A 13C and 15N Solid-State NMR Study of Structural Disorder and Aurophilic Bonding in AuI and AuIII Cyanide Complexes

Article abstract of DOI:10.1021/ic8022198

Solid-state nuclear magnetic resonance has been used to study several cyanoaurates. Carbon-13 and nitrogen-15 NMR spectra of samples enriched with isotopically labeled ¹³C, ¹⁵N cyanide ligands were recorded for stationary samples and

Full text of DOI:10.1021/ic8022198

Inorg. Chem. 2009, 48, 2316-2332
13
15
A C and N Solid-State NMR Study of Structural Disorder and
Aurophilic Bonding in AuI and AuIII Cyanide Complexes
Kristopher J. Harris and Roderick E. Wasylishen*
Department of Chemistry, UniVersity of Alberta, Edmonton, Alberta, T6G 2G2, Canada
Received November 19, 2008
Solid-state nuclear magnetic resonance has been used to study several cyanoaurates. Carbon-13 and nitrogen-15
NMR spectra of samples enriched with isotopically labeled 13C,15N cyanide ligands were recorded for stationary
samples and samples spinning at the magic angle. Several salts of the dicyanoaurate(I) anion, M[Au(CN)2], where
M ) n-butylammonium, potassium, and thallium, were studied via solid-state NMR. A gold(III) cyanide, K[Au(CN)4],
was also investigated. Carbon-13 and nitrogen-15 chemical shift tensors are reported for each salt, as are the
measured 13C,15N direct dipolar coupling constants together with the related derived cyanide bond lengths, r(C,N).
The value for r(C,N) in [(n-C4H9)4N][Au(CN)2], 1.17(5) Å, was determined to be more realistic than a previously
reported X-ray diffraction value of 1.03(4) Å. Large 13C NMR line widths from Tl[Au(CN)2], 250-315 Hz, are attributed
to coupling with 197Au (I ) 3/2) and/or 203/205Tl (I ) 1/2), as confirmed by measurements of the transverse relaxation
constant, T2. Investigation of the carbon-13 chemical shifts for cyanide ligands bound to gold involved in a variety
of metallophilic bonding environments demonstrates that the chemical shift is sensitive to metallophilic bonding.
Differences in Au-Tl metallophilic bonding are shown to cause a difference in the isotropic carbon-13 chemical
shift of up to 15.7 ppm, while differences in Au-Au aurophilic bonding are found to be responsible for a change
of up to 5.9 ppm. The disordered polymeric material gold(I) monocyanide, AuCN, was also investigated using 13
C
and 15N SSNMR. Two-dimensional 13C,13C double-quantum dipolar-recoupling spectroscopy was used to probe
connectivity in this material. The 13C NMR site multiplicity in AuCN is explained on the basis of sensitivity of the
carbon-13 chemical shift to aurophilic bonding of the directly bonded gold atom. This assignment allows estimation
of the position of the linear [-M-CN-]∞ chain’s position with respect to the neighboring polymer chain. For the
samples studied, a range of 7 ( 2% to 25 ( 5% of the AuCN chains are found to be “slipped” instead of aligned
with the neighboring chains at the metal position.
1. Introduction
now understood to occur through a relativistic strengthening
of the van der Waals interaction, an increase which can be
enough to rival the energy of a hydrogen bond.6 Much of
the current research on gold compounds focuses on using
aurophilic bonds for controlling supramolecular struc-
tures,5,7-9 or studying the unusual photophysics often
associated with the presence of aurophilic bonds.6,10-12 For
example, recent studies have found that the photoluminesence
Molecules containing gold have been recognized for some
time as having the potential to form an “extra” bond between
closed-shell gold cations, despite the expected Coulombic
repulsion.1-5 While this interaction between heavy, closed-
shell atoms has been assigned a variety of labels, for
convenience we here apply the terms aurophilic, to describe
gold-gold interactions, and metallophilic, to describe the
analogous heteronuclear bonds. Metallophilic interactions are
