Kx[Bi4-xMnxS6], Design of a Highly Selective Ion
Exchange Material and Direct Gap 2D Semiconductor
Ruiqi Wang, Haijie Chen, Yi Xiao, Ido Hadar, Kejun Bu, Xian Zhang, Jie Pan,
Yuhao Gu, Zhongnan Guo, Fuqiang Huang, and Mercouri G. Kanatzidis
J. Am. Chem. Soc., Just Accepted Manuscript • DOI: 10.1021/jacs.9b08674 • Publication Date (Web): 30 Sep 2019
Downloaded from pubs.acs.org on October 5, 2019
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a service to the research community to expedite the dissemination
of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts appear in
full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been fully
peer reviewed, but should not be considered the official version of record. They are citable by the
Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered to authors. Therefore,
the “Just Accepted” Web site may not include all articles that will be published in the journal. After
a manuscript is technically edited and formatted, it will be removed from the “Just Accepted” Web
site and published as an ASAP article. Note that technical editing may introduce minor changes
to the manuscript text and/or graphics which could affect content, and all legal disclaimers and
ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors or
consequences arising from the use of information contained in these “Just Accepted” manuscripts.
is published by the American Chemical Society. 1155 Sixteenth Street N.W.,
Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the
course of their duties.

Page 1 of 42
Journal of the American Chemical Society
1
2
3
4
5
6
7
1
8
9
Kx[Bi4-xMnxS6], Design of a Highly Selective Ion
10
2
Exchange Material and Direct Gap 2D Semiconductor
11
12
13
3
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
Ruiqi Wang,a Haijie Chen,b Yi Xiao,a Ido Hadar,b Kejun Bu,c Xian Zhang,d Jie Pan,c Yuhao Gu,a
Zhongnan Guo,b Fuqiang Huang,*,a,c Mercouri G. Kanatzidis*,b
6
a
7
8
9
Beijing National Laboratory for Molecular Sciences and State Key Laboratory of Rare Earth
Materials Chemistry and Applications, College of Chemistry and Molecular Engineering, Peking
University, Beijing 100871, China
10
11
b Department of Chemistry, Northwestern University, 2145 Sheridan Road, Evanston, Illinois 60208,
United States
c
12
13
14
CAS Key Laboratory of Materials for Energy Conversion and State Key Laboratory of
High-Performance Ceramics and Superfine Microstructure, Shanghai Institute of Ceramics, Chinese
Academy of Sciences, Shanghai 200050, P. R. China
d
15
16
Qian Xuesen Laboratory of Space Technology, China Academy of Space Technology, Beijing
100094, P. R. China
17
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 2 of 42
1
2
3
4
5
6
7
8
9
1
2
3
4
5
ABSTRACT. Layered sulfides with high selectivity for binding heavy metal ions and radionuclide
ions are promising materials in effluent treatment and water purification. Here we present a
rationally designed layered sulfide Kx[Bi4-xMnxS6] (x = 1.28) deriving from the Bi2Se3-strucutre type
by targeted substitution to generate quintuple [Bi4-xMnxS6]x layers and K+ cations between them.
The material has dual functionality: it is an attractive semiconductor with a bandgap of 1.40 eV and
also an environmental remediation ion-exchange material. The compound is paramagnetic and
optical adsorption spectroscopy and DFT electronic structure calculations reveal that it possesses a
direct band gap and a work function of 5.26 eV. The K+ ions exchange readily with alkali or
alkaline-earth ions (Rb+, Cs+ and Sr2+) or soft ions (Pb2+, Cd2+, Cr3+ and Zn2+). Furthermore, when the
K+ ions are depleted the Mn2+ atoms in the Bi2Se3-type slabs can also be replaced by soft ions,
achieving large adsorption capacities. The ion exchange reactions of Kx[Bi4-xMnxS6] can be used to
create new materials of the type Mx[Bi4-xMnxS6] in a low temperature kinetically controlled manner
with significantly different electronic structures. The Kx[Bi4-xMnxS6] (x = 1.28) exhibits efficient
capture of Cd2+ and Pb2+ ions with high distribution coefficient, Kd (107 mL/g), and exchange
capacities of 221.2 and 342.4 mg/g, respectively. The material exhibits excellent capacities even in
high concentration of competitive ions and over a broad pH range (2.5-11.0). The results highlight
the promise of the Kx[Bi4-xMnxS6] (x = 1.28) phase to serve not only as a highly selective adsorbent
for industrial and nuclear wastewater but also as a magnetic 2D semiconductor for optoelectronic
applications.
10
11
12
13
14 6
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
KEYWORDS: Water purification, work function, ion exchange, toxic metal removal, nuclear
remediation, spintronics, topological properties
ACS Paragon Plus Environment

Page 3 of 42
Journal of the American Chemical Society
1
2
3
4
5
6
7
1
2
INTRODUCTION
Effluent treatment of industrial and nuclear wastes has been a major concern around the world.1-3
8
9
90
3
Several heavy metal ions (Pb2+, Cd2+, Hg2+, etc.) and radionuclides (137Cs and Sr, etc.) are major
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
pollutants in these effluents and threaten human health and the environment.4-5 Traditional
commonly used and inexpensive adsorbents are clays, zeolites and activated carbon.6-9 However,
because of their weak binding affinity towards these hazardous metal ions, they suffer from
relatively low selectivity and capacity, often cannot reduce the concentrations to desirable levels and
tend to perform poorly in acidic conditions or in solutions with high salt concentration.10-18
Recently, layered chalcogenides with ion-exchange properties have been demonstrated as
promising adsorbents in a wide pH range.19-35 The ability of the layered structure to expand along the
stacking axis contributes to the fast ion exchange kinetics. One example is the KMS series
compounds which are based on SnS2-type layers with mix-occupied Sn/M (M = Mn, Mg, In) sites
and K+ intercalated between the layers. Their efficient adsorption properties have been confirmed on
many heavy metal ions and radionuclides. 19-25, 27, 29, 34-38 The high selectivity of these ion exchangers
arises from their Lewis soft S2 ligands in the anionic slabs, as the pollutant metal ions are soft Lewis
acid. Hard ions such as H+, Na+ and Ca2+ only interact weakly with S2, thus the pollutant metal
adsorption can be effective over a broad pH range and in the present of high salt concentration.10-11
From this point of view, softer Lewis basicity in the chalcogenide slabs will benefit efficiency and
selectivity in the heavy metal adsorption.
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
The Lewis basicity of the chalcogenide slab is determined mainly by the metal ion in the
framework. Compared with Sn4+ in the KMS series, Bi3+ is less positively-charged and possesses
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 4 of 42
1
2
3
4
5
6
7
8
9
1
2
larger ion radii, thus we can expect that the Bi3+-based slabs are more Lewis basic and should
possess stronger binding affinity towards heavy metal ions. The five-atom-thick Bi2Se3-type layers
are an ideal kind of matrix for the rational design of new ion exchangers. This is done by replacing a
fraction of Bi3+ ions in the structure with other metals ions of lower positive charge. This creates a
negatively charged layer whose exact charge depends on the M metal such as [Bi2-xMxSe3]δ. The
compounds AxCdxBi4-xQ6 (A = K, Rb, Cs; Q = S, Se), are examples of this process,39-40 however,
these materials contain heavy and toxic Cd2+ which limits their application in effluent treatment.
In this work, we targeted the Kx[Bi4-xMnxS6] with several considerations in mind. First, the
presence of Mn makes the system suitable for environmental remediation investigations. Second, the
relatively weak Mn-S bonds imply that Mn2+ can also contribute to the adsorption capacity of heavy
metal ions. The solubility constant ksp of MnS (4.6510-14) is more than 10 orders of magnitude
higher than those of heavy metal sulfides such as CdS (8.010-27) and PbS (7.010-29).41-43 The Mn
contribution of adsorption capacity has been demonstrated in KMS-1 (K2xMnxSn3-xS6 (x = 0.50.95)
and K2xMn1-xPS3, as Mn2+ of MnS6 octahedral units inside the layers can be exchanged by Cd2+ and
Pb2+.21, 34 Third, the variable valence states Mn can adopt in the structure can provide an additional
knob to further tune the ion-exchange function as well as the magnetic properties. We hypothesized
that the five-atom-thick octahedral Bi2Se3-type slab could be a better host for achieving this function
than the three-atom-thick SnS2-type KMS-1 slabs because Mn2+ can be better protected from
oxidation inside the thicker slabs.
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Guided by the abovementioned concepts, we synthesized Kx[Bi4-xMnxS6] (x = 1.28) (i.e.
K1.28Mn1.28Bi2.72S6) with quintuple Bi2Se3-type [Bi4-xMnxS6]x layers and K+ cations between them.
ACS Paragon Plus Environment

Page 5 of 42
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
1
2
Optical adsorption and DFT calculations reveal that it is a new semiconductor with a direct band gap
of 1.40 eV, potentially promising for optoelectronic applications. This compound is paramagnetic
and exhibits anisotropic and thermally activated charge transport behavior. Various M ions such as
Rb+, Cs+, Sr2+, Pb2+, Cd2+, Cr3+, and Zn2+ replace the K+ ions rapidly and topotactically, and even the
Mn2+ ions held in the slabs can be exchanged totally or partially by soft ions (M2+ = Pb2+、Cd2+、Cr3+
and Zn2+). These ion exchange reactions create new materials of the type My[Bi4-xMnxS6] in a low
temperature kinetically controlled manner with significantly different electronic structures as verified
by optical absorption and work function measurements. With Cs+ exchange a remarkable topotactic
oxidation of Mn2+ to Mn3+ was observed, and confirmed with single-crystal X-ray diffraction and
X-ray photoelectron spectroscopy (XPS). We show highly selective absorption of Cd2+ and Pb2+ by
Kx[Bi4-xMnxS6] (x = 1.28) over a broad pH range that follows the Langmuir model with high
exchange capacities of 221.2 and 342.4 mg/g and particularly high distribution coefficient Kd of 107
mL/g. The selectivity for heavy metal ion remediation, high pH resistance and discrimination against
hard Lewis acid ions make the Kx[Bi4-xMnxS6] system promising for future industrial and nuclear
waste applications.
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
EXPERIMENTAL SECTION
Reagents. The following reagents were used as purchased: Mn (Alfa Aesar, 99.9%), Bi (Alfa
Aesar, 99.9%) and S (Alfa Aesar, 99.9%). K2S5 was prepared by the stoichiometric reaction of
elements in liquid NH3 as described previously.44-45
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 6 of 42
1
2
3
4
5
6
7
8
9
1
2
Synthesis of Kx[Bi4-xMnxS6] (x = 1.28). All operations were carried out in an Ar-filled glovebox.
0.0592 g K2S5 (0.25 mmol), 0.0275 g Mn (0.5 mmol), 0.2299 g Bi (1.1 mmol) and 0.0368 g S (1.15
mmol) were mixed and loaded in a carbon coated silica tube with an inner diameter of 10 mm. The
tube was flame-sealed under vacuum (103 mbar), heated to 700 °C in 10 h, held for 48 h, and
followed by slow cooling to 450 °C in 3 days. Black single crystals were obtained with a yield of ~
99% based on the Bi element. Large plate-like single crystals (1 mm  2 mm  0.2 mm) of
Kx[Bi4-xMnxS6] (x = 1.28) used for electrical resistivity measurement were synthesized by adding
extra 0.0592 g K2S5 (0.25 mmol) into the combination of reactants (to act as a flux) and following
the same heating procedure mentioned above. The product was washed with deionized water twice to
remove the extra K2S5.
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Single Crystal X-ray Crystallography. Single crystals were selected from the products and
mounted on the tips of glass fiber loops with glue for X-ray diffraction. X-ray diffraction data were
collected at 180 K on a Rigaku XtaALB PRO 007HF single crystal X-ray diffractometer equipped
with mirror-monochromatized Mo-K radiation ( = 0.71073
Å) and Oxford Cryo stream (80-500
K). The crystal structures were solved via direct methods and refined by full-matrix least-squares on
F2 using the SHELXTL program package.46 Multi-scan absorption corrections were performed. The
crystallographic data and structure refinement results of Kx[Bi4-xMnxS6] (x = 1.28) are shown in
Table 1 and the selected bond lengths and angles are shown in Table 2. Atomic coordinates,
equivalent isotropic displacement parameters and anisotropic displacement parameters are shown in
Table S1-S2.
ACS Paragon Plus Environment

Page 7 of 42
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
1
2
Physical Properties Measurements. Direct-current magnetization measurements as a function of
temperature and magnetic field were performed using a Physical Properties Measurement System
(PPMS) from Quantum Design. Zero-field-cooled (ZFC) and field-cooled (FC) susceptibility data
were collected from 300 to 2 K in an applied magnetic field of 1 T. Magnetic hysteresis, M(H), were
collected with applied magnetic field from 1 to 1 T at 2, 10, 50, 100, 150, 200 and 300 K,
respectively. Electrical resistivity measurements on single crystals were done using the standard
two-probe method on the PPMS.
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
Work Function. The work function data was collected by photoemission yield spectroscopy in air
(PYSA). In PYSA, the sample is scanned with monochromatic UV light (3.46.2 eV) and the
generated photoelectrons are measured at each energy, the work function is defined by the onset in
the PYSA spectrum.47 PYSA measurements were performed using an AC-2 spectrometer (Riken
Keiki).
9
10
11
12
13
14
15
16
17
18
19
20
21
Electronic Structure Calculations. First-principles calculations were performed by using the
Projected Augmented Wave Method (PAW)48 within the density functional theory (DFT) as
implemented in the Vienna Ab Initio Simulation Package (VASP).49-51 The exchange correlation
functional was treated within the spin-polarized generalized gradient approximation (GGA) and
parameterized by Perdew-Burke-Ernzerhof (PBE) version.52 The cutoff energy of plane wave basis
was set to 380 eV and the Monkhorst-Pack k-point grid of 463 was used for Brillouin zone (BZ)
sampling. The crystal structure and the lattice parameters were fixed as the values observed in
experiments during the structural optimization, while the positions of atoms were relaxed until the
atomic forces on each atom were less than 0.01 eV/Å.
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 8 of 42
1
2
3
4
5
6
7
8
9
1
2
ICP-AES and ICP-MS Analysis. The concentration of K+, Cs+, Mn2+, Cd2+, and Pb2+ in the range
of 1-100 ppm were determined using a Leeman Prodigy 7 ICP-AES spectrometer. Standards of these
ions were prepared by diluting the commercial ~1000 ppm ICP standards, and the calibration was
liner with maximum errors of 5%. The solutions were diluted to appropriate concentrations using 1
wt % HNO3. The intensity was obtained using a 35 sec exposure and the result was the average of
three readings. The residual concentrations of Cd2+ and Pb2+ in the solutions after ion exchange were
at ppb levels and were determined by ICP-MS using a PerkinElmer NexION 350X ICP-MS
spectrometer.
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
9
Ion-Exchange Experiments. The ion-exchange properties of Kx[Bi4-xMnxS6] (x = 1.28) were
studied as follows: the crystals of the material (~10.0 mg) were added into 0.2 mol/L aqueous
solutions (10 mL) of RbCl, CsCl, SrCl26H2O, CrCl36H2O, ZnCl2, CdCl22.5H2O, or Pb(NO3)2,
respectively. After three days, the products were collected by filtration, washed with water and
acetone and then dried in air. Ion-exchange crystals were selected for SEM imaging and EDS
analysis. Rb+, Cs+ and Zn2+-exchanged single crystals were picked out for detailed crystallographic
analysis. Ground powder of Kx[Bi4-xMnxS6] (x = 1.28) (100 mg) were add in 0.2 mol/L aqueous
solutions (20 mL) of the ions mentioned above. The mixture was stirred for 24 h and the solid
products collected by filtration and characterized with PXRD and UV-Vis spectroscopy.
Sorption studies of Kx[Bi4-xMnxS6] (x = 1.28) with Cs+, Cd2+ and Pb2+ were carried out by the
batch method at V:m = 1000 mL/g at RT. An amount of 10.0 mg ground powder of Kx[Bi4-xMnxS6] (x
= 1.28) was added into 10 mL aqueous solutions containing gradient concentration of Cs+, Cd2+ or
10
11
12
13
14
15
16
17
18
19
20
ACS Paragon Plus Environment

Page 9 of 42
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
1
2
Pb2+. The mixture was stirred for 24 h and then filtered. The concentration of ions was determined by
ICP-AES or ICP-MS. The obtained data was used for the determination of the sorption isotherms.
Kinetic studies were carried out to estimate the rate and pathways of sorption. Typically, amounts
of 10.0 mg of ground powder of Kx[Bi4-xMnxS6] (x = 1.28) were added into 10 mL of Cs+ (100 ppm),
Pb2+ (350 ppm) or Cd2+ (200 ppm) aqueous solutions in individual tubes and stirred. After certain
time intervals, the solutions were filtered, and the concentrations were determined by ICP-AES.
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
RESULTS AND DISCUSSION
9
Synthesis and Thermal Behavior. Kx[Bi4-xMnxS6] (x = 1.28) was synthesized via solid state
reactions of K2S5, Mn, Bi and S at 700 °C. The phase purity of the as-synthesized product was
validated by comparing the experimental PXRD pattern with the simulated one, as shown in Figure
1a. Energy dispersive X-ray spectroscopy (EDS) confirmed that all the elements distribute uniformly
in the crystals, as shown in Figure S1. The accurate molar ratio of K/Mn/Bi as determined by
ICP-AES is 1.32/1.28/2.72 is consistent with the single crystal X-ray crystallographic refinement. By
adding extra reactant K2S5 to serve as flux, we succeeded in obtaining large flaky crystals (1 mm  2
mm  0.2 mm) suitable for the resistivity measurements. The thermal behavior of Kx[Bi4-xMnxS6] (x
= 1.28) was investigated using DSC analysis. In the first heating cycle of the DSC a single
endothermic peak was observed at 693.8 C, and on cooling a single exothermic peak at 255.5 C
corresponding to the crystallization of Bi metal, Figure 1b. In the second cycle the endothermic peak
at 693.8 C disappeared, while a new peak appeared at 269.5 C on heating, indicating the melting of
Bi. The product obtained after DSC analysis was examined by PXRD, and the pattern can be well
10
11
12
13
14
15
16
17
18
19
20
21
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 10 of 42
1
2
3
4
5
6
7
1
2
matched with the patterns of KBiS2 (PDF#08-0441), MnS (PDF#06-0518) and Bi (PDF#44-1246),
as shown in Figure S2. Therefore, Kx[Bi4-xMnxS6] (x = 1.28) melts incongruently.
8
9
3
Crystal Structure. The structure and stoichiometry of Kx[Bi4-xMnxS6] (x = 1.28) was determined
from the single crystal X-ray crystallographic refinements. The crystallographic data and structure
refinements are summarized in Table 1. The structure derives from the layered quintuple hexagonal
Bi2Se3 structure, with some Bi3+ sites in the slabs are replaced by Mn2+ ions which requires
disordered alkali cations between the interlayers to balance charge (Figure S3). This compound
crystallizes in space group P63/mmc and is isostructural with the compounds Cs1.2Ag0.6Bi3.4Q6 (Q = S,
Se) and AxCdxBi4-xQ6 (A = K, Rb, Cs; Q = S, Se).39-40
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Kx[Bi4-xMnxS6] (x = 1.28) is composed of anionic Bi2Se3-type quintuple [Bi2.72Mn1.28S6]1.28 layers
of edge-sharing distorted (Mn/Bi)S6 octahedra intercalated by K+ cations, Figure 2a, 2b. There are
two independent K sites (2b, 2c Wyckoff position), one independent Bi/Mn site (4f, occupancy: Bi
68.0% and Mn 32.0%) and two independent S sites (2a, 4f). The coordination environment of
(Mn/Bi)S6 octahedral is shown in Figure 2b. The Mn2+ ion in the (Mn/Bi)S6 octahedra of
Kx[Bi4-xMnxS6] (x = 1.28) is in a relatively loose coordination environment originally intended for the
Bi3+ atoms. The two K sites are partly occupied with refined occupancies 21% and 43%. A
graphene-like layered arrangement of K+ is obtained after omitting the partial occupation of K sites,
as shown in Figure 2c. The open interlayer space of Kx[Bi4-xMnxS6] and relatively large thermal
factors of K+ atoms (Table S1-S2) imply a strong tendency to engage in facile ion-exchange.
Optical Absorption and Electronic Structure Calculations. The optical absorption properties of
Kx[Bi4-xMnxS6] (x = 1.28) were investigated by UV-Vis diffuse reflectance spectroscopy, which
ACS Paragon Plus Environment

Page 11 of 42
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
1
2
shows a well-defined band gap of 1.40 eV (Figure 1c). In order to gain insight into the nature of the
electronic structure we performed DFT calculations using an ordered structure model with the space
group Cmcm (Figure S4a) to represent the mixed-occupied Mn/Bi sites that is a periodic array of
fully occupied Mn and Bi sites. The [Bi2.72Mn1.28S6]1.28 layers were approximated as [Bi4Mn2S9]2
layers with the Mn:Bi ratio of 1:2. In each of the sublayers, every MnS6 octahedron is surrounded by
six BiS6 octahedra, as shown in Figure S4b. The disordered K+ layers were modified by removing
all 4c K sites and fully occupying the 8g K sites (Figure S4c). Charge neutrality was satisfied with a
general formula of K2Bi4Mn2S9. Because of the presence of magnetic Mn2+ ions spin-polarized
calculations were carried out. The electronic structures and density of states (DOS) of K2Bi4Mn2S9
are depicted in Figure 3. The valence band maximum (VBM) and the conduction band minimum
(CBM) are both located at  point (Figure 3a), which indicates the direct-band-gap character. The
3
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
4
5
6
7
8
9
10
11
12
*
effective masses of the CBM (me*) and VBM (mh ) for a and c directions were calculated by fitting
―1
∂2퐸
2
13
14
15
16
17
18
19
20
21
the E-k bands around the CBM and VBM with m* =
, where
is Plank’s constant, E is
ℏ
ℏ (∂푘2)
the band energy, and k is the wave vector. The calculated electron effective mass (me*) and hole
*
effective mass (mh ) along the a direction (  Y) is 0.36m0 and 1.17m0 (m0 is the effective mass of
*
free electron), respectively, while both me* and mh along the c direction (  Z) are essentially
infinite. This points to the two-dimensional nature of the material and explains its highly anisotropic
conductivity.
For K2Bi4Mn2S9 the DOS of two different spin directions are shown in Figure 3b and Figure S5.
The VBM is mainly contributed by S 3p states and Mn 3d states in the spin-up direction, while the
VBM of the spin-down direction locates at 0.5 eV. The Bi 6s lone-pair states mainly locate between
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 12 of 42
1
2
3
4
5
6
7
8
9
1
2
1.5 eV and the VBM in both spin directions. The Bi 6p and S 3p states make similar contribution to
the CBM in both spin directions, while the spin-down Mn 3d states also significantly contribute to
the CBM. The spin-up Mn 3d states are fully occupied and mainly locate between 4 and 1.3 eV,
while the spin-down states are empty in the range of 1.2 – 2.7 eV. These results indicate that the
Mn2+ ions in MnS6 octahedra are in high spin (HS) state, which implies the presence of magnetic
properties presented below.
