Title: DNA Adduct Detection after Post-Labeling Technique with PCR
Amplification (DNA-ADAPT–qPCR) Identifies the Pre-Ribosomal
RNA Gene as a Direct Target of Platinum–Acridine Anticancer
Agents
Authors: Xiyuan Yao and Ulrich Bierbach
This manuscript has been accepted after peer review and appears as an
Accepted Article online prior to editing, proofing, and formal publication
of the final Version of Record (VoR). This work is currently citable by
using the Digital Object Identifier (DOI) given below. The VoR will be
published online in Early View as soon as possible and may be different
to this Accepted Article as a result of editing. Readers should obtain
the VoR from the journal website shown below when it is published
to ensure accuracy of information. The authors are responsible for the
content of this Accepted Article.
To be cited as: Chem. Eur. J. 10.1002/chem.202102263
Link to VoR: https://doi.org/10.1002/chem.202102263
01/2020

10.1002/chem.202102263
Chemistry - A European Journal
DNA Adduct Detection after Post-Labeling Technique with PCR Amplification (DNA-
ADAPT–qPCR) Identifies the Pre-Ribosomal RNA Gene as a Direct Target of Platinum–
Acridine Anticancer Agents
Xiyuan Yao and Ulrich Bierbach*
Dr. X. Yao, Prof. U. Bierbach
Department of Chemistry
Wake Forest University
Wake Downtown Campus
455 Vine St.
Winston-Salem, NC 27101 (USA)
E-mail: bierbau@wfu.edu
1
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Abstract:
To study the DNA damage caused by a potent platinum–acridine anticancer agent (PA) in cancer
cells, an assay based on biorthogonal post-labeling using a click chemistry-enabled, azide-
modified derivative (APA) was developed. The method involves biotinylation, affinity capture,
and bead-based enrichment of APA-modified genomic DNA. The key steps of the assay were
validated and optimized in model duplexes, including full-length plasmids, restriction fragments,
and a DNA ladder. Native DNA treated with APA and subsequently subjected to post-labeling
with a biotin affinity tag was enzymatically digested and fragments were analyzed by in-line LC-
MS and MS/MS. The monofunctional–intercalative adducts formed by APA in 5´-
pyrimidine/guanine sequences in double-stranded DNA are quantitatively biotinylated by strain-
promoted 1,3-dipolar cycloaddition chemistry. When applied to DNA extracted from A549 lung
cancer cells, the assay in combination with qPCR amplification demonstrates that platinum–
acridines form adducts in the gene sequences encoding pre-ribosomal RNA, a potential
pharmacological target of these agents.
2
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Introduction
Cytochemical and immunocytochemical imaging and affinity pulldown techniques have become
indispensable tools for studying the cellular mechanism of DNA-targeted small molecules,[1]
including platinum-based anticancer agents.[2] Fluorescent post-labeling using bioorthogonal click
chemistry has also been instrumental for probing the subcellular distribution of platinum–acridine
hybrid agents, a novel class of highly potent cytotoxics.[3] The most potent derivatives of this
class, such as PA (Figure 1A), show a unique anticancer spectrum and promising preclinical
potential.[4] The unique monofunctional–intercalative DNA adducts formed by platinum–
acridines induce replication fork arrest, which leads to DNA double-strand breaks,[5] and inhibit
RNA polymerase II (Pol II)-mediated transcription.[6] Data from structure–activity and
mechanistic studies in mammalian cells and chemical genomics screening in yeast are consistent
with the hypothesis that DNA is the pharmacological target of these agents.[7]
Most strikingly, using fluorescent post-labeling of click chemistry-enabled derivatives, we
demonstrated that platinum–acridines accumulate in the nucleoli in cells in interphase at
significantly higher levels than in the surrounding chromatin.[3b] Because the nucleolus is the site
of precursor ribosomal RNA (pre-rRNA) synthesis, which is a critical step in ribosome biogenesis,
the pre-rRNA gene repeats (“rDNA”) transcribed by RNA polymerase I (Pol I) are a promising
target for DNA-directed chemotherapies.[8] Lung cancer cells in interphase treated with platinum–
acridines showed a distinct time-dependent shrinkage of the nucleoli and a concomitant quenching
of pre-rRNA synthesis.[3a] Immunocytochemical staining of the nuclei in treated lung cancer cells
using a phosphorylated histone 2A-directed antibody (anti--H2AX) provided additional
circumstantial evidence that platinum–acridines may damage nucleolar rDNA.[5a] In these
experiments DNA double-strand breaks were detected in the regions surrounding the nucleoli
3
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
(nucleolar caps), which are the sites of rDNA repair.[9] Based on these observations we
hypothesized that the high level of PA in the nucleoli might render rDNA a direct target of these
agents. However, neither of the above techniques provided insight into the ultimate cause of the
observed cellular responses and whether permanent Pt–rDNA adducts may be involved in the
mechanism triggering apoptotic cancer cell death.
In the present study, we employed a terminal azide-functionalized derivative of PA, APA
(Figure 1A), to detect Pt–rDNA adducts in cancer cells using chemical labeling and affinity
capture. We designed an assay based on biotin post-labeling of covalent, azide-containing DNA
adducts of APA, which we termed DNA Adduct Detection after Post-labeling Technique (DNA-
ADAPT) (Figure 1B). The bioorthogonal chemistry of DNA adduct labeling was validated by
bottom-up digestion of APA-modified native DNA in conjunction with MS/MS fragmentation,
and the pull-down was tested and optimized with plasmid DNA and oligodeoxyribonucleotides.
Finally, we applied the technique in combination with quantitative PCR (DNA-ADAPT–qPCR)
to APA-modified DNA isolated from treated cancer cells to demonstrate that the 47S pre-rRNA
gene is indeed targeted by platinum–acridines.
4
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Figure 1. Using an azide-functionalized platinum–acridine derivative (APA) to affinity-capture
and detect Pt-modified genomic DNA. (A) Chemical structures of compound APA and the biotin
affinity tag, DBCO-PEG4-BIOTIN; the nitrate counter ions for PA and APA are not shown. (B)
Workflow of DNA-ADAPT: (a) Extraction of genomic DNA from cancer cells treated with APA,
purification, fragmentation; (b) post-labeling of Pt-containing fragments with DBCO-PEG4-
BIOTIN; (c) affinity capture on streptavidin-coated magnetic beads; (d) release of enriched target
DNA sequences from the beads; (e) analysis of DNA by quantitative PCR (qPCR). For details,
see the text and Experimental Section.
5
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Results and Discussion
Design of DNA-ADAPT
To detect potential rDNA damage by APA, a chemically robust and sensitive technique is required
to capture and enrich Pt−rDNA adducts. APA was derived from compound PA by replacing the
methyl group (R) on the amino nitrogen of amidine with a N-(2-azidoethyl)propionamide group
(Figure 1A; see the SI for synthetic details). This modification has previously been demonstrated
to not interfere with the DNA binding of platinum−acridine agents and their subcellular
localization.[3b, 7a] The level of APA detected in DNA extracted from A549 cells (5 drug molecules
per 10,000 base pairs when treated at 10 M APA for 6 hours) was similar to that determined for
unmodified platinum–acridines.[5b, 10] Likewise, APA and the parent compound produce a similar
cytotoxic response in this cell line (49 ± 8 nM vs. 29 ± 3 nM for PA[4a]), suggesting that APA
mimics PA biologically.
The overall strategy of the assay is outlined in Figure 1B. Cancer cells are treated with
APA under conditions that do not compromise cell viability while producing the desired level of
Pt–DNA adducts. DNA is extracted from the cells and purified to remove protein and RNA,
resulting in a fraction of Pt-modified and unmodified DNA, which is subjected to sonication to
produce qPCR-compatible, 100−500 base-pair fragments of double-stranded DNA (dsDNA).
DBCO-PEG4-BIOTIN (Figure 1A) is then introduced to post-label the Pt-modified DNA
fragments with a biotin affinity tag via strain-promoted click chemistry. Biotin-labeled Pt–DNA
is affinity purified using streptavidin-coated magnetic beads. After removal of unlabeled DNA,
the platinated–biotinylated DNA is dissociated from the beads by incubation with sodium cyanide
under conditions that completely reverse the monofunctional adducts.[11] The enriched, affinity-
6
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
purified DNA is subjected to a clean-up step, ultrasonically sheared, and subsequently analyzed
by quantitative PCR (qPCR) to detect potential target sequences (DNA-ADAPT–qPCR).
Validation of key reactions
To test the chemical feasibility of ADAPT in dsDNA, the two key reactions, (i) monofunctional
adduct formation, which involves platination of guanine (G)-N7 in the major groove of the
duplex,[5b] and (ii) labeling of adducts using copper-free click chemistry, were studied at atomic
resolution in native DNA (Figure 2A). After reaction of calf thymus DNA with APA, samples
were enzymatically digested to afford
a
pool of Pt-modified and unmodified
oligodeoxyribonucleotides and 2´-deoxyribonucleosides (Figure 2A). In a parallel experiment, the
APA-modified DNA was treated with DBCO-PEG4-BIOTIN to biotinylate the adducts prior to
endonucleolytic digestion (Figure 2A). The resulting mixtures were then separated by reverse-
phase HPLC (Figure 2B) and analyzed by electrospray mass spectrometry (ESMS). Target ions
were further subjected to MS/MS fragmentation to confirm the nucleobase specificity and
sequence context of adduct formation.
7
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
A
B
Figure 2. (A) Structural characterization of monofunctional–intercalative G-N7 adducts before
and after post-labeling in native dsDNA. (B) Analysis of enzymatic digests: calf-thymus DNA
was treated with APA and enzymatically digested before (top traces) or after post-labeling with
DBCO-PEG4-BIOTIN (bottom traces) yielding mixtures of Pt-modified and unmodified
deoxyribonucleos(t)ides, which were separated by reverse-phase HPLC. APA-modified
fragments (fractions a, b, and c) and the corresponding biotinylated forms (fractions a´/a´´, b´/b´´,
8
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
and c´/c´´) were identified in HPLC traces at a wavelength specific for the acridine chromophore
(413 nm, green traces) and analyzed by ESMS. Selected ions were analyzed by MS/MS (see the
SI for a detailed structural analysis of major adduct fragments). Red and blue traces are total ion
count (TIC) chromatograms and UV chromatograms recorded at 254 nm, respectively. The
asterisk denotes an unidentified product.
Enzymatic digestion resulted in the four native 2´-deoxyribonucleosides and three
platinated fragments, dG* (Pt-modified 2´-deoxyguanosine), 5´-TpG*-3´, and 5´-GpTpG*-3´
(asterisks indicate the sites of the Pt adducts) (Figure 2B). A similar digestion pattern is observed
after treatment of the dsDNA with the DBCO-PEG4-BIOTIN tag (bottom three traces in Figure
2B) with the corresponding peaks shifted to longer retention times. The 1,3 dipolar cycloaddition
between the terminal azide moiety in APA and DBCO yields the expected pairs of triazene
regioisomers[3a] (labeled ´ and ´´ in Figure 2B). Most importantly, the reaction of APA adducts in
the DNA major groove with the DBCO affinity tag proved to be quantitative, which renders it a
suitable, highly efficient post-labeling step for the proposed assay. Furthermore, the data confirms
that introduction of a linker with a terminal azide group does not alter the well-established
propensity of platinum−acridines to form adducts with G-N7 at 5´-pyrimidine/purine sites.[5b] This
observation provides further support that APA faithfully mimics critical features of the parent PA.
9
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Affinity purification of APA-modified, biotinylated DNA
In addition to the post-labeling chemistry (biotinylation), the suitability of ADAPT for detecting
Pt-modified genomic DNA critically depends on affinity pull-down of the nucleic acid and its
purification using streptavidin magnetic beads. Initially, the feasibility of this step was tested using
linearized plasmid DNA (Figure 3A). The plasmid pBR322 was modified with APA at a platinum-
to-base pair ratio of 0.01 and then mixed with untreated pUC19 plasmid. After treatment with
DBCO-PEG4-BIOTIN, samples were subjected to magnetic bead purification and analyzed by
agarose gel electrophoresis (Figure 3B). The recovery of plasmid was estimated from the
intensities of ethidium-stained bands containing affinity-purified DNA relative to a control that
had not undergone bead purification. Approximately 8% of pBR322 could be recovered under
these conditions whereas no pUC19 plasmid was detectable. This experiment demonstrates that
ADAPT selectively enriches DNA modified with APA from a stoichiometric mixture of the two
plasmids.
To better mimic sheared DNA, which will be used in the downstream qPCR amplification
reactions, and to optimize the reaction conditions, we also performed the assay in restriction
fragments 375 bp to 4361 bp in length generated from pBR322 plasmid. Doubling the amount of
streptavidin-coated beads resulted in a modest increase in recovery of affinity-purified DNA from
10% to 14% (Figure S7). On the other hand, 10-fold DBCO-PEG4-BIOTIN in the mixtures
completely abrogated affinity capture, consistent with excess biotinylation reagent blocking
binding sites, which diminishes the binding capacity of the beads (Figure S9). Inefficient
dissociation of DNA from the beads in the last step of the assay can be ruled out as a yield-limiting
factor, as treatment of the beads with higher sodium cyanide concentrations for extended time
periods did not result in higher DNA recoveries (Figure S8).
10
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
A
Figure 3. Validation and optimization of DNA purification by affinity capture in model duplexes.
(A) Assay design for plasmid DNA: (a) Preparation of linearized forms of two plasmids; (b)
treatment of pBR322 with APA and post-labeling with DBCO-PEG4-BIOTIN (2 steps); (c)
pooling of unmodified pUC19 and APA-modified pBR322 plasmid samples; (d) affinity capture
on beads (red spheres) and (e) removal of nonspecifically bound plasmid; (f) dissociation of
affinity-captured pBR322 and detection/quantification by gel electrophoresis. (B) Agarose gel for
affinity purification of plasmid DNA. The recovered pBR322 (8%) is highlighted with a red box.
(C) Agarose gel for affinity purification of a DNA ladder. The DNA was modified with APA at a
drug-to-base pair ratio of 0.02.
Lane assignments: 1-unpurified DNA, 2-
unplatinated/unbiotinylated control, 3-unplatinated control, 4-ADAPT-purified DNA. The
11
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
estimated cumulative recovery of DNA (lane 4 vs. lane 1) is 11% (Image J software). (An accurate
quantification was not possible because of variabilities in the ethidium staining efficiency for
individual fragments.)
Using the optimized conditions, DNA-ADAPT was finally validated using a 100–2000-bp
DNA ladder (Figure 3C). Visual inspection of the agarose gel confirms that sequences as short as
200 bp could be pulled down. The results show that the overall recovery of DNA duplexes based
on integrated band intensities for all fragments is approximately 11% of the non-affinity purified
control lane. For some sequences, the recoveries exceeded those observed with the (digested)
plasmid DNA, resulting in 15% recovery for the 2000-bp, 20% for the 1500-bp, and 18% for the
600-bp fragment. Relatively weaker bands are observed for the shorter fragments in both treatment
and control lanes, which may be due to inefficient staining of the DNA with ethidium bromide or
indicate a lower abundance in the fragment mixture.
Post-labeling has previously been applied to platinum-based pharmacophores both in intact
cells and cellular extracts.[2a, b, e] The method circumvents several limitations encountered if the
bioactive molecule of interest is modified with an affinity label or a reporter group prior to treating
cultured cells. These include altered uptake, subcellular distribution, and target interactions caused
by the structural modification.[3a, 12] Nonspecific sequestration of biotinylated probes by
endogenous biotin-binding proteins is another potential drawback[13] that can be overcome by
labeling the probe after it has engaged with its cellular target. DNA-ADAPT combines exquisitely
efficient biotinylation at the damage site with quantitative reversal of the Pt-mediated cross-links
for purification of bead-captured APA-modified DNA.
12
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Application of DNA-ADAPT–qPCR to DNA extracted from cancer cells
Finally, we tested our hypothesis that platinum−acridine agents cause permanent “covalent”
damage in nucleolar rDNA because of their high level of accumulation in this subnuclear structure.
We used ADAPT to enrich the Pt-damaged DNA isolated from cultured cancer cells and amplified
the products by quantitative PCR (qPCR). To calculate the enrichment of APA-modified,
biotinylated DNA relative to a sample of APA-modified, unbiotinylated DNA that was PCR-
amplified using the same primers (negative control), we used the percent of input method [14] (see
the Experimental Section). Primer pairs previously validated for rDNA analysis[15] were used to
first pre-screen the 13.3-kb 47S pre-rRNA gene for Pt adducts within the coding (coding) region,
the low-affinity Pol I-binding region (gap), and putative G-quadruplex forming sequences (rg4).[15]
Adduct formation in the noncoding intergeneric spacer (igs) as well as the promoter and
transcription regulating regions (prom and ctcf) was also assessed (Figure 4A).[15] For comparison,
we also included primers for the housekeeping gene GAPDH and the oncogene KRAS (both located
on chromosome 12), and for mitochondrial genomic DNA (mtDNA) (see the Experimental Section
and Table S2 for sequence information).
13
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
A
B
C
Figure 4. Application of ADAPT−qPCR to DNA extracted from APA-treated A549 lung cancer
cells. (A) Map of human rDNA tandem repeats and locations of sequences screened in this
study. (B) Pre-screening for adducts in rDNA, GAPDH, mtDNA, and KRAS sequences. Samples
of drug-modified DNA (‘drug’) not subjected to the post-labeling step (‘unbiotinylated’) were
included as negative control. qPCR results were calculated using percent of input method. (C)
Comparison of target enrichment for two selected primer sets. Data shown are means of three
biological independent experiments each performed with three technical replicates; mean ± s.d.;
**, p < 0.01 and *, p < 0.05; n.s., not significant, p > 0.05; two-way ANOVA with Tukey post-
hoc test. The higher relative enrichments observed for all primers compared to negative controls
in (B) vs (C) are due to the larger number of amplification cycles employed, resulting in higher
calculated drug/input values.
14
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Details of the cell treatments and extraction of genomic DNA are presented in the
Experimental Section. After reversal of the APA–DNA adducts, the purified genomic DNA was
amplified with the appropriate primer pairs. Figure 4B shows the results of a pre-screening
experiment in which three of the six rDNA primers – gap, coding, and ctcf – produced the highest
amplification and enrichment levels. Significant enrichment (p < 0.05) over non-post-labeled
control groups was also observed for the primer set used to monitor APA-induced damage in
mitochondrial DNA (mtDNA), but not for primers used to amplify the GAPDH and KRAS
sequences. Based on these results, gap, which consistently showed the highest enrichment among
all rDNA primers, was screened along with GAPDH in three additional, biologically independent
experiments. The results confirm that gap-amplified DNA was significantly enriched over the
negative control pulldown by approximately 2.6-fold and relative to GAPDH, for which
enrichment proved to be not significant (Figure 4C). This outcome provides evidence that
platinum–acridines induce permanent adducts in rDNA and that the G-rich (73% for 45S sequence;
NCBI reference: NR 046235) pre-rRNA gene is a direct cellular target of platinum–acridines. The
pronounced enrichment observed for mtDNA is surprising since accumulation of platinum–
acridines in the cells’ mitochondria has been firmly ruled out in co-staining/colocalization images
captured by confocal microscopy.[3b, 10] It is possible that APA reacts with mitochondrial DNA
that has been released into the cytoplasm (cytosolic mtDNA), as a consequence of genotoxic stress
and during apoptotic signaling.[16]
Variations in sequence enrichment are not only observed between genes, but also within
the same gene. It is known that factors such as transcriptional status and chromatin state affect the
DNA binding efficiency of drugs and chemical probes.[17] Thus, the higher enrichment of
sequences amplified with the primer sets gap, coding, and ctcf compared to other rDNA primers
15
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
may indicate a higher binding affinity of APA for these regions due to a more accessible
nucleosome structure.[15] A large portion of the rDNA repeats, including actively transcribed and
transcriptionally inactive sequences, exist in a loosely packaged, non-nucleosomal state,[18] and
thus may be highly susceptible to the formation of monofunctional–intercalative adducts.
Alternatively, the trends in enrichment may simply be caused by differences in APA–DNA adduct
frequency in primer-specific amplicons, depending on G content. To evaluate this possibility, we
quantified potential binding sites in the rDNA gap and GAPDH amplicons. A total of 20 putative
high-affinity binding sites (base-pair steps) were identified within the amplified 103-bp rDNA
sequence (19%) and 18 within the 95-bp fragment of GAPDH (19%), suggesting that the
differences in enrichment are not related to nucleobase content and sequence context.
Furthermore, the normalization method by which relative enrichment was calculated should rule
out the possibility that differences in gene copy number (~400 for rDNA vs. 2 for GAPDH) may
be responsible for the differences in PCR amplification yields.
The central role of the nucleolus in ribosome biogenesis, which fuels aggressive cancer
growth,[8] and the fact that DNA double-strand break repair in the nucleolus is inefficient and error
prone[19] may render it an ideal target for platinum–acridines. Consequently, the formation of
cytotoxic PA–rDNA adducts and their downstream effects on ribosome biogenesis might help
overcome drug resistance in DNA repair-proficient cancers.
16
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Conclusion
In summary, we have developed a chemical-biology tool to address an important mechanistic
detail of a promising DNA-targeted agent at the cellular level. This was possible after turning the
parent drug, PA, into an azide-functionalized chemical probe, APA. The method allows chemical
pull-down of platinum-modified genomic DNA sequences extracted from cells by taking
advantage of ex-vivo biotinylation via strain-promoted click chemistry. The qPCR-based
enrichment pattern supports the hypothesis that rDNA is a direct target of platinum–acridines.
ADAPT, in combination with next generation sequencing (“DNA-ADAPT-seq”), may provide an
opportunity to generate a more comprehensive and unbiased map of the genomic targets of these
hybrid agents.
17
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Experimental Section
Materials and methods
The plasmids pUC19 (SD0061) and pBR322 (SD0041), restriction enzymes EcoRI (FD0274), PstI
(FD0614), and BamHI (FD0054), DNase I enzyme (EN0521), and the 100-bp DNA ladder (15628-
019) were purchased from Invitrogen/Thermo Fisher (Waltham, MA). Deoxyribonucleic acid
sodium salt from calf thymus (D1501) was purchased from Sigma Aldrich (St. Louis, MO). DNA
primers sequences (see Table S2) for qPCR amplifications were synthesized and purified by
standard desalting by Eton Bioscience Inc. (Research Triangle Park, NC). Shrimp alkaline
phosphatase (78390) was purchased from Affymetrix (Santa Clara, CA), and nuclease P1 (N7000)
was purchased from USBiological (Salem, MA). DBCO-PEG4-BIOTIN (CAS. #1255942-07-4)
was obtained from Click Chemistry Tools (Scottsdale, AZ). Dynabeads M-280 Streptavidin
(11205D) and Dynabeads MyOne Streptavidin T1 (65601) were obtained from Invitrogen
(Carlsbad, CA). Float-A-Lyzer G2 100–500 Da dialysis devices were from Spectra-Por (Sigma
Aldrich, St. Louis, MO). All other biochemical grade reagents and synthetic precursors were
purchased from common vendors and used as supplied. For additional supplies, see the description
of specific assays.
1H NMR spectra of APA were recorded on a Bruker Ascend 400 MHz NMR instrument
and are summarized in the conventional form including chemical shifts (, ppm), multiplicities (s
= singlet, d = doublet, t = triplet, q = quartet, m = multiplet, br = broad), coupling constants (Hz),
and integral signal intensities. NMR spectra were processed and analyzed with MNova (version
12.0.3, Mestrelab Research, Escondido, CA). In-line LC-ES-MS analysis was performed on a
Bruker AmaZon SL ion trap mass spectrometer equipped with an atmospheric pressure
electrospray ionization (ESI) source and an in-line Shimadzu UFLC detector. Eluent nebulization
18
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
was achieved with a N2 pressure of 44 psi, and solvent evaporation was assisted by a flow of N2
drying gas (250 °C). Mass spectra were recorded in positive-ion mode with a capillary voltage of
4.5 kV over a mass-to-charge scan range of 150–2000 m/z. APA purity was determined in
methanol containing 0.1% formic acid and separation of the diluted samples on a 4.6 mm × 150
mm reverse-phase Agilent ZORBAX SB-C18 (5 μm) analytical column at 25 °C using the
following solvent system: solvent A, Optima water/ 0.1% formic acid, and solvent B, methanol/
0.1% formic acid, at a flow rate of 0.4 mL/min and a gradient of 5% B for 5 min, 5% B–95% B
over 15 min, 95% B for 10 min followed by 95% B−5% B over 5 min. Elution profiles were
recorded at an acridine-specific wavelength at 413 nm. High resolution mass spectra for APA
were obtained on a Thermo Orbitrap LTQ XL instrument equipped with Accela UPLC and
autosampler. The spray voltage was 4 kV, and the temperature of the heated capillary was 300 °C.
The sheath gas flow rate and the auxiliary gas flow rate were 31 and 13 (arbitrary units),
respectively.
Synthesis of [PtCl(pn)(C22H27N8O)](NO3)2 (APA, dinitrate salt) (Scheme S1)
Compounds 1.2–1.9 were synthesized according to previously published procedures.[7a] The
platinum–nitrile complex [PtCl(pn)(MeCN)]Cl (pn = propane-1,3-diamine) (1.9) (136 mg, 0.357
mmol) was converted to its nitrite salt via anion exchange with AgNO3 (58 mg, 0.34 mmol) in 0.5
mL of anhydrous DMF. AgCl was removed by syringe filtration and the filtrate was cooled to -
20 °C. The azide-modified acridine precursor 1.8 (135 mg, 0.357 mmol) was dissolved in 0.5 mL
of anhydrous DMF and added to the filtrate, and the mixture was stirred at 4 °C for 24 hours before
it was allowed to warm to room temperature. After treatment with activated carbon, the reaction
mixture was precipitated in 300 mL of vigorously stirred diethyl ether. The product was collected
19
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
by membrane filtration and dried in a vacuum overnight. The crude mononitrate salt was re-
dissolved in methanol containing one equivalent of aqueous 1 M HNO3, and the resulting dinitrate
salt was recovered by precipitation with anhydrous diethyl ether. The product was further purified
by recrystallization from hot ethanol to give 246 mg of APA as a yellow microcrystalline solid
1
(Yield: 88%). H NMR (400 MHz, DMF-d7) δ 13.89 (s, 1H), 9.88 (s, 1H), 8.70 (d, J = 8.7 Hz,
2H), 8.35 (t, J = 5.6 Hz, 1H), 8.12 – 7.94 (m, 3H), 7.65 (ddd, J = 8.3, 6.5, 1.4 Hz, 2H), 6.51 (s,
1H), 5.42 (s, 2H), 5.02 (s, 2H), 4.51 (s, 2H), 4.12 (t, J = 7.3 Hz, 3H), 3.83 (t, J = 6.7 Hz, 2H), 3.49
(s, 6H), 3.48 – 3.32 (m, 4H), 2.60 (t, J = 6.7 Hz, 2H), 1.82 (d, J = 6.6 Hz, 3H). Analytical purity
(by LC-MS): 100%. HRMS (ESI, positive-ion mode): m/z for C25H36ClN10OPt ([M]+), calculated,
722.24043; found, 722.23944 (1.37 ppm). C25H37ClN10OPt ([M]2+), calculated, 362.12394; found,
362.12355 (1.08 ppm).
General cell culture maintenance
The human cancer cell line A549 (lung adenocarcinoma, doubling time 21 h) was obtained from
the American Type Culture Collection (ATCC) (Manassas, VA, USA) and cultured in DMEM/F12
media (Thermo Fisher, 11330-032) supplemented with 10% FBS (Thermo Fisher, A3160601) and
1% penicillin-streptomycin (Thermo Fisher, 15070-063). Cells were incubated at a constant
temperature at 37 °C in a humidified atmosphere containing 5% CO2 and subcultured every 2–3
days. The maximum passage number for A549 cells was 20, and cells were tested periodically for
mycoplasma infections by fluorescence microscopy after staining with Hoechst 33258 dye.
20
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Cell proliferation assay
Cell proliferation assays were conducted using the CellTiter 96 kit as described previously.[4b]
A549 cells were harvested and seeded in 96-well plates at a density of 5000 cells/well and allowed
to attach overnight in the incubator prior to treatment with serially diluted APA for 72 hours. To
assess cell viability, 20 L of a mixture of MTS/PMS solution was added to each well, and
incubation was continued for 1–2 h. Conversion of MTS to formazan was quantified by
absorbance measurements at 490 nm using a plate reader (Synergy HTX, BioTek, Winooski, VT).
Cell viability was calculated as a percentage of untreated control. Three individual experiments
were performed in triplicate wells. IC50 values were calculated from nonlinear curve fits of the
log[drug] vs. response data in GraphPad Prism (La Jolla, CA) and are reported as the mean ±
standard deviation (SD).
Quantification of APA–DNA adducts by inductively coupled plasma mass spectrometry
(ICP-MS)
700,000 A549 cells in 2.5 mL of complete DMEM/F12 media were seeded into T-25 flasks and
allowed to attach overnight. Cells were then treated with 10 M APA for 6 h. Drug-containing
medium was aspirated, and cells were washed 3 × with fresh media. Trypsin was added to detach
cells, and 3 mL of fresh medium was added to each flask to collect the cell suspensions, which
were pelleted by centrifugation at 250 × g for 5 min. After the supernatant was aspirated, pellets
were washed with 2 × 3 mL of PBS solution and centrifuged again at 250 × g for 3 min. Genomic
DNA was extracted and purified using the AllPrep DNA/RNA Mini Kit (Thermo Fisher, 80204)
following the manufacturer’s protocol. The yield and purity of DNA harvested from each
21
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
experiment was determined using a NanodropTM 2000/2000c Spectrophotometer (average of two
readings with 1 L per run). The extracted DNA had an A260/A280 ratio of ~ 1.8. Pelleted cells
were homogenized by microwave-assisted digestion (ETHOS UP Milestone, Sorisole, Italy) in
trace-metal grade HCl/HNO3. Standard curves were generated with appropriately diluted Pt
standard (High-Purity Standards, Charleston, SC). Samples were analyzed on a 8800 Triple
Quadrupole ICP-MS spectrometer (Agilent, Tokyo, Japan) equipped with a SPS 4 automatic
sampler, a Scott-type double pass spray chamber operated at 2 °C, and a Micromist concentric
nebulizer. Helium gas ( 99.999%, Airgas, Colfax, NC) was used in the collision/reaction cell to
minimize potential spectral interferences while monitoring the isotope 195Pt. The APA-to-DNA
base pair ratio was calculated for triplicate experiments.
Enzymatic digestion and mass spectrometric analysis of platinum-modified DNA
Calf thymus DNA was treated with APA at a drug-to-base pair ratio of 0.05 in 10 mM Tris buffer
at 37 °C for 24 h. A fraction of the sample was removed and treated with 1 equivalent of DBCO-
PEG4-BIOTIN at room temperature for an additional 24 h. Enzymatic digestions were performed
with 100 L of the platinum-modified DNA samples using the following protocol (incubation
times at 37 °C): (i) 10 L 50 mM MnCl2 + 10 u DNase I (2 h); (ii) 6.5 u of DNase I (2 h); (iii) 4 u
nuclease P1 (2 h); (iv) 1 u nuclease P1 (16 h); (v) 10 L of 10  alkaline phosphatase buffer (200
mM Tris-HCl, pH 8.0 and 100 mM MgCl2) + 5 u alkaline phosphatase; (vi) 3 u alkaline
phosphatase. The mixtures were heat denatured at 65 °C for 15 min, centrifuged at 13000 rpm for
5 min, and the supernatants were collected. The digested samples were desalted against water
overnight at 4 °C using Float-A-Lyzer disposable dialysis tubes (100-500 Da cut-off). Samples
22
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
were finally lyophilized and redissolved in 80 L of 0.1% formic acid in HPLC grade water for
LC-MS analysis.
Sample analysis was performed on a Bruker Amazon-SL ion trap mass spectrometer
equipped with an atmospheric pressure electrospray ionization (ESI) source and an in-line
Shimadzu UFLC detector. Eluent nebulization was achieved with a N2 pressure of 44 psi, and
solvent evaporation was assisted by a flow of N2 drying gas (250 °C). Mass spectra were recorded
in positive-ion mode with a capillary voltage of 3 kV over a 150–2000 m/z scan range. Prior to
MS/MS analysis of DNA fragments, precursor ions were identified in HPLC traces after separation
of the diluted samples on a 4.6 mm × 150 mm reverse-phase Agilent ZORBAX SB-C18 (5 μm)
analytical column at 25 °C using the following solvent system: solvent A, optima water/0.1%
formic acid, solvent B, acetonitrile/0.1% formic acid at a flow rate of 0.75 mL/min; 5% B to 27%
B over 22 min, 27% B to 95% B from 22 min to 25 min; maintain at 95% B from 25 min to 32
min, and 95% B to 5% B from 32 min to 40 min. Elution of APA-modified and post-biotinylated
APA-modified DNA fragments was monitored at 413 nm and in total ion count (TIC)
chromatographs. Fragmentation of selected ions in MS/MS experiments was achieved by collision
induced dissociation (CID) for target masses in Smart Parameter Setting (SPS) mode with an
isolation width of 4.0. The Compass Data Analysis software suite (Bruker Daltonics, Billerica,
MA) was used for peak integration.
DNA-ADAPT optimization in cell free systems
pUC19 DNA (2686 bp) and pBR322 DNA (4361 bp) were linearized by treatment with EcoRI
according to manufacturer’s protocol. Then, 10 g of linearized pBR322 were treated with APA
23
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
at a drug-to-base pair ratio of 0.01 for 24 h at 37 °C in FastDigest buffer provided with the enzyme.
After completion of the reaction, 10 g of linearized pUC19 were added, and the sample was
thoroughly mixed and supplemented with 1 equivalent (based on APA) of DBCO-PEG4-BIOTIN.
This mixture was stored at room temperature for 24 h. M-280 dynabeads were added at a ratio of
1 mg of the beads per 10 g of DNA, and samples were gently vertically mixed for 1 h using a
Multi-Mix tube rotator (VWR). Beads were recovered from the mixtures using a Dyna-Mag-Spin
magnet (Invitrogen) and washed 3 times with B&W buffer (5 mM Tris-HCl, 0.5 mM EDTA, 1 M
NaCl, pH 7.5). To retrieve the affinity-captured DNA, the beads were resuspended in 100 L of
3 mM aqueous NaCN solution and vertically mixed at 37 °C for 24 h. The supernatant was
collected, lyophilized, and redissolved in Millipore water for downstream applications. Assays
performed with pBR322 after digestion with EcoRI, BamHI, and PstI, and affinity capture of APA-
modified DNA ladder were performed in the same manner. Samples were analyzed by
electrophoresis on 1−1.5% agarose gels (70 V, room temperature, running time 2.5 h, TAE buffer,
pH 8.3). Gels were pre-stained with ethidium bromide (1 g/mL). Each lane contained
approximately 100 ng of DNA. Gels were photo-documented using an Amersham Imager 600
(GE Healthcare), and band intensities were integrated with Image J (version 1.52a, National
Institutes of Health, Bethesda, MD).
Isolation of APA-modified DNA from A549 lung cancer cells
A549 cells at 90% confluency were harvested from three T-75 culture flasks, which had been
subcultured at least three times. One day prior to treatment with APA, 4 × 106 cells were plated
in each of four 10-cm cell culture dishes in 8 mL of DMEM/F12 media (supplemented with
24
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
penstrep, and FBS) and allowed to attach overnight at 37 °C in a humidified atmosphere of 5%
CO2. On the day of treatment, culture media was replaced with fresh media, and APA (10 mM
stock solution in DMF) was added to afford a final drug concentration of 10 M. Cells were then
returned to the incubator for 6 h. The APA-containing media was removed from each dish, and
the cells were washed twice with 2 mL of warm PBS. Cells were detached with 2 mL of warm
trypsin-EDTA solution and transferred into 15-mL conical tubes after addition of 6 mL of medium
to quench the trypsin. The cells suspensions were centrifuged for 5 min at 250 × g at 4 °C, and
the supernatant was aspirated. Cell pellets can be flash-frozen in liquid nitrogen and stored at -
80 °C for later analysis. Genomic DNA was extracted from the pellets and purified using the
AllPrep DNA/RNA Mini Kit (Thermo Fisher, 80204) following the manufacturer’s protocol. The
yield and purity of DNA harvested from each experiment was determined using a NanodropTM
2000/2000c Spectrophotometer (average of two readings with 1 L per run). The recovered DNA
showed an A260/A280 ratio of ~1.8.
Preparation of post-labeled genomic DNA for qPCR
Genomic DNA samples were sheared at 4 °C for 5 min using a Sonicator Q800R (QSonica,
Newtown, CT) (‘15 sec on–15 sec off’ cycles at 20% amplitude) to the desired fragment range of
100–1000 bp, which was confirmed by electrophoresis on 1.2% agarose gels. The DNA was then
aliquoted at 10 µg in 100 µL of autoclaved water into sample tubes. Prior to post-labeling, 2 µL
of each sample were removed and set aside as input control for qPCR amplification. The APA-
modified genomic DNA samples were then either treated with DBCO-PEG4-BIOTIN to generate
biotinylated DNA or left untreated to serve as unbiotinylated negative controls. The amount of
25
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
DBCO-PEG4-BIOTIN required to label all APA–DNA adducts in each sample was estimated from
the adduct frequency determined by ICP-MS (drug-to-base pair ratio of 0.0005, equivalent to 0.775
pmol of label per µg of DNA). Accordingly, samples were treated with 1.1 equivalent of DBCO-
PEG4-BIOTIN and incubated at room temperature for 16 h.
Prior to affinity purification, Dynabeads MyOne Streptavidin T1 (65601) were pre-washed
for 5 min once with 1000 µL of 1  Binding and Washing (B&W)/Tween buffer and twice with
1000 µL of 1  B&W buffer. T1 beads were then resuspended in 2  B&W buffer equivalent to
twice the original suspended bead volume. [B&W buffer (2 ) contained 10 mM Tris-HCl (pH
7.5) 1 mM EDTA, 2 M NaCl; B&W/Tween buffer (2 ) contained 10 mM Tris-HCl (pH 7.5) 1
mM EDTA, 2 M NaCl, 0.1% Tween 20]. 50 µL of the beads was added to 100 mL of the sheared
DNA, and the mixture was incubated at room temperature for 30 min with continuous agitation by
vertical rotation. The beads were washed three times for 7 min with 500 µL of 1  B&W/Tween
buffer and twice with 500 µL of 1  B&W buffer. To reverse the Pt-DNA adducts and release the
affinity-purified DNA from the beads, 100 L of 3 mM sodium cyanide solution was added to the
mixture and incubation was continued for another 16 h at 37 °C. The same procedure was
performed for each biotinylated and unbiotinylated sample. All DNA samples were finally
purified using a Qiaquick PCR Purification Kit (28104) (Qiagen, Germantown, MD) prior to qPCR
analysis.
Quantitative PCR
Quantitative PCR (qPCR) was performed on a QuantStudio 3 Real-Time PCR System
(ThermoFisher). PCR reaction mixtures (10 L) contained SYBR Select Master Mix (Applied
26
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Biosystems), 200 nM of each primer, diluted input, diluted template DNA, and autoclaved water
depending on the specific experiment. Three technical replicates were run for each sample. PCR
reactions consisted of one cycle at 50 °C for 2 min and 95 °C for 2 min, followed by 40 cycles at
95 °C for 15 s and 60 °C for 1 min, and a final melting curve analysis at 60 °C to 95 °C for 15 s,
95 °C to 60 °C for 1 min, and 95 °C for 1 s. The percent of input method[20] was used to calculate
enrichments:
Adjusted input = average Ct – log2 50
% Input = 100  2(adjusted input – Ct)
(1)
(2)
Statistical significance of experimental results for two-sample group comparisons was determined
with a two-tailed Student t-test. One-way ANOVA with Tukey post-hoc test and 95% confidence
intervals was used for comparisons of three or more sample groups with one independent variable
(GraphPad Prism 8, GraphPad Software, San Diego, CA).
Acknowledgements
This work was supported in part by NIH Cancer Center Grant P30 CA012197 and by Wake
Forest Innovations. The authors thank Drs. Ke Zhang and Bahjat Fadi Marayati (WFU
Department of Biology) for technical advice with the qPCR experiments.
Conflict of Interest
The authors declare no conflict of interest.
27
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
Keywords: Antitumor agent ∙ Click chemistry ∙ DNA damage ∙ Platinum ∙ pre-rRNA gene
References
[1] a) S. Solier, S. Muller, R. Rodriguez, Curr. Opin. Chem. Biol. 2020, 56, 42-50; b) G. S.
Erwin, D. Bhimsaria, A. Eguchi, A. Z. Ansari, Angew. Chem. Int. Ed. 2014, 53, 10124-
10128; c) C. Jin, L. Yang, M. Xie, C. Lin, D. Merkurjev, J. C. Yang, B. Tanasa, S. Oh, J.
Zhang, K. A. Ohgi, H. Zhou, W. Li, C. P. Evans, S. Ding, M. G. Rosenfeld, Proc. Natl.
Acad. Sci. USA 2014, 111, 9235-9240.
[2] a) E. C. Sutton, C. E. McDevitt, M. V. Yglesias, R. M. Cunningham, V. J. DeRose, Inorg.
Chim. Acta 2019, 498; b) J. D. White, M. M. Haley, V. J. DeRose, Acc. Chem. Res. 2016, 49,
56-66; c) J. C. Hu, J. D. Lieb, A. Sancar, S. Adar, Proc. Natl. Acad. Sci. USA 2016, 113,
11507-11512; d) X. T. Shu, X. S. Xiong, J. H. Song, C. He, C. Q. Yi, Angew. Chem. Int. Ed.
2016, 55, 14244-14247; e) N. J. Farrer, D. M. Griffith, Curr. Opin. Chem. Biol. 2020, 55, 59-
68.
[3] a) X. Qiao, S. Ding, F. Liu, G. L. Kucera, U. Bierbach, J. Biol. Inorg. Chem. 2014, 19, 415-
426; b) S. Ding, X. Qiao, J. Suryadi, G. S. Marrs, G. L. Kucera, U. Bierbach, Angew. Chem.
Int. Ed. 2013, 52, 3350-3354.
[4] a) S. Zhang, X. Yao, N. H. Watkins, P. K. Rose, S. R. Caruso, C. S. Day, U. Bierbach,
Angew. Chem. Int. Ed. 2020, 59, 21965-21970; b) X. Yao, N. H. Watkins, H. Brown-
Harding, U. Bierbach, Sci. Rep. 2020, 10, 15201.
28
This article is protected by copyright. All rights reserved.

10.1002/chem.202102263
Chemistry - A European Journal
[5] a) F. Liu, J. Suryadi, U. Bierbach, Chem. Res. Toxicol. 2015, 28, 2170-2178; b) X. Qiao, A.
E. Zeitany, M. W. Wright, A. S. Essader, K. E. Levine, G. L. Kucera, U. Bierbach,
Metallomics 2012, 645-652; c) C. L. Smyre, G. Saluta, T. E. Kute, G. L. Kucera, U.
Bierbach, ACS Med. Chem. Lett. 2011, 2, 870-874.
[6] H. Kostrhunova, J. Malina, A. J. Pickard, J. Stepankova, M. Vojtiskova, J. Kasparkova, T.
Muchova, M. L. Rohlfing, U. Bierbach, V. Brabec, Mol. Pharmaceutics 2011, 8, 1941-1954.
[7] a) S. Ding, X. Qiao, G. L. Kucera, U. Bierbach, J. Med. Chem. 2012, 55, 10198-10203; b) K.
Cheung-Ong, K. T. Song, Z. Ma, D. Shabtai, A. Y. Lee, D. Gallo, L. E. Heisler, G. W.
Brown, U. Bierbach, G. Giaever, C. Nislow, ACS Chem. Biol. 2012, 7, 1892-1901; c) Z. Ma,
L. Rao, U. Bierbach, J. Med. Chem. 2009, 52, 3424-3427.
[8] J. Pelletier, G. Thomas, S. Volarevic, Nat. Rev. Cancer 2018, 18, 51-63.
[9] M. van Sluis, B. McStay, Curr. Opin. Cell Biol. 2017, 46, 81-86.
[10] A. J. Pickard, F. Liu, T. F. Bartenstein, L. G. Haines, K. E. Levine, G. L. Kucera, U.
Bierbach, Chem. Eur. J. 2014, 20, 16174-16187.
[11] J. R. Choudhury, L. Rao, U. Bierbach, J. Biol. Inorg. Chem. 2011, 16, 373-380.
[12] R. Rodriguez, K. M. Miller, Nat. Rev. Genet. 2014, 15, 783-796.
[13] H. L. Tytgat, G. Schoofs, M. Driesen, P. Proost, E. J. Van Damme, J. Vanderleyden, S.
Lebeer, Microb. Biotechnol. 2015, 8, 164-168.
[14] X. Lin, L. Tirichine, C. Bowler, Plant Methods 2012, 8, 48.
[15] G. E. Zentner, A. Saiakhova, P. Manaenkov, M. D. Adams, P. C. Scacheri, Nucleic Acids
Res. 2011, 39, 4949-4960.
29
This article is protected by copyright. All rights reserved.
