Diatoms are known to produce a variety of halogenated compounds, which were recently shown to have a role in allelopathic interactions between competing species. The production of these compounds is linked to haloperoxidase activity. This research, has shown that this system may also be involved in diatom-bacteria interactions via the H₂O₂ dependent inactivation of a type of quorum sensing (QS) molecule, i.e., N-β-ketoacylated homoserine lactones (AHLs), by a natural haloperoxidase system from the benthic diatom Nitzschia cf pellucida. The AHL degradation pathway towards corresponding halogenated derivatives was elucidated via HPLC-MS analysis and the synthesis of a broad series of novel halogenated AHL analogues as reference compounds. Furthermore, their biological activity as quorum sensing modulators was directly compared and evaluated against a series of naturally occurring β-keto-AHLs. It has been demonstrated that the loss of the QS activity results from the final cleavage of the halogenated N-acyl chain of the signal molecules.

Full text of DOI:10.3390/md12010352

Mar. Drugs 2014, 12, 352-367; doi:10.3390/md12010352
OPEN ACCESS
marine drugs
ISSN 1660-3397
www.mdpi.com/journal/marinedrugs
Article
Haloperoxidase Mediated Quorum Quenching by Nitzschia cf
pellucida: Study of the Metabolization of N-Acyl Homoserine
Lactones by a Benthic Diatom
Michail Syrpas 1, Ewout Ruysbergh 1, Lander Blommaert 2, Bart Vanelslander 2, Koen Sabbe 2,
Wim Vyverman 2,*, Norbert De Kimpe 1 and Sven Mangelinckx 1,*
1
Department of Sustainable Organic Chemistry and Technology, Faculty of Bioscience Engineering,
Ghent University, Coupure Links 653, Ghent B-9000, Belgium;
E-Mails: Michail.Syrpas@UGent.be (M.S.); Ewout.Ruysbergh@UGent.be (E.R.);
Norbert.DeKimpe@UGent.be (N.D.K.)
2
Laboratory of Protistology and Aquatic Ecology, Department of Biology, Ghent University,
Krijgslaan 281-S8, Ghent B-9000, Belgium; E-Mails: Lander.Blommaert@UGent.be (L.B.);
Bart.Vanelslander@gmail.com (B.V.); Koen.Sabbe@UGent.be (K.S.)
* Authors to whom correspondence should be addressed;
E-Mails: Sven.Mangelinckx@UGent.be (S.M.); Wim.Vyverman@UGent.be (W.V.);
Tel.: +32-(0)9-264-59-51 (S.M.); Fax: +32-(0)9-264-62-21 (S.M.);
Tel.: +32-(0)9-264-85-01 (W.V.); Fax: +32-(0)9-264-85-99 (W.V.).
Received: 5 November 2013; in revised form: 16 December 2013 / Accepted: 23 December 2013 /
Published: 17 January 2014
Abstract: Diatoms are known to produce a variety of halogenated compounds, which were
recently shown to have a role in allelopathic interactions between competing species. The
production of these compounds is linked to haloperoxidase activity. This research, has
shown that this system may also be involved in diatom-bacteria interactions via the H2O2
dependent inactivation of a type of quorum sensing (QS) molecule, i.e., N-β-ketoacylated
homoserine lactones (AHLs), by a natural haloperoxidase system from the benthic diatom
Nitzschia cf pellucida. The AHL degradation pathway towards corresponding halogenated
derivatives was elucidated via HPLC-MS analysis and the synthesis of a broad series of
novel halogenated AHL analogues as reference compounds. Furthermore, their biological
activity as quorum sensing modulators was directly compared and evaluated against a
series of naturally occurring β-keto-AHLs. It has been demonstrated that the loss of the QS
activity results from the final cleavage of the halogenated N-acyl chain of the
signal molecules.

Mar. Drugs 2014, 12
353
Keywords: quorum sensing; haloperoxidase; degradation pathway; AHL; reference
compounds; diatom-bacteria interactions
1. Introduction
Algae are known as an important source of bioactive compounds with potential agrochemical and
pharmaceutical applications [1]. Some of these bioactive metabolites include halogenated
compounds [2]. These types of compound often demonstrate interesting biological properties including
antifungal, anti-inflammatory, antifeedant, cytotoxic, insecticidal, and antibacterial activity [3].
Biohalogenation in marine organisms usually occurs via the action of haloperoxidases [4], which are
enzymes that mediate the oxidation of halides by hydrogen peroxide via various mechanisms [5]. Until
now, screening for bioactive halogenated compounds in marine environments has mainly been focused
on macroalgae rather than on microalgae [2]. Research on diatoms, one of the most common type of
marine microalgae, is even less widespread.
Many bacteria use signal molecules, i.e., autoinducers, to control the expression of specific genes
important for phenotypes, such as biofilm formation, bioluminescence, virulence expression, motility,
conjugation, and symbiosis and this in a population density dependent manner [6]. This interbacterial
signaling is widely known as quorum sensing (QS). N-Acylated homoserine lactones (AHLs) represent
a major class of these signal molecules, and are commonly produced by Gram negative bacteria [7].
The QS system in these bacteria usually consists of two components: a LuxI homologue that
synthesizes the AHL autoinducer, and a LuxR homologue which is an autoinducer-dependent
transcriptional activator [7]. Different bacterial species have been shown to produce different
AHLs [8]. The basic structure of AHLs consists of a homoserine lactone ring adjoined with an N-acyl
chain. The acyl chain can vary in length from four to 14 carbon atoms, as can the degree of saturation
and the chain may or may not contain an oxo- or hydroxy-group at the 3-carbon position [9]. A wide
variety of AHLs, including various saturated and β-keto-AHLs, are found in marine stromatolite mats
but also in intertidal surfaces colonized by algae and in intertidal rock pools [10,11]. AHLs are also
known to modulate the settlement rate of green alga Ulva intestinalis [12]. The AHL producing
Alphaproteobacteria, which are dominant in benthic diatom biofilms, were shown to have an influence
on the diatom growth and the release of extracellular polymeric substances [13]. Across different
kingdoms these kinds of interactions may exert wider ecological effects [14].
In aquatic environments, bacteria interact in various ways with other organisms as pathogens,
symbionts or competitors in the search for resources [14–16]. Many marine organisms have developed
defense or deterrence mechanisms, which are often involved in the production of small diffusible
signal molecules that can interfere with the QS systems [17,18]. A well-studied example is the
production of halogenated furanones by the red alga Delisea pulchra [19,20]. In addition, QS
antagonistic activity has been demonstrated in algae from Caulerpaceae (green algae), Rhodomelaceae
and Galaxauraceae families (red algae) [21], red macroalga Asparagopsis taxiformis [22], green
microalga Chlamydomonas reinhardtii [23], freshwater green microalga Chlorella sacharophilla [24],
gorgonian corals from the Caribbean reefs [25] and the marine sponge Luffariella variabilis [26,27].

Mar. Drugs 2014, 12
354
Furthermore, another way of QS disruption in nature occurs via the action of enzymes. Enzymatic
degradation of QS signal molecules by acylases and lactonases of bacterial origin has been
demonstrated [28]. In another pathway, haloperoxidases from Delisea pulchra and Laminaria digitata
were shown to mediate the deactivation of β-keto-AHLs by electrophilic halogenation with
bromine [29,30]. Several diatoms are linked with the release of reactive bromine and iodine which is
influenced by temperature, H2O2 concentration, bromide (and iodide) concentration, light, and pH [31].
The release leads to the formation of a wide range of halocarbons, formed via rapid and aspecific
reactions of these reactive halogen intermediates with many organic molecules. Furthermore, this
event plays a substantial role in oceanic bromoform production via the haloform reaction [32].
Interestingly, the production of volatile halocarbons by several Nitzschia species has been linked to
haloperoxidase activity [33,34]. Nevertheless, not much is known about QS antagonistic compounds
derived from diatoms. To the best of our knowledge there is no data which demonstrates the release of
reactive bromine (or iodine) from diatoms as a possible defense mechanism against bacterial fouling.
In the present study, it was envisioned that the natural haloperoxidase system from the benthic
diatom N. cf pellucida, besides allelopathic interactions between competing species, may also be
involved in the deactivation of bacterial QS molecules. Therefore, the goal of this study was to analyze
the effect of haloperoxidase activity by the diatom N. cf pellucida on bacterial QS. During this
research, the degradation pathway of the QS molecules was elucidated and a variety of halogenated
AHL degradation derivatives were synthesized and evaluated for their ability to either induce or inhibit
QS activity.
2. Results and Discussion
2.1. Nitzschia cf pellucida Deactivation of β-Keto-AHLs
A first series of experiments was performed in order to determine whether the haloperoxidase
system within Nitzschia cf pellucida is capable of mediating the deactivation of AHLs. In a previous
study, the presence of a haloperoxidase in this benthic diatom was detected via the phenol red
assay [33]. In the present study, haloperoxidase activity was verified via the formation of bromophenol
blue after addition of phenol red and H2O2 (to ensure sufficient production of reactive halogen
intermediates [29,30]) to the cultures (data not shown) [33]. Furthermore, the activity of
N-3-oxohexanoyl homoserine lactone (OHHL) and N-hexanoyl homoserine lactone (HHL) was
monitored over time with the Chromobacterium violaceum CV026 bioassay in the absence or presence
of N. cf pellucida (Table 1). These compounds were selected, because OHHL is a known biofilm
enhancer. For the control sample (synthetic seawater + H2O2 + OHHL) and the sample in which the
N. cf pellucida culture was only supplemented with OHHL, the QS activity was retained throughout
the monitoring period. The decrease in QS activity that was observed for these samples after
180 min of incubation is most probably due to pH-dependent AHL lactonolysis [35]. The addition of
synthetic homoserine lactone bearing a β-keto moiety (OHHL) in combination with H2O2 to a
N. cf pellucida culture resulted in the deactivation of this type of AHL which is demonstrated in
Figure 1. This is in accordance with previous studies in which natural haloperoxidase systems of
Laminaria digitata and Delisea pulchra mediated the deactivation of these AHLs in C. violaceum

Mar. Drugs 2014, 12
355
CV026 [30] and A. tumefaciens NT1 bioassays [29]. Activity of β-keto-AHL was lost after 60 min in
cultures in which H2O2 was added. Not surprisingly, HHL which does not contain a β-keto moiety, was
not affected and retained QS activity. In a next step, in order to verify whether the deactivation of the
OHHL was due to haloperoxidase activity, two additional experiments were performed. In the first
experiment, catalase was added to an active N. cf pellucida culture. Catalase is an enzyme that
catalyzes the decomposition of hydrogen peroxide, which occurs in algal cells due to the Mehler
reaction [36], to water and oxygen. It was expected that in the absence of hydrogen peroxide, the
haloperoxidase would not be able to mediate the oxidation of halides and subsequently the
halogenation of OHHL. This assumption was found to be true as can be seen from the final entry in
Table 1. Similar to the sample containing the culture and OHHL, the QS stimulating activity was
retained for the culture where catalase and H2O2 were added, which demonstrates that the deactivation
of β-keto-AHLs is H2O2-dependent.
Table 1. Effect of N. cf pellucida haloperoxidase on the quorum sensing (QS) activity of
signal molecules (N-hexanoyl homoserine lactone (HHL) and N-3-oxohexanoyl
homoserine lactone (OHHL)), assessed by the Chromobacterium violaceum CV026
bioassay (+ + + strong QS activity, − no QS activity).
Sample
0 min
+ + +
−
30 min
+ + +
−
60 min
+ + +
−
120 min
+ +
−
180 min
Synthetic seawater + H2O2 + OHHL
N. cf pellucida
+
−
N. cf pellucida + OHHL
+ + +
+ + +
+ + +
+ + +
+ + +
+ + +
+ + +
+ +
+
N. cf pellucida + H2O2 + OHHL
N. cf pellucida + HHL
+ +
+
−
−
+ + +
+ + +
+ + +
+ + +
+ + +
+ + +
+ +
+ +
+ +
+ +
+ +
+
N. cf pellucida + H2O2 + HHL
N. cf pellucida + H2O2 + OHHL + Catalase
Figure 1. Loss of quorum sensing (QS) activity of N-3-oxohexanoyl homoserine lactone
(OHHL) in the Chromobacterium violaceum CV026 bioassay monitored over time.
(N. cf pellucida + H2O2 + OHHL treatment). Where, 1: t = 0 min; 2: t = 30 min;
3: t = 60 min; 4: t = 120 min; 5: t = 180 min.
The second experiment was performed in order to evaluate the possibility that cyanogen bromide
(BrCN) could react with the signal molecules and cause the deactivation (Table 2). BrCN is one of the
main and most active halogenated metabolites previously identified in N. cf pellucida extracts [33].
Two different concentrations (2 and 4 μM) within the range of BrCN levels produced by
N. cf pellucida were evaluated. From these experiments, it could be seen that the addition of BrCN did
not result in the deactivation of the signal molecules. Moreover, no inhibition of bacterial growth was
observed for the control samples, which is in accordance with a previous study [33].

Mar. Drugs 2014, 12
Table 2. QS activity of N-Acylated homoserine lactones (AHLs) in the Chromobacterium
356
violaceum CV026 bioassay in the presence of two different concentrations of cyanogen
bromide (BrCN) (+ + + strong QS activity, − no QS activity).
Sample
Activity
−
2 μM BrCN
4 μM BrCN
−
2 μM BrCN + HHL
4 μM BrCN + HHL
2 μM BrCN + OHHL
4 μM BrCN + OHHL
+ + +
+ + +
+ +
+ +
2.2. Degradation Pathway of β-Keto-AHLs
The formation of halogenated compounds by a haloperoxidase system can be elaborated either via
direct binding of the substrate to the active site or via the release of hypohalous acids from the active
site. The latter can occur via bromide, chloride or iodide oxidation by hydrogen peroxide, which has an
effect on electrophilic halogenating reactions. The suggested degradation pathway of
N-β-keto-acylated homoserine lactone bacterial signaling molecules is presented in Scheme 1 [37].
Scheme 1. Degradation pathway of N-3-oxohexanoyl homoserine lactone (OHHL) (1a).
Scheme adopted from [37].
O
O
O
O
O
O
+ HOBr
-H2O
+ HOBr
-H2O
(S)
(S)
(S)
N
N
O
N
O
O
H
H
H
Br Br
H
Br
O
O
O
(MBHL) 2a
(DBHL) 3a
+H2O
O
(OHHL) 1a
OH
OH
O
O
(S)
+H2O
Br
Br
N
N
O
OH
H
H
Br
Br
O
O
6
4
(DAHL) 5
The degradation pathway of β-keto-AHL bacterial signaling molecules by the natural
haloperoxidase system of N. cf pellucida was investigated using a reversed-phase HPLC separation
method developed to detect the parent lactones and the occurring halogenated products. Structure
elucidation of the anticipated reaction products was achieved by photodiode array UV spectroscopy
coupled with mass spectrometry. The chromatographic analysis of the degradation of OHHL (1a,
Scheme 1) revealed the formation of the brominated products 2a, 3a and 5 (Table 3). OHHL yielded
the (M + H)+ ion with the anticipated m/z value of 214. The peaks eluting at a later stage were assumed
to be the monobrominated OHHL (MBHL, 2a) and the dibrominated OHHL (DBHL, 3a). Indeed,
mass spectrometric analysis yielded a pseudomolecular ion with m/z value of 292/294 that can be
attributed to MBHL (2a) (retention time 15.7 min). The 1:1 isotope peak pattern further indicated the
addition of one bromine atom to OHHL. The m/z values of 370/372/374 (retention time 19.3 min)
showed a 1:2:1 isotope peak pattern which is consistent with the DBHL (3a), formed by the
introduction of two bromine atoms. Cleavage of the halogenated N-acyl chain resulted subsequently in

Mar. Drugs 2014, 12
357
the formation of N-(α,α-dibromoacetyl) homoserine lactone (DAHL, 5). For the latter compound 5 a
pseudomolecular ion with m/z value of 300/302/304 was observed, again with the characteristic 1:2:1
isotope peak pattern. Finally, structure elucidation of these compounds was further verified via the
preparation of synthetic standards 1, 2, 3 and 5 as reference compounds (see section 2.3). To the best
of our knowledge this is the first time that the suggested degradation pathway has been verified by the
use of reference compounds.
Table 3. Degradation of N-3-oxohexanoyl homoserine lactone (OHHL) (1a) analyzed
by HPLC-MS.
Relative Abundance (%) at 220 nm
Compound
(M + H)+
R.T. (min) a
30 min
60 min
120 min
180 min
(OHHL) 1a
(MBHL) 2a
(DBHL) 3a
(DAHL) 5
214
292
370
300
5.2
15.7
19.3
4.1
37
21
42
0
29
24
47
0
25
27
48
0
<3
27
63
7
a Retention time (R.T.) corresponds with the R.T. of synthetically prepared reference compounds.
2.3. Synthesis and Biological Evaluation of Halogenated AHL Analogues
2.3.1. Synthesis of N-3-Oxoacylated Homoserine Lactones
(S)-Homoserine lactone hydrobromide 9 was prepared as previously described by reaction of
L-methionine with bromoacetic acid [38]. β-Keto-AHLs 1a–f were prepared by reaction of homoserine
lactone hydrobromide 9 with adducts 8a–f, which were initially prepared by reaction of Meldrum’s
acid with the appropriate acid chloride 7a–f (Scheme 2) [39]. This methodology allows the preparation
of a wide variety of AHLs with a β-keto functionalized acyl chain in an efficient manner.
Scheme 2. Synthesis of β-keto AHLs 1.
2.3.2. Synthesis of Halogenated N-3-Oxoacylated Homoserine Lactone Analogues
In the next step, N-3-oxoacylated homoserine lactones 1a–f were brominated chemoselectively to
the corresponding α-monobrominated β-keto-AHLs 2a–f by the use of a combination of vanadium
pentoxide, ammonium bromide and hydrogen peroxide in a biphasic system of dichloromethane and
water (Scheme 3) [40]. This transformation resembles the suggested natural process activated by

Mar. Drugs 2014, 12
358
vanadium-dependent haloperoxidases [5]. Alternatively, the α,α-dibrominated analogues 3a–f were
prepared by reaction of the corresponding β-keto-AHLs 1a–f with a freshly prepared solution of
sodium hypobromite [41]. Additionally, iodinated analogues 10a–f were prepared by grinding the
corresponding β-keto-AHL 1a–f with N-iodosuccinimide (NIS) under neat conditions [42]. Finally,
reaction of β-keto-AHLs 1a–f with an aqueous solution of sodium hypochlorite resulted in the desired
α,α-dichlorinated analogues 11a–f.
Scheme 3. Synthesis of halogenated β-keto-AHL analogues.
In a last step, the final cleavage products of the halogenated AHLs were prepared in acceptable
yields by EDC-mediated coupling of the appropriate α,α-dihaloacetic acid 12a,b with (S)-homoserine
lactone hydrobromide 9 to yield N-α,α-dibromo- and N-α,α-dichloroacetyl homoserine lactones 5 and
13 in moderate yields (Scheme 4). Furthermore, N-acetyl homoserine lactone 15 was synthesized by
reaction of acetyl chloride 14 with homoserine lactone hydrobromide 9 [38].
Scheme 4. Synthesis of N-acetyl homoserine lactone 15 and halogenated derivatives 5
and 13.

Mar. Drugs 2014, 12
359
2.3.3. Biological Evaluation
In a next part of this research, all the synthesized compounds were tested for their ability to activate
quorum sensing in the E. coli JB523 microplate assay. E. coli JB523 was selected as biosensor for this
series of tests because of its relative high sensitivity and the ability to detect AHLs with various acyl
chain lengths. The ability of the natural β-keto-AHLs 1, their halogenated analogues 2, 3, 5, 10, 11, 13
and N-acetyl homoserine lactone 15 to induce fluorescence was expressed as percentage of relative
fluorescence (Supplementary Table S1). The QS stimulating activity of OHHL (1a) and the resulting
degradation products 2a, 3a and 5 are demonstrated in Figure 2.
Figure 2. Quorum sensing-regulated green fluorescent protein (GFP) production by
Escherichia coli JB523 induced by OHHL 1a and the occuring degradation products.
N-(α,α-Dibromoacetyl) homoserine lactone (DAHL) 5 was inactive in all concentrations.
GFP production was determined by measuring the specific fluorescence. GFP fluorescence
was corrected for the cell density of the reporter strain (fluorescence/OD450). Phosphate
buffer saline was used as control. Results are expressed as mean value ± standard deviation
of six repetitions.
In most of the cases, the natural AHLs 1a–f demonstrated agonistic activity in the entire
concentration range (1000–1.25 nM). Not surprisingly, the activity of these natural AHLs 1 decreased
with increasing length of the acyl chain (Supplementary Table S1). N-3-Oxohexanoyl and
N-3-oxoheptanoyl homoserine lactone 1a and 1b showed the highest activity. Mono- and dibrominated
analogues 2 and 3 were the most active compounds among the halogenated analogues. Frequently
compounds 2 and 3 displayed activation in the whole concentration range. Nevertheless, their activity
was reduced when compared to the natural AHL 1 with the same acyl chain length. Iodinated
analogues 10a–f demonstrated reduced activity when compared to their monobrominated analogues 2,
with the N-α-iodo-β-ketodecanoyl homoserine lactone 10e being the most active among them.
Surprisingly, the dichlorinated analogues 11a–f with exception of 11d and 11f showed almost no
activity. Moreover, the final degradation product 5, the corresponding N-α,α-dichloroacetyl analogue
13 and N-acetyl derivative 15, were also evaluated as QS inducers. Overall, these compounds failed to
induce GFP production. Since no activity was observed for N-acetyl homoserine lactone 15, it can be

Mar. Drugs 2014, 12
360
suggested that cleavage of the acyl chain to an N-acetyl derivative is the crucial step for the complete
loss of activity that was also observed in the Chromobacterium violaceum bioassay.
Subsequently, the halogenated analogues 2, 3, 5, 10, 11 and 13 were screened for their ability to
disrupt QS in a competition test with the natural autoinducer OHHL 1a in the Escherichia coli
bioassay (Supplementary Table S2). However, none of the halogenated lactones was able to
significantly reduce QS regulated GFP production in the whole concentration range (Supplementary
Table S2). One might expect that due to the inductive effect of the halogen as an electrophilic moiety,
a covalent bond could be formed between the halogenated analogue and the binding site of the
receptor [43]. However, the absence of antagonistic activity of the novel halogenated analogues 2, 3,
10 and 11 indicates that the reduction in QS activity results from the presence of larger halogen
substituents which causes changes in the steric and electronic properties of the N-acyl chain.
3. Experimental Section
3.1. Deactivation of N-Acylated Homoserine Lactones
3.1.1. N. cf pellucida Culture
N. cf pellucida was isolated from the “Rammekenshoek” intertidal mudflat in the Westerschelde
Estuary, The Netherlands (51°26′50′′N, 3°38′38′′E) on March 3, 2009. Cultures and permanent slides
of the cultures used for the experiments were stored in DCG: BCCM 303 (Belgian Coordinated
Collections of Microorganisms) Diatom Culture Collection hosted by the Laboratory of Protistology
& Aquatic Ecology, Ghent University, Belgium. The culture medium was prepared by filtration and
autoclavation of North Sea seawater which was supplemented with f/2 nutrients. The cultures were
maintained in a climate room at 19 ± 1 °C and illuminated by cool-white fluorescent lamps at a rate of
50 μmol photons m−2s−1 with a light/dark cycle of 12/12 h.
3.1.2. Phenol Red Assay
Haloperoxidase activity was verified via the bromination of phenol red (phenolsulfonphthalein) into
bromophenol blue (3′,3′′,5′,5′′-tetrabromophenolsulfonphthalein). Phenol red (30 μM final
concentration) was added to N. cf pellucida cultures 3h after daybreak. After two hours phenol red and
bromophenol blue were monitored spectrophotometrically at 433 nm and 592 nm, respectively.
3.1.3. Chromobacterium violaceum Bioassay
Chromobacterium violaceum CV026 is a mini-Tn5 mutant that is deficient in CviI (AHL synthase)
which produces the purple pigment violacein in the presence of exogenous AHL [44]. This biosensor
is most sensitive to HHL. A quantity of 10 mL of Luria-Bertani (LB) hard agar (1.5% agar) was placed
in a Petri dish. The solidified agar was then covered with 5 mL of soft LB agar (0.5% agar) mixed with
100 µL of Chromobacterium violaceum CV026 culture (grown overnight at 27 °C). When the second
layer was solidified, the agar was subsequently punched with a sterile glass pipette to form a well.
Then 50 µL of test sample was removed from the appropriate culture and added to the well. Plates
were incubated at 27 °C for 24 h and examined for violacein production. Violacein production was

Mar. Drugs 2014, 12
361
ranked visually from + + + (intense pigment, same as control with AHL added) to − (no pigment
production, synthetic seawater was used as a negative control). For the deactivation experiment the
conditions were: AHL (HHL or OHHL 1a) concentration 5 ppm and H2O2 concentration 0.25 mM. For
the catalase and BrCN experiments the conditions were the same as mentioned for the
deactivation experiment.
3.1.4. Catalase Experiment
The effect of the H2O2-decomposing enzyme catalase (600 units bovine liver catalase mL−1
dissolved in water, Sigma-Aldrich, St. Louis, MO, USA) on the QS deactivation by N. cf pellucida
haloperoxidase was assessed by adding catalase together with H2O2 to N. cf pellucida cultures one hour
before the onset of light and the C. violaceum bioassay was performed as described above, 3 h after the
onset of light [33].
3.2. Degradation Pathway
3.2.1. Liquid-Liquid Extraction of OHHL 1a and Degradation Products
To active cultures of N. cf pellucida, 10 ppm of OHHL 1a was added. The degradation of OHHL 1a
was followed over time (30 min; 60 min; 120 min; 180 min) by removing and filtering the culture
medium with a GF/F filter. The culture medium was extracted twice with an equal volume of
dichloromethane. The organic phases were collected and dried with MgSO4 and subsequently
evaporated with a gentle stream of air. The dry extracts were stored in the freezer (−18 °C) prior
to analysis.
3.2.2. HPLC-MS Method
The analyses were performed with an Agilent 1100 LC-MSD system (Agilent Technologies,
Waldbronn, Germany). The system was equipped with a quaternary pump, an autosampler, a vacuum
degasser, and as a detector a Diode-array variable detector (DAD) and an 1100 6-port auto injector
valve were used. The system was controlled by an Agilent software v.A.09.03. The Phenomenex C-18
(ODS, Octadecyl) security guard and the Phenomenex Luna C18 100A (Phenomenex, Torrance, CA,
USA) column used were maintained at 35 °C. Elution was performed at a flow rate of 0.5 mL/min. As
a mobile phase, a mixture of 0.02% acetic acid in water (solvent A) with pH = 3.1 and LC-MS grade
acetonitrile (solvent B) were used. Detection of OHHL 1a and the degradation products was performed
at 220, 280 and 320 nm with a diode array detector. The mass spectrometer system was an Agilent
1100 equipped with an Agilent G1946D (SL) quadrapole mass spectrometer and electrospray
ionization (ESI) system. As nebulizing gas, nitrogen was used at a pressure of 50 psi and with a flow
of 13 L/min. The heated capillary was maintained at 350 °C and the voltage at 4.1 kV. The full mass
spectra were measured from m/z 75 up to m/z 1000. The data were collected in positive
ionization mode.

Mar. Drugs 2014, 12
362
3.3. Chemical Synthesis
3.3.1. Synthesis of Homoserine Lactone Hydrobromide 9
A mixture of (S)-methionine (0.10 mol) and bromoacetic acid (0.11 mol) in 150 mL of a
water-isopropanol-acetic acid mixture (5:5:2 v:v) was stirred at reflux overnight. The solvent was then
removed under reduced pressure. Subsequently, the orange sticky oil was partly dissolved in 50 mL of
a 4:1 mixture (v:v) of isopropanol:30% hydrogen bromide (HBr) in acetic acid. The desired compound
was collected by filtration and the purification procedure was repeated starting by evaporation of the
orange filtrate to dryness. Compound 9 was collected as a beige powder, mp 227–229 °C
(mp 226–228 °C [38]). All other physical and analytical data were in agreement with literature
data [38].
3.3.2. Synthesis of β-Keto-AHLs 1a–f
In a flame dried flask, Meldrum’s acid (36.9 mmol) and 6 mL of pyridine (74.2 mmol) were
dissolved in dry dichloromethane (30 mL) under a nitrogen atmosphere. The appropriate acid chloride
7a–f (36.9 mmol) was added dropwise at ice bath temperature. The mixture was stirred overnight,
during which the temperature was allowed to increase to room temperature. Then, the reaction mixture
was quenched with 1 M aq. HCl and the organic phase was washed with water and brine. The organic
phase was collected and evaporated to yield adducts 8a–f. The crude adducts 8a–f were dissolved in
acetonitrile, after which homoserine lactone hydrobromide 9 (36.9 mmol) and Et3N (36.9 mmol) were
added and the reaction mixture was stirred overnight at reflux. The organic phase was evaporated and
the crude product was dissolved in ethyl acetate. The organic phase was washed with 1M aq. HCl and
brine. The organic phase was dried with MgSO4, evaporated and the crude product was purified
via column chromatography on silica gel (EtOAc:petroleum ether 3:2) to yield the desired
β-keto-AHLs 1a–f.
3.3.3. Synthesis of α-Bromo-β-keto-AHLs 2a–f
To a stirred solution of vanadium pentoxide (1.9 mmol) in water was added 50% solution of
hydrogen peroxide in water (76 mmol) at ice-bath temperature while stirring. The color changed from
light orange to deep red after 25–30 min. Then, ammonium bromide (5.7 mmol) was added and the
reaction mixture was stirred for another 10 min. Subsequently, β-keto-AHL 1a–f (3.8 mmol) was
added in dichloromethane and the reaction mixture was then stirred further for 3 h at the same
temperature. After completion of the reaction, as monitored by TLC, the mixture was extracted twice
with dichloromethane (25 mL) and the organic layer was washed with saturated sodium metabisulfite
solution (15 mL). Finally, it was washed with water and dried with MgSO4. The organic phase was
evaporated and the crude products were purified via column chromatography on silica gel
(EtOAc:petroleum ether 4:1) to yield the desired 2a–f.

Mar. Drugs 2014, 12
363
3.3.4. Synthesis of α,α-Dichloro-β-keto and α,α-Dibromo-β-keto-AHLs 11a–f and 3a–f
To a solution of the appropriate β-keto-AHL 1a–f (1.20 mmol) in acetone (5 mL) and glacial acetic
acid (2 mL) cooled to 0 °C was added dropwise sodium hypochlorite solution (3.6 mmol). The mixture
was stirred for 2 h at 0 °C, then poured into saturated Na2CO3 solution and extracted with
dichloromethane. The combined organic layers were dried (MgSO4) and concentrated in vacuo. The
crude product was purified by flash chromatography on silica gel (EtOAc:petroleum ether 2:3) to
afford the dichlorinated products 11a–f. Brominations were conducted as described above using
freshly prepared sodium hypobromite solution (7.2 mmol). The stock solution of sodium hypobromite
was prepared by slowly adding bromine (16.6 mmol) to a solution of sodium hydroxide (50 mmol) in
water (25 mL) at 0 °C. The mixture was stirred for 15 min and used immediately.
3.3.5. Synthesis of α-Iodo-β-keto-AHLs 10a–f
In a porcelain mortar 1 mmol of the appropriate β-keto-AHL 1a–f was ground for 5 min with
N-iodosuccinimide (1 mmol) and the mixture was left to react at room temperature for 3 h. The formed
paste was subsequently extracted with dichloromethane and the organic phase was washed with water.
The collected organic phase was dried with MgSO4 and evaporated. Crude products were purified by
column chromatography on silica gel (EtOAc:petroleum ether 4:1) to yield the desired α-iodo-β-keto
AHLs 10.
3.3.6. Synthesis of N-α,α-Dibromo- and N-α,α-Dichloroacetyl Homoserine Lactones 5 and 13
To a stirred solution of (S)-homoserine lactone hydrobromide 9 (2 mmol) in 5 mL of water,
triethylamine (2 mmol) was added, followed by the addition of the appropriate brominated or
chlorinated acetic acid 12 (3 mmol) and 1-ethyl-3-(3-dimethylaminopropyl)carbodiimide hydrochloride
(3 mmol). The mixture was stirred overnight at room temperature. The aqueous phase was extracted
two times with ethyl acetate (20 mL) and the organic phase was washed with saturated aq. NaHCO3
solution and brine. Drying with MgSO4, filtration and evaporation of the solvent gave the
corresponding halogenated acetyl homoserine lactones 5 and 13. The crude product was purified via
column chromatography on silica gel (EtOAc:petroleum ether 4:1).
3.3.7. Synthesis of N-Acetyl Homoserine Lactone 15
Under dry conditions, triethylamine (3.8 mmol) was added to a stirred solution of (S)-homoserine
lactone hydrobromide 9 (1.8 mmol) in 50 mL dichloromethane cooled at −78 °C. Acetyl chloride 14
(2 mmol) was then added dropwise and the temperature was allowed to rise to room temperature
during a period of 2 h. Evaporation to dryness gave a white semi-solid which was partly dissolved by
ethyl acetate and the salt remaining was separated by filtration. The organic phase was evaporated and
purified by column chromatography on silica gel (EtOAc:petroleum ether 4:1).

Mar. Drugs 2014, 12
364
3.4. Biological Activity of Novel Halogenated AHL Analogues
Escherichia coli JB523 Green Fluorescent Protein (GFP) Microplate Assay
E. coli JB523 is a highly sensitive biosensor which contains plasmid pJBA130 that encodes green
fluorescent protein (GFP) in response to exogenous AHL [45]. Strain JB523 was grown overnight at
28 °C in LB medium supplemented with 20 mg/L tetracycline until the optical density (OD) reached
approximately 1 at 550 nm. The bacteria were then diluted to an OD600 of 0.1. Then 100 μL of the
diluted culture was mixed with 100 μL of the appropriate concentration of the tested compound.
Phosphate buffer saline (PBS) was used to prepare the stock solutions for all concentrations. PBS was
used as a negative control for activation tests. For the inhibition tests, the procedure was the same with
the exception of the addition of 100 μL of a 100 nM solution OHHL 1a to the culture medium to reach
a final concentration of 50 nM. The plate was gently stirred in an incubator at 28 °C for 2 h.
QS-regulated GFP production was then assessed by fluorescence measurements (excitation at 475 nm
and emission at 515 nm) using a PerkinElmer VICTOR X (PerkinElmer, Waltham, MA, USA)
multilabel plate reader. The fluorescence was normalized for cell density of the reporter strain.
4. Conclusions
In conclusion, the deactivation of β-keto-AHLs by the natural haloperoxidase system of the benthic
diatom N. cf pellucida has been reported for the first time. The disruption of these signal molecules
was shown to be H2O2-dependent. In addition, the degradation pathway towards halogenated
derivatives was elucidated by means of HPLC-MS and by the synthesis of a broad library of novel
halogenated AHL analogues as reference compounds. The ability of these AHL analogues as quorum
sensing modulators was directly compared to and evaluated against a series of naturally occurring
β-keto AHLs. Finally, it was demonstrated that the haloperoxidase mediated loss of QS activity
resulted from the final cleavage of the halogenated N-acyl chain of the signal molecules.
Acknowledgements
The authors are indebted to the “Research Foundation Flanders (FWO)” (G:0374.11N) and Ghent
University (BOF-GOA project 01G01911) for financial support of this research. The authors are
indebted to Belspo/BCCM for providing the diatom in study. The authors would also like to thank
Peter Bossier (A.R.C., Ghent University) for kindly providing the reporter strains for the bioassays.
Conflicts of Interest
The authors declare no conflict of interest.
References
1. Cardozo, K.H.M.; Guaratini, T.; Barros, M.P.; Falcão, V.R.; Tonon, A.P.; Lopes, N.P.; Campos,
S.; Torres, M.A.; Souza, A.O.; Colepicolo, P.; et al. Metabolites from algae with economical
impact. Comp. Biochem. Physiol. C Pharmacol. Toxicol. 2007, 146, 60–78.

Mar. Drugs 2014, 12
365
2. Cabrita, M.T.; Vale, C.; Rauter, A.P. Halogenated Compounds from Marine Algae. Mar. Drugs
2010, 8, 2301–2317.
3. Blunt, J.W.; Copp, B.R.; Hu, W.P.; Munro, M.H.; Northcote, P.T.; Prinsep, M.R. Marine natural
products. Nat. Prod. Rep. 2009, 26, 170–244.
4. Butler, A.; Carter-Franklin, J.N. The role of vanadium bromoperoxidase in the biosynthesis of
halogenated marine natural products. Nat. Prod. Rep. 2004, 21, 180–188.
5. Butler, A.; Walker, J.V. Marine haloperoxidases. Chem. Rev. 1993, 93, 1937–1944.
6. de Kievit, T.R. Quorum sensing in Pseudomonas aeruginosa biofilms. Environ. Microbiol. 2009,
11, 279–288.
7. Whitehead, N.A.; Barnard, A.M.L.; Slater, H.; Simpson, N.J.L.; Salmond, G.P.C.
Quorum-sensing in gram-negative bacteria. FEMS Microbiol. Rev. 2001, 25, 365–404.
8. Williams, P. Quorum sensing, communication and cross-kingdom signalling in the bacterial
world. Microbiology 2007, 153, 3923–3938.
9. Decho, A.W.; Frey, R.L.; Ferry, J.L. Chemical Challenges to Bacterial AHL Signaling in the
Environment. Chem. Rev. 2011, 111, 86–99.
10. Tait, K.; Williamson, H.; Atkinson, S.; Williams, P.; Camara, M.; Joint, I. Turnover of quorum
sensing signal molecules modulates cross-kingdom signalling. Environ. Microbiol. 2009, 11,
1792–1802.
11. Decho, A.W.; Visscher, P.T.; Ferry, J.; Kawaguchi, T.; He, L.; Przekop, K.M.; Norman, R.S.;
Reid, R.P. Autoinducers extracted from microbial mats reveal a surprising diversity of
N-acylhomoserine lactones (AHLs) and abundance changes that may relate to diel pH. Environ.
Microbiol. 2009, 11, 409–420.
12. Wheeler, G.L.; Tait, K.; Taylor, A.; Brownlee, C.; Joint, I. Acyl-homoserine lactones modulate
the settlement rate of zoospores of the marine alga Ulva intestinalis via a novel chemokinetic
mechanism. Plant Cell Environ. 2006, 29, 608–618.
13. Bruckner, C.G.; Bahulikar, R.; Rahalkar, M.; Schink, B.; Kroth, P.G. Bacteria associated with
benthic diatoms from Lake Constance: Phylogeny and influences on diatom growth and secretion
of extracellular polymeric substances. Appl. Environ. Microbiol. 2008, 74, 7740–7749.
14. Amin, S.A.; Parker, M.S.; Armbrust, E.V. Interactions between diatoms and bacteria. Microbiol.
Mol. Biol. Rev. 2012, 76, 667–684.
15. Goecke, F.; Labes, A.; Wiese, J.; Imhoff, J.F. Chemical interactions between marine macroalgae
and bacteria. Mar. Ecol. Prog. Ser. 2010, 409, 267–299.
16. de Carvalho, C.C.C.R.; Fernandes, P. Production of Metabolites as Bacterial Responses to the
Marine Environment. Mar. Drugs 2010, 8, 705–727.
17. Dobretsov, S.; Teplitski, M.; Bayer, M.; Gunasekera, S.; Proksch, P.; Paul, V.J. Inhibition of
marine biofouling by bacterial quorum sensing inhibitors. Biofouling 2011, 27, 893–905.
18. Natrah, F.M.I.; Defoirdt, T.; Sorgeloos, P.; Bossier, P. Disruption of Bacterial Cell-to-Cell
Communication by Marine Organisms and its Relevance to Aquaculture. Mar. Biotechnol. 2011,
13, 109–126.

Mar. Drugs 2014, 12
366
19. Manefield, M.; de Nys, R.; Kumar, N.; Read, R.; Givskov, M.; Steinberg, P.; Kjelleberg, S.A.
Evidence that halogenated furanones from Delisea pulchra inhibit acylated homoserine lactone
(AHL)-mediated gene expression by displacing the AHL signal from its receptor protein.
Microbiology 1999, 145, 283–291.
20. Manefield, M.; Rasmussen, T.B.; Henzter, M.; Andersen, J.B.; Steinberg, P.; Kjelleberg, S.;
Givskov, M. Halogenated furanones inhibit quorum sensing through accelerated LuxR turnover.
Microbiology 2002, 148, 1119–1127.
21. Skindersoe, M.E.; Ettinger-Epstein, P.; Rasmussen, T.B.; Bjarnsholt, T.; de Nys, R.; Givskov, M.
Quorum sensing antagonism from marine organisms. Mar. Biotechnol. 2008, 10, 56–63.
22. Jha, B.; Kavita, K.; Westphal, J.; Hartmann, A.; Schmitt-Kopplin, P. Quorum Sensing Inhibition
by Asparagopsis taxiformis, a Marine Macro Alga: Separation of the Compound that Interrupts
Bacterial Communication. Mar. Drugs 2013, 11, 253–265.
23. Teplitski, M.; Chen, H.C.; Rajamani, S.; Gao, M.S.; Merighi, M.; Sayre, R.T.; Robinson, J.B.;
Rolfe, B.G.; Bauer, W.D. Chlamydomonas reinhardtii secretes compounds that mimic bacterial
signals and interfere with quorum sensing regulation in bacteria. Plant Physiol. 2004, 134,
137–146.
24. Natrah, F.M.I.; Kenmegne, M.M.; Wiyoto, W.; Sorgeloos, P.; Bossier, P.; Defoirdt, T. Effects of
micro-algae commonly used in aquaculture on acyl-homoserine lactone quorum sensing.
Aquaculture 2011, 317, 53–57.
25. Hunt, L.R.; Smith, S.M.; Downum, K.R.; Mydlarz, L.D. Microbial Regulation in Gorgonian
Corals. Mar. Drugs 2012, 10, 1225–1243.
26. Motti, C.A.; Ettinger-Epstein, P.; Willis, R.H.; Tapiolas, D.M. ESI FTICR-MS Analysis of Larvae
from the Marine Sponge Luffariella variabilis. Mar. Drugs 2010, 8, 190–199.
27. Ettinger-Epstein, P.; Tapiolas, D.M.; Motti, C.A.; Wright, A.D.; Battershill, C.N.; de Nys, R.
Production of manoalide and its analogues by the sponge Luffariella variabilis is hardwired. Mar.
Biotechnol. 2008, 10, 64–74.
28. Defoirdt, T.; Boon, N.; Bossier, P.; Verstraete, W. Disruption of bacterial quorum sensing: An
unexplored strategy to fight infections in aquaculture. Aquaculture 2004, 240, 69–88.
29. Sandy, M.; Carter-Franklin, J.N.; Martin, J.D.; Butler, A. Vanadium bromoperoxidase from
Delisea pulchra: enzyme-catalyzed formation of bromofuranone and attendant disruption of
quorum sensing. Chem. Commun. 2011, 47, 12086–12088.
30. Borchardt, S.A.; Allain, E.J.; Michels, J.J.; Stearns, G.W.; Kelly, R.F.; McCoy, W.F. Reaction of
acylated homoserine lactone bacterial signaling molecules with oxidized halogen antimicrobials.
Appl. Environ. Microbiol. 2001, 67, 3174–3179.
31. Hill, V.L.; Manley, S.L. Release of reactive bromine and iodine from diatoms and its possible role
in halogen transfer in polar and tropical oceans. Limnol. Oceanogr. 2009, 54, 812–822.
32. Wever, R.; van der Horst, M.A. The role of vanadium haloperoxidases in the formation of volatile
brominated compounds and their impact on the environment. Dalton Trans. 2013, 42,
11778–11786.
33. Vanelslander, B.; Paul, C.; Grueneberg, J.; Prince, E.K.; Gillard, J.; Sabbe, K.; Pohnert, G.;
Vyverman, W. Daily bursts of biogenic cyanogen bromide (BrCN) control biofilm formation
around a marine benthic diatom. Proc. Natl. Acad. Sci. USA 2012, 109, 2412–2417.

Mar. Drugs 2014, 12
367
34. Moore, R.M.; Webb, M.; Tokarczyk, R.; Wever, R. Bromoperoxidase and iodoperoxidase
enzymes and production of halogenated methanes in marine diatom cultures. J. Geophys. Res.
1996, 101, 20899–20908.
35. Yates, E.A.; Philipp, B.; Buckley, C.; Atkinson, S.; Chhabra, S.R.; Sockett, R.E.; Goldner, M.;
Dessaux, Y.; Camara, M.; Smith, H.; Williams, P. N-acylhomoserine lactones undergo
lactonolysis in a pH-, temperature-, and acyl chain length-dependent manner during growth of
Yersinia pseudotuberculosis and Pseudomonas aeruginosa. Infect. Immun. 2002, 70, 5635–5646.
36. Collen, J.; Delrio, M.J.; Garciareina, G.; Pedersen, M. Photosynthetic production of hydrogen
peroxide by Ulva rigida C. Ag. (Chlorophyta). Planta 1995, 196, 225–230.
37. Michels, J.J.; Allain, E.J.; Borchardt, S.A.; Hu, P.F.; McCoy, W.F. Degradation pathway of
homoserine lactone bacterial signal molecules by halogen antimicrobials identified by liquid
chromatography with photodiode array and mass spectrometric detection. J. Chromatogr. A 2000,
898, 153–165.
38. Persson, T.; Hansen, T.H.; Rasmussen, T.B.; Skinderso, M.E.; Givskov, M.; Nielsen, J. Rational
design and synthesis of new quorum-sensing inhibitors derived from acylated homoserine
lactones and natural products from garlic. Org. Biomol. Chem. 2005, 3, 253–262.
39. Hodgkinson, J.T.; Galloway, W.R.J.D.; Casoli, M.; Keane, H.; Su, X.; Salmond, G.P.C.; Welch,
M.; Spring, D.R. Robust routes for the synthesis of N-acylated-L-homoserine lactone (AHL)
quorum sensing molecules with high levels of enantiomeric purity. Tetrahedron Lett. 2011, 52,
3291–3294.
40. Khan, A.T.; Goswami, P.; Choudhury, L.H. A mild and environmentally acceptable synthetic
protocol for chemoselective alpha-bromination of beta-keto esters and 1,3-diketones. Tetrahedron
Lett. 2006, 47, 2751–2754.
41. Meketa, M.L.; Mahajan, Y.R.; Weinreb, S.M. An efficacious method for the halogenation of
beta-dicarbonyl compounds under mildly acidic conditions. Tetrahedron Lett. 2005, 46,
4749–4751.
42. Pravst, I.; Zupan, M.; Stavber, S. Halogenation of ketones with N-halosuccinimides under
solvent-free reaction conditions. Tetrahedron 2008, 64, 5191–5199.
43. Amara, N.; Mashiach, R.; Amar, D.; Krief, P.; Spieser, S.A.H.; Bottomley, M.J.; Aharoni, A.;
Meijler, M.M. Covalent Inhibition of Bacterial Quorum Sensing. J. Am. Chem. Soc. 2009, 131,
10610–10619.
44. McClean, K.H.; Winson, M.K.; Fish, L.; Taylor, A.; Chhabra, S.R.; Camara, M.; Daykin, M.;
Lamb, J.H.; Swift, S.; Bycroft, B.W.; et al. Quorum sensing and Chromobacterium violaceum:
Exploitation of violacein production and inhibition for the detection of N-acylhomoserine
lactones. Microbiology 1997, 143, 3703–3711.
45. Andersen, J.B.; Heydorn, A.; Hentzer, M.; Eberl, L.; Geisenberger, O.; Christensen, B.B.; Molin,
S.; Givskov, M. Gfp-based N-acyl homoserine-lactone sensor systems for detection of bacterial
communication. Appl. Environ. Microbiol. 2001, 67, 575–585.
© 2014 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
