12) with lower Al
content in the previous study [8].
Generally, all the MOR samples after the postsynthesis fluorination-alkaline and acid
leaching displayed some uniform features with a decrease in the total OH bands and well-
expressed change in the relative ratio of the 12/8-ring structures. For all the samples, the
treatments led to a steep increase in the intensity of the Lewis band at about 2323 cm-1. It
seemed significant that both the acid (Series 5) and combined treatments (Series 1 – 4)
induced elimination of the 2280 cm-1 band, assigned to unspecified defect structures present
in the parent zeolite.
Some indication on the presence and relative concentration of the AlOH structures
indicated by the IR band in the 3 660 cm-1 region could be gained, suggesting the formation of
this structure after the combined treatment and not fully regularly decreasing again after acid
treatment. These results are to some extent consistent with previous studies on the acid
leaching of MOR zeolites, which indicated preferential dealumination of the T4 site
connected to the 12-ring [18, 26, 27] and accordingly relatively higher stability of the 8-ring
13

sites, connected with the T3 site [41]. The same could be indicated for the formation of the
perturbed Al species, connected either to the Al-related Lewis positions or to the AlOH
structure. All these structures could be regarded as perturbed Al sites in the framework in a
less ordered environment and/or Al species partly removed from the framework.
The changes in the FTIR spectra observed either before or after the d3-acetonitrile
adsorption/desorption cycle of the samples exposed to fluorination-alkaline treatment thus
indicate partial extraction of Al from the framework preferentially from the 12-ring sites and
formation of perturbed framework Al groups and some amount of extra-framework Al
species, including Al-related Lewis species. Increasing the concentrations of the agents used
for fluorination-alkaline treatments (Figure 7) led to an increase in the Al elimination process
going from Series 1 to 3. The changes in the spectra of the MOR in Series 5 were rather
similar, indicating similar production of Al species after both fluorination-alkaline treatment
and acid treatments but with much smaller formation of the (SiO)3AlOH groups after acid
treatment.
3.1.3. Summary of structural features of supermicroporous mordenites
The structural changes in mordenites induced by a partial dealumination using mineral acids
were described at a molecular level by Van Geem [18] and others [27]. Preferential removal
of aluminium from the labile T4 site in the 4-ring forming the walls of the main 12-ring
channels results in widening of part of the 8-ring channels and the creation of new
interconnections between the main channels [8, 18, 27]. However, a small microporous
volume (Table 1) and low accessibility of the OH groups for n-hexane (Table 2) in the mildly
dealuminated deAl-MOR/6.6 sample indicate that the desirable changes in the channel
structure require the removal of larger proportions of Al from the framework. 27Al MAS
NMR analysis (Figure 7) and the adsorption measurements (Table 1) clearly showed that the
acid treatment does not extract all the atoms removed from the framework and various extra-
framework species partly block the pores. In contrast, the fluorination-alkaline-acid treatment
(series I – 3) leads to a much larger increase in the volume of the supermicropores when a
similar amount of Al is extracted from the zeolites (compare, e.g., VMI 0.15 and 0.24 cm3.g-1
for deAl-MOR/6.6 and deAl-MOR-1F/6.8, respectively). The chemism of the concurrent
extraction of Al and Si atoms from the zeolite framework by fluorination-alkaline treatments,
as described by Yu et al. [20], is shown in Figure 5. After fluorination, a fraction of Si-O-Al
framework entities is cleaved by the incorporation of fluorides, but the attacked Al sites are
still integrated within the framework as F-bearing tetrahedral Al species [20]. The F-bearing
14

Al are extracted from the zeolite in the form of [AlF2(OH)2]-Na+ together with the
neighbouring Si atoms during the subsequent alkaline leaching (Figure 5). Figure 6B shows
an illustration of the changes in the local arrangements of the 8-ring after extraction of Al
from the T4 site and a neighbouring Si atom from the T2 or T4 site. Although we do not have
data showing the dislocation of specific T-atoms, the illustration is in a good agreement with
the textural data (Table 1) and the extraction of Al from the framework preferentially from the
12-ring sites is confirmed by the FTIR spectra either before or after the d3-acetonitrile
adsorption.
The changes in the microporous volume, the micropore size and the accessibility of
the acid with the chemical conditions of the fluorination-alkaline leaching (Tables 1 and 2)
indicate that the proportion of the extracted atoms is controlled by the interplay of the
concentration/distribution of Al in zeolite and the conditions of the treatment. The high
27
intensities in the signals at 30 and 0 ppm in the Al MAS NMR spectra reflect the large
content of the penta-coordinated and octahedral extraframework Al in the samples prepared
using the highest concentrations of the fluorination agent (≥1 M NH4F). Subsequent acid
leaching of MOR-1F/5.4 using 0.1 M HNO3 (deAl-MOR-1F/6.8) resulted in a slight increase
in the molar Si/Al ratio and a significant increase in the microporous volume from 0.12 to
0.24 cm3g-1 (Table 1), as well as a slight increase in the concentration of Brønsted sites from
0.22 to 0.24 mmol g-1 and Levis sites from 0.71 to 0.81 mmol g-1 (Table 2). These findings
indicate that the extraframework Al species formed in the channels after the fluorination-
alkaline treatment and blocking part of the micropores were removed by acid leaching. The
principle of the fluorination-alkaline-acid treatment is similar to the coupling of
dealumination with desilication employed for flexible tailoring of the concentration of
aluminum related acid sites in micromesoporous zeolites [7, 8, 28, 42]. The uniqueness of the
fluorination-alkaline-acid procedure lies in the effective formation of 3D connected
supermicroporous channels enhancing the accessibility of the acid sites without the formation
of a significant proportion of the secondary mesoporosity (VMI up to 0.25 cm3g-1, the mean
pore size ~ 7.5 Å).
3.1.4. Structure of platinum
The platinum loaded in the amount of 1.5 wt. % in the form of well-dispersed metallic
clusters was shown to guarantee the hydrogenation-dehydrogenation function under the
employed reaction conditions and the formation of hexane/hexene according to the
thermodynamic equilibrium [8, 9]. The hydroisomerisation under these conditions is
15

controlled by the acidic functions of the bi-functional Pt/H-MOR catalysts [43, 44].
Accordingly, the dispersion and the state of Pt was analysed using complementary HR-TEM
and the adsorption of CO followed by FTIR. The HR-TEM images in Figure 9B indicate
smoothly distributed nanoparticles with a size up to 2 - 3 nm. Also the occurrence of a minor
fraction of platinum clusters with a wide distribution in the size range of 3 - 40 nm was
observed on the external surface of the zeolite crystals. The FTIR spectra of adsorbed CO on
reduced Pt/H-MOR were characterised by a dominant adsorption band at 2080 cm-1, reflecting
the stretching mode of linearly adsorbed CO on the reduced Pt0 in metallic clusters of 1 - 20
nm in size [45, 46]. The reduced form of platinum is also confirmed by the absence of any
significant absorption intensity at about at 2180 - 2130 cm-1 characteristic of adsorbed CO on
Pt2+ ions or Ptnδ+ clusters [45, 46].
3.2.Hydroisomerisation of n-hexane
Figure 10 shows the hydroisomerisation activity over the series of MOR zeolites after
fluorination-alkaline and subsequent acid treatments. The catalytic activity is expressed as the
yield of the branched C6 species (the sum of all the di-branched 2,2- and 2,3-dimethylbutanes
and mono-branched 2- and 3-methylpentanes) in dependence on the reaction temperature. The
selectivity is reflected in the yields of all the C1-C5 cracking by-products as the cracking took
place in parallel with isomerisation at higher temperatures. The yields of the individual
branched hexane isomers and lower molecular weight by-products for hydroisomerisation of
n-hexane over all the prepared Pt/H-MOR at 225 °C and 250 °C are given in Table 3.
Over the parent Pt/H-MOR/5.8, a very low yield of iso-C6 isomers first appeared at
150 °C, (see Fig. 10 A), and then their yield continuously increased up to approximately 44%
at 275 °C, and finally decreased again (as a result of unselective cracking reactions, which
began to take place at 250 °C and then increased continuously to high temperatures, see
Figure 10 B). Thus the yield of iso-C6 finally attained values below 23% at 325 °C. The
fluorination-alkaline treatments of the parent MOR under mild conditions in the 1st series
resulted in a substantial increase in its activity and the isomer yield was improved by more
than two-fold in the broad temperature range 175 - 250 °C. Further, the subsequent mild
dealumination led to a further increase and the resultant iso-C6 yield exceeded 62 - 63% of
branched isomers at temperatures of 225 - 250 °C. The corresponding cracking was
analogously elevated at temperatures above 250 °C (see Figure 10 B). In the 2nd series
(Figures 10 C, D) the slightly stronger fluorination followed by stronger alkali treatment
16

compared to Series 1 and the mild acid dealumination of the MOR increased the catalyst
activity even further and 66% iso-C6 yield was obtained at T < 250°C, over both fluorination-
alkaline-acid treated catalysts. Substantially stronger fluorination in series 3 (Figures 10 E, F)
followed by mild dealumination finally brought the highest isomer yield increase up to 72%,
which was obtained at a temperature as low as 225 °C. All the improved isomer yields were
also accompanied by increased cracking yields of C1 - C5 by-products, their values increased
approximately 3 - 4 times compared to the parent/microporous MOR, e.g. the yield increased
from approximately 4% to 15%, from the parent to the last fluorination-alkaline-acid treated
MOR, respectively, at 250 °C and continued to predominate at the highest temperatures.
The strongest fluorination-alkaline treatment of 4M NH4F in 4th series caused a
dramatic drop in the yield of isomers (shown in Figures 10 G, H), although a slight
improvement with mild dealumination was found, nevertheless not achieving the original
activity of the parent MOR. In this case, the formation of by-products was proportionately
suppressed. Thus, using the optimal fluorination-alkaline-acid step sequence in series 3, a
resultant highest yield of C6-isomers as high as 72% was achieved at a temperature of 225 °C,
compared to 44% at 275°C achieved for the parent MOR. For comparison, only a 55% yield
at 250 °C was achieved on dealuminated deAl-MOR/6.6 (Series 5) with a corresponding
increase in the amount of by-products from 4% to 12% at 250 °C (shown in Figs. 10 I, J).
Summing up, the mordenite zeolites with the 3D connected supermicroporous
channels provide much higher yields of branched isomers in the hydroisomerization reaction.
The high activity is unequivocally linked to enhancement of accessibility of the active sites
and molecular transport in an environment of nonrestricted microporous channels. However,
we can not exclude that the increase in the yield of branched isomers and corresponding
specific activity is also associated with contributions from others synergistic effects. The
presence of electron acceptor Lewis sites in zeolites can contribute to the enhancement of
catalytic activity, as demonstrated in the literature for numerous hydrocarbons [47-50]. The
significant concentrations of the Levis sites were observed in the FTIR spectra of adsorbed d3-
acetonitrile (Figure 8 and Table 2) and the presence of penta-coordinated and octahedral
extraframework Al was obvious in the 27Al MAS NMR spectra (Figure 7) of the
supermicroporous mordenites. An increased strength of the Brønsted sites next to Lewis sites
[51, 52] or additional polarization of reactants by a Lewis acid site adjacent to a Brønsted site
[53, 54] can contribute to the overall activity of the supermicroporous mordenites.
17

The stability of the yields and selectivity as a function of time-on-stream was analysed
over the parent MOR/5.8 and over the resultant fluorination-alkaline-acid treated deAl-MOR-
0.5F/5.6 from Series 2 as a typical supermicroporous MOR zeolite (Figure 11). The yield of
all the isomers decreased slightly over the parent MOR/5.8, from 24% of the initial value to
21% after 48 h of continuous C6-feeding at a reaction temperature of 235 °C. It was observed
to be nearly constant, i.e. 44 - 46%, over deAl-MOR-0.5F/5.6 and the yields of the individual
mono-branched (38 - 40%) and di-branched isomers (~ 6%) were also constant within > 48 h
of time-on-stream. The amount of (C1 - C5) by-products was below ∼ 1% during both reaction
runs. All these observations indicate sufficient structural stability and the absence of any
substantial structural damage to the supermicroporous Pt/H-MOR under the reaction
conditions; moreover, it also demonstrated some improvement in the time-on-stream stability
compared with the untreated parent MOR/5.8.
4. CONCLUSIONS
We demonstrated that the simultaneous extraction of Al and Si from the Al-rich MOR
framework using fluorination-alkaline-acid treatment leads to high micropore volume (up to
0.25 cm3.g-1), enlargement of the micropores (with mean diameter of about 7.5 Å) and
interconnection of the channels. The re-organisation of the mono-dimensional channel system
of the MOR zeolite into a three-dimensional supermicroporous zeolite structure with
connectivity of the pore network resulting in good accessibility to the acid sites allows the
preparation of catalytic materials providing strongly enhanced hydroisomerisation properties.
These findings highlight the essential role of the 3D supermicroporous structure in the
catalytic activity, selectivity of the transformation of n-hexane into the corresponding
branched isomers without excessive participation of consecutive cracking reactions, and long-
term catalytic stability. The concept provides opportunities for the creation of accessible
Brønsted and Lewis active sites in Al-rich zeolites for diffusion-restricted reactions.
Acknowledgments
This work was supported by the Grant Agency of the Czech Republic under project No. 15-
12113S. The authors acknowledge the assistance provided by the Research Infrastructures
NanoEnviCz (Project No. LM2015073) and Pro-NanoEnviCz (Project No.
18

CZ.02.1.01/0.0/0.0/16_013/0001821), supported by the Ministry of Education, Youth and
Sports of the Czech Republic.
References
[1] W. Vermeiren, J.P. Gilson, Impact of zeolites on the petroleum and petrochemical
industry, Topics in Catalysis, 52 (2009) 1131-1161.
[2] H. Weyda, E. Köhler, Modern refining concepts—an update on naphtha-isomerization to
modern gasoline manufacture, Catalysis Today, 81 (2003) 51-55.
[3] D. Kaucký, B. Wichterlová, J. Dedecek, Z. Sobalik, I. Jakubec, Effect of the particle size
and surface area of tungstated zirconia on the WOx nuclearity and n-heptane isomerization
over Pt/WO3–ZrO2, Applied Catalysis A: General, 397 (2011) 82-93.
[4] T. Løften, E.A. Blekkan, Isomerisation of n-hexane over sulphated zirconia modified by
noble metals, Applied Catalysis A: General, 299 (2006) 250-257.
[5] S. Kuba, P. Lukinskas, R.K. Grasselli, B.C. Gates, H. Knözinger, Structure and properties
of tungstated zirconia catalysts for alkane conversion, Journal of Catalysis, 216 (2003) 353-
361.
[6] A. Chica, A. Corma, Hydroisomerization of pentane, hexane, and heptane for improving
the octane number of gasoline, J. Catal., 187 (1999) 167-176.
[7] P. Sazama, Z. Sobalik, J. Dedecek, I. Jakubec, V. Parvulescu, Z. Bastl, J. Rathousky, H.
Jirglova, Enhancement of Activity and Selectivity in Acid-Catalyzed Reactions by
Dealuminated Hierarchical Zeolites, Angewandte Chemie-International Edition, 52 (2013)
2038-2041.
[8] J. Pastvova, D. Kaucky, J. Moravkova, J. Rathousky, S. Sklenak, M. Vorokhta, L. Brabec,
R. Pilar, I. Jakubec, E. Tabor, P. Klein, P. Sazama, Effect of Enhanced Accessibility of Acid
Sites in Micromesoporous Mordenite Zeolites on Hydroisomerization of n-Hexane, ACS
Catalysis, 7 (2017) 5781-5795.
[9] P. Sazama, D. Kaucky, J. Moravkova, R. Pilar, P. Klein, J. Pastvova, E. Tabor, S. Sklenak,
I. Jakubec, L. Mokrzycki, Superior activity of non-interacting close acidic protons in Al-rich
Pt/H-*BEA zeolite in isomerization of n-hexane, Applied Catalysis a-General, 533 (2017) 28-
37.
[10] M. Tromp, J.A. van Bokhoven, M.T. Garriga Oostenbrink, J.H. Bitter, K.P. de Jong,
D.C. Koningsberger, Influence of the Generation of Mesopores on the Hydroisomerization
Activity and Selectivity of n-Hexane over Pt/Mordenite, Journal of Catalysis, 190 (2000) 209-
214.
[11] S.V. Konnov, I.I. Ivanova, O.A. Ponomareva, V.I. Zaikovskii, Hydroisomerization of n-
alkanes over Pt-modified micro/mesoporous materials obtained by mordenite
recrystallization, Microporous and Mesoporous Materials, 164 (2012) 222-231.
[12] H. Chiang, A. Bhan, Catalytic consequences of hydroxyl group location on the kinetics
of n-hexane hydroisomerization over acidic zeolites, J. Catal., 283 (2011) 98-107.
[13] K.-j. Chao, H.-c. Wu, L.-j. Leu, Hydroisomerization of light normal paraffins over series
of platinum-loaded mordenite and beta catalysts, Applied Catalysis A: General, 143 (1996)
223-243.
[14] N. Viswanadham, L. Dixit, J.K. Gupta, M.O. Garg, Effect of acidity and porosity
changes of dealuminated mordenites on n-hexane isomerization, Journal of Molecular
Catalysis A: Chemical, 258 (2006) 15-21.
[15] R.M. Barrer, 435. Syntheses and reactions of mordenite, Journal of the Chemical Society
(Resumed), (1948) 2158-2163.
19

[16] B. Wichterlova, Z. Tvaruzkova, Z. Sobalik, P. Sarv, Determination and properties of acid
sites in H-ferrierite: A comparison of ferrierite and MFI structures, Microporous Mesoporous
Mater., 24 (1998) 223-233.
[17] J.A. Van Bokhoven, D.C. Koningsberger, P. Kunkeler, H. Van Bekkum, A.P.M.
Kentgens, Stepwise dealumination of zeolite Beta at specific T-sites observed with 27Al MAS
and 27Al MQ MAS NMR, Journal of the American Chemical Society, 122 (2000) 12842-
12847.
[18] P.C. Van Geem, K.F.M.G.J. Scholle, G.P.M. Van Der Velden, W.S. Veeman, Study of
the transformation of small-port into large-port mordenite by magic angle spinning NMR and
infrared spectroscopy, J. Phys. Chem., 92 (1988) 1585-1589.
[19] P.A. Webb, Clyde O., Analytical Methods in Fine Particle Technology, in: M.I.
Corporation (Ed.)Norcoss, GA 30093 U.S.A., 1997.
[20] L. Yu, S. Huang, S. Miao, F. Chen, S. Zhang, Z. Liu, S. Xie, L. Xu, A facile top-down
protocol for postsynthesis modification of hierarchical aluminum-rich MFI zeolites, Chem.
Eur. J., 21 (2015) 1048-1054.
[21] J.C. Groen, J.A. Moulijn, J. Perez-Ramirez, Desilication: on the controlled generation of
mesoporosity in MFI zeolites, Journal of Materials Chemistry, 16 (2006) 2121-2131.
[22] P. Sazama, Z. Sobalik, J. Dedecek, I. Jakubec, V. Parvulescu, Z. Bastl, J. Rathousky, H.
Jirglova, Enhancement of Activity and Selectivity in Acid-Catalyzed Reactions by
Dealuminated Hierarchical Zeolites, Angew. Chem., Int. Ed., 52 (2013) 2038-2041.
[23] N. Viswanadham, M. Kumar, Effect of dealumination severity on the pore size
distribution of mordenite, Microporous and Mesoporous Mater., 92 (2006) 31-37.
[24] M. Tromp, J.A. van Bokhoven, M.T. Garriga Oostenbrink, J.H. Bitter, K.P. de Jong,
D.C. Koningsberger, Influence of the Generation of Mesopores on the Hydroisomerization
Activity and Selectivity of n-Hexane over Pt/Mordenite, J. Catal., 190 (2000) 209-214.
[25] A.N.C. Van Laak, S.L. Sagala, J. Zecevic, H. Friedrich, P.E. De Jongh, K.P. De Jong,
Mesoporous mordenites obtained by sequential acid and alkaline treatments - Catalysts for
cumene production with enhanced accessibility, J. Catal., 276 (2010) 170-180.
[26] M. Muller, G. Harvey, R. Prins, Comparison of the dealumination of zeolites beta,
mordenite, ZSM-5 and ferrierite by thermal treatment, leaching with oxalic acid and treatment
with SiCl4 by H-1, Si-29 and Al-27 MAS NMR, Microporous and Mesoporous Mater., 34
(2000) 135-147.
[27] M.-C. Silaghi, C. Chizallet, J. Sauer, P. Raybaud, Dealumination mechanisms of zeolites
and extra-framework aluminum confinement, J. Catal., 339 (2016) 242-255.
[28] P. Sazama, B. Wichterlova, J. Dedecek, Z. Tvaruzkova, Z. Musilova, L. Palumbo, S.
27
Sklenak, O. Gonsiorova, FTIR and Al MAS NMR analysis of the effect of framework Al-
and Si-defects in micro- and micro-mesoporous H-ZSM-5 on conversion of methanol to
hydrocarbons, Microporous and Mesoporous Materials, 143 (2011) 87-96.
[29] P. Sazama, B. Wichterlova, S. Sklenak, V.I. Parvulescu, N. Candu, G. Sadovska, J.
Dedecek, P. Klein, V. Pashkova, P. Stastny, Acid and redox activity of template-free Al-rich
H-BEA* and Fe-BEA* zeolites, Journal of Catalysis, 318 (2014) 22-33.
[30] J. Brus, L. Kobera, W. Schoefberger, M. Urbanová, P. Klein, P. Sazama, E. Tabor, S.
Sklenak, A.V. Fishchuk, J. Dědeček, Structure of framework aluminum lewis sites and
27
perturbed aluminum atoms in zeolites as determined by Al{1H} REDOR (3Q) MAS NMR
spectroscopy and DFT/molecular mechanics, Angewandte Chemie - International Edition, 54
(2015) 541-545.
[31] P. Sazama, E. Tabor, P. Klein, B. Wichterlova, S. Sklenak, L. Mokrzycki, V. Pashkkova,
M. Ogura, J. Dedecek, Al-rich beta zeolites. Distribution of Al atoms in the framework and
related protonic and metal-ion species, Journal of Catalysis, 333 (2016) 102-114.
20

[32] A. Samoson, E. Lippmaa, G. Engelhardt, U. Lohse, H.G. Jerschkewitz, Quantitative
27
high-resolution Al NMR: tetrahedral non-framework aluminium in hydrothermally treated
zeolites, Chemical Physics Letters, 134 (1987) 589-592.
[33] B.H. Wouters, T. Chen, P.J. Grobet, Steaming of zeolite Y: formation of transient Al
species, Journal of Physical Chemistry B, 105 (2001) 1135-1139.
[34] T.H. Chen, B.H. Wouters, P.J. Grobet, Aluminium coordinations in zeolite mordenite by
27Al multiple quantum mas NMR spectroscopy, European Journal of Inorganic Chemistry,
(2000) 281-285.
[35] M.J. Remy, D. Stanica, G. Poncelet, E.J.P. Feijen, P.J. Grobet, J.A. Martens, P.A. Jacobs,
Dealuminated H-Y zeolites: Relation between physicochemical properties and catalytic
activity in heptane and decane isomerization, Journal of Physical Chemistry, 100 (1996)
12440-12447.
[36] T.H. Chen, B. Wouters, P. Grobet, Distorted tetrahedral coordinated aluminum in
calcined mordenite identified by nutation and 2D 27Al MQMAS NMR spectroscopy,
Chemical Journal on Internet, 2 (2000) 7-13.
[37] J. Chen, T. Chen, N. Guan, J. Wang, Dealumination process of zeolite omega monitored
by 27Al 3QMAS NMR spectroscopy, Catalysis Today, 93-95 (2004) 627-630.
[38] M.-C. Silaghi, C. Chizallet, J. Sauer, P. Raybaud, Dealumination mechanisms of zeolites
and extra-framework aluminum confinement, Journal of Catalysis, 339 (2016) 242-255.
[39] F. Wakabayashi, J. Kondo, A. Wada, K. Domen, C. Hirose, FT-IR STUDIES OF THE
INTERACTION BETWEEN ZEOLITIC HYDROXYL-GROUPS AND SMALL
MOLECULES .1. ADSORPTION OF NITROGEN ON H-MORDENITE AT LOW-
TEMPERATURE, Journal of Physical Chemistry, 97 (1993) 10761-10768.
[40] V.L. Zholobenko, M.A. Makarova, J. Dwyer, INHOMOGENEITY OF BRONSTED
ACID SITES IN H-MORDENITE, Journal of Physical Chemistry, 97 (1993) 5962-5964.
[41] W.M. Meier, The Crystal Structure Of Mordenite (Ptilolite), Zeitschrift fur
Kristallographie - New Crystal Structures, 115 (1961) 439-450.
[42] S. Yang, C. Yu, L. Yu, S. Miao, M. Zou, C. Jin, D. Zhang, L. Xu, S. Huang, Bridging
Dealumination and Desilication for the Synthesis of Hierarchical MFI Zeolites, Angewandte
Chemie International Edition, 56 (2017) 12553-12556.
[43] A. Van De Runstraat, J.A. Kamp, P.J. Stobbelaar, J. Van Grondelle, S. Krijnen, R.A. Van
Santen, Kinetics of hydro-isomerization of n-hexane over platinum containing zeolites,
Journal of Catalysis, 171 (1997) 77-84.
[44] F. Ribeiro, C. Marcilly, M. Guisnet, Hydroisomerization of n-hexane on platinum
zeolites. I. Kinetic study of the reaction on platinum/Y-zeolite catalysts: Influence of the
platinum content, Journal of Catalysis, 78 (1982) 267-274.
[45] A.Y. Stakheev, E.S. Shpiro, O.P. Tkachenko, N.I. Jaeger, G. Schulz-Ekloff, Evidence for
monatomic platinum species in H-ZSM-5 from FTIR spectroscopy of chemisorbed CO,
Journal of Catalysis, 169 (1997) 382-388.
[46] P. Kubanek, H.W. Schmidt, B. Spliethoff, F. Schüth, Parallel IR spectroscopic
characterization of CO chemisorption on Pt loaded zeolites, Microporous and Mesoporous
Materials, 77 (2005) 89-96.
[47] O. Bortnovsky, P. Sazama, B. Wichterlova, Cracking of pentenes to C 2-C 4 light olefins
over zeolites and zeotypes: Role of topology and acid site strength and concentration, Applied
Catalysis A: General, 287 (2005) 203-213.
[48] A. Corma, J. Planelles, J. Sánchez-Marín, F. Tomás, The role of different types of acid
site in the cracking of alkanes on zeolite catalysts, Journal of Catalysis, 93 (1985) 30-37.
[49] H. Matsuura, N. Katada, M. Niwa, Additional acid site on HZSM-5 treated with basic
and acidic solutions as detected by temperature-programmed desorption of ammonia,
Microporous and Mesoporous Materials, 66 (2003) 283-296.
21

[50] S. Schallmoser, T. Ikuno, M.F. Wagenhofer, R. Kolvenbach, G.L. Haller, M. Sanchez-
Sanchez, J.A. Lercher, Impact of the local environment of Brønsted acid sites in ZSM-5 on
the catalytic activity in n-pentane cracking, Journal of Catalysis, 316 (2014) 93-102.
[51] A. Corma, A. Martínez, P.A. Arroyo, J.L.F. Monteiro, E.F. Sousa-Aguiar, Isobutane/2-
butene alkylation on zeolite beta: Influence of post-synthesis treatments, Applied Catalysis A:
General, 142 (1996) 139-150.
[52] S. Li, A. Zheng, Y. Su, H. Zhang, L. Chen, J. Yang, C. Ye, F. Deng, Brønsted/Lewis
Acid Synergy in Dealuminated HY Zeolite:ꢀ A Combined Solid-State NMR and Theoretical
Calculation Study, Journal of the American Chemical Society, 129 (2007) 11161-11171.
[53] C. Song, Y. Chu, M. Wang, H. Shi, L. Zhao, X. Guo, W. Yang, J. Shen, N. Xue, L. Peng,
W. Ding, Cooperativity of adjacent Brønsted acid sites in MFI zeolite channel leads to
enhanced polarization and cracking of alkanes, Journal of Catalysis, 349 (2017) 163-174.
[54] C. Song, M. Wang, L. Zhao, N. Xue, L. Peng, X. Guo, W. Ding, W. Yang, Z. Xie,
Synergism between the Lewis and Brönsted acid sites on HZSM-5 zeolites in the conversion
of methylcyclohexane, Chinese Journal of Catalysis, 34 (2013) 2153-2159.
Fig. 1. Scheme of the preparation of the supermicroporous mordenites using postsynthesis
fluorination-alkaline-acid (Series I-IV), and acid (Series V) treatments
Fig. 2. Representative HR-TEM images of A) parent MOR/5.8 mordenite, B) MOR-0.36F/5.8, C)
deAl-MOR-0.36F/7.0, D) MOR-1F/5.4, E) deAl-MOR-1F/6.8, and F) deAl-MOR/6.6.
Fig. 3. XRD patterns of prepared MOR samples
Fig. 4. Adsorption of N2 and Ar/LN2 at 77 K and detail of distribution of microporous and
mesoporous structure before and after fluorination-alkaline-acid treatments (Series I - III), and
also simple acid (Series V) treatment.
Fig. 5. Illustration of mechanism of the simultaneous extraction of Al3+ and Si4+ atoms and
formation of the extraframework Al species by alkaline treatment of fluorinated Al-rich
mordenites.
Fig. 6. Schematic illustration of mordenite openings before and after extraction of Si and Al by
fluorination-alkaline-acid treatments. A) Illustration of pore size changes and B) structure of the
8-ring a) before the treatment and an illustration of the changes in local arrangements after
extraction of Al from the T4 site and a neighbouring Si atom from b) the T2 or c) the T4 site.
22

Fig. 7. 27Al MAS NMR spectra for hydrated mordenite zeolites after fluorination-alkaline-acid
treatments (Series I - III), and also simple acid (Series V) treatment.
Fig 8. Comparison of FTIR spectra of adsorbed d3-acetonitrile (B, D, and F) and the OH stretching
region (A, C, and E) for mordenite zeolites after fluorination-alkaline-acid treatments (Series I -
III), and acid (Series V) treatment. A), B) Series I; C, D) Series II and V, and E, F) Series III.
Fig. 9. A) Typical FTIR spectra of CO adsorbed on Pt/H-MOR zeolites reduced by hydrogen at 250
°C and B) characteristic TEM images of Pt in Pt/H-MOR catalysts, of a) parent MOR/5.8, b) MOR-
1F/5.4, c) deAl-MOR-1F/6.8 and d) deAl-MOR/6.6.
Fig. 10. The yields of branched C6 isomers and C1-C5 by-products in the hydroisomerization of n-
hexane over Pt/H-MOR zeolites. A, B) Series I; C, D) Series II; E, F) Series III; G, H) Series IV and I),
J) Series V.
Fig. 11. The test of catalytic stability over A) microporous zeolite MOR/5.8 and B)
supermicroporous deAl-MOR-0.5F/5.6 as a dependence of yields of the individual branched
hexane isomers and C1-C5 by-products on time-on-stream in hydroisomerization of n-hexane.
23

24

25

26

27

Table 1. Preparation and textural properties of fluorinated Al-rich mordenites determined by adsorption of N2
and Ar at the temperature of liquid nitrogen.
b
c
VMI
VME
SEXT
Sample
Synthesis
Si/Ala
(cm3.g1) (cm3.g1) (m2.g-1)
MOR/5.8
MOR-0.36F/5.8
deAl-MOR-0.36F/7.0
MOR-0.5F/5.6
H-MOR parent
0.36 M NH4F + 0.2 M NaOH
5.8
5.7
7.2
5.6
6.5
5.4
6.8
6.2
6.9
6.6
0.16
0.21
0.21
0.20
0.23
0.12
0.24
0
0.02
0.04
0.05
0.05
0.06
0.06
0.06
-
23
40
51
63
57
65
68
-
0.36 M NH4F + 0.2 M NaOH + 0.1 M HNO3
0.5 M NH4F + 0.4 M NaOH
deAl-MOR-0.5F/5.6
MOR-1F/5.4
0.5 M NH4F + 0.4 M NaOH + 0.1 M HNO3
1M NH4F + 0.4 M NaOH
deAl-MOR-1F/6.8
MOR-4F/6.2
1 M NH4F + 0.4 M NaOH + 0.1 M HNO3
4 M NH4F + 0.4 M NaOH
deAl-MOR-4F/6.9
deAl-MOR/6.6
4 M NH4F + 0.4 M NaOH + 0.1 M HNO3
0.1 M HNO3
0.12
0.15
-
18
44
0.04
a from chemical analysis
b estimated from BdB t-plot method
c Vmeso = Vtotal - Vmicro
28

Table 2. Concentrations of bridging hydroxyls and Brønsted and Lewis sites in zeolite and accessibility of OH
groups in fluorinated Al-rich mordenites.
Accessibility
cAl
b
c
d
cB cL cB+2L
of OH
groups e
a
Sample
Si/Ala
(mmol.g-1)
(%)
MOR/5.8
5.8 2.31 0.97 0.45 1.86
19
48
MOR-0.36F/5.8 5.7 2.51 0.37 0.81 1.99
deAl-MOR-
0.36F/7.0
0.55 0.75 2.04
7.2
51
54
78
64
59
24
2.05
MOR-0.5F/5.6
5.6 2.55 0.22 0.81 1.85
deAl-MOR-
0.5F/5.6
0.17 0.47 1.11
6.5
2.24
MOR-1F/5.4
5.4 2.65 0.22 0.71 1.64
deAl-MOR-
1F/6.8
0.24 0.80 1.83
6.8 2.16
deAl-MOR/6.6
6.6 2.22 0.32 0.96 2.25
a from chemical analysis
b, c concentrations of acid Brønsted and Lewis sites, respectively, from FTIR spectra of adsorbed d3-acetonitrile
d concentration of Al estimated from the concentration of Brønsted and Lewis sites (cAl = cB + 2cL)
e from FTIR spectra of the bridging OH groups after adsorption of n-hexane
29
