Synthesis and studies of the inhibitory effect of hydroxylated phenylpropanoids and biphenols derivatives on tyrosinase and laccase enzymes

Article abstract of DOI:10.3390/molecules25112709

The impaired activity of tyrosinase and laccase can provoke serious concerns in the life cycles of mammals, insects and microorganisms. Investigation of inhibitors of these two enzymes may lead to the discovery of whitening agents, medicinal products, anti-browning substances and compounds for controlling harmful insects and bacteria. A small collection of novel reversible tyrosinase and laccase inhibitors with a phenylpropanoid and hydroxylated biphenyl core was prepared using naturally occurring compounds and their activity was measured by spectrophotometric and electrochemical assays. Biosensors based on tyrosinase and laccase enzymes were constructed and used to detect the type of protein-ligand interaction and half maximal inhibitory concentration (IC₅₀). Most of the inhibitors showed an IC₅₀ in a range of 20–423 nM for tyrosinase and 23–2619 nM for laccase. Due to the safety concerns of conventional tyrosinase and laccase inhibitors, the viability of the new compounds was assayed on PC12 cells, four of which showed a viability of roughly 80% at 40 μM. In silico studies on the crystal structure of laccase enzyme identified a hydroxylated biphenyl bearing a prenylated chain as the lead structure, which activated strong and effective interactions at the active site of the enzyme. These data were confirmed by in vivo experiments performed on the insect model Tenebrio molitur.

Full text of DOI:10.3390/molecules25112709

molecules
Article
Synthesis and Studies of the Inhibitory Effect of
Hydroxylated Phenylpropanoids and Biphenols
Derivatives on Tyrosinase and Laccase Enzymes
Maria Antonietta Dettori 1 , Davide Fabbri
,†
1,†
, Alessandro Dessì 1 , Roberto Dallocchio ,
1
Paola Carta 1 , Claudia Honisch
2,3
, Paolo Ruzza
2,3
, Donatella Farina , Rossana Migheli ,
4
4
4
5,6
5
4,
Pier Andrea Serra , Roberto A. Pantaleoni
, Xenia Fois , Gaia Rocchitta * and
1
,
Giovanna Delogu *
1
Istituto di Chimica Biomolecolare, Consiglio Nazionale Ricerche, 07100 Sassari, Italy;
mariaantonietta.dettori@cnr.it (M.A.D.); davidegaetano.fabbri@cnr.it (D.F.); alessandro.dessi@cnr.it (A.D.);
robertonico.dallocchio@cnr.it (R.D.); paola.carta@cnr.it (P.C.)
Dipartimento di Scienze Chimiche, Università degli Studi di Padova, 35131 Padova, Italy;
claudia.honisch@phd.unipd.it (C.H.); paolo.ruzza@unipd.it or paolo.ruzza@cnr.it (P.R.)
Istituto di Chimica Biomolecolare, Consiglio Nazionale Ricerche, 35131 Padova, Italy
Dipartimento di Scienze Mediche, Chirurgiche e Sperimentali, Università degli Studi, 07100 Sassari, Italy;
donatellafarina@tiscali.it (D.F.); rmigheli@uniss.it (R.M.); paserra@uniss.it (P.A.S.)
Istituto di Ricerca sugli Ecosistemi Terrestri, Consiglio Nazionale Ricerca, 07100 Sassari, Italy;
roberto.pantaleoni@iret.cnr.it (R.A.P.); xeniafois@hotmail.it (X.F.)
2
3
4
5
6
Dipartimento di Agraria, Università degli Studi, 07100 Sassari, Italy
*
Correspondence: grocchitta@uniss.it (G.R.); giovanna.delogu@icb.cnr.it (G.D.);
Tel.: +39-079-228526 (G.R.); +39-079-2841220 (G.D.)
†
These authors contributed equally to this work.
ꢀ
ꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Michael Gütschow
Received: 16 April 2020; Accepted: 9 June 2020; Published: 11 June 2020
ꢀ
ꢁꢂꢃꢄꢅꢆ
Abstract: The impaired activity of tyrosinase and laccase can provoke serious concerns in the life cycles
of mammals, insects and microorganisms. Investigation of inhibitors of these two enzymes may lead to
the discovery of whitening agents, medicinal products, anti-browning substances and compounds for
controlling harmful insects and bacteria. A small collection of novel reversible tyrosinase and laccase
inhibitors with a phenylpropanoid and hydroxylated biphenyl core was prepared using naturally
occurring compounds and their activity was measured by spectrophotometric and electrochemical
assays. Biosensors based on tyrosinase and laccase enzymes were constructed and used to detect
the type of protein-ligand interaction and half maximal inhibitory concentration (IC ). Most of
50
the inhibitors showed an IC50 in a range of 20–423 nM for tyrosinase and 23–2619 nM for laccase.
Due to the safety concerns of conventional tyrosinase and laccase inhibitors, the viability of the new
compounds was assayed on PC12 cells, four of which showed a viability of roughly 80% at 40 µM. In
silico studies on the crystal structure of laccase enzyme identified a hydroxylated biphenyl bearing a
prenylated chain as the lead structure, which activated strong and effective interactions at the active
site of the enzyme. These data were confirmed by in vivo experiments performed on the insect model
Tenebrio molitur.
Keywords: oxidase and polyphenol oxidase; polyphenols; tyrosinase inhibitors; chitin inhibitors;
SAR studies; biosensors; spectrophotometric assay; viability
1
. Introduction
Tyrosinase—also referred to as monophenol monooxygenases (E.C. 1.14.18.1)—is a key enzyme
in melanin biosynthesis and is involved in determining the color of mammalian skin and hair, the
Molecules 2020, 25, 2709; doi:10.3390/molecules25112709
www.mdpi.com/journal/molecules

Molecules 2020, 25, 2709
2 of 21
enzymatic browning of plant-derived food, and the molting process of insects [
1
,2
]. Tyrosinase contains
a binuclear, active copper site responsible for catalyzing two distinct reactions involving molecular
oxygen. These reactions are the hydroxylation of monophenols to o-diphenols (monophenolase activity)
and the oxidation of o-phenols to o-quinones (diphenolase activity), as described in Figure 1.
Figure 1. Enzyme reactions of (a) tyrosinase and (b) laccase and (c) natural inhibitors.
In the central domain of tyrosinase, in all living organisms originating from a common ancestral
gene, the two copper ions activate interactions with oxygen atoms [3]. Each copper ion is bound
to three conserved histidine residues which are essential for the stabilization of the active site.
The natural substrate of tyrosinase, the amino acid L-tyrosine, is also the melanin precursor. An
abnormal lack of melanin causes albinism, whereas an excessive accumulation of melanin can
result in hyperpigmentation, melanoma in humans, as well as undesirable browning in fruits and
vegetables [
4–
6]. Tyrosinase oxidizes dopamine, which forms melanin in the brain, and thus plays a
role in the first stage of Parkinson’s and other neurodegenerative diseases [
7]. Moreover, the enzyme
product melanin has been shown to compromise the activity of traditional antibiotics [8].
Laccase, a phenoloxidase (PO, EC 1.10.3.2), is a member of multicopper oxidases family that has
been found in higher plants, fungi, bacteria and insects [9,10]. It catalyzes the monoelectronic oxidation
of substrates at the expense of molecular oxygen (Figure 1) [11]. Laccases have a wide substrate range,
and thus are used for industrial purposes and/or bioremediation processes [12].
Like tyrosinase, laccase was found in the cuticle of many insect species, and plays a primary role
in insect development and immunity, such as cuticle sclerotization, wound healing and defense against
foreign pathogens, and thus provides a new target for insect pest control [13,14].
Several crystal structures of different tyrosinases and laccases from various sources have been
isolated and studied [15–18], however a high-resolution structure of human tyrosinase has not been
fully characterized due to its flexible structural feature [19].
Laccases and tyrosinases are two groups of phenoloxidases that catalyze the transformation of a
large number of phenolic and non-phenolic aromatic compounds. Investigating the inhibitors of both
enzymes would thus lead to the development of a wide range of compounds ranging from novel skin

Molecules 2020, 25, 2709
3 of 21
whitening agents, to medicinal products, to anti-browning substances and to compounds capable of
controlling harmful insects and bacteria [20 22]. From a mechanistic point of view, a commercially
–
suitable tyrosinase/laccase inhibitor would bind reversibly to the enzyme and reduce its catalytic
capacity [23]. Although many tyrosinase and laccase inhibitors have been identified and their activity
has been measured even at low concentrations, few have been put into practical use. The main reasons
are the lack of the specific activity, instability and safety concerns [24,25].
Commercial alternatives to hydroquinone and rhodendrol, two tyrosinase inhibitors both banned
from the market due to health concerns [26], include natural-occurring compounds such as kojic acid
[
(
5-hydroxy-2-(hydroxymethyl)-4H-pyran-4-one] and arbutin (hydroquinone-O-
Figure 1) [27 28]. Unfortunately, neither compound offers a satisfactory safe and effective
replacement [29].
However, compound
β-d-glucopyranoside)
,
0
(4,4 -dihydroxy-biphenyl), a biphenol produced by cyanobacteria and
1
known as a radical scavenger, has been found to be a potent tyrosinase inhibitor—and more effective
than kojic acid and arbutin (Figures 1 and 2) [30]. It interacts with tyrosinase enzyme as a classical
reversible competitive inhibitor.
Structurally, compound
1 belongs to the class of hydroxylated biphenyls widely distributed in the
plant kingdom [31]. Hydroxylated biphenyls play an important role in biosystems due to their unique
pharmacophore structure that is made up of two aromatic rings bridged by a single C–C bond [32]. The
high level of specificity of the hydroxylated biphenyls scaffold with the catalytic domain of different
proteins suggests that the structure could be an effective template for the discovery and design of new
protein targets [33–35].
In our continuing research on the synthesis of hydroxylated biphenyls with interesting
stereochemical and biologic features [36
i.e., compounds ) structurally related to compound
spectrophotometric and electrochemical assays, using a tyrosinase biosensor for the electrochemical
–40], we recently prepared a set of C -symmetry biphenols
2
(
2–
6
1 and evaluated their tyrosinase inhibition by
assays [41]. Some of the molecules reported here (compounds 2, 3, 5 and 6) showed a higher tyrosinase
inhibitory activity than that of biphenol 1 (Figure 2).
The molecular basis of the new inhibitors mainly relies on an
conjugated to an aromatic scaffold which confers complete electron delocalization to the molecule thus
reducing its redox potential [42 44]. This geometric motif is highly susceptible to electron transfer
reactions with the amino acid residues of the catalytic domain of tyrosinase and laccase proteins [45 46].
α,β-unsaturated carbonyl function
–
,
With this in mind—and inspired by recent articles on new tyrosinase and laccase phenolic
inhibitors—the aim of the present work is to prepare a small library of compounds with unsaturated
chains whose structures are reminiscent of hydroxylated phenyl propanoids and biphenols. The
effect of the compounds on the viability of PC12 cells was also assayed. A set of biosensors based on
tyrosinase and laccase enzymes was constructed, and the inhibitory activity of the compounds was
detected separately. Biosensor detection enabled us to investigate the reversibility of the inhibitors,
the type of protein-ligand interactions that affect the catalytic domain, and lastly the IC50 of the new
compounds. A computational study on the interactions between a laccase crystal data set and a
potential cuticle inhibitor was performed in accordance with in vivo assays carried out on mealworm
larvae of the insect model Tenebrio molitor.
2
. Results
2
.1. Synthesis of Compounds
Figure 2 shows a set of phenols and hydroxylated biphenyls, compounds 7, 8 and 10–17, bearing
an α,β-unsaturated carbonyl function, which were prepared under straightforward and sustainable
procedures. Three biphenyl-analogs of
units were also prepared.
1, compounds 18–20, embedded with prenylated or glycosylated

Molecules 2020, 25, 2709
4 of 21
Figure 2. Hydroxylated phenylpropanoids and biphenols derivatives.
Starting with an appropriate ketone and aldehyde the Claisen-Schmidt condensation reaction
was applied to synthetise compounds 16. This involves the reaction of a ketone with an aldehyde
under basic conditions with the simultaneous loss of a water molecule. Compound was prepared
with a more straightforward and sustainable procedure than that the one used in the literature for the
7
–
7
synthesis of this compound [43] producing a 60% yield, whereas compounds
described in the literature (Scheme 1) [40,47–49].
8–11 were prepared as
Dimer of chalcone 11, biphenyl 14, was prepared starting with the reaction of OMe-
dehydrodiapocynin and four equivalents of tetrahydropyranyl vanillyl acetal (Scheme 2).
Both A rings of chalcones 12 and 15 have the core of apocynin (3-methoxy-4-hydroxyacetophenone)
which in the presence of 3,4-dimethoxybenzaldehyde for chalcone 12 and OMe-dehydrodivanillin
for biphenyl 15, led to yields for the two chalcones of 85% and 70%, respectively (Schemes 1 and 2).
Following the same procedure as applied for 15, chalcone 16 was prepared with a 55% yield using
2
-hydroxy-5-methoxyacetophenone as the starting ketone. The glycosylated compound 13 was obtained
by the condensation reaction of per-O-acetylated -C-glucopyranosyl ketone and tetrahydropyranyl
β
vanillyl acetal under basic conditions and further cleavage of the tetrahydropyranyl and acetate
protecting groups (Scheme 2). Dimer of ferulic ethyl ester 17 was obtained from the esterification of
the corresponding diacid with a 95% yield, obtained in turn by a known procedure. Biphenol
1
and its
derivate 3,3 -dibromo-4,4 -dihydroxy-biphenyl, were glycosylated at one phenolic–OH group by the
reaction of 2,3,4,6-tetra-O-acetyl- -d-glucopyranosyl bromide and K CO and further hydrolysis of
acetyl groups which obtained compounds 18 and 19, respectively, as β-anomer (Scheme 3).
0
0
α
2
3

Molecules 2020, 25, 2709
5 of 21
◦
a) for compound 7: NaOH, acetone, 12 h at 50 C; for compounds
Scheme 1. Reagents and conditions: (
and : NaOH acetone, 12 h at rt; for compound 10: LiOH, MeOH, 6 days at rt; for compound 11
KOH, MeOH, 12 h at rt; for compound 12: KOH/H O, MeOH, 96 h at rt; for compound 13: pyrrolidine,
8
9
,
:
2
CH Cl , 72 h then PPTS, 3 h at rt then MeONa/MeOH, 10 min at rt; (b) Pd/C 10%, EtOAc, 3 h at rt.
2
2
◦
Scheme 2. Reagents and conditions: (
MeOH, 3 h at 0 C → 12 h at rt, then p-TsOH, 2 h at rt.
a
) KOH/H O, MeOH, 3 h at 0 C, then 96 h at rt; (
b
) KOH/H O,
2
2
◦

Molecules 2020, 25, 2709
6 of 21
Scheme 3.
Reaction and conditions:
(
a
)
Br2, CH Cl , AcOH, 48
h
at rt;
(b)
2
2
◦
2,3,4,6-tetra-O-acetyl-
α
-d-glucopyranosyl bromide and K CO in acetone for 48 h at 50 C, then
2
3
MeOH: EtOAc 1:1 solution, MeONa at rt for 1 h; (
at 100 C.
c
) DMF, Cs CO , [Pd(OAc) ] , linalool, MW 10 min
2 3 2 3
◦
0
0
The oxidative coupling reaction of 3,3 -dibromo-4,4 -dihydroxy-biphenyl with linalool in the
presence of [Pd(OAc) ] catalyst and under microwave conditions, after 10 min, led to a 40% yield of
2
3
dimer 20.
2
.2. Spectrophotometric Detection of Tyrosinase Inhibitory Activity
The ability of compounds 7–20 to inhibit tyrosinase activity was evaluated by UV-Vis spectroscopy
using either the natural substrate tyrosine or dopamine, and slightly modifying the previously described
method [41 50 51]. The oxidation of tyrosine by tyrosinase enzyme induced the appearance of two
,
,
distinct absorption bands at 311 and 472 nm (Figure S1). The first band was attributable to the
o-diphenol formation, while the latter was due to the production of the o-quinone (Figure S1).
The time course of tyrosine oxidation at 311 nm (Figure S1 insert) showed the characteristic
lag-phase due to the time required to accumulate a sufficient amount of o-diphenol by the catalytic
activity of the small amount of oxy-tyrosinase present in the enzyme preparation. The o-diphenol is
subsequently transformed to o-quinone by the met form of tyrosinase which is reduced to the deoxy
form, which shows a high affinity for molecular oxygen originating the oxy form [21,23,52]. On the
other hand, the oxidation of dopamine by tyrosinase induces the appearance of the only absorption
band at about 470 nm attributable to the o-quinone formation (Figure S2).
As shown in the insert of Figure S2, the time course of dopamine oxidation is characterized by
the absence of the lag-phase due to the o-diphenol structure of dopamine. This substrate, in fact, can
be used to selectively evaluate the diphenolase activity of tyrosinase. In addition, a decrease in the
intensity of the o-quinone band was detected with increasing time reaction.

Molecules 2020, 25, 2709
7 of 21
The efficiency of the tested compounds to inhibit the tyrosinase activity was determined by
comparing the absorbance intensity at either 311 or 472 nm of the oxidized substrates alone or with
inhibitors at different times according to Equation (1):
%
inhibition = 1 − [(D − C) / (B − A)] × 100
(1)
where C and D are the absorbance values at either 311 or 472 nm in presence of inhibitor before the
mixing, and after either 24 or 10 min, using tyrosine or dopamine as the substrate, respectively. A and
B are the corresponding values without the inhibitor. The results are summarized in Figure 3.
Figure 3. Percentage of tyrosinase inhibition determined by UV-Vis spectroscopy. Tyrosine was
dissolved in 50 mM phosphate buffer, pH 6.8, final concentration 80
µM and with the added inhibitor
(
final concentration 20 M) and tyrosinase (83 U/mL). The absorbance values were determined after 24
µ
min of incubation. In the presence of dopamine, experiments were performed using 10-fold diluted
solutions, and the absorbance values were determined after 10 min of incubation.
As shown in Figure 3, compound
7 was the most active tyrosinase inhibitor in the presence of
both substrates. Similarly, compounds 16 and 10 also showed a comparable activity in both the tested
substrates, although their efficiency was reduced (about 70% for 16 and only 10% for 10). All the
other tested compounds were characterized by a preferential activity in one of the used substrates. In
particular, compounds 11, 12, 13, 14, 15, 18 and 19 were characterized by a predominant inhibition of
tyrosine oxidation, similar to that observed for biphenyl
) strongly inhibited the oxidation of dopamine compared to that of tyrosine, suggesting a selectivity
towards the diphenolase activity of tyrosinase.
1. The remaining compounds (i.e., 8, 9, 17 and
2
0
2
.3. Evaluation of IC50 and Inhibitory Activity of Compounds 7–20 with Tyrosinase and Laccase Biosensors
As shown in Table 1, the IC50 values obtained of each compound on tyrosinase and laccase
enzymes were evaluated.

Molecules 2020, 25, 2709
8 of 21
Table 1. Calculated IC50 of each compound on tyrosinase and laccase enzymes and type of inhibition
exerted. Concentrations are expressed in nM.
Compound
IC50
Type of Inhibition
Tyrosinase
Laccase
Tyrosinase
Laccase
7
8
9
26
54
122
101
38
72
20
22
120
62
27
218
2238
212
62
1043
23
47
209
987
184
2619
130
118
competitive
mixed
competitive
mixed
competitive
noncompetitive
uncompetitive
mixed
competitive
competitive
mixed
competitive
noncompetitive
competitive
competitive
mixed
competitive
competitive
mixed
competitive
competitive
competitive
competitive
competitive
competitive
10
11
12
13
14
15
16
17
18
19
20
130
65
24
competitive
noncompetitive
competitive
423
For the tyrosinase enzyme, all the compounds showed IC50 values ranging between 20 and 130 nM.
Only compound 20 showed a higher IC , equal to 423 nM.
50
The values of IC50 for laccase were generally higher than those obtained for tyrosinase. Table 1
shows that compounds 11 13 and 14 had a lower IC50 value than 100 nM. Most of the compounds
7
,
,
tested had an IC50 value between 118 and 218 nM. While compounds 12 and 16 yielded an IC50 value
of about 1000 nM, compounds 9 and 18 exceeded 2000 nM.
The inhibitory activity of the compounds on tyrosinase and laccase enzymes was assessed as
explained in Section 4.3. Lineweaver-Burk plots, derived from VMAXs and K s values obtained
M
by biosensor calibrations, whose values are shown in Table S1 in the Supplementary Materials, are
reported in Figures S3–S16 and summary data are reported in Table 1. A representative IC50 calculation
plot for tyrosinase and laccase has been reported in Figure S17 for compound 20.
The data indicate that all the compounds are reversible inhibitors. Seven of the tested compounds
produced the same type of inhibition on both enzymes, which proved to be competitive. The
Lineweaver-Burk plot obtained for compound
7 highlights a competitive inhibition on the tyrosinase
enzyme (Table 1), as previously demonstrated with different techniques [43]. In fact, the presence
of the inhibitor resulted in a significant increase in K s, but VMAXs was essentially the same. Only
M
compound 14 led to a mixed inhibition on both enzymes, resulting in a significant variation in both
VMAX and KM.
The remaining compounds resulted in different types of inhibitions on the two enzymes. In most
cases, such as
8, 10 and 17, the tyrosinase enzyme suffered from a mixed inhibition, undergoing a
variation in both VMAX and K , while on the laccase enzyme, a competitive inhibition was highlighted
M
for compounds 10 and 17. On the other hand, compound 8 led to a noncompetitive inhibition, in which
there was a significant variation in enzyme VMAX, but not K . Compound 11 led to a competitive
M
inhibition on tyrosinase, but a mixed inhibition on laccase.
In addition, 12 and 19 produced the same type of noncompetitive inhibition on tyrosinase, as they
led to a significant variation in VMAX, leaving KM substantially the same, but a competitive inhibition
on laccase. The remaining compounds exerted different inhibition type on tyrosinase and laccase.
Compound 11 produced a competitive inhibition on tyrosinase, while exerting a mixed inhibition on
laccase. Finally, compound 13 produced the only uncompetitive inhibition on tyrosinase enzyme, but
led to a competitive inhibition on laccase.

Molecules 2020, 25, 2709
9 of 21
2
.4. Computational Evaluation of Laccase Inhibitory Activity
The laccase X-ray structure of Trametes versicolor fungus [18] was used to perform molecular
docking with a conventional chitin inhibitor, diflubenzuron (N-[(4-chlorophenyl)carbamoyl]-2,6-
difluorobenzamide) (DFB). The best docked conformation of DFB (the lowest binding energy and
highest population) was well embedded inside the hydrophobic binding pocket at T1 site in the crystal
structure of the enzyme featured by the Cu1–N cluster formed with the residue of HIS458 (Figure 4).
The chitin inhibitor fits the catalytic domain with an inhibition constant Ki of 56.87 µM and activates
H-bond with ALA393 and lipophilic interactions with HIS458 whose basic residue is involved in the
key interaction Cu1–N. Table S1 lists the scores of the binding conformation for DBF.
The docking protocol was evaluated then on biphenyl 1 and biphenyl 20 which both share the
same hydroxylated core, but have different lipophilicity values due to two additional prenylated chains
located at 3,3’ positions in biphenyl 20 (Figure 4). The interactions with the protein are almost similar
to that of DFB and thus reveal the same lipophilic interaction with HIS458 (Figure 5 and Table S2).
The Ki values for biphenyl
1
and 20 were 108.39 and 29.54
µM, respectively. Both biphenyls activated
more H-bonds than DFB with the following amino acids: PRO163 and ALA393 for biphenyl
1
and
PHE162 and ASN264 for biphenyl 20. Moreover, compound 20 also interacted with further amino
acids involved in the catalytic site of laccase enzyme. The docking study of biphenyl 20 is in agreement
with the results achieved from the kinetics study, where a competitive action was detected.
Figure 4. Representation of diflubenzuron (N-[(4-chlorophenyl)carbamoyl]-2,6-difluorobenzamide)
(
DFB), compounds 1 and 20 with the catalytic T1 site of laccase performed with Chimera [53].

Molecules 2020, 25, 2709
10 of 21
Figure 5. Hydrophobic interactions of DFB, compounds
respectively and performed with LigPlot+ [54].
1 and 20 with the catalytic T1 site of laccase,
2
.5. Cytotoxicity of Inhibitors and Protection Against Oxidative Stress
Initially, the inhibitor concentrations on PC12 cells, i.e., a rat pheochromocytoma-derived cell line,
were screened to assess the possible cytotoxicity of the molecules under study [55]. As highlighted in
Table 2 and in Figures S3–S16, compounds 11 12 14 15 and 16 were found to be toxic to cells, as they
resulted in a significant (p < 0.05) decrease in viability, when compared with the control, ranging from
a concentration of 5 M up to 40 M. Given the toxicity of these compounds, the protective activity
against oxidative stress of these compounds was not tested.
,
,
,
µ
µ

Molecules 2020, 25, 2709
11 of 21
Table 2. Results obtained on PC12 cells following the screening of concentrations (from 1 to 40
the compounds under study, the co-treatment with 100 µM H O and with 1 mM MnCl .
µM) of
2
2
2
Toxic Concentration
H O Damage Protection
MnCl Damage Protection
2
2
2
Compound
(
µM) 1
(µM)
(µM)
7
8
9
>10
40
>10
>20
>10
>1
>20
>5
>5
1
n.p.
n.a.
n.a.
n.p.
n.a.
n.a.
n.a.
n.a.
n.a.
n.a.
n.a.
n.a.
n.a.
1
n.p.
n.p.
20
10
11
12
13
14
15
16
17
18
19
20
n.a.
n.a.
n.p.
n.a.
n.a.
n.a.
n.p.
n.p.
n.p.
>5
>5
none
none
none
none
1
cell viability < 80%; n.p.: no protection; n.a.: not available;
Although the remaining compounds resulted in a significant (p < 0.05) decrease in viability when
compared with control, they produced a loss of viability of about 20% at all the concentrations tested.
There was only a more sustained decrease in viability for compounds
to 45%, but just at the highest concentrations. Given the low impact on cell viability, for these four
compounds the possible protection against oxidative stress induced by hydrogen peroxide 100
7, 9, 10 and 20, from 30% up
µM
was assessed. As shown in Figures S5–S16, most the compounds with low impact on cell viability
did not protect PC12 cell culture from oxidative stress. Consequently, these compounds were unable
to restore the reduced cell viability due to hydrogen peroxide. Compounds
8, 18 and 19 produced a
significant decrease (p < 0.05 vs H O ) in cells viability at all concentrations tested while compounds
9
2
2
and 13 only led to a significant decrease (p < 0.05 vs H O ) at a concentration of 20 µM.
2
2
Only three compounds,
7, 10 and 20, showed a protective activity against H O -induced oxidative
2 2
stress, at 1 M for compound 7, at 20 µM for compound 10, while at >5 µM for compound 20, producing
µ
a significant increase (p < 0.05) in cells viability when compared with that produced by hydrogen
peroxide. Therefore, these three compounds were also tested for protection against oxidative stress
generated by manganese dichloride. As shown in Figures S3 and S6, compound 7 and 10 were not able
to restore the cells viability reduced by MnCl treatment. On the contrary, compound 20 exhibited a
2
general increase in cells viability, but which was significant (p < 0.05 vs MnCl ) only at a concentration
2
of 1 µM.
2
.6. Insecticidal Properties of Inhibitors
Mortality differed significantly among treatments (F15:79 = 44.47, p-value < 0.001). Of those tested,
only compound 20 showed some insecticidal activity on mealworm larvae (Tenebrio molitor) though
significantly less than diflubenzuron (DFB), an inhibitor of chitin synthesis (Table 3).

Molecules 2020, 25, 2709
12 of 21
Table 3. Insecticide activity, as percentage of mortality, on mealworm larvae (Tenebrio molitor) of
fourteen of inhibitors compared with DFB*.
√
Mortality%
Mean ± SD)**
Arcsine( x)
Mean Comparison***
(Duncan Test, α = 0.05)
Compounds
(
Transformation
DFB
control
97.0 ± 4.47
1.0 ± 2.24
2.0 ± 2.74
4.0 ± 5.48
3.0 ± 2.74
3.0 ± 4.47
16.0 ± 9.62
1.0 ± 2.24
5.0 ± 7.07
10.0 ± 7.07
4.0 ± 6.51
4.0 ± 2.24
0
1.46 ± 0.15
0.05 ± 0.10
0.09 ± 0.12
0.13 ± 0.18
0.14 ± 0.12
0.11 ± 0.15
0.40 ± 0.13
0.05 ± 0.10
0.14 ± 0.20
0.29 ± 0.17
0.12 ± 0.18
0.18 ± 0.10
0
a
e
e
e
e
e
1
2
3
4
5
6
7
8
9
d
d
d
c
e
e
d
c
d
d
d
e
e
e
e
e
11
12
14
15
20
0
0
0
0
67.0 ± 14.83
0.97 ± 0.16
b
*
Treatments for immersion in 2.5 mL compound/acetone solution at concentration of 6.4 mg/mL (w:v). Details in
Section 4.5. **Mean
±
SD of mortality proportion data after arcsine transformation (arcsine of the square root).
*
**Means followed by the same letter are not significantly different.
3
. Discussion
Based on the design and synthesis of tyrosinase inhibitors in literature with an
α,β-unsaturated
carbonyl function, we focused on the synthesis of propanoids derivatives, particularly on
chalcone-derivatives. We incorporated this functional motif into the structures of simple phenols and
hydroxylated biphenyls (i.e., compounds
spectrophotometric and electrochemical assays. Of the synthetic methods that provide the synthesis
of an -unsaturated carbonyl function conjugated to an aromatic scaffold, the Claisen-Schimdt
condensation seemed to be the most straightforward route.
In compounds 7, 8 and 10 17 the presence of a conjugated double bond and a wide delocalization
-electrons decreases the redox potential of the molecule that would be activated, as Michael
7–17) and a comparison was made in terms of activity by
α,β
–
of
π
acceptor, to electron transfer reactions with nucleophilic species present in the amino acids residues of
the protein.
Given the role that biphenol 1 plays as tyrosinase inhibitor [41], we used this scaffold to prepare
biphenyl-analogs 18
–20 with prenylated or glycosylated units. Under pressure and microwave
conditions and by palladium-catalyzed Heck reaction, we were able to reduce the time of the reaction
when a prenylated chain was added to compound 1, brominated beforehand, to achieve diprenylated
biphenyl 20.
Hydroxylated biphenyls 14–17 and 20 possess a C -symmetry axis that create the two
2
indistinguishable aromatic rings. This structural feature provides an increase in reaction selectivity and,
in terms of molecule-protein recognition, identical interactions would take place on each symmetrical
portion of the molecule. As with dimeric secondary metabolites present in plants that manifest
inhibition to tyrosinase enzyme [56], we prepared hydroxylated biphenyls 14–20 bearing functional
groups that use the chemical space effectively by increasing the structural complexity and providing
more interactions with amino acid residues.
Compound
electrochemical assays in accordance with the literature [43]. This compound was used by us
as a control. The activities of compounds 20, all of which containing one or two phenolic–OH groups,
were correlated to . Spectrophotometric results showed that in the chalcone series the presence
of electron donating groups in both aromatic rings promoted enzyme–inhibition interactions (i.e.,
7 is a potent tyrosinase inhibitor as detected in both spectrophotometric and
8–
7

Molecules 2020, 25, 2709
13 of 21
compound 10 versus 11
,
12 and 14
–
16, Figure 3). The presence of a phenolic–OH group in 4-position of
the aromatic ring plays a key role in the activity of chalcones monomers 11 and 12, highlighting that 11
has a higher percentage of inhibition given the better electron delocalization throughout the structure.
Unlike monomers 11 and 12, the position of the phenolic–OH group in the A or B ring of
chalcone structure was irrelevant in the corresponding dimers 14 and 15. This is likely due to the
extended electron delocalization in the biphenylic structure and the improved π-π stacking interactions
that contributed to effective tyrosinase inhibition. Similar inhibitory activity to the monophenolasic
activity was detected for dimer 16 where the phenolic–OH group is in ortho-position thus creating a
six-membered intramolecular H-bonded ring which would stabilize the compound and promote the
copper coordination of the tyrosinase catalytic domain. A hydroxylated biphenyl structure was also
used as a lead structure for the synthesis of compounds 17–20 where a different trend of mono and
diphenolasic activity was detected in relation to the moiety bonded to the hydroxylated core. Free
phenolic–OH group and high hydrophilicity (i.e., compound 18) both favored monophenolasic activity
whereas the increase of lipophylicity as in compounds 19 and 20 affected that enzyme phase.
The diphenolase activity of tyrosinase was determined using dopamine as substrate using the
spectrophotometric method. The decrease in the intensity of the o-quinone band (Figure S2) was likely
due to the reaction of the o-quinone moiety with either the amino group of dopamine (intramolecular
reaction) or reactive groups (amino, hydroxyl, thiol) present on the surface of the enzyme. This
behavior has been described for analogs of caffeic acid, which at high concentrations act as irreversible
(
suicide) inhibitors of tyrosinase due to the high reactivity of the corresponding o-quinone [57
,58].
Compounds 17 and 20 manifested a selectivity towards the diphenolasic phase probably due to a
8, 9,
restricted molecular volume, high structural flexibility and antioxidant activity which together may
provide strong interactions with the amino acids residues or with the substrate dopamine.
Electrochemical detection of dopamine oxidation in the presence of the studied compounds
performed by biosensors and based on the immobilization of tyrosinase and laccase enzymes provided
useful information on the diphenolasic phase by identifying the type of interaction. In a biosensor,
the mechanism of enzyme inhibition is often complex due to the enzyme immobilization, thus the
interference with the active site by the action of an inhibitor could give different results from those
achieved when the enzyme is in a free aqueous medium as in the spectrophotometric assay.
The mode of inhibition can be competitive, uncompetitive, mixed type (competitive/uncompetitive)
and noncompetitive. A competitive inhibitor can bind to the free enzyme preventing the substrate from
binding to the catalytic active site, whereas an uncompetitive inhibitor binds only the enzyme–substrate
complex. When a compound binds to the free enzyme and the enzyme–substrate complex with the
same equilibrium constant, it can be considered a noncompetitive inhibitor. Mixed and competitive
types are the main modes of inhibition observed for phenols and polyphenols in kinetics studies on
mushroom tyrosinase [23].
Even though to different extent, compounds 7, 9, 15, 16, 18 and 20 inhibited both tyrosinase and
laccase enzymes competitively by mimicking the substrate of the enzyme and, probably, by trapping
the o-dopaquinone intermediate due to the nucleophilic feature of the phenolic–OH group present in
these compounds. Compounds 10, 13 and 17 are uncompetitive or mixed inhibitors for tyrosinase
enzyme by binding the enzyme-dopamine complex, whereas they showed a competitive inhibition in
the presence of laccase. Laccases tend to have a broader range of substrates than that of tyrosinase.
Our data confirmed this trend by identifying eleven compounds as competitive inhibitors for laccase
(
Table 1). Interestingly, a different behavior was observed between chalcones isomers 11 and 12 towards
tyrosinase and laccase, respectively, highlighting how a different electron delocalization and a strong
hydrogen bond may influence the interactions enzyme-substrate-inhibitor.
With regard to IC , all the compounds studied, except for compound 20, had low value in
50
the tyrosinase series, whereas laccase had a broader range of the IC50 values and was sensitive to
the compound structure. Since conventional inhibitors suffer from toxicity and lack of efficacy, all
compounds were subjected to viability assay on PC12 cells. Compounds 17–20 showed almost no

Molecules 2020, 25, 2709
14 of 21
toxicity (cell viability
oxidative stress caused by H O and MnCl treatments.
−
80%) on PC12 cells up to 40
µ
M and among them, biphenyl 20 protected against
2
2
2
Taking in account the key role that different types of laccases have in the cuticle of many insects
species suggesting an involvement in cuticle sclerotization, compound 20 together with compounds
7
-
9
,
11
,
12
,
14 and 15 which showed a good inhibition to laccase enzyme, were assayed in vivo against
, which we had detected in the
larvae of Tenebrio molitor as a model insect. Tyrosinase inhibitors
1–6
diphenolasic phase [41], were added to the same assay. Of the compounds tested, only biphenyl 20 was
effective against mealworm larvae of Tenebrio molitor that ranged about 65% of mortality in comparison
to DFB, a conventional chitin inhibitor. The molecular docking studies carried on the crystal structure
of Trametes versicolor fungus [18] showed that compounds 20
with the same cluster of amino acids. Compared to biphenol
,
1
and DFB fit the catalytic domain almost
and DFB, compound 20 activated
1
stronger interactions (H-bond) especially with PHE162 and ASN264. Interestingly, the lowest inhibition
constant was estimated for compound 20 (Ki 29.54 µM), probably due to an acquired conformational
flexibility of the structure bearing a hydroxylated biphenyl and two identical hydroxyprenylated
chains that activate a greater number of interactions, which are also more specific, with the amino
acids residues. Interactions of compound 20 with HIS458, which is a putative key amino acid in the
Cu1–N bond at T1 site [18], may affect the hypothesized contribution of the free electron pair from
the N to the Cu1, rendering the protein less active. The fact that biphenyl 20 showed the best affinity
for the catalytic site of laccase protein (lowest Ki value) is in agreement with results achieved from a
spectrophotometric assay that highlighted a more inhibitory effect of 20 in the diphenolasic activity
than with biphenyl 1, and this was further confirmed by an in vivo experiment against larvae of Tenebrio
molitor. In addition. the influence of the prenylated chain of compound 20 in the mortality of the
mealworm larvae measured in in vivo assay in comparison with the mortality caused by hydroxylated
biphenyls 1–6 and 14–15 cannot be ruled out. In fact, a prenylated moiety interferes with the lipophilic
proteins embedded in the outer membrane of microorganisms and insects leading to destruction of the
cuticle and favoring intracellular uptake of the inhibitor [59].
4
. Materials and Methods
4
.1. Synthesis of Compounds 18 and 19 from Derivates 21 and 22
General Procedure for the Synthesis of 21 and 22
0
0
0
To a solution of 4,4 -dihydroxy-biphenyl
1
or 3,3 -dibromo-4,4 -dihydroxy-biphenyl [60] (1 eq) in
-d-glucopyranosyl bromide
1,5 eq mmol) were added. The mixture was stirred for 48 h at 50 C. The solvent was evaporated in
vacuum, the crude product was diluted with diethyl ether, acidified with hydrochloridric acid (10%
solution) and extracted with diethyl ether (3 50 mL), the organic phases were combined and dried
anhydrous acetone (100 mL), K CO (1,5 eq) and 2,3,4,6-tetra-O-acetyl-
α
2
3
◦
(
×
over anhydrous sodium sulfate. The crude product was purified by flash chromatography using a 1:1
mixture of petroleum ether:ethyl acetate (for 21) or 2:1 mixture of petroleum ether: ethyl acetate (for
2
2) as eluent to give compound 21 or 22 as white solid.
(
3
2R,3R,4S,5R,6S)-2-(acetoxymethyl)-6-((4’-hydroxy-[1,1’-biphenyl]-4-yl)oxy)tetrahydro-2H-pyran-
◦
,4,5-triyl triacetate 21: (25%): mp = 83–84 C; [α] D 18.8 (c = 1.0, CHCl ); H-NMR (CD COCD ) δ
3 3 3
20
1
1
.96 (s, 3H), 2.02 (s, 3H), 2.17 (s, 3H), 2.27 (s, 3H), 4.21 (d, J = 6.8 Hz, 2H), 4.46 (td, J = 0.8, 6.4 Hz, 1H),
5
4
1
.28 (m, 1H), 5.43–5.49 (series of m, 3H), 7.15–7.20 (series of m, Ar, 4H), 7.60–7.64 (series of m, Ar,
13
H); C-NMR (CD COCD )
δ
19.70, 19.72, 19.81, 20.17, 67.38, 68.64, 70.71, 70.92, 71.02, 117.06, 122.17,
27.52, 128.05, 134.91, 137.80, 150.34, 156.80, 168.91, 169.46, 169.57, 169.75, 169.97. Anal. Calcd. for
C H O C, 60.46; H, 5.46 Found: C, 60.52; H, 5.48.
3
3
26
28 11
(
2R,3R,4S,5R,6S)-2-(acetoxymethyl)-6-(3,3’-dibromo-4’-hydroxy-[1,1’-biphenyl]-4-yl)oxy)tetrahydro
◦
20
1
-2H-pyran-3,4,5-triyl triacetate 22: (26%): mp = 109–110 C; [
α] D 10.2 (c = 1.0, CHCl ); H-NMR δ
3
2
.04 (s, 3H), 2.08 (s, 3H), 2.12 (s, 3H), 2.20 (s, 3H), 4.10 (t, J = 8.4 Hz, 1H,), 4.20 (dd, J = 6.0, 11.2 Hz, 1H),

Molecules 2020, 25, 2709
15 of 21
4
1
.26 (dd, J = 6.8, 11.2 Hz, 1H,); 5.01 (d, J = 7.6 Hz; 1H), 5.13 (dd, J = 3.6, 10.8 Hz; 1H), 5,4 (d, J = 3.2 Hz,
H), 5.61(dd, J = 8.4, 10.8 Hz; 1H), 7.17 (d, J = 8.0 Hz, Ar, 1H,), 7.21 (d, J = 8.4 Hz, Ar, 1H), 7.39 (dd,
J = 2.4, 8.8 Hz, Ar, 1H); 7.45 (dd, J = 2.0, 8.8, Ar, 1H), 7.71 (d, J = 2.0 Hz, Ar, 1H); 7.74 (d, J = 2.0 Hz, Ar,
13
1
H); C-NMR
δ 20.61, 20.68, 20.71, 20.81, 66.79, 68.07, 70.66, 71.28, 100.53, 113.70, 116.73, 117.91, 124.03,
126.98, 127.13, 131.66, 132.02, 135.78, 138.67, 147.77, 153.44, 168.32, 169.35, 170.16, 170.23. Anal. Calcd.
for C H Br O C, 46.31; H, 3.89 Found: C, 46.52; H, 3.94.
26
26
2
11
General Procedure for the Synthesis of 18 and 19
To a solution of compound 21 or 22 (1 eq) in MeOH:EtOAc 1:1 solution (16 mL), sodium methoxide
(
1.45 eq) was added. The solution was stirred at room temperature for 1 h. The reaction mixture was
+
neutralized using a Dowex Marathon C (H form) resin for 10 min at room temperature, filtrated and
concentrated in vacuo to obtain 18 or 19.
(
3
3
2S,3R,4S,5S,6R)-2-((4’-hydroxy-[1,1’-biphenyl]-4-yl)oxy)-6-(hydroxymethyl)tetrahydro-2H-pyran-
◦
20
1
,4,5-triol 18: white solid (85%): mp = 260–262 C; [
.57 (dd, J = 3.6, 10.0 Hz, 1H), 3.69–3.90 (series of m, 4H), 3.91 (d, J = 2.4 Hz 1H), 4.86 (d, J = 10.0 Hz,
H), 6.80 (m, Ar, 2H); 7.12 (m, Ar, 2H); 7.38 (m, Ar, 2H); 7.44 (m, Ar, 2H); C-NMR (CD OD)
α
] D
−
22 (c = 0.3, MeOH); H-NMR (CD OD) δ
3
13
1
6
δ
60.99,
8.80, 70.88, 73.44, 75.54, 101.60, 115.13, 116.64, 126.89, 127.28, 132.03, 135.27, 145.34, 156.66. Anal.
Calcd. for C H O C, 62.06; H, 5.79 Found: C, 62.50; H, 5.58.
3
18
20
7
(
2S,3R,4S,5S,6R)-2-((3,3’-dibromo-4’-hydroxy-[1,1’-biphenyl]-4-yl)oxy)-6-(hydroxymethyl)tetrahydro
◦
20
1
-
2H-pyran-3,4,5-triol 19: white solid (85%): mp 176–178 C; [
CD COCD ) 3.88–3.99 (series of m, 4H), 4.17 (d, J = 5.6 Hz 1H), 4.86 (d, J = 4.0 Hz, 1H), 5.04 (d,
J = 7.6 Hz, 1H), 7.06 (d, J = 8.8 Hz, Ar, 1H), 7.33 (d, J = 8.4 Hz, Ar, 1H); 7.48 (dd, J = 2.4, 8.4 Hz, Ar, 1H),
.52 (dd, J = 2.4, 8.8 Hz, Ar, 1H,); 7.76 (d, J = 7.6 Hz, Ar, 1H); 7.78 (d, J = 2.4 Hz, Ar, 1H); 13C-NMR
CD COCD ) 61.39, 68.88, 71.12, 73.85, 75.82, 101.65, 110.06, 112.37, 116.64, 116.75, 126.58, 126.96,
α] D 19.8 (c = 0.3, MeOH); H-NMR
(
δ
3
3
7
(
δ
3
3
1
30.75, 130.95, 132.31, 134.59, 153.44, 153.58. Anal. Calcd. for C H Br O : C, 42.71; H, 3.58 Found: C,
18
18
2
7
4
2.93; H, 3.62.
3
3
2
,3’-bis((E)-3-hydroxy-3,7-dimethylocta-1,6-dien-1-yl)-[1,1’-biphenyl]-4,4’-diol 20: To a solution of
0
0
,3 -dibromo-4,4 -dihydroxybiphenyl [60] (1.00 g, 2.91 mmol) in DMF (10 mL), Cs CO (0.94 g
2
3
.91 mmol), [Pd(OAc) ] (10% mol, 0.19 g, 0.29 mmol) and linalool (1.79 g, 11.64 mmol) were added.
2
3
◦
The reaction mixture was stirred under MW irradiation for 10 min at 100 C. The crude product was
diluted with Et O and finally washed with brine. The organic layer was dried over anhydrous sodium
2
sulfate, concentrated under vacuum and purified by flash chromatography, using a 3:1 mixture of
◦
1
Et O:petroleum ether as eluent to give 20 as brown solid (0.57 g, 40%): mp = 127–128 C; H-NMR
2
(
CD COCD )
δ
1.37 (s, 6H); 1.58 (s, 6H),1.61–1.65 (series of m, 4H), 1.63 (s, 6H); 2.04–2.21 (series of m,
3
3
4
(
H); 5.15 (m, 4H), 6.47 (d, J = 16.4 Hz, 2H), 6.91 (d, J = 8 Hz, Ar, Ar, 2H), 6.98 (d, J = 16.4 Hz, 2H), 7.28
dd, J = 2.4 Hz, 8.0 Hz, Ar, 2H); 7.64 (d, J = 2.4 Hz, Ar, 2H); 8.51(bs, 2 OH); 13C-NMR (CD COCD )
δ
3
3
1
1
6.84, 22.79, 24.98, 27.97, 43.06, 72.22, 115.96, 121.52, 124.67, 124.76, 125.00, 126.02, 130.48, 132.82, 137.67,
53.57. Anal. Calcd. for C H O : C, 78.33; H, 8.63; Found: C, 78.41; H, 8.68.
32
42
4
4
.2. Spectrophotometric Assay
Kinetic assays were carried out by measuring the appearance of the product of either tyrosine or
dopamine oxidation in the reaction medium at 311 and 472 nm, respectively, in a Shimadzu UV-2501
spectrophotometer (Shimadzu, Kyoto, Japan) equipped with the UV-Probe software, using a tandem
quartz cuvette (Hellma, Milan, Italy) with a 2
×
4.375-mm path length [1,2,51]. Briefly, one side of the
dual chamber cuvette was filled with 1000 l of mushroom tyrosinase solution in 50 mM phosphate
µ
buffer, pH 6.8, 166 Units/mL using tyrosine as substrate or a 16.6 Units/mL when dopamine was used
as substrate. The other chamber was loaded with 980 µL of substrate solution (180 µM tyrosine or 18
µM dopamine) in 20 mM phosphate buffer (pH 6.8) added of either 20
µL of DMSO (control) or 20 µL
of a 2 mM (0.2 mM in dopamine experiments) solution of tested inhibitors in DMSO. A background

Molecules 2020, 25, 2709
16 of 21
spectrum in the 250–700 nm range was acquired with a 2.0 nm slit and fast speed before starting the
reaction. Thereafter, the solutions in the two chambers were mixed by inversion and the UV-Vis spectra
were acquired at increasing time intervals. Spectra were recorded at 311 or 472 nm in the presence of
the inhibitor before mixing, and after either 24 or 10 min, using tyrosine or dopamine as a substrate,
respectively. Data processing was performed with UV Probe and OriginPro 2019 (v. 9.60) softwares.
The mushroom tyrosinase was used as purchased without further purification.
solutions (tyrosinase, substrates and inhibitors) were filtered through a 0.45- m syringe filter,
aliquoted in Eppendorf tubes, and stored in freezer. The relative concentration was determined
All
µ
−1
−1
−1 −1
cm ;
spectrophotometrically (
ε
274.6 nm = 1420 M
·
cm ;
ε
at 280 nm = 2670 M
dopamine
·
tyrosine
at 280 nm = 1426 M 1·cm−1).
−
ε
tyrosinase
4
.3. Inhibition Protocols on Tyrosinase and Laccase Biosensors
Inhibition types and IC50 were assessed by means of carbon-based amperometric biosensors [61
–
65],
that are described in the Supplementary Materials. During the experiments carried out to determine
the IC50 values, the lowest inhibitory concentration of each compound was also evaluated.
To verify the inhibition types, the following protocol was used. An initial calibration with
dopamine, ranging between 0 and 140 mM, was performed in order to ascertain the values of VMAX and
K . Another calibration with the same protocol was performed after having exposed the biosensors to
M
twice the lowest inhibiting concentration of each inhibitor, in order to ensure the safe inhibition of
enzymatic activity. The biosensors were exposed to the inhibitor for 30 min and after having reached a
stabile baseline, a calibration with dopamine, ranging between 0 and 140 mM, was performed and
the value of VMAX and KM were calculated. The variations of both VMAX and KM were then analyzed
by using the Lineweaver-Burk plot in order to identify the type of inhibition induced by the tested
compound. The statistical difference in VMAX and K , before exposing the biosensors to the inhibitor
M
and then afterwards, was calculated by means of a paired t-test (p < 0.05).
4
.4. Computational Equipment and Software
The crystal structure of a laccase from the fungus Trametes Versicolor was released from the
RCSB protein databank (PDB ID: 1GYC) (www.rcsb.org) [18]. Computational modelling experiments
were carried out on an HP8100 PC and an EXXACT Tensor Workstation TWS-1686525-AMB with OS
Ubuntu 18.4 or Windows 10 and Centos, respectively. The atomic charges were assigned using the
Gasteiger-Marsili method for the ligand and the protein [66]. Binding of the compounds was analyzed
using MGLTools 1.5.7rc1 [67] and AutoDock 4.2.6 docking programs [68
docked using the Lamarckian genetic algorithm (LGA). In all the docking procedures, the LGA was
defined through a centerd grid, coordinates: x = 10, y = 20, z = 38, with 60 60 60 grid points in
,69]. The structures were
×
×
x, y, z dimensions, respectively, spacing 0.375 Å. The Lamarckian genetic algorithm (LGA) with up
to 100 runs was set to the population size of 150 individuals, maximum number of generations and
energy evaluations of 27,000 and 25,000,000, respectively. From the estimated free energy of ligand
binding (E.F.E.B.,
∆G), the estimated inhibition constant (E.I.C., Ki) for each ligand was calculated. Ki
is calculated by the Equation (2):
Ki = exp[(∆G × 1000)/(R × T)]
G is the docking estimated free energy, R (gas constant) = 1.98719 cal/(K
(2)
where
∆
×
mol) and T = 298.15 K.
The poses derived from the docking were represented graphically using Chimera v.1.13.1 [53]. DFB, 1
and 20 structures were built using the standard fragment database as in MacroModel v.6.0 [70]. AMBER
force field was used for the minimization of structures, performed with MacroModel/BachMin v.6.0.
An extensive conformational search was carried out using the Monte Carlo/energy minimization [71].
Representative minimum energy conformations of each compound were optimized using density

Molecules 2020, 25, 2709
17 of 21
functional theory (DFT) quantum chemistry program Gaussian 09 W (DFT, B3LYP, 6–311G) (Wallingford,
CT, USA). Visual analysis was performed with GaussView v.5.0 [72,73].
4
.5. Testing Insecticidal Properties on Mealworm Larvae
Late instar larvae of Tenebrio molitor from a twenty-year-old insect culture at the Research Institute
on Terrestrial Ecosystems (National Research Council, Sassari, Italy) were used in the experiments.
◦
The species was reared on bran flour, with the integration of fresh vegetables, at 25 C, 65% relative
humidity and 16:8 hours light/darkness.
One hundred medium instar larvae were isolated in a petri dishes (diam. 50 mm). They were
then immersed for three seconds in 2.5 mL of an acetone solution (concentration 6.4 mg/mL w:v) of one
of the fourteen compounds listed in Table 3. In addition, a treatment with the commercial formulation
Dimilin (WP, 25% a.i. diflubenzuron) (acetone solution, 25.6 mg/mL w:v) and a negative control (no
treatment) were tested.
After treatment, the larvae were subdivided into five 20-specimen groups and reared for five days
in a small PVC box (150 L
Mortality was recorded daily.
×
120 W
×
50 H mm) with the same feed and conditions as standard rearing.
The statistical analysis was conducted with the R software (R Development Core Team 2016).
√
Mortality data, expressed as a percentage, were arcsin( x)-transformed to satisfy assumptions of
normality. ANOVA was performed by the Duncan test for mean separation.
5
. Conclusions
Novel multitarget tyrosinase and laccase enzymes inhibitors featured by a phenylpropanoid and
hydroxylated biphenyl core were prepared under straightforward synthetic procedures starting from
naturally occurring, commercially available compounds. A drug repositioning concept was applied to
discover effective tyrosinase and laccase inhibitors. Both spectrometric and electrochemical assays
enabled us to reveal the inhibitory activity of the compounds identifying, by PC12 cell viability, the
structure of safe candidates for the future. In silico studies performed on the crystal structure of the
laccase enzyme and in vivo experiments identified a promising lead structure in compound 20 for the
control and management of many species of insects.
Supplementary Materials: The following are available online, 1.1. Chemistry—synthesis of compounds
17; 1.2. Spectrophotometric assay of tyrosine and dopamine, Figures S1 and S2; 1.3. Electrochemical assays:
biosensor calibration and inhibition protocols; 1.4. Viability and oxidative stress assays (Table S1 Kinetic parameters
of calibrations); 1.5. Lineweaver-Burk plot for compounds (Figure S3), (Figure S4), (Figure S5), 10 (Figure S6),
(Figure S7), 12 (Figure S8), 13 (Figure S9), 14 (Figure S10), 15 (Figure S11), 16 (Figure S12), 17 (Figure S13), 18
7 and
12–
7
8
9
1
1
(
Figure S14), 19 (Figure S15) and 20 (Figure S16) on tyrosinase and laccase enzymes; 1.6. Representative plot of
IC50 calculation for compound 20, (Figure S17); 1.7. Computational studies of compounds DFB, 1 and 20 (Tables S2
and S3).
Author Contributions: Conceptualization, G.D. and G.R.; methodology, M.A.D., D.F. (Davide Fabbri), P.C., R.M.,
R.A.P. and P.R.; software, A.D. and R.D.; validation, A.D. R.D., R.M., G.R., C.H. and P.R.; formal analysis, C.H.,
X.F., M.A.D., D.F. (Davide Fabbri), P.C. and D.F. (Donatella Farina); investigation, G.R., P.A.S., P.R., R.A.P. and
G.D.; resources, P.R., G.R., P.A.S. and G.D.; data curation, M.A.D., D.F. (Davide Fabbri), P.C., R.M., G.R. and P.R.;
writing—original draft preparation, G.D.; writing—review and editing, G.D. and G.R.; visualization, A.D., R.D.,
P.R., P.A.S.; supervision, G.D.; project administration, G.D., R.A.P. and G.R.; funding acquisition, G.D., R.A.P. and
G.R. All authors have read and agreed to the published version of the manuscript.
Funding: This research was funded by Sardinia Autonomous Region, project COSMESAGRO, L.R. 7, 2007, CRP
2
5,114 (G.D.). Fondo di Ateneo per la ricerca 2019, Università degli Studi di Sassari, Italy (G.R. and R.A.P.)
Conflicts of Interest: The authors declare no conflicts of interest.
References
1
.
Solomon, E.J.; Sundaram, U.M.; Machonkin, T.E. Multicopper oxidase and oxygenases. Chem. Rev. 1996, 96,
563–2605. [CrossRef] [PubMed]
2

Molecules 2020, 25, 2709
18 of 21
2
3
4
5
6
7
8
.
.
.
.
.
.
.
.
Vavrocla, C.J.; Han, Q.; Mehere, P.; Ding, H.; Christensen, B.M.; Li, J. Tyrosine metabolic enzymes from
insects and mammals: A comparative perspective. Insect Sci. 2014, 21, 13–19.
Kim, Y.-J.; Uyama, H. Tyrosinase inhibitors from natural and synthetic sources: Structure, inhibition
mechanism and perspective for the future. Cell. Mol. Life Sci. 2005, 62, 1707–1723. [CrossRef]
Ullah, S.; Son, S.; Yun, H.Y.; Kim, D.H.; Chun, P.; Moon, H.R. Tyrosinase inhibitors: A patent review
(2011–2015). Expert. Opin.Ther. Pat. 2016, 26, 347–362. [CrossRef] [PubMed]
Park, K.-C.; Huh, S.Y.; Choi, H.R.; Kim, D.-S. Biology of melanogenesis and the search for hypopigmenting
agents. Dematol. Sinica 2010, 28, 53–58. [CrossRef]
McEvily, A.J.; Iyengar, R.; Otwell, W.S. Inhibition of enzymatic browning in foods and beverages. Crit. Rev.
Food Sci. Nutr. 1992, 32, 253–273. [CrossRef] [PubMed]
Fowler, D.M.; Koulov, A.V.; Alory-Jost, C.; Marks, M.S.; Balch, W.E.; Kelly, J.W. Functional amyloid formation
within mammalian tissue. PloS Biol. 2006, 4, e6. [CrossRef] [PubMed]
Yuan, Y.; Jin, W.; Nazir, Y.; Fercher, C.; Blaskovich, M.A.T.; Cooper, M.A.; Barnard, R.T.; Ziora, Z.M. Tyrosinase
inhibitors as potential antibacterial agents. Eur. J. Med. Chem. 2020, 187, 111892. [CrossRef]
Baldrian, P. Fungal laccases – Occurrence and properties. FEMS Microbiol. Rev. 2006, 30, 215–242. [CrossRef]
9
1
0. Asano, T.; Seto, Y.; Hashimoto, K.; Kurushima, H. Mini-review an insect-specific system for terrestrializazion:
Laccase-mediate cuticle formation. Insect Biochem. Mol. Biol. 2019, 108, 61–70. [CrossRef]
1. Majeau, J.-A.; Brar, S.K.; Tyagi, R.D. Laccases for removal of recalcitrant and emerging pollutants. Biores.
Technol. 2010, 101, 2331–2350. [CrossRef] [PubMed]
1
1
1
2. Riva, S. Laccases: Blue enzymes for green chemistry. Trends Biotechnol. 2006, 24, 219–226. [CrossRef]
[
PubMed]
3. Abele, A.; Zheng, D.; Evans, J.; Sugumaran, M. Reexamination of the mechanisms of oxidative transformation
of the insect cuticular sclerotizing precursor, 1,2-dehydro-N-acetyldopamine. Insect Biochem. Mol. Biol. 2010
0, 650–659.
,
4
1
1
1
4. Balabanidou, V.; Grigoraki, L.; Vontas, J. Insect cuticle: A critical determinant of insecticide resistance. Curr.
Opin. Insect Sci. 2018, 27, 68–74. [CrossRef]
5. Sendovki, M.; Kanteev, M.; Ben-Yosef, V.S.; Adir, N.; Fishman, A. First structures of an active bacterial
tyrosinase reveal copper plasticity. J. Mol. Biol. 2011, 405, 227–237. [CrossRef]
6. Ismaya, W.T.; Rozeboom, H.; Weijn, A.; Mes, J.J.; Fusetti, F.; Wichers, H.J.; Dijkstra, B.W. Crystal structure of
Agaricus bisporus mushroom tyrosinase: Identity of the tetramer subunits and interaction with tropolone.
Biochem. 2011, 50, 5477–5486. [CrossRef]
1
7. Goldfeder, M.; Kanteev, M.; Isaschar-Ovdat, S.; Adir, N.; Fishman, A. Determination of tyrosinase
substrate-binding modes reveals mechanistic differences between type-3 copper proteins. Nature Commun.
2
014, 5, 4505. [CrossRef]
8. Piontek, K.; Antorini, M.; Choinowski, T. Crystal structure of a laccase from the fungus Trametes versicolor at
.90 Å resolution containing a full complement of coppers. J. Biol. Chem. 2002, 277, 37663–37669. [CrossRef]
9. Lai, X.; Wichers, H.J.; Soler-L pez, M.; Dijkstra, B.W. Phenylthiourea binding to human tyrosinase-related
1
1
2
2
1
ó
protein 1. Int. J. Mol. Sci. 2020, 21, 915. [CrossRef]
0. Hae, G.D.; Jo, J.M.; Kim, S.Y.; Kim, J.W. Tyrosinase inhibitors from natural source as skin-whitening agents
and the application of edible insects: A mini review. Int. J. Clin. Nutr. Diet. 2019, 5, 141. [CrossRef]
1. Zolghadri, S.; Bahrami, A.; Khan, M.T.H.; Munoz-Munoz, J.; Garcia-Molina, F.; Garcia-Canovas, F.;
Saboury, A.A. A comprehensive review on tyrosinase inhibitors. J. Enz. Inhib. Med. Chem. 2019, 34,
2
79–309. [CrossRef]
2. Smit, N.; Vicanova, J.; Pavel, S. The hunt for natural skin whitening agents. Int. Mol. Sci. 2009, 10, 5326–5349.
CrossRef]
2
[
2
2
3. Chang, T.-S. An updated review of tyrosinase inhibitors. Int. J. Mol. Sci. 2009, 10, 2440–2475. [CrossRef]
4. Ladizinski, B.; Mistry, N.; Kundu, R.V. Widespread use of toxic skin lightening compounds: Medical and
psychosocial aspects. Dermatol. Clin. 2011, 29, 111–123. [CrossRef]
2
5. Cho, K.; Ruy, C.S.; Jeong, S.; Kim, Y. Potenial adverse effect of tyrosinase inhibitors on telosts: A review.
Comp. Biochem. Physiol. Part. C 2020, 228, 108655.
2
6. Ito, S.; Wakamatzu, K. Biochemical mechanism of rhododendrol-induced leukoderma. Int. J. Mol. Sci. 2018
,
1
9, 552.

Molecules 2020, 25, 2709
19 of 21
2
7. Parvez, S.; Kang, M.; Chung, H.-S.; Bae, H. Naturally occurring tyrosinase inhibitors: Mechanism and
applications in skin health, cosmetics and agriculture industries. Phytother. Res. 2007, 21, 805–816. [CrossRef]
PubMed]
8. Couteau, C.; Coiffard, L. Overview of skin whitening agents: Drugs and cosmetic products. Cosmetics 2016
, 27. [CrossRef]
[
2
2
3
,
3
9. Gillbro, J.M.; Olsson, M.J. The melonogenesis and mechanisms of skin-lightening agents-existing and new
approaches. Int. J. Cosmetic Sci. 2011, 33, 210–221. [CrossRef]
0
0. Kim, Y.J.; No, J.K.; Lee, J.H.; Chung, H.Y. 4,4 -Dihydroxybiphenyl as a new potent tyrosinase inhibitor. Biol.
Pharm. Bull. 2005, 28, 323–327. [CrossRef]
3
3
1. Ward, R.S. Lignans, neolignans and related compounds. Nat. Prod. Rep. 1999, 16, 75–96. [CrossRef]
2. Hajduk, P.J.; Bures, M.; Praestagaard, J.; Fesik, S.W. Privileged molecules for protein binding identified from
NMR-based screening. J. Med. Chem. 2000, 43, 3443–3447. [CrossRef] [PubMed]
3
3. Martin, S.; Lamb, H.K.; Brady, C.; Lefkove, B.; Bonner, M.Y.; Thompson, P.; Lovat, P.E.; Arbiser, J.L.;
Hawkins, A.R.; Redfern, C.P.F. Inducing apostosis of cancer cells using small-molecule plant compounds
that bind to GRP78. British J. Cancer 2013, 109, 433–443. [CrossRef] [PubMed]
3
4. Schuhly, W.; Hufner, A.; Pferschy-Wenzig, E.M.; Prettner, E.; Adams, M.; Bodensieck, A.; Kunert, O.;
Oluwemino, A.; Haslinger, E.; Bauer, R. Design and synthesis of ten biphenyl-neolignan derivatives and their
in vitro inhibitory potency against cyclooxygenase-1/2 activity and 5-lipoxygenase-mediated LTB4-formation.
Bioorg. Med. Chem. 2009, 17, 4459–4465. [CrossRef]
3
3
5. Bringmann, G.; Gulder, T.; Gulder, T.A.M.; Breuning, M. Atroposelective total synthesis of axially chiral
biaryl natural products. Chem. Rev. 2011, 111, 563–639. [CrossRef]
6. Kancheva, V.; Slavova-Kazakova, A.; Fabbri, D.; Dettori, M.A.; Delogu, G.; Janiak, M.; Amarowicz, R.
Protective effects of equimolar mixture of monomer and dimer of dehydrozingerone with alfa-tocopherol
and/or ascorbyl palmitate during bulk lipid autoxidation. Food Chem. 2004, 157, 263–274. [CrossRef]
3
3
3
4
4
7. Oufensou, S.; Scherm, B.; Balmas, V.; Fabbri, D.; Dettori, M.A.; Carta, P.; Malbrán, I.; Migheli, Q.; Delogu, G.
Honokiol, magnolol and its monoacetyl derivative show strong anti-fungal effect on Fusarium isolates of
clinical relevance. PLoS ONE 2019, 14, e0221249. [CrossRef]
8. Maioli, M.; Basoli, V.; Carta, P.; Fabbri, D.; Dettori, M.A.; Cruciani, S.; Serra, P.A.; Delogu, G. Synthesis
of magnolol and honokiol derivatives and their effect against hepatocarcinoma cells. PLoS ONE 2018, 13,
e0192178. [CrossRef]
9. Monti, P.; Calia, G.; Marceddu, S.; Dettori, M.A.; Fabbri, D.; Jaoua, S.; O’Neill, R.; Migheli, Q.; Delogu, G.;
Serra, P.A. Low electro-synthesis potentials improve permeselectivity of polymerized natural phenols in
biosensor applications. Talanta 2017, 162, 151–156. [CrossRef]
0. Marchiani, A.; Mammi, S.; Siligardi, G.; Hussain, R.; Tessari, I.; Bubacco, L.; Delogu, G.; Fabbri, D.;
Dettori, M.A.; Sanna, D.; et al. Small molecules interacting with
α-synuclein: Antiaggregating and
cytoprotective properties. Amino Acids 2013, 45, 327–338. [CrossRef]
1. Ruzza, P.; Serra, P.A.; Fabbri, D.; Dettori, M.A.; Rocchitta, G.; Delogu, G. Hydroxylated biphenyls as
tyrosinase inhibitor: A spectrophotometric and electrochemical study. Eur. J. Med. Chem. 2017, 126,
1
034–1038. [CrossRef] [PubMed]
4
4
2. Boo, Y.C. p-Coumaric acid as an active ingredient in cosmetics: A review focusing on its antimelanogenic
effects. Antioxidants 2019, 8, 275. [CrossRef] [PubMed]
3. Kuo, P.-C.; Damu, A.G.; Cherng, C.-Y.; Jeng, J.-F.; Teng, C.-M.; Lee, E.-J.; Wu, T.-S. Isolation of a natural
antioxidant, dehydrozingerone from Zingiber officinale and synthesis of its analogues for recognition of
effective antioxidant and antityrosinase agents. Arch. Pharm. Res. 2005, 28, 518–528. [CrossRef] [PubMed]
4. Ullah, S.; Park, Y.; Lee, S.; Kang, D.; Yang, J.; Akter, J.; Chun, P.; Moon, H.R. Antioxidant, anti-tyrosinase and
anti-melanogenic effects of (E)-2,3-diphenylacrylic acid derivatives. Bioorg. Med. Chem. 2019, 27, 2192–2200.
4
4
4
[CrossRef] [PubMed]
5. Akhtar, M.N.; Sakeh, N.M.; Zareen, S.; Gul, S.; Lo, K.M.; Ul-Haq, Z.; Shah, S.A.A.; Ahmad, S. Design and
synthesis of chalcone derivatives as potent tyrosinase inhibitors and their structural activity relationship. J.
Mol. Sci. 2015, 1085, 97–103. [CrossRef]
6. Sheng, Z.; Ge, S.; Xu, X.; Zhang, Y.; Wu, P.; Zhang, K.; Xu, X.; Li, C.; Zhao, D.; Tang, X. Design, synthesis and
evaluation of cinnamic acid ester derivatives as mushroom tyrosinase inhibitors. Med. Chem. Comm. 2018, 9,
8
53–861. [CrossRef] [PubMed]

Molecules 2020, 25, 2709
20 of 21
4
4
4
5
7. Chuprajob, T.; Chatchawan, C.; Chokchaisiric, R.; Chunglokd, W.; Sornkaewa, N.; Apichart Suksamrarna, A.
Synthesis, cytotoxicity against human oral cancer KB cells and structure–activity relationship studies of
trienone analogues of curcuminoids. Bioorg. Med. Chem. Lett. 2014, 24, 2839–2844. [CrossRef]
8. Jae-Chul, J.; Soyong, J.; Yongam, L.; Dongguk, M.; Eunyoung, L.; Heyin, J.; Miyeon, O.; Seikwan, O.; Mankil, J.
Efficient synthesis and neuroprotective effect of substituted 1,3-diphenyl-2-propen-1-ones. J. Med. Chem.
2
008, 51, 4054–4058.
9. Pathak, V.; Ahmad, I.; Kahlon, A.K.; Hasanian, M.; Sharma, S.; Srivastava, K.K.; Sarkar, J.; Shankar, K.;
Gupta, A. Syntheses of 2-methoxyestradiol and eugenol template based diarylpropenes as non-steroidal
anticancer agents. RSC Advances 2014, 4, 35171–35185. [CrossRef]
0. Ruzza, P.; Rosato, A.; Nassi, A.; Rondina, M.; Zorzin, M.; Rossi, C.R.; Floreani, M.; Quintieri, L.
Synthesis and preliminary in vitro biological evaluation of 4-[(4-hydroxyphenyl)sulfanyl] but-3-en-2-one, a
4
-mercaptophenol derivative designed as a novel bifunctional antimelanoma agent. J. Med. Chem. 2009, 52,
4
973–4976. [CrossRef]
5
5
5
1.
S
á
nchez-Ferrer,
Á.; Neptuno Rodríguez-López, J.; García-Cánovas, F.; García-Carmona, F. Tyrosinase: A
comprehensive review of its mechanism. BBA - Protein Struct. Mol. Enzym. 1995, 1247, 1–11. [CrossRef]
2. Honisch, C.; Osto, A.; de Matos, A.D.; Vincenzi, S.; Ruzza, P. Isolation of a tyrosinase inhibitor from unripe
grapes juice: A spectrophotometric study. Food Chem. 2020, 305, 1–5. [CrossRef] [PubMed]
3. Pettersen, E.F.; Goddard, T.D.; Huang, C.C.; Couch, G.S.; Greenblatt, D.M.; Meng, E.C.; Ferrin, T.E. UCSF
Chimera - a visualization system for exploratory research and analysis. J. Comput. Chem. 2004, 25, 1605–1612.
[CrossRef] [PubMed]
5
5
5
5
4. Laskowski, R.A.; Swindells, M.B. LigPlot+: Multiple ligand-protein interaction diagrams for drug discovery.
J. Chem. Inf. Model. 2011, 51, 2778–2786. [CrossRef]
5. Pinna, A.; Ricco, R.; Migheli, R.; Rocchitta, G.; Serra, P.A.; Falcaro, P.; Malfatti, L.; Innocenzi, P. A MOF-based
carrier for in situ dopamine delivery. RSC Adv. 2018, 8, 25664–25672. [CrossRef]
6. Menezes, C.J.M.D.S.; Diederich, M.F. Natural dimers of coumarin, chalcones, and resveratrol and the link
between structure and pharmacology. Eur. J. Med. Chem. 2019, 182, 111637. [CrossRef]
7. Jia, Y.L.; Zheng, J.; Yu, F.; Cai, Y.X.; Zhan, X.L.; Wang, H.F.; Chen, Q.X. Antityrosinase kinetics and antibacterial
process of caffeic acid N-nonyl ester in Chinese Olive (Canarium album) postharvest. Int. J. Biol. Macromol.
2
016, 91, 486–495. [CrossRef]
8. Garcia-Jimenez, A.; Teruel-Puche, J.A.; Garcia-Ruiz, P.A.; Saura-Sanmartin, A.; Berna, J.;
Rodr guez-L pez, J.N.; Garcia-Canovas, F. Action of tyrosinase on caffeic acid and its n-nonyl ester.
5
í
ó
Catalysis and suicide inactivation. Int. J. Biol. Macromol. 2018, 107, 2650–2659. [CrossRef]
5
6
6
9. Wang, Y.; Yu, Z.; Zhang, J.; Moussian, B. Regionalization of surface lipids in insects. Proc. R. Soc. B 2016, 283,
2
0152994. [CrossRef]
0. Smith, D.W.; Babb, D.A., Jr.; Snelgrove, R.V.; Townsend, P.H.; Martin, S.J. Polynaphthalene: Networks from
Bisphenols. J. Amer. Chem. Soc. 1998, 120, 9078–9079. [CrossRef]
1. Calia, G.; Rocchitta, G.; Migheli, R.; Puggioni, G.; Spissu, Y.; Bazzu, G.; Mazzarello, V.; Lowry, J.P.; O’Neill, R.D.;
Desole, M.S.; et al. Biotelemetric monitoring of brain neurochemistry in conscious rats using microsensors
and biosensors. Sensors 2009, 9, 2511–2523. [CrossRef] [PubMed]
6
2. Bazzu, G.; Puggioni, G.G.; Dedola, S.; Calia, G.; Rocchitta, G.; Migheli, R.; Desole, M.S.; Lowry, J.P.;
O’Neill, R.D.; Serra, P.A. Real-time monitoring of brain tissue oxygen using a miniaturized biotelemetric
device implanted in freely moving rats. Anal. Chem. 2009, 81, 2235–2241. [CrossRef] [PubMed]
3. Barberis, A.; Garbetta, A.; Cardinali, A.; Bazzu, G.; D’Antuono, I.; Rocchitta, G.; Fadda, A.; Linsalata, V.;
D’Hallewin, G.; Serra, P.A.; et al. Real-time monitoring of glucose and phenols intestinal absorption through
an integrated Caco-2TC7cells/biosensors telemetric device: Hypoglycemic effect of fruit phytochemicals.
Biosens Bioelectron. 2017, 88, 159–166. [CrossRef] [PubMed]
6
6
4. Rocchitta, G.; Migheli, R.; Dedola, S.; Calia, G.; Desole, M.S.; Miele, E.; Lowry, J.P.; O’Neill, R.D.; Serra, P.A.
Development of a distributed, fully automated, bidirectional telemetry system for amperometric microsensor
and biosensor applications. Sens. Actuat. B Chem. 2007, 126, 700–709. [CrossRef]
6
5. Serra, P.A.; Rocchitta, G.; Bazzu, G.; Manca, A.; Puggioni, G.M.; Lowry, J.P.; O’Neill, R.D. Design and
construction of a low-cost single-supply embedded telemetry system for amperometric biosensor applications.
Sens. Actuat. B Chem. 2007, 122, 118–126. [CrossRef]

Molecules 2020, 25, 2709
21 of 21
6
6. Gateiger, J.; Marsili, M. Iterative partial equalization of orbital electronegativity – a rapid access to atomic
charges. Tetrahedron 1980, 36, 3219–3228. [CrossRef]
6
7. Morris, G.M.; Huey, R.; Lindstrom, W.; Sanner, M.F.; Belew, R.K.; Goodsell, D.S.; Olson, A.J. Autodock4 and
AutoDockTools4: Automated docking with selective receptor flexiblity. J. Comput. Chem. 2009, 16, 2785–2791.
[
CrossRef]
8. Morris, G.M.; Goodsell, D.S.; Halliday, R.S.; Huey, R.; Hart, W.E.; Belew, R.K.; Olson, A.J. Automated docking
using a Lamarckian genetic algorithm and an empirical binding free energy function. J. Comput. Chem. 1988
9, 1639–1662. [CrossRef]
6
,
1
6
7
9. Huey, R.; Morris, G.M.; Olson, A.J.; Goodsell, D.S. A semiempirical free energy force field with charge-based
desolvation. J. Comput. Chem. 2007, 28, 1145–1152. [CrossRef]
0. Mohamadi, F.; Richards, N.G.; Guida, W.C.; Liskamp, R.; Lipton, M.; Caufiel, C.; Chang, G.; Hendrickson, T.;
Still, W.C. Macromodel—An integrated software system for modeling organic and bioorganic molecules
using molecular mechanics. J. Comput. Chem. 1990, 11, 440–467. [CrossRef]
7
7
7
1. Chang, G.; Guida, W.C.; Still, W.C. An internal-coordinate Monte Carlo method for searching S46
conformational space. J. Am. Chem. Soc. 1989, 111, 4379–4386. [CrossRef]
2. Frisch, M.J.; Trucks, G.W.; Schlegel, H.B.; Scuseria, G.E.; Robb, M.A.; Cheeseman, J.R.; Scalmani, G.; Barone, V.;
Mennucci, B.; Petersson, G.A.; et al. aussian 09, Revision B, 01; Gaussian, Inc.: Wallingford, CT, USA, 2010.
3. Dennington, R.; Keith, T.; Millam, J. GaussView Version 5; Semichem Inc.: Shawnee, KS, USA, 2009.
Sample Availability: Samples of the compounds 7–20 are available from the authors.
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
