Synthesis of 1h-1,5,7-triaza- cyclopenta[c,d]phenalenes, a new heterocyclic system

Full text of DOI:10.1007/s10593-010-0481-6

Chemistry of Heterocyclic Compounds, Vol. 46, No. 1, 2010
SYNTHESIS OF 1H-1,5,7-TRIAZA-
CYCLOPENTA[c,d]PHENALENES,
A NEW HETEROCYCLIC SYSTEM
A. V. Aksenov1**, A. S. Lyakhovnenko1, and N. C. Karaivanov1
Keywords: sodium azide, perimidines, PPA, 1H-1,5,7-triazacyclopenta[c,d]phenalenes, peri annela-
tion, Schmidt reaction.
In previous work [1-4], we have developed a number of methods for the peri annelation of
six-membered rings to give perimidines. In light of the high biological activity of a significant number of indole
derivatives, we propose a method for the peri annelation of the pyrrole ring to perimidines. The reaction of
ketones 1a-c (1 mmol) and NaN3 (0.07 g, 1.08 mmol) in PPA* (2-3 g) at 70-80°C for 1 h and then at 150-160°C
for 4 h monitored by thin-layer chromatography leads to 1H-1,5,7-triazacyclopenta[c,d]phenalenes 3a-c in
36-48% yield.
The reaction involves intermediante formation of amides 2a-c, which cam be isolated, for example 2a.
The 1H NMR spectra were taken on a Bruker WP-200 spectrometer at 200 MHz in DMSO-d6 with TMS
as the internal standard. The reaction course and purity of the products obtained were monitored on
Silufol UV-254 plates with 1:1 ethyl acetate–ethanol as the eluent.
R
R
R
N
NH
O
N
NH
N
N
NaN3
PPA
∆
N
H
R1
HN
R1
O
R1
3a–c
1a–c
2a–c
1–3 a R = H, R1 = Me, b R = R1 = Me, c R = Me, R1 = Ph
_______
*The PPA sample used containing 86% P2O5 was prepared according to Uhlig [5].
** To whom correspondence should be addressed, e-mail: k-biochem-org@stavsu.ru.
1Stavropol State University, Stavropol 355009, Russia.
__________________________________________________________________________________________
Translated from Khimiya Geterotsiklicheskikh Soedinenii, No. 1, pp. 146-147, January, 2010. Original
article submitted November 9, 2009.
0009-3122/10/4601-0127©2010 Springer Science+Business Media, Inc.
127

The reaction mixture was treated with 50 ml water and then brought to pH 8-9 by adding ammonium
hydroxide. The precipitate formed was filtered off and the mother liquor was extracted with three 50-ml benzene
portions. The solvent was distilled off and the residue was combined with the precipitate. The products obtained
were purified by recrystallization.
6(7)-Acetaminoperimidine (2a) was obtained in 86% yield; mp 225-226°C (ethyl acetate). 1H NMR, δ,
ppm (J, Hz): 2.08 (3H, s, COCH3); 6.43 (2H, m, H-4(9), H-9(4)); 7.03 (1H, d, J = 8.5, H-7(6)); 7.15 (1H, dd,
J = 8.5, J = 7.3, H-8(5)); 7.24 (1H, d, J = 8.1, H-7(6)); 7.32 (1H, s, H-2); 9.21 (1H, br. s, NHCO); 10.61 (1H,
br. s, NH). Found, %: C 69.45; H 4.86; N 18.61. C13H11N3O. Calculated, %: C 69.32; H 4.92; N 18.65.
2-Methyl-1H-1,5,7-triazacyclopenta[c,d]phenalene (3a) was obtained in 44% yield (0.091 g);
mp 259-260°C (benzene). 1H NMR spectrum, δ, ppm (J, Hz): 2.98 (3H, s, CH3); 7.58 (1H, d, J = 9.0, H-9); 7.78
(1H, d, J = 9.0, H-3); 8.31 (1H, d, J = 9.0, H-4); 8.47 (1H, d, J = 9.0, H-8); 9.36 (1H, s, H-6); 13.1 (1H, br. s,
NH). Found, %: C 75.54; H 4.31; N 20.15. C13H9N3. Calculated, %: C 75.35; H 4.38; N 20.28.
2,6-Dimethyl-1H-1,5,7-triazacyclopenta[c,d]phenalene (3b) was obtained in 48% yield (0.106 g);
1
mp 271-272°C (benzene). H NMR spectrum, δ, ppm (J, Hz): 2.87 (3H, s, 2-CH3), 2.95 (3H, s, 6-CH3), 7.50
(1H, d, J = 9.0, H-9); 7.67 (1H, d, J = 9.0, H-3); 8.24 (1H, d, J = 9.0, H-4); 8.41 (1H, d, J = 9.0, H-8); 12.8 (1H,
br. s, NH). Found, %: C 76.18; H 4.95; N 18.87. C14H11N3. Calculated, %: C 76.00; H 5.01; N 18.99.
6-Methyl-2-phenyl-1H-1,5,7-triazacyclopenta[c,d]phenalene (3c) was obtained in 36% yield
1
(0.102 g); mp 291-292°C (benzene). H NMR spectrum, δ, ppm (J, Hz): 2.92 (3H, s, CH3); 7.49 (1H, t, J = 7.7,
H-4 Ph); 7.49 (2H, t, J = 7.7, H-3, H-5 Ph); 7.68 (1H, d, J = 9.0, H-9); 7.81 (1H, d, J = 9.0, H-3); 8.19 (2H, d,
J = 7.7, H-2, H-6 Ph); 8.34 (1H, d, J = 9.0, H-4); 8.73 (1H, d, J = 9.0, H-8); 12.9 (1H, br. s, NH). Found, %:
C 80.69; H 4.55; N 14.76. C19H13N3. Calculated, %: C 80.69; H 4.62; N 14.83.
This work was carried out with the financial support of the Russian Basic Research Fund
(Grant No. 10-03-00193a).
REFERENCES
1.
2.
3.
4.
5.
A. V. Aksenov and I. V. Aksenova, Khim. Geterotsikl. Soedin., 167 (2009). [Chem. Heterocycl. Comp.,
45, 130 (2009)].
A. V. Aksenov, A. S. Lyakhovnenko, I. V. Aksenova, and O. N. Nadein, Tetrahedon Lett., 49, 1808
(2008).
A. V. Aksenov, I. V. Borovlev, I. V. Aksenova, S. V. Pisarenko, and D. A. Kovalev, Tetrahedron Lett.,
49, 707 (2008).
A. V. Aksenov, I. V. Borovlev, I. V. Aksenova, and D. A. Kovalev, Khim. Geterotsikl. Soedin., 1590
(2007). [Chem. Heterocycl. Comp., 43, 1353 (2007)].
F. Uhlig, Angew. Chem., 66, 435 (1954)
