Research on Controllable Degradation of Novel Sulfonylurea Herbicides in Acidic and Alkaline Soils

Article abstract of DOI:10.1021/acs.jafc.7b03029

The degradation issue of sulfonylurea (SU) has become one of the biggest challenges that hamper the development and application of this class of herbicides, especially in the alkaline soils of northern China. On the basis of the previous discovery that some substituents on the fifth position of the benzene ring in Chlorsulfuron could hasten its degradation rate, apparently in acidic soil, this work on Metsulfuron-methyl showed more convincing results. Two novel compounds (I-1 and I-2) were designed and synthesized, and they still retained potent herbicidal activity in tests against both dicotyledons and monocotyledons. The half-lives of degradation (DT₅₀) assay revealed that I-1 showed an accelerated degradation rate in acidic soil (pH 5.59). Moreover, we delighted to find that the degradation rate of I-1 was 9-10-fold faster than that of Metsulfuron-methyl and Chlorsulfuron when in alkaline soil (pH 8.46), which has more practical value. This research suggests that a modified structure that has potent herbicidal activity as well as accelerated degradation rate could be realized and this approach may provide a way to improve the residue problem of SUs in farmlands with alkaline soil.

Full text of DOI:10.1021/acs.jafc.7b03029

Subscriber access provided by UNIVERSITY OF ADELAIDE LIBRARIES
Article
Research on Controllable Degradation of Novel
Sulfonylurea Herbicides in Acidic and Alkaline Soils
Shaa Zhou, Xue-Wen Hua, Wei Wei, Yu-Cheng Gu, Xiaoqing Liu, Jinghuo Chen, Minggui Chen, Yong-Tao
Xie, Sha Zhou, Xiang-De Meng, Yan Zhang, Yong-Hong Li, Baolei Wang, Haibin Song, and Zheng-Ming Li
J. Agric. Food Chem., Just Accepted Manuscript • DOI: 10.1021/acs.jafc.7b03029 • Publication Date (Web): 16 Aug 2017
Downloaded from http://pubs.acs.org on August 17, 2017
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
Journal of Agricultural and Food Chemistry is published by the American Chemical
Society. 1155 Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 37
Journal of Agricultural and Food Chemistry
Research on Controllable Degradation of Novel
Sulfonylurea Herbicides in Acidic and Alkaline Soils
Shaa Zhou,† XueꢀWen Hua,‡ Wei Wei,† YuꢀCheng Gu,§ XiaoꢀQing Liu,† JingꢀHuo
Chen,† MingꢀGui Chen,† YongꢀTao Xie,† Sha Zhou,† XiangꢀDe Meng,† Yan Zhang,†
YongꢀHong Li,† BaoꢀLei Wang,† HaiꢀBin Song,† ZhengꢀMing Li*,†
†
State Key Laboratory of ElementoꢀOrganic Chemistry, Collaborative Innovation Center of
Chemical Science and Engineering (Tianjin), College of Chemistry, Nankai University,
Tianjin 300071, China
‡ College of Agriculture, Liaocheng University, Liaocheng 252000, China
§ Syngenta Jealott's Hill International Research Centre, Bracknell, Berks, RG42 6EY, UK
* Address correspondence to this author at State Key Laboratory of
ElementoꢀOrganic Chemistry, Nankai University, No. 94, Weijin Road, Nankai
District, Tianjin 300071, China (telephone: +86 022ꢀ23503732; Fax: +86
022ꢀ23503732; eꢀmail: nkzml@vip.163.com)
1
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 2 of 37
1
2
Abstract: The degradation issue of sulfonylurea (SU) has become one of the biggest
challenges that hamper the development and application of this class of herbicides,
especially in alkaline soils of Northern China. On the basis of previous discovery that
some substituents on the 5th position of the benzene ring in Chlorsulfuron could
hasten its degradation rate apparently in acidic soil, this work on Metsulfuronꢀmethyl
showed more convincing results. Two novel compounds (I-1 and I-2) were designed
and synthesized, at the same time, they still retained potent herbicidal activity against
both tested dicotyledon and monocotyledon. The halfꢀlives of degradation (DT50)
assay revealed that I-1 showed accelerated degradation rate in acidic soil (pH 5.59).
Moreover, we delighted to find that the degradation rate of I-1 was 9~10 folds faster
than that of Metsulfuronꢀmethyl and Chlorsulfuron when in alkaline soil (pH 8.46),
which have more practical value. This research suggests that a modified structure
which has potent herbicidal activity as well as accelerated degradation rate could be
realized and this approach may provide a way to improve the residue problem of SUs
in farmlands with alkaline soil.
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Keywords: Sulfonylurea herbicide, Metsulfuronꢀmethyl, herbicidal activity, soil
degradation, DT50.
2
ACS Paragon Plus Environment

Page 3 of 37
Journal of Agricultural and Food Chemistry
18 Introduction
19
20
21
22
23
Sulfonylurea (SU) herbicides have been widely applied due to their ultraꢀlow
dosage, broad spectra and good selectivity.1ꢀ2 Their sole target is Acetolactate
Synthase (ALS) which exists only in plants and microbes, not in mammals. The
inhibition of ALS results in the disruption of three essential amino acids synthesis in
meristem and eventually death of weeds.3ꢀ6
24
25
26
27
28
29
30
31
32
33
Many sulfonylurea herbicides have been introduced into China and are widely
available in Chinese plant protection market.7 The common cultivation practice in
China is to rear 2~3 different crops successively within a year on the same plot of
land. The short crops cycle demands herbicides with high activity, low toxicity and
fast degradation rate. Due to the relatively long persistence of Chlorsulfuron,
Metsulfuronꢀmethyl and Ethametsulfuron that can injure next season crops including
wheat, corn, paddy rice, cotton and bean,8ꢀ10 the Ministry of Agriculture of China
suspended their field application in 2014.11 From an environmental and ecological
standpoint, we took a green approach to study this issue according to the Anastas 10th
Principle of Green Chemistry—Design for Degradation.12
34
35
36
37
pH is one of the most important factors that influences the degradation rate of
sulfonylurea herbicides in soil. Walker et al reported that the DT50 of
Metsulfuronꢀmethyl was 23 days in pH 5.8 soil and 73 days in pH 7.3 soil.13 Yadav et
al found that there was 83% dissipation of Metsulfuronꢀmethyl in low pH 5.6 soil and
3
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 4 of 37
38
39
40
41
42
43
44
45
46
47
48
49
53% in high pH 8.1 soil after 120 days.14 After research of the hydrolysis of
sulfonylurea herbicides in water at different pH, we concluded that the 5th position on
the benzene ring in SU structures is the key factor influencing their degradation
behaviors.15ꢀ18 Our previous study reported that the introduction of some substituents
onto the 5th position of the benzene ring in Chlorsulfuron could speed up its
degradation rate in acidic soil relatively.19ꢀ20 Based on these previous findings,
dimethylamino and diethylamino groups were introduced into the Metsulfuronꢀmethyl
structure (Figure 1) to investigate their influence on biological activities as well as
soil degradation behaviors. Considering the difference of soil pH in China and the soil
degradation of sulfonylurea herbicides has strong negative correlation with soil
pH,13ꢀ14, 21 two representative standard soil samples (pH 5.59 Jiangxi Province and pH
8.46 Hebei Province) were selected to carry out our research.
4
ACS Paragon Plus Environment

Page 5 of 37
Journal of Agricultural and Food Chemistry
50 Materials and Methods
51
52
53
54
55
56
57
58
59
60
61
62
63
64
Instruments and Materials. All reaction reagents were analytical grade, all
analytical reagents for high performance liquid chromatograph (HPLC) were HPLC
grade including methanol and acetonitrile. The melting points were determined on an
Xꢀ4 binocular microscope melting point apparatus (Beijing Tech Instrument Co.,
1
13
Beijing, China), and the temperatures were uncorrected. H and C nuclear magnetic
resonance (NMR) spectra were obtained on a Bruker AVꢀ400 spectrometer (Bruker
Co., Switzerland) in Acetoneꢀd6 or DMSOꢀd6 solution with tetramethylsilane (TMS)
as the internal standard, and chemicalꢀshift values (δ) were given in parts per million
(ppm). Highꢀresolution mass spectrometry (HRMS) data were obtained on a Varian
QFTꢀESI instrument. Ultraviolet (UV) spectra were performed on a TUꢀ1810
ultravioletꢀvisible spectrophotometer (Persee general analysis Co., Beijing, China).
HPLC data were obtained on a SHIMADZU LCꢀ20AT (SHIMADZU Co., Japan).
Column chromatography purification was carried out using silica gel (200~300
mesh).
5
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 6 of 37
65
66
67
68
69
70
71
72
General Procedure for the Synthesis of Target Compounds I-1.
1ꢀ(2ꢀMethoxycarbonylꢀ5ꢀdimethylaminophenylsulfonyl)ꢀ3ꢀ(4ꢀmethoxyꢀ6ꢀmethylꢀ1,3,
5ꢀtriazinꢀ2ꢀyl)urea I-1 was synthesized by the following method.22 To a toluene
solution of 10a (1.0 mmol), 2ꢀaminoꢀ4ꢀmethoxyꢀ6ꢀmethylꢀ1,3,5ꢀtriazine (1.2 mmol)
was added under stirring. The mixture was heated to reflux with continuous removal
of the azeotrope formed by ethanol and toluene. After completion of the reaction, the
solvent was evaporated in vacuum and the residue was purified on silica gel column
eluting with petroleum/ethyl acetate (v/v, 1:1) to obtain I-1.
73
74
75
76
77
78
79
1ꢀ(2ꢀMethoxycarbonylꢀ5ꢀdimethylaminophenylsulfonyl)ꢀ3ꢀ(4ꢀmethoxyꢀ6ꢀmethylꢀ1,
o
1
3,5ꢀtriazinꢀ2ꢀyl)urea (I-1). White solid, yield 87%, m.p. 195ꢀ197 C. H NMR (400
MHz, Acetone) δ 12.60 (s, 1, NH), 9.59 (s, 1, NH), 7.77 (d, 1, J = 8.7 Hz, PhꢀH), 7.60
(d, 1, J = 2.7 Hz, PhꢀH), 6.95 (dd, 1, J = 8.8, 2.8 Hz, PhꢀH), 4.06 (s, 3, CO2CH3), 3.84
13
(s, 3, OCH3), 3.13 (s, 6, N(CH3)2), 2.56 (s, 3, CH3). C NMR (101 MHz, DMSO) δ
178.6, 170.2, 166.0, 163.9, 151.4, 148.5, 138.7, 132.7, 115.1, 114.4, 114.2, 55.3, 52.3,
39.7, 25.1. HRMS (ESI) Calcd for C16H21N6O6S [M+H]+ 425.1243, found 425.1239.
80
I-2 was prepared with the same procedure.
81
82
83
84
1ꢀ(2ꢀMethoxycarbonylꢀ5ꢀdiethylaminophenylsulfonyl)ꢀ3ꢀ(4ꢀmethoxyꢀ6ꢀmethylꢀ1,3,
o
1
5ꢀtriazinꢀ2ꢀyl)urea (I-2). White solid, yield 85%, m.p. 189ꢀ191 C. H NMR (400
MHz, Acetone) δ 12.58 (s, 1, NH), 9.54 (s, 1, NH), 7.74 (d, 1, J = 8.8 Hz, PhꢀH), 7.61
(d, 1, J = 2.8 Hz, PhꢀH), 6.93 (dd, 1, J = 8.8, 2.8 Hz, PhꢀH), 4.06 (s, 3, CO2CH3), 3.83
6
ACS Paragon Plus Environment

Page 7 of 37
Journal of Agricultural and Food Chemistry
85
86
87
88
(s, 3, OCH3), 3.54 (q, 4, J = 7.1 Hz, N(CH2CH3)2), 2.56 (s, 3, CH3), 1.23 (t, 6, J = 7.1
Hz, N(CH2CH3)2). 13C NMR (101 MHz, DMSO) δ 178.6, 170.2, 166.0, 164.0, 149.0,
148.6, 138.8, 133.0, 114.3, 113.8, 99.6, 55.3, 52.3, 44.3, 25.1, 12.1. HRMS (ESI)
Calcd for C18H25N6O6S [M+H]+ 453.1556, found: 453.1548.
7
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 8 of 37
89
90
X-ray Diffraction Analysis. A colorless crystal of I-1 was obtained by
selfꢀevaporation in the mixture solvent of dichloromethane and nꢀhexane. The crystal
with dimensions of 0.20 ×0.20 ×0.20 mm was mounted on a glass fiber for Xꢀray
diffraction analysis. The data was collected at 113 K on a Rigaku Saturn 724 CCD
diffractometer (Rigaku Co. Japan) with graphite monochromated Mo Kα radiation (λ
= 0.71075 Å), θmax = 25.01o. The molecular formula is C16H20N6O6S, and the formula
weight is 424.44 g·molꢀ1. The crystal was a monoclinic system, space group P 21/c,
with cell parameters existed as ɑ = 13.5479(19) Å, b = 9.9822(12) Å, c = 15.552(2) Å;
cell ratio as ɑ/b = 1.3572, b/c = 0.6419, c/ɑ = 1.1479; calculated density was 1.46883
g/cm3; V = 1919.22(43) Å3; Z = 4, ꢀ (Mo Kα) = 0.217 mmꢀ1. In total, 14901 integrated
reflections were collected, reducing to a data set of 3263 unique with Rint = 0.0405
and the completeness of data was 96.8%. Data were collected and processed using
CrystalClear (Rigaku). An empirical absorption correction was applied using
CrystalClear (Rigaku). The structure was solved by direct methods with the
SHELXSꢀ97 program.23 Fullꢀmatrix leastꢀsquares refinement based on F2 gave final
values of R = 0.1195, wR = 0.3482. Hydrogen atoms were observed and refined with
a fixed value of their isotropic displacement parameter.
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
8
ACS Paragon Plus Environment

Page 9 of 37
Journal of Agricultural and Food Chemistry
106
107
108
109
110
Biological Assay. The root growth inhibition of oil seed rape (Brassica campestris)
was tested using the reported method.24 Pot trials for herbicidal activities against oil
seed rape (Brassica campestris), amaranth (Amaranthus retroflexus), barnyard grass
(Echinochloa crusgalli) and crab grass (Digitaria sanguinalis) were tested in
greenhouse (25 ± 2 oC) according to the procedures in the literature.24, 25
111
112
113
114
115
116
Molecular Docking. The surflexꢀdock method26 was applied to study the binding
mode of SU structures with the AHAS using the SYBYL 6.9 software package. I-1
was manually docked into the active site of yeast AHAS on the basis of the crystal
complex of Chlorimuronꢀethyl and yeast AHAS27 which was retrieved from the
RCSB Protein Data Bank (PDB code: 1N0H). The receptor and the ligand molecule
were prepared by standard procedures.
117
118
119
120
121
122
123
124
125
Soil Degradation Experimental Strategies. Soil Selection. To investigate the
degradation behaviors of Metsulfuronꢀmethyl and its derivatives, a red acidic soil (pH
5.59) from Ji’an, Jiangxi Province and an alkaline soil (pH 8.46) from Cangzhou,
Hebei Province in China were selected. The soil from the fresh farmland was sampled
from the upper layer (0ꢀ25 cm), airꢀdried in the shade and passed through a 2 mm
sieve according to the Chinese National Standard GB/T 31270.1ꢀ2014.28 The soil
texture, pH value, organic matter, cation exchange capacity (CEC) and mechanical
composition of the test soils were listed in Table 1, which were determined by Tianjin
Institute of Agriculture Resource and Environment.
9
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 10 of 37
126
127
128
129
130
131
132
133
134
135
136
HPLC Processing and Establishment of Standard Curves. The samples were
analyzed by HPLC following the Chinese National Standard GB/T 16631ꢀ2008.29 The
method employed a Shimadzu HPLC (series LCꢀ20AT), equipped with a binary pump
(Shimadzu, LCꢀ20AT), an UV/VIS detector (Shimadzu, SPDꢀ20A), an auto sampler
(Shimadzu, SILꢀ20A), a column oven (Shimadzu, CTOꢀ20AC) and a Shimadzu
shimꢀpack VPꢀODS column (5 mm, 250 mm × 4.6 mm) connected to a Shimadzu
shimꢀpack GVPꢀODS (10 mm × 4.6 mm) preꢀcolumn, and a computer (model Dell)
for carrying out the data analysis. Chromatographic pure methanol, acetonitrile and
ultraꢀpure water (pH 3.0) were used as mobile phase. After that, standard curves used
for quantitative conversion were established with the injection volume of 10 µL and
the temperature was set at 20 oC.
137
138
139
140
141
142
143
144
145
146
Measurement of the Recovery Rate. Appropriate extraction solvents were adopted
and mixed to guarantee the eligible average recovery rate, standard deviation and
coefficients of variation (Table 2) according to the Chinese Agricultural Industry
Standard NY/T 788ꢀ2004.30 The concentrations of target compound in soil were 5, 2,
0.5 mg·kgꢀ1, and the soil humidity was kept at 60% of the water holding capacity.
Different extraction solvents were decanted into the homogeneous soils, followed by
shaking for 3 h at 200 rpm·minꢀ1 with a SHZꢀ88 thermostatic oscillator (Jintan
Medical Instrument Factory, Jiangsu, China). The samples were then centrifuged for 2
min at 6500 rpm·minꢀ1 with a Thermo Scientific Legend Mach 1.6 R centrifuge to
obtain supernatant which was then concentrated in vacuum at room temperature. After
10
ACS Paragon Plus Environment

Page 11 of 37
Journal of Agricultural and Food Chemistry
147
148
149
150
151
152
the residue was extracted by dichloromethane (30 mL × 2) and distilled water (30
mL), the combined organic solution was dried by anhydrous sodium sulfate, filtered
and concentrated. The product was dissolved in acetonitrile (10 mL), and filtered
through a millipore filter (organic, nylon 66, 0.22 µm) for HPLC analysis. The
addition recovery rate were measured and calculated according to the corresponding
average values of 5 replicates.
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
Cultivation of Samples and Management. Testing soil (20.00 g) was weighed
into 6 groups in 100 mL conical flasks, triplications in each group, and the standard
sample solutions were added to a concentration of 5 a.i. mg·kgꢀ1. Then an appropriate
volume of distilled water was added to adjust the soil moisture content to
approximately 60% of water holding capacity and thoroughly mixed. The bottles were
then sealed with Para film and put into a SPXꢀ150BꢀZ biochemical incubator (Boxun
o
Industrial Co., Shanghai, China) at 25 ± 1 C and 80% humidity in the dark. In the
process of cultivation, the moisture content in conical flasks was adjusted regularly to
maintain the original waterꢀholding state. The samples were taken periodically for
HPLC analysis at 6 different intervals and each sample was repeated 3 times.
According to previous studies, the initial degradation of sulfonylurea herbicides
follows the firstꢀorder kinetic equation.19,31ꢀ34 The degradation curves of firstꢀorder
kinetic equation of tested compounds were established according to the data from six
samplings. After that, halfꢀlives of degradation (DT50) were calculated using the
formula: DT50 = LN(2)/K.
11
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 12 of 37
168 Results and Discussion
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
Chemistry. The synthetic procedures of all compounds were showed in Figure 2.
The reactions of diazotization of 1, ammoniation of 2 and successive reduction of 5
were prepared according to reported methods,19 and 10 was synthesized through the
reaction of 9 and ethyl chlorocarbonate using the procedure in literature.24 Compound
4 was obtained in the aqueous solution of chromium trioxide by adding concentrated
sulfuric acid and 2ꢀmethylꢀ5ꢀnitrobenzenesulfonamide successively, for 24h at room
temperature.35 The ringꢀopening reaction of 4 was prepared by leading in hydrogen
chloride gas continuously in methanol.17 The protection and deprotection of
sulphonamide were carried out for the alkylation of aniline, and DMFꢀDMA was
taken as the protective agent.36ꢀ38 The intermediate 8a was obtained as previous
reported.19 Compound 8b can be prepared as 8a, and can also be synthesized by the
following procedure that 7 was dissolved in glacial acetic acid, and then NaBH4 was
added in batches, the mixture was stirred overnight to adjust pH until there was no
longer white solid produced,39 this method was more effective and with more higher
yield than 8a.
184
185
186
187
188
In assay of alkaline soil degradation, the soil extraction of I-2 failed due to an
unexpected peak overlapped with the sample which resulted in a ＞130 % recovery.
By numerous replacement of the mobile phases and change of their ratios, we
successfully separated the mixed peaks by HPLC condition as CH3OH/CH3CN/H2O
(pH 3.0) = 35/35/30. As a result, the alkaline soil degradation of I-2 was determined
12
ACS Paragon Plus Environment

Page 13 of 37
Journal of Agricultural and Food Chemistry
189
in another batch, taking Chlorsulfuron as a control.
190
191
192
193
194
195
196
197
198
199
200
Crystal Structure Analysis. The crystal structure of I-1 was showed in Figure 3
(CCDC number. 1540975). The sum angles of O(5)ꢀC(11)ꢀN(2) 123.878(535)o,
O(5)ꢀC(11)ꢀN(3) 120.792(502)o and N(2)ꢀC(11)ꢀN(3) 115.314(471)o was 359.984o,
indicating the plane sp2 hybridization state of C(11) atom. The bonds angles of
O(3)ꢀS(1)ꢀC(1), O(4)ꢀS(1)ꢀC(1), N(2)ꢀS(1)ꢀC(1) were 109.858(271)o, 108.886(256)o
and 105.792(250)o respectively which indicated the sp3 hybridization state of the S(1)
atom. The torsion angle of O(5)ꢀC(11)ꢀN(2)ꢀH(2) was ꢀ175.66(53)o while the
O(5)ꢀC(11)ꢀN(3)ꢀH(3) showed as 8.376(799)o. The benzene ring and the triazine ring
were nonꢀplane for their dihedral angle was 74.041(146)o. From Figure 3, one kind of
Hꢀbond could be found: N(2)ꢀH(2)···N(5), it could be explained as the reason of the
torsion angles of O(5)ꢀC(11)ꢀN(2)ꢀH(2) and O(5)ꢀC(11)ꢀN(3)ꢀH(3).
201
202
203
204
205
Biological Assay. The inhibition rate of the root growth oil seed rape (Brassica
campestris) was measured to evaluate the herbicidal activities of the target
compounds and the corresponding results were listed in Table 3. From the results, it
was observed that the new compound I-1 matched commercial Metsulfuronꢀmethyl in
herbicidal potency at the rate of 0.1 ug·mLꢀ1, whereas I-2 was slightly weaker.
206
207
208
On this basis, the herbicidal activities of target compounds against dicotyledon
Brassica campestris, Amaranthus retroflexus and monocotyledon Echinochloa
crusgalli, Digitaria sanguinalis were further screened through pot experiments at 15
13
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 14 of 37
209
210
211
212
213
214
215
216
217
and 150 a.i. g·haꢀ1 with Metsulfuronꢀmethyl as a positive control. The results were
showed in Table 4. From the data, it was found that the target compounds retained
their efficient herbicidal activities, where I-1 exhibited excellent inhibition effect
against Digitaria sanguinalis at 150 a.i. g·haꢀ1. The 100% inhibition rate against
Brassica campestris was showed at 15 a.i. g·haꢀ1 by soil treatment as well as foliage
spray. The effect on Echinochloa crusgalli of I-1 was also 100% at 15 a.i. g·haꢀ1 in
postꢀemergence treatment. Overall the introduction of dimethylamino and
diethylamino groups onto the 5th position of the benzene ring in Metsulfuronꢀmethyl
retained or improved their herbicidal activities.
218
219
220
221
222
223
224
225
226
227
228
229
Molecular Docking Results. I-1 was taken in the molecular docking study for its
hyper herbicidal activity, and the result was illustrated in Figure 4. As it showed the
conformations of the aromatic ring and triazine ring connected to the sulfonyl urea
bridge were situated in approximately mutual vertical position which was similar to
the binding structure of Chlorimuronꢀethyl and AHAS that the heterocyclic part
blocks the substrate access channel. The section of methoxy carbonyl was also located
in the channel to block the substrate. There was a π–π stacking interaction between
the indole side chain of B/Trp 586 and the triazine moiety of I-1. There was also
several Hꢀbonds interaction between the ureaꢀtriazine moiety of I-1 and the guanidine
group of B/Arg 380. The docking results ascertained that I-1 is also a typical AHAS
interaction.5 From the conformation of the docking results, the dimethylamino group
was located along the extended plane of the benzene ring outside the channel, it could
14
ACS Paragon Plus Environment

Page 15 of 37
Journal of Agricultural and Food Chemistry
230
231
232
233
explain its high biological activity. The conformation of sulfonylurea bridge was
rotated for the better docking with AHAS through the torsion of C(11)ꢀN(3) bond, and
it was consistent with the active conformation of Chlorimuronꢀethyl and
Monosulfuron.40ꢀ41
234
235
236
Soil Degradation. The degradation curves of firstꢀorder kinetic equation of tested
compounds were established according to the data from six samplings (Figure 5 and
Figure 6). After that, halfꢀlives of degradation (DT50) were calculated (Table 5).
237
238
239
240
241
242
243
244
The soil degradation behaviors of target compounds in acidic soil (pH 5.59) with
Metsulfuronꢀmethyl as a positive control were investigated preliminarily to explore
the corresponding relationship between structural modification and soil degradation.
From the halfꢀlives of degradation, the degradation rate of dimethylamino substituted
compounds I-1 was increased significantly that its DT50 was 2.85 days, 2 folds faster
than Metsulfuronꢀmethyl. Furthermore, the degradation rate of I-2 with its DT50 as
5.11 days, which had approximately the same degradation rate as metsulfuronꢀmethyl
(5.50 days).
245
246
247
Then, the alkaline soil (pH 8.46) degradation behaviors of target compounds were
examined to survey their difference in degradation rate in two types of soils, taking
Metsulfuronꢀmethyl and Chlorsulfuron as positive controls.
248
249
From Table 5, the DT50 of compound I-1 was 8.40 days which showed a significant
10 folds faster degradation rate than Chlorsulfuron (84.53 days) and 9 folds faster
15
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 16 of 37
250
251
252
253
254
255
than Metsulfuronꢀmethyl (75.34 days). The DT50 of compound I-2 was 26.56 days
while the DT50 of Chlorsulfuron was longer than 100 days. The experimental data
demonstrated that the introduction of dimethylamino and diethylamino groups onto
the 5th position of the benzene ring in Metsulfuronꢀmethyl could efficiently accelerate
its soil degradation rate. The research provide critical information for the solution to
soil degradation problems in our green chemistry approach especially in alkaline soil.
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
After structural modification, the optimized new structure I-1 upgraded its
degradation rate not only in standardized acidic soil, but also in standardized alkaline
soil. From the degradation results in acidic soil (pH 5.59), DT50 of I-1 accelerated to
2.85 days while I-2 was 5.11 days comparing with the 5.50 days of
Metsulfuronꢀmethyl. Particularly in alkaline soil (pH 8.46), the DT50 of I-1 hastened
nearly 9 folds from 75.34 to 8.40 days in comparison with Metsulfuronꢀmethyl that
there was considerable faster degradation in alkaline soil than acidic soil, the same as
compound I-2. Interestingly I-1 and I-2 also retained their active herbicidal activity in
comparison with the parent structure. The perfect surflexꢀdocking results also
confirmed that I-1 was a typical AHAS interaction. Our study further ascertained that
in Metsulfuronꢀmethyl, the 5th position substituted approach also has apparent
influence on its degradation rate, though the influence mensuration is somewhat
different. This might be due to the difference in their molecular structures.
Considering the particular planting practice in China which requires individual
cultivation cycle for each crop, it convinces us that by modifying SU structures
16
ACS Paragon Plus Environment

Page 17 of 37
Journal of Agricultural and Food Chemistry
271
272
273
274
delicately, a control of their degradation rate which is in accordance with our
cultivation pattern is possible.42 After further understanding of their
structure/activity/degradation relationship, it will be possible to optimize the novel
herbicidal application in the particular planting system.
275
276
ABBREVIATIONS USED
277
278
AHAS: acetohydroxy acid synthase; DMFꢀDMA: N,NꢀDimethylformamide dimethyl
acetal; THF: tetrahydrofuran; RT: room temperature; Trp: tryptophan; Arg: aginine.
279
280
ACKNOWLEDGMENT
281
282
283
284
285
This work was supported by the National Natural Science Foundation of China (No.
21272129), State Key Laboratory of ElementoꢀOrganic Chemistry (Nankai
University), Collaborative Innovation Center of Chemical Science and Engineering
(Tianjin), and Syngenta PhD Scholarship. Thank Whittingham William for polishing
this article.
286
Supporting Information Description
13
287
288
289
1H NMR, C NMR spectra for the target compounds; Crystal data of the compound
I-1; Determination results of tested soils. This material is available free of charge via
the Internet at http: //pubs.acs.org.
17
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 18 of 37
290
References
291
292
1. Levitt, G. Synthesis and chemistry of agrochemicals II, ACS Symposium Series.
Washington DC: American Chemistry Society, 1991, 443, 16ꢀ31.
293
2. Levitt, G. Herbicidal sulfonamides: US 4127405, 1978.
294
295
296
297
3. Wang, J. G.; Lee, P. K. M.; Dong, Y. H.; Pang, S. S.; Duggleby, R. G.; Li, Z. M.;
Guddat, L. W. Crystal structures of two novel sulfonylurea herbicides in complex
with Arabidopsis thaliana acetohydroxyacid synthase. FEBS J., 2009, 276,
1282ꢀ1290.
298
299
4. Duggleby, R. G.; Pang, S. S. Acetohydroxyacid synthase. BMB Rep., 2000, 33,
1ꢀ36.
300
301
302
303
5. Li, Z. M.; Ma, Y.; Guddat, L.; Cheng, P. Q.; Wang, J. G.; Pang, S. S.; Dong, Y. H.;
Lai, C. M.; Wang, L. X.; Jia, G. F.; Li, Y. H.; Wang, S. H.; Liu, J.; Zhao W. G.;
Wang, B. L. The structureꢀactivity relationship in herbicidal monosubstituted
sulfonylureas. Pest Manag. Sci., 2012, 68, 618ꢀ628.
304
305
306
6. Vulliet, E.; Emmelin, C.; Chovelon, J. M.; Guillard, C.; Herrmann, J. M.
Photocatalytic degradation of sulfonylurea herbicides in aqueous TiO 2. Appl.
Catal. BꢁEnviron., 2002, 38, 127ꢀ137.
307
308
7. MCDOUGALL—AGRISERVICE P. Products sectionꢀ2011 market. US: Phillips
McDougall—Agriservice, 2012.
18
ACS Paragon Plus Environment

Page 19 of 37
Journal of Agricultural and Food Chemistry
309
310
8. Liu, L. J.; Gao, H. W.; Li, H. W. Conservation tillage for cornꢀwheat two crops a
year region. Trans. Chin. Soc. Agric. Eng., 2004, 3, 016.
311
312
313
314
9. Fang, Q.; Yu, Q.; Wang, E.; Chen, Y.; Zhang, G.; Wang, J.; Li, L. Soil nitrate
accumulation, leaching and crop nitrogen use as influenced by fertilization and
irrigation in an intensive wheatꢀmaize double cropping system in the North China
Plain. Plant Soil, 2006, 284, 335ꢀ350.
315
316
317
318
10. Qiu, J.; Tang, H.; Frolking, S.; Boles, S.; Li, C.; Xiao, X.; Qin, X. Mapping
singleꢀ, doubleꢀ, and tripleꢀcrop agriculture in China at 0.5 × 0.5 by combining
countyꢀscale census data with a remote sensingꢀderived land cover map. Geocarto
Int., 2003, 18, 3ꢀ13.
319
320
321
11. Announcement No. 2032 of the Ministry of agriculture of the People's Republic of
China, Bulletin of the Ministry of agriculture of the People's Republic of China 53,
2014.
322
323
324
12. Anastas, P. T.; Warner, J. C. Green Chemistry: Theory and Practice, Oxford
University Press: New York, 1998, p.30. By permission of Oxford University
Press.
325
326
327
13. Walker, A.; Cotterill, E. G.; Welch, S. J. Adsorption and degradation of
chlorsulfuron and metsulfuronꢀmethyl in soils from different depths. Weed Res.,
1989, 29, 281ꢀ287.
19
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 20 of 37
328
329
14. Yadav D.; Singh S.; Malik R. Yadav A. Persistence of metsulfuronꢀmethyl in soil
as influenced by soil pH and microbes. Pestology, 1998, 12, 31ꢀ34.
330
331
332
15. Wang, M. Y.; Mu, X. L.; Guo, W. C.; Li, Y. H.; Li, Z. M. Synthesis and
herbicidal activity of novel 5ꢀsubstituted benzenesulfonylureas. Chem. Res. Chin.
Univ., 2007, 23, 674ꢀ678.
333
334
335
16. Wang, M. Y.; Ma, Y.; Li, Z. M.; Wang, S. H. 3DꢀQSAR Study of Novel
5ꢀSubstituted Benzenesulfonylurea Compounds. Chem. J. Chin. Univ., 2009, 30,
1361ꢀ1364.
336
337
338
17. Cao, G.; Wang, M. Y.; Wang, M. Z.; Wang, S. H.; Li, Y. H.; Li, Z. M. Synthesis
and herbicidal activity of novel sulfonylurea derivatives. Chem. Res. Chin. Univ.,
2011, 27, 60ꢀ65.
339
340
341
18. Wang, M.Y.; Ma, Y.; Wang, H. Y.; Cao, G.; Li. Z. M. Kinetics of the Chemical
Hydrolysis and 3DꢀQSAR Study of 5ꢀSubstituted Benzenesulfonylurea
Compounds. Chem. J. Chin. Univ., 2016, 37, 1636ꢀ1642.
342
343
344
19. Hua, X. W.; Chen, M. G.; Zhou, S.; Zhang, D. K.; Liu, M.; Zhou, S.; Liu, J. B.;
Lei, K.; Song, H. B.; Li, Y. H.; Gu, Y. C.; Li, Z. M. Research on controllable
degradation of sulfonylurea herbicides. RSC Adv., 2016, 6, 23038ꢀ23047.
345
346
20. Hua, X. W.; Zhou, S.; Chen, M. G.; Wei, W.; Liu, M.; Lei K.; Li, Z. M.
Controllable Effect of Structural Modification of Sulfonylurea Herbicides on Soil
20
ACS Paragon Plus Environment

Page 21 of 37
Journal of Agricultural and Food Chemistry
347
Degradation. Chin. J. Chem., 2016, 34, 1135ꢀ1142.
348
349
21. Walker, A.; Welch, S. J. The relative movement and persistence in soil of
chlorsulfuron, metsulfuronꢀmethyl and triasulfuron. Weed Res., 1989, 29, 375ꢀ383.
350
351
352
22. Wei, W.; Cheng, D. D.; Liu, J. B.; Li, Y. X.; Ma, Y.; Li, Y. H.; Yu, S. J.; Zhang, X.;
Li, Z. M. Design, synthesis and SAR study of novel sulfonylureas containing an
alkenyl moiety. Org. Bio. Chem., 2016, 14, 8356.
353
354
23. Sheldrick, G. M. SHELXTL (Version 5.0), University of Göttingen: Göttingen,
Germany, 2001.
355
356
357
24. Wang, B. L.; Duggleby, R. G.; Li, Z. M.; Wang, J. G.; Li, Y. H.; Wang, S. H.; Song,
H. B. Synthesis, crystal structure and herbicidal activity of mimics of
intermediates of the KARI reaction. Pest Manag. Sci., 2005, 61, 407ꢀ412.
358
359
360
361
25. Teaney, S. R.; Armstrong, L.; Bentley, K.; Cotterman, D.; Leep, D.; Liang, P. H.;
Powley, C.; Summers, J.; Cranwell, S.; Lichtner, F.; Stichbury, R. DPXꢀKE459ꢀa
new sulfonylurea for postemergence grass and broadleaf weed control in cereals.
Brighton Crop Prot. Conf.ꢁWeeds, 1995, 1, 49.
362
363
26. Jain, A. N. Surflex: fully automatic flexible molecular docking using a molecular
similarityꢀbased search engine. J. Med. Chem., 2003, 46, 499ꢀ511.
364
365
27. Pang, S. S.; Guddat, L. W.; Duggleby, R. G. Molecular basis of sulfonylurea
herbicide inhibition of acetohydroxyacid synthase. J. Bio. Chem., 2003, 278,
21
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 22 of 37
366
7639ꢀ7644.
367
368
369
28. Chinese National Standard GB/T 31270.1ꢀ2014 Test guidelines on environmental
safety assessment for chemical pesticidesꢀPart 1:Transformation in soils,
2014ꢀ10ꢀ10.
370
371
29. Chinese National Standard GB/T 16631ꢀ2008 General rules for high performance
liquid chromatography, 2008ꢀ6ꢀ18.
372
373
30. Chinese Agricultural Industry Standard NY/T 788ꢀ2004 guideline on pesticide
residue trials, 2004ꢀ4ꢀ16.
374
375
376
31. Levitt, G.; Ploeg, H. L.; Weigel, Jr. R. C.; Fitzgerald, D. J.
2ꢀChloroꢀNꢀ[(4ꢀmethoxyꢀ6ꢀmethylꢀ1,
3,
5ꢀtriazinꢀ2ꢀyl)
aminocarbonyl]
benzenesulfonamide, a new herbicide. J. Agric. Food Chem., 1981, 29, 416ꢀ418.
377
378
32. Thirunarayanan, K.; Zimdahl, R. L. and Smika, D. E. Chlorsulfuron adsorption
and degradation in soil. Weed Sci., 1985, 558ꢀ563.
379
380
33. Oppong, F. K.; Sagar, G. R. Degradation of triasulfuron in soil under laboratory
conditions. Weed Res., 1992, 32, 167ꢀ173.
381
382
34. Hamaker, J. W.; Goring, C. A. I. Turnover of Pesticide Residues in Soil. Acs Symp.
Ser. Amer. Chem. Soc., 1976, 9, 219ꢀ243.
383
384
35. Gençera, N.; Demir, D.; Sonmez, F.; Kucukislamoglu, M. New saccharin
derivatives as tyrosinase inhibitors. Bioorg. Med. Chem., 2012, 20, 2811ꢀ2821.
22
ACS Paragon Plus Environment

Page 23 of 37
Journal of Agricultural and Food Chemistry
385
386
387
388
36. Dudutienė, V.; Zubrienė, A.; Smirnov, A.; Gylytė, J.; Timm, D.; Manakova, E.;
Gražulis, S.; Matulis, D. 4ꢀSubstitutedꢀ2, 3, 5, 6ꢀtetrafluorobenzenesulfonamides
as inhibitors of carbonic anhydrases I, II, VII, XII, and XIII. Bioorg. Med. Chem.,
2013, 21, 2093ꢀ2106.
389
390
391
37. Gazvoda, M.; Kočevar, M.; Polanc, S. In situ formation of vilsmeier reagents
mediated by oxalyl chloride: a tool for the selective synthesis of
Nꢀsulfonylformamidines. Eur. J. Org. Chem., 2013, 5381ꢀ5386.
392
393
394
38. Chandna, N.; Chandak, N.; Kumar, P.; Kapoor, J. K.; Sharma, P. K. Metalꢀand
solventꢀfree synthesis of Nꢀsulfonylformamidines. Green Chem., 2013, 15,
2294ꢀ2301.
395
396
397
39. Vaidyanathan, G.; Song, H.; Affleck, D.; McDougald, D. L.; Storms, R. W.;
Zalutsky, M. R.; Chin, B. B. Targeting aldehyde dehydrogenase: a potential
approach for cell labeling. Nucl. Med. Biol., 2009, 36, 919ꢀ929.
398
399
400
40. McCourt, J. A.; Pang, S. S.; Guddat, L. W.; Duggleby, R. G. Elucidating the
specificity of binding of sulfonylurea herbicides to acetohydroxyacid synthase.
Biochem., 2005, 44, 2330ꢀ2338
401
402
403
404
41. Chen, P. Q.; Sun, H. W.; Li, Z. M.; Wang, J. G.; Ma, Y.; Lai, C. M. Molecular
dynamics simulation of conformational conversion between crystal conformation
and active conformation of herbicidal monosulfuron. Chem. J. Chin. Univ., 2007,
28, 278ꢀ282.
23
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 24 of 37
405
406
407
408
42. Feng, D. J.; Bai, B.; Wang, H. L.; Suo, Y. R. Novel Fabrication of Biodegradable
Superabsorbent Microspheres with Diffusion Barrier through ThermoꢀChemical
Modification and Their Potential Agriculture Applications for Water Holding and
Sustained Release of Fertilizer. J. Agric. Food Chem., 2017, 65, 5896–5907.
24
ACS Paragon Plus Environment

Page 25 of 37
Journal of Agricultural and Food Chemistry
FIGURE CAPTIONS
Figure 1 Design Strategy of Target Compounds.
Figure 2 Synthesis Strategy for Target Compounds.
Figure 3 The Crystal Structure of I-1.
Figure 4 Binding Mode of I-1 to Yeast AHAS.
Figure 5 Degradation Curves in Acidic Soil (pH 5.59).
Figure 6 Degradation Curves in Alkaline Soil (pH 8.46).
25
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 26 of 37
Tables
Table 1 Analysis data of Soils
Mechanical composition
Cation
exchange
capacity
(cmol·kgꢀ1
)
Silt
Clay
Sand
Organic
matter
(%)
Soil
Fine
Coarse
Soils
pH
(1ꢀ0.
05
Coarse
(0.05ꢀ0.
01 mm)
(%)
Fine
(<0.00
1 mm)
(%)
texture
(0.01ꢀ0. (0.005ꢀ0
005
mm)
(%)
.001
mm)
(%)
mm)
(%)
Acidic
soil
loam
clay
5.59
8.46
0.763
0.757
13.55
10.39
36
30
10
26
10
8
12
8
32
28
Alkali
ne soil
26
ACS Paragon Plus Environment

Page 27 of 37
Journal of Agricultural and Food Chemistry
Table 2 Analytical Conditions for Soil Degradation.
HPLC analysis
conditions
Adding
Average
recovery
Coefficient
of
Compou
nds
Extraction solvents
(v/v)
concentration
(wavelength, flow rate,
235 nm, 0.8 mL·minꢀ1,
CH3OH/H2O (pH 3.0) =
65/35
(mg·kgꢀ1)
variation/%
1.23
CH3COCH3:CH2Cl2
:CH3OH:H3PO4
5
84.82
78.78
74.06
80.53
76.74
77.58
88.60
85.12
76.90
84.74
77.29
83.73
77.16
74.05
74.13
70.80
73.19
90.65
85.83
72.75
I-1
I-2
2
0.5
5
2.12
3.49
1.27
1.42
2.50
1.61
3.14
3.33
1.76
3.82
1.19
2.87
1.23
0.62
1.04
3.27
1.98
1.51
2.90
aqueous solution
(pH 2.0) = 40:5:5:5
CH3COCH3:CH2Cl2
230 nm, 0.8 mL·minꢀ1,
CH3OH/H2O (pH 3.0) =
70/30
Acidic
soil
: CH3OH: H3PO4
aqueous solution
(pH 2.0) = 40:5:5:5
2
0.5
5
(pH
5.59)
CH3COCH3:CH2Cl2
: H3PO4 aqueous
solution (pH 2.0) =
40:5:5
2
Metsulf
230 nm, 1.0 mL·minꢀ1,
uronꢀme CH3OH/H2O (pH 3.0) =
0.5
2
thyl
55/45
0.5
5
235 nm, 0.8 mL·minꢀ1,
CH3OH/H2O (pH 3.0) =
65/35
CH3COCH3:CH2Cl2
: H3PO4 aqueous
I-1
2
solution (pH 2.0) =
0.5
5
40:5:10
Alkali
ne soil
230 nm, 0.8 mL·minꢀ1,
CH3OH/CH3CN/H2O
(pH 3.0) = 35/35/30
CH3COCH3:CH2Cl2
: H3PO4 aqueous
I-2
2
(pH
solution (pH 2.0) =
0.5
5
8.46)
40:5:5
CH3COCH3:CH2Cl2
Metsulf
230 nm, 1.0 mL·minꢀ1,
: H3PO4 aqueous
solution (pH 2.0) =
40:5:10
uronꢀme CH3OH/H2O (pH 3.0) =
thyl 55/45
2
0.5
27
ACS Paragon Plus Environment

Journal of Agricultural and Food Chemistry
Page 28 of 37
Table 3 Inhibition of the Root Growth of Rape (Brassica campestris).
Inhibition rate (%)
compounds
0.1 µg·mLꢀ1
61.8
1 µg·mLꢀ1
67.9
10 µg·mLꢀ1
68.4
I-1
I-2
45.8
61.4
67.5
Metsulfuronꢀmethyl
61.2
66.6
67.3
28
ACS Paragon Plus Environment

Page 29 of 37
Journal of Agricultural and Food Chemistry
Table 4 Herbicidal Activity of Target Compounds by Soil Treatment and Foliage
Spray.
Inhibition rate (%)
Concentration
Brassica
Amaranthus
retroflexus
Echinochloa
crusgalli
Digitaria
compounds
campestris
sanguinalis
(a.i g·haꢀ1)
Pre
Post
100
100
100
100
100
100
Pre
91.4
100
91.8
100
100
100
Post
92.5
100
97.8
100
100
100
Pre
77.4
100
53.4
100
64.7
96.7
Post
100
100
85.2
100
84.1
98.9
Pre
27.7
98.1
49.9
90
Post
15
150
15
100
100
100
100
100
100
12.2
65.6
0
I-1
I-2
150
15
0
61.5
100
31.7
45.4
Metsulfuronꢀme
thyl
150
29
ACS Paragon Plus Environment
