Full Paper
2025 (CO), 1951 (CO), 1425 cmꢀ1 (OAc); elemental analysis calcd
(%) for C33H25N5O9Ru2: C 47.31, H 3.01, N 8.36; found: C 47.26, H
2.98, N 8.32.
NP), 7.65 (d, J=5.28 Hz, 2H, Ph), 7.57 (d, J=1.1 Hz, 2H, Ph), 7.46
(d, J=8.2 Hz, 2H, Ph), 7.32 (d, J=8.4 Hz, 2H, Ph), 5.19–5.14 (m, 1H,
CHCHOH), 4.06 (dd, J1 =13.9 Hz, J2 =4.6 Hz, 1H, CH2), 3.71 (dd, J1 =
14.0 Hz, J2 =3.2 Hz, 1H, CH2), 2.43 (s, 3H, Me-NP), 2.75–2.76 (m, 1H,
CHiPr), 1.75 (d, J=6.6 Hz, 3H, CH3iPr), 1.71 ppm (d, J=6.7 Hz, 3H,
CH3iPr); 13C NMR (99.5 MHz, CD3CN, 296.2 K): d=208.2 (CO), 203.9
(CO), 202.5 (CO), 184.2 (CO), 178.3 (NCNIm), 165.4 (NCNNP), 163.8
(OCO), 156.1 (NNPCNIm), 155.2 (CCNNP), 151.4 (CCCNP), 145.2 (CCCNP),
141.8 (CCCNP), 135.7 (CCNPh), 129.7 (CCCNP), 128.2 (NCCIm), 126.4
(CCCPh), 125.2 (CCCPh), 125.2 (CCCPh), 125.1 (CCCPh), 122.6 (CCCPh),
122.5 (CCCPh), 120.6 (CCCPh), 118.5 (CCCPh), 118.5 (CCCPh), 117.4
(CCCPh), 112.7 (CCCPh), 54.5 (FCC), 48.9 (NCCiPr), 23.2 (CCCiPr),
21.5 ppm (CCCiPr); 19F NMR (372.5 MHz, CD3CN, 294 K): d=ꢀ63.0
(CF3C6H4COO), ꢀ63.5 (CF3L4), ꢀ151.7 (BF4); IR (KBr): n=2074 (CO),
Synthesis of 2: Compound 2 was synthesized following a similar
procedure employed for the synthesis of 1 by using PIN·HBr
(60 mg, 0.17 mmol), Ru2(CO)4(CH3COO)2 (75 mg, 0.17 mmol), TlBF4
(49 mg, 0.17 mmol), and p-nitrobenzaldehyde (40 mg, 0.26 mmol).
Crystals suitable for X-ray diffraction were grown by layering
hexane over a concentrated dichloromethane solution of 2 inside
an 8 mm o.d. vacuum-sealed glass tube. Yield: 113 mg (74%). M.p.
>2508C; 1H NMR (400 MHz, CD3CN, 294 K): d=8.94 (d, J=9.2 Hz,
1H, NP), 8.16 (d, J=9.2 Hz, 1H, NP), 8.10 (d, J=2.3 Hz, 1H, Im), 8.0
(d, J=8.7 Hz, 2H, Ph), 7.90 (d, J=8.3 Hz, 2H, Ph), 7.79 (s, 1H, NP),
7.57 (d, J=2.4 Hz, 1H, Im), 5.03–5.09 (m, 1H, CHCHOH), 4.35 (dd, J1 =
14.2 Hz, J2 =2 Hz, 1H, CH2), 4.01 (dd, J1 =14.2 Hz, J2 =2 Hz, 1H,
CH2), 2.82 (s, 3H, Me-NP), 2.75–2.76 (m, 1H, CHiPr), 2.46 (s, 3H,
CH3OAc), 1.64 (s, 3H, CH3iPr), 1.63 ppm (s, 3H, CH3iPr); 13C NMR
(99.5 MHz, CD3CN, 296.2 K): d=211.1 (CO), 206.5 (CO), 202.7 (CO),
191.9 (CO), 189.4 (NCNNP), 184.6 (NNPCNIm), 180.4 (OCOOAc), 179.4
(NCNIm), 162.4 (CCNNP), 156.3 (CCCNP), 153.2 (CCCNP), 142.2 (CCCNP),
141.2 (CCNPh), 139.1 (CCCNP), 133.2 (NCCIm), 129.8 (CCCPh), 127.0
(CCCPh), 125.1 (CCCPh), 123.0 (CCCPh), 121.5 (CCCPh), 120.4 (CCCNP),
119.2 (NImCC), 54.4 (CCO), 49.6 (CCOOAc), 48.9 (NCCiPr), 29.8 (CH3NP),
28.1 (CH2NP), 23.2 (CCCiPr), 18.5 ppm (CCCiPr); IR (KBr): n=2071 (CO),
2025 (CO), 1951 (CO), 1426 (OAc), 1061 cmꢀ1 (BF4); ESI-MS: m/z=
792 corresponding to [2ꢀBF4]+; elemental analysis calcd (%) for
C31H28N5O9BF4Ru2: C 39.74, H 2.87, N 7.99; found: C 39.69, H 2.81, N
7.84.
2033 (CO), 1984 (CO), 1325 (CF3C6H4COO), 1066 cmꢀ1 (BF4 ); ESI-MS:
–
m/z=945 corresponding to [4ꢀBF4]+; elemental analysis calcd (%)
for C36H27N4O7BF10Ru2: C 41.96, H 2.64, N 5.44; found: C 41.90, H
2.61, N 5.38.
General procedure for the catalytic reaction
Complex 1 (9.26 mg, 0.01 mmol), DABCO (5.6 mg, 0.05 mmol), alco-
hol (1 mmol), amine (1.2 mmol), nonane (0.2 mmol), 4ꢂ molecular
sieves (100 mg), and toluene (3 mL) were placed in an oven-dried
reaction vessel. The reaction mixture was heated at reflux at 1108C
with stirring for 24 h. It was cooled to room temperature and the
solvent was removed in vacuo. The residue was purified by silica
gel column chromatography (hexane/Et2O 10:0!9:1 with 5%
Et3N) to afford the imine.
Synthesis of 3: Compound 3 was synthesized following a similar
procedure employed for the synthesis of 1 by using PIN·HBr
(60 mg, 0.17 mmol), Ru2(CO)4(CH3COO)2 (75 mg, 0.17 mmol), TlBF4
(49 mg, 0.17 mmol), and p-cyanobenzaldehyde (34 mg, 0.26 mmol).
Crystals suitable for X-ray diffraction were grown by layering
hexane over a concentrated dichloromethane solution of 3 inside
an 8 mm o.d. vacuum-sealed glass tube. Yield: 107 mg (72%). M.p.
>2508C; 1H NMR (400 MHz, CD3CN, 294 K): d=8.94 (d, J=9.1 Hz,
1H, NP), 8.53 (d, J=9.4 Hz, 1H, NP), 8.20 (d, J=2.7 Hz, 1H, Im), 8.0
(d, J=8.7 Hz, 2H, Ph), 7.98 (d, J=8.5 Hz, 2H, Ph), 7.90 (s, 1H, NP),
7.50 (d, J=2.4 Hz, 1H, Im), 5.15–5.06 (m, 1H, CHCHOH), 4.34 (dd, J1 =
14.1 Hz, J2 =2 Hz, 1H, CH2), 4.03 (dd, J1 =14.2 Hz, J2 =2 Hz, 1H,
CH2), 2.83 (s, 3H, Me-NP), 2.74–2.72 (m, 1H, CHiPr), 2.46 (s, 3H,
CH3OAc), 1.66 (s, 3H, CH3iPr), 1.61 ppm (s, 3H, CH3iPr); 13C NMR
(99.5 MHz, CD3CN, 296.2 K): d=210.1 (CO), 206.1 (CO), 201.2 (CO),
192.0 (CO), 187.2 (NCNNP), 184.1 (NNPCNIm), 179.1 (NCNIm), 162.0
(CCNNP), 156.7 (CCCNP), 153.0 (CCCNP), 142.7 (CCCNP), 141.4 (CCNPh),
139.8 (CCCNP), 133.2 (NCCIm), 129.2 (CCCPh), 127.5 (CCCPh), 124.7
(CCCPh), 123.0 (CCCPh), 121.1 (CCCPh), 120.0 (CCCNP), 119.2 (NImCC),
55.4 (CCO), 54.1 (OCOOAc), 48.9 (CCOOAc), 48.2 (NCCiPr), 29.6 (CH3NP),
28.0 (CH2NP), 22.9 (CCCiPr), 18.9 ppm (CCCiPr); IR (KBr): n=2067 (CO),
2025 (CO), 1947 (CO), 1422 (OAc), 1060 cmꢀ1 (BF4); ESI-MS: m/z=
772 corresponding to [3ꢀBF4]+; elemental analysis calcd (%) for
C30H26N5O7BF4Ru2: C 42.02, H 3.06, N 8.17; found: C 41.99, H 3.01, N
8.09.
X-ray data collection and refinement
Single-crystal X-ray studies were performed on a CCD Bruker
SMART APEX diffractometer equipped with an Oxford Instruments
low-temperature attachment. All the data were collected at
100(2) K using graphite-monochromated MoKa radiation (la =
0.71073 ꢂ). The frames were indexed, integrated, and scaled by
using the SMART and SAINT software packages[31] and the data
were corrected for absorption by using the SADABS program.[32]
The structures were solved and refined with the SHELX suite of
programs.[33] All hydrogen atoms were included in the final stages
of the refinement and were refined with a typical riding model.
Structure solution and refinement details for compounds 1–4 are
provided in the Supporting Information. Anisotropic treatment of
these three atoms resulted nonpositive definite displacement ten-
sors and were therefore subjected to isotropic refinement. The
“SQUEEZE” option in the PLATON program[34] was used to remove
a disordered solvent molecule from the overall intensity data of
compounds 1 and 4. Pertinent crystallographic data for com-
pounds 1–4 are summarized in Table S2 in the Supporting Informa-
tion. The crystallographic figures used in this manuscript have
been generated using Diamond 3.1e software.[35] CCDC-949508 (1),
949509 (2), 949510 (3), and 949511 (4) contain the supplementary
crystallographic data for this paper. These data can be obtained
free of charge from The Cambridge Crystallographic Data Centre
Synthesis of 4: Compound 4 was synthesized following a similar
procedure employed for the synthesis of 1 by using PIN·HBr ligand
precursor (60 mg, 0.17 mmol), Ru2(CO)4(CH3COO)2 (75 mg,
0.17 mmol), TlBF4 (49 mg, 0.17 mmol), and p-trifluromethylbenzal-
dehyde (45 mg, 0.26 mmol). Crystals suitable for X-ray diffraction
were grown by layering hexane over a concentrated dichlorome-
thane solution of 4 inside an 8 mm o.d. vacuum-sealed glass tube.
Yield: 129 mg (72%). M.p. >2508C; 1H NMR (400 MHz, CD3CN,
294 K): d=8.80 (d, J=5.5 Hz, 1H, NP), 8.09 (d, J=9.2 Hz, 1H, NP),
8.08 (d, J=2.3 Hz, 1H, Im), 8.06 (d, J=2.4 Hz, 1H, Im), 7.67 (s, 1H,
Computational study
Calculations were performed by using density functional theory
(DFT) with Becke’s three-parameter hybrid exchange functional[36]
and the Lee–Yang–Parr correlation functional (B3LYP).[37] Geometry-
optimized structures were characterized fully by analytical frequen-
cy calculations as minima on the potential energy surface. The
&
&
