The Journal of Organic Chemistry
Article
filtrate was eluted through a column of Amberlyst A26 with MeOH as
eluent. (The Amberlyst A26 column had been previously flushed with
MeOH). MeOH was evaporated under reduced pressure, and the
residue was purified by chromatography on silica gel (eluent: CH2Cl2/
MeOH = 25:1), to yield indolizidine 13 (48 mg, 56%) along with 2,2-
dimethyl-1,3-propanediol (23 mg, 70%). Under the same conditions, a
little bit higher amounts of 11 (270 mg, 0.70 mmol and 400 mg, 1.03
mmol) afforded indolizidine 13 with a slightly lower but reproducible
53% yield (100 and 147 mg, respectively).
eoselective nucleophilic addition to (3R,4R)-3,4-bis(tert-bu-
toxy)-3,4-dihydro-2H-pyrrole-1-oxide (10),6b a useful building
block in turn prepared from D-tartaric acid in five steps with
46% overall yield. The formed hydroxylamine 11 featuring the
requested three stereogenic centers with the correct config-
uration is then converted into (−)-1 in two simple steps with
48% overall yield. The major achievement of this novel
approach is the creation of the indolizidine skeleton by catalytic
hydrogenation of 11 in the presence of a strong protic acid to
trigger a sequence of two simultaneous and two tandem
reactions, i.e., hydroxylamine N−O hydrogenolysis, acetal
hydrolysis, intramolecular condensation, and reduction of the
cyclic iminium ion 13 in a single laboratory operation. This
strategy provides a practical and scalable access to (−)-lenti-
ginosine to further in vitro and in vivo studies (in progress).
The same sequence applied to L-tartaric acid is a novel synthesis
of the natural iminosugar (+)-lentiginosine.
Procedure B. Following the same procedure used to prepare 11,
(2R,3R,4R)-2-(4,4-diethoxybutyl)-3,4-di-tert-butoxypyrrolidin-1-ol (7,
R1 = t-Bu; R2 = Et) was obtained starting from 4-chloro-1,1-
diethoxybutane (1 g, 5.53 mmol) and nitrone 10 (633 mg, 2.76
mmol). Purification by chromatography on silica gel (eluent:
petroleum ether/EtAcOEt = 3:1) afforded hydroxylamine 7 (R1 = t-
Bu; R2 = Et) as a colorless viscous oil in 89% yield (923 mg).
7 (R1 = t-Bu; R2 = Et): Rf = 0.28 (petroleum ether/EtAcOEt = 3:1);
21
1
[α]D = −24 (c = 0.74, CHCl3); H NMR (CDCl3, 400 MHz): δ =
4.48 (pseudo t, J = 5.6 Hz, 1H, OCHO), 3.92 (pseudo dt, J = 2.8; 4.6
Hz, 1H, 4-H), 3.67−3.57 (m, 3H, 3-H + OCHHMe × 2), 3.473 (dq, J
= 9.3; 7.1 Hz, 1H, OCHHMe), 3.470 (dq, J = 9.4; 7.1 Hz, 1H,
OCHHMe), 3.17 (d, J = 4.7 Hz, 2H, 5-H), 2.75 (pseudo q, J = 5.9 Hz,
1H, 2-H), 1.71−1.49 (m, 6H, CH2CH2CH2), 1.19 [s, 9H, C(CH3)3],
1.18 (t, J = 7.1 Hz, 6H, CH2CH3 × 2), 1.16 [s, 9H, C(CH3)3] ppm;
13C NMR (CDCl3, 100 MHz): δ = 102.9 (d, OCHO), 81.7 (d, C-3),
77.0 (d, C-4), 74.2 (s, Me3CO), 73.8 (s, Me3CO), 73.3 (d, C-2), 64.5
(t, C-5), 61.0 (t, CH2Me), 60.8 (t, CH2Me), 33.8 (t, CH2CH2), 30.0
(t, CH2CH2), 29.0 [q, 3C, C(CH3)3], 28.6 [q, 3C, C(CH3)3], 21.7 (t,
CH2CH2), 15.3 (q, 2C, CH2CH3 × 2) ppm; IR (CDCl3): ν = 3580,
3380, 2978, 2873, 1457, 1391, 1367, 1190 cm−1; C20H41NO5 (375.3):
calcd C 63.96, H 11.00, N 3.731; found C 63.55, H 10.80, N 3.48.
To a mixture of hydroxylamine 7 (R1 = t-Bu; R2 = Et, 63.4 mg, 017
mmol) and Pd/C (10% in weight, 18 mg; Pd: 3.4 mg, 10 mol %) in
EtOH (8.4 mL) under H2 atmosphere (balloon) was added TMSCl
(0.121 mL, 0.951 mmol) with a syringe below the surface of the liquid.
After being stirred under H2 atmosphere (balloon) at 30 °C for 23 h,
the mixture was filtered through a pad of Celite and the filtrate was
eluted through a column of Amberlyst A26 with MeOH as eluent.
(The Amberlyst A26 column had been previously flushed with
MeOH). MeOH was evaporated under reduced pressure, and the
residue was purified by chromatography on silica gel (eluent: CH2Cl2/
MeOH = 25:1), to yield indolizidine 13 (22.1 mg, 46%) along with
(2R,3R,4R)-3,4-di-tert-butoxy-2-(4-ethoxybutyl)pyrrolidine (9 mg,
17%).
EXPERIMENTAL SECTION
■
General Information. Rf values refer to TLC on 0.25 mm silica gel
1
plates. H and 13C NMR data are reported in δ (ppm) relative to
CDCl3 (7.26 and 77.0 ppm) or methanol-d4 (3.31 and 49.05 ppm),
and peak assignments were made on the basis of 1H−1H COSY,
HSQC, and HMBC experiments.
(2R,3R,4R)-2-[3-(5,5-Dimethyl-1,3-dioxan-2-yl)propyl]-3,4-di-tert-
butoxypyrrolidin-1-ol (11). A solution of chloroacetal 811 (999.5 mg,
5.19 mmol) and 1,2-dibromoethane (156 mg, 0.83 mmol) in
anhydrous THF (1 mL) was slowly added under stirring to
magnesium turnings (354 mg, 14.57 mmol) under nitrogen
atmosphere at 30 °C. The mixture was maintained at ca. 30 °C by
periodic removal of the warm bath for 1.5 h and then diluted with
THF (3 mL) and cooled to 0 °C. Nitrone 106b (662.5 mg, 2.89 mmol)
in THF (7 mL) was added dropwise over 20 min at 0 °C. The
resulting mixture was allowed to warm to rt and stirred for 2 h further.
A saturated aqueous solution of NH4Cl (9 mL) was added dropwise at
0 °C, the mixture was filtered through a cotton plug, the layers were
separated, and the aqueous layer was extracted with CH2Cl2 (4 × 8
mL). The combined organic layers were dried over Na2SO4, filtered,
and concentrated under reduced pressure. The crude product (1.57 g)
was purified by chromatography on silica gel [eluent: initially
petroleum ether/AcOEt = 3:1 followed in sequence by petroleum
ether/AcOEt = 3:2, AcOEt 100%, AcOEt/MeOH = 25:1, and AcOEt/
MeOH (NH3 1%) = 10:1] to yield hydroxylamine 11 as a colorless
viscous oil (861 mg, 77%) along with unreacted nitrone 10 (93.3 mg,
14%) and chloroacetal 8 (302 mg, 30%).
23
13: Rf = 0.22 (CH2Cl2/MeOH = 20:1); [α]D = −42 (c = 0.58,
CHCl3) [lit. ent-13: [α]D21 = +42.8 (c = 0.48, CHCl3); [α]D25 = +42.0
(c = 0.54, CHCl3)];6a,8c 1H NMR (CDCl3, 400 MHz): δ = 3.77 (ddd, J
= 7.2; 4.0; 1.6 Hz, 1H, 2-H), 3.62 (dd, J = 8.7; 4.0 Hz, 1H, 1-H), 2.95−
2.88 (m, 1H, 5-Ha), 2.90 (dd, J = 9.9; 1.6 Hz, 1H, 3-Ha), 2.41 (dd, J =
9.9; 7.2 Hz, 1H, 3-Hb), 1.94−1.50 (m, 6H, 5-Hb + 6-H + 7-Ha + 8a-H
+ 8-Ha), 1.29−1.10 (partially obscured, m, 2H, 7-Hb + 8-Hb), 1.20 (s,
9H, CH3 × 3), 1.16 (s, 9H, CH3 × 3) ppm; 13C NMR (CDCl3, 100
MHz): δ = 83.8 (d, C-1), 76.9 (d, C-2), 73.7 (s, Me3CO), 73.5 (s,
Me3CO), 67.1 (d, C-8a), 62.2 (t, C-3), 53.6 (t, C-5), 29.3 (q, 3 C, CH3
× 3), 28.7 (q, 3 C, CH3 × 3) and (t, C-8), 24.9 (t, C-6), 24.1 (t, C-7)
ppm. Spectral properties were identical to those reported for ent-136a
(the resonance of protons 7-Hb and 8-Hb, which are partially
obscured by the intense singlets of the two t-Bu groups and were
previously erroneously assigned above 1.47−1.45 ppm,6a,8c could be
25
11: Rf = 0.18 (petroleum ether/AcOEt = 3:1); [α]D = −24 (c =
0.71, CHCl3); 1H NMR (CD3OD, 400 MHz): δ = 4.48−4.44 (m, 1H,
OCHO), 3.93 (pseudo dt, J = 6.8; 3.2 Hz, 1H, 4-H), 3.69−3.63 (m,
1H, 3-H), 3.56 (A part of an AB system, J = 11.0 Hz, 2H, OCHH × 2),
3.45 (B part of an AB system, J = 11.0 Hz, 2H, OCHH × 2), 3.15 (A
part of an ABX system, J = 11.1; 2.8 Hz, 1H, 5-Ha), 3.02 (B part of an
ABX system, J = 11.1; 6.9 Hz, 1H, 5-Hb), 2.61−2.54 (m, 1H, 2-H),
1.66−1.54 (m, 6H, CH2CH2CH2), 1.22 (s, 9H, CH3 × 3), 1.19 (s, 9H,
CH3 × 3), 1.16 (s, 3H, CH3), 0.72 (s, 3H, CH3) ppm; 13C NMR
(CD3OD, 100 MHz): δ = 103.4 (d, OCHO), 82.4 (d, C-3), 78.1 (t,
2C, CH2O × 2), 77.7 (d, C-4), 75.4 (s, Me3CO), 75.0 (s, Me3CO),
74.0 (d, C-2), 65.6 (t, C-5), 36.0 (t, CH2), 31.2 (t, CH2), 31.0 (s,
Me2C), 29.6 (q, 3C, CH3 × 3), 29.2 (q, 3C, CH3 × 3), 23.5 (q, CH3),
22.1 (q, CH3), 21.5 (t, CH2) ppm; IR (CDCl3): ν = 3690, 3580, 3378,
2978, 2853, 1472, 1463, 1394, 1366, 1190 cm−1; MS (+ESI): m/z =
388 [M + H]+, 410 [M + Na]+. C21H41NO5 (387.6): calcd C 65.08, H
10.66, N 3.61; found C 65.09, H 10.38, N 3.28.
1
observed by H−1H COSY, HSQC, and TOCSY experiments, see
(1R,2R,8aR)-Octahydroindolizine-1,2-diol [(−)-Lentiginosine,
(−)-1]. Indolizidine 13 (164 mg, 0.61 mmol) was dissolved in TFA
(1.9 mL) at 0 °C. The mixture was stirred at rt for 16 h and then
concentrated under reduced pressure. The last traces of TFA were
coevaporated with MeOH, and then the residue was filtered through a
column of of Amberlyst A26 with MeOH as eluent. MeOH was
evaporated under reduced pressure, and the crude product (103 mg)
was purified by chromatography on silica gel [eluent: CH2Cl2/MeOH
(NH3 33%) = 41:8. 1], to yield (−)-lentiginosine (82 mg, 85%).
(1R,2R,8aR)-1,2-Di-tert-butoxyoctahydroindolizine (13). Proce-
dure A. To a mixture of 11 (123 mg, 0.317 mmol) and Pd/C (10%
in weight, 34 mg; Pd: 3.4 mg, 10 mol %) in MeOH (16 mL) under H2
atmosphere (balloon) was added dropwise TMSCl (0.121 mL, 0.951
mmol) at 0 °C. After being stirred under H2 atmosphere (balloon) at
50 °C for 44 h, the mixture was filtered through a pad of Celite and the
C
J. Org. Chem. XXXX, XXX, XXX−XXX
