Investigation of potential hybrid capacitor property of chelated N-Heterocyclic carbene Ruthenium(II) complex

Article abstract of DOI:10.1016/j.jorganchem.2018.04.035

The synthesis of chelated ruthenium(II) complex type Ru(η⁶-HMB) (NHC)Cl (NHC=N-heterocyclic carbene, HMB = hexamethylbenzene) is presented. The ruthenium(II)-NHC complex 6 was obtained in good yield and was fully characterised by NMR spectrosco

Full text of DOI:10.1016/j.jorganchem.2018.04.035

Accepted Manuscript
Investigation of potential hybrid capacitor property of chelated N-Heterocyclic carbene
Ruthenium(II) complex
Mitat Akkoç, Erdinç Öz, Serkan Demirel, Vincent Dorcet, Thierry Roisnel, Ali Bayri,
Christian Bruneau, Serdar Altin, Sedat Yaşar, İsmail Özdemir
PII:
S0022-328X(18)30288-2
10.1016/j.jorganchem.2018.04.035
JOM 20427
DOI:
Reference:
To appear in: Journal of Organometallic Chemistry
Received Date: 21 February 2018
Revised Date: 21 April 2018
Accepted Date: 30 April 2018
Please cite this article as: M. Akkoç, Erdinç. Öz, S. Demirel, V. Dorcet, T. Roisnel, A. Bayri, C. Bruneau,
S. Altin, S. Yaşar, İ. Özdemir, Investigation of potential hybrid capacitor property of chelated N-
Heterocyclic carbene Ruthenium(II) complex, Journal of Organometallic Chemistry (2018), doi: 10.1016/
j.jorganchem.2018.04.035.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
Investigation of Potential Hybrid Capacitor Property of Chelated N-Heterocyclic
Carbene Ruthenium(II) Complex
a
b,c
b,d
e
e
Mitat Akkoç , Erdinç Öz , Serkan Demirel , Vincent Dorcet , Thierry Roisnel , Ali
b
e
b,
a,
a
Bayri , Christian Bruneau , Serdar Altin * , Sedat Yaşar *, İsmail Özdemir
a
İnönü University, Faculty of Science and Art, Department of Chemistry, 44280, Malatya,
Turkey
b
İnönü University, Faculty of Science and Art, Department of Physics, 44280, Malatya,
Turkey
c
Ankara University, Institute of Accelerator Technologies, Ankara, 06830, Turkey
d
National Defense University, Naval Petty Officer Vacational School, Yalova, Turkey
e
Université de Rennes, UMR 6226: CNRS Sciences Chimiques de Rennes, 35042, France
Corresponding Authors: Sedat Yaşar, Tel:+904223773735, Fax:+904223410212, e-
mail:sedat.yasar@inonu.edu.tr; Serdar Altın, serdar.altin@inonu.edu.tr
Keywords: Cyclic Voltametry of ruthenium(II), hybrid capasitor; N-heterocyclic carbene;
ruthenium; chelate ligand; transfer hydrogenation
Abstract
6
The synthesis of chelated ruthenium(II) complex type Ru(η -HMB)(NHC)Cl (NHC=N-
heterocyclic carbene, HMB=hexamethylbenzene) is presented. The ruthenium(II)-NHC
complex 6 was obtained in good yield and was fully characterised by NMR spectroscopy, X-
ray diffraction and HRMS analysis. Electrochemical analysis by cyclic voltammetry (CV)
revealed reversible redox behaviour at the ruthenium centre in 6. DFT studies and the
catalytic activity of complex 6 on transfer hydrogenation reaction of aryl ketones are also
presented. The potential hybrid capacitor applications of Ru-NHC complex is discussed and
reported firstly in the literature. It was found that the highest performance was found at 20.1
F/g, which is a promising result for energy storage applications.

ACCEPTED MANUSCRIPT
1
. Introduction
N-heterocyclic carbenes (NHCs) have become a widely used as a class of complexes in
different areas such as transition metal catalysis [1], organocatalysis [2], biochemistry and
medicine [3]. They are seen as an alternative to phosphine ligands, although their σ-donor
property is more pronounced. This pronounced σ-donor property of NHC leads to more stable
different transition metal ions at the centre of the molecule in the catalytic reaction, which
does not readily undergo ligand dissociation [4]. Metal-carbon (M-C) bond stability may
always be useful for catalytic activity, as many complexes carrying flexible NHC ligands
combined with the robust nature of the M-NHC bond have been successfully used in high
temperature required catalytic reactions [5-8]. Examples of ruthenium complexes (numbered
1
-5 as seen in Figure 1), produced by chelating NHCs bearing oxygen [9,10], phosphorous
[
11,12], allyl [13], sulphur [14] and nitrogen [15-26] moieties, have been used successfully as
catalysts for the transfer hydrogenation reaction. Peris and coworkers reported on rhodium
and ruthenium complexes derived from an NHC ligand functionalised with a pendant alcohol
[
27]. In our case, a bidentate NHC-Ru(II) complex with a tethered carboxylate group was
obtained by transmetallation of silver(I)-NHC to ruthenium(II) in dry dichloromethane
DCM). According to studies conducted by Peris et al., such complexes are formed as a result
(
of in situ oxidation of the alcohol group. The results we reported in this study are consistent
with this comment that Peris and his colleagues have done.
Compared to other imidazole functionalised NHC complexes, benzimidazole based-
functionalised NHC ruthenium (II) complexes are still merit [28]. As far as we know,
complex 6 in Figure 1 is the first example of a benzimidazole-based carboxylate donor
functionalised NHC ruthenium(II) complex.

ACCEPTED MANUSCRIPT
Figure 1. Some examples of bidentate chelating NHC-Ru(arene) complexes
In addition to the unique catalytic properties of N-heterocyclic carbenes, In addition to the
catalytic activities of the NHCs, it is possible to have hybrid capacitor capability. Thus, they
may be used on the energy storage devices . Hybrid capacitors consist of electrodes and
electrolytes. In recent decades, hybrid capacitors have garnered considerable attention due to
-1
their intrinsic properties, i.e. a high capacity value of 4-250 Fg [29]. It is well-known that a
high capacity value of a hybrid capacitor can be achieved by the increasing the surface area
and/or the conductivity of the electrodes [30]. Another important aspect of capacitors is to the
search for new electrode materials. The highest capacitive performance of supercapacitors has
been obtained with carbon-based materials [31]. Recently, studies have focused on metal
oxide materials, i.e. Ni, Mn, Fe and Co, to achieve high capacitive performance [32]. Organic
materials are another group of capacitors used in different devices such as poly(3,4-
ethylenedioxythiophene) and poly(methyl methacrylate) [33]. Although organometallic
complexes may consider as possible electrode materials for a device, there is no information
about their capacitive performance.
The electrolyte materials are another important component of hybrid capacitors, as it is well-
known that the capacity value changes from one electrolyte to another. For example, if the

ACCEPTED MANUSCRIPT
electrolyte is changed from 1-ethyl-3-methylimidazolium bis(trifluoromethylsulphonyl)imide
-1
-1
to H SO , the capacity of the cell increases from 65-150 Fg to 454-710 Fg [34].
2
4
Our group has been interested in the chemistry and catalytic activity of functionalised N-
heterocyclic carbene and related transition metal complexes since the early 1990s. The study
reported here describes the preparation of a redox-active benzimidazole-based oxygen donor
NHC-ruthenium complex, which was assessed in the context of DFT, the catalytic activity
during the transfer hydrogenation reaction and hybrid capacitor applications.
2
. Results and Discussion
2
.1.Synthesis and characterisation
The N-heterocyclic carbene precursor has been synthesized by addition of 2-iodoethanol to a
n-BuOH solution of 1-(pentamethylbenzyl)benzimidazole at room temperature. Then the
o
reaction mixture was heated and stirred at 120 C for 24 h. This residue was purified to
obtain 1-pentamethylbenzyl-3-hydroxyethylbenzimidazolium iodide salt as yellow crystalline
solid. This salt soluble in water, methanol, acetonitrile, chlorinated solvents and DMSO. The
resonance of the NCHN proton of 1-pentamethylbenzyl-3-hydroxyethylbenzimidazolium
1
6)
iodide salt in H NMR (DMSO-d observed at 8.97 ppm and NCHN carbons resonate in the
1
3
1
C{ H} NMR spectra at 141.8 ppm (see supporting information for NMR spectra).

ACCEPTED MANUSCRIPT
1
13
Figure 2 H, C and APT NMR spectra of complex 6
Water soluble benzimidazolium salt was completely transformed into silver-NHC complex
under in situ conditions by Ag O. To synthesis Ag(I)-NHC complex, Ag O (1 mmol), 1-
2
2
pentamethylbenzyl-3-hydroxyethylbenzimidazolium iodide salt (1 mmol) and 20 mL dry
DCM was put in to a Schlenk tube under argon and stirred 24 hours under exclusive of light.
The Ag(I)-NHC complex did not isolated and used as formed for the synthesis of complex 6.
1
13
However, H, C and APT NMR spectra of in situ generated Ag(I)-NHC complex were
recorded in order to understand in which step the oxidation of ligand takes place. The NMR
spectra sign out that oxidation of pro-ligand occurs during the synthesis of silver-NHC
complex due to a signal at 165.6 ppm which attributed to carbonil carbon of carboxylate
1
3
group on the C NMR spectra. In this light, the proposed structure for the in situ synthesised
silver complex is shown in Figure 3. We think that carboxylate specie coordinates to silver
1
3
centre due to C NMR chemical shifts of carboxylate group on Ag(I)-NHC and complex 6 at
67,2 and 170, 6 ppm respectively. The NC N-Ag carben carbon peak was not detected
1
2
probably due to low concentration or nature of silver-NHC complex.

ACCEPTED MANUSCRIPT
N
N
Ag O
N
N
2
I-
Ag
O
DCM, rt
OH
O
1
3
Figure 3. Proposed structure of in situ synthesised Ag(I)-NHC complex and C NMR spectra
To synthesis complex 6, 0.5 mmol RuCl (HMB) was added to the DCM solution of Ag(I)-
2
2
NHC in dark. After stirring 24 h at room temperature, reaction mixture was filtrated upon
celite and all volatiles removed under high vacuum. By dissolving the crude product of 6 in
DCM/diethyl ether solution led to obtain single crystals suitable for X ray diffractions
1
analysis. The H NMR of 6 in CDCl confirms the formation of chelated Ru(II)-NHC
3
13
complexes by evanescent NCHN proton. C carbon of chelated Ru(II)-NHC complexes in C
2
NMR spectra shifted to 191.5 ppm, also confirm formation of 6. Also, CH COO-Ru carbon
2

ACCEPTED MANUSCRIPT
resonate at 170.6 ppm which is the expected value (Figure 2). The APT NMR spectra of
complex 6 confirming the formation of a CH COO- group by giving a peak in the negative
2
zone at 170.6 ppm (Figure 2). The HRMS spectra were verified the proposed structures for
the 6, recorded in methanol in negative-ion mode. The most intense peaks correspond to
-
molecular fragment ionized by the loss of one ion (Cl ) in negative-ion mode. The HRMS
spectra of complex 6 in methanol displayed ruthenium containing peaks.
2
.2.Crystallography
The molecular structure of the complex 6 obtained from the ORTEP analysis of single crystal
x-ray diffraction is given in Figure 4.
Figure 4. ORTEP plot of the complex 6
o
The bond lengths (Å) and bond angles ( ) of the complex are shown in Table 1. The molecule
structure of the complex was investigated by DFT calculations. The obtained crystallographic
data, which included bonds lengths and the angles between atoms, is given in Table 1 and
compared with the experimentally obtained crystallographic data. It can be seen that the
computational and experimental crystallographic data were compatible with each other. For
example, the experimental and computational bond lengths of Ru1-C26 and Ru1-O21 were
2
.028-2.013 Å and 2.412-2.485 Å, respectively. The experimental and computational angles
o
o
o
o
of N25-C26-Ru1 and N25-C26-N33 were 120.91 -122.43 and 105.88 -105.92 , respectively.

ACCEPTED MANUSCRIPT
According to crystal structure of complex 6, it can be said that the Ru(II) complex with an
6
g
0
g
octahedral environment has a t e electronic configuration. It should be pointed out here
2
that thermal spin state transition is not expected for the complex of 4d and 5d transition
elements since the ligand field strength is very high when compared with similar 3d
complexes. Hence, practically all 4d and 5d transition metal complexes show a low spin
electronic configuration. The strength of the ligand fields was in order of 5d>4d>>3d [35].
Thus, a low spin configuration is expected in complex 6, which was also support by the NMR
results of the complexes.
Table 1 Analogy of experimental and theoretical computation bond length and angle results
of the complex
Exp.
Lenght (Å)
2.412
2.108
2.028
1.355
1.368
1.281
1.232
1.530
1.460
2.222
2.199
2.305
2.301
DFT
Lenght (Å)
2.485
2.076
2.013
1.383
1.389
1.320
1.258
1.550
1.470
2.353
2.318
2.433
2.411
Bond
Ru1-Cl1
Ru1-O21
Ru1-C26
C26-N25
C26-N33
O21-C22
C22-O23
C22-C24
C24-N25
Ru1-C5
Ru1-C6
Ru1-C3
Ru1-C2
0
0
Angle
( )
( )
C4-Ru1-Cl1
C3-Ru1-Cl1
C5-Ru1-C26
C1-Ru1-O21
Ru1-O21-C22
O21-C22-O22
C22-C24-N25
C24-N25-C26
N25-C26-Ru1
C26-N33-C34
N25-C26-N33
O21-Ru1-C26
O21-Ru1-Cl1
92.19
88.74
93.30
91.58
88.58
99.97
89.74
88.59
125.57
124.28
115.86
126.10
120.91
122.89
105.88
83.99
126.60
124.68
116.53
125.89
122.43
122.27
105.92
85.96
84.77
86.55

ACCEPTED MANUSCRIPT
Cl1-Ru1-C26
C26-N25-C27
C26-N33-C32
C1-C2-C3
91.84
111.20
110.30
119.77
90.58
110.85
110.45
119.62
2
.3.HOMO and LUMO analysis
The electronic structure of complex 6 was calculated by the DFT computation technique from
the optimised structure. Structural concordance was observed from the comparison of bond
lengths and angles between the calculated and X-ray determined structure of 6. The
B3LYP/LanL2DZ basis set was used for the calculation of the energy of the highest occupied
molecular orbital (HOMO) and the lowest unoccupied molecular orbital (LUMO). The energy
of HOMO and LUMO orbitals were found to be -5.34186 eV and -1.454720 eV, respectively.
The molecular energy gap (E = LUMO-HOMO) from the optimised molecular structure by
g
DFT method was calculated as 3.88714 eV.
Figure 5b and c show the HOMO and LUMO states of the molecule, related to electrostatic
interactions with the environment of 6. Increasing the energy of the HOMO and decreasing
the energy of the LUMO can cause a decrease in ionization energy. Due to the high energy
gap value of 6, it is expected that complex 6 is irrelevant to electron transfer.

ACCEPTED MANUSCRIPT
(a)
(b)
(c)
Figure 5. (a) Optimized molecule, (b) HOMO and (c) LUMO state by DFT calculation
The MEP results of the complex are given in Figure 6 and the green colored regions on
correspond to positive electrostatic region and the red sink regions represent the negative
electrostatic potential surface in the complex 6. It is found that the value of the positively
charged region is low when compared with the negatively charged region in Figure 6. So, it
can be predicted that the complex has a nucleophilic character and is sensitive against
electrophilic sort. It can be seen in Figure 6 that the electrophilic region of the complex has a
small value, which means weak attractive potential for negative complexes, but the red region
-
in Figure 6 shows a good electrophilic effect, especially in the region with Cl ions.

ACCEPTED MANUSCRIPT
(a)
(b)
Figure 6. (a) front and (b) back view of MEP surface of the complex (green color indicates
neutral charge density. The blue and red colors indicate the positive and negative charge
densities, respectively)
2
.4.Catalysis
The transfer hydrogenation reaction of ketones was conducted in refluxing 2-propanol using
the ruthenium-based catalyst in the presence of a base; this is an important reaction in
industry [36,37]. Under these conditions, stable catalysts are readily able to catalyse transfer
hydrogenation reactions. The action of chelating donor-functionalised NHCs could be to
stabilise the ruthenium centre while decomposition take place. The potency of chelating
ruthenium NHC complexes as catalysts in the transfer hydrogenation reaction have been
reported by different groups [9-12,38-42].
Table 2. Results of transfer hydrogenation of ketones catalyzed by complex 6.
a
Entry
Catalyst
Ketone
Product
Yield(%)
1
6
O
OH
99

ACCEPTED MANUSCRIPT
2
3
4
5
6
7
6
6
OH
98
95
60
45
3
Cl
OH
6
OH
F
6
OH
H CO
3
none
none
OH
OH
8
Cl
t
o
All reactions were carried out with a Catalyst/KO Bu/Substrate ration of 1:25:250 in isopropanol (3 mL) at 80 C
in 2 hours under anhydrous and air free reaction conditions.
a
Yields were determined by GC with undecane as internal standard and were reported as an average of three
runs.
To our knowledge, there are no any reports on the transfer hydrogenation catalysed by
ruthenium complexes with benzimidazole-based carboxylate-functionalised chelating NHCs.
o
Complex 6 catalysed the transfer hydrogenation of ketones at 80 C with 2-propanol as the
t
hydrogen source in the presence of KO Bu as an activator (catalyst/base/substrate, 1:25:250;
Table 2). With this loading under an air atmosphere, different ketones were turned into the
corresponding alcohols with good to high yields in 2 hours.
2
.5.Redox properties
Figure 7 shows the cyclic voltammograms taken in a 0.05 M acetonitrile solution of n-
Bu NClO as the supporting electrolyte containing 0.05 mM RuCl(NHC)(HMB). The curve
4
4
shows the voltammogram obtained with the Pt working electrode and the Ag/AgO reference
electrode.
Ruthenium complex 6 underwent a single-electron redox reaction between Ru(II) and Ru(III)
in the activation/deactivation process, as illustrated in Figure 7. The measurement was carried
out in acetonitrile at 25°C with n-Bu NClO as the supporting electrolyte. Complexes showed
4
4

ACCEPTED MANUSCRIPT
waves corresponding to the Ru(II) a Ru(III) interconversion, which was highly reproducible
as quasi-reversible in each of several scans. The redox potential of complex 6 was E = -0.13
pa
V, E = 0.14 V, E = 0.005 V for a 100 mV/s scan rate, as shown in Table 3. We concluded
Pc
1/2
that low redox potential of complex 6 may help catalyse the transfer hydrogenation reaction.
EPc and E values changed with an increasing scan rate, which can be explained by the
pa
Randles-Sevcik equation showing that the peak values in CV are proportional to the square
root of the scan rate.
Figure 7. CV of the complex 6 for different scan rate
Table 3. CV properties of complex 6 on different scan rates
Scan Rates (mV/s)
EPc (eV)
EPa(eV)
E1/2(eV)
4
2
1
00
00
00
0.18
0.16
0.14
-0.14
-0.14
-0.13
0.02
0.01
0.005

ACCEPTED MANUSCRIPT
5
2
1
0
5
0
0.13
0.12
0.11
-0.12
-0.10
-0.08
0.005
0.01
0.02
2
.6.Design of the hybrid capacitor and performance analysis
It was important to investigate the capacitive behavior of the complex. For this, we designed a
device including an electrolyte and electrodes with the hybrid capacitor. To determine the
cycle life and capacity of the device, fabricated using complex 6 as an electrode material, we
fabricated a capacitor using a CR2032 coin cell case. The hybrid capacitors were designed in
the electrode/electrolyte/membrane (cellulose)/electrolyte/electrode device configuration.

ACCEPTED MANUSCRIPT
Figure 8. Cyclic Voltograms of complex 6 in different electrolytes
Although the CV graph of a supercapacitor is theoretically expected to have a rectangle
shape, the CV graph of the hybrid capacitors exhibited a hysteretic curve with reduction and
oxidation peaks, as seen in previous studies [43]. The oxidation and reduction peaks indicate a
reversible reaction with the electrodes and electrolytes. It is well-known that the electrode and
electrolyte interaction has an important effect on the capacitive properties. Thus, the
interaction of positive and negative ions in the electrolyte is a key parameter of the CV graph
of the cell. First of all, we measured the CV graph of the electrodes using four different
electrolyte materials to determine the changes in the capacitive properties of the complex, as
seen in Figure 8. Although all electrolytes showed a hysteretic structure during charge and

ACCEPTED MANUSCRIPT
discharge of the cell, the electrolyte Bu NClO showed the lowest performance for the
4
4
capacitive properties and the electrolytes NaCl and Na SO exhibited irreversible peaks
2
4
during charge and discharge, which means surface modification of the electrodes occurred
during the charge and discharge process. The best CV graph was obtained for the cell
including the KOH electrolyte.
Figure 9a shows charge and discharge curve of the capacitors in the potential range of -0.3-
0
.8 V for different electrolytes. It can be seen that the charge curve shows an increase and the
discharge curve exhibits an exponential decrease depending on the time, which is
characteristic behaviour of a capacitor. A change in the electrolyte changed the time constant
of the charge-discharge curve. It is well-known that the charging and discharging time is
directly related to the capacity of the cell, and it can be seen in Figure 8a that the charging
time is longer than discharging time, which is unwanted behaviour of the cell.
The capacity of the cell for different electrolyte materials was calculated by the following
equation:
ꢁ
ΔV
Δꢂ
1
ꢀ
=
∙ ꢄ
ꢃ
−
Where I is the applied constant current, which is positive for charging and negative for
discharging, ∆V/∆t is the slope of the charge and discharge curve and m is the mass of the
coated sample on the Ti substrate.

ACCEPTED MANUSCRIPT
a)
b)
Figure 9. (a) Charge/discharge curve and (b) capacity-cycle number measurement of the cell
for different electrolytes.

ACCEPTED MANUSCRIPT
The capacity changes in the capacitors over 1000 cycles were measured, as seen in Figure 8b.
Four different electrolyte materials were used to see the change in the capacity value of the
cell. Figure 8b shows that the capacity of the cell fabricated using n-Bu NClO was zero after
4
4
1
40 cycles of the cell and, when the cell was disassembled, we saw that the electrolyte was
dried and it was concluded that the loss of capacitive behaviour of the cell was directly related
with the drying of the electrolyte. When we compared the discharge capacity of the cell for
different electrolytes, it was found that KOH˃NaCl˃Na SO . This needs further intensive
2
4
study to develop higher capacity cells.
Table 4. The capacity of the cell for charging (Ch), discharging (Dch) and capacity fade (C.F)
of the cells fabricated using different electrolytes
st
th
th
th
th
1
Cycle
100 Cycle
250 Cycle
500 Cycle
1000 Cycle
Electrolyte
Ch. Dch. Ch. Dch. C.F Ch. Dch. C.F Ch. Dch. C.F Ch. Dch. C.F
-
1
-1
-1
-1
-1
(
Fg )
(Fg )
%
(Fg )
%
(Fg )
%
(Fg )
%
Bu NClO4
0.28 0.12 0.08 0.07
20.2 0.36 0.67 0.28
1.11 0.35 0.40 0.25
50
-
-
-
-
-
-
4
KOH
NaCl
12 0.59
0.3
6
0.52 0.33
3
0.38 0.35
1
14 0.35 0.23
12 0.29 0.21
14 0.24 0.19
16
Na SO4
0.76 0.17 0.18 0.15
2
0.18 0.15
2
0.18 0.15
2
0.18 0.15
2
2
The charge/discharge capacity at the first, 100th, 250th, 500th and 1000th cycle and the
capacity fade values of the cell for different electrolytes are presented in Table 4.

ACCEPTED MANUSCRIPT
-1
The first capacity value of the cell with KOH showed 20.2 Fg , which is close to the capacity
value of a traditional supercapacitor cell [44]. It was concluded that the complex 6 has
excellent potential in supercapacitor applications, and we believe that these organometallic
compounds will be used as supercapacitors in the near future after improving their properties.
The explanation of the fast decrease on the capacity of the cell is an important for future
+
-
studies. The decrease may be related to the reactions with the electrolyte (the K and OH ions
for KOH) and complex 6 which causes to obstruct the formation of electric field. Another
factor may be given the formation of buffer layer which block the formation of uniform
electric field due to motion of ions in electrolyte component. The last possible mechanism
may be the loss of the ionic permeability of the membrane. As a result, the fast capacity fade
of the cell should be pointed out some in situ experiments during the cycling of the cell.
3
. Conclusions
In this study, we successfully synthesized complex 6 and the crystal structure data was
compared with experimentally obtained and theoretically calculated data from the Gaussian
program. It was found that the structure matched the theoretically calculated data. The energy
gap of HOMO and LUMO of complex 6 was 3.88714 eV, which is important for the catalytic
activity.
We used complex 6 as a hybrid capacitor cell by using as an electrode material. Different
electrolyte materials were used to determine the highest performance of the cell. It should be
noted that KOH as an electrolyte in the cell was the best capacitive performance among the
others in this study. The highest obtained capacity value of complex 6 was 20.2 F/g, which is
a promising result for the energy storage applications for organometallic compounds. For

ACCEPTED MANUSCRIPT
energy technology, the capacitive properties of Ru-complexes is important, and we believe
that this type compound will be used as an energy storage material in the near future.
4
. Experimental Section
4
.1.General procedures
1
13
The H and C NMR spectra were recorded with a Bruker Avance III 300 or 400 MHz NMR
spectrometer with sample solutions prepared in CDCl . The chemical shifts were reported in δ
3
units downfield from the internal reference (Me Si) as seen in Figure 2. (C H ClN O Ru);
4
33 41
2
2
M= 634.20.D8 VENTURE Bruker AXS diffractometer *, Mo-K radiation (λ = 0.71073
α
Å), T = 150 K; triclinic P -1 (I.T.#2), a = 8.7163(7), b = 11.0249(10), c = 17.5312(15) Å, α =
8
1.993(3), β = 87.738(3), γ = 83.814(3) °, V = 1658.0(2) Å3. Z = 2, d = 1.270 g.cm-3, µ =
-1
0
.582 mm . The structure was solved by a dual-space algorithm using the SHELXT program
[
[
45], and then refined with the full-matrix least-squares methods based on F2 (SHELXL)
46]. The contribution of the disordered solvents to the calculated structure factors was
estimated following the BYPASS algorithm [47], implemented as the SQUEEZE option
in PLATON [48]. A new data set, free of the solvent contribution, was then used in the final
refinement. All non-hydrogen atoms were refined with anisotropic atomic displacement
parameters. H atoms were finally included in their calculated positions and treated as riding
on their parent atom with constrained thermal parameters. A final refinement on F2 with 7599
unique intensities and 359 parameters converged at ωR(F2) = 0.0546 (R(F) = 0.0227) for
6
958 observed reflections with I > 2σ(I). The ORTEP plot of the crystal structure is given in
supporting info.
Cyclic voltammetry of 6 was performed by using Zive SP1 potentiostat/galvanostat. A three-
electrode electrochemical cell system was used for CV measurements and the Ag/AgCl
electrode was chosen as the reference, a platinum disk as the working electrode and a

ACCEPTED MANUSCRIPT
platinum wire in the as the counter electrode were used in the cell, with acetonitrile containing
tetrabutylammoniumperchlorate (TBAP) as the supporting electrolyte. Electrochemical grade
TBAP and acetonitrile were purchased from Sigma-Aldrich. The CV of 6 was studied in the
potential range of +0.8 to -0.3 V at a differential scan rate of 10-400 mV/s.
To perform a device of the hybrid-capacitor, the following procedure was used. Before the
film application, the mixture of 80% complex 6, 10% carbon black and 10% PVDF were
milled in an ball milling system for 2h then an appropriate amount of NMP was added to
powder and re-milled for 24h. The obtained gel form of the mixture were coated on the Ti foil
o
using 100 µm doctor blade and were dried at 100 C for evaporation of the solvent. The film
was cut for 1.5 cm diameters for the insertion of the CR2032 case. Since the anode and
cathode of the capacitor are same, we named as electrode for both component of the cell.
Na SO , KOH, NaCl and n-Bu NClO were used as electrolyte materials for the cells. The
2
4
4
4
hybrid capacitors were designed as electrode /electrolyte/membrane (cellulose)/electrolyte
electrode configuration for device fabrication. The CV measurement of the cell was
/
performed using a two-electrode configuration and the capacity was measured using a
constant current of ±1 mA for the voltage range of (-0.4)-(+0.8) V since the largest loop was
obtained for this range in the CV graph of the cells.
The hybrid capacitors were designed using a CR2032 coin cell case and the electrode
/
electrolyte/membrane (cellulose)/electrolyte /electrode configuration was used for device
fabrication. The electrode materials were coated on Ti foil 8 mm in diameter using a doctor
blade. The film was fabricated using 80% active material, 10% carbon black and 10% PVDF
to increase conductivity and the grip of the electrode materials on the Ti substrate. Na SO ,
2
4
KOH, NaCl and n-Bu NClO were used as electrolyte materials for the cells. The CV
4
4
measurement of the cell was performed using a two-electrode configuration and the capacity
was measured using a constant current of ±1 mA.

ACCEPTED MANUSCRIPT
DFT optimisations of complex 6 were performed using the GAUSSIAN 09 W software
package with the B3LYP (Becke, 3-parameter, Lee-Yang-Parr)/LanL2DZ (Los Alamos
National Laboratory 2 Double Zeta) basis set. First, the molecular geometry was optimised by
DFT to determine the global minimum energy level and the optimised structure. The excited
level, HOMO and LUMO energies and molecular electrostatic potential (MEP) of complex 6
were obtained by these calculations. GC analyses were performed on a Shimadzu GC-2010
Plus equipped with an HP-5 capillary column. The yields were calculated by GC using an
internal standard (undecane); the yields are based on ketones.
4
4
.2.Synthesis
.2.1. 1-pentamethylbenzyl-3-hydroxyethylbenzimidazolium iodide
1
-(pentamethylbenzyl)benzimidazole (1 mmol) was dissolved in n-BuOH (5 mL), then 2-
o
hydroxyethyl iodide (1.2 mmol) was added. The solution was stirred for 24 h at 120 C. The
precipitated yellow solid was filtered, washed with diethyl ether (3x5 mL) and dried under
high vacuum. The precipitate was then crystallised from DCM-diethyl ether to give the title
compound as a yellow crystal (0.35 g, 75%).
1
H NMR (400 MHz, CDCl ) δ = 8.97 (s, 1H, NCHN), 7.80-7.50 (m, 4H, C H ), 5.59 (s, 4H,
3
6
4
CH C (CH ) -2,3,4,5,6), 4,64 (t, J=8 Hz, 4H, NCH CH ), 3.95 (t, J=8 Hz, 4H, NCH CH ),
2
6
3 5
2
2
2
2
1
3
2
1
1
.32 and 2.29 (s, 15H, CH C (CH ) -2,3,4,5,6). C NMR (100 MHz, CDCl ) δ = 140.7,
2 6 3 5 3
37.9, 134.3, 133.6, 132.0, 131.6, 127.5, 127.4, 124.1, 113.6, 113.2, 58.7, 49.9, 47.4, 17.4,
7.3, 17.2, 17.1, 17.0.
4
.2.2. Synthesis of complex 6
A suspension of 1-pentamethylbenzyl-3-hydroxyethylbenzimidazolium iodide (1 mmol) and
Ag O (1 mmol) was added to 10 mL of ad DCM, placed in a Schlenk tube and stirred in the
2
dark for 5 hours. Then, 0.5 mmol RuCl (HMB) was added to the solution. After stirring in
2
2

ACCEPTED MANUSCRIPT
the dark for 24 hours, the crude product was filtered through a pad of Celite in air. The filtrate
was concentrated to 5 mL and 10 mL of hexane was added to afford complex 6 as orange
crystals (0.4 g, 63%).
1
o
H NMR (CDCl , 400 MHz, 25 C): δ=1.98 (s, 3H, CH C (CH ) ), 2.10 (s, 18H, C (CH ) ),
3
2
6
3 5
6
3 6
2
4
.26 (s, 6H, CH C (CH ) ), 2.33 (s, 3H, CH C (CH ) ), 4.32 (d, 1H, j = 20 Hz, CH COO),
2 6 3 5 2 6 3 5 2
.93 (d, 1H, j = 20 Hz, CH COO), 5.37 (d, 1H, j = 20 Hz, CH C (CH ) ), 5.93 (d, 1H, j = 20
2
2
6
3 5
Hz, CH C (CH ) ), 6.45 (d, 1H, j = 20 Hz, C H ), 6.73 (t, 1H, j = 12 Hz, C H ), 7.03 (t, 1H, j
2
6
3 5
6
4
6
4
13
o
=
12 Hz, C H ), 7.19 (d, 1H, j = 20 Hz, C H ). C NMR (CDCl , 100 MHz, 25 C):δ=16.3
6 4 6 4 3
(
C (CH ) ), 16.7, 17.1, 17.3, 17.5, 17.7 (CH C (CH ) ), 49.7 (CH COO), 50.4
6 3 6 2 6 3 5 2
(
CH C (CH ) ), 94.7 (C (CH ) ), 109.1, 111.5, 122.4, 122.9 (C H ), 128.1, 132.5, 133.3,
2 6 3 5 6 3 6 6 4
1
33.8, 34.4, 135.2, 136.2, 136.9 (CH C (CH ) ), 170.6 (CH COO), 191.5 (C -Ru). HRMS
2
6
3 5
2
2
-
(
ESI): calcd. for C H ClN O Ru [M-H] 635.1978; found 635.1970; calcd. for
3
3
41
2
2
-
C H N O Ru [M-Cl] 599.2212; found 599.2230.
33
41
2
2
Appendix A. Supplementary data
CCDC 1579884 contains the supplementary crystallographic data for the compound
reported in this article. These data can be obtained free of charge via
http://www.ccdc.cam.ac.uk/data_request/cif, or from the Cambridge Crystallographic Data
Centre, 12 Union Road, Cambridge CB2 1EZ, UK; fax: (+44) 1223-336-033; or e-mail:
deposit@ccdc.cam.ac.uk.
Acknowledgements
The author Prof. Sedat Yaşar would like to thanks to TUBİTAK (114Z036) for financial
support to synthesis and characterisation of the complex 6, Dr. Serdar Altın also want to

ACCEPTED MANUSCRIPT
thanks to Inonu University under project numbers of 2016/53 and G2016/52 for the
electrochemical and capacitive properties of complex 6, and Erdinç Öz want to thanks to
TARLA project (project no: 2006K-120470) for the financial support.
REFERENCES
[
1] (a) From Laboratory Curiosities to Efficient Synthetic Tools, RSC Publishing, Cambridge,
UK, 2011; (b) F. Glorius, N-Heterocyclic Carbenes in Transition Metal Catalysis,
Springer-Verlag, Heidelberg, Germany, 2007; (c) V. Ce
Gade, Chem. Soc. Rev. 33 (2004) 619 ; (d) F. E. Hahn, M. C. Jahnke, Angew. Chem.
Int. Ed. 47 (2008) 3122; (e) S. Dı ez-Gonza lez, N. Marion, S.P. Nolan, Chem. Rev. 109
2009) 3612; (f) J. C. Y.Lin, R.T.W. Huang, C.S. Lee, A.W. Bhattacharyya, S. Hwang, I.
J. B. Lin, Chem. Rev. 109 (2009) 3561; (g) P. L. Arnold, I. J. Casely, Chem. Rev. 109
2009) 3599.
́sar, S. Bellemin-Laponnaz, L. H.
́
́
(
(
[
[
2] (a) D. Enders, O. Niemeier, A. Henseler, Chem. Rev. 107 (2007) 5606; (b) N. Marion,
S. Dı ez-Gonza lez, S.P. Nolan, Angew. Chem. Int. Ed. 46( 2007) 2988.
́
́
3] (a) G. Gasser, I. Ott, N. Metzler-Nolte, J. Med. Chem. 54 (2011) 3; (b) K. A. Nebioglu,
M. J. Panzner, C.A. Tessier, C.L. Cannon, W. Youngs, J. Coord. Chem. Rev. 251 (2007)
8
84.
[
[
4] W. A. Herrmann, Angew. Chem. Int. Ed. 41 (2002) 1290–1309
5] (a) Lee, H. M.; Lee, C. C.; Cheng, P. Y. Curr. Org. Chem. 2007, 11, 1491; (b) O. Kuhl,
Chem. Soc. Rev. 36 (2007) 592; (c) A. John, P. Ghosh, Dalton Trans. 39 (2010) 7183
[
6] (a) M. Bierenstiel, E.D. Cross, Coord. Chem. Rev. 255 (2011) 574; (b) C. Fliedel, P.
Braunstein, Organometallics, 29 (2010) 5614; (c) C. Fliedel, A. Sabbatini, P. Braunstein,

ACCEPTED MANUSCRIPT
Dalton Trans. 39 (2010) 8820; (d) C. Fliedel, G. Schnee, P. Braunstein, Dalton Trans.
2
474 (2009) 2474; (e) A. Ros, M. Alcarazo, D. Monge, E. Alvarez, R. Ferna ń dez, J. M.
Lassaletta, Tetrahedron Asymmetry, 21 (2010) 1557; (f) S. J. Roseblade, A. Ros, D.
Monge, M. Alcarazo, E. Alvarez, J.M. Lassaletta, R. Fernandez, Organometallics, 26
(2007) 2570; (g) A. Ros, D. Monge, M. Alcarazo, E. Alvarez, J.M. Lassaletta, R.
Fernandez, Organometallics, 25 (2006) 6039; (h) H. V. Huynh, D. Yuan, Y. Han, Dalton
Trans. (2009), 7262; (i) H.V. Huynh, C.H. Yeo, G.K. Tan, Chem. Commun. (2006) 3833
[
7] C. Gandolfi, M. Heckenroth, A. Neels, G. Laurenczy, M. Albrecht, Organometallics, 28
(2009) 5112
[
[
[
8] A. T. Normand, K.J. Cavell, Eur. J. Inorg. Chem. (2008) 2781–2800.
9] S. Horn, C. Gandolfi, M. Albrecht, Eur. J. Inorg. Chem. 2011, 2863–2868.
10] J. DePasquale, J.; N.J. White, E.J. Ennis, M. Zeller, J.P. Foley, E.T. Papish, Polyhedron,
5
8 (2013) 162–170.
[
[
11] P.L. Chiu, H.M. Lee, Organometallics, 24 (2005) 1692–1702.
12] V. Miranda-Soto, D.B. Grotjahn, A.L. Cooksy, J.A. Golen, C.E. Moore, A.L. Rheingold,
Angew. Chem. Int. Ed. 2011, 50, 631–635.
[
13] (a) J. Huang, E. D. Stevens, S.P. Nolan, J.L. Petersen, J. Am. Chem. Soc., 121 (1999)
2
674; (b) M. Poyatos, M. Mas-Marza, M. Sanau, E. Peris, Inorg. Chem. 43 (2004)
793; (c) L. Mercs, A. Neels, M. Albrecht, Dalton Trans. (2008) 5570; (d) Y. Cheng, H-
1
J. Xu, J-F. Sun, Y-Z. Li, X-T. Chen, Z-L. Xue, Dalton Trans., (2009) 7132.
[
14] A. Labande, J-C. Daran, N.J. Long, A.J.P. White, R. Poli, New J. Chem., 35 (2011)
2162–2168.

ACCEPTED MANUSCRIPT
[
15] Y. Cheng, J-F. Sun, H-L. Yang, H-J. Xu, Y-Z. Li, X-T. Chen, Z-L. Xue,
Organometallics, 28 (2009) 819–823.
[
[
[
[
16] W. B. Cross, C. G. Daly, Y. Boutadla, K. Singh, Dalton Trans. 40 (2011) 9722–9730
17] W. N. O. Wylie, A. J. Lough, R.H. Morris, Chem. Commun.46( 2010) 8240–8242.
18] F. Zeng, Z. Yu, Organometallics, 27 (2008) 6025–6028.
19] A. Sinha, P. Daw, S. M. W. Rahaman, B. Saha, J.K. Bera, J. Organomet. Chem.,696
(2011) 1248–1257.
[
[
20] W. N. O. Wylie, A.J. Lough, J. H. Morris, Organometallics, 28 (2009) 6755–6761.
21] M. Poyatos, J. A. Mata, E. Falomir, R. H. Crabtree, E. Peris, Organometallics, 22 (2003)
1110–1114.
[
22] M. Poyatos, A. Maisse-François, S. Bellemin-Laponnaz, E. Peris, L.H. Gade, J.
Organomet. Chem., 691 (2006) 2713–2720.
[
[
[
23] F. E. Fernández, M. C. Puerta, P. Valerga, Organometallics, 30 (2011) 5793–5802.
24] F. E. Fernández, M. C. Puerta, P. Valerga, Organometallics, 31 (2011) 6868–6879.
25] X-W. Li, F. Chen, W-F. Xu, Y-Z. Li, X-T. Chen, Z-L. Xue, Inorg. Chem. Commun. 14
(2011) 1673–1676.
[
[
[
26] W. N. O. Wylie, A. J. Lough, R.H. Morris, Organometallics, 30 (2011) 1236–1252.
27] M. Benitez, E. Mas-Marza, J. A. Mata, E. Peris, Chem. Eur. J. 17 (2011) 10453.
28] P. N. Muskawar, P. Karthikeyan, S. A. Aswar, P. R. Bhagat, S. S. Kumar, Arab. J. Chem.
9
(2016) 1765-1778.

ACCEPTED MANUSCRIPT
[
[
29] S. Hong, S. H. Lee, S. W. Kim, Electrochem. Solid-State Lett. 5 (2002) 227-230.
30] V. Barranco, M. A. Lillo-Rodenas, A. Linares-Solano, A. Oya, F. Pico, J. Ibañez, F.
Agullo-Rueda, J. M. Amarilla, J. M. Rojo, J. Phys. Chem. C, 114 (2010) 10302–10307.
[
[
31] T. Chen, L. Dai, Materials Today, 16 (2013) 272-280.
32] (a) Q.Yang, Z. Lu, J. Liu, X. Lei, Z. Chang, L. Luo, X. Sun, Natural Science: Materials
International, 23 (2013) 351-366; (b) D-Y. Lee, G-H. An, H-J. Ahn, journal of
Industrial and Engineering Chemistry, 52 (2017) 121-127; (c) J. Bae, J. Y. Park, O. S.
Kwon, C-S. Lee, Journal of Industrial and Engineering Chemistry, 51 (2017) 1-11; (d)
H. R. Barai, A. N. Banerjee, F. Bai, S. W. Joo, Journal of Industrial and Engineering
Chemistry, article in press, 2018.
[
33] J-Y. Wang, M-C. Wang, D-J. Jan, Sol. Energy Mater Sol. Cells. 160 (2017) 476-483.
[
34] C. Zhong, Y. Deng, W. Hu, J. Qiao, L. Zhang, J. Zhang, Chem. Soc. Rev. 44 (2015)
484.
7
[
35] M. M. T. Khan, Activation Of Small Inorganic Molecules, 1st Edition, Elsevier, 2012.
36] A. J. Blacker, Enantioselective transfer hydrogenation, in: C.J.E. Johannes, G. De Vries
[
(Eds.), The handbook of homegenous hydrogenation, Wiley-VCH, Weinheim, 2007.
[
[
37] T. Ikariya, A. J. Blacker, Acc. Chem. Res. 40 (2007) 1300-1308.
38] W. Baratta, J. Schütz, E. Herdtweck, W.A. Herrmann, P. Rigo, J. Organomet. Chem.,
690 (2005) 5570–5575.
[
[
39] S. Burling, B.M. Paine, D. Nama, W.S. Brown, M.F. Mahon, T.J. Prior, P.S. Pregosin,
M.K. Whittlesey, J. M .J . Williams, J. Am. Chem. Soc., 129 (2007) 1987–1995.
40] N. Gürbüz, S. Yaşar, E.Ö. Özcan, İ. Özdemir, B. Çetinkaya, Eur. J. Inorg. Chem. 19
(2010) 3051–3056.

ACCEPTED MANUSCRIPT
[
41] S. Demir, İ. Özdemir, B. Çetinkaya, E. Sahin, C. Arici, J. Coord. Chem. 64 (2011)
2565–2572.
[
[
42] B. Yigit, M. Yigit, I. Özdemir, E. Çetinkaya, Transit. Met. Chem. 37 (2012) 297–302.
43] J. Ajuria, E. Redondo, M. Arnaiz, R. Mysyk, T. Rojo, E. Goikolea, J. Power Sources,
3
59 (2017) 359, 17-26.
44] X. Zhang, X. Wang, L. Jiang, H. Wu, H. Wu J. Su, J. Power Sources, 216 (2012) 290-
96.
[
2
[
[
[
[
45] G. M. Sheldrick, Acta Cryst. A71 (2015) 3-8.
46] G.M. Sheldrick, Acta Cryst. C71 (2015) 3-8.
47] P. V. D. Sluis, A. L. Spek, Acta Cryst. A46 (1990) 194-201.
48] A. L. Spek, J. Appl. Cryst. 36 (2003) 7-13.

ACCEPTED MANUSCRIPT
Highlights:
-
-
-
Benzimidazol based NHC ligand and its chelated Ru(II)-NHC complex was reported.
Structure for Ag(I)-NHC was proposed.
Hybrid capacitor potential of chelated Ru(II)-NHC complex was investigated and
reported for the first time.
