Structural identification of antibacterial lipids from Amazonian palm tree endophytes through the molecular network approach

Article abstract of DOI:10.3390/ijms20082006

A library of 197 endophytic fungi and bacteria isolated from the Amazonian palm tree Astrocaryum sciophilum was extracted and screened for antibacterial activity against methicillin-resistant Staphylococcus aureus (MRSA). Four out of five antibacterial ethyl acetate extracts were also cytotoxic for the MRC-5 cells line. Liquid chromatography coupled to tandem mass spectrometry (UPHLC-HRMS/MS) analyses combined with molecular networking data processing were carried out to allow the identification of depsipeptides and cyclopeptides responsible for the cytotoxicity in the dataset. Specific ion clusters from the active Luteibacter sp. extract were also highlighted using an MRSA activity filter. A chemical study of Luteibacter sp. was conducted leading to the structural characterization of eight fatty acid exhibiting antimicrobial activity against MRSA in the tens of μg/mL range.

Full text of DOI:10.3390/ijms20082006

International Journal of
Molecular Sciences
Article
Structural Identification of Antibacterial Lipids from
Amazonian Palm Tree Endophytes through the
Molecular Network Approach
Morgane Barthélemy 1, Nicolas Elie 1 , Léonie Pellissier 2 , Jean-Luc Wolfender 2
,
Didier Stien 3, David Touboul 1,
*
and Véronique Eparvier 1,
*
1
CNRS-Institut de Chimie des Substances Naturelles, UPR2301, Universit
é
Paris-Saclay, 91198 Gif-sur-Yvette
CEDEX, France; morgane.barthelemy@cnrs.fr (M.B.); nicolas.elie@cnrs.fr (N.E.)
School of Pharmaceutical Sciences, EPGL, University of Geneva, University of Lausanne, Rue Michel Servet
1, CH-1211 Geneva, Switzerland; leonie.pellissier@unige.ch (L.P.); jean-luc.wolfender@unige.ch (J.-L.W.)
Sorbonne Université, CNRS, Laboratoire de Biodiversité et Biotechnologie Microbienne, USR3579,
Observatoire Océanologique, 66650 Banyuls-sur-mer, France; didier.stien@cnrs.fr
Correspondence: david.touboul@cnrs.fr (D.T.); veronique.eparvier@cnrs.fr (V.E.);
Tel.: +33-(0)16-982-3032 (D.T.); +33-(0)16-982-3679 (V.E.)
2
3
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 31 March 2019; Accepted: 17 April 2019; Published: 24 April 2019
Abstract: A library of 197 endophytic fungi and bacteria isolated from the Amazonian palm tree
Astrocaryum sciophilum was extracted and screened for antibacterial activity against methicillin-resistant
Staphylococcus aureus (MRSA). Four out of five antibacterial ethyl acetate extracts were also
cytotoxic for the MRC-5 cells line. Liquid chromatography coupled to tandem mass spectrometry
(UPHLC-HRMS/MS) analyses combined with molecular networking data processing were carried
out to allow the identification of depsipeptides and cyclopeptides responsible for the cytotoxicity in
the dataset. Specific ion clusters from the active Luteibacter sp. extract were also highlighted using
an MRSA activity filter. A chemical study of Luteibacter sp. was conducted leading to the structural
characterization of eight fatty acid exhibiting antimicrobial activity against MRSA in the tens of
µg/mL range.
Keywords: Astrocaryum sciophilum; endophytes; molecular networking; antibacterial; cytotoxicity;
fatty acids
1. Introduction
Endophytes are microorganisms that live inside the tissues of a host plant without causing
apparent symptoms either for all or a part of their life cycle [1]. This colonization is ubiquitous for
all plants in various environments. Indeed, endophytes have been isolated not only in environments
ranging from tropical to temperate climates but also in extreme habitats [2,3].
Plants are widely explored for new chemical entities with therapeutic purposes. Plant endophytes
are increasingly regarded as an important and a relatively underrated source of natural products for
drug discovery. Recent surveys suggested that tropical forests harbour several million hyperdiverse
endophyte species [4,5] that are expected to lead to the discovery of unique bioactive secondary
metabolites [ ]. Additionally, because endophytes contribute to the defence of their host, their
6
metabolites are expected to exert a defensive role, for example acting as antimicrobials or pathogen
growth-inhibitors [1].
We have pursued the study of the palm tree Astrocaryum sciophilum endophytes. A. sciophilum
grows as an understorey palm throughout the North-East Amazon (Brazil [Par
á, Amapá], French
Guiana, Surinam, Guyana) [ ]. Its development reflects a long-life cycle with a maturation age reaching
7
Int. J. Mol. Sci. 2019, 20, 2006; doi:10.3390/ijms20082006
www.mdpi.com/journal/ijms

Int. J. Mol. Sci. 2019, 20, 2006
2 of 13
approximately 170 years. It has periodical leaf production of 16 months on average, allowing the
dating of each leaf [ ]. Leaves can reach 20 years of age. As a result, endophytes of this model plant
8
are thought to persist for a long time in leaves and thus are able to resist environmental threats. For all
of these reasons, A. sciophilum endophytes may have developed antimicrobial weaponry to a greater
extent than other microbes.
A collection of 197 strains of cultivable endophytes from young (<16 months) and old (2–21 years)
healthy leaves collected from 6 specimens of A. sciophilum was cultured, extracted and screened towards
methicillin-resistant Staphylococcus aureus (MRSA). Additionally, the full strain collection was analysed
by high-resolution tandem mass spectrometry profiling (HRMS/MS), and the resulting fragmentation
data were organized as molecular networks (MNs). Molecular networking approaches allow the
organization of untargeted tandem MS datasets according to their spectral similarity, and generate
clusters of structurally related metabolites [9]. These approaches have become powerful tools for
navigating the chemical space of complex biological systems and can be used to view the chemical
constituents of a wide variety of extracts in a single map.
2. Results
2.1. Biological Activities of Endophyte Extracts
The 197 endophyte isolates (66 bacteria and 131 fungi) were identified, cultivated on solid media
and then extracted with ethyl acetate. All of the extracts were tested for antibacterial activity against
methicillin-resistant S. aureus. Five extracts, four from fungi (BSNB-0575, -0651, -0303 and -0732) and
one from bacteria (BSNB -0721) were active (Minimal Inhibitory Concentration (MIC)
The most active extracts arise from endophytic fungi with MIC of 32 (BSNB-0575 and BSNB-0651), 16
(BSNB-0303) and g/mL (BSNB-0732) (Table S1). Three of these four fungal extracts come from the
≤
64 µg/mL).
≤
8 µ
Fusarium genus (BSNB-0575, -0651 and -0303), and the fourth was identified as Akanthomyces attenuatus.
Extract obtained from bacteria Luteibacter sp. (BSNB-0721) have a MIC value of 64 µg/mL.
The cytotoxicity of all 5 antimicrobial extracts was evaluated using a normal human lung fibroblast
MRC-5 cell line. The bacterial extracts of Luteibacter sp. (BSNB-0721) was not cytotoxic, with an
antibacterial selectivity index above 1 (Table S1).
2.2. Molecular Networking
All active and inactive ethyl acetate (EtOAc) extracts were analysed by Ultra-High Performance
Liquid Chromatography-High Resolution Mass Spectrometry (UHPLC-HRMS/MS) using the
data-dependent acquisition mode. Data were first processed by MZmine 2.33 [10], generated by
MetGem [11] and molecular networks (MNs) were visualized using Cytoscape 3.7.0.
Relative quantification of the ions was represented by pie chart diagrams, with their proportions
based on the respective areas of the corresponding extracted ion chromatograph (XIC) areas [12].
Targeted analysis of the MN was made possible by colouring the nodes based on the extract’s
antibacterial activity, highlighting node clusters among the antibacterial extracts.
A first MN was built with the data from the 131 fungal extracts (Figure S1) composed of 28,719
nodes in 13,060 clusters. Eleven clusters contained nodes from the four active fungal extracts. MS2
spectra of the ions at m/z 640.42, 654.43, 668.45 (Cluster 2), 600.41, 552.41, 586.39 (Cluster 1) and 730.42
(Cluster 9) matched respectively with three depsipeptides, three pentacyclopeptide and Exumolide A
(another depsipeptide) referenced in the available libraries (See Figure 1 and Figure S2). Examination
of the MS2 spectra of other active clusters showed that these compounds share MS2 fragmentation
patterns that are similar to that of a peptide because of the typical loss of fragment at m/z 113.08
(Leucine/Isoleucine), m/z 99.07 (Valine), m/z 71.04 (Alanine) and m/z 101.05 (Threonine) (See Figure S2).
According to the MN, these compounds are also found in extracts with MIC of 128 µg/mL from other
Fusarium strains. Differences of activity for these extracts can be explained by the relative quantities of
metabolites in the extracts (Figure S3).

Int. J. Mol. Sci. 2019, 20, 2006
3 of 13
Figure 1.
quantification values of each ion within the extracts are represented as an extracted ion chromatograph
(XIC) area-dependent pie chart. ( ) Dereplication process nodes belongings to cluster 2 composed by
(A) Molecular network (MN) of the 131 extracts from fungal endophytes. Relative
B
ions from the extracts of BSNB-0575 and BSNB-0651. Cluster 2 appears to group the ions corresponding
to depsipeptides metabolites. MIC, Minimal Inhibitory Concentration.
The MN generated from the data of the 66 bacterial endophytes extract is composed of 13,763
nodes in 4485 clusters (Figures S4 and S5). This MN showed clusters containing nodes from the one
active extract of Luteibacter sp. BSNB-0721 (Figure 2A). Comparison of experimental spectral MS2 data
obtained with databases supported the dereplication of a cluster with fatty acids analogues (Figure 2B).
Consequently, the dereplication process could highlight the presence of fatty acid derivatives in
Luteibacter extract. Other clusters contained nodes specific to the extract of the Luteibacter sp. strain
and indicated a valuable chemical diversity in this particular strain.

Int. J. Mol. Sci. 2019, 20, 2006
4 of 13
Figure 2. (A) Molecular network of the 66 extracts from bacterial endophytes. Relative quantification
values of each ion within the extracts are represented as a XIC area-dependent pie chart. (B) Clusters of
ions from the active extracts of Luteibacter sp. BSNB-0721.
2.3. Isolated Compounds from Luteibacter sp. BSNB-0721
The ethyl acetate extract of Luteibacter sp. BSNB-0721 was subjected to bioguided fractionation
and eight pure compounds were isolated from the three active fractions (See Table S2). All isolated
compounds have been determined by spectroscopic data (Figures S6–S29). These compounds were
identified as fatty acids with an aliphatic chain of between 15 and 17 carbons that may be terminated with
an isopropyl group. Five bear a hydroxyl group on position 2: (R)-2-hydroxy-13-methyltetradecanoic
acid (1) or on position 3 (R)-3-hydroxy-14-methylpentadecanoic acid (2), (S)-β-hydroxypalmitic acid
(3), (R)-3-hydroxy-15-methylhexadecanoic acid (4) and (R)-3-hydroxy-13-methyltetradecanoic acid
(5). We also isolated and identified 13-methyltetradecanoic acid (6) that does not exhibit a hydroxyl
group. The configurations of the compounds were determined by measuring the optical rotation and
comparing with the corresponding literature values.
Compounds (7) and (8) presented an unsaturated chain. Based on the coupling constant of
the multiplet (δH 5.35), the Z configuration was determined. The localization of the unsaturation
was determined by MS2 analysis using the method described by Vrkoslav and Cvacka [13]. After
esterification, the two molecules were subjected to atmospheric pressure chemical ionization (APCI)
leading to the formation of [M+C3H5N]+ adducts. Careful analysis of the MS2 data allowed the
determination of the double bonds’ position (Figures S30 and S31). These two compounds were finally
identified as (9Z)-hexadecenoic acid (7) and 15-Methyl-(9Z)-hexadecenoic acid (8).
These fatty acids were tested for their antimicrobial activities against MRSA. They showed MIC
values ranging from 128 to 32 µg/mL. The most active compound (7) is a C17 fatty acid with a Z double
bond at C-9. Fatty acids with hydroxyl at C-3 (2 – 5) or gem-dimethyl at the final position (8) appear to
have lower antibacterial activities (Table 1).

Int. J. Mol. Sci. 2019, 20, 2006
5 of 13
Table 1. Minimal Inhibitory Concentration (MIC) of compounds 1–8 against methicillin-resistant S.
aureus.
Fatty Acid
MIC on MRSA 1 (µg/mL)
1
2
64
128
3
4
5
6
128
128
ND
128
7
8
32
64
1 Positive Control: Vancomycin (MIC = 1
aureus.
µg/mL). ND = Not Determined. MRSA = methicillin-resistant Staphylococcus
3. Discussion
Our study, related to the secondary metabolites of the plant host model Astrocaryum sciophilum’s
associated microorganisms, demonstrated that isolated endophytic strains could produce antibacterial
compounds. Indeed, six out of 197 endophytic extracts displayed significant antimicrobial activity.
The four antibacterial extracts derived from fungi (three Fusarium strains and one Akanthomyces
strain) also exhibited cytotoxic activity against MRC-5 cells. Thus, there is a high probability that the
antibacterial activity of these extracts depends on the presence of cytotoxic secondary metabolites.
Using a molecular networking-based approach, several structurally related analogues of depsipeptide
and cyclic peptide - molecules known to be cytotoxic - were highlighted from four active fungal extracts.
Depsipeptides have been frequently isolated from fungi belonging to the Fusarium genus [14]. More
precisely, three cyclic pentapeptides and a cyclic lipopeptide Fusaristatin A were isolated from a strain
of Fusarium decemcellular [15]. The isolation of a strain from the Akanthomyces genus is quite surprising
because it is known as a spider parasitic genus. Previous chemical studies of species from this genus
have led to the isolation of glycosylated derivatives [16] and pyrone derivatives [17]. Nevertheless,
the prediction of numerous peptides in the four active fungal extracts could explain their biological
activities. To the best of our knowledge, the present work represents the first time that this class of
compounds was detected in the Akanthomyces genus.
Of the 66 isolated and extracted bacteria, two shown an antibacterial activity with no cytotoxicity:
one Luteibacter strain (BSNB-0721) and one Bacillus strain (BSNB-0730).
Bacteria from the genus Luteibacter were first isolated from the rhizosphere of Barley [18]. To date,
three species of this genus have been described: L. anthropi, L. yeojuensis [19] and L. rhizovicinus. No
chemical study has ever been performed on this genus, and the analysis of the UHPLC-HRMS/MS data
of its EtOAc extract presumed the presence of specific unknown metabolites and fatty acid derivatives.
Thus, the extract from the Luteibacter sp. (BSNB-0721) was selected for further investigation in order

Int. J. Mol. Sci. 2019, 20, 2006
6 of 13
to identify bioactive compounds against MRSA. Eight fatty acid derivatives were isolated in the
present study as the major compounds of the EtOAc extract. They appeared to be responsible for the
antibacterial activity observed in the crude extract. Nevertheless, ions from the MN cluster unique
to the Luteibacter extract were not recovered with a fractionation by reverse-phase chromatography
because they may be produced in minute amounts and should be further investigated.
The antifungal and bactericidal properties of fatty acids (FA) have been widely studied. Their
mechanisms of action are not completely understood; however, it is accepted that FA disrupt
cell membranes [20,21]. Many studies have analysed the relationships between FA structure and
antibacterial activity, and some general trends have been elucidated. Saturated fatty acids composed of
12 carbons in the chain appear to be the most active, and their activity decreases as the chain becomes
either longer or shorter [20,22]. The presence of a Z double bond was found to increase the antibacterial
activity of a fatty acid, whereas a trans configuration leads to an inactive compound [22]. Moreover, a
free carboxyl group allows better antibacterial activity than that of esterified fatty acids [23]. These
molecules may be an alternative to the common antimicrobial agents for applications in agriculture,
food preservation or cosmetics [22,24]. Such literature data may explain, in part, the highest activity
observed in this study for compounds 1, 7 and 8. Indeed, it is observed in our study that there is no
difference in the activity between unbranched and isobranched FA. The presence of a hydroxyl group
at position 3 does not appear to increase the antibacterial activity but may increase the solubility of
these compounds. However, in agreement with the literature data, we noticed that the presence of a Z
double bond enhances antibacterial activity. Luteibacter’s ability to produce such a panel of FA must be
correlated with its ability for defence against aggressors and must improve its survival. The origin of
the FA remains uncertain. In fact, they could be sequestered in the membranes until quick release by
some lipases during bacterial attack. Further investigation to identify their biosynthetic origin should
be performed later.
4. Materials and Methods
4.1. General
Optical rotations were measured using an Anton Paar MCP 200 polarimeter (Anton Paar Graz,
Austria) in a 350
a Bruker 500 MHz spectrometer or a Bruker 600 MHz spectrometer equipped with a 2 mm invers
detection probe (Bruker, Rheinstetten, Germany). Chemical shifts ( ) are reported in ppm relative to
µL cell with a length of 100 mm. NMR spectra were recorded in CD3OD using
δ
the TMS (tetramethylsilane) signal. Coupling constants (J) are in Hertz. High-resolution ESITOFMS
measurements were performed using a Waters Acquity UPLC system (Waters, Manchester, England)
with a column bypass coupled to a Waters Micromass LCT (Low Chromatography Times-of-flight)
Premier time-of-flight mass spectrometer equipped with an electrospray interface (ESI). Flash
chromatography was performed using a Grace Reveleris system equipped with a 120 g C18 column.
The flow rate was 80 mL/min, and detection was performed with dual UV at 210 and 270 nm and
ELSD (Evaporative Light Scattering Detector). Analytical and preparative HPLC experiments were
conducted using a Gilson system equipped with a 322 pumping device, GX-271 fraction collector, 171
diode array detector and prepELSII detector electrospray nebulizer. The columns used for analytical
experiments included a Phenomenex Luna C18
4.6 250 mm. The columns used for preparative experiments included a Phenomenex Luna C18
21.2 250 mm and a Phenomenex Luna C8 5 m 21.2
flow rates were 1 mL/min and 21 mL/min, respectively, for analytical and preparative experiments and
were carried out using a linear gradient of H2O mixed with an increasing proportion of acetonitrile
(CH3CN). Both solvents were modified with 0.1% formic acid. All of the solvents used for analysis
were of HPLC grade.
5
µ
m 4.6
×
250 mm and a Phenomenex Luna C8 5
µ
m
m
×
5
µ
×
µ
×
250 mm (Phenomenex, Le Pecq, France). The

Int. J. Mol. Sci. 2019, 20, 2006
7 of 13
4.2. Endophyte Material
Astrocaryum sciophilum palm trees were sampled in French Guiana in Piste de Saint-Elie, Sinnamary,
in July 2014. The general procedures adopted for the isolation of the microorganisms followed the
methodology described by Casella et al. [25]. After collection, the plant material was washed with
sterile water and its surface was sterilized by immersion in 70% aqueous ethanol (3 min), followed by
immersion in a 5% aqueous sodium hypochlorite (5 min) and finally in 70% aqueous ethanol (1 min).
The leaves were cut into small pieces (1–0.5 cm2) that were placed in a potato dextrose agar medium
(potato dextrose agar (PDA), Fluka Analytical, Steinheim, Germany) in Petri dishes at 28 ◦C (4–5 parts
per Petri dishes). Each individual hyphal tip of emerging fungi was removed and placed in a sterile
PDA culture medium in 10 cm Petri dishes. The leaf fragments were cultured for a maximum of
1 month. All of the isolated endophytic strains were deposited in the “ICSN/CNRS Strain Library
France”. The strains are maintained in triplicate at
solution of glycerol and water (1:1).
−
80 ◦C in a 2 mL cryotube containing 1 mL of a
4.3. Identification of Endophytic Strains
Fungal and bacterial strains were identified using nucleotides sequencing of rDNA ITS (ITS1-5,
8S-ITS2) and rDNA 16S regions, respectively. The obtained sequences were then submitted to BLAST
on NCBI to identify the strain. The sequence data were submitted to GenBank with an accession
number for each strain (Table S1).
4.4. Cultures and Extraction
Each strain was cultivated at 28 ◦C in 10 Petri dishes (10 cm diameter) of the PDA culture media.
Then, the culture was extracted with ethyl acetate (EtOAc) at room temperature for 24 h. The organic
phase was removed via filtration, washed three times with H2O, dried with anhydrous solid Na2SO4
and evaporated using a rotary evaporator under reduced pressure to yield a crude mixture. An extract
of the culture media without microorganisms was also conducted.
4.5. UPLC-HRMS Analysis
Chromatographic separation was performed using an Acquity UHPLC system interfaced to a
Q-Exactive Plus mass spectrometer (Thermo Scientific, Bremen, Germany), using a heated electrospray
ionization (HESI-II) source. Thermo Scientific Xcalibur 2.1 software was used for instrument control
and data analysis. The LC conditions were as follows: column, Waters BEH (Ethylene Bridget Hybrid)
C18 50
formic acid; flow rate, 600
×
2.1 mm, 1.7
µ
m; mobile phase, (A) water with 0.1% formic acid; (B) acetonitrile with 0.1%
µ
L/min; injection volume, 1 L; gradient, linear gradient of 5 100% B over
µ
−
7 min and isocratic at 100% B for 1 min. An Acquity UPLC photodiode array detector was used to
acquire the PDA spectra which were collected in the 200–500 nm range. In the positive ion mode,
the di-isooctyl phthalate C24H38O4 [M + H]+ ion (m/z 391.28429) was used as the internal lock mass.
The optimized HESI-II parameters were as follows: source voltage, 3.5 kV (pos); sheath gas flow
rate (N2), 55 units; auxiliary gas flow rate, 15 units; spare gas flow rate, 3.0; capillary temperature,
275.00 ◦C (pos), S-Lens RF Level, 45. The mass analyser was calibrated using a mixture of caffeine,
methionine
−
arginine
−
phenylalanine
−
alanine acetate (MRFA), sodium dodecyl sulphate, sodium
−
taurocholate, and Ultramark 1621 in an acetonitrile/ methanol/water solution containing 1% formic
acid by direct injection. The data-dependent MS/MS events were performed on the four most intense
ions detected in full scan MS (Top3 experiment). The MS/MS isolation window width was 1 Da, and
the normalized collision energy (NCE) was set to 35 units. In the data-dependent MS/MS experiments,
full scans were acquired at a resolution of 35,000 FWHM (at m/z 200) and MS/MS scans were acquired
at 17,500 FWHM both with a maximum injection time of 50 ms. After being acquired in a MS/MS scan,
the parent ions were placed on the dynamic exclusion list for 2.0 s.

Int. J. Mol. Sci. 2019, 20, 2006
8 of 13
4.6. MZmine 2.33 Data-Preprocessing Parameters
Raw files were converted into MzXML (mass spectrometry data format) files using the MSConvert
software. Then, MzXML files were processed using Mzmine 2.37 [10]. Mass detection was carried out
with a centroid mass detector with the noise level set to 5.0E5 for the MS level set to all. The ADAP
(Automated Data Analysis Pipeline) chromatogram builder [26] was achieved using a minimum group
size of scans of 5, a minimum group intensity threshold of 5.0E5, a minimum highest intensity of 5.0E5
and a m/z tolerance of 0.002 or 5 ppm. The wavelets (ADAP) algorithm was used for the chromatogram
deconvolution with the following settings: S/N threshold of 10, an intensity window SN, a minimum
feature height of 1000, a coefficient area threshold of 100, a peak duration range between 0.01 and 0.5
and an RT wavelet range between 0.001 and 0.05. The m/z and RT range for MS2 scan pairing were set to
0.001 Da and 0.3 min, respectively. Chromatograms were deisotoped using the isotopic peaks grouper
algorithm with an m/z tolerance of 0.003 (5 ppm), RT tolerance of 0.1 (absolute), maximum charge of 2
and the representative isotope used was the most intense. Peak alignment was performed using the
join aligner method: m/z tolerance of 0.001 or 5.0 ppm, weight for m/z of 0.001, RT tolerance of 0.3 min,
weight for RT of 0.1. Adduct search (Na+, K+, NH4+, ACN+) was conducted on the peak list with an
RT tolerance set to 1.0 min and the maximum relative peak height at 50%. The found adducts were
then removed from the peak list. The peak list was gap-filled with the peak finder module: intensity
tolerance of 90%, m/z tolerance of 0.001 or 5.0 ppm and RT tolerance of 0.1 min. For further analysis,
the peak list was reduced to the ions with the m/z values between 200 and 900, in order to decrease the
number of data.
4.7. Molecular Network Analysis
After preprocessing the UHPLC-HRMS/MS data with MZmine 2.33, the output mgf file was
processed with the MetGem software [11] to give a network containing nodes distributed in clusters.
To decrease the size of the peak list, ions with the m/z values of 200-900 and/or selfloop nodes can
be removed. Networks were generated using the following parameters: m/z tolerance set to 0.02,
Minimum Matched Peaks set to 6, topK set to 10, Minimal Cosine score Value of 0.7 and Max. Connected
Component Size of 100. Then, the associated CSV file was loaded. For the mapping process, the
relative quantification of each ion was represented by pie chart-diagrams for which the proportions
were based on the respective areas of the corresponding extracted ion chromatograph areas (XIC).
Then, the analogues of the spectra in the network were searched in the available spectral libraries.
The library spectra were filtered in the same manner as the input data. All of the matches between
network spectra and library spectra were required to have a score above 0.7 and at least 6 matched
peaks. The m/z tolerance for the analogues’ search was set to 100. For a more advanced retreatment of
the network, the MN was also exported to the Cytoscape 3.7.0 software (https://cytoscape.org/).
4.8. Large-Scale Cultivation of Luteibacter sp. and Isolation
Strains were cultivated 15 days at 28 ◦C in 14 cm Petri dishes of PDA (potato dextrose agar) media.
Culture media was extracted three times consecutively with ethyl acetate (EtOAc) at room temperature
(the organic phase after 24 h and replacing the remaining agar in EtOAc). The combined organic
solution was washed as described above.
Large-scale cultivation of Luteibacter sp. was conducted on 210 14 cm Petri dishes to yield
1.96 g of a brown-yellow crude extract. This crude extract (1.8 g) was fractionated by reverse flash
chromatography on a C18 column with a 5-min-step gradient of water mixed with an increasing
proportion of acetonitrile (v/v, 95:5, 75:25, 50:50, 20:80 and 0:100). Six fractions were generated based
on the UV and ELSD detection: F1 (22.2 mg, 1.2%), F2 (165.5 mg, 9.2%), F3 (93.6 mg, 5.2%), F4 (41.0 mg,
2.3%), F5 (46.3 mg, 2.6%) and F6 (563.8 mg, 31.3%). A step gradient of acetonitrile—methylene chloride
(v/v, 50:50–0:100) was conducted to generate 2 additional fractions: F7 (334.4 mg, 18.6%), F8 (91.8 mg,
5.1%).

Int. J. Mol. Sci. 2019, 20, 2006
9 of 13
F4 (35.0 mg) was purified by preparative HPLC (Luna C18, mobile phase H2O + 0.1% FA/CH3CN
+ 0.1% FA, isocratic elution 60:40 during 6 min then linear gradient from 60:40 to 0:100 over 13 min,
flow rate 21 mL/min) to obtain (R)-3-hydroxy-13-methyltetradecanoic acid (5) (0.2 mg, tR = 26.5 min).
F5 (41.4 mg) was purified by preparative HPLC (Luna C8, mobile phase H2O + 0.1% FA / CH3CN +
0.1% FA, isocratic elution 40:60 during 6 min then linear gradient from 40:60 to 0:100 over 13 min,
flow rate 21 m/min) to obtain (R)-2-hydroxy-13-methyltetradecanoic acid (1) (3.7 mg, tR = 14.0 min),
(R)-3-hydroxy-14-methylpentadecanoic acid (2) (1.5 mg, tR = 15.3 min), (S)-β-hydroxypalmitic acid (3)
(1.9 mg, tR = 15.6 min) and 9Z-hexadecenoic acid (7) (0.4 mg, tR = 21.5 min). F6 (258.0 mg) was purified
by preparative HPLC (Luna C8, mobile phase H2O + 0.1% FA / CH3CN + 0.1% FA, isocratic elution
35:65 during 30 min, flow rate 21 mL/min) to obtain (R)-3-hydroxy-15-methylhexadecanoic acid (4)
(7.2 mg, tR= 15.0 min), 9Z-hexadecenoic acid (7) (30.7 mg, tR = 21.0 min), 13-methyltetradecanoic acid
(6) (62.2 mg, tR = 24.0 min) and 15-methyl-9Z-hexadecenoic acid (8) (63.8 mg, tR = 27.0 min).
20
(R)-2-hydroxy-13-methyltetradecanoic acid (1): White powder. [
α
]
= 5.6 (c = 0.5, chloroform).
−
D
1H-NMR (500 MHz, CD3OD): 4.07 (1H, dd, J = 7.4, 4.4, H-2), 1.75 (1H, m, H-3), 1.63 (1H, m, H-3), 1.52
(1H, non, J = 6.7, H-3), 1.44 (2H, m, H-4), 1.30 (14H, s, H-5 to H-11), 1.17 (2H, m, H-11), 0.88 (6H, d, J = 6.8,
H-14, H-15). 13C-NMR (500 MHz, CD3OD): 178.6 (C-1), 71.9 (C-2), 40.4 (C-12), 35.7 (C-3), 31.2–30.8 (5C,
C-6 to C-10), 30.7 (C-5), 29.3 (C-13), 28.7 (C-11), 26.3 (C-4), 23.2 (2C, C-14, C-15). HR-ESI-MS: 257.2109
([M − H]−, C15H29O3−; calc. 257.2122), 515.4294 ([2M − H]−, C30H59O6−: calc. 515.4317).
20
(R)-3-hydroxy-14-methylpentadecanoic acid (2): White powder. [
α
]
= −5.6 (c = 0.5, chloroform).
D
1H-NMR (600 MHz, CD3OD): 3.96 (1H, m, H-3), 2.42 (1H, dd, J = 15.1, 4.7, H-2), 2.34 (1H, dd, J = 15.1,
8.2, H-2), 1.52 (1H, non, J = 6.7, H-14), 1.47 (4H, m, H-4, H-5), 1.30 (14H, s, H-5 to H-12), 1.18 (2H, m,
H-13), 0.88 (6H, d, J = 6.8, H-15, H-16). 13C-NMR (600 MHz, CD3OD): 176.7 (C-1), 69.6 (C-3), 43.7 (C-2),
40.4 (C-13), 38.2 (C-4), 31.2-30.9 (6C, C-6 to C-11), 29.3 (C-14), 28.7 (C-12), 26.8 (C-5), 23.2 (2C, C-1−5,
C-16). HR-ESI-MS: 271.2274 ([M
calc. 543.4630).
−
H]−, C16H31O3−; calc. 271.2279), 543.4611 ([2M
−
H]−, C32H63O6
;
1
(S)-β-hydroxypalmitic acid (3): White powder. [α]
20 = +18 (c = 0.1, chloroform). H-NMR (600 MHz,
D
CD3OD): 3.97 (1H, m, H-3), 2.43 (1H, dd, J = 15.1, 4.7, H-2), 2.36 (1H, dd, J = 15.1, 8.2, H-2), 1.47 (4H, m,
H-4, H-5), 1.30 (20H, s, H-6 to H-15), 0.90 (3H, t, J = 7.2, H-16). 13C-NMR (600 MHz, CD3OD): 176.1
(C-1), 69.5 (C-3), 43.5 (C-2), 38.3 (C-4), 33.2 (C-14), 30.9-30.6 (8C, C-6 to C-13), 26.8 (C-5), 23.9 (C-15), 14.6
H]-, C16H31O3 ; calc. 271.2279), 543.4611 ([2M
−
H]−, C32H63O6
-
−
;
(C-16). HR-ESI-MS: 271.2274 ([M
calc. 543.4630).
−
20
(R)-3-hydroxy-15-methylhexadecanoic acid (4): White powder. [
α
]
= 20 (c = 0.1, chloroform).
−
D
1H-NMR (500 MHz, CD3OD): 3.96 (1H, m, H-3), 2.43 (1H, dd, J = 15.1, 4.7, H-2), 2.35 (1H, dd, J = 15.2,
8.2, H-2), 1.53 (1H, non, J = 6.7, H-15), 1.47 (2H, m, H-4), 1.30 (18H, s, H-5 to H-12), 1.18 (2H, m, H-14),
0.88 (6H, d, J = 6.6, H-16, H-17). 13C-NMR (500 MHz, CD3OD): 176.5 (C-1), 69.7 (C-3), 43.7 (C-2), 40.4
(C-14), 38.3 (C-4), 31.2-30.9 (7C, C-6 to C-12), 29.3 (C-15), 28.7 (C-12), 26.8 (C-5), 23.2 (2C, C-15, C-16).
HR-ESI-MS: 285.2431 ([M
571.4943).
−
H]−, C17H33O3−; calc. 285.2435), 571.4926 ([2M
−
H]
, C34H67O6−; calc.
−
20
(R)-3-hydroxy-15-methylhexadecanoic acid (4): White powder. [
α
]
= 20 (c = 0.1, chloroform).
−
D
1H-NMR (500 MHz, CD3OD): 3.96 (1H, m, H-3), 2.43 (1H, dd, J = 15.1, 4.7, H-2), 2.35 (1H, dd, J = 15.2,
8.2, H-2), 1.53 (1H, non, J = 6.7, H-15), 1.47 (2H, m, H-4), 1.30 (18H, s, H-5 to H-12), 1.18 (2H, m, H-14),
0.88 (6H, d, J = 6.6, H-16, H-17). 13C-NMR (500 MHz, CD3OD): 176.5 (C-1), 69.7 (C-3), 43.7 (C-2), 40.4
(C-14), 38.3 (C-4), 31.2-30.9 (7C, C-6 to C-12), 29.3 (C-15), 28.7 (C-12), 26.8 (C-5), 23.2 (2C, C-15, C-16).
HR-ESI-MS: 285.2431 ([M
571.4943).
−
H]−, C17H33O3−; calc. 285.2435), 571.4926 ([2M
−
H]
, C34H67O6−; calc.
−
20
(R)-3-hydroxy-13-methyltetradecanoic acid (5): White powder. [
α
]
= 15 (c = 0.1, chloroform).
−
D
1H-NMR (600 MHz, CD3OD): 3.89 (1H, s, H-3), 2.33 (1H, m, H-2), 2.24 (1H, m, H-2), 1.52 (1H, m, H-13),
1.45 (4H, s, H-4, H-5), 1.30 (12H, s), 1.18 (2H, s, H-12), 0.88 (6H, d, J = 6.6, H-14, H-15). 13C-NMR (600

Int. J. Mol. Sci. 2019, 20, 2006
10 of 13
MHz, CD3OD): 176.5 (C-1), 70.4 (C-3), 45.3 (C-2), 40.4 (C-12), 38.2 (C-4), 31.2-30.9 (5C, C-6 to C-10), 29.3
(C-13), 28.7 (C-11), 26.8 (C-5), 23.1 (2C, C-14, C-15). HR-ESI-MS: 257.2101 ([M
−
H]−, C15H29O3−; calc.
257.2122), 515.4285 ([2M − H]−, C30H59O6−; calc. 515.4317).
13-methyltetradecanoic acid (6): White powder. 1H-NMR (500 MHz, CD3OD): 2.27 (1H, t, J = 7.4,
H-2), 1.60 (1H, m, H-3), 1.52 (1H, non, J = 6.6, H-13), 1.30 (16H, s, H-4 to H-11), 1.18 (1H, m, H-12), 0.88
(6H, d, J = 6.7, H-14, H-15). 13C-NMR (500 MHz, CD3OD): 177.9 (C-1), 40.4 (C-11), 35.2 (C-2), 31.2-30.4
and 28.7 (8C, C-4 to C-10), 29.3 (C-13), 26.3 (C-3), 23.2 (2C, C-14, C-15). HR-ESI-MS: 241.2168 ([M
−
H]−,
C15H29O2−; calc. 241.2173), 483.4432 ([2M − H]−, C30H59O4−; calc. 483.4419).
1
9Z-hexadecenoic acid (7): yellow oily liquid. H-NMR (500 MHz, CD3OD): 5.35 (2H, dt, J = 11.3, 6.2,
H-9, H-10), 2.27 (2H, t, J = 7.5, C-2), 2.03 (4H, m, H-8, H-11), 1.60 (2H, m, H-3), 1.33 (16H, s), 0.90 (3H, t,
J = 6.9, H-16). 13C-NMR (500 MHz, CD3OD): 178.0 (C-1), 131.1 (C-10), 130.9 (C-11), 35.3 (C-2), 33.1
(C-14), 31.0 (s, C-13), 31.0-30.2 (5C, C-4 to C-8), 28.3 (2C, C-9, C-12), 26.3 (C-3), 23.9 (C-15), 14.6 (C-16).
HR-ESI-MS: 255.2326 ([M + H]+, C16H31O2+; calc. 255.2319), 253.2164 ([M
253.2162), 507.4426 ([2M − H]−, C32H59O4−; calc. 507.4408).
−
H]−, C16H29O2−; calc.
1
15-methyl-9Z-hexadecenoic acid (8): yellow oily liquid. H-NMR (500 MHz, CD3OD): 5.35 (2H, dt,
J = 11.3, 6.2, H-10, H-11), 2.27 (2H, t, J = 7.4, H-2), 2.04 (4H, m, H-9, H-12), 1.60 (2H, m, H-3), 1.53 (1H,
non, J = 6.7, H-15), 1.33 (12H, s), 1.19 (2H, m, H-14), 0.88 (6H, d, J = 6.6, H-16, H-17). 13C-NMR (500
MHz, CD3OD): 177.9 (C-1), 131.0 (2C, C-10, C-11), 40.3 (C-14), 35.2 (C-2), 31.3-30.3 (5C, C-4 to C-8),
29.3 (C-15), 28.3 (2C, C-9, C-11), 28.3 (C-13), 26.3 (C-3), 23.2 (2C, C-16, C-17). HR-ESI-MS: 269.2484
([M + H]+, C17H33O2+; calc. 269.2475), 267.2334 ([M
([2M − H]−, C16H31O2−; calc. 535.4721).
−
H]−, C17H31O2−; calc. 267.2330), 535.4756
4.9. Preparation of Fatty Acid Methyl Esters (FAMEs)
Preparation of FAMEs was carried out based on methanolysis/methylation using conc.
Hydrochloric acid (HCl) as described by Ichihara and Fukubayashi [27]. A solution of 8.0% (w/v) HCl
was obtained by diluting conc. HCl (37%, w/w; 9.1 mL) in methanol (40.9 mL). Each fatty acid was
dissolved in toluene to reach a concentration of 0.005 g/mL. Then, methanol (7.5-fold) and 8.0% HCl
solution (1.5-fold) were added sequentially to this solution. The solution was stirred at 45◦C overnight.
After cooling at room temperature, hexane (5-fold) and water (5-fold) were added for the extraction of
FAMEs. HCl (37%, w/w) was purchased from Carlo Erba©.
FAMEs were then diluted in CH2Cl2 to a concentration of 2 mg/mL and then were diluted in
CH3CN to the concentration 200
mass spectrometer (Agilent, Les Ulis, France) by direct introduction at a flow rate of 10
using an APCI (Atmospheric Pressure Chemical Ionization) ion source in the positive mode. The corona
current was set to 2
A, the nebulizer pressure was 60 psig and 8 L/min nitrogen flow heated at 300 ◦C
µg/mL. These solutions were analysed by MS/MS on a Q-ToF 6540
µL/min and
µ
was used for desolvation. Capillary, fragmentor and skimmer voltages were set to 3000 V, 100 V, and
45 V, respectively. CH2Cl2 and CH3CN were purchased from J.T. Baker©. The MS/MS collision energy
was 15 (arbitrary units).
4.10. Determination of Minimal Inhibitory Concentration
The ATCC strains were purchased from the Pasteur Institute. The strain used in this study
was methicillin-resistant S. aureus ATCC33591. Extracts, fractions and pure compounds were tested
according to the reference protocol of the European Committee on Antimicrobial Susceptibility
Testing [28]. The standard microdilution test as described by the Clinical and Laboratory Standards
Institute guidelines (M7-A8) was used to determine minimal inhibition concentrations (MIC) against
bacteria [29]. Crude extracts and pure compounds were tested at concentrations ranging from 256
to 0.5 µ
g/mL. The microplates were incubated at 35 ◦C, and MIC values were calculated after 24 h.

Int. J. Mol. Sci. 2019, 20, 2006
11 of 13
The MIC values reported in Table S2 refer to the lowest concentration preventing visible growth in the
wells. All assays were conducted in triplicate.
4.11. Cytotoxicity Evaluation
The crude extract for each strain was tested to determine its cytotoxicity using the MRC-5 (ATCC
CCL-171) normal human lung fibroblast cells (LGC standards, Molsheim, France). MRC-5 cells were
seeded into 96-well microplates at 2000 cells per well. The assay was conducted according to the
procedure described by Temp
ête et al. [30]. After 24 h in wells, solubilized extracts in DMSO are
deposited in triplicate as well as the solvent and docetaxel (Taxot
ère) controls. Cell viability is evaluated
in comparison with untreated control cultures after 3 days. Extracts are tested at the concentration of
10 µg/mL.
Supplementary Materials: Supplementary materials can be found at http://www.mdpi.com/1422-0067/20/8/2006/
s1.
Author Contributions: M.B. performed the experiments, analysed the data and wrote the article. N.E., L.P.
contributed to analysis tools and analysed the data. J.-L.W., D.S., D.T. and V.E. designed the study. All authors
read and approved the manuscript.
Funding: This work has benefited from a joint Agence Nationale de la Recherche - Swiss National Science
Foundation (ANR-SNF) grant (SECIL, ref ANR-15-CE21-0016 and SNF N◦ 310030E-164289) and from an
“Investissement d’Avenir” grant (CEBA, ref ANR-10-LABX-0025) managed by the ANR.
Conflicts of Interest: The authors declare no conflict of interest.
Abbreviations
MRSA
Methicillin-resistant Staphylococcus aureus
UHPLC-HRMS/MS
Ultra-High Performance Liquid Chromatography-High Resolution Mass Spectrometry
MIC
EtOAc
MN
Minimal Inhibitory Concentration
Ethyl acetate
Molecular Network
Extracted Ion Chromatogram
Potato Dextrose Agar
Fatty Acid Methyl Ester
Formic Acid
XIC
PDA
FAME
FA
HCl
Hydrochloric acid
References
1.
Arnold, A.E.; Mejía, L.C.; Kyllo, D.; Rojas, E.I.; Maynard, Z.; Robbins, N.; Herre, E.A. Fungal endophytes
limit pathogen damage in a tropical tree. Proc. Natl. Acad. Sci. USA 2003, 100, 15649–15654. [CrossRef]
[PubMed]
2.
3.
Rosa, L.H.; Vaz, A.B.M.; Caligiorne, R.B.; Campolina, S.; Rosa, C.A. Endophytic fungi associated with the
Antarctic grass Deschampsia antarctica Desv. (Poaceae). Polar. Biol. 2009, 32, 161–167. [CrossRef]
Ali, A.H.; Abdelrahman, M.; Radwan, U.; El-Zayat, S.; El-Sayed, M.A. Effect of Thermomyces fungal endophyte
isolated from extreme hot desert-adapted plant on heat stress tolerance of cucumber. Appl. Soil Ecol. 2018
124, 155–162. [CrossRef]
,
4.
5.
Arnold, A.E.; Lutzoni, F. Diversity and host range of foliar fungal endophytes: Are tropical leaves biodiversity
hotspots? Ecology 2007, 88, 541–549. [CrossRef]
Higgins, K.L.; Arnold, A.E.; Coley, P.D.; Kursar, T.A. Communities of fungal endophytes in tropical forest
grasses: Highly diverse host- and habitat generalists characterized by strong spatial structure. Fungal Ecol.
2014, 8, 1–11. [CrossRef]
6.
Rosa, L.H.; Vieira, M.L.A.; Cota, B.B.; Johann, S.; Alves, T.M.A.; Zani, C.L.L.; Rosa, C.A. Endophytic Fungi
of Tropical Forests: A Promising Source of Bioactive Prototype Molecules for the Treatment of Neglected
Diseases. In Drug Development—A Case Study Based Insight into Modern Strategies; Rundfeldt, C., Ed.; In-Tech:
Rijeka, Croatia, 2011; pp. 469–486.

Int. J. Mol. Sci. 2019, 20, 2006
12 of 13
7.
8.
Kahn, F. El género Astrocaryum (Arecaceae). Rev. Peru. Biol. 2014, 15, 31–48. [CrossRef]
Charles-dominique, P.; Chave, J.; Dubois, M.A.; De Granville, J.J.; Riera, B.; Vezzoli, C. Colonization front of
the understorey palm Astrocaryum sciophilum in a pristine rain forest of French Guiana. Glob. Ecol. Biogeogr.
2003, 12, 237–248. [CrossRef]
9.
Wang, M.; Carver, J.J.; Phelan, V.V.; Sanchez, L.M.; Garg, N.; Peng, Y.; Nguyen, D.D.; Watrous, J.; Kapono, C.A.;
Luzzatto-Knaan, T.; et al. Sharing and community curation of mass spectrometry data with Global Natural
Products Social Molecular Networking. Nat. Biotechnol. 2016, 34, 828–837. [CrossRef]
10. MZmine 2: Modular Framework for Processing, Visualizing, and Analyzing Mass Spectrometry-Based
Molecular Profile Data. Available online: https://bmcbioinformatics.biomedcentral.com/articles/10.1186/
1471-2105-11-395 (accessed on 30 August 2018).
11. Olivon, F.; Elie, N.; Grelier, G.; Roussi, F.; Litaudon, M.; Touboul, D. MetGem Software for the Generation of
Molecular Networks Based on the t-SNE Algorithm. Anal. Chem. 2018, 90, 13900–13908. [CrossRef]
12. Olivon, F.; Grelier, G.; Roussi, F.; Litaudon, M.; Touboul, D. MZmine 2 Data-Preprocessing To Enhance
Molecular Networking Reliability. Anal. Chem. 2017, 89, 7836–7840. [CrossRef]
13. Vrkoslav, V.; Cvacˇka, J. Identification of the double-bond position in fatty acid methyl esters by liquid
chromatography/atmospheric pressure chemical ionisation mass spectrometry. J. Chromatogr. A 2012, 1259,
244–250. [CrossRef]
14. Wang, X.; Gong, X.; Li, P.; Lai, D.; Zhou, L. Structural Diversity and Biological Activities of Cyclic
Depsipeptides from Fungi. Molecules 2018, 23, 169. [CrossRef]
15. Li, G.; Kusari, S.; Golz, C.; Strohmann, C.; Spiteller, M. Three cyclic pentapeptides and a cyclic lipopeptide
produced by endophytic Fusarium decemcellulare LG53. RSC Adv. 2016, 6, 54092–54098. [CrossRef]
16. Helaly, S.E.; Kuephadungphan, W.; Phongpaichit, S.; Luangsa-Ard, J.J.; Rukachaisirikul, V.; Stadler, M.
Five Unprecedented Secondary Metabolites from the Spider Parasitic Fungus Akanthomyces novoguineensis.
Molecules 2017, 22, 991. [CrossRef]
17. Kuephadungphan, W.; Helaly, S.E.; Daengrot, C.; Phongpaichit, S.; Luangsa-ard, J.J.; Rukachaisirikul, V.;
Stadler, M. Akanthopyrones A–D, α-Pyrones Bearing a 4-O-Methyl-β-D-glucopyranose Moiety from the
Spider-Associated Ascomycete Akanthomyces novoguineensis. Molecules 2017, 22, 1202. [CrossRef]
18. Johansen, J.E.; Binnerup, S.J.; Kroer, N.; Mølbak, L. Luteibacter rhizovicinus gen. nov., sp. nov., a
yellow-pigmented gammaproteobacterium isolated from the rhizosphere of barley (Hordeum vulgare L.).
Int. J. Syst. Evol. Microbiol. 2005, 55, 2285–2291. [CrossRef]
19. Kämpfer, P.; Lodders, N.; Falsen, E. Luteibacter anthropi sp. nov., isolated from human blood, and
reclassification of Dyella yeojuensis Kim et al. 2006 as Luteibacter yeojuensis comb. nov. Int. J. Syst.
Evol. Microbiol. 2009, 59, 2884–2887. [CrossRef] [PubMed]
20. Bergsson, G.; Arnfinnsson, J.; Steingrímsson, O.; Thormar, H. Killing of Gram-positive cocci by fatty acids
and monoglycerides. Acta Pathol. Microbiol. Immunol. Scand. 2001, 109, 670–678. [CrossRef]
21. Parsons, J.B.; Yao, J.; Frank, M.W.; Jackson, P.; Rock, C.O. Membrane Disruption by Antimicrobial Fatty
Acids Releases Low-Molecular-Weight Proteins from Staphylococcus aureus. J. Bacteriol. 2012, 194, 5294–5304.
[CrossRef] [PubMed]
22. Kabara, J.J.; Swieczkowski, D.M.; Conley, A.J.; Truant, J.P. Fatty Acids and Derivatives as Antimicrobial
Agents. Antimicrob. Agents Chemother. 1972, 2, 23–28. [CrossRef] [PubMed]
23. Kodicek, E.; Worden, A.N. The effect of unsaturated fatty acids on Lactobacillus helveticus and other
Gram-positive micro-organisms. Biochem. J. 1945, 39, 78–85. [CrossRef]
24. Desbois, A.P.; Smith, V. Antibacterial free fatty acids: Activities, mechanisms of action and biotechnological
potential. Appl. Microbiol. Biotechnol. 2009, 85, 1629–1642. [CrossRef]
25. Casella, T.M.; Eparvier, V.; Mandavid, H.; Bendelac, A.; Odonne, G.; Dayan, L.; Duplais, C.; Espindola, L.S.;
Stien, D. Antimicrobial and cytotoxic secondary metabolites from tropical leaf endophytes: Isolation of
antibacterial agent pyrrocidine C from Lewia infectoria SNB-GTC2402. Phytochemistry 2013, 96, 370–377.
[CrossRef]
26. Myers, O.D.; Sumner, S.J.; Li, S.; Barnes, S.; Du, X. One Step Forward for Reducing False Positive and False
Negative Compound Identifications from Mass Spectrometry Metabolomics Data: New Algorithms for
Constructing Extracted Ion Chromatograms and Detecting Chromatographic Peaks. Anal. Chem. 2017, 89,
8696–8703. [CrossRef]

Int. J. Mol. Sci. 2019, 20, 2006
13 of 13
27. Ichihara, K.; Fukubayashi, Y. Preparation of fatty acid methyl esters for gas-liquid chromatography. J. Lipid
Res. 2010, 51, 635–640. [CrossRef]
28. Rodriguez, A.M.S.; Theodoro, P.; Eparvier, V.; Basset, C.; Silva, M.R.R.; Beauchêne, J.; Espindola, L.; Stien, D.
Search for Antifungal Compounds from the Wood of Durable Tropical Trees. J. Nat. Prod. 2010, 73, 1706–1707.
[CrossRef]
29. Clinical and Laboratory Standards. Methods for Dilution Antimicrobial Susceptibility Tests for Bacteria That Grow
Aerobically, 8th ed.; Approved Standard M7-A8; Clinical and Laboratory Standards Institute: Wayne, PA,
USA, 2009.
30. Tempête, C.; Werner, G.; Favre, F.; Rojas, A.; Langlois, N. In vitro cytostatic activity of
9-demethoxyporothramycin B. Eur. J. Med. Chem. 1995, 30, 647–650. [CrossRef]
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
