On the basis of fluorescent resonance energy transfer from 1,8-naphthalimide to rhodamine B, a new fluorophore dyads (4) containing rhodamine B and a naphthalimide moiety was synthesized as a ratiometric fluorescent probe for detecting Hg²⁺ wit

Full text of DOI:10.1016/j.dyepig.2011.07.020

Dyes and Pigments 92 (2012) 909e915
Contents lists available at ScienceDirect
Dyes and Pigments
journal homepage: www.elsevier.com/locate/dyepig
A naphthalimideerhodamine ratiometric fluorescent probe for Hg2þ based on
fluorescence resonance energy transfer
*
Yunlong Liu, Xin Lv, Yun Zhao, Maliang Chen, Jing Liu, Pi Wang, Wei Guo
School of Chemistry and Chemical Engineering, Shanxi University, Taiyuan 030006, China
a r t i c l e i n f o
a b s t r a c t
Article history:
On the basis of fluorescent resonance energy transfer from 1,8-naphthalimide to rhodamine B, a new
fluorophore dyads (4) containing rhodamine B and a naphthalimide moiety was synthesized as a ratio-
metric fluorescent probe for detecting Hg2þ with a broad pH range 5.7e11.0. The selective fluorescence
response of 4 to Hg2þ is due to the Hg2þ-promoted desulfurization of the thiocarbonyl moiety, leading to
Received 25 June 2011
Received in revised form
24 July 2011
Accepted 25 July 2011
Available online 4 August 2011
the ring-opening of rhodamine B moiety of 4. When 4 was employed at 0.1 mM with the slit size being
20 nm/20 nm, a low level of Hg2þ (up to 3 ꢀ 10ꢁ8 M) can be detected using the system.
Ó 2011 Elsevier Ltd. All rights reserved.
Keywords:
Fluorescent probe
Ratiometric
Naphthalimide
Rhodamine
Desulfurization
Mercury ion
1. Introduction
probe concentration can interfere with the signal output. To elim-
inate those effects, a ratiometric fluorescent measurement is
desirable [10e14]. This technique uses the ratio of the fluorescent
intensities at two different wavelengths, and provides a built-in
correction for environmental effects, and stability under illumina-
tion, allowing precise and quantitative analysis and imaging even in
complicated systems.
Mercury is the third most frequently found and second most
common toxic heavy metal in the list of the Agency for Toxic
Substances and Disease Registry (ATSDR) of the U.S. Department of
Health and Human Services [1,2]. The extreme toxicity of mercury
and its derivatives results from its high affinity for thiol groups
in proteins and enzymes, leading to the dysfunction of cells
and consequently causing health problems [3e5]. Unfortunately,
mercury contamination can occur through a variety of natural and
anthropogenic sources including oceanic and volcanic emissions,
gold mining, and combustion of fossil fuels. Thus, the health
concerns over exposure to mercury have motivated the exploration
of selective and efficient methods for the monitoring of mercury in
biological and environmental samples.
Fluorescence spectroscopy has become a powerful tool for
sensing and imaging trace amounts of species such as metal ions
because of its simplicity and high sensitivity [6e9]. The most
reported fluorescent sensors display an increase or decrease in the
emission intensity upon binding to species of interest. As the
change in fluorescence intensity is the only detection signal, factors
such as instrumental efficiency, environmental conditions, and the
Several signaling mechanisms, such as intramolecular charge
transfer (ICT) [15e18], excimer/exciplex formation [19e22], and
fluorescence resonance energy transfer (FRET) [23e28], can be
employed for the design of ratiometric measurement. Among them,
FRET is a nonradiative energy transfer process in which the exci-
tation energy of the donor is transferred to the nearby acceptor via
long-range dipoleedipole interaction and/or short-range multi-
polar interaction. Although the efficiency of energy transfer is
affected by the distance between the donor and the acceptor as well
as the relative orientation of transition dipoles of both the donor
and acceptor, it is mainly determined by the extent of the spectral
overlap between the donor emission and acceptor absorption [29].
Therefore, it would be possible to fabricate a ratiometric probe
based on the FRET mechanism if a molecule could generate a suit-
able fluorescent energy acceptor by the interaction with target
analyte. In addition, because the pseudo-Stokes shifts of FRET-
based probes are larger than the Stokes shifts of either the donor
or acceptor dyes, thus, the possible self-quenching as well as
fluorescence detection errors due to backscattering effects from the
* Corresponding author. Tel./fax: þ86 351 7011600.
E-mail address: guow@sxu.edu.cn (W. Guo).
0143-7208/$ e see front matter Ó 2011 Elsevier Ltd. All rights reserved.
doi:10.1016/j.dyepig.2011.07.020

910
Y. Liu et al. / Dyes and Pigments 92 (2012) 909e915
excitation source will be efficiently avoided [30]. However, despite
many advantages, examples of the ratiometric fluorescence probes
for Hg2þ based on FRET are considerably limited [31e34].
On the basis of the spirolactam (nonfluorescent) to ring-open
amide (fluorescent) equilibrium of rhodamine, rhodamine-based
dyes have been demonstrated to be excellent OFF/ON-type fluores-
cence probes [35,36]. On the other hand, 1,8-naphthalimide deriva-
tives are excellent fluorophores due to their high stability and
quantum yield as well as convenient functionalization at 4-position or
imine site, and have been widely exploited as fluorescent probes
[37e44]. Recently, two independent energy transfer dyads, both of
which combine the properties of 1,8-naphthalimide and rhodamine
dyes in a donoreacceptor chemical architecture for excited state
energy transfer, were exploited as fluorescence ratiometric and turn-
on probes for Cr3þ [25] and Hg2þ [45], respectively. Inspired by these
results as well as the Hg2þ-induced desulfurization reactions [46e49],
in this paper we hope to report a new naphthalimideerhodamine
ratiometric fluorescent probe for Hg2þ based on FRET. The strategy for
FRET detection of Hg2þ is based on modulating the FRET process in
a fluorophore dyads (4) comprising a 1,8-naphthalimide donor and
a rhodamine-thiosemicarbazide acceptor linked by a rigid phenyl
spacer (Fig. 1). In the absence of Hg2þ, the rhodamine moiety adopts
a closed, non-fluorescent spirolactam form, thus, FRET is suppressed,
and only the yellow emission of the donor is observed upon excitation
Fig. 2. Spectral overlap of the donor 3 emission with the acceptor rhodamine B
absorption.
2.2. Synthesis
of the 1,8-naphthalimide donor. In the presence of Hg2þ, the Hg2þ
-
2.2.1. Compound 4
promoted reaction of thiosemicarbazide to oxadiazole will induce
opening of the rhodamine moiety [46], and produces intense
rhodamine absorption in the 1,8-naphthalimide emission region.
Therefore, excitation of the 1,8-naphthalimide chromophore results in
strong red emission of rhodamine due to FRET.
A solution of 4-morpholin-1,8-naphthalic anhydride (1, 0.1 g,
0.35 mmol) and p-phenylenediamine (0.76 g, 0.70 mmol) in
ethanol (40 mL) was heated under reflux for 24 h. After left to cool,
the precipitated crystals were filtered and washed with ethanol to
give 2 as yellow solid (96 mg, 73%). Mp: 306e308 ꢂC. 1H NMR
(300 MHz, DMSO-d6)
d
8.49 (d, J ¼ 9.0, 1H), 8.44 (d, J ¼ 6.9, 1H), 8.37
(d, J ¼ 8.1, 1H), 7.80 (t, J ¼ 7.8, 1H), 7.35 (d, J ¼ 8.1, 1H), 6.88 (d, J ¼ 7.2,
2H), 6.62 (d, J ¼ 8.1, 2H), 5.19 (b, 2H), 3.90 (b, 4H), 3.21 (b, 4H).
A solution of 2 (0.1 g, 0.26 mmol) in CH2Cl2 (10 mL) was added
2. Experiment
2.1. Materials and general methods
slowly to a solution of thiocarbonyl chloride (75 mL, 0.1 mmol) in
CH2Cl2 (12 mL) and NEt3 (1 mL), and the mixture was stirred for 5 h
at room temperature. Then the reaction mixture was washed with
water, dried over Na2SO4, and evaporated under reduced pressure.
The solid was purified on flash silica gel using CH2Cl2 as eluent to
4-Morpholin-1,8-naphthalic anhydride (1) [50] and rhodamine
B hydrazine [51] were prepared by literature procedures. All other
reagents and solvents were purchased from commercial sources
and were of the highest grade. Solvents were dried according to
standard procedures. All reactions were magnetically stirred and
monitored by thin-layer chromatography (TLC). Flash chromatog-
raphy (FC) was performed using silica gel 60 (230e400 mesh).
Absorption spectra were taken on an Agilent 8453 spectropho-
tometer. Fluorescence spectra were taken on HITACHI F-2500
fluorescence spectrometer. The 1H NMR and 13C NMR spectra were
recorded at 300 and 75 MHz, respectively. The following abbrevi-
ations were used to explain the multiplicities: s ¼ singlet;
d ¼ doublet; t ¼ triplet; q ¼ quartet; m ¼ multiplet; br ¼ broad.
High resolution mass spectra were obtained on a Varian QFT-ESI
mass spectrometer.
give 3 as yellow solid (97 mg, 90%). 1H NMR (300 MHz, CDCl3)
d 8.68
(d, J ¼ 6.9,1H), 8.63 (d, J ¼ 8.1,1H), 8.54 (d, J ¼ 8.4,1H), 7.82 (t, J ¼ 8.1,
1H), 7.46e7.32 (m, 5H), 4.09 (b, 4H), 3.36 (b, 4H).
Fig. 3. Changes in absorption spectra of 4 (10
(10 mM TriseHCl, pH 7.0) with various amounts of Hg2þ ions. Inset: Job’s plot for
determining the stoichiometry of 4 and Hg2þ
mM) in 2:1 (v/v) MeOH/water solution
Fig. 1. The response mechanism of 4 to Hg2þ
.
.

Y. Liu et al. / Dyes and Pigments 92 (2012) 909e915
911
Fig. 4. Fluorescence titration spectra of 4 [10
m
M, 1
mM, and 0.1
m
M for (a), (b) and (c), respectively] in 2:1 (v/v) MeOH/water solution (10 mM TriseHCl, pH 7.0) upon gradual
addition of Hg2þ. Inset: Fluorescence intensity ratio changes (I585/I545) of 4 upon gradual addition of Hg2þ
.
lex ¼ 400 nm. Slits: 10 nm/10 nm for (a), 20 nm/20 nm for (b) and (c).
A
stirred of solution of rhodamine B hydrazide (0.11 g,
(b, 1H), 7.53e7.70 (m, 5H), 7.19e7.28 (m, 4H), 7.05e7.10 (m, 3H),
6.50 (d, J ¼ 8.1, 2H), 6.44 (s, 1H), 6.32 (d, J ¼ 8.1, 2H), 4.02 (b, 4H),
3.27e3.34 (m, 12H), 1.15 (t, J ¼ 6.6, 12H). 13C NMR (75 MHz,
CDCl3): 165.0, 164.6, 156.6, 154.9, 150.8, 150.0, 140.9, 138.5, 135.0,
133.6, 132.7, 132.2, 131.1, 130.9, 129.8, 129.3, 128.3, 126.8, 126.6,
125.4, 124.6, 124.0, 117.7, 115.7, 109.1, 104.8, 99.0, 67.6, 54.1, 46.5,
45.1, 13.3. TOF MS calcd. for (MþH)þ 872.3516, found 872.3539.
0.24 mmol) and compound 3 (0.1 g, 0.24 mmol) in DMF was
heated at 60 ꢂC for 36 h. The solvent was evaporated at reduced
pressure, and the residue was purified on flash gel using CH2Cl2/
MeOH (10:1, v/v) as eluent to give 4 as yellow solid (95 mg, 45%).
Mp: 242e244 ꢂC. 1H NMR (300 MHz, CDCl3)
d 8.50 (m, 4H), 8.01
2.2.2. Compound 5
A mixture of compound 4 (87.2 mg, 0.1 mmol) and Hg(NO3)2$H2O
(34.2 mg, 0.1 mmol) was stirred in MeOH for 10 min at room
temperature. The solvent was evaporated under reduced pressure
and the crude product was purified by column chromatography on
silica gel using CH2Cl2/MeOH (20:1, v/v) as eluent to give 5 as red solid
(77 mg, 91%). 1H NMR (300 MHz, CDCl3):
d 11.14 (b, 1H), 8.40e8.52
(m, 3H), 8.22 (b, 1H), 7.89 (d, J ¼ 8.4, 2H), 7.67 (m, 3H), 7.08e7.27 (m,
6H), 6.72e6.81 (m, 4H), 3.99 (b, 4H), 3.52 (b, 8H), 3.24 (b, 4H), 1.25 (b,
12H). 13C NMR (75 MHz, CDCl3): 165.0, 161.3, 158.9, 156.3, 139.7, 133.6,
132.3, 131.7, 131.2, 131.0, 129.8, 126.8, 124.4, 119.4, 118.1, 115.8, 115.0,
114.7, 97.3, 67.8, 54.3, 46.9, 13.5. TOF MS calcd. for (M)þ 838.3717,
found 838.3722.
2.2.3. Compound 6
Compound 6 was synthesized according to the similar procedure
to compound 4 except that phenyl isothiocyanate was used. 1H NMR
(300 MHz, DMSO-d6)
d 8.03 (d, 1H), 7.66e7.54 (m, 3H), 7.48 (s, 2H),
7.15(d, J ¼ 7.2, 2H), 7.07 (d, J ¼ 2.1, 3H), 6.95(d, J ¼ 3.6,1H), 6.75 (s,1H),
6.48 (m, 3H), 6.31 (s, 1H), 3.33 (q, 8H), 1.15 (t, J ¼ 6.6, 12H). 13C NMR
(75 MHz, CDCl3): 183.2, 167.7, 154.8, 150.7, 149.8, 138.2, 134.8, 129.5,
128.8, 126.6, 125.6, 125.3, 124.4, 108.8, 104.7, 98.8, 67.7, 44.9, 13.1.
Fig. 5. Normalized excitation, absorption and emission spectra of 5 in 2:1 (v/v) MeOH/
water solution (10 mM TriseHCl, pH 7.0). The emission data were collected at 585 nm.
The excitation wavelength is 400 nm.

912
Y. Liu et al. / Dyes and Pigments 92 (2012) 909e915
O
NH2
NCS
O
O
O
CSCl2
CH2Cl2
N
O
N
EtOH, reflux
O
N
O
O
1
N
N
2
3
O
O
O
O
S
NH
NH
N
NH2
NCS
DMF
N
3
Hg(NO3)2
MeOH
5
4
DMF
N
O
N
N
O
6
N
rhodamine B hydrazide
Scheme 1. Synthesis of compounds 4, 5 and control compound 6.
2.3. Procedures of ions sensing
(see: Experimental section). As we know, the spectra overlap is
the main factor that determines the efficiency of FRET. In the
construction of FRET system of 4, 1,8-naphthalimide fluorophore
was chosen as an energy donor because it has strong emission in
the visible range and its broad emission (450e650 nm) covers
a part of rhodamine’s absorption, fulfilling a favorable condition for
FRET (Fig. 2). A 2:1 (v/v) MeOH/water solution (10 mM TriseHCl,
pH 7.0) was selected as a testing system to investigate the chemical
response of 4 to Hg2þ at room temperature (about 20 ꢂC). A time
course of the absorption response of 4 upon addition of Hg2þ
revealed the recognizing event could complete in 10 min, and
remains quite stable from 10 to 50 min. Thus, a reaction time of
10 min was chosen for the present studies.
Deionized water was used throughout all experiments. Solutions
of Ca2þ and Au3þ were prepared from their chloride salts; solutions
of Naþ, Kþ, Agþ, Mg2þ, Cu2þ, Cd2þ, Co2þ, Mn2þ, Ni2þ, Zn2þ, Hg2þ
,
Pb2þ, Cr3þ, and Fe3þ were prepared from their nitrate salts. Solution
of PdCl2 was prepared in 95:5 MeOH/Brine. A stock solution of 4
(1.25 ꢀ10ꢁ2 M) was prepared in DMF. The stock solution of 1 was
then diluted to the corresponding concentration (10 mM and 1 mM)
with the 2:1 (v/v) MeOH/water solution (10 mM TriseHCl, pH 7.0).
The Hg2þ stock solution of 5.0 ꢀ 10ꢁ2 M was diluted to 1.0 ꢀ 10ꢁ2 M,
1.0 ꢀ 10ꢁ3 M and 1.0 ꢀ 10ꢁ4 M with deionized water for spectra
titration studies. In the titration experiments, a 2.5 mL solution of 4
(10 mM and 1 mM) was poured into a quartz optical cell of 1 cm
optical path length each time, and Hg2þ solution was added into the
quartz optical cell gradually by using a micro-pipette. Spectra data
were recorded in an indicated time after the addition.
3.1. UV/Vis titration investigation
The UV/Vis spectrum of 4 showed only the absorption profile of
the donor (1,8-naphthalimide), which has a maximum at 405 nm.
Addition of Hg2þ ions induced an increase in the absorption intensity
at 565 nm (Fig. 3), which corresponds to the absorption of rhodamine.
The absorption stabilized after the amount of added Hg2þ ions
3. Results and discussion
Compound 4 and its ring-opened product 5, as well as a control
compound 6 were efficiently synthesized and well characterized
Fig. 7. Changes in absorption (565 nm) of 4 (10 mM) in 2:1 (v/v) MeOH/water solution
Fig. 6. Fluorescence titration spectra of 4 and 6 (both: 1
m
M) in 2:1 (v/v) MeOH/water
measured with and without Hg2þ (1 equiv) as a function of pH. 4 þ Hg2þ (red), 4
(black). (For interpretation of the references to colour in this figure legend, the reader
is referred to the web version of this article.)
solution (10 mM TriseHCl, pH 7.0) upon addition of Hg2þ (1 equiv). lex ¼ 400 nm. Slits:
20 nm/20 nm.

Y. Liu et al. / Dyes and Pigments 92 (2012) 909e915
913
reached 1 equiv and a significant color change from colorless to red
3.2. Fluorescence titration investigation
could be observed easily by eye, indicating that the addition of Hg2þ
ions can promote the formation of the ring-opened compound 5.
Further evidence for the formation of 5 comes from the independent
synthesis of 5 from 4 by using 1 equiv of Hg(NO3)2 in MeOH at room
temperature (see: Experimental section). Job plot analysis of the
UVeVis titrations revealed a maximum at about 0.5 mole fraction
(Fig. 3, inset), indicating 1:1 binding stoichiometry. Noteworthy is that
in the titration process the 1,8-naphthalimide absorption at 405 nm
was almost unchanged, and the absorption spectrum obtained after
adding 1 equiv Hg2þ ions reflects the presence of the separate 1,8-
naphthalimide and rhodamine B units, indicating that there are
very weak electronic interactions between the donor and the acceptor
in the ground state.
As shown in Fig. 4a, the free 4 (10
m
M) displayed a weak 1,8-
naphthalimide emission band centered at 540 nm when excited at
400 nm (excitation of 1,8-naphthalimide moiety). The weak fluo-
rescence emission of naphthalimide unit of 4 is probably due to
photo-induced electron transfer (PET) from the nitrogen atom of
thiosemicarbazide moiety to the photoexcited naphthalimide
moiety. Upon addition of Hg2þ the 1,8-naphthalimide emission
decreased, and a new emission band centered at 585 (emission of
rhodamine B moiety) appeared and gradually increased in intensity.
The emission intensity stabilized after the amount of added Hg2þ
ions reached 1 equiv with a well-defined isoemission point. The
emission intensities at 585 nm and 545 nm (F585/F545) exhibited
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
a
2+
Hg
0.8
0.6
0.4
0.2
+
Others
Ag
0.0
500
550
600
650
700
Wavelength/nm
300
250
300
250
200
150
100
50
b
2+
Hg
200
150
100
50
0
+
Ag
Others
0
500
550
600
Wavelength/nm
650
700
Fig. 8. The absorption (a) and fluorescence (b) spectra of 4 (10
m
M and 1 m ,
M, respectively) upon addition of 1 equiv of Hg2þ and various other metal ions, including of Naþ, Kþ, Mg2þ
Fe2þ, Fe3þ, Cr3þ, Ca2þ, Zn2þ, Co2þ, Pb2þ, Cd2þ, Ni2þ, Agþ, Au3þ, Pd2þ (10 equiv) and Cu2þ (1 equiv), in 2:1 (v/v) MeOH/water solution (10 mM TriseHCl, pH 7.0). Inset: spectra
response of 4 to Hg2þ containing various metal ions.

914
Y. Liu et al. / Dyes and Pigments 92 (2012) 909e915
a big change from 0.44 in the absence of Hg2þ to 28.7 when the
fluorescence and absorption changes (Fig. 8, inset). In addition,
because the excess of Cu2þ can partly quenches the fluorescence of
4 þ Hg2þ due to its paramagnetic property, thus, only 1 equiv of
Cu2þ was used in the selectivity experiment.
amount of Hg2þ ions added reached 1 equiv of 4. A good linear
working range from 2 to 10 mM was observed in the titration
experiment. In addition, we also measured the sensitivity of 4 for
monitoring the lower concentration of Hg2þ by changing the slit
size. When 4 was employed at 1
20 nm, the good linear working range from 0.3 to 1
(Fig. 4b). Further, when 4 was employed at 0.1 M with the same slit
size (20 nm/20 nm), the good linear working range from 0.03 to
m
M with the slit size being 20 nm/
4. Conclusions
mM is obtainable
m
In summary, we have developed a new ratiometric fluorescent
probe 4 for Hg2þ based on an intramolecular FRET with an excellent
selectivity over other metal ions. It exhibits a clear Hg2þ-induced
change in the intensity ratio of the two emission bands of naph-
thalimide and rhodamine. The selective absorption and fluores-
cence response of 4 is due to the Hg2þ-promoted desulfurization of
the thiocarbonyl moiety, leading to the ring-opening of rhodamine
B moiety of 4. We expect that the method will serve as practical tool
for environmental samples analysis and biological studies.
0.08 mM can still be obtained (Fig. 4c), suggesting a lower level of
Hg2þ can be detected using the system.
It was clear that the FRET process was switched on by Hg2þ ions
as excitation of 1,8-naphthalimide at 400 nm resulted in the
emission of rhodamine with a maximum of 585 nm. This can also
be corroborated by the excitation spectra of the ring-opened
product 5. The excitation spectra obtained by collecting emission
data of 5 at 585 nm shows both the donor and the acceptor bands
with good correspondence with the absorption spectra (Fig. 5),
indicating that both the two transitions participate in the emission
process, and an efficient energy transfer can occur from the 1,8-
naphthalimide donor to the rhodamine acceptor. The efficiency of
energy transfer (EET) was calculated to be 86.3% based on the
Acknowledgments
We would like to thank the Natural Science Foundation of China
(NSFC Nos. 20772073 and 21072121) and the Natural Science
Foundation of Shanxi Province (2008011015-2) for financial
support.
equation [52]: hEET ¼ 1 ꢁ FF(donor in FRET system)
/FF(free donor), in which
hEET is the efficiency of energy transfer, FF(donor in FRET system) is the
fluorescence quantum yields of the donor part in FRET system (1,8-
naphthalimide part in 5 in this investigation), and FF(free donor) is the
fluorescence quantum yields of the donor when not connected to
the acceptor (1,8-naphthalimide part in 4 in this investigation).
Further, to evaluate the role of the 1,8-naphthalimide donor
moiety, a control compound 6 (with the 1,8-naphthalimide group
in 4 being replaced by a phenyl group) was synthesized (Scheme 1)
and its fluorescent response performances were investigated and
compared with that of 4 in the same conditions. The free 6 dis-
played no any emission when excited at 400 nm (excitation of 1,8-
naphthalimide). Upon addition of 1 equiv Hg2þ, only a weaker
emission compared with 4 þ Hg2þ was observed at 585 nm (Fig. 6).
Obviously, the 1,8-naphthalimide donor plays an important role for
FRET of 4 þ Hg2þ. The property is especially important because
a large Stokes shift (185 nm) can be realized in this system, which
can eliminate any influence of excitation backscattering effects on
the fluorescence assay and facilitate the practical application.
References
[1] Patrick L. Mercury toxicity and antioxidants. Part 1. Role of glutathione and
alpha-lipoic acid in the treatment of mercury toxicity. Altern Med Rev 2002;7:
456e71.
[2] US EPA. Regulatory impact analysis of the clean air mercury rule. Final Report.
EPA-452/R-05e003. Research Triangle Park, NC: US EPA; 2005.
[3] Grandjean P, Weihe P, White RF, Debes F. Cognitive performance of children
prenatally exposed to “safe” levels of methylmercury. Environ Res 1998;77:
165e72.
[4] Takeuchi T, Morikawa N, Matsumoto H, Shiraishi Y. A pathological study of
Minamata disease in Japan. Acta Neuropathol 1962;2:40e57.
[5] Harada M. Minamata disease: methylmercury poisoning in Japan caused by
environmental pollution. Crit Rev Toxicol 1995;25:1e25.
[6] Callan JF, de Silva AP, Magri DC. Luminescent sensors and switches in the early
21st century. Tetrahedron 2005;61:8551e88.
[7] Martínez-Máñez R, Sancanón F. Fluorogenic and chromogenic chemosensors
and reagents for anions. Chem Rev 2003;103:4419e76.
[8] Czarnik AW. Chemical communication in water using fluorescent chemo-
sensors. Acc Chem Res 1994;27:302e8.
[9] Kim JS, Quang DT. Calixarene-derived fluorescent probes. Chem Rev 2007;
107:3780e99.
[10] Grynkiewicz G, Poenie M, Tsien RY. A new generation of Ca2þ indicators with
greatly improved fluorescence properties. J Biol Chem 1985;260:3440e50.
[11] Tsien RY, Harootunian AT. Practical design criteria for a dynamic ratio imaging
system. Cell Calcium 1990;11:93e109.
3.3. pH investigation
In addition, to apply 4 in more complicated systems, the spectra
response of 4 in the absence and presence of Hg2þ in different pH
values were evaluated (Fig. 7). Without Hg2þ, no obvious charac-
teristic absorption of rhodamine could be observed for 4 between
pH 5.7 and 11.0. Upon addition of Hg2þ, 4 responded stably to Hg2þ
in the same region without any interference by protons. These
results indicate that 4 successfully react with Hg2þ and allow Hg2þ
detection in a wide pH range.
[12] Coskun A, Akkaya EU. Ion sensing coupled to resonance energy transfer:
a highly selective and sensitive ratiometric fluorescent chemosensor for Ag(I)
by a modular approach. J Am Chem Soc 2005;127:10464e5.
[13] Coskun A, Akkaya EU. Signal ratio amplification via modulation of resonance
energy transfer: proof of principle in an emission ratiometric Hg(II) sensor.
J Am Chem Soc 2006;128:14474e5.
[14] Lin W, Yuan L, Long L, Guo C, Feng J. A fluorescent cobalt probe with a large
ratiometric fluorescence response via modulation of energy acceptor molar
absorptivity on metal ion binding. Adv Funct Mater 2008;18:2366e72.
[15] Xu Z, Qian X, Cui J. Colorimetric and ratiometric fluorescent chemosensor with
a
large red-shift in emission: Cu(II)-only sensing by deprotonation of
secondary amines as receptor conjugated to naphthalimide fluorophore. Org
Lett 2005;7:3029e32.
3.4. Selectivity investigation
[16] Yang H, Liu Z, Zhou Z, Shi E, Li F. Highly selective ratiometric fluorescent
sensor for Cu(II) with two urea groups. Tetrahedron Lett 2006;47:2911e4.
[17] Liu Z, Zhang C, He W, Yang Z, Gao X, Guo Z. A highly sensitive ratiometric
fluorescent probe for Cd2þ detection in aqueous solution and living cells.
Chem Commun 2010;46:6138e40.
[18] Goswami S, Sen D, Das NK. A new highly selective, ratiometric and colori-
metric fluorescence sensor for Cu2þ with a remarkable red shift in absorption
and emission spectra based on internal charge transfer. Org Lett 2010;12:
856e9.
An important feature of 4 is its high selectivity toward the Hg2þ
over the other competitive species. Changes of fluorescence and
UV/Vis spectra of 4 caused by Cu2þ and miscellaneous metal ions
including Naþ, Kþ, Mg2þ, Fe2þ, Fe3þ, Cr3þ, Ca2þ, Zn2þ, Co2þ, Pb2þ
,
Cu2þ, Cd2þ, Ni2þ, Agþ, Au3þ and Pb2þ in 2:1 (v/v) MeOH/water
solution (10 mM TriseHCl, pH 7.0) are recorded in Fig. 8. Most of the
competitive cations, except for Agþ, which had a slight effect, did
not lead to any significant fluorescence and absorption changes in
the visible region. Moreover, in the presence of miscellaneous
competitive metal ions, the Hg2þ ion still resulted in the similar
[19] Kim JS, Choi MG, Song KC, No KT, Ahn S, Chang S-K. Ratiometric determination
of Hg2þ ions based on simple molecular motifs of pyrene and dioxaoctane-
diamide. Org Lett 2007;9:1129e32.
[20] Kim H, Hong J, Hong A, Ham S, Lee J, Kim JS. Cu2þ-induced intermolecular
static excimer formation of pyrenealkylamine. Org Lett 2008;10:1963e6.

Y. Liu et al. / Dyes and Pigments 92 (2012) 909e915
915
[21] Jung H, Park M, Han D, Kim E, Lee C, Kim JS. Cu2þ ion-induced self-assembly of
pyrenylquinoline with a pyrenyl excimer formation. Org Lett 2009;11:3378e81.
[22] Xu Z, Yoon J, Spring DR. A selective and ratiometric Cu2þ fluorescent probe
based on naphthalimide excimeremonomer switching. Chem Commun 2010;
46:2563e5.
[38] Liu B, Tian H. A ratiometric fluorescent chemosensor for fluoride ions based on
a proton transfer signaling mechanism. J Mater Chem 2005;15:2681e6.
[39] Lu ZJ, Wang PN, Zhang Y, Chen JY, Zhen S, Leng B, et al. Tracking of mercury
ions in living cells with a fluorescent chemodosimeter under single- or two-
photon excitation. Anal Chim Acta 2007;597:306e12.
[23] Kim HJ, Park SY, Yoon S, Kim JS. FRET-derived ratiometric fluorescence sensor
[40] Hanaoka K, Muramatsu Y, Urano Y, Terai T, Nagano T. Design and synthesis of
for Cu2þ. Tetrahedron 2008;64:1294e300.
a
highly sensitive off-on fluorescent chemosensor for zinc ions utilizing
[24] Lee SY, Kim HJ, Wu JS, No K, Kim JS. Metal ion-induced FRET modulation in
a bifluorophore system. Tetrahedron Lett 2008;49:6141e4.
internal charge transfer. Chem Eur J 2010;16:568e72.
[41] Huang J, Xu Y, Qian X. A red-shift colorimetric and fluorescent sensor for
Cu2þ in aqueous solution: unsymmetrical 4,5-diaminonaphthalimide with
N-H deprotonation induced by metal ions. Org Biomol Chem 2009;7:
1299e303.
[42] Xu Z, Xiao Y, Qian X, Cui J, Cui D. Ratiometric and selective fluorescent sensor
for Cu2þ based on internal charge transfer (ICT). Org Lett 2005;7:889e92.
[43] Xu Z, Pan J, Spring DR, Cui J, Yoon J. Ratiometric fluorescent and colorimetric
sensors for Cu2þ based on 4,5-disubstituted-1,8-naphthalimide and sensing
cyanide via Cu2þ displacement approach. Tetrahedron 2010;66:1678e83.
[44] Xu Z, Baek KH, Kim HN, Cui J, Qian X, Spring DR, et al. Zn2þ-triggered amide
tautomerization produces a highly Zn2þ-selective, cell-permeable, and ratio-
metric fluorescent sensor. J Am Chem Soc 2010;132:601e10.
[25] Zhou Z, Yu M, Yang H, Huang K, Li F, Yi T, et al. FRET-based sensor for imaging
chromium(III) in living cells. Chem Commun; 2008:3387e9.
[26] Long L, Lin W, Chen B, Gao W, Yuan L. Construction of a FRET-based ratio-
metric fluorescent thiol probe. Chem Commun 2011;47:893e5.
[27] Han ZX, Zhang XB, Li Z, Gong YJ, Wu XY, Jin Z, et al. Efficient fluorescence
resonance energy transfer-based ratiometric fluorescent cellular imaging
probe for Zn2þ using a rhodamine spirolactam as a trigger. Anal Chem 2010;
82:3108e13.
[28] Sun Y, Zhong C, Gong R, Mu H, Fu E. A ratiometric fluorescent chemo-
dosimeter with selective recognition for sulfite in aqueous solution. J Org
Chem 2009;74:7943e6.
[29] Lakowicz JR. Principles of fluorescence spectroscopy. 2nd ed. New York:
Plenum; 1999.
[30] Tolosa L, Nowaczyk K, Lakowicz J. An introduction to laser spectroscopy. 2nd
ed. New York: Kluwer; 2002.
[31] Zhang X, Xiao Y, Qian X. A ratiometric fluorescent probe based on fret for
imaging Hg2þ ions in living cell. Angew Chem Int Ed 2008;47:8025e9.
[32] Shang GQ, Gao X, Chen MX, Zheng H, Xu JG. A novel Hg2þ selective ratiometric
fluorescent chemodosimeter based on an intramolecular FRET mechanism.
J Fluoresc 2008;18:1187e92.
[33] Atilgan S, Ozdemir T, Akkaya EU. Selective Hg(II) sensing with improved
Stokes shift by coupling the internal charge transfer process to excitation
energy transfer. Org Lett 2010;12:4792e5.
[34] Suresh M, Mishra S, Mishra SK, Suresh E, Mandal AK, Shrivastav A, et al.
Resonance energy transfer approach and a new ratiometric probe for Hg2þ in
aqueous media and living organism. Org Lett 2009;11:2740e3.
[35] Kim HN, Lee MH, Kim HJ, Kim JS, Yoon J. A new trend in rhodamine-based
chemosensors: application of spirolactam ring-opening to sensing ions.
Chem Soc Rev 2008;37:1465e72.
[36] Beija M, Afonso CAM, Martinho JMG. Synthesis and applications of rhodamine
derivatives as fluorescent probes. Chem Soc Rev 2009;38:2410e33.
[37] Liu B, Tian H. A selective fluorescent ratiometric chemodosimeter for mercury
ion. Chem Commun; 2005:3156e8.
[45] Kumar M, Kumar N, Bhalla V, Singh H, Sharma PR, Kaur T. Naphthalimide
appended rhodamine derivative: through bond energy transfer for sensing of
Hg2þ ions. Org Lett 2011;13:1422e5.
[46] Yang YK, Yook KJ, Tae J. A rhodamine-based fluorescent and colorimetric
chemodosimeter for the rapid detection of Hg2þ ions in aqueous media. J Am
Chem Soc 2005;127:16760e1.
[47] Zou Q, Tian He. Chemodosimeters for mercury(II) and methylmercury(I) based
on 2,1,3-benzothiadiazole. Sensor Actuator B Chem 2010;149:20e7.
[48] Leng B, Jiang J, Tian H. A mesoporous silica supported Hg2þ chemodosimeter.
AIChE J 2010;56:2957e64.
[49] Guo Z, Zhu W, Zhu M, Wu X, Tian H. Near-infrared cell-permeable Hg2þ
-
selective ratiometric fluorescent chemodosimeters and fast indicator paper
for MeHg2þ based on tricarbocyanines. Chem Eur J 2010;16:14424e32.
[50] Zhou Y, Xiao Y, Chi S, Qian X. Isomeric boron-fluorine complexes with donor-
acceptor architecture: strong solid/liquid fluorescence and large Stokes shift.
Org Lett 2008;10:633e6.
[51] Yang XF, Guo XQ, Zhao YB. Development of a novel rhodamine-type fluo-
rescent probe to determine peroxynitrite. Talanta 2002;57:883e90.
[52] Yu H, Xiao Y, Guo H, Qian X. Convenient and efficient FRET platform featuring
a rigid biphenyl spacer between rhodamine and BODIPY: transformation of
‘turn-on’ sensors into ratiometric ones with dual emission. Chem Eur J 2011;
17:3179e91.
