Synthesis and Structure of Planar Chiral, Bifunctional
Aminoboronic Acid Ferrocene Derivatives
Andrei S. Batsanov, Damien He´rault, Judith A. K. Howard, Leonard G. F. Patrick,
Michael R. Probert, and Andrew Whiting*
Department of Chemistry, Durham UniVersity, Sciences Laboratories, South Road,
Durham DH1 3LE, United Kingdom
ReceiVed January 14, 2007
N,N′-Diisopropylferrocenecarboxamide is utilized for an asymmetric, directed metalation approach to
several planar chiral bifunctional ferrocene derivatives. Directed metalation using n-butyllithium-(-)-
sparteine on N,N′-diisopropylferrocenecarboxamide can be achieved to give high yields of the
corresponding boronic acid; however, it was found that a sequence involving asymmetric directed
metalation-bromination, followed by lithium-halogen exchange, was more convenient to access the
same derivatives since this allowed straightforward determination of the enantiomeric excess. (pR)-2-
[(N,N-Diisopropylamino)methyl]ferrocenylboronic acid and derivatives thereof could be readily accessed
with high enantiomeric excess, followed by amide reduction.
from amines and carboxylic acids.10 In this paper, we document
the synthesis and structure of planar chiral 2-N,N′-diisopropy-
laminomethyferrocenylboronate derivatives, which are direct
chiral analogues of a class of compounds that are valuable
bifunctional catalysts for direct amide formation.10
Introduction
Aminoarylboronic acids have been attracting considerable
interest for a wide variety of applications, including quantifica-
tion of enantiomeric excess,1 electrochemical,2 colorimetric, or
fluorescence saccharide sensor applications,3 selective saccharide
binding systems,4 and indicators to follow reaction kinetics.5
In addition, early studies by Letsinger et al. demonstrated the
potential for such systems as bifunctional catalysts for simple
alkylation and hydrolysis reactions.6 Indeed, there have been
many studies on the intramolecular interactions between boron
and nitrogen7 and how such interactions tune complexation
characteristics.8 However, the application of aminoarylboronic
acids as bifunctional catalysts is largely unexplored, with a noted
exception,6 and this has led us to examine the synthesis and
structure of aminoarylboronate systems9 in order to examine
their potential as catalysts for a range of organic transformations,
including the important area of in situ direct amide formation
Results and Discussion
2-N,N′-Diisopropylaminomethyphenylboronic acid is an ex-
ceptional catalyst for the direct amide formation of less reactive
amine-carboxylic acid combinations,10 which is partly ex-
plained by the effect of the hindered diisopropylamino function
that inhibits B-N chelation in both solution and solid states.9b
We therefore wanted to access a planar chiral version of this
system to examine a range of catalytic asymmetric transforma-
tions including acylation processes. Perhaps the most direct
chiral analogue of 2-N,N′-diisopropylaminomethyphenylboronic
acid would be the corresponding ferrocene-based system, i.e.,
2-N,N′-diisopropylaminomethyferrocenylboronic acid, since
the amide derivative had already been reported by Snieckus et
al.,11 and other groups had shown that ferrocenyl-based ami-
noboronate systems have interesting physical and chemical
properties.8d,12
* Corresponding author. Tel: +44 191 334 2081. Fax: +44 191 384
4737. E-mail: andy.whiting@durham.ac.uk.
(1) (a) Zhu, L.; Anslyn, E. V. J. Am. Chem. Soc. 2004, 126, 3676-
3677. (b) Zhu, L.; Zhong, Z.; Anslyn, E. V. J. Am. Chem. Soc. 2005, 127,
4260-4269.
Commercially available ferrocenecarboxaldehyde 1 was
transformed into the diisopropylamide 3 using essentially
literature methods,11a,13 as shown in Scheme 1. Diisopropylamide
3 was then subjected to asymmetric directed ortho-metalation
(2) (a) Norrild, J. C.; Søtofte, I. J. Chem. Soc., Perkin Trans. 2002, 2,
303-311. (b) Orl, A.; Shinkai, S. J. Chem. Soc., Chem. Commun. 1995,
1771-1772.
(3) (a) Ward, C. J.; Patel, P.; James, T. D. J. Chem. Soc., Perkin Trans.
2002, 1, 462-470. (b) Zhao, J.; James, T. D. Chem. Commun. 2005, 1889-
1891.
(9) (a) Giles, R. L.; Howard, J. A. K.; Patrick, L. G. F.; Probert, M. R.;
Smith, G. E.; Whiting, A. J. Organomet. Chem. 2003, 680, 257-262. (b)
Coghlan, S. W.; Giles, R. L.; Howard, J. A. K.; Probert, M. R.; Smith, G.
E.; Whiting, A. J. Organomet. Chem. 2005, 690, 4784-4793. (c) Blatch,
A. J.; Chetina, O. V.; Howard, J. A. K.; Patrick, L. G. F.; Smethurst, C.
A.; Whiting, A. Org. Biomol. Chem. 2006, 4, 3297-3302.
(10) Arnold, K.; Davies, B.; Giles, R. L.; Grosjean, C.; Smith, G. E.;
Whiting, A. AdV. Synth. Catal. 2006, 348, 813-820.
(11) (a) Tsukazaki, M.; Tinkl, M.; Roglans, A.; Chapell, B. J.; Taylor,
N. J.; Snieckus, V. J. Am. Chem. Soc. 1996, 118, 685-686. (b) Metallinos,
C.; Szillat, H.; Taylor, N. J.; Snieckus, V. AdV. Synth. Catal. 2003, 345,
370-382.
(4) Dowlut, M.; Hall, D. G. J. Am. Chem. Soc. 2006, 128, 4226-4227.
(5) Nguyen, B. T.; Wiskur, S. L.; Anslyn, E. V. Org. Lett. 2004, 6, 2499-
2501.
(6) (a) Letsinger, R. L.; Dandegaonker, S. H. J. Am. Chem. Soc. 1959,
81, 498-501. (b) Letsinger, R. L.; MacLean, D. B. J. Am. Chem. Soc. 1963,
85, 2230-2236.
(7) (a) Hawkins, R. T.; Snyder, H. R. J. Org. Chem. 1960, 82, 3863-
3866. (b) Toyota, S.; Futawaka, T.; Asakura, M.; Ikeda, H.; Oki, M.
Organomet. 1998, 17, 4155-4163.
(8) (a) Wiskur, S. L.; Lavigne, J. J.; Ait-Haddou, H.; Lynch, V.; Chiu,
Y. H.; Canary, J. W.; Anslyn, E. V. Org. Lett. 2001, 3, 1311-1314. (b)
Norrild, J. C.; Søtofte, I. J. Chem. Soc., Perkin Trans. 2001, 2, 727-732.
(c) Norrild, J. C. J. Chem. Soc., Perkin Trans. 2001, 2, 719-726. (d)
Bresner, C.; Aldridge, S.; Fallis, I. A.; Jones, C.; Ooi, L.-L. Angew. Chem.,
Int. Ed. 2005, 44, 3606-3609.
(12) (a) Silva, M. E. N. P. R. A.; Pombeiro, A. J. L.; Frau´sto da Silva,
J. J. R.; Herrman, R.; Deus, N.; Bozak, R. E. J. Organomet. Chem. 1994,
480, 81-90. (b) Marr, G.; Moore, R. E.; Rockett, B. W. Tetrahedron Lett.
1968, 2521-2534.
10.1021/om070038l CCC: $37.00 © 2007 American Chemical Society
Publication on Web 03/30/2007

Aminoboronic Acid Ferrocene DeriVatiVes
Organometallics, Vol. 26, No. 9, 2007 2415
Scheme 1. Preparation of the Ferrocenecarboxylic Acid Amide 3
Scheme 2. Directed Metalation to Access Boronates 5 and 6
Scheme 3. Sparteine-Directed Metalation and Amide Reduction to Access (pR)-Bromide 8
Scheme 4. Competing Amide Reduction Providing Both
to give the crystalline pinacol derivative (pR)-5, the crystal
structure of which is shown in Figure 2. The expected11a (pR)-
absolute stereochemistry of the main component of 4 and 5 (as
shown in Figures 1 and 2) has been confirmed by anomalous
X-ray scattering (see Supporting Information).
Amine 10 and Methyl Derivatives 11
The isolation of the amide-boronic acid derivative 4 allowed
us to attempt amide reduction, as developed in the corresponding
benzene series.9b Indeed, this worked well using excess borane
at reflux to provide the desired 2-[N,N′-(diisopropylamino)-
methyl]ferrocenylboronic acid (6), which was also readily
crystallized and subjected to single-crystal X-ray structure
determination (Figure 3). It is noteworthy that the lone electron
pair of the (amino) nitrogen atom is not donated to boron; rather
it accepts an intramolecular hydrogen bond from the boronic
acid moiety. Although this bond, O(2)-H‚‚‚N, is somewhat
weaker in 6 than in the known dimethylamino analogue2a
(O‚‚‚N 2.730(3) vs 2.672(1) Å), it is preferred over B-N
chelation when there are suitably hindering substituents on
nitrogen.9b This preference is entirely as expected from our
previous observations9 and is important for the potential
application of such systems as catalysts and receptors, i.e., by
being able effectively to switch off B-N chelation. This solid-
state structure of 6 is also retained in solution, as indicated by
the 11B NMR signal at δ 32.3, characteristic of the arylboronic
acid function.
Scheme 5. Lithium-Halogen Exchange to Access Boronic
Acid 6 and Formation of the Difluoroborane‚HF Complex 12
using (-)-sparteine, as described by Snieckus,11 to give the
ortho-boronic acid 4 (Scheme 2), the 3D structure of which
was confirmed by X-ray crystallography (Figure 1). Attempts
to determine the enantiomeric excess of 4 using the methods
described11b failed to provide any separation, as did a range of
other chiral HPLC columns. It was, however, possible to verify
the clean formation of the (pR)-boronic acid 4 by esterification
Thus in 6 the boron atom maintains essentially the same
planar trigonal geometry as in 4 and 5. In all three compounds,
the boronate function is approximately coplanar with the
ferrocene ring, forming dihedral angles of 14.9° in 4, 11.9° in
5, and 18.5° in 6. In molecule 4, like in 6, this type of
conformation is stabilized by an intramolecular hydrogen bond,
(13) Neto, A. F.; Miller, J.; Faria de Andrade, V.; Fujimoto, S. Y.; Ma´ısa
de Freitas, A.; Archanjo, F. C.; Darin, V. A.; Andrade e Silva, M. L.; Borges
A. D. L.; Del Ponte, G. Z. Anorg. Allg. Chem. 2002, 628, 209-216.
