Phosphine-Catalyzed [4 þ 2] Annulation
of γ‑Substituent Allenoates:
Facile Access to Functionalized
Spirocyclic Skeletons
Erqing Li, You Huang,* Ling Liang, and Peizhong Xie
State Key Laboratory and Institute of Elemento-Organic Chemistry, Nankai University,
Tianjin 300071, China
hyou@nankai.edu.cn
Received May 15, 2013
ABSTRACT
The first phosphine-catalyzed [4 þ 2] annulation of γ-substituted allenoates with 2-arylidene-1H-indene-1,3(2H)-diones is disclosed. In the
reaction, the γ-substituted allenoate serves as a new type of 1,4-dipolar synthon; this broadens the application of γ-substituted allenoates. This
method also offers a powerful approach to the construction of highly substituted spiro[4.5]dec-6-ene skeletons in excellent yields, and with
complete regioselectivity and high diastereoselectivity.
Spirocyclic skeletons are the structural centerpieces of a
wide variety of natural and synthetic compounds that
exhibit diverse biological activities. Consequently, ap-
proaches to the efficient synthesis of these molecules have
received considerable attention.1
Various methods such as organocatalysis2 and transition-
metal catalysis3 have previously been described in the
literature. However, drawbacks such as unsatisfactory
yields, tedious purification processes, and poor chemo-
and/or diastereoselectivities have restricted the application
of these approaches. The development of novel, straight-
forward, and flexible methods for the preparation of
spirocyclic compounds is therefore highly desirable.
Recently, because of their comparatively strong and
readily tunable nucleophilicities, phosphines have been
used as efficient catalysts in organic synthesis.4,5 A series
(1) (a) Ma, S.; Han, X. Q.; Krishnan, S.; Virgil, S. C.; Stoltz, B. M.
Angew. Chem., Int. Ed. 2009, 48, 8037. (b) Shangary, S. Proc. Natl. Acad.
Sci. U.S.A. 2008, 105, 3933. (c) Schulz, V.; Davoust, M.; Lemarie, M.;
Lohier, J.-F.; Santos, J. S. O.; Metzner, P.; Briere, J.-F. Org. Lett. 2007,
9, 1745. (d) Galliford, C. V.; Scheidt, K. A. Angew. Chem., Int. Ed. 2007,
46, 8748. (e) Franz, A. K.; Dreyfuss, P. D.; Schreiber, S. L. J. Am. Chem.
Soc. 2007, 129, 1020. (f) Ding, K. J. Am. Chem. Soc. 2005, 127, 10130. (g)
Chen, C.; Li, X.; Neumann, C. S.; Lo, M. M. C.; Schreiber, S. L. Angew.
Chem., Int. Ed. 2005, 44, 2249. (h) Lo, M. M. C.; Neumann, C. S.;
Nagayama, S.; Perlstein, E. O.; Schreiber, S. L. J. Am. Chem. Soc. 2004,
126, 16077. (i) Lin, H.; Danishefsky, S. J. Angew. Chem., Int. Ed. 2003,
42, 36. (j) Marti, C.; Carreira, E. M. Eur. J. Org. Chem. 2003, 2209.
(2) (a) Tan, B.; Candeias, N. R.; Barbas, C. F., III. Nat. Chem. 2011,
3, 473. (b) Tan, B.; Candeias, N. R.; Barbas, C. F., III. J. Am. Chem. Soc.
2011, 133, 4672. (c) Tan, B.; Hernandez-Torres, G.; Barbas, C. F., III.
J. Am. Chem. Soc. 2011, 133, 12354. (d) Cao, Y.; Jiang, X.; Liu, L.; Shen,
F.; Zhang, F.; Wang, R. Angew. Chem., Int. Ed. 2011, 50, 9124. (e)
Zhong, F.; Han, X.; Wang, Y.; Lu, Y. Angew. Chem., Int. Ed. 2011, 50,
7837. (f) Jiang, X.; Cao, Y.; Wang, Y.; Liu, L.; Shen, F.; Wang, R. J. Am.
Chem. Soc. 2010, 132, 15328. (g) Bencivenni, G.; Wu, L.-Y.; Mazzanti,
A.; Giannichi, B.; Pesciaioli, F.; Song, M.-P.; Bartoli, G.; Melchiorre, P.
Angew. Chem., Int. Ed. 2009, 48, 7200.
(4) For reviews, see: (a) Cowen, B. J.; Miller, S. J. Chem. Soc. Rev.
2009, 38, 3102. (b) Ye, L.-W.; Zhou, J.; Tang, Y. Chem. Soc. Rev. 2008,
37, 1140. (c) Denmark, S. E.; Beutner, G. L. Angew. Chem., Int. Ed. 2008,
47, 1560. (d) Nair, V.; Menon, R. S.; Sreekanth, A. R.; Abhilash, N.;
Biju, A. T. Acc. Chem. Res. 2006, 39, 520. (e) Lu, X.; Du, Y.; Lu, C. Pure
Appl. Chem. 2005, 77, 1985. (f) Methot, J. L.; Roush, W. R. Adv. Synth.
Catal. 2004, 346, 1035. (g) Valentine, D. H.; Hillhouse, J. H. Synthesis
2003, 317. (h) Lu, X.; Zhang, C.; Xu, Z. Acc. Chem. Res. 2001, 34, 535.
(5) Some example on Domino reactions, see: (a) Yao, C.; Xiao, Z.;
Liu, R.; Li, T.; Jiao, W.; Yu, C. Chem.;Eur. J. 2013, 19, 456. (b) Ma, C.;
Jia, Z.; Liu, J.; Zhou, Q.; Dong, L.; Chen, Y. Angew. Chem., Int. Ed.
2013, 52, 948. (c) Zhou, S.-L.; Li, J.-L.; Dong, L.; Chen, Y.-C. Org. Lett.
2011, 13, 5874.
(3) (a) Hanhan, N. V.; Ball-Jones, N. R.; Tran, N. T.; Franz, A. K.
Angew. Chem., Int. Ed. 2011, 50, 1. (b) Badillo, J. J.; Arevalo, G. E.;
Fettinger, J. C.; Franz, A. K. Org. Lett. 2011, 13, 418. (c) Hojo, D.;
Noguchi, K.; Tanaka, K. Angew. Chem., Int. Ed. 2009, 48, 8129. (d)
Tanaka, K.; Otake, Y.; Sagae, H.; Noguchi, K.; Hirano, M. Angew.
Chem., Int. Ed. 2008, 47, 1312. (e) Trost, B. M.; Cramer, N.; Silverman,
S. M. J. Am. Chem. Soc. 2007, 129, 12396. (c) Basavaiah, D.; Reddy,
K. R. Org. Lett. 2007, 9, 57.
r
10.1021/ol401249e
XXXX American Chemical Society

of named reactions, such as the RauhutꢀCurrier and
MoritaꢀBaylisꢀHillman reactions, have been developed.
Among these significant studies, Lu first reported the
phosphine-catalyzed [3 þ 2] cycloaddition of activated
olefins with 2,3-butadienoate for the construction of var-
ious five-membered carbocyclic compounds and hetero-
cyclic compounds [Scheme 1, (a)].6 In further investiga-
tions, Kwon and Lu independently reported new [2 þ 2 þ 2]
and [2 þ 3] annulations catalyzed by phosphines [Scheme 1,
(b) and (c)].7 At the same time, our group first reported a
novel [1 þ 4] annulation of allenoates and salicyl-N-
thiophosphinylimines using a new bifunctional phos
phine catalyst, (20-hydroxybiphenyl-2-yl)diethylphosphane
(LBBA-1), in which allenoates served as one-carbon
units participating in a domino process [Scheme 1, (d)].8
Based on these pioneering studies, Kwon et al. devel-
oped a phosphine-catalyzed [4 þ 2] cycloaddition of
compounds, further proving its synthetic efficiency.11
However, compared with the significant progress made
with allenoates and R-substituted allenoates, phosphine-
catalyzed domino reactions involving γ-substituted al-
lenoates are rare.12 In 2009, our group reported the first
example of γ-substituted allenoates acting as C2 and C3
synthons in phosphine-catalyzed [4 þ 2] and [3 þ 2]
annulations.12a Recently, Shi et al. and Nair et al. reported
novel phosphine-catalyzed reactions of γ-substituted
allenoates.13 However, to the best of our knowledge,
γ-substituted allenoates acting as a new type of 1,4-dipolar
synthon have not been reported. In this letter, we disclose
the first case of a phosphine-catalyzed [4 þ 2] annulation
of γ-substituted allenoates and activated olefins under
mild conditions (Scheme 1).
Scheme 2. Phosphine-Catalyzed Annulations of γ-Substituent
Allenoates
Scheme 1. Various Pathways for Phosphine-Catalyzed Annu-
lations
In view of our previous study of phosphine-catalyzed
domino reactions of allenoates,14 we initially used
2- benzylidene-1H-indene-1,3(2H)-dione (1a) (0.3 mmol)
and methyl 5-phenyl-2,3-pentadienoate (2a) (0.6 mmol) as
the model substrates and a catalytic amount of PPh3
(30 mol %) as the catalyst at 40 °C in CH2Cl2 to test
the reaction procedure (Scheme 2).12a Unfortunately, this
R-substituted allenoates with imides,9 and subsequent
research has shown that the [4 þ 2] cycloaddition of
R-substituted allenoates with activated olefins or ketones
is also feasible [Scheme 1, (e)].10 Kwon et al. used this
method in the synthesis of natural products and bioactive
(11) (a) Andrews, I. P.; Kwon, O. Chem. Sci. 2012, 3, 2510. (b) Villa,
R. A.; Xu, Q. H.; Kwon, O. Org. Lett. 2012, 14, 4634. (c) Jones, R. A.;
Krische, M. J. Org. Lett. 2009, 11, 1849. (d) Tran, Y. S.; Kwon, O. Org.
Lett. 2005, 7, 4289. (e) Wang, J. C.; Krische, M. J. Angew. Chem., Int. Ed.
2003, 42, 5855.
(12) (a) Meng, X.; Huang, Y.; Zhao, H.; Xie, P.; Ma, J.; Chen, R.
Org. Lett. 2009, 11, 911. (b) Ma, R.; Xu, S.; Tang, X.; Wu, G.; He, Z.
Tetrahedron 2011, 67, 1053. (c) Xu, S.; Zhou, L.; Ma, R.; Song, H.; He,
Z. Chem.;Eur. J. 2009, 15, 8698.
(13) (a) Zhang, X.-C.; Cao, S.-H.; Wei, Y.; Shi, M. Chem. Commun.
2011, 47, 1548. (b) Jose, A.; Lakshmi, K. C. S.; Suresh, E.; Nair, V. Org.
Lett. 2013, 15, 1858.
(6) Zhang, C.; Lu, X. J. Org. Chem. 1995, 60, 2906.
(7) (a) Zhu, X.-F.; Henry, C. E.; Wang, J.; Dudding, T.; Kwon, O.
Org. Lett. 2005, 7, 1387. (b) Lu, Z.; Zheng, S.; Zhang, X.; Lu, X. Org.
Lett. 2008, 10, 3267.
(14) (a) Xie, P.; Li, E.; Zheng, J.; Li, X.; Huang, Y.; Chen, R. Adv.
Synth. Catal. 2013, 355, 161. (b) Yang, L.; Xie, P.; Li, E.; Li, X.; Huang,
Y.; Chen, R. Org. Biomol. Chem. 2012, 10, 7628. (c) Hu, C.; Geng, Z.;
Ma, J.; Huang, Y.; Chen, R. Chem.;Asian J. 2012, 7, 2032. (d) Xie, P.;
Lai, W.; Geng, Z.; Huang, Y.; Chen, R. Chem.;Asian. J. 2012, 7, 1533.
(e) Xie, P.; Huang, Y.; Chen, R. Chem.;Eur. J. 2012, 18, 7362. (f) Xie,
P.; Huang, Y.; Lai, W.; Meng, X.; Chen, R. Org. Biomol. Chem. 2011, 9,
6707. (g) Ma, J.; Xie, P.; Hu, C.; Huang, Y.; Chen, R. Chem.;Eur. J.
2011, 17, 7418. (h) Xie, P.; Huang, Y.; Chen, R. Org. Lett. 2010, 12, 3768.
(i) Meng, X.; Huang, Y.; Chen, R. Chem.;Eur. J. 2008, 14, 6852.
(8) Meng, X.; Huang, Y.; Chen, R. Org. Lett. 2009, 11, 137.
(9) Zhu, X.-F.; Lan, J.; Kwon, O. J. Am. Chem. Soc. 2003, 125, 4716.
(10) (a) Tran, Y. S.; Kwon, O. J. Am. Chem. Soc. 2007, 129, 12632. (b)
Castellano, S.; Fiji, H. D. G.; Kinderman, S. S.; Watanabe, M.; de Leon,
P.; Tamanoi, F.; Kwon, O. J. Am. Chem. Soc. 2007, 129, 5843. (c) Zh,
X.-F.; Schaffner, A.-P.; Li, R. C.; Kwon, O. Org. Lett. 2005, 7, 2977. (d)
Wurz, R. P.; Fu, G. C. J. Am. Chem. Soc. 2005, 127, 12234. (e) Wang, T.;
Ye, S. Org. Lett. 2010, 12, 4168.
